Ford F650 Superduty 2021, F750 Superduty 2021 Owner's Manual

2021 F-650/F-750 Owner’s Manual

owner.ford.com

ford.ca

November 2019

First Printing

Litho in U.S.A.

MC4J 19A321 AA

The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted.

Part Number: 202010 20191025184616

California Proposition 65

WARNING: Operating, servicing and

maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when servicing your vehicle. For more information go to www.P65Warnings.ca.gov/passenger-vehicle.

WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm.

Wash your hands after handling.

Introduction

About This Manual ..........................................7

Symbols Glossary ..........................................10

Data Recording ................................................13

Perchlorate ........................................................17

Ford Credit .........................................................17

Replacement Parts Recommendation

............................................................................17

Special Notices ...............................................18

Mobile Communications Equipment

...........................................................................19

Export Unique Options ...............................20

Federal Highway Administration

Regulation ...................................................20

Entering, Exiting or Climbing on This

Vehicle ...........................................................20

Environment

Protecting the Environment .......................21

Noise Pollution Control ................................21

At a Glance

Instrument Panel ...........................................22

Child Safety

General Information .....................................23

Installing Child Restraints ..........................25

Booster Seats ..................................................31

Child Restraint Positioning ........................33

Child Safety Locks ........................................35

Seatbelts

Principle of Operation .................................36

Fastening the Seatbelts ..............................37

Seatbelt Height Adjustment ....................40

Seatbelt Warning Lamp and Indicator

Chime .............................................................41

Seatbelt Reminder ........................................41

Child Restraint and Seatbelt

Maintenance ...............................................43

Seatbelt Extensions .....................................43

Keys and Remote Controls

General Information on Radio

Frequencies .................................................44

Remote Control .............................................45

Replacing a Lost Key or Remote Control

...........................................................................47

Doors and Locks

Locking and Unlocking ...............................48

Security

Passive Anti-Theft System .......................50

Steering Wheel

Adjusting the Steering Wheel ....................51

Cruise Control - Vehicles With: Adaptive

Cruise Control ..............................................51

Cruise Control - Vehicles With: Cruise

Control ...........................................................52

Information Display Control ......................52

Horn ....................................................................52

Wipers and Washers

Windshield Wipers ........................................53

Windshield Washers ....................................53

Lighting

General Information .....................................54

Lighting Control .............................................54

Autolamps .......................................................55

Instrument Lighting Dimmer ....................55

Headlamp Exit Delay ...................................55

Daytime Running Lamps ...........................56

Automatic High Beam Control ................56

Direction Indicators .......................................57

Interior Lamps .................................................57

Windows and Mirrors

Power Windows ............................................58

Exterior Mirrors ...............................................59

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Interior Mirror ...................................................61

Sun Visors .........................................................61

Instrument Cluster

Gauges ..............................................................62

Warning Lamps and Indicators ...............65

Audible Warnings and Indicators ............68

Information Displays

General Information ....................................69

Information Messages .................................72

Climate Control

Manual Climate Control ..............................77

Hints on Controlling the Interior Climate

...........................................................................78

Heated Exterior Mirrors ...............................79

Seats

Sitting in the Correct Position ..................80

Head Restraints .............................................80

Manual Seats ..................................................82

Power Seats ....................................................83

Rear Seats .......................................................84

Front Seat Armrest .......................................85

Rear Seat Armrest ........................................86

Auxiliary Power Points

Auxiliary Power Points .................................87

Storage Compartments

Overhead Console ........................................89

Starting and Stopping the

Engine

General Information ....................................90

Ignition Switch ...............................................90

Starting a Gasoline Engine .........................91

Starting a Diesel Engine .............................92

Switching Off the Engine ...........................93

Engine Idle Shutdown .................................93

Engine Block Heater ....................................94

Fuel and Refueling

Safety Precautions .......................................95

Fuel Quality - Diesel ....................................96

Fuel Quality - Gasoline ...............................99

Running Out of Fuel - Diesel ..................100

Running Out of Fuel - Gasoline .............100

Refueling - Diesel ........................................100

Refueling - Gasoline ....................................101

Fuel Consumption ......................................102

Fuel Tank Selector Switch .......................104

Engine Emission Control

Emission Law ................................................105

Catalytic Converter .....................................106

Selective Catalytic Reductant System -

Diesel ...........................................................108

Diesel Particulate Filter ...............................112

Transmission

Automatic Transmission ............................118

Power Take-Off ............................................122

Rear Axle

General Information ...................................124

Electronic Locking Differential ................124

2-Speed Rear Axle .......................................125

Brakes

General Information ...................................126

Hints on Driving With Anti-Lock Brakes

..........................................................................127

Parking Brake .................................................127

Hill Start Assist .............................................130

Air Brakes .........................................................131

Exhaust Brake ...............................................132

Trailer Brakes .................................................134

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Table of Contents

Traction Control

Principle of Operation ................................138

Using Traction Control - Vehicles With:

Air Brakes ....................................................138

Using Traction Control - Vehicles With:

Hydraulic Brakes ......................................138

Stability Control

Principle of Operation - Vehicles With:

Hydraulic Brakes .....................................140

Principle of Operation - Vehicles With:

Air Brakes .....................................................141

Using Stability Control ...............................142

Cruise Control - Vehicles With:

