Ford E 350 2015, E 450 2015 Owner's Manual
fordowner.com ford.ca
2015 E-SERIES Owner’s Manual
2015 E-SERIES Owner’s Manual
December 2014
Second Printing
Owner’s Manual
E-Series
Litho in U.S.A.
FC2J 19A321 AA
Table of Contents 1
Introduction 7
Child Safety 16
Child seat positioning ...................................18
Booster seats .........................................19
Installing child seats ....................................22
Safety Belts 28
Fastening the safety belts ................................30
Safety belt height adjustment .............................33
Safetybeltwarninglightandindicatorchime..................33
Safety belt-minder .....................................34
Child restraint and safety belt maintenance ...................35
Supplementary Restraints System 36
Driver and passenger airbags .............................38
Crash sensors and airbag indicator .........................44
Airbag disposal........................................45
Keys and Remote Control 46
General information on radio frequencies.....................46
Remote control .......................................46
Replacing a lost key or remote control.......................48
Locks 49
Locking and unlocking ..................................49
Security 52
SecuriLock® passive anti-theft system.......................52
Steering Wheel 55
Adjusting the steering wheel ..............................55
Wipers and Washers 56
Windshield wipers .....................................56
Windshield washers ....................................56
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
2 Table of Contents
Lighting 58
Lighting control .......................................58
Instrument lighting dimmer...............................59
Daytime running lamps ..................................59
Turn signal control .....................................60
Interior lamps ........................................60
Windows and Mirrors 61
Power windows .......................................61
Exteriormirrors.......................................61
Interiormirrors .......................................64
Sunvisors...........................................65
Instrument Cluster 66
Gauges .............................................66
Warning lamps and indicators .............................67
Audible warnings and indicators ...........................71
Information Displays 72
Controls.............................................72
Information messages ...................................76
Climate Control 79
Manual heating and air conditioning ........................79
Seats 83
Sitting in the correct position .............................83
Head restraints........................................84
Manual seats .........................................84
Power seats ..........................................86
Auxiliary Power Points 87
Starting and Stopping the Engine 90
Ignition switch ........................................90
Engine block heater ....................................93
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Table of Contents 3
Fuel and Refueling 95
Fuel quality ..........................................96
Running out of fuel ....................................97
Refueling............................................98
Fuel consumption......................................99
Transmission 104
Transmission operation .................................104
Brakes 109
Brakes .............................................109
Hints on driving with anti-lock brakes ......................110
Parking brake........................................110
Traction Control 111
TractionControl™....................................111
Cruise Control 112
Using cruise control ...................................112
Driving Aids 114
Steering ............................................114
Load Carrying 115
Vehicle loading .......................................115
Towing 122
Trailertowing........................................122
Trailer brake controller-integrated .........................127
Wrecker towing ......................................133
Recreational towing ...................................134
Driving Hints 135
Economical driving ....................................137
Floormats..........................................139
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
4 Table of Contents
Roadside Emergencies 141
Getting roadside assistance ..............................141
Hazard flasher control..................................143
Fuel pump shut-off ....................................143
Jump-starting the vehicle ...............................144
Customer Assistance 147
Reporting safety defects (U.S. only) .......................154
Reporting safety defects (Canada only) .....................154
Fuses 155
Changing a fuse ......................................155
Fuse specification chart ................................156
Maintenance 164
General information ...................................164
Opening and closing the hood ............................165
Under hood overview ..................................166
Engine oil dipstick ....................................167
Engine oil check......................................167
Engine coolant check ..................................168
Automatic transmission fluid check ........................172
Brake fluid check .....................................179
Power steering fluid check ..............................179
Fuel filter...........................................180
Washer fluid check ....................................181
Changing the vehicle battery .............................181
Checking the wiper blades ..............................183
Changing the wiper blades ..............................184
Air filter(s) .........................................184
Adjusting the headlamps ................................185
Changing a bulb ......................................189
Removing a headlamp ..................................189
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Table of Contents 5
Vehicle Care 194
Cleaning products.....................................194
Cleaning the exterior ..................................194
Waxing.............................................196
Repairing minor paint damage ............................196
