THERMAL
MONOCULARS FOR
PUBLIC SAFETY
PRODUCT CATALOG
CONTENTS
THERMAL IMAGING MONOCULA RS
SCION PT M .......................................8
SCION OT M .......................................9
SCO UT T K ......................................11
SCO UT II .......................................11
SCOUT III .......................................11
BREACH ........................................12
LS -X / LS -X R ....................................13
THERMA L MONOCULAR SPECS ..................14
DRI SP EC S ..................................14-15
EXPORT INFORMATION
FLIR products are subject to the International Trafc in Arms Regulations (ITAR). The
“Use” of any ITAR-controlled products requires that prior authorization be obtained
from the U.S. Department of State to allow non-U.S. persons and af liates to use these
FLIR products.
*Equipment described herein may require U.S. Government authorization for expor t
purposes. Diversion contrary to US law is prohibited.
According to the ITAR §120.10 and the EAR part 772, this document does not contain
technical data / technology.
PROBLEMS SEEN
ARE PROBLEMS
SOLVED
The human eye only tells part of the story. When danger lies
in the darkness, through the haze, or under the brush, FLIR
outts military and law enforcement professionals with tools
to counter unseen threats. Years of battle-tested innovation
help FLIR technologies combat the unknown, maximizing
condence and readiness of the modern warghter. From
advanced vehicle-mounted targeting systems to unmanned
personal reconnaissance systems, each branch of the
military relies on FLIR technologies to heighten situational
awareness and save lives on the battleeld.
INNOVATION LEADER
With 241 patents led and over $290 million invested
in research and development over the past year, FLIR
is committed to driving innovation of thermal imaging
and sensing technologies. Whether increasing topend performance of existing systems or improving the
accessibility of thermal solutions, FLIR’s continued
investment in technology helps face some of the world’s
most pressing challenges.
GLOBAL REACH
FLIR develops and distributes advanced sensing systems
to improve the safety and well-being of people around
the world. With product distribution spanning 173
different countries, FLIR aims to expand the positive
global impact of thermal imaging technology.
THERMAL IMAGING
MONOCULARS
Thermal imaging handheld optics generate images based
on heat energy—or infrared radiation—rather than
visible light. Invisible to the naked eye, infrared radiation
is emitted by all humans, animals, and objects, allowing
thermal sensors to operate in complete darkness,
through glaring light, and in the presence of smoke,
fog, or sparse vegetation. Handheld monoculars bring
on-demand thermal surveillance to law enforcement
ofcers and outdoor enthusiasts. Compact, man-portable
thermal imagers quickly detect objects of interest and
boost situational awareness while on foot or from a
vehicle, allowing users to scan elds, forests, and urban
environments without revealing their position.
FLIR SCION® PTM
Built to equip law enforcement professionals with
superior thermal surveillance, the FLIR Scion®
PTM packs high-performance thermal imaging
compatibility into a rugged, IP67-rated handheld
monocular. Capable of geotagged video recording
and live video transmission, the Scion PTM can
instantly stream encrypted thermal footage of any
pursuit, evidence recovery, or search and rescue
eort to the command center via wireless network.
A smooth 60 Hz refresh rate and picture-in-picture
zoom capture minute details from a distance
and maintain peripheral awareness for constant
thermal supervision of suspects, team members,
and standbys.
Detector 320 x 256
640 x 512 VOx
Refresh Rate 60 Hz
Focal Length 13.8 mm, 25 mm, 36 mm
Weather Rating IP67
Detection Range 550 m, 1000 m, 1420 m
THERMAL IMAGING MONOCULAR
FLIR
SCION
®
Scion Rechargeable Battery Kit (GPX310)
The GPX310 lets you operate FLIR Scion thermal imaging
monoculars for up to 10 hours. Its high-capacity 8.5 Ah
battery pack features a smart fuel gauge that displays on-
screen battery life when the Scion is on. Added electronics
protection helps prevent battery-related safety incidents.
FLIR Scion Docking Station (GTX100)
The GTX100 mounts easily to surfaces. Its built-in locking
feature latches FLIR Scion thermal imaging monoculars
securely in place even during prolonged vibration and abrupt
maneuvering. When powered, the station charges FLIR
GPX310 rechargeable batteries while the Scion is docked.
8
FLIR SCION® OTM
The FLIR Scion® OTM leverages high-performance
thermal imaging and a refined user interface to
quickly detect objects of interest and provide
superior awareness in low visibility conditions.