Adaptive Cruise Control

Using Adaptive Cruise Control ...............144

Cruise Control - Vehicles With:

Cruise Control

What Is Cruise Control ..............................150

Switching Cruise Control On and Off

.........................................................................150

Setting the Cruise Control Speed .........150

Canceling the Set Speed ..........................150

Resuming the Set Speed ...........................151

Cruise Control Indicators ...........................151

Driving Aids

Driver Alert ......................................................152

Lane Keeping System ................................153

Steering ...........................................................156

Pre-Collision Assist - Vehicles With: Air

Brakes ...........................................................157

Pre-Collision Assist - Vehicles With:

Hydraulic Brakes ......................................159

Load Carrying

Load Limit ......................................................164

Air Suspension ..............................................165

Towing

Towing a Trailer .............................................167

Recommended Towing Weights ...........168

Essential Towing Checks ..........................169

Fifth Wheel Operation ...............................170

Driving Hints

General Driving Points ................................172

Economical Driving ......................................173

Cold Weather Precautions ........................173

Breaking-In .....................................................175

Driving Through Water ...............................176

Roadside Emergencies

Roadside Assistance ...................................177

Hazard Flashers ............................................178

Fuel Shutoff ...................................................178

Jump Starting the Vehicle ........................179

Transporting the Vehicle ............................181

Towing Points ................................................182

Customer Assistance

Getting the Services You Need ...............183

In California (U.S. Only) ............................184

The Better Business Bureau (BBB) Auto

Line Program (U.S. Only) .....................185

Getting Assistance Outside the U.S. and

Canada .......................................................186

Ordering Additional Owner's Literature

.........................................................................187

Reporting Safety Defects (U.S. Only)

.........................................................................187

Reporting Safety Defects (Canada Only)

........................................................................188

Fuses

Fuse Specification Chart ..........................189

Changing a Fuse ...........................................197

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Table of Contents

Vehicle Inspection Guide

Vehicle Inspection Information ..............199

Maintenance

General Information ..................................208

Opening and Closing the Hood ............209

Under Hood Overview - 6.7L Diesel .......211

Under Hood Overview - 7.3L ....................212

Engine Oil Dipstick - 7.3L ...........................213

Engine Oil Dipstick - 6.7L Diesel .............213

Engine Oil Check - 7.3L ..............................213

Engine Oil Check - 6.7L Diesel ................214

Changing the Engine Oil and Oil Filter

.........................................................................215

Oil Change Indicator Reset ......................216

Changing the Engine Air Filter - 6.7L

Diesel ............................................................217

Changing the Engine Air Filter - 7.3L ......219

Draining the Fuel Filter Water Trap - 6.7L

Diesel ............................................................221

Engine Coolant Check - 7.3L ...................222

Engine Coolant Check - 6.7L Diesel ......227

Automatic Transmission Fluid Check

........................................................................232

Brake Fluid Check .......................................233

Power Steering Fluid Check ....................234

Changing the 12V Battery ........................235

Adjusting the Headlamps ........................236

Washer Fluid Check ...................................238

Fuel Filter - 7.3L ...........................................238

Checking the Wiper Blades ....................238

Changing the Wiper Blades ....................238

Removing a Headlamp .............................239

Changing a Bulb ..........................................239

Changing the Engine-Mounted and

Diesel Fuel Conditioner Module Fuel

Filters - 6.7L Diesel .................................240

Electrical System Inspection ..................243

Air Induction System Inspection ...........243

Exhaust System Inspection ....................244

Brake System Inspection .........................244

Axle Inspection ............................................247

Steering System Inspection ...................248

Suspension System Inspection ............248

Frame and Tow Hook Inspection .........249

Rear Axle Fluid Check ...............................249

Spring U-Bolt Check ..................................249

Vehicle Care

General Information ...................................251

Cleaning Products .......................................251

Cleaning the Exterior ..................................251

Waxing ............................................................253

Cleaning the Engine ...................................253

Cleaning the Windows and Wiper Blades

........................................................................253

Cleaning the Interior ..................................254

Cleaning the Instrument Panel and

Instrument Cluster Lens ......................254

Repairing Minor Paint Damage ..............255

Cleaning the Wheels .................................255

Vehicle Storage ...........................................256

Wheels and Tires

Tire Care .........................................................258

Using Snow Chains .....................................273

Changing a Road Wheel ...........................273

Technical Specifications ..........................275

Capacities and Specifications

Engine Specifications - 6.7L Diesel .......277

Engine Specifications - 7.3L ....................278

Motorcraft Parts - 6.7L Diesel ................279

Motorcraft Parts - 7.3L ...............................281

Vehicle Identification Number ...............282

Transmission Code Designation ...........283

Capacities and Specifications - 6.7L

Diesel ..........................................................284

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Table of Contents

Capacities and Specifications - 7.3L

........................................................................293

Bulb Specification Chart ..........................301

Connected Vehicle

Connected Vehicle Requirements .......303

Connected Vehicle Limitations .............303

Connecting the Vehicle to a Mobile

Network .....................................................303

Connected Vehicle – Troubleshooting

........................................................................303

Audio System

General Information ..................................304

Audio Unit .....................................................304

Digital Radio .................................................307

Connecting a Bluetooth Device ............309

Streaming Bluetooth Audio ....................310

Playing Media From a USB Device .......310

Audio Input Jack ..........................................310

USB Port ...........................................................311

Using Voice Recognition ............................312

Accessories

Auxiliary Switches .......................................313

Ford Protect

Ford Protect ...................................................315

Scheduled Maintenance

General Maintenance Information ........317

Normal Scheduled Maintenance ...........321

Special Operating Conditions Scheduled

Maintenance .............................................327

Scheduled Maintenance Record ..........335

Appendices

Electromagnetic Compatibility .............346

End User License Agreement ................348

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Table of Contents

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

ABOUT THIS MANUAL

Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about your vehicle, the greater the safety and pleasure you will get from driving it.