Cleaning the engine ...................................196
Cleaning the windows and wiper blades .....................197
Cleaning the interior ...................................198
Cleaning the instrument panel and instrument cluster lens .......198
Cleaning leather seats ..................................199
Cleaning the alloy wheels ...............................200
Vehiclestorage.......................................201
Wheels and Tires 204
Tire care ...........................................206
Using snow chains ....................................224
Tire Pressure Monitoring System (TPMS) ...................225
Changing a road wheel .................................232
Technical specifications.................................239
Wheel lug nut torque ..................................239
Capacities and Specifications 241
Engine specifications ..................................241
Engine drivebelt ......................................241
Part numbers ........................................248
Vehicle identification number ............................249
Vehicle certification label ...............................250
Transmission code designation............................250
Accessories 251
Accessories .........................................251
Upfitter controls ......................................252
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
6 Table of Contents
Extended Service Plan 254
Audio System 257
AM/FMstereo........................................259
AM/FM/CD with SYNC .................................260
Satellite radio information ...............................262
Auxiliary input jack ...................................265
USB port ...........................................266
SYNC® 268
Pairing your phone for the first time .......................273
911 Assist™ .........................................288
Vehicle Health Report ..................................290
Appendices 319
Scheduled Maintenance 329
Normal scheduled maintenance and log .....................334
Index 345
The information contained in this publication was correct at the time of going to
print. In the interest of continuous development, we reserve the right to change
specifications, design or equipment at any time without notice or obligation.
No part of this publication may be reproduced, transmitted, stored in a retrieval
system or translated into any language in any form by any means without our
written permission. Errors and omissions excepted.
© Ford Motor Company 2014
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Introduction 7
ABOUT THIS MANUAL
Thank you for choosing Ford. We recommend that you take some time to
get to know your vehicle by reading this manual. The more that you
know about it, the greater the safety and pleasure you will get from
driving it.
WARNING: Always drive with due care and attention when
using and operating the controls and features on your vehicle.
Note: This manual describes product features and options available
throughout the range of available models, sometimes even before they
are generally available. It may describe options not fitted to your vehicle.
Note: Some of the illustrations in this manual may show features as used
in different models, so may appear different to you on your vehicle.
However, the essential information in the illustrations is always correct.
Note: Always use and operate your vehicle in line with all applicable
laws and regulations.
Note: Pass on this manual when selling your vehicle. It is an integral
part of the vehicle.
Note:This vehicle was sold as an incomplete vehicle by Ford Motor
Company or an authorized Ford dealer and may have since been upfitted
by a vehicle modifier. As a result, some of the options and features on
this vehicle may differ from what we describe in this manual.
This manual may qualify the location of a component as left-hand side or
right-hand side. The side is determined when facing forward in the seat.
A
A. Right-hand side
B. Left-hand side
B
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
8 Introduction
Protecting the Environment
You must play your part in protecting the environment. Correct
vehicle usage and the authorized disposal of waste, cleaning
and lubrication materials are significant steps toward this aim.
SYMBOL GLOSSARY
These are some of the symbols you may see on your vehicle.
Symbol Description Symbol Description Symbol Description
Safety alert See Owner’s
Manual
Avoid
smoking,
flames, or
sparks
Brake fluid –
non
petroleum
base
Check fuel
cap
Child seat
tether
anchor
Engine air
filter
Engine oil Explosive
Battery Battery acid
Brake
system
Child Safety
Door Lock
and Unlock
Cruise
control
Engine
coolant
gas
Anti-lock
braking
system
Cabin air
filter
Child seat
lower anchor
Do not open
when hot
Engine
coolant
temperature
Fan warning
Fasten
safety belt
Front airbag Front fog
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
lamps
Introduction 9
Symbol Description Symbol Description Symbol Description
Fuel pump
reset
Heated rear
window
Lighting
control
Panic alarm Parking aid
Fuse
compartment
Interior
luggage
compartment
release
Low tire
pressure
warning
system
Hazard
warning
flasher
Jack
Maintain
correct fluid
level
Parking
brake system
Power
steering fluid
Service
engine soon
Windshield
defrost and
demist
DATA RECORDING
Service Data Recording
Service data recorders in your vehicle are capable of collecting and
storing diagnostic information about your vehicle. This potentially
includes information about the performance or status of various systems
and modules in the vehicle, such as engine, throttle, steering or brake
systems. In order to properly diagnose and service your vehicle, Ford
Motor Company, Ford of Canada, and service and repair facilities may
access or share among them vehicle diagnostic information received
through a direct connection to your vehicle when diagnosing or servicing
your vehicle. Additionally, when your vehicle is in for service or repair,
Ford Motor Company, Ford of Canada, and service and repair facilities
Power
windows
front and
rear
Side airbag Stability
Windshield
washer and
wiper
Power
window
lockout
control
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
10 Introduction
may access or share among them data for vehicle improvement purposes.