Built around FLIR’s powerful Boson core, the Scion
OTM produces smooth thermal imaging up to 60
Hz and captures geotagged video and still images
for playback long after the day is done. A rugged,
IP67-rated housing and intuitive controls allow
single-hand operation in harsh weather conditions,
maintaining reliable thermal imaging in the most
demanding outdoor environments.
FLIR SCION® OTM
The FLIR Scion® OTM captures clear thermal imaging and leverages a refined user interface to quickly
detect objects of interest in complete darkness and
through glaring light or haze. Built around FLIR’s
powerful Boson core, the Scion OTM produces 9 Hz
thermal imaging and records geotagged video and
still images for playback long after the day is done.
A rugged, IP67-rated housing and intuitive controls
allow single-hand operation in harsh weather
conditions, maintaining reliable thermal imaging in
the most demanding outdoor environments.
Detector 320 x 256
640 x 512 VOx
Refresh Rate 60 Hz
Focal Length 13.8 mm, 18 mm, 25 mm, 36 mm
Weather Rating IP67
Detection Range 550 m, 710 m, 1000 m, 1420 m
Detector 320 x 256
640 x 512 VOx
Refresh Rate 9 Hz
Focal Length 13.8 mm, 18 mm, 25 mm
Weather Rating IP67
Detection Range 550 m, 710 m, 1000 m, 1420 m
THERMAL IMAGING MONOCULAR
FLIR
SCION
®
9
10
FLIR SCOUT® TK
THERMAL IMAGING MONOCULAR
FLIR
SCOUT
®
The FLIR Scout TK is a pocket-sized thermal vision
monocular for exploring the outdoors at night
and in lowlight conditions. Scout TK reveals your
surroundings and helps you see people, objects,
and animals over 100 yards (90 m) away. Simple
to use, with still image and video recording, Scout
TK is the perfect companion, whether in the back
country or your own backyard.
FLIR SCOUT® II
Oering clear thermal imaging in a compact monocular, Scout II quickly detects humans, animals,
and objects in low visibility environments—day
or night. Generating images based on heat, rather
than visible light, thermal imaging gives users
increased situational awareness in complete
darkness and haze, providing reliable vision for
surveillance and safe navigation. A rugged IP67
housing allows on-demand thermal imaging in the
most trying conditions.
Detector 160 x 120 VOx
Refresh Rate <9 Hz
Focal Length 13 mm
Onboard Recording Video/Images
Detection Range 100 m
Detector 336 x 256
640 x 512 VOx
Refresh Rate <9 Hz
Focal Length 19 mm, 35 mm
Weather Rating IP67
Detection Range 550 m, 1140 m
FLIR SCOUT® III
Scout III captures sharp thermal imaging at a fast
framerate for smooth, impeccable vision on running targets and from moving vehicles. Designed
to increase situational awareness at any time of
day, Scout III can detect humans, animals, and
objects in complete darkness, haze, or through
glaring light. A rugged IP67 rated housing stands
up to harsh weather and drops, equipping law
enforcement professionals, hunters, and outdoor
enthusiasts with reliable thermal imaging in
tough conditions.
Detector 336 x 256
640 x 512 VOx
Refresh Rate 30 Hz, 60 Hz
Focal Length 19 mm, 35 mm
Weather Rating IP67
Detection Range 550 m, 1140 m
11
FLIR BREACH®
THERMAL IMAGING MONOCULAR
FLIR
BREACH
®
Built for the rigors of law enforcement, the FLIR
Breach® PTQ136 spots the heat of suspects and
objects in total darkness. Featuring the latest FLIR
Boson core and a compact design, the FLIR Breach
oers unmatched tactical awareness. Weighing
only 7.4 ounces (210 grams), the FLIR Breach can be
concealed in a pocket or mounted to a helmet with
its mini-rail feature, while adding minimal weight
to ocers’ heavy gear. Additional features include
onboard recording and seven palettes for fast
detection of suspects or evidence, day or night.
Swing Arm #37 and #172
Swing Arm #37 is an adapter to PVS-7 / PVS-14 Headset
/ Helmet that allows a night vision device attachment to
standard MICH and PASGT helmet mount assembly
Swing Arm #172 mounts Mini Rail devices to standard
Dovetail mounts, attaching compact optics such as
FLIR Breach to helmet rigs.
