Ford E-250 2005, E-350 2005, E-450 2005 Owner Manual

Introduction 4

Instrument Cluster 12

Warning and control lights 12 Gauges 15

Entertainment Systems 18

AM/FM stereo 18 AM/FM stereo cassette 19 AM/FM stereo with CD 22 AM/FM stereo with in-dash six CD 25 AM/FM stereo with single CD 28

Climate Controls 38

Heater only 38 Manual heating and air conditioning 39

Lights 41

Headlamps 41 Turn signal control 45 Bulb replacement 46

Driver Controls 51

Windshield wiper/washer control 51 Steering wheel adjustment 52 Power windows 56 Mirrors 56 Speed control 58

Locks and Security 61

Keys 61 Locks 61

Table of Contents

Seating and Safety Restraints 66

Seating 66 Safety restraints 72 Airbags 82 Child restraints 86

Tires, Wheels and Loading 101

Tire Information 104 Tire Inflation 105 Changing tires 109 Lug Nut Torque 117 Vehicle loading 126 Trailer towing 133 Recreational towing 144

Driving 145

Starting 145 Brakes 149 Transmission operation 153

Roadside Emergencies 163

Getting roadside assistance 163 Hazard flasher switch 164 Fuel pump shut-off switch 164 Fuses and relays 166 Jump starting 174 Wrecker towing 179

Customer Assistance 180

Reporting safety defects (U.S. only) 188

Cleaning 189

Underbody preservation 193

Table of Contents

Maintenance and Specifications 195

Engine compartment 197 Engine oil 198 Battery 201 Engine Coolant 203 Fuel information 209 Air filter(s) 224 Part numbers 224 Refill capacities 226 Lubricant specifications 230

Accessories 238

Index 240

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and

certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.

For more information on Ford Motor Company and its products visit the following website:

• In the United States: www.ford.com

• In Canada: www.ford.ca

• In Australia: www.ford.com.au

• In Mexico: www.ford.com.mx

Additional owner information is given in separate publications.

This Owner’s Guide describes every option and model variant available and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.

Introduction

Remember to pass on this Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the

safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment

We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

Introduction

BREAKING-IN YOUR VEHICLE

During the first 1,000 miles (1,600 km) of driving, maintain speeds below 70 mph (110 km/h) and vary speeds frequently. This is recommended to give the moving parts a chance to break in. Do not tow a trailer during this break-in period. For more information regarding trailer towing, refer to Trailer towing in the Driving chapter.

SPECIAL NOTICES

Emission warranty

The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s

Guide.

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.

Introduction

Event Data Recording

Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as:

• how various systems in your vehicle were operating;

• whether or not the driver and passenger seatbelts were buckled;

• how far (if at all) the driver was depressing the accelerator and/or the

brake pedal;

• how fast the vehicle was traveling; and

• where the driver was positioning the steering wheel.

To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS)

in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should

NEVER be placed in front of an active passenger air bag.

Introduction

Notice to owners of diesel-powered vehicles

Read the 6.0 Liter Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for information regarding correct operation and

maintenance of your Diesel-powered light truck.

Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than

other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Using your vehicle as an ambulance

If your light truck is equipped with the Ford Ambulance Preparation Package, it may be utilized as an ambulance. Ford urges ambulance manufacturers to follow the recommendations of the Ford Incomplete

Vehicle Manual, Ford Truck Body Builder’s Layout Book and the Qualified Vehicle Modifiers (QVM) Guidelines as well as pertinent

supplements. For additional information, please contact the Truck Body Builders Advisory Service at 1–877–840–4338.

Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance usage without the preparation package could cause high underbody temperatures, overpressurized fuel and a risk of spraying fuel which could lead to fires.

Introduction

If your vehicle is equipped with the Ford Ambulance Preparation Package, it will be indicated on the Certification label. The label is located on the driver’s side door pillar or on the rear edge of the driver’s door. You can determine whether the ambulance manufacturer followed Ford’s recommendations by directly contacting that manufacturer. Ford Ambulance Preparation Package is only available on certain 6.0L Diesel engine equipped vehicles.

Using your vehicle as a stationary power source (PTO)

Refer to the Driving chapter for more information and guidelines for operating a vehicle equipped with an aftermarket power take-off system.

