MPX Motorized Varifocal Cameras
TM
C237ED/ C237EDP
2.1MP HD Motorized Varifocal
WDR Dome MPX Camera
C237BD / C237BD1 / C237BDP / C237BD1P
2.1MP HD Motorized Varifocal
WDR Bullet MPX Camera
The FLIR 2.1MP HD Motorized Varifocal WDR Dome and Bullet MPX
cameras use the latest HD-CVI technology and True WDR to deliver
outstanding 1080p picture quality over coax cabling in any lighting
condition. Ideal for retrofit applications, C237ED / C237BD are
compatible with FLIR MPX DVRs offering a hassle-free upgrade to HD
resolution plus the added advantage of remote zoom and focus control
via the DVR or web interface. Dual video output offers simultaneous HD
and 960H video streams.
HD PICTURE QUALITY
Outstanding image detail, both day and night
• C237ED - 2.1MP HD, 1080p @ 25/30 FPS, 1/2.8” CMOS, 2.8-12mm Motorized
Varifocal lens, 100ft / 30m IR
• C237BD - 2.1MP HD, 1080p @ 25/30 FPS, 1/2.8” CMOS, 2.8 -12mm
Motorized Varifocal lens, 115ft / 35m IR
• C237BD1 - 2.1MP HD, 1080p @ 25/30 FPS, 1/2.8” CMOS, 6 -22mm
Motorized Varifocal lens, 115ft / 35m IR
EASY INSTALL ATION
Upgrade to HD without the expense of re-cabling
• Dual BNC output – MPX 1080p / 96 0H Analog
www.flir.com/security
• Cable pass-through bracket design
• Remote zoom and focus adjustment
SUPERIOR PERFORMANCE
Virtually no latency, extended cable runs up to 1650ft/500m
• IP66 weatherproof rated housings
• -22°F (-30°C) Cold Climate Capable
Specifications
Camera C237ED C237BD C237 BD1
Imaging Device 1/2.8” - 2.1MP Exmor™ 1/2.8” - 2.1MP Exmor™ 1/2.8” - 2.1MP Exmor™
Effective Pixels H: 1920 V: 108 0 H: 1920 V: 108 0 H: 1920 V: 108 0
Image Type CMOS CMOS CMOS
Image Readout Progressive Scan Progressive Scan Progressive Scan
Day/Night Y Y Y
Mechanical IR Cut Filter Y Y Y
Min. Illumination 0.1 Lux @ F1.4 (Color) 0.1 Lux @ F1.4 (Color) 0.1 Lux @ F1.4 (Color)
S/N Ratio ≥50dB (AGC OFF) ≥50dB (AGC OFF) ≥50dB (AGC OFF)
Horizontal Field of View MPX: 34 -9 0°
IR Illumination Range 100ft/30m 115ft/35m 115ft/35m
IR Wavelength 840~850nm 840~850nm 840~850nm
IR On/Off Control N N N
Video Output BN C (1080 p MPX, Digital)
Electronic Shutter Range 1/6 0 (1/ 50 ) ~ 1/ 60,0 00 1/6 0 (1/ 50 ) ~ 1/ 60,0 00 1/6 0 (1/ 50 ) ~ 1/ 60,0 00
Optical
Lens Typ e B oard Typ e Bo ard Ty pe B oard Type
Focal Length 2.8 -12 mm 2.8 -12m m 6-22mm
F-Number F1.4 F1.4 F1.4
Zoom Y - Motorized Y - Motorized Y - Motorized
Iris Control Type / Adjustment Electronic / Auto or Manual Electronic / Auto or Manual Electronic / Auto or Manual
Video
Frame rates 25/30fps 25/30fps 25/30fps
Backlight Compensation BLC / HLC BLC / HLC BLC / HLC
Wide Dynamic Range Tru e W DR Tru e W DR True W D R
White Balance Auto / ATW / Preset / Manual Auto / ATW / Preset / Manual Auto / ATW / Preset / Manual
Gain Control AGC - 0-20 Selectable AGC - 0-20 Selectable AGC - 0 -20 Selectable
Noise Reduction 2D/3D - Low/Mid /High Selectable 2D/3D - Low/Mid/High Selectable 2D/3D - Low/Mid/ High Selectable
Window Blanking Y - 15 Zone Selectable Y - 15 Zone Selectable Y - 15 Zone Selectable
Menu Languages English, German, French, Spanish,
Russian, Polish, Italian, Portuguese
Mechanical
Construction Aluminum Alloy Aluminum Alloy Aluminum Alloy
Product Dimensions
(Diag x H)
Product Weight 1.4lbs / 0.6kg 1.7lbs / 0. 8kg 1.7lbs / 0.8kg
Electrical
Power Input 12V DC / 24V AC 12V DC / 24V AC 12V DC / 24V AC
Power Consumption 8W 15W 15W
Current Consumption 500 mA (12V) / 315mA (24V) 700mA (12V) / 5 85mA (24V ) 700mA (12V ) / 585mA (24V)
Built-in Heater N N N
Alarm I/O N N N
Environment
Operating Temperature -22° F - 122°F / -30°C - 6 0°C -22°F - 122° F / -3 0°C - 60°C -22°F - 122°F / -30°C - 60 °C
Operating Humidity ≤ 85% RH ≤85% RH ≤8 5% RH
Ingress Protection IP66 IP66 IP66
Vandal Resistance N N N
Certifications
Certifications FCC, CE, ROHS FCC, CE, ROHS FCC, CE, ROHS
960H: 32-84°
BNC (9 60 H, Analog)
4.7” x 3.9” /
120mm x 99 mm
English, German, French, Spanish,
Russian, Polish, Italian, Portuguese
3.9” x 3.5” x 10.6” / 99 mm x 89 mm
MPX: 34 -9 0°
960H: 32-84°
BNC (1080p MPX, Di gital)
BNC (9 60 H, Analog)
x 269mm
MPX: 17-36°
96 0 H: 15 -34°
BNC (1080p MPX, Di gital)
BNC (9 60 H, Analog)
English, German, French, Spanish,
Russian, Polish, Italian, Portuguese
3.9” x 3.5” x 10.6” / 99 mm x 89 mm
x 269mm
* Remote Zoom/focus adjustment through DVR when using MP X video output only. No remote zoom /focus control suppor ted through standard analog video
output. Instead, OSD controller can be utilized during setup for zoom/ focus adjustment.
www.flir.com/security
IP66 WEATHERPROOF
IP66 WEATHERPROOF
IR NIGHT VISION
VARIFOCAL LENS
Dimensions
3.9” /
99mm
4.7” / 120mm
VARIFOCAL LENS
Dimensions
3.5” /
89mm
IR NIGHT VISION
10.6” /
269mm
MARKHAM, ONTARIO
FLIR S ystems, Inc.
250 Royal Cres t Court
Mark ham, ON L3R 3S1
Canada
PH: +1 866.344.4674
CABLE THROUGH BRACKET
3.9” / 9 9mm
Ordering Information
C237ED: 8-41430-01063-0
C237EDP: 8- 41430-01207-8
C237BD: 8-41430- 01208-5
C237BD1: 8-41430-01233-7
C237BDP: 8-41430-01208-5
C237BDP1: 8-41430-01253-5
Package Dimensions
C237ED Series: 6 .4 x 6.1 x 4.9” / 162 x 155 x 125mm
C237B D Series: 9.6 x 5.8 x 5.2” / 24 5 x 148 x 132mm
