Flir N233ZD, N233ZC Specsheet

N233ZC / N233ZCP

1.3MP Micro PT Dome IP Camera

N233ZD / N233ZDP

2.1MP Micro PT Dome IP Camera

MICRO PT CAMERA

Available in 1.3MP/2.1MP configurations, the FLIR HD Micro PT IP cameras
offer the most compact pan/ tilt viewing solution at outstanding value.
With a miniature and discreet form factor at 2.2”/57mm height and

5.1”/130mm diameter, the Micro PT packs impressive performance with HD
picture quality, Edge storage, 100°/s rotation speed, built-in microphone,
plus rugged IK10 & IP66 vandal and weatherproof housing.

HD IN REAL TIME

Outstanding image detail, both day and night

• N233ZC - 1.3MP HD, 720p @ 25/ 30fps, 1/3” CMOS, 3.6mm lens

• N233ZD - 2.1MP HD, 1080p @ 25/30fps, 1/2.8” Sony Exmor™ CMOS, 3.6mm
lens

• 3D-DNR, D-WDR, H.264/MJPEG Dual Stream

MICRO PT

Compact Pan/Tilt viewing solution

• Discreet micro form factor at 2.2” / 57mm height and 5.1” / 130mm diameter

• Provides ±180° pan range / 2°~90° Tilt, 100°/sec max rotation speed, 25
presets

• Powerful 3x Digital Zoom, suppor ts MicroSD card (6 4GB max)

www.flir.com/security

EAS Y INSTAL L AT ION

Quick clip-on mounting bracket and PoE support

• Easy install ceiling mounting bracket, wall mount accessory available

• 12V / PoE (802.3af) operation, Onvif Profile S conformance

• IP66 weatherproof, IK10 vandalproof, Microphone built-in

FLIR CLOUD REMOTE VIEWING

Centralized control over multiple sites with
FLIR Cloud on PC/Mac, iOS /Android

• Centralized viewing and control of up to 64 cameras on each screen with
PC/Mac

• Access live or recorded video at any time on your iPhone / Android / iPad

• Advanced mobile app features including remote playback, push notifications
for motion/alarm, E-map, manual record/snapshot to device

Specifications

Camera N233 ZC / N23 3ZCP N233 ZD / N23 3ZDP

Imaging Device 1. 3M P, 1/ 3” 2.1 MP, 1/2.8”
Effective Pixels 1280 (H) x 9 60 ( V) 204 8 (H) x 153 6 (V )
Image Type CMOS
Image Readout Progressive Scan
Day / Night Auto/Color/B/ W
Mechanical IR Cut Filter No
Min. Illumination 0.1lux (Color)
S/N Ratio >50dB
Field of View (H) 70° 88°
IR Illumination No
IR On / Off Control N/A
Video Output N/A
Electronic Shutter Range 1/3 (4)~1/10000s

Optical

Lens Type Fixed
Mount Type Board type
Focal Length 3.6mm
Zoom 3x Digital
Focus Fixed
Aperture F1.2

Pan/Tilt

Pan / Tilt Range ±180° Pan / 2° ~ 9 0° Tilt
Preset Speed (Maximum) 100 °/s
Presets 25

Video

Video Compression MJPEG / H.2 64
Video Streams H.26 4 & MJPEG Dual Stream
Resolution Selection 1.3M (1280×960) /

720p (1280×720) / D1

(704×576/704×480)/CIF

(352X288/352X240)
Aspect Ratio 16 : 9
Frame rates (Maximum) 1280 x9 60 @ 25 /30fps /

D1/CIF@ 25/30fps
Bit Rate Control CBR / VBR
Bit Rate Selection Compression Type: 32K~

8192Kbps
Wide Dynamic Range Digital WDR
Backlight Compensation BLC / HLC / DWDR
White Balance Auto / Manual
Gain Control Auto / Manual
Noise Reduction 3D
Video Mirroring Horizontal Mirror / Vertical Flip
Video Overlay Time / Date / Camera / Custom
Window Blanking (Privacy) Up to 4 Areas
Menu Languages English

Network

Protocols IPv4 / IPv6, HTTP, HTTP S, SSL, TCP / IP, UDP, UPnP,

ICM P, IGMP, S NM P, R T S P, RT P, SM T P, N T P, D H C P,

DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
ONVIF Conformance Profile S
Users Up to 20 users

Audio

Input/Output Built-in Microphone
Encoding G.711a / G.711u / PCM

1080P (1920 x 1080) /

720P (1280 x 720) /

D1 (704×576/704×480) /

CIF (352×288/352×240)

1080P / 720P @ 25/ 30fps

/D1/CIF@ 25/3 0fps

Compression Type: 32K~

8192Kbps

IP66 WEATHERPROOF

3.6mm LENS

±180° PAN RANGE