Middle East/North Africa vehicle specific information

For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this

Owner’s Guide for all other required information and warnings.

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

Fasten Safety Belt Air Bag-Front

Air Bag-Side Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Powertrain Malfunction Speed Control

Master Lighting Switch Hazard Warning Flasher

Fog Lamps-Front Fuse Compartment

See Owner’s Guide

Child Seat Lower Anchor

Brake System

Brake Fluid Non-Petroleum Based

Fuel Pump Reset Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

Vehicle Symbol Glossary

Introduction

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout

Interior Luggage Compartment Release Symbol

Panic Alarm Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

Emission System Engine Air Filter

MAX

MIN

Passenger Compartment Air Filter

Check fuel cap

Jack

Instrument Cluster

WARNING LIGHTS AND CHIMES

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately.

If your vehicle is equipped with a Diesel engine, it has a unique cluster, refer to Starting the engine in your 6.0 Liter Power Stroke Direct

Injection Turbo Diesel Owner’s Guide Supplement.

Service engine soon: The Service engine soon indicator light

illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures

could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Instrument Cluster

Electronic throttle control (if equipped): Illuminates when the

engine has defaulted to a ’limp-home’ operation. Report the fault to a dealer at the earliest opportunity.

Check fuel cap: Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service Engine Soon warning light to come on, refer to Fuel filler cap in the Maintenance and Specification chapter.

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

Driving a vehicle with the brake system warning light on is

dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

BRAKE

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated.

Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced

ABS

Instrument Cluster

immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.

Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

Low fuel: Illuminates when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).

Check gauge: Illuminates when any of the following conditions has occurred:

• The engine coolant temperature is high.

• The engine oil pressure is low.

• Flashes when Failsafe cooling mode has been activated.

Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.

High beams: Illuminates when the high beam headlamps are turned on.

Transmission control indicator light (TCIL): Illuminates when the

overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.

CHECK

GAGE

OVERDRIVE

Instrument Cluster

Transmission Tow/Haul light (TCIL) (5.4L and 6.8L gasoline engines only): Illuminates when

the Tow/Haul feature of the transmission has been turned on, refer to the Driving chapter.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.

Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

Parking brake ON warning chime: Sounds when the parking brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km).

GAUGES

Speedometer: Indicates the current vehicle speed.

Instrument Cluster

Engine coolant temperature gauge: Indicates engine coolant

temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section,

the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is running or hot.

Odometer: Registers the total miles (kilometers) of the vehicle.

Trip odometer: Registers the miles (kilometers) of individual journeys. Press the SELECT/RESET control once to switch from the odometer to the trip odometer. Press the control again to select Trip A and Trip B features. To reset the trip, press and hold the control again until the trip reading is 0.0 miles.

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked as soon as possible.

Instrument Cluster

Engine oil pressure gauge:

Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level. Add oil if needed. If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician.

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade.

The FUEL icon and arrow indicates which side of the vehicle the fuel filler door is located.

Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

Entertainment Systems

AM/FM STEREO (IF EQUIPPED)

1. Seek: Press

/ to find the

next listenable station down/up the frequency band.

2. Tune: Press

/ to manually

adjust the radio frequency down/up.

3. AM/FM: Press to choose a

frequency band in radio mode.

4. Memory preset buttons: To set

a station: Select frequency band

1 2 3 4

AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns.

5. Power/volume: Press to turn

ON/OFF; turn to increase or decrease volume levels.

AM/FM

VOL

PUSH

Entertainment Systems

6. Tone: Press TONE until the

desired level — Bass, Treble, Fade appears on the display. Turn the volume control to raise/lower the

TONE

CLK

VOL

PUSH

levels, or to move the audio sound from the right to left or the front to back (if equipped).

7. CLK (Clock): To set the hour,

press and hold CLK until CLOCK SET appears in the display. Press SEEK to decrease

increase the hours.

To set the minute, press and hold CLK until CLOCK SET appears in the display. Press TUNE to decrease

or increase the minutes.

AM/FM STEREO CASSETTE (IF EQUIPPED)

VOL - PUSH ON

13 14 15 16 17 1 234

BASS TREB BAL FADE

FM1

CLK

TAPE

AMS

SEEK

TUNE

SCAN

SIDE

REW FF

1 - 2

123456

1. Balance: Press to shift sound to

the left/right speakers.

