N133EB
1MP Fixed IR Dom e IP Camera
N133ED
2.1MP Fixed IR Dome IP Cam era
N133ED-2
2.1MP Fixed IR Dome IP Cam era 2 Pack
Fixed IR Dome IP Cameras
Available in 1MP / 2.1MP / 3MP configurations, the FLIR Fixed IR Dome IP
Cameras offer HD picture quality in real time with outstanding night vision
capabilities. Installation is made easy with a PoE power option. Built rugged,
FLIR’s Fixed IR Dome IP Cameras are suitable for both indoor and outdoor
installations (IP6 6 rated) and cold climates (-22°F/- 30°C).
HD PICTURE QUALITY
Outstanding image detail, both day and night
• N133EB - 1MP HD, 720p @ 30fps, 1/4” CMOS, 3.6mm lens, 70 ft IR
• N133ED - 2.1MP HD, 1080p @ 30fps, 1/3” CMOS, 3.6mm lens, 65ft IR
• N233EE - 3MP HD, 3MP @ 20fps, 1/3” CMOS, 3.6mm lens, 8 0ft IR
EASY INSTALLATION
PoE (Class 3) support for simplified cabling
• 12V / PoE (802.3af ) operation
• Onvif Profile S conformance
• 3 Axis design for wall/ceiling mounting
N233EE
3MP Fixed IR Dome IP Cam era
RUGGED DESIGN
Durable weatherproof housing
• IP66 weatherproof rated
• Cold climate capable (-22°F/-30°C)
• True Day/Night with ICR, 2D- DNR, D-WDR
FLIR CLOUD REMOTE VIEWING
Remote access via iOS, Android, PC/Mac with FLIR Cloud
• Centralized viewing and control of up to 64 cameras on each screen
with PC/Mac
• Access live or recorded video at any time on your iPhone / Android / iPad
• Advanced mobile app features including remote playback, push
notifications for motion/alarm, E-map, manual record/snapshot to device
www.flir.com/security
Specifications
Camera N133E B N133ED N233EE
Imaging Device 1 MP, 1/4" 2.1 MP, 1/3" 3 MP, 1/3"
Effective Pixels 1280 (H) x 72 0 (V ) 204 8 (H) x 1536 (V) 204 8 (H) x 1536 (V)
Image Type CMOS
Image Readout Progressive Scan
Day / Night Auto(ICR)/Color/B/ W
Mechanical IR Cut Filter Yes
Min. Illumination 0.1lux (Color) 0.1lux (Color) 0.01lux (Color)
0.01lux (B/W) 0lux (B/W) 0.005lux (B/W)
S/N Ratio >50dB
Field of View (H) 64° 72° 72°
IR Illumination Yes , 8 50nm
IR On / Off Control Yes
Video Output RJ45
Electronic Shutter Range 1/4~1/10000s
Optical
Lens Type P Fixed
Mount Type Board in
Focal Length P 3.6mm
Aperture F1.8 F1.6 F1.8
Video
Video Compression MJPEG / H.26 4
Video Streams H.26 4 & MJPEG Dual Stream
Resolution Selection 720P (1280×720) /
D1 (704×576/704×480) /
CIF (352×288/352×240)
Aspect Ratio 16 : 9
Frame rates (Maximum) 1980 x720 @ 25/ 30fps /
D1/CIF@ 25/30fps
Bit Rate Control CBR / VBR
Bit Rate Selection Compression Type:
56K~ 8129Kbps
Wide Dynamic Range Digital WDR
Backlight Compensation BLC / HLC / DWDR
White Balance Auto / Manual
Gain Control Auto / Manual
Noise Reduction 2D 2D 3D
Video Mirroring Horizontal Mirror
Video Overlay Time / Date / Camera / Custom
Window Blanking (Privacy) Up to 4 Areas
Menu Languages English
Network
Protocols IPv4 / IPv6 , HT TP, HTT PS, S SL, TCP / IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP,
RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, F TP, IP Filter, QoS, Bonjour
ONVIF Conformance Profile S
Users Up to 20 users
SDK / API Availability SDK / API
1080P (1920 x 108 0) /
720P (1280 x 720) /
D1 (704×576/704×480) /
CIF (352×288/352×240)
1920 x1080 @ 25fps /
1280 x 720 @ 30fps
Compression Type:
16K~ 819 2K bps
3MP (2048×1536) /
1080P (1920×1080) /
720P(1280×720) /
D1 (704×4 80 ) /
CIF(352×240)
3.0M @ 20fps /
1080P/720P@25/30fps
Compression Type:
32K~ 8192Kbps
www.flir.com/security
Specifications
Mechanical N133E B N133ED N233EE
Product Dimensions
(LxWxH)
Product Weight 0.4kg
Electrical
Network Port 10 / 100 Base-T
Power Input 12V DC, PoE
Power Consumption
(Maximum)
Current Consumption
(Maximum)
Environmental
Operating Temperature -30°C ~ 6 0°C
Operating Humidity Less then 9 5% RH
Ingress Protection IP66
Φ108mm x 86 mm
3W
250mA
IP66 WEATHERPROOF
IR NIGHT VISION
WIDE ANGLE LENS
Ordering Information
N133EB: 8-41430-01049-4
N133E D: 8- 414 30- 010 37-1
N133ED -2: 8-414 30- 01051-7
N2 33EE: 8-41430 -0103 9- 5
Package Dimensions
N133EB: 5.5 x 5.4 x 4.5” /
136 x 137 x 113mm
N133ED: 5.5 x 5.4 x 4.5” /
136 x 137 x 113mm
N133ED -2: 11 x 10.1 x 4.7” /
279 x 257 x 118mm
N233ED: 5.5 x 5.4 x 4.5” /
136 x 137 x 113mm