WARNING: Driving while distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

Note: Always use and operate your vehicle in line with all applicable laws and regulations.

Note: Pass on this manual when selling your vehicle. It is an integral part of your vehicle.

Note: Your vehicle’s powertrain control systems can detect and store information about vehicle modifications that increase horsepower and torque output such as whether or not performance-enhancing powertrain components commonly referred to as performance chips have been used. This information will stay in the system’s memory and cannot be erased even if the modification is removed. Ford Motor Company, Ford of Canada, Ford of Mexico and service or repair facilities can retrieve this information when servicing your vehicle. Ford Motor Company may use this information to determine if your warranty covers any needed repairs.

Note: Some aftermarket products may cause severe engine/transmission and/or exhaust system damage; refer to your warranty information for more information.

Your new diesel engine will feel, drive and function somewhat differently than a gasoline engine. Therefore it is very important that you read and thoroughly familiarize yourself and others operating the vehicle with this guide. There is a special procedure for turning off the diesel engine. See Starting a Diesel Engine (page 92). It is important to read and understand this material in order to maintain the best service life for your engine.

Ford may discontinue models or change specifications without any notice and without incurring obligations.

Note: Either Ford Motor Company or an authorized Ford dealer may have originally sold this incomplete vehicle to a vehicle modifier who upfitted it. As a result, some of the options and features on this vehicle may differ from what we describe in this manual.

This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

E154903

Right-hand side.A Left-hand side.B

Warnings

WARNING: Throughout this guide,

you will find warnings identified by the warning symbol. Warnings remind you to be especially careful to reduce the risk of personal injury.

Diesel Engine Information

The diesel engine fuel system is a pressurized two-stage filtration system and consists of:

• A frame-mounted Fuel and Water Separator primary filter with an electric fuel pump and water drain

• An engine-mounted secondary fuel filter

• A fuel injector for each cylinder (8 total)

• A high-pressure fuel pump

• A high-pressure fuel rail for each

cylinder bank (2 total)

• Numerous high-pressure pipes from the high-pressure pump to the rails, and rails to the injectors

The fuel and water separator removes both water and impurities from the fuel. The engine-mounted filter filters finer impurities from the diesel fuel. The engine-mounted fuel filter and the frame-mounted fuel filter should be changed at the recommended service interval or when indicated by the information display LOW FUEL PRESSURE message. See Scheduled Maintenance (page 317).

The fuel and water separator should be drained at regular intervals (recommended at every oil change) or when indicated by the information display and water in fuel indicator light. See Fuel Quality (page

96). Proper fuel filter maintenance and prompt

water draining when the water in fuel light illuminates is essential to prevent injection equipment damage. Ignoring the water in fuel light or the information display message WATER IN FUEL DRAIN FILTER can cause your vehicle to go into a reduced power mode.

A frame-mounted electric fuel pump located inside the fuel and water separator draws fuel from the fuel tank to provide pressurized fuel to the engine. The fuel pump contains a pressure relief valve for overpressure protection in the event of restricted flow.

The fuel injection system is controlled through the powertrain control module.

Engine Protection Mode

Ford diesel engines are equipped with engine protection and emission control systems. These systems monitor critical temperatures and pressures, and modify engine operation accordingly. These modified engine performance characteristics are normal.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

If these modified engine performance characteristics persist for an extended period and either the service engine soon or powertrain malfunction, reduced power, electronic throttle control light is illuminated, have the system checked by an authorized dealer.

Service engine soon

Powertrain malfunction, reduced power, electronic throttle control

Diesel Lubrication System

It is important to change the engine oil at the recommended service intervals or when indicated by the information display to maintain oil viscosity. Extending the oil and filter change interval beyond the recommended interval can negatively affect engine performance, fuel economy and engine life. See Engine Oil Check (page 214).

Engine and secondary cooling system

The cooling system contains a primary cooling loop to cool the engine and a secondary cooling loop to cool the transmission, charge air, and fuel. The coolant serves three primary purposes: to provide heat transfer, freeze point protection, and corrosion protection using additives.

Vehicles with diesel engines typically are used to carry heavy loads and accumulate mileage rapidly. These two factors may cause the additives in the coolant to wear out in a shorter time. You can find more information about coolant additives and coolant change intervals in the coolant chapter. See General Maintenance Information (page 317). Operating the engine with insufficient coolant or coolant additive can cause severe engine damage.

Selective catalytic reduction system

Your vehicle is equipped with a selective catalytic reduction system designed to reduce emission levels of nitrogen oxides from the exhaust of your diesel engine. This system relies on the use of Diesel Exhaust Fluid (DEF) that you must replenish at certain intervals. Failure to maintain proper DEF levels or if the DEF becomes contaminated will result in vehicle speed limitations or result in your vehicle entering an idle-only mode. See Selective

Catalytic Reductant System (page 108).

