Fisher IEC62591 Wireless Interface Instruction Manual (for ControlWave Micro) - D5139 Manuals & Guides

Download

Part Number D301709X012

October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave

Micro)

Remote Automation Solutions

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Device Safety Considerations

 Reading these Instructions

Before operating the device, read these instructions carefully and understand their safety implications. In some situations, improperly using this device may result in damage or injury. Keep this manual in a convenient location for future reference. Note that these instructions may not cover all details or variations in equipment or cover every possible situation regarding installation, operation, or maintenance. Should problems arise that are not covered sufficiently in the text, immediately contact Customer Support for further information.

 Protecting Operating Processes

A failure of this device – for whatever reason -- may leave an operating process without appropriate protection and could result in possible damage to property or injury to persons. To protect against this, you should review the need for additional backup equipment or provide alternate means of protection (such as alarm devices, output limiting, fail-safe valves, relief valves, emergency shutoffs, emergency switches, etc.). Contact Remote Automation Solutions for additional information.

 Returning Equipment

If you need to return any equipment to Remote Automation Solutions, it is your responsibility to ensure that the equipment has been cleaned to safe levels, as defined and/or determined by applicable federal, state and/or local law regulations or codes. You also agree to indemnify Remote Automation Solutions and hold Remote Automation Solutions harmless from any liability or damage which Remote Automation Solutions may incur or suffer due to your failure to ensure device cleanliness.

 Grounding Equipment

Ground metal enclosures and exposed metal parts of electrical instruments in accordance with OSHA rules and regulations as specified in Design Safety Standards for Electrical Systems, 29 CFR, Part 1910, Subpart S, dated: April 16, 1981 (OSHA rulings are in agreement with the National Electrical Code). You must also ground mechanical or pneumatic instruments that include electrically operated devices such as lights, switches, relays, alarms, or chart drives. Important: Complying with the codes and regulations of authorities having jurisdiction is essential to ensuring personnel safety. The guidelines and recommendations in this manual are intended to meet or exceed applicable codes and regulations. If differences occur between this manual and the codes and regulations of authorities having jurisdiction, those codes and regulations must take precedence.

 Protecting from Electrostatic Discharge (ESD)

This device contains sensitive electronic components which be damaged by exposure to an ESD voltage. Depending on the magnitude and duration of the ESD, it can result in erratic operation or complete failure of the equipment. Ensure that you correctly care for and handle ESD-sensitive components.

System Training

A well-trained workforce is critical to the success of your operation. Knowing how to correctly install, configure, program, calibrate, and trouble-shoot your Emerson equipment provides your engineers and technicians with the skills and confidence to optimize your investment. Remote Automation Solutions offers a variety of ways for your personnel to acquire essential system expertise. Our full-time professional instructors can conduct classroom training at several of our corporate offices, at your site, or even at your regional Emerson office. You can also receive the same quality training via our live, interactive Emerson Virtual Classroom and save on travel costs. For our complete schedule and further information, contact the Remote Automation Solutions Training Department at 800-338-8158 or email us at education@emerson.com

Ethernet Connectivity

This automation device is intended to be used in an Ethernet network which does not have public access. The inclusion of this device in a publicly accessible Ethernet-based network is

not recommended.

System Training

ii Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Contents

Chapter 1 – General Information 1-1

1.1 Overview ........................................................................................................................................ 1-1

1.2 Scope of Manual ............................................................................................................................ 1-2

1.3 Hardware ........................................................................................................................................ 1-2

1.3.1 IEC 62591 Wireless Interface Module ............................................................................... 1-2

1.3.2 Emerson Wireless 781 Smart Antenna .............................................................................. 1-3

1.3.3 WirelessHART Field Devices ............................................................................................. 1-4

1.4 Configuration/Commissioning Software ......................................................................................... 1-5

1.5 Additional Technical Information .................................................................................................... 1-5

Chapter 2 – Installation 2-1

2.1 Installing the IEC 62591 Module .................................................................................................... 2-1

2.2 Installing the Wireless 781S Smart Antenna .................................................................................. 2-2

2.2.1 Optimizing the Location ...................................................................................................... 2-2

2.2.2 Positioning the 781S .......................................................................................................... 2-2

