114, 115, and 117
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
True-rms Multimeters
Users Manual
PN 2572573
July 2006, Rev. 1, 2/07
© 2006, 2007 Fluke Corporation, All rights reserved. Printed in China
All product names are trademarks of their respective companies.
®
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
This Fluke product will be free from defects in material and workmanship for three
years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling. Resellers are not authorized to extend any
other warranty on Fluke’s behalf. To obtain service during the warranty period, contact
your nearest Fluke authorized service center to obtain return authorization information,
then send the product to that Service Center with a description of the problem.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER WARRANTIES, SUCH AS
FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE
IS NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since
some states or countries do not allow the exclusion or limitation of an implied warranty
or of incidental or consequential damages, this limitation of liability may not apply to
you.
Fluke Corporation
P.O. Box 9090
Everett, WA 98206-9090
U.S.A.
11/99
Fluke Europe B.V.
P.O. Box 1186
5602 BD Eindhoven
The Netherlands
True-rms Multimeters
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Introduction
The Fluke Model 114, Model 115, and Model 117 are
battery-powered, true-rms multimeters (hereafter "the
Meter") with a 6000-count display and a bar graph. This
manual applies to all three models. All figures show the
Model 117.
These meters meet CAT III IEC 61010-1 2
standards. The IEC 61010-1 2nd Edition safety standard
defines four measurement categories (CAT I to IV)
based on the magnitude of danger from transient
impulses. CAT III meters are designed to protect
against transients in fixed-equipment installations at the
distribution level.
Contacting Fluke
To contact Fluke, call:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore +65-738-5655
Anywhere in the world: +1-425-446-5500
Visit Fluke's web site at www.fluke.com
Register your Meter at register.fluke.com
.
.
nd
Edition
Unsafe Voltage
To alert you to the presence of a potentially
hazardous voltage, the Y symbol is displayed when
the Meter measures a voltage ≥30 V or a voltage
overload (OL) condition. When making frequency
measurements >1 kHz, the Y symbol is unspecified.
Test Lead Alert
Personal injury or damage to the
Meter can occur if you attempt to
make a measurement with a lead in an
incorrect terminal.
To remind you to check that the test leads are in the
correct terminals,
audible beep sounds when you move the rotary
switch to
XWWarning
is briefly displayed and an
LEAd
or from any A (Amps) position.
1
114, 115, and 117
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Users Manual
Safety Information
A "XWWarning" statement identifies hazardous conditions and actions that could cause bodily harm or death.
A "WCaution" statement identifies conditions and actions that could damage the Meter or the equipment under test.
To avoid possible electric shock or personal injury, follow these guidelines:
• Use the Meter only as specified in this manual or the protection provided by the Meter might
be impaired.
• Do not use the Meter or test leads if they appear damaged, or if the Meter is not operating
properly.
• Always use proper terminals, switch position, and range for measurements.
• Verify the Meter's operation by measuring a known voltage. If in doubt, have the Meter
serviced.
• Do not apply more than the rated voltage, as marked on Meter, between terminals or
between any terminal and earth ground.
• Use caution with voltages above 30 V ac rms, 42 V ac peak, or 60 V dc. These voltages pose
a shock hazard.
• Disconnect circuit power and discharge all high-voltage capacitors before testing
resistance, continuity, diodes, or capacitance.
• Do not use the Meter around explosive gas or vapor.
• When using test leads or probes, keep your fingers behind the finger guards.
• Only use test leads that have the same voltage, category, and amperage ratings as the meter
and that have been approved by a safety agency.
• Remove test leads from Meter before opening the battery door or Meter case.
2
True-rms Multimeters
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Safety Information
• Comply with local and national safety requirements when working in hazardous locations.
• Use proper protective equipment, as required by local or national authorities when working
in hazardous areas.
• Avoid working alone.
• Use only the replacement fuse specified or the protection may be impaired.
• Check the test leads for continuity before use. Do not use if the readings are high or noisy.
• Do not use the Auto Volts function to measure voltages in circuits that could be damaged by
this function’s low input impedance (≈3 kΩ)(114 and 117 only).
B AC (Alternating Current) I Fuse
F DC (Direct Current) T Double Insulated
X Hazardous voltage W Important Information; Refer to manual
N
Battery (Low battery when shown on the
display.)
Do not dispose of this product as unsorted
municipal waste. Contact Fluke or a
~
qualified recycler for disposal.
Symbols
J Earth ground
D AC and DC
3
114, 115, and 117
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Users Manual
Display
6
5
4
3
2
1
16
15
VoltAlert
7
14
17
8
9
11
18
10
12
13
No. Symbol Meaning Model
A w The Meter is in the VoltAlert™ non-contact voltage detect mode.
B s The Meter function is set to Continuity.
C R The Meter function is set to Diode Test
D O Input is a negative value.
E
Y
X Unsafe voltage. Measured input voltage ≥30 V, or voltage
overload condition (OL).
117
114, 115, & 117
115 & 117
114, 115, & 117
114, 115, & 117
4
edy02f.eps
True-rms Multimeters
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Display
F K Display hold enabled. Display freezes present reading.
G M
VWX
H (Red LED) Voltage presence through the non-contact VoltAlert sensor
I
J nµF mVµA
K DC AC Direct current or alternating current
L
M 610000 mV Indicates the Meter’s range selection.
N (Bar graph) Analog display.
O Auto Volts
P + Bar graph polarity
Q 0L W The input is too large for the selected range.
R LEAd W Test lead alert. Briefly displayed whenever the Meter’s
LoZ
MkΩ kHz
N
Auto
Manual
MIN MAX AVG mode enabled.
Maximum, minimum, average or present reading displayed
The Meter is measuring voltage or capacitance with a low input
impedance.
Measurement units.
Battery low warning.
The Meter is in the Auto Volts function.
Autoranging. The Meter selects the range for best resolution.
Manual ranging. User sets the Meter’s range.
function switch is rotated to or from any A position.
114, 115, & 117
114, 115, & 117
117
114, 115 & 117
114, 115, & 117
114, 115 & 117
114, 115, & 117
114, 115, & 117
114, 115, & 117
114 & 117
114, 115, & 117
114, 115, & 117
114, 115, & 117
114, 115, & 117
115 & 117
5
114, 115, and 117
Shop for Fluke products online at:
1.877.766.5412
www.MyFlukeStore.com
Users Manual
Terminals
1
A
10 A
FUSED
2
COM
V
3
No. Description
A Input terminal for measuring ac and dc current to 10 A. 115 & 117
B Common (return) terminal for all measurements. 114, 115, & 117
Input terminal for measuring voltage, continuity, resistance, capacitance,
C
frequency and testing diodes.
Error Messages
bAtt Battery must be replaced before the Meter will operate.
CAL Err Calibration required. Meter calibration is required before the Meter will operate.
EEPr Err Internal error. The Meter must be repaired before it will operate.
F11 Err Internal error. The Meter must be repaired before it will operate.
6
114, 115, & 117
edy01f.eps