Entertainment Systems

2. Fade: Press to shift sound to the

rear/front speakers.

3. CLK: To set the hour, press and

hold CLK. Then press SEEK to decrease

or increase the

CLK

hours.

To set the minute, press and hold CLK and press TUNE to decrease or increase the minutes.

4. Tape AMS: In tape mode, press

and hold to activate Automatic

TAPE

AMS

Music Search (allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection). Then, press REW (for the beginning of the current selection) or FF (to advance to the next selection). The tape MUST have a blank section of at least four seconds duration between programs.

5. Side 1–2: Press to change tape

SIDE 1 - 2

direction.

6. REW (rewind): Press to rewind

REW

the tape.

FF (fast forward): Press to

advance the tape.

7. Memory preset buttons: To set

a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns.

Dolby威 noise reduction: Works in tape mode only. Reduces tape

noise and hiss; press to activate/deactivate.

9. Scan: Press SCAN to hear a brief

sampling of all listenable radio stations or all tape selections. Press again to stop.

10. Tune: Works in radio mode only.

Press TUNE

/ to change

frequency down/up

11. Seek: Press and

release

/ for previous/next

strong station, selection or track.

12. Power/volume: Press to turn

ON/OFF; turn to increase or decrease volume levels.

13. AM/FM: Press to choose a

frequency band in radio mode.

Entertainment Systems

14. Bass: Press

/ to

decrease/increase the bass output.

15. Treble: Press

/ to

decrease/increase the treble output.

16. EJ (Eject): Press to eject a

tape.

17. Cassette door: Insert a cassette into the cassette door.

Entertainment Systems

AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED)

VOL - PUSH ON

SEEK

TUNE

16 17

AM FM

BASSCDTREB BAL FADE

CDCD

123456

1. BAL (Balance): Press

to shift sound to the left/right speakers.

2. FADE: Press

/ to shift

sound to the front/rear speakers.

FM1

DISC

1 234

COMP

SHUFFLE

7910

SCN

CLK

3. SCN (Scan): Press to hear a

brief sampling of all listenable stations or CD tracks. Press again to stop.

4. CLK (Clock): To set the hour,

press and hold CLK and press SEEK to decrease

or increase the

hours.

CLK

Entertainment Systems

To set the minute, press and hold CLK and press TUNE to decrease or increase the minutes.

5. EJ (Eject): Press to eject a CD.

6. COMP (Compression): In CD

mode, press to bring louder and softer levels into more comfortable listening level. The compression icon (c) will appear in the display.

7. SHUFFLE: Press to listen to the

tracks on the CD in random order. Press again to turn off.

8. Memory presets: To set a

station: Select frequency band

CDCD

123456

AM/FM; tune to a station. Press and hold a preset button until sound returns. This radio is equipped with six station memory preset controls which allow you to set up to six AM stations and 12 FM stations (six in FM1 and six in FM2).

9. CD

: Press and hold until desired point of a selection is reached.

10.

CD: Press and hold until

desired point of a selection is reached.

11. TUNE: In radio mode, press to move up or down the frequency band in individual increments.

12. SEEK: Press and release SEEK

/ for previous/next

strong station, selection or track.

13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

SHUFFLE

Entertainment Systems

14. CD: Press to enter CD mode or to play a CD already loaded into the system.

15. AM/FM: Press to choose a frequency band in radio mode.

16. BASS: Press

/ to

increase/decrease the bass output.

17. TREB (Treble): Press

to increase/decrease the treble output.

18. CD slot: Insert a CD printed

DISC

side up.

CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

Entertainment Systems

PREMIUM IN-DASH SIX CD SOUND SYSTEM (IF EQUIPPED)

COMP

MUTE

SHUF

LOAD

SCAN

171615

DISC TUNE

SEEK REW FF

2 3

PUSH ON

BALBASS

SEL

FADETREB

1 2 3 4 5 6

12 11 10 9

1. Seek: Press and release SEEK

/ for previous/next

strong station, or track of the current disc.

2. Rewind: Press and hold until the desired point of a selection is reached.

Fast forward: Press and hold until the desired point of a selection is reached.