Minor Troubleshooting Guide

If the engine won’t crank

WARNING: Battery posts,

terminals and related accessories contain lead and lead compounds. Wash hands after handling.

Turn on the headlights. If the lights are dim, do not go on at all or when the ignition is turned to the start position, the lights become dim or go out, the battery connections may be loose or corroded, or the battery may be discharged. If there is a clicking or stuttering sound coming from the engine compartment when you turn the key to the start position, this may also indicate a loose or corroded battery connection.

Check the battery connections at the battery posts, cable connection to the engine grounding point and at the starter connection.

If you suspect a discharged battery, have it checked and corrected.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

• The gearshift lever must be in P (Park) or N (Neutral) in order for the starter to operate.

• Try operating the starter switch several times. This operation may clean potentially corroded contacts or make the switch temporarily operable until you can reach the dealer.

• If all electrical connections are tight and you need assistance to start, See

Jump Starting the Vehicle (page 179).

If engine cranks but won’t start

Prolonged starter cranking (in excess of 10 seconds) could cause damage to the starter motor or the high-pressure fuel pump.

• Check the fuel gauge. You may be out of fuel. If the gauge shows that there is fuel in the tank, the trouble may be in the electrical system or the fuel system. If equipped with an auxiliary tank, be sure that the tank control switch is set for the tank with fuel and not on an empty tank.

• Leaving your ignition key turned to on for over two minutes without starting may make starting difficult because the glow plugs will cease activation. Reset the system by turning the ignition key to off and then back to on again.

Note: If the system is out of fuel and the engine will not start, do not continue cranking the engine. Continued cranking can damage the high-pressure fuel pump.

If the engine runs hot

The following could cause the engine to overheat:

• Lack of coolant

• Dirty cooling system.

• Plugged radiator fins, A/C condenser

and/or oil cooler

• Malfunctioning fan drive

• Driving with frozen coolant

• Sticking thermostat

• Overloading or pulling heavy trailers

during hot weather

• Grill or radiator air blockage

• Slipping or missing drive belt

• Plugged or very dirty air filter

If fuses burn out

WARNING: Replacement fuses and

circuit breakers must always be the same rating as the original equipment shown. Never replace a fuse or circuit breaker with one of a higher rating. Higher rated fuses or circuit breakers could allow circuit overloading in the event of a circuit malfunction, resulting in severe vehicle damage or personal injury due to fire.

Burned-out or blown fuses usually indicate an electrical short-circuit, although a fuse may occasionally burn out from vibration. Insert a second fuse. If this fuse immediately burns out and you cannot locate the cause, return your vehicle to your dealer for a circuit check. See

Changing a Fuse (page 197).

Selective catalytic reduction system speed limit and Idle-only modes

If the vehicle’s speed is limited or in an idle-only mode, the selective catalytic reduction system may be limiting the vehicle’s functions due to low or contaminated DEF. Check the DEF. See

Selective Catalytic Reductant System

(page 108).

SYMBOLS GLOSSARY

These are some of the symbols you may see on your vehicle.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

Air conditioning system

E231157

Air conditioning system lubricant type

Anti-lock braking system

Avoid smoking, flames or sparks

Battery

Battery acid

Brake fluid - non petroleum based

Brake system

E270480

Brake system

Cabin air filter

Check fuel cap

Child safety door lock or unlock

Child seat lower anchor

Child seat tether anchor

E71340

Cruise control

Do not open when hot

Engine air filter

Engine coolant

Engine coolant temperature

Engine oil

Explosive gas

Fan warning

Fasten seatbelt

E231160

Flammable

Front airbag

Front fog lamps

Fuel pump reset

Fuse compartment

Hazard flashers

Heated rear window

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

Windshield defrosting system

Interior luggage compartment release

Jack

Keep out of reach of children

Lighting control

Low tire pressure warning

Maintain correct fluid level

Note operating instructions

E270945

Horn control

Panic alarm

E139213

Parking aid

Parking brake

Power steering fluid

Power windows front/rear

Power window lockout

E231159

Requires registered technician

Safety alert

See Owner's Manual

E231158

See Service Manual

Service engine soon

Passenger airbag activated

Passenger airbag deactivated

Side airbag

Shield the eyes

E138639

Stability control

E163957

Hill descent control

E272858

Trail control

Windshield wiping system

Windshield wash and wipe

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

DATA RECORDING

WARNING: Do not connect

wireless plug-in devices to the data link connector. Unauthorized third parties could gain access to vehicle data and impair the performance of safety related systems. Only allow repair facilities that follow our service and repair instructions to connect their equipment to the data link connector.

We respect your privacy and are committed to protecting it. The information contained in this publication was correct at the time of going to print, but as technology rapidly changes, we recommend that you visit the regional Ford website for the latest information.

Your vehicle has electronic control units that have data recording functionality and the ability to permanently or temporarily store data. This data could include information on the condition and status of your vehicle, vehicle maintenance requirements, events and malfunctions. The types of data that can be recorded are described in this section. Some of the data recorded is stored in event logs or error logs.

Note: Error logs are reset following a service or repair.