For U.S. only (if equipped), if you choose to use the SYNC® Vehicle
Health Report, you consent that certain diagnostic information may also
be accessed electronically by Ford Motor Company and Ford authorized
service facilities, and that the diagnostic information may be used for any
purpose. See the SYNC® chapter for more information.
Event Data Recording
This vehicle is equipped with an event data recorder (EDR). The
main purpose of an EDR is to record, in certain crash or near
crash-like situations, such as an airbag deployment or hitting a
road obstacle; this data will assist in understanding how a
vehicle’s systems performed. The EDR is designed to record data
related to vehicle dynamics and safety systems for a short period
of time, typically 30 seconds or less. The EDR in this vehicle is
designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were
buckled/fastened;
• How far (if at all) the driver was depressing the accelerator
and/or the brake pedal;
• How fast the vehicle was travelling;
• Where the driver was positioning the steering wheel.
This data can help provide a better understanding of the
circumstances in which crashes and injuries occur.
Note: EDR data is recorded by your vehicle only if a non-trivial
crash situation occurs; no data is recorded by the EDR under
normal driving conditions and no personal data or information
(e.g., name, gender, age, and crash location) is recorded (see
limitations regarding 911 Assist and Traffic, Directions and
Information privacy below). However, parties, such as law
enforcement, could combine the EDR data with the type of
personally identifying data routinely acquired during a crash
investigation.
To read data recorded by an EDR, special equipment is required,
and access to the vehicle or the EDR is needed. In addition to the
vehicle manufacturer, other parties, such as law enforcement,
that have such special equipment, can read the information if
they have access to the vehicle or the EDR. Ford Motor Company
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Introduction 11
and Ford of Canada do not access event data recorder
information without obtaining consent, unless pursuant to court
order or where required by law enforcement, other government
authorities or other third parties acting with lawful authority.
Other parties may seek to access the information independently
of Ford Motor Company and Ford of Canada.
Note: Including to the extent that any law pertaining to Event
Data Recorders applies to SYNC® or its features, please note the
following: Once 911 Assist (if equipped) is enabled (set ON), 911
Assist may, through any paired and connected cell phone, disclose
to emergency services that the vehicle has been in a crash
involving the deployment of an airbag or, in certain vehicles, the
activation of the fuel pump shut-off. Certain versions or updates
to 911 Assist may also be capable of being used to electronically
or verbally provide to 911 operators the vehicle location (such as
latitude and longitude), and/or other details about the vehicle or
crash or personal information about the occupants to assist 911
operators to provide the most appropriate emergency services.
If you do not want to disclose this information, do not activate
the 911 Assist feature. See your SYNC® chapter for more
information.
Additionally, when you connect to Traffic, Directions and
Information (if equipped, U.S. only), the service uses GPS
technology and advanced vehicle sensors to collect the vehicle’s
current location, travel direction, and speed (“vehicle travel
information”), only to help provide you with the directions,
traffic reports, or business searches that you request. If you do
not want Ford or its vendors to receive this information, do not
activate the service. For more information, see Traffic, Directions
and Information, Terms and Conditions. See your SYNC® chapter
for more information.
CALIFORNIA PROPOSITION 65
WARNING: Some constituents of engine exhaust, certain vehicle
components, certain fluids contained in vehicles and certain
products of component wear contain or emit chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
12 Introduction
PERCHLORATE MATERIAL
Note: Certain components in your vehicle, such as airbag modules,
safety belt pretensioners, and remote control batteries, may contain
perchlorate material. Special handling may apply for service or vehicle
end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate for
more information.
FORD CREDIT (U.S. ONLY)
Ford Credit offers a full range of financing and lease plans to help you
acquire your vehicle. If you have financed or leased your vehicle through
Ford Credit, thank you for your business.