2.2.3 Mounting the 781S ............................................................................................................. 2-2

2.3 Wiring the Module and 781S .......................................................................................................... 2-3

2.3.1 Wiring the 781S .................................................................................................................. 2-3

2.3.2 Wiring the IEC 62591 Module to the 781S ......................................................................... 2-5

2.4 Configuring Wireless Devices for the Network ............................................................................... 2-6

2.5 Preparing for Configuration and Commissioning ........................................................................... 2-9

Chapter 3 – Configuration and Commissioning 3-1

3.1 Overview ........................................................................................................................................ 3-2

3.1.1 Configuring Devices and Planning the Network................................................................. 3-2

3.1.2 Network ID and Join Key .................................................................................................... 3-3

3.1.3 Rosemount THUM™ Adapter ............................................................................................. 3-3

3.1.4 Active List and Commission List ........................................................................................ 3-4

3.2 IEC 62591 Sample Program(s) ...................................................................................................... 3-4

3.2.1 Before You Begin ............................................................................................................... 3-5

3.2.2 Accessing the IEC 62591 Sample Program(s) .................................................................. 3-5

3.2.3 Modifying the IEC62591_STRUCTS Datatypes Worksheet .............................................. 3-7

3.2.4 ErrorCatch Function Block (Optional) ................................................................................ 3-9

3.2.5 Modifying the DevData Function Block (Optional) ............................................................. 3-9

3.2.6 Modifying the ACT_LIST Function Block (Optional) ........................................................ 3-11

3.2.7 Configuring the Commission List ..................................................................................... 3-12

3.2.8 Specifying the Join Key .................................................................................................... 3-13

3.2.9 Specifying the Network ID and Slot Number .................................................................... 3-14

3.2.10 Configuring the Statistics List (Optional) ........................................................................ 3-14

3.2.11 Generating Alarms Based on IEC62591 Function Block Status (Optional) ................... 3-15

3.2.12 Additional Programming Notes ...................................................................................... 3-15

3.3 Commissioning Wireless Devices ................................................................................................ 3-16

3.3.1 Active Advertising ................................................................................................................ 3-16

3.4 Decommissioning or Replacing Wireless Devices ....................................................................... 3-17

3.5 WirelessHART Data Access and Statistics .................................................................................. 3-17

3.5.1 WirelessHART Data Access ............................................................................................ 3-17

3.5.2 WirelessHART Communication Statistics ........................................................................... 3-19

3.6 Upgrading Module Firmware ........................................................................................................ 3-19

Revised October 2021 iii

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Chapter 4 – Troubleshooting 4-1

4.1 Troubleshooting Guidelines ............................................................................................................ 4-1

4.2 Common Troubleshooting Techniques ........................................................................................... 4-2

4.2.1 Identify which System Components are Working ............................................................... 4-2

4.2.2 Basic Items to Check for Hardware .................................................................................... 4-3

4.2.3 Checking Error/Status Codes in the IEC 62591 Application ............................................... 4-3

4.3 Troubleshooting Checklist ............................................................................................................... 4-7

4.4 Best Practices ................................................................................................................................. 4-8

4.5 Data Updates .................................................................................................................................. 4-9

iv Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Chapter 1 – General Information

In This Chapter

1.1 Overview ...................................................................................................................... 1-1

1.2 Scope of Manual ......................................................................................................... 1-2

1.3 Hardware ..................................................................................................................... 1-2

1.3.1 IEC 62591 Wireless Interface Module ............................................................ 1-2

Emerson Wireless 781 Smart Antenna ............................................... 1-3

1.3.2

1.3.3 WirelessHART Field Devices ........................................................... 1-4

1.4 Configuration/Commissioning Software ...................................................................... 1-5

1.5 Additional Technical Information ................................................................................. 1-5

1.1 Overview

This manual covers both the hardware – the IEC 62591 Wireless Interface module for the ControlWave Micro device and the Emerson™ Wireless 781S Smart Antenna (“781S”) – and the software you need to configure and commission the hardware components.

Note: The IEC 62591 Wireless Interface uses open source software.

Refer to Open Source Software Listing (included in the same .zip file as this manual) for a complete listing of all components. Source code is available upon request by contacting Remote Automation Solutions Technical Support.