Note: We may provide information in response to requests from law enforcement, other government authorities and third parties acting with lawful authority or through a legal process. Such information could be used by them in legal proceedings.

Data recorded includes, for example:

• Operating states of system components, for example, fuel level, tire pressure and battery charge level.

• Vehicle and component status, for example, wheel speed, deceleration, lateral acceleration and seatbelt status.

• Events or errors in essential systems, for example, headlamps and brakes.

• System responses to driving situations, for example, airbag deployment and stability control.

• Environmental conditions, for example, temperature.

Some of this data, when used in combination with other information, for example, an accident report, damage to a vehicle or eyewitness statements, could be associated with a specific person.

Service Data

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company (Ford of Canada in Canada), and service and repair facilities may access or share among them vehicle diagnostic information received through a direct connection to your vehicle when diagnosing or servicing your vehicle. Additionally, Ford Motor Company (Ford of Canada, in Canada) may, where permitted by law, use vehicle diagnostic information for vehicle improvement or with other information we may have about you, for example, your contact information, to offer you products or services that may interest you. Data may be provided to our

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

service providers such as part suppliers that may help diagnose malfunctions, and who are similarly obligated to protect data. We retain this data only as long as necessary to perform these functions or to comply with law. We may provide information where required in response to official requests to law enforcement or other government authorities or third parties acting with lawful authority or court order, and such information may be used in legal proceedings. For U.S. only (if equipped), if you choose to use connected apps and services, you consent that certain diagnostic information may also be accessed electronically by Ford Motor Company and Ford authorized service facilities, and that the diagnostic information may be used to provide services to you, personalizing your experience, troubleshoot, and to improve products and services and offer you products and services that may interest you, where permitted by law. For Canada only, for more information, please review the Ford of Canada privacy policy at www.ford.ca, including our U.S. data storage and use of service providers in other jurisdictions who may be subject to legal requirements in Canada, the United States and other countries applicable to them, for example, lawful requirements to disclose personal information to governmental authorities in those countries.

Event Data

This vehicle is equipped with an event data recorder. The main purpose of an event data recorder is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle; this data assist in understanding how a vehicle’s systems performed. The event data recorder is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less.

The event data recorder in this vehicle is designed to record such data as:

• How various systems in your vehicle were operating;

• Whether or not the driver and passenger seatbelts were buckled/fastened;

• How far (if at all) the driver was depressing the accelerator and/or the brake pedal; and

• How fast the vehicle was traveling; and

• Where the driver was positioning the

steering wheel.

This data can help provide a better understanding of the circumstances in which crashes and injuries occur.

Note: Event data recorder data is recorded by your vehicle only if a non-trivial crash situation occurs; no data is recorded by the event data recorder under normal driving conditions and no personal data or information (e.g., name, gender, age, and crash location) is recorded. However, other parties, such as law enforcement, could combine the event data recorder data with the type of personally identifying data routinely acquired during a crash investigation.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

To read data recorded by an event data recorder, special equipment is required, and access to the vehicle or the event data recorder is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have such special equipment, can read the information if they have access to the vehicle or the event data recorder.

Comfort, Convenience and Entertainment Data

Your vehicle has electronic control units that have the ability to store data based on your personalized settings. The data is stored locally in the vehicle or on devices that you connect to it, for example, a USB drive or digital music player. You can delete some of this data and also choose whether to share it through the services to which you subscribe.

Comfort and Convenience Data

Data recorded includes, for example:

• Seat and steering wheel position.

• Climate control settings.

• Radio presets.

Entertainment Data

Data recorded includes, for example:

• Music, videos or album art.

• Contacts and corresponding address

book entries.

• Navigation destinations.

Services That We Provide

If you use our services, we collect and use data, for example, account information, vehicle location and driving characteristics, that could identify you. We transmit this data through a dedicated, protected connection. We only collect and use data

to enable your use of our services to which you have subscribed, with your consent or where permitted by law. For additional information, see the terms and conditions of the services to which you have subscribed.

Services That Third Parties Provide

We recommend that you review the terms and conditions and data privacy information for any services to which you subscribe. We take no responsibility for services that third parties provide.

Vehicles With a Connectivity Device (If Equipped)

E314755

The connectivity device has a SIM. The connectivity device was

enabled when your vehicle was built and periodically sends messages to stay connected to the cell phone network. These messages could include information that identifies your vehicle, the SIM and the electronic serial number of the connectivity device. Cell phone network service providers could have access to additional information, for example, cell phone network tower identification.

Note: The connectivity device continues to send this information unless you disable the connectivity device. To find out more about having the connectivity device disabled, contact the Ford Customer Relationship Center. Disabling this connectivity device is permanent. See Connected Vehicle (page

303).

If FordPass is connected to your vehicle, Ford also receives additional information, for example, location and vehicle data. See FordPass Terms and Privacy Policy. For additional information about our privacy policy, visit www.FordConnected.com or refer to your local Ford website.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

Note: To stop the connectivity device from

sharing this information, for example, location and vehicle data, see your Connectivity Settings through the FordPass app. You may also remove the vehicle from your FordPass account.

Note: The service can be unavailable or interrupted for a number of reasons, for example, environmental or topographical conditions and data plan coverage.

Note: To find out if your vehicle has a connectivity technology, visit

www.FordConnected.com.