For your convenience, we offer a number of ways to contact us, as well
as help manage your account.
Phone: 1-800-727-7000
For more information regarding Ford Credit, as well as access to
Account Manager, please go to www.fordcredit.com.
REPLACEMENT PARTS RECOMMENDATION
Your vehicle has been built to the highest standards using quality parts.
We recommend that you demand the use of genuine Ford and Motorcraft
parts whenever your vehicle requires scheduled maintenance or repair.
You can clearly identify genuine Ford and Motorcraft parts by looking
for the Ford, FoMoCo or Motorcraft branding on the parts or their
packaging.
Scheduled Maintenance and Mechanical Repairs
One of the best ways for you to make sure that your vehicle provides
years of service is to have it maintained in line with our
recommendations using parts that conform to the specifications detailed
in this owner’s manual. Genuine Ford and Motorcraft parts meet or
exceed these specifications.
Collision Repairs
We hope that you never experience a collision, but accidents do happen.
Genuine Ford replacement collision parts meet our stringent
requirements for fit, finish, structural integrity, corrosion protection and
dent resistance. During vehicle development, we validate that these parts
deliver the intended level of protection as a whole system. A great way
to know for sure you are getting this level of protection is to use genuine
Ford replacement collision parts.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Introduction 13
Warranty on Replacement Parts
Genuine Ford and Motorcraft replacement parts are the only
replacement parts that benefit from a Ford Warranty. Damage caused to
your vehicle as a result of the failure of non-Ford parts may not be
covered by the Ford Warranty. For additional information, see the terms
and conditions of the Ford Warranty.
SPECIAL NOTICES
New Vehicle Limited Warranty
For a detailed description of what is covered and what is not covered
by your vehicle’s New Vehicle Limited Warranty, see the warranty
information that is provided to you along with your owner’s manual.
Special Instructions
For your added safety, your vehicle is fitted with sophisticated electronic
controls.
WARNING: Please read the Supplementary Restraints System
chapter. Failure to follow the specific warnings and instructions
could result in personal injury.
WARNING: Front seat mounted rear-facing child or infant seats
should NEVER be placed in front of an active passenger airbag.
Notice to owners of pickup trucks and utility type vehicles
WARNING: Utility vehicles have a significantly higher rollover
rate than other types of vehicles.
Before you drive your vehicle, please read this Owner’s Manual carefully.
Your vehicle is not a passenger car. As with other vehicles of this type,
failure to operate your vehicle correctly may result in loss of vehicle
control, vehicle rollover, personal injury or death.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
14 Introduction
Using your vehicle as an ambulance
If your light truck is equipped with the Ford Ambulance Preparation
Package, it may be utilized as an ambulance. Ford urges ambulance
manufacturers to follow the recommendations of the Ford Incomplete
Vehicle Manual, Ford Truck Body Builder’s Layout Book and the
Qualified Vehicle Modifiers (QVM) Guidelines as well as pertinent
supplements. For additional information, please contact the Truck Body
Builders Advisory Service at http://www.fleet.ford.com/truckbbas/ and
then by selecting “Contact Us” or by phone at 1–877–840–4338.
Use of your Ford light truck as an ambulance, without the Ford
Ambulance Preparation Package voids the Ford New Vehicle Limited
Warranty and may void the Emissions Warranties. In addition, ambulance
usage without the preparation package could cause high underbody
temperatures, overpressurized fuel and a risk of spraying fuel which
could lead to fires.
If your vehicle is equipped with the Ford Ambulance Preparation
Package, it will be indicated on the Safety Compliance Certification
Label. The label is located on the driver’s side door pillar or on the rear
edge of the driver’s door. You can determine whether the ambulance
manufacturer followed Ford’s recommendations by directly contacting
that manufacturer.
MOBILE COMMUNICATIONS EQUIPMENT
Using mobile communications equipment is becoming increasingly
important in the conduct of business and personal affairs. However, you
must not compromise your own or others’ safety when using such
equipment. Mobile communications can enhance personal safety and
security when appropriately used, particularly in emergency situations.
Safety must be paramount when using mobile communications
equipment to avoid negating these benefits.
Mobile communication equipment includes, but is not limited to, cellular
phones, pagers, portable email devices, text messaging devices and
portable two-way radios.