This chapter details the structure of this manual and provides an overview of the IEC 62591 Wireless Interface and its components.

The International Electrotechnical Commission’s 62591 standard (commonly called WirelessHART®) is a global IEC-approved standard that specifies an interoperable self-organizing mesh technology in which field devices form wireless networks that dynamically mitigate obstacles in the process environment. This architecture creates a costeffective automation alternative that does not require wiring and other supporting infrastructure.

Remote Automation Solutions’ IEC 62591 implementation consists of an IEC 62591 Wireless Interface module installed in a ControlWave Micro RTU. The module is wired to a field-installed 781S. The wiring powers the 781S and transmits data between the 781S and a number of field-installed WirelessHART devices. The ControlWave implementation supports up to 100 devices. (See Figure 1-1, which shows a ControlWave Micro, a 781S, and several WirelessHART devices.)

Revised October 2021 General Information 1-1

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 1-1. IEC 62591 Field Installation

1.2 Scope of Manual

This manual contains the following chapters:

1.3 Hardware

1.3.1 IEC 62591 Wireless Interface Module

Chapter 1 General Information

Chapter 2 Installation

Chapter 3 Configuring and Commissioning

Chapter 4 Troubleshooting

Provides an overview of the hardware for the IEC 62591 Wireless Interface.

Provides information on installing the IEC 62591 Wireless Interface modules, installing the 781S, and wiring the 781S to the module.

Provides information on using ControlWave Designer to configure and commission the Wireless Interface.

Provides general troubleshooting tips.

The IEC 62591 Wireless Interface has two basic components: the IEC 62591 Wireless Interface module (“module”) and the 781S.

The IEC 62591 module has the standard appearance of a ControlWave Micro module (see Figure 1-2).

1-2 General Information Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

USB Port

The module’s USB port supports firmware upgrades and provides

Figure 1-2. IEC 62591 Wireless Interface Module

You can place the module in any open I/O slot on the ControlWave Micro except the last slot of any housing (due to a mechanical restriction). Each ControlWave Micro can support only one IEC 62591 Wireless Interface module.

You cannot use the IEC 62591 with the ControlWave Micro Distributed I/O System.

Note: For information on installing modules in the ControlWave

Micro, refer to the ControlWave Micro Instruction Manual (part D301392X012).

debug information for product support. For further information, refer to Chapter 3, Configuration and Commissioning.

1.3.2 Emerson Wireless 781 Smart Antenna

The second component in the Wireless Interface is the Wireless 781S Smart Antenna (see Figure 1-3). You install the 781S away from the controller in the optimal location for best network performance. A 4wire connection between the module and the 781S provides the 12-30 Vdc power the 781S requires and transmits communication signals sent to the 781S from the various WirelessHART field devices.

Revised October 2021 General Information 1-3

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 1-3. Emerson Wireless 781S Smart Antenna

For instructions on installing the 781S, refer to Chapter 2, Installation.

1.3.3 WirelessHART Field Devices

The two components of Remote Automation Solutions’ IEC 62591 Wireless Interface provide you with the ability to manage data from a network of WirelessHART field devices. Remote Automation Solutions supports transmitters that conform to the WirelessHART protocol. The physical configuration of the IEC 62591 Wireless Interface is based on the ControlWave Micro and the total number of field devices. A ControlWave Micro implementation supports up to 100 devices.

Note: The IEC 62591 Wireless Interface Module is designed to return

the process and dynamic variables (PV, SV, TV, QV, slot 0, 1, 2,

3) from any device which meets the IEC 62591 specification (HCF_SPEC-285, Revisions 2.0). For a current list of the transmitters Remote Automation Solutions has tested with the IEC 62591 Interface, refer to the product data sheet

ControlWave Micro IEC 62591 (D301714X012) (available at www.EmersonProcess.com/RemoteAutomation). If you have a

WirelessHART device which does not appear in the product data

sheet. consult with the manufacturer of the device to determine whether the process variable values you want to collect are available through the PV, SV, TV, QV and slot 0, 1, 2, and 3. If the device meets the discrete control specification, it should work with the IEC 62591 Wireless Interface; alternatively, it may be treated like an analog wireless device. Always test any WirelessHART devices not listed to see whether they work with the IEC 62591 Wireless Interface before you install them in the field.