Detector 240 x 180
Detector 320 x 256 VOx
336 x 256
Refresh Rate 60 Hz
640 x 512 VOx
Focal Length 9.1 mm
Refresh Rate 9Hz
Digital Zoom 2x, 4x
Focal Length 13mm, 19mm, 35mm
Detection Range 360 m
Weather Rating IP67
Detection Range 350m, 550m, 1140m
12
FLIR LS-X / LS-XR™
THERMAL IMAGING MONOCULAR
TM
FLIR
LS-X / LS-XR
The FLIR LS-X and LS-XR handheld thermal monoculars are designed for the men and women
who protect and serve. This powerful, easy-touse imager gives ocers the tactical advantage
when pursuing suspects, looking for evidence, or
conducting search and rescue. The LS-X and LS-XR
feature high resolution displays, extended zooming
capabilities, and video output. Whatever you need
to see, find it with the FLIR LS-X and LS-XR.
Detector 336 x 256
640 x 512 VOx
Refresh Rate 7.5 Hz, 30 Hz, 60 Hz
Focal Length 19 mm, 35 mm
Weather Rating IP67
Detection Range 550 m, 1140 m
13
THERMAL MONOCULAR SPECIFICATIONS
SPECS SCOU T TK SCOUT BREACH
PRODUCTS
DETECTOR
LENS 13 mm Fixed Focus 19 mm Fixed Focus 35 mm Fixed Focus 9.1 mm; F/1.04
FIEL D OF VIEW 18° × 14° 17° × 13° 18° × 14° 24° × 19°
DETECTION RANGE
OPT ICAL
MAGNIFICATION
DIGITAL ZOOM No 2x 2x 2x, 4x 2x, 4x 2x, 4x , 8x 2x, 4x
REFRESH RATE < 9 Hz
VIDE O CAPABLE Video Capture Composite Video Out Video Output Composite Video Out Video Output Digital Video
POWER Internal Li-Ion Cell, > 5 hrs
DIMENSIONS
OVERALL DIMENSIONS N/A 139 × 54 × 72 mm (5.5 × 2.1 × 2.8 in)
WEIGHT 0.17 kg (0.375 lbs) 0.34 kg (0.75 lbs) 0.21 kg (0.46 lbs)
*
SPECS SCION
PRODUCTS
DETECTOR 320 × 256 VOx 12um Microbolometer
LENS 13.8 mm 14 mm 18 mm 25 mm 36 mm
FIEL D OF VIEW 16° × 12° 31° × 24° 12° × 9° 24° × 18° 18° × 13° 9° × 6.5° 6° × 4.5° 12° × 9°
DETECTION RANGE
MAN
OPT ICAL
MAGNIFICATION
DIGITAL ZOOM 1x, 2x, 4x 1x, 2x, 4x, 8x 1x, 2x, 4x 1x, 2x, 4x, 8x 1x, 2x, 4x, 8x 1x, 2x, 4x 1x, 2x, 4x 1x, 2x, 4x, 8x
REFRESH RATE 9 Hz, 60 Hz 60 Hz 9 Hz, 60 Hz 60 Hz 9 Hz, 60 Hz 60 Hz
VIDE O CAPABLE Yes Yes Yes Yes
POWER 6 x CR123a 3V Lithium battery, Optional rechargeable battery pack
DIMENSIONS
WEIGHT
239 × 76.8 × 60.5 mm
OTM 130 , 136 II 320 III 320 LS-X II 6 40 III 640 LS-XR PTQ 13 6
160 × 120
12um Microbolometer
100 m 550 m 1140 m 360 m
1x 1.1x 1.1x 1x
< 9 Hz 60 Hz 7.5 or 60 Hz < 9 Hz 30 Hz 7.5 or 30 Hz 60 Hz
152 × 51 × 51 mm
(6 × 2 × 2 in)
OTM 130 / 136 PT M 166 OTM 230 / 236 OTM 260 / 26 6 OTM 366 / PT M 366 PTM 336 OTM 4 30 / 43 6 PTM 4 66
550 m 710 m 1000 m 1420 m
1.5x 0.7x 1.9x 1x 1.3x 2.6x 3.8x 2.0x
(9 × 3 × 2.4 in)
227 × 76.8 × 60.5 mm
(9.4 × 3 × 2.4 in)
unit only 0.452 kg (1 lbs)
with battery 0.565 kg (1.25 lbs)
320 × 256 VOx
12um Microbolometer
336 × 256
17µm microbolometer
170 × 58 × 62 mm (6.7 × 2.3 × 2.4 in) 96 × 48 × 68 mm (3.8 × 1.9 × 2.7 in)
640 × 512 VOx
12um Microbolometer
239 × 76.8 × 60.5 mm (9 × 3 × 2.4 in) 227 × 76.8 × 60.5 mm (9.4 × 3 × 2.4 in)
640 × 512 VOx 12um
Microbolometer
unit only 0.567 kg (1.25 lbs)
with battery 0.68 kg (1.5 lbs)
640 × 512
17µm microbolometer
320 × 256 VOx 12um
Microbolometer
12µm microbolometer
1 CR123A 3V Lithium batteries,
up to 90 minutes
320 × 256 VOx 12um
Microbolometer