Note: If you plan to no longer use your vehicle, for example, by selling or donating it, remember to remove the vehicle from your FordPass account. If you recently purchased the vehicle and want to disable connectivity, please contact the Ford Customer Relationship Center through the FordPass app or by using the e-mail address on the local Ford website.

Vehicles With SYNC

Mobile Device Data

If you connect a mobile device to your vehicle, you can display data from your device on the touchscreen for example, music and album art. You can share your vehicle data with mobile apps on your device through the system.

The mobile apps function operates by your connected device sending data to us in the United States. The data is encrypted and includes the vehicle identification number of your vehicle, the SYNC module serial number, odometer, enabled apps, usage statistics and debugging information. We retain it only as long as necessary to provide the service, to troubleshoot, for continuous improvement and to offer you products and services that may be of interest to you according to your preferences and where allowed by law.

If you connect a cell phone to the system, the system creates a profile that links to that cell phone. The cell phone profile enables more mobile features and efficient operation. The profile contains, for example, data from your phonebook, read and unread text messages and call history, including history of calls when your cell phone was not connected to the system.

If you connect a media device, the system creates and retains a media device index of supported media content. The system also records a short diagnostic log of approximately 10 minutes of all recent system activity.

The cell phone profile, media device index and diagnostic log remain in your vehicle unless you delete them and are generally accessible only in your vehicle when you connect your cell phone or media device. If you no longer plan to use the system or your vehicle, we recommend you use the master reset function to erase the stored information.

System data cannot be accessed without special equipment and access to your vehicle's module.

For additional information about our privacy policy, refer to your local Ford website.

Note: To find out if your vehicle has a connectivity technology, visit

www.FordConnected.com.

Vehicles With an Emergency Call System

When the emergency call system is active, it may disclose to emergency services that your vehicle has been in a crash involving the deployment of an airbag or activation of the fuel pump shut-off. Certain versions or updates to the emergency call system may also be capable of electronically or verbally disclosing to emergency services operators your vehicle location or other

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

details about your vehicle or crash to assist emergency services operators to provide the most appropriate emergency services. If you do not want to disclose this information, do not activate the emergency call system.

Note: You cannot deactivate emergency call systems that are required by law.

PERCHLORATE

Certain components in your vehicle such as airbag modules, seatbelt pretensioners and remote control batteries may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal.

For more information visit:

Web Address

www.dtsc.ca.gov/hazard-

ouswaste/perchlorate

FORD CREDIT

US Only

Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.

For assistance call 1-800-727-7000, or for more information about Ford Credit and access to the online Account Manager tool, visit www.ford.com/finance.

REPLACEMENT PARTS RECOMMENDATION

We have built your vehicle to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging.

Scheduled Maintenance and Mechanical Repairs

One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this Owner’s Manual. Genuine Ford and Motorcraft parts meet or exceed these specifications.

Collision Repairs

We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development we validate that these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

Warranty on Replacement Parts

Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. The Ford Warranty may not cover damage caused to your vehicle as a result of failed non-Ford parts. For additional information, refer to the terms and conditions of the Ford Warranty.

SPECIAL NOTICES

New Vehicle Limited Warranty

Vehicles sold in the United States and Canada

For a detailed description of what is covered by your New Vehicle Limited Warranty, see your warranty guide that is available online. For more information, refer to our website and download your copy of the warranty guide.

Vehicles sold outside the United States and Canada

For a detailed description of what is covered by your New Vehicle Limited Warranty, see the warranty guide that is provided to you along with your Owner’s Manual.

Special Instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

WARNING: You risk death or serious injury to yourself and others if you do not follow the instruction highlighted by the warning symbol. Failure to follow the specific warnings and instructions could result in personal injury.

WARNING: NEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the CHILD can occur.

On Board Diagnostics Data Link Connector

WARNING: Do not connect

Your vehicle has an OBD Data Link Connector (DLC) that is used in conjunction with a diagnostic scan tool for vehicle diagnostics, repairs and reprogramming services. Installing an aftermarket device that uses the DLC during normal driving for purposes such as remote insurance company monitoring, transmission of vehicle data to other devices or entities, or altering the performance of the vehicle, may cause interference with or even damage to vehicle systems. We do not recommend or endorse the use of unapproved aftermarket plug-in devices. The vehicle Warranty will not cover damage caused by an aftermarket plug-in device.

Notice to Owners of Pickup Trucks and Utility Type Vehicles

WARNING: Utility vehicles have a

significantly higher rollover rate than other types of vehicles.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Using Your Vehicle With a Snowplow

Do not use this vehicle for snowplowing.

Your vehicle does not have a snowplowing package.

Using your Vehicle as an Ambulance

If your light truck has the Ford Ambulance Preparation Package, it may be utilized as an ambulance. Ford urges ambulance manufacturers to follow the recommendations of the Ford Incomplete Vehicle Manual, Ford Truck Body Builder’s Layout Book and the Qualified Vehicle Modifiers (QVM) Guidelines as well as pertinent supplements. For additional information, please contact the Truck Body Builders Advisory Service at http://www.fleet.ford.com/truckbbas/ and then by selecting Contact Us or by phone at 1–877–840–4338.

Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the emissions warranties. In addition, ambulance usage without the preparation package could cause high underbody temperatures, over-pressurized fuel and a risk of spraying fuel, which could lead to fires.