WARNING: Driving while distracted can result in loss of vehicle
control, crash and injury. We strongly recommend that you use
extreme caution when using any device that may take your focus off
the road. Your primary responsibility is the safe operation of your
vehicle. We recommend against the use of any handheld device while
driving and encourage the use of voice-operated systems when possible.
Make sure you are aware of all applicable local laws that may affect the
use of electronic devices while driving.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Introduction 15
EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION
For your particular global region, your vehicle may be equipped with
features and options that are different from the features and options that
are described in this owner’s manual. A market unique supplement may
be supplied that complements this book. By referring to the market
unique supplement, if provided, you can properly identify those features,
recommendations and specifications that are unique to your vehicle. This
owner’s manual is written primarily for the U.S. and Canadian Markets.
Features or equipment listed as standard may be different on units built
for Export. See this owner’s manual for all other required
information and warnings.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
16 Child Safety
GENERAL INFORMATION
See the following sections for directions on how to properly use safety
restraints for children.
WARNING: Always make sure your child is secured properly in a
device that is appropriate for their height, age and weight. Child
safety restraints must be bought separately from your vehicle. Failure
to follow these instructions and guidelines may result in an increased
risk of serious injury or death to your child.
WARNING: All children are shaped differently. The
recommendations for safety restraints are based on probable
child height, age and weight thresholds from NHTSA and other safety
organizations, or are the minimum requirements of law. Ford
recommends checking with a NHTSA Certified Child Passenger Safety
Technician (CPST) and consulting your pediatrician to make sure your
child seat is appropriate for your child, and is compatible with and
properly installed in your vehicle. To locate a child seat fitting station
and CPST, contact the NHTSA toll free at 1-888-327-4236 or on the
internet at http://www.nhtsa.dot.gov. In Canada, check with your local
St. John Ambulance office for referral to a CPST or for further
information, contact your provincial ministry of transportation, or locate
your local St. John Ambulance office by searching for St. John
Ambulance on the internet, or Transport Canada at 1–800–333–0371
(http://www.tc.gc.ca). Failure to properly restrain children in safety
seats made especially for their height, age, and weight may result in an
increased risk of serious injury or death to your child.
WARNING: Do not leave children or animals unattended in the
vehicle. On hot days, the temperature in the trunk or vehicle
interior can rise very quickly. Exposure of people or animals to these
high temperatures for even a short time can cause death or serious
heat-related injuries, including brain damage. Small children are
particularly at risk.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 17
Recommendations for Safety Restraints for Children
Child size, height, weight, or
age
Infants
or
toddlers
Small
children
Larger
children
• You are required by law to properly use safety seats for infants and
toddlers in the U.S. and Canada.
• Many states and provinces require that small children use approved
booster seats until they reach age eight, a height of 4 feet 9 inches
(1.45 meters) tall, or 80 pounds (36 kilograms). Check your local and
state or provincial laws for specific requirements about the safety of
children in your vehicle.
• When possible, always properly restrain children twelve (12) years of
age and under in a rear seating position of your vehicle. Accident
statistics suggest that children are safer when properly restrained in
the rear seating positions than in a front seating position. See
Passenger Airbag ON and OFF Switch in the Supplemental Restraints
System chapter for more information.
Children weighing 40 lb (18 kg)
or less (generally age four or
younger).
Children who have outgrown or no
longer properly fit in a child safety
seat (generally children who are
less than 4 ft. 9 in. (1.45 m) tall,
are greater than age four (4) and
less than age twelve (12), and
between 40 lb (18 kg) and 80 lb
(36 kg) and upward to 100 lb
(45 kg) if recommended by your
child restraint manufacturer).
Children who have outgrown or
no longer properly fit in a
belt-positioning booster seat
(generally children who are at least
4 ft. 9 in. (1.45 m) tall or greater
than 80 lb (36 kg) or 100 lb
(45 kg) if recommended by child
restraint manufacturer).
Recommended
restraint type
Use a child safety seat
(sometimes called an
infant carrier,
convertible seat, or
toddler seat).
Use a belt-positioning
booster seat.
Use a vehicle safety belt
having the lap belt snug
and low across the hips,
shoulder belt centered
across the shoulder and
chest, and seat back
upright.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
18 Child Safety
CHILD SEAT POSITIONING
WARNING: Airbags can kill or injure a child in a child seat.