239 × 76.8 × 60.5 mm
(9 × 3 × 2.4 in)
unit only 0.68 kg (1.5 lbs)
with battery 0.793 kg (1.75 lbs)
320 × 256
640 × 480 VOx 12um
Microbolometer
278 × 77 × 73mm
(10.9 × 3.03 × 2.87)
Product range performance - Human
1140
Height: 1.8 m
Width: 0.5 m
Critical Dimention: 0.75 m
1420
SCOUT TK
SCOUT II / III 320 / LS-X
SCOUT II / III 640 / LS-XR
PTQ1xx
OTM1xx / PTM1xx
OTM2xx
OTM3xx / PTM3xx
OTM4xx / PTM4xx
MAN-RecognitionMAN-Detection
50
100
130
550
240
90
360
140
550
180
710
250
1000
360
0 m 200 m 400 m 600 m 800 m 1000 m 1200 m 1400 m 1600 m
14
PRODUCT RANGE PERFORMANCE
Product range performance - Vehicle
VEHICLE-RecognitionVEHICLE-Detection
Height: 2.3 m
Width: 2.3 m
Critical Dimention: 2.3 m
SCOUT TK
SCOUT II / III 320 / LS-X
SCOUT II / III 640 / LS-XR
PTQ1xx
OTM1xx / PTM1xx
OTM2xx
OTM3xx / PTM3xx
OTM4xx / PTM4xx
130
520
320
1280
590
2370
360
860
340
430
600
860
1340
1730
2400
3450
0 m 500 m 1000 m 1500 m 2000 m 2500 m 3000 m 3500 m 4000 m
SCOUT TK
SCOUT II / III 320 / LS-X
SCOUT II / III 640 / LS-XR
PTQ1xx
OTM1xx / PTM1xx
OTM2xx
OTM3xx / PTM3xx
OTM4xx / PTM4xx
Product range performance - Boat
Height: 3.0 m
BOAT-RecognitionBOAT-Detection
Width: 10.0 m
Critical Dimention: 5.5 m
310
1230
760
3060
1410
5640
510
2050
800
3200
1030
4110
1430
5700
2050
8220
0 m 1000 m 2000 m 3000 m 4000 m 5000 m 6000 m 7000 m 8000 m 9000 m
WARRANTY
FLIR aims to develop the most complete lineup of outdoor and personal
vision systems in the world and is committed to assisting when product
service becomes necessary.
All qualifying products properly registered with FLIR within 60 days of
the purchase date are eligible for extended warranty coverage under
the FLIR Personal Vision Systems 2-3-10 Global Limited Warranty.
PRODUCTS
QUALIFY ING
PRODUCTS
ALL OTHER
PRODUCTS
STANDARD LIMI TED
WARRANTY PERIOD
2 years on components and
manufacturing defects, from
original date of purchase.
2 years on components and
manufacturing defects, from
original date of purchase.
EXTENDED LIMITED
WARRANTY PERIOD
3 years on components and
manufacturing defects.10 years
on uncooled detector from
original date of purchase.
For more information, please visit www.ir.com/support
FLIR SYSTEMS, INC.
Corporate Headquarters
1201 S. Joyce Street
Suite C006
Arlington, VA 22202
Office: +1 703.682.3 40 0
PORTLAND
FLIR Systems, Inc.
27700 SW Parkway Ave.
Wilsonville, OR 97070, USA
PH: 1.877.773.3547
NASHUA
FLIR Systems, Inc.
9 Townsend West
Nashua, NH 03063, USA
PH: 1.888.959.2259
PH: 603.324.7600
BELGIUM
HQ of Solutions Division
FLIR Systems
Luxemburgstraat 2
2321 Meer, Belgium
PH: +32 (0) 36 65 5100
SWEDEN
Sales and Administration EMEA
PO Box 7376
Antennvägen 6
SE-187 15 Täby, Sweden
PH: +46 (0)8 753 25 00
EMAIL: service@flir.se
none
www.ir.com
NASDAQ: FLIR
Specications are subject to change without notice
©2021 FLIR Systems, Inc. All other brand and product names are trademarks of their respective owners. The images
displayed may not be representative of the actual resolution of the camera shown. Images for illustrative purposes only.
Updated 011921 [21-0078-OTS]
Loading...