If your vehicle has the Ford Ambulance Preparation Package, it will be indicated on the Safety Compliance Certification Label. The label is on the driver side door pillar or on the rear edge of the driver door. You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer.

MOBILE COMMUNICATIONS EQUIPMENT

WARNING: Driving while

distracted can result in loss of vehicle control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any hand-held device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits. Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

EXPORT UNIQUE OPTIONS

For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this Owner’s Manual. A market unique supplement may be supplied that complements this book. By referring to the market unique supplement, if provided, you can properly identify those features, recommendations and specifications that are unique to your vehicle. This Owner’s Manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for export. Refer to this Owner’s

Manual for all other required information and warnings.

FEDERAL HIGHWAY ADMINISTRATION REGULATION

Regulations such as those issued by the Federal Highway Administration or issued pursuant to the Occupational Safety and Health Act (OSHA), and state and local laws and regulations may require additional equipment for the way you intend to use your vehicle. It is the responsibility of the registered owner to determine the applicability of such laws and regulations to your intended use for the vehicle, and to arrange for the installation of required equipment. The dealer has information about the availability of equipment which can be ordered for your vehicle.

ENTERING, EXITING OR CLIMBING ON THIS VEHICLE

WARNING: Do not carry items

while entering, exiting or climbing. Make sure you keep a firm grip. Always face the vehicle step and handle system while climbing up and down. Do not climb behind the cab unless you have three point contact with a step and handle system at all times.

You must be careful and deliberate to minimize the possibility of personal injury from a slip and fall when entering, exiting or climbing on your vehicle. Always use the steps and assist handles before climbing. Do not skip any steps or assist handles. Use three point contact at all times with at least two feet and one hand or two hands and one foot firmly placed during all phases of entering, exiting or climbing. Always keep your shoe soles and hands clean. Keep the steps and assist handles free of snow, ice, oil, grease, substances or debris. Be sure to take extra care in bad weather. Avoid wearing thick gloves. Always perform trailer hook-up while standing on the ground.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Introduction

PROTECTING THE ENVIRONMENT

You should play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim.

For additional information about our sustainability progress and initiatives, visit

www.sustainability.ford.com.

NOISE POLLUTION CONTROL

In order to keep to the federal exterior noise regulations, your vehicle may be equipped with noise emission items. Depending on your vehicle configuration, it may have all or some of the following items:

Air Intake System

Inspect the air cleaner. Do not alter its location. Do not alter inlet and outlet piping.

Body

Inspect wheel well splash shields, cab shields and under hood insulation for deterioration, dislocation and orientation.

Cooling System

• Inspect the fan for blade damage. If you find any damage, replace with the recommended parts. Inspect for fan-to-shroud interference and any damage to shroud, such as cracks and holes.

• Do not change fan ratio or alter fan spacer dimensions and positions.

• Inspect fan clutch for proper operation. Make sure the fan is disengaged when cooling of the engine is not required.

• Inspect radiator shutters (if equipped) for proper operation. The shutters should be open during normal operating temperatures.

Engine

Valve covers and block covers damp-out engine mechanical noise. If they need replacing, make sure to replace them with the recommended parts. Check for mechanical isolations.

Transmission Enclosure

Inspect for cracks, holes and tears. Clean any deposits, such as oil, dirt and stones.

Exhaust System

• Inspect for leaks at various joint connections and loose clamps.

• Perform a visual inspection for cracks or holes in the muffler and tail pipe.

• Always use the recommended replacement parts.

• Do not change the tail pipe elbow or offset tail pipe orientation from the standard position as originally received.

• To avoid abnormal changes in vehicle sound levels, it is necessary for the owner to perform inspections and necessary maintenance at specified intervals. See Scheduled Maintenance (page 317).

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Environment

INSTRUMENT PANEL

E307565

Direction indicators. See Direction Indicators (page 57). Wiper lever. See Windshield Wipers (page 53).

Information display control. See Information Display Control (page 52).B Instrument cluster. See General Information (page 69).C Gearshift lever. See Automatic Transmission (page 118).D Hazard flasher switch. See Hazard Flashers (page 178).E Audio unit. See Audio System (page 304).F Climate controls. See Climate Control (page 77).G Auxiliary switches. See Auxiliary Switches (page 313).H Ignition. See Ignition Switch (page 90).I Horn.J Steering wheel adjustment. See Adjusting the Steering Wheel (page 51).K Cruise control. See Cruise Control (page 150).L Lighting control. See Lighting Control (page 54).M

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

At a Glance

GENERAL INFORMATION

See the following sections for directions on how to properly use safety restraints for children.

WARNING: Always make sure your child is secured properly in a device that is appropriate for their height, age and weight. Child safety restraints must be bought separately from your vehicle. Failure to follow these instructions and guidelines may result in an increased risk of serious injury or death to your child.

WARNING: All children are shaped differently. The National Highway Traffic Safety Administration and other safety organizations, base their recommendations for child restraints on probable child height, age and weight thresholds, or on the minimum requirements of the law. We recommend that you check with a NHTSA Certified Child Passenger Safety Technician

(CPST) to make sure that you properly install the child restraint in your vehicle and that you consult your pediatrician to make sure you have a child restraint appropriate for your child. To locate a child restraint fitting station and CPST, contact NHTSA toll free at 1-888-327-4236 or go to www.nhtsa.dot.gov. In Canada, contact Transport Canada toll free at 1-800-333-0371 or go to www.tc.gc.ca to find a Child Car Seat Clinic in your area. Failure to properly restrain children in child restraints made especially for their height, age and weight, may result in an increased risk of serious injury or death to your child.