1-4 General Information Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Name

Part Number

ControlWave Micro IEC 62591 Interface

D301714X012

Field Tools Quick Start Guide

D301703X412

1.4 Configuration/Commissioning Software

Once you have installed the modules and wired them to the 781S, use ControlWave Designer, the AMS Device Configurator, or a hand-held HART configurator (such as the 375 or 475 Field Communicator or the AMS Trex™ Device Communicator) to configure and then commission (“activate”) the entire network.

To directly configure newer transmitters (such as the Rosemount 928 transmitter), use a hand-held field communicator, the AMS Device Manager, the AMS Wireless Configurator, or any WirelessHART communicator. For remote configuration, use the AMS Device Manager, the AMS Wireless Configurator, or the Smart Wireless Gateway.

Refer to Chapter 3, Configuring and Commissioning, for specific instructions.

1.5 Additional Technical Information

Refer to the following technical documentation (available at

www.Emerson.com) for additional technical and most-current

information:

Table 1-1. Additional Technical Information

Revised October 2021 General Information 1-5

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

1-6 General Information Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Chapter 2 – Installation

In This Chapter

2.1 Installing the IEC 62591 Module ...................................................... 2-1

2.2 Installing the Wireless 781S Smart Antenna ................................... 2-2

2.2.1 Optimizing the Location ........................................................ 2-2

2.2.2 Positioning the 781S ............................................................ 2-2

2.2.3 Mounting the 781S ............................................................... 2-3

2.3 Wiring the Module and 781S ........................................................... 2-3

2.3.1 Wiring the 781S .................................................................... 2-3

2.3.2 Wiring the IEC 62591 Module to the 781S ........................... 2-5

2.4 Configuring Wireless Devices for the Network ................................ 2-6

2.5 Preparing for Configuration and Commissioning ............................. 2-9

This chapter describes installing the IEC 62591 module in a ControlWave Micro, installing the Emerson Wireless 781S Smart Antenna (“781S”), and connecting the 781S to the IEC 62591 Wireless Interface module.

Note: This chapter covers the physical installation process. To

configure and commission the IEC 62591 Wireless Interface, refer to Chapter 3, Configuring and Commissioning.

2.1 Installing the IEC 62591 Module

You install the IEC 62591 Wireless Interface module in the ControlWave Micro as you would any other module. However, you can install only one IEC 62591 module.

Notes:

 Only ControlWave Micro’s with 05.50 (or newer) system firmware

support the IEC 62591 module. Version 5.70 (or newer) system firmware is required for discrete control.

 Version 05.80 (or newer) system firmware is required with IEC

Module Firmware V1.20 or later to support new Burst and Event parameters.

 You can install the IEC 62591 module in any I/O slot (slot 3 or

higher except for the last slot in any chassis/housing) in the ControlWave Micro. You cannot use the IEC 62591 with the ControlWave Micro Distributed I/O System.

1. Disconnect power from the ControlWave Micro.

2. Choose an open I/O slot (except for the last slot of any housing).

3. Locate the built-in guides on the top and bottom of the housing.

Revised October 2021 Installation 2-1

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Control room

RS-485 cable

Emerson Wireless 781S Smart Antenna

Mast or pipe

Infrastructure

4. Gently slide the IEC 62591 module into the housing until it seats

into the connectors on the interior back of the housing.

5. Restore power to the unit.

2.2 Installing the Wireless 781S Smart Antenna

This section covers where and how to install the 781S.

2.2.1 Optimizing the Location

Mount the 781S in a location that provides convenient access to the host system network (wireless I/O devices) and the network of wireless field devices. Find a location where the 781S has optimal wireless performance. Ideally, this is 4.6 to 7.6 m (15-25 ft) above the ground or 2 m (6 ft) above obstructions or major infrastructures. See Figure 2-1.

Figure 2-1. Mounting the 781S

2.2.2 Positioning the 781S

Position the 781S vertically approximately 3 ft. (1 m) from any large structure, building, or conductive surfaces to allow clear communication with other devices. If you are installing multiple antennas, ensure that each antenna has at least 3 feet of horizontal separation from any other. See Figure 2-1.

