Fluke 8060A Data Sheet

Fluke 8060A/8062A 4-1/2
Digital
Handheld Multimeters

Product Home | Specifications | Models, Options & Accessories |

Manuals

Fluke's 8060A and 8062A
4-1/2-digit/20000 Count DMMs offer
more measurement capabilities than
many bench/portable models. Well
suited for engineers and technicians
working in audio, video,
telecommunications, or computer
technology, both meters combine
precision and accuracy with a wealth
of features to fit nearly every
application.

Register your Fluke Multimeter here

Download application notes for more
information on multimeter

procedures.

True-rms AC voltage and
current measurement
(Volts to 100 kHz [8060A];
Volts to 30 kHz [8062A])

●

Fast audible-visual continuity
tests

●

Relative Reference (offset):
When measuring ohms with
the 8060A or 8062A, the
relative reference function
displays only the difference
between a stored reference
value and a measured value,

●

even if the range was changed
between readings. Relative
mode works in all functions
and ranges.

Low-power ohms on all
resistance ranges, for in-circuit
resistor tests

●

Constant-current diode test
mode

●

Resistance and conductance
measurements

●

Frequency and dB
measurements (8060A). The
8060A's direct dB readout
(referenced to 600Ohms)
easily and accurately measures
the dB gain or loss of
amplifiers, filters or
attenuators.

●

Digital Display/Counts: 20000●
Resistance to 300 MΩ●

© 1995 - 2000 Fluke Corporation

Privacy Statement

Fluke 8060A/8062A 4-1/2 Digit Handheld
Multimeters
Specifications

Product Home | Specifications | Models, Options & Accessories | Manuals

● Technical Specifications

● General Specifications

Technical Specifications

VDC

Range and Resolution: 200.00 mV, 2.0000V, 20.000V,

200.00V, 1000.0V

8060A: 200.00 mV, 2.0000V, 20.000V, 200.00V, 1000.0V
8062A: ±(0.05%+2)

VAC (True-RMS, AC
Coupled)

Range and Resolution: 200.00 mV, 2.0000V, 20.000V,

200.00V, 750.0V

8060A: ±(0.2%+10)
8062A: ±(0.5%+10)

dBm, 600Ohms
reference

Range and Resolution: -50.00 - +60.00 dBm
8060A: ±(0.15 dB)
8062A: NA

ADC

Range and Resolution: 200.00 µA, 2.0000 mA, 20.000 mA,

200.00 mA, 2000.0 mA

8060A: ±(0.2%+2)
8062A: ±(0.3%+2)

AAC (True-RMS)

Range and Resolution: 200.00 µA, 2.0000 mA, 20.000 mA,

200.00 mA, 2000.0 mA

8060A: ±(0.75%+10)
8062A: ±(0.75%+10)

Resistance

Range and Resolution: 200.00Ohms, 2.0000 kOhms, 20.000

kOhms, 200.00 kOhms, 300.0 MOhms

8060A: ±(0.07%+2)
8062A: ±(0.1%+2)

Frequency

Range and Resolution: 200.00 Hz, 2.0000 kHz, 20.000 kHz,

200.00 kHz

8060A: ±(0.05%+1)
8062A: NA

Conductance

Range and Resolution: 2000.0 nS (equivalent to 500

kOhms)

8060A: ±(0.5%+20)
8062A: NA

General Specifications

Battery Life

170 hours typical (9V alkaline)

Weight

0.41 kg (0.90 lb)

Size

180 mm L x 86 mm W x 45 mm D (7.1" L x 3.4" W x 1.8" D)

One Year Warranty

One year guaranteed calibration

© 1995 - 2000 Fluke Corporation

Privacy Statement

Fluke 8060A/8062A 4-1/2 Digit Handheld
Multimeters
Models, Options & Accessories

Product Home | Specifications | Models, Options & Accessories | Manuals

Model Name Product Description

8060A

Digital Multimeter

8062A

Digital Multimeter

Available Accessories and Options

Model Name Accessory or Option Description

80i-400 AC Current Clamp

80K-40 High Voltage Probe (DC only)
80K-6 High Voltage Probe (DC only)

80T-150U Universal Temperature Probe
80T-IR Non-Contact Infrared Temperature Probe
80TK Thermocouple Module

85RF High Frequency Probe, 500 MHz

C100 Universal Carrying Case
C25 Soft Case DMM with Holster
C510 Leather Meter Case
C530 Leather Accessory Case
C550 Tool bag
C90 Soft Case DMM

FOM Fiber Optic Meter includes an optical power meter, two

multimode ST-ST patch cables, one multimode ST-ST adapter,
instruction sheet and instrument case.

i-1010 Clamp-on AC/DC Current Probe
i-410 Clamp-on AC/DC Current Probe
i200 AC Current Clamp
PV350 Pressure/Vacuum Module (0 to 350 PSI)
TL20 63" Test Lead Set
TL22 63" Right Angle Silicone Test Lead Set
TL23F Electrical Test Lead Set
TL23R Electrical Test Lead Set
TL24 63" Right Angle/Straight Silicone Test Leads
TL26A 60" 5-Way Test Lead Set
TL28A 63" Alligator Clip Test Lead Set
TL74 4 mm Diameter Test Leads
TL75 48" Hardpoint Test Lead Set
Y8140A 48" Slim Flex Test Lead Set