Never place a rear-facing child seat in front of an active airbag.
If you must use a forward-facing child seat in the front seat, move the
vehicle seat upon which the child seat is installed all the way back.
When possible, all children age 12 and under should be properly
restrained in a rear seating position. If all children cannot be seated and
restrained properly in a rear seating position, properly restrain the
largest child in the front seat.
WARNING: Always carefully follow the instructions and
warnings provided by the manufacturer of any child restraint to
determine if the restraint device is appropriate for your child’s size,
height, weight, or age. Follow the child restraint manufacturer’s
instructions and warnings provided for installation and use in
conjunction with the instructions and warnings provided by your
vehicle manufacturer. A safety seat that is improperly installed or
utilized, is inappropriate for your child’s height, age or weight, or does
not properly fit the child, may increase the risk of serious injury or
death.
WARNING: Never let a passenger hold a child on his or her lap
while your vehicle is moving. The passenger cannot protect the
child from injury in a crash, which may result in serious injury or death.
WARNING: Never use pillows, books, or towels to boost a child.
They can slide around and increase the likelihood of injury or
death in a crash.
WARNING: Always restrain an unoccupied child seat or booster
seat. These objects may become projectiles in a crash or sudden
stop, which may increase the risk of serious injury.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 19
WARNING: Never place, or allow a child to place, the shoulder
belt under a child’s arm or behind the back because it reduces
the protection for the upper part of the body and may increase the risk
of injury or death in a crash.
WARNING: To avoid risk of injury, do not leave children or pets
unattended in your vehicle.
Recommendations for attaching child safety restraints for
children
Combined
Restraint type
Rear-facing child
seat
Rear-facing child
seat
Forward-facing
child seat
Forward-facing
child seat
Note: The child seat must rest tightly against the vehicle seat upon
which it is installed. It may be necessary to lift or remove the head
restraint. See the Seats chapter for information on head restraints.
BOOSTER SEATS
WARNING: Never place, or allow a child to place, the shoulder
belt under a child’s arm or behind the back because it reduces
the protection for the upper part of the body and may increase the risk
of injury or death in a crash.
weight of
child and
child seat
Up to 65 lb
(29.5 kg)
Over 65 lb
(29.5 kg)
Up to 65 lb
(29.5 kg)
Over 65 lb
(29.5 kg)
Use any attachment method as
indicated below by X.
Safety belt and top
tether anchor
X
X
Safety
belt
only
X
X
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
20 Child Safety
Use a belt-positioning booster seat for children who have outgrown or no
longer properly fit in a child safety seat (generally children who are less
than 4 feet 9 inches (1.45 meters) tall, are greater than age four (4) and
less than age twelve (12), and between 40 pounds (18 kilograms) and
80 pounds (36 kilograms) and upward to 100 pounds (45 kilograms) if
recommended by your child restraint manufacturer). Many state and
provincial laws require that children use approved booster seats until
they reach age eight (8), a height of 4 feet 9 inches (1.45 meters) tall, or
80 pounds (36 kilograms).
Booster seats should be used until you can answer YES to ALL of these
questions when the child is seated without a booster seat.
• Can the child sit all the way
back against their vehicle seat
with knees bent comfortably at
the edge of the seat cushion?
• Can the child sit without
slouching?
• Does the lap belt rest low across the hips?
• Is the shoulder belt centered on the shoulder and chest?
• Can the child stay seated like this for the whole trip?
Always use booster seats in conjunction with your vehicle lap and
shoulder belt.
Types of Booster Seats
• Backless booster seats
If your backless booster seat has a removable shield, remove the shield.
If a vehicle seating position has a low seatback or no head restraint, a
backless booster seat may place your child’s head (as measured at the
tops of the ears) above the top of the seat. In this case, move the
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 21
backless booster to another seating position with a higher seatback or
head restraint and lap and shoulder belts, or consider using a high back
booster seat.
• High back booster seats
If, with a backless booster seat, you cannot find a seating position that
adequately supports your child’s head, a high back booster seat would be
a better choice.