3. Comp (Compression): The compression feature operates in CD mode and brings soft and loud CD passages together for a more consistent listening level. Press the COMP control until COMP ON is displayed.

4. Mute: Press to MUTE the playing media. Press again return to playing media.

5. Eject: Press to eject a CD. Press and hold to eject all loaded discs. If disc is not removed, it will reload into the system. Works with the ignition on or off.

Entertainment Systems

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance and Fade controls to adjust levels. Use with MENU to set the clock and RDS function on/off.

8. Balance: Press BAL; then press SEL left/right speakers.

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press MENU and SEL to access clock mode, RDS on/off, Traffic announcement mode, Program type mode, Shuffle and Compression mode. The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend that FM radio broadcasters use RDS technology to transmit information. FM radio stations are independently operated and individually elect to use RDS technology to transmit station ID and program type as desired.

Traffic: Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data).Traffic information is not available in most

U.S. markets.

FIND Program type: Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40.

Show TYPE: Displays the station’s call letters format. Setting the clock: Press MENU until SELECT HOUR or SELECT MINS

is displayed. Use SEL to manually increase ( hours/minutes. Press MENU again to disengage clock mode.

/ to decrease/increase

/ to shift sound to the

) or decrease ( )the

Entertainment Systems

10. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.

11. CD: Press to select CD mode.

12. AM/FM: Press to select AM/FM1/FM2 frequency band. In CD mode, press to begin radio play.

Autoset: Stores the six strongest stations without erasing your current presets. To activate, press and momentarily hold AM/FM. AUTOSET will flash in the display. The six strongest stations will fill the memory preset buttons for AM/FM1/FM2 if enough stations are available. If not, stations will be repeated. Press again to deactivate.

13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

14. Load: Press LOAD to load a CD in the system. The display will read SELECT SLOT. Select the desired memory preset slot (1–6). The display will then read LOAD CD. Partially load the CD label side up and the system will pull the CD in. LOADING CD# will appear in the display. Press and hold LOAD to autoload up to six discs at once.

15. Shuffle: Press to play tracks in random order.

16. Scan: Press SCAN to move up the radio frequency band. SCAN automatically finds a station, plays it for five seconds, then moves to the next station. Press again to stop. CD: Press SCAN for a brief sampling of CD tracks. Press again to stop.

Entertainment Systems

17. Disc tune: Radio: Press or to manually tune down or up

the radio frequency band. CD: Press

SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SINGLE CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED)

/ to select the previous/next CD.

1. SEEK: Press and release SEEK strong station or track.

2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display, its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display. Press TEXT to scroll through the text fields. The display will scroll through all of the text in the current field before changing to the next field. (TEXT must be pressed within 3 seconds of the previous press to proceed to the next/last text display. The last text field shown on the display will become the new display message default. TEXT is also available when equipped with Satellite radio. Your radio comes equipped with Satellite ready capability. The kit to enable Satellite

/ for previous/next

Entertainment Systems

reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

3. AUX: This function is not operational.

4. MUTE: Press to MUTE playing media; press again to return to playing media.

5. EJ: Press to eject a CD.

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance, Fade and other menu selections.

/ to decrease/increase

8. Balance: Press BAL; then press SEL left/right speakers.

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press MENU and SEL to access AUTOSET, Speed sensitive volume and Setting the clock.

Autoset: Press MENU until AUTOSET appears in the display. Press SEL to toggle ON/OFF. Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2. When the six strongest stations are filled, the station

/ to shift sound to the

Entertainment Systems

stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.

Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed. Use SEL to manually increase (

) the hours/minutes. Press MENU again to disengage clock mode.

(

Folder/Track mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE.

10. REPEAT: Repeats the current CD/MP3 track when active (ON). Press to show repeat status. Press again to toggle status.

11. SHUFFLE: Plays CD/MP3 tracks in random order when active (ON). Press to show shuffle status. Press again to toggle status.

12. FOLDER the next MP3 directory.

: Press to access

) or decrease

13. FOLDER the previous MP3 directory.

14. FF(Fast forward): In CD/MP3 mode, press until desired selection is reached.

15. REW(Rewind): In CD/MP3 mode, press until desired selection is reached.

16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your dealer. Detailed satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

: Press to access

+ 218 hidden pages