WARNING: On hot days, the temperature inside the vehicle can rise very quickly. Exposure of people or animals to these high temperatures for even a short time can cause death or serious heat related injuries, including brain damage. Small children are particularly at risk.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Child Safety

Recommendations for Safety Restraints for Children

Recommended Restraint

Type

Child Size, Height, Weight, or AgeChild

Use a child restraint

(sometimes called an

infant carrier, convertible

seat, or toddler seat).

Children weighing 40 lb (18 kg) or less

(generally age four or younger).

Infants or

toddlers

Use a belt-positioning

booster seat.

Children who have outgrown or no longer

properly fit in a child restraint (generally

children who are less than 57 in (1.45 m)

tall, are greater than age four and less

than age 12, and between 40 lb (18 kg)

and 80 lb (36 kg) and upward to 100 lb

(45 kg) if recommended by your child

restraint manufacturer).

Small children

Use a vehicle seatbelt having the lap belt snug and low across the hips,

shoulder belt centered

across the shoulder and

chest, and seat backrest

upright.

Children who have outgrown or no longer

properly fit in a belt-positioning booster

seat (generally children who are at least

57 in (1.45 m) tall or greater than 80 lb

(36 kg) or 100 lb (45 kg) if recommended

by child restraint manufacturer).

Larger children

• You are required by law to properly use child restraints for infants and toddlers in the United States and Canada.

• Many states and provinces require that small children use approved booster seats until they reach age eight, a height of 57 in (1.45 m) tall, or 80 lb (36 kg). Check your local and state or provincial laws for specific requirements about the safety of children in your vehicle.

• When possible, always properly restrain children 12 years of age and under in a rear seating position of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position.

• When installing a rear facing child restraint, adjust the vehicle seats to avoid interference between the child restraint and the vehicle seat in front of the child restraint.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Child Safety

INSTALLING CHILD RESTRAINTS

Child Restraints

E142594

Use a child restraint (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers, or children weighing 40 lb (18 kg) or less (generally age four or younger).

Using Lap and Shoulder Belts

WARNING: Do not place a

rearward facing child restraint in front of an active airbag. Failure to follow this instruction could result in personal injury or death.

WARNING: Properly secure children 12 years old and under in a rear seating position whenever possible. If you are unable to properly secure all children in a rear seating position, properly secure the largest child on the front seat. If you must use a forward facing child restraint on the front seat, move the seat as far back as possible. Failure to follow these instructions could result in personal injury or death.

WARNING: Depending on where you secure a child restraint, and depending on the child restraint design, you may block access to certain seatbelt buckle assemblies and LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, make sure occupants only use seating positions where they are able to be properly restrained.

When installing a child restraint with combination lap and shoulder belts:

• Use the correct seatbelt buckle for that seating position.

• Insert the belt tongue into the proper buckle until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle.

• Keep the buckle release button pointing up and away from the child restraint, with the tongue between the child restraint and the release button, to prevent accidental unbuckling.

• Place the vehicle seat upon which the child restraint will be installed in the upright position.

• This vehicle does not require the use of a locking clip.

Perform the following steps when installing the child restraint with combination lap and shoulder belts:

Note: Although the child restraint illustrated is a forward facing child restraint, the steps are the same for installing a rear facing child restraint.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Child Safety

E142528

1. Position the child restraint in a seat with a combination lap and shoulder belt.

E142529

2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.

E142530

3. While holding the shoulder and lap belt portions together, route the tongue through the child restraint according to the child restraint manufacturer's instructions. Be sure the belt webbing is not twisted.

E142531

4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.

E142875

5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until you pull all of the belt out.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Child Safety

6. Allow the belt to retract to remove slack. The belt clicks as it retracts to indicate it is in the automatic locking mode.

7. Try to pull the belt out of the retractor to make sure the retractor is in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6.

E142533

8. Remove remaining slack from the belt. Force the seat down with extra weight, for example, by pressing down or kneeling on the child restraint while pulling up on the shoulder belt in order to force slack from the belt. This is necessary to remove the remaining slack that exists once you add the extra weight of the child to the child restraint. It also helps to achieve the proper snugness of the child restraint to your vehicle. Sometimes, a slight lean toward the buckle helps to remove remaining slack from the belt.

9. Attach the tether strap (if the child restraint is equipped).

E142534

10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place.

To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 in (2.5 cm) of movement for proper installation.

We recommend checking with a NHTSA Certified Child Passenger Safety Technician to make certain the child restraint is properly installed. In Canada, check with Transport Canada for referral to a Child Car Seat Clinic.

Using Cinch Tongue Lap and Shoulder Belts (All Front Center, Super Cab and Crew Cab Rear Center Positions)

WARNING: Do not place a

rearward facing child restraint in front of an active airbag. Failure to follow this instruction could result in personal injury or death.

F650750 (TBC) , enUSA, Edition date: 202010, First-Printing

Child Safety

+ 353 hidden pages