2-2 Installation Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

2.2.3 Mounting the 781S

You typically mount the 781S on a pipe or mast using the clamps provided in the kit (see Figure 2-2).

1. Insert the U-bolt around a 2-in. pipe or mast, through the saddle,

through the L-shaped bracket, and through the washer plate.

2. Use a ½-in. socket-head wrench to fasten the nuts to the U-bolt.

3. Secure the antenna to the L-shaped bracket with a 5/16-in. threaded

bolt.

4. Use a 5/16 in. wrench to tighten the nuts to the housing.

Figure 2-2. 781S Mounting

2.3 Wiring the Module and 781S

Note: Although its housing is permanently sealed, the 781S is prewired

and only needs to be connected to the module. Ensure that wiring between the IEC 62591 module and the 781S meets all appropriate local requirements (use of conduit, etc.).

This section assumes you have already installed the IEC 62591 module in the ControlWave Micro and installed the 781S in its permanent field location.

Communications between the IEC 62591 module and the 781S occur through an RS-485 connection. Remote Automation Solutions recommends that you use shielded, twisted-pair cable for I/O signal wiring. The twisted-pair minimizes signal errors caused by electromagnetic interference (EMI), Radio Frequency Interference (RFI), and transients. The removable terminal blocks on the module accept wire sizes up to 14 AWG.

2.3.1 Wiring the 781S

1. Power down the IEC 62591 module (if it is currently powered).

2. Connect the positive power lead to the “+” power terminal and the

negative power lead to the “–” power terminal.

3. Connect the data + lead to the “A (+)” terminal and the data – lead

to the “B (–)” terminal (see Figure 2-3).

Revised October 2021 Installation 2-3

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

4. Connect the grounding wire to the modules and seal any unused

conduit connectors.

If you are connecting multiple antennas, repeat this process for terminal connection 2.

A. Power output B. RS-485 comm

Figure 2-3. 781S Power and Data Wiring

2-4 Installation Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

From 781S

IEC 62591 Module

2.3.2 Wiring the IEC 62591 Module to the 781S

Note: Although its housing is permanently sealed, the 781S is prewired

and only needs to be connected to the module. Examine the two leads coming out of the 781S and identify which are the communication (RS-485) leads (white and blue) and the power leads (red and black). Connect the 781S to the module as shown in Figure 2-4.

Figure 2-4 provides a wiring diagram for the IEC 62591 module. You

must connect an RS-485 cable between the RS-485 port on the module and the 781S. This requires a Belden 2-twisted pair cable. Table 2-1 shows connections for the twisted pair cable.

You must also connect termination jumper wires as shown in Figure 2-

Table 2-1. RS-485 Cable Connections

A (+) (White/RS-485) A

B (–) (Blue/RS-485) B

POWER – (Black) GND

POWER + (Red) PWR

Figure 2-4. Power and Data Wiring from 781S to IEC 62591 Module

Revised October 2021 Installation 2-5

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Termination Jumpers

Figure 2-5. IEC 62591 Module – Connecting Termination Jumpers

2.4 Configuring Wireless Devices for the Network

See the product data sheet (available on

www.Emerson.com/RemoteAutomation) for a list of devices Emerson

has tested with the IEC 62591 Wireless Interface.

You must configure the following for each device in the wireless network:

 A long tag name (which is unique in the wireless network)

 A Network ID (must be the same for every device in the wireless

network)

 A Join Key (must be same for every device in the wireless network)

Caution

Configure all devices belonging to a site to use the same Network ID and join key. To avoid network errors, configure all devices in adjacent networks to use a different Network ID and join key.

You configure these values using the 375 or 475 Field Communicator or the AMS Device Configurator. If you have AMS Device Configurator software, see its online help for details on how to do this.

2-6 Installation Revised October 2021

Basic instructions for setting the long tag, Network ID and Join Key using the 375 Field Communicator are included below; see the 375

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

375 Main Menu

HART App

FOUNDA Settings Listen F ScratchPad

HART Applicationnnnnnnnnnnnnnnnnnnn Online

0:WHART01

1 Overview

2 Confi

3 Service Too

1 Guided Setup

2 Ma

Field Communicator User’s Manual (part 00375-0047-0001) if you

need more information.