Children and booster seats vary in size and shape. Choose a booster that
keeps the lap belt low and snug across the hips, never up across the
stomach, and lets you adjust the shoulder belt to cross the chest and
rest snugly near the center of the shoulder. The following drawings
compare the ideal fit (center) to a shoulder belt uncomfortably close to
the neck and a shoulder belt that could slip off the shoulder. The
drawings also show how the lap belt should be low and snug across the
child’s hips.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
22 Child Safety
If the booster seat slides on the vehicle seat upon which it is being used,
placing a rubberized mesh sold as shelf or carpet liner under the booster
seat may improve this condition. Do not introduce any item thicker than
this under the booster seat. Check with the booster seat manufacturer’s
instructions.
INSTALLING CHILD SEATS
Child Seats
Use a child safety seat (sometimes
called an infant carrier, convertible
seat, or toddler seat) for infants,
toddlers or children weighing
40 pounds (18 kilograms) or less
(generally age four or younger).
Using Lap and Shoulder Belts
WARNING: Airbags can kill or injure a child in a child seat.
Never place a rear-facing child seat in front of an active airbag.
If you must use a forward-facing child seat in the front seat, move the
seat upon which the child seat is installed all the way back.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 23
WARNING: Airbags can kill or injure a child in a child seat.
Children 12 and under should be properly restrained in the rear
seat whenever possible.
WARNING: Depending on where you secure a child restraint,
and depending on the child restraint design, you may block
access to certain safety belt buckle assemblies, rendering those features
potentially unusable. To avoid risk of injury, occupants should only use
seating positions where they are able to be properly restrained.
When installing a child safety seat with combination lap and shoulder
belts:
• Use the correct safety belt buckle for that seating position.
• Insert the belt tongue into the proper buckle until you hear a snap
and feel it latch. Make sure the tongue is securely fastened in the
buckle.
• Keep the buckle release button pointing up and away from the safety
seat, with the tongue between the child seat and the release button,
to prevent accidental unbuckling.
• Place the vehicle seat upon which the child seat will be installed in
the upright position.
• Put the safety belt in the automatic locking mode. See Step 5. This
vehicle does not require the use of a locking clip.
Perform the following steps when installing the child seat with lap and
shoulder belts:
Note: Although the child seat illustrated is a forward facing child seat,
the steps are the same for installing a rear facing child seat.
1. Position the child safety seat in a
seat with a combination lap and
shoulder belt.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
24 Child Safety
2. Pull down on the shoulder belt
and then grasp the shoulder belt
and lap belt together.
3. While holding the shoulder and
lap belt portions together, route the
tongue through the child seat
according to the child seat
manufacturer’s instructions. Be sure
the belt webbing is not twisted.
4. Insert the belt tongue into the
proper buckle (the buckle closest to
the direction the tongue is coming
from) for that seating position until
you hear a snap and feel the latch
engage. Make sure the tongue is
latched securely by pulling on it.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 25
5. To put the retractor in the
automatic locking mode, grasp the
shoulder portion of the belt and pull
downward until all of the belt is
pulled out.
Note: The automatic locking mode is available on the front passenger
and rear seats. This vehicle does not require the use of a locking clip.
6. Allow the belt to retract to remove slack. The belt will click as it
retracts to indicate it is in the automatic locking mode.
7. Try to pull the belt out of the retractor to make sure the retractor is
in the automatic locking mode (you should not be able to pull more belt
out). If the retractor is not locked, unbuckle the belt and repeat Steps 5
and 6.
8. Remove remaining slack from the
belt. Force the seat down with extra
weight, for example, by pressing
down or kneeling on the child
restraint while pulling up on the
shoulder belt in order to force slack
from the belt.
This is necessary to remove the remaining slack that will exist once the
extra weight of the child is added to the child restraint. It also helps to
achieve the proper snugness of the child seat to your vehicle.
Sometimes, a slight lean toward the buckle will provide extra help to
remove remaining slack from the belt.
9. Attach the tether strap (if the child seat is equipped). See Using
Tether Straps.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
26 Child Safety
10. Before placing the child in the
seat, forcibly move the seat forward
and back to make sure the seat is
securely held in place.
To check this, grab the seat at the belt path and attempt to move it side
to side and forward and back. There should be no more than 1 inch
(2.5 centimeters) of movement for proper installation.
Ford recommends checking with a NHTSA Certified Child Passenger
Safety Technician to make certain the child restraint is properly installed.