1. Connect the Field Communicator clips to the communication

connectors on the wireless device, and turn the communicator on.

From the Main Menu, double-tap HART Application.

licationnnnnnnnnnnnnnnnnnnn

TION Fieldbus Application

or PC

2. When the HART application detects the device you want to

configure, double-tap on it.

nnnnnnnnnnnnnnnnnnnnnnn

3. From the Online Menu, double-tap Configure.

Online

gure nnnnnnnnnnnnnnnnnnnnnnn

4. From the Configure Menu, double-tap Manual Setup.

Revised October 2021 Installation 2-7

Configure

nual Setup nnnnnnnnnnnnnnnnnnnn

Alert Setup

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

1 Wirelessnnnn nnnnnnnnnnnnnnnnnnnn

2 Process Sensor 3 Percent of Rang 4 Device Temperatures 5 Device Information 6 Device Display 7 Other

1 Network ID 2 Join Device to Net… 3 Broadcas 4 C 5 6 Power Source

1 Tag

2 Lo

3 Device 4 Sensor 5 Wireless

1 LocationnnnnnnnnnnnnnnInternal Flash

2 Name 3 Config Type

5. From the Manual Setup Menu, double-tap Wireless.

Manual Setup

6. From the Wireless Menu, double-tap either:

a. Network ID to set the Network ID using the on-screen keypad.

b. Join Device to Net… to set the Join Key using the on-screen

keypad.

Wireless

t Rates

onfigure Broadca…

Power Mode

7. From the Manual Setup Menu (shown in Step 7), double-tap Device

Information to call up the Device Information menu, then choose Long Tag to set the long tag using the on-screen keypad.

Device Information

8. When you’re finished with your configuration, tap SAVE, and

choose to save the changes to the Internal Flash memory of the device and tap SAVE again.

Save as…

2-8 Installation Revised October 2021

ng Tagxxxxxxxxxxxxxxxxxxxxxxxxxxx

WHART01

Device

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

2.5 Preparing for Configuration and Commissioning

Once you have completed the wiring between the 781S and the ControlWave Micro, re-attach the plastic bezel covers and apply power to the ControlWave Micro.

Proceed to Chapter 3.

Revised October 2021 Installation 2-9

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

2-10 Installation Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Chapter 3 – Configuration and Commissioning

In This Chapter

3.1 Overview .......................................................................................... 3-2

3.1.1 Configuring Devices and Planning the Network ................... 3-2

3.1.2 Network ID and Join Key ...................................................... 3-3

3.1.3 Rosemount THUM™ Adapter ................................................ 3-3

3.1.4 Active List and Commission List........................................... 3-4

3.2 IEC 62591 Sample Program(s)........................................................ 3-4

3.2.1 Before You Begin ................................................................. 3-5

3.2.2 Accessing the IEC 62591 Sample Program(s)..................... 3-5

3.2.3 Modifying the IEC62591_STRUCTS Datatypes Worksheet 3-7

3.2.4 ErrorCatch Function Block (Optional) .................................. 3-9

3.2.5 Modifying the DevData Function Block (Optional) ............... 3-9

3.2.6 Modifying the ACT_LIST Function Block (Optional) .......... 3-11

3.2.7 Configuring the Commission List........................................ 3-12

3.2.8 Specifying the Join Key ...................................................... 3-13

3.2.9 Specifying the Network ID and Slot Number ...................... 3-14

3.2.10 Configuring the Statistics List (Optional) ............................ 3-14

3.2.11 Generating Alarms Based on IEC62591 Function Block Status

(Optional) ............................................................................ 3-15

3.2.12 Additional Programming Notes........................................... 3-15

3.3 Commissioning Wireless Devices.................................................. 3-16

3.3.1 Active Advertising ................................................................. 3-16

3.4 Decommissioning or Replacing Wireless Devices ........................ 3-17

3.5 WirelessHART Data Access and Statistics ................................... 3-17

3.5.1 WirelessHART Data Access............................................... 3-17

3.5.2 WirelessHART Communication Statistics ............................. 3-19

3.6 Upgrading Module Firmware ......................................................... 3-19

In addition to wiring the Emerson Wireless 781S Smart Antenna (“781S”) to the IEC 62591 module and applying power to the module, you need to configure your ControlWave project to access the wireless network so it can discover and commission each WirelessHART device in the entire network. You also need to individually configure each WirelessHART device that will belong in the network with a unique long tag name and a common Network ID and common Join Key.

Note: Refer to the AMS Device Manager Installation Guide (part

AW703M01V131EN) for instructions on using the AMS Device Configurator to configure the WirelessHART devices with the long tag name, Network ID, and Join Key.

Keep in mind that for each device configuration and commissioning is a two-step process:

 Configure each device using the AMS Device Configurator and a

HART modem (or you can use a hand-held configuration device such as the Emerson 375 or 475 Field Communicator. During this step you individually add network information (Network ID, Join Key, and long tag name) to the field-based wireless device.

Revised October 2021 Configuration and Commissioning 3-1

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 Use ControlWave Designer to program the ControlWave Micro so it

can detect the network and activate (or “commission”) each device.

3.1 Overview

As indicated previously, a wireless interface network consists of wireless devices, a 781S, and an IEC 62591 module installed in a ControlWave Micro. The IEC 62591 module can communicate with a maximum of 100 wireless devices; the actual number allowed for a given application varies depending upon the burst rate. An 8-second burst rate allows the full number of 100 devices, a faster burst rate (such as 1-second) reduces the number of devices allowed.

The configuration and commissioning tasks described in this chapter use a PC running ControlWave Designer.

Figure 3-1. Wireless Interface

3.1.1 Configuring Devices and Planning the Network

Before you can use a WirelessHART device, you must first configure it. For this task you may use the AMS Device Configurator and a HART modem (or you can use a field communicator (such as Emerson’s 375 or 475 Field Communicator. Ideally, you commission individual devices at a workbench in a protected environment, although you can fieldcommission a device you might add to the network. During the configuration, you identify the Network ID to which the device eventually belongs and provide the network-specific Join Key (see Network ID and Join Key).

During configuration, you must also give the wireless device a unique 32-character tag name based on its use or location (such as PMP1TEMP, PMP2PRES, or WEL02LVL).

Notes:

3-2 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 Tag names cannot exceed 32 characters, and the tag name must be

unique for this wireless network.

 You must configure the tag name as a long tag name. All references

to tag names in this manual refer to the long tag name.

 Use upper-case (capital) letters for tag names; this corresponds to

how the program internally stores tag names.

The individual devices should fit into a general organizational plan for your fields. By identifying logical groups and pre-assigning devices to those groups, you can eliminate guesswork during commissioning, efficiently define networks, and more quickly begin to acquire data.

Note: An important restriction in planning networks is to know that a

network can have only one Network ID, one Join Key, one 781S, and one controller (a ControlWave Micro supporting up to 100 devices).

3.1.2 Network ID and Join Key

A 5-character Network ID defines one logical grouping of WirelessHART devices, all of which send their information to one 781S. (You define a device’s Network ID when you first configure the device.) Valid values for the Network ID range from 1 to 36863.

Note: A Network ID or Join Key cannot be all zeros (such as 00000).

The Join Key is the password that allows a device to access its defined network. During configuration, you also provide the device with its network-specific Join Key. When you configure your ControlWave project using ControlWave Designer, you will need to know the Network ID and Join Key for this network.

3.1.3 Rosemount THUM™ Adapter

Note: Each THUM adapter supports only one wired HART device.

Rosemount’s THUM Adapter provides wireless connectivity to a wired HART device. If you have already commissioned a wired HART device into your network and want to connect it to a THUM adapter, you must first decommission the device, attach the THUM adapter, and then recommission the device. For further information about THUM adapters, refer to:

 Emerson™ Wireless 775 THUM™ Adapter Reference Manual,

00809-0100-4075

 Emerson™ Wireless 775 THUM™ Adapter Quick Installation

Guide, 00825-0100-4075

The Quick Installation Guide was packed in the box with the THUM; the Reference Manual is available through the Emerson website (www.Emerson.com/Rosemount).