In Canada, check with your local St. John Ambulance office for referral
to a Child Passenger Safety Technician.
Using Tether Straps
Many forward-facing child safety seats include a tether strap
which extends from the back of the child safety seat and hooks
to an anchoring point called the top tether anchor. Tether
straps are available as an accessory for many older safety seats.
Contact the manufacturer of your child seat for information about
ordering a tether strap, or to obtain a longer tether strap if the tether
strap on your safety seat does not reach the appropriate top tether
anchor in the vehicle.
Attach the tether strap only to the appropriate tether anchor as shown.
The tether strap may not work properly if attached somewhere other
than the correct tether anchor.
Note: If you install a child seat with rigid LATCH attachments, and have
attached the top tether strap to the proper top tether anchor, do not
tighten the tether strap enough to lift the child seat off the vehicle seat
cushion when the child is seated in it. Keep the tether strap just snug
without lifting the front of the child seat. Keeping the child seat just
touching the vehicle seat gives the best protection in a severe crash.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Child Safety 27
Perform the following steps to install a child safety seat with tether
anchors:
You can attach the tether directly to
the rear of the front seat.
1. Adjust the front passenger seat fully forward.
2. Route the child safety seat tether
strap over the back of the front
passenger seat as shown.
3. Clip the tether strap hook to the
seat pedestal at the location shown.
If the tether strap is clipped
incorrectly, the child safety seat
may not be retained properly in the
event of a crash.
4. Adjust the front passenger seat to the full rearward position.
5. Tighten the child safety seat tether strap according to the
manufacturer’s instructions.
If the safety seat is not anchored properly, the risk of a child being
injured in a crash greatly increases.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
28 Safety Belts
PRINCIPLES OF OPERATION
WARNING: Always drive and ride with your seatback upright
and the lap belt snug and low across the hips.
WARNING: Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot protect the
child from injury in a crash.
WARNING: To reduce the risk of injury, make sure children sit
where they can be properly restrained.
WARNING: All occupants of the vehicle, including the driver,
should always properly wear their safety belts, even when an
airbag supplemental restraint system is provided. Failure to properly
wear your safety belt could seriously increase the risk of injury or
death.
WARNING: It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a crash, people riding in these
areas are more likely to be seriously injured or killed. Do not allow
people to ride in any area of your vehicle that is not equipped with
seats and safety belts. Be sure everyone in your vehicle is in a seat and
using a safety belt properly.
WARNING: In a rollover crash, an unbelted person is
significantly more likely to die than a person wearing a safety
belt.
WARNING: Each seating position in your vehicle has a specific
safety belt assembly which is made up of one buckle and one
tongue that are designed to be used as a pair. 1) Use the shoulder belt
on the outside shoulder only. Never wear the shoulder belt under the
arm. 2) Never swing the safety belt around your neck over the inside
shoulder. 3) Never use a single belt for more than one person.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Safety Belts 29
WARNING: Safety belts and seats can become hot in a vehicle
that has been closed up in sunny weather; they could burn a
small child. Check seat covers and buckles before you place a child
anywhere near them.
WARNING: Front seat occupants, including pregnant women,
should wear safety belts for optimum protection in an accident.
All seating positions in this vehicle have lap and shoulder safety belts.
All occupants of the vehicle should always properly wear their safety
belts, even when an airbag supplemental restraint system is provided.
The safety belt system consists of:
• Lap and shoulder safety belts.
• Shoulder safety belt with automatic locking mode (except driver
safety belt).
• Height adjuster at the front outboard seating positions.
• Safety belt pretensioner at the front outboard seating positions.
• Safety belt warning light and chime. See Safety belt warning
light and indicator chime.
• Crash sensors and monitoring system with readiness
indicator. See Crash sensors and airbag indicator in the
Supplemental Restraints System chapter.
The safety belt pretensioners are designed to activate in frontal or
near-frontal crashes and may deploy in rollovers if the vehicle is
equipped with roll stability control. The safety belt pretensioners at the
front seating positions are designed to tighten the safety belts firmly
against the occupant’s body when activated. This helps increase the
effectiveness of the safety belts.
2015 Econoline (eco)
Owners Guide gf, 2nd Printing, December 2014
USA (fus)
Loading...