Revised October 2021 Configuration and Commissioning 3-3

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

3.1.4 Active List and Commission List

When the 781S detects a wireless device that has the correct Network ID and Join Key, the IEC 62591 program running in the ControlWave Micro stores information about that device in a structure called the Active List. The Active List represents the entire network of wireless devices from which the 781S could potentially collect process variable data.

The program compares tag names for devices in the Active List to another structure called the Commission List. If a device in the Active List has a matching tag name in the Commission List, and its associated decommission flag is FALSE, the program stores configuration and process variable data for the device in the Commission List. The device is then considered to be “commissioned” as an active device in the network.

3.2 IEC 62591 Sample Program(s)

The ControlWave Designer software includes sample IEC 62591 programs that you can refer to or modify when creating your own IEC 62591-capable application. Alternatively, you can copy all the POUs, structures, and variables from one of the sample IEC 62591 programs into an existing ControlWave Designer project.

The sample programs include the IEC 62591 function block, as well as structure and type definitions needed for the commission list, active list, and statistics list.

Note: For details on specific parameters in the IEC 62591 function

block, refer to the ACCOL3 online help in ControlWave Designer.

3-4 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

3.2.1 Before You Begin

Some of the structure data types used in the IEC 62591 sample programs have changed over time to add functionality.

 The ControlWave Micro firmware version 5.80 includes

modifications for burst and event functionality for newly released transmitters. To use features available in the 5.80 firmware or later, earlier ControlWave projects must replace the COMMISSION_ARRAY or the COMMISSION_ARRAY_DISCRETE and the COMMISSION_POINT or the

COMMISSION_POINT_DISCRETE structure data types with the COMMISSION_ARRAY_V1_20 and COMMISSION_POINT_V1_20

structure data types, and then re-compile the projects. These burst and event data type definitions are available in the ACCOL3 online help for the IEC62591 function block in 5.80 or in the IEC62591_V1_20_Example.zwt sample project.

 ControlWave Micro firmware version 5.70 includes modifications

for discrete control functionality. To use features available in the

5.70 firmware, earlier ControlWave projects must replace the COMMISSION_ARRAY and the COMMISSION_POINT structure data types with the COMMISSION_ARRAY_DISCRETE and COMMISSION_POINT_DISCRETE structure data types, and then re-compile the projects. These discrete data type definitions are available in the ACCOL3 online help for the IEC62591 function block in 5.70 or in the IEC62591_DIO_Example.zwt sample project.

 You do not need to modify your application if you are not upgrading

the existing firmware (version 5.60 or earlier).

In addition to familiarity with ControlWave Designer programming, you will need to know the following information prior to modifying one of the sample programs.

 The Network ID for the wireless network  The Join Key for the wireless network  The unique long tag names assigned to each wireless device  The slot number in the ControlWave Micro that holds the IEC

62591 module

 The maximum number of wireless devices in your wireless network.

We recommend you specify a maximum number that includes room for growth of the network, in case you add a few more devices later.

3.2.2 Accessing the IEC 62591 Sample Program(s)

1. Start ControlWave Designer.

2. Click File >Open Project/Unzip Project

3. If not already there, navigate to the OpenBSI/Projects area and open

one of the IEC62591 sample projects.

Table 3-1. IEC 62591 Sample Programs

Revised October 2021 Configuration and Commissioning 3-5

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Sample Program Name

Description

EC62591_V1_20_Example.zwt

Addition of support for discrete control

firmware 5.60

IEC62591_V1_20_Example.zwt; Additional support for Burst Msg0 and

Burst Msg1 for newer transmitters with CW Micro Firmware 5.80 or newer and IEC module Firmware 1.20 or newer.

IEC62591_DIO_Example.zwt

IEC62591_Example.zwt

(use with CW Micro firmware 5.70 or newer).

Original version of IEC 62591 sample project (use with CW Micro or earlier).

Notes:

 The structures and names shown in the following sections

are representative of the original IEC 62591_Example.zwt project; subsequent sample projects may have variations in names but the purpose of the basic structures and variables (commission list, active list, join key, etc.) remains the same.

 See the program comments in the sample projects for the

most current information.

4. When you open the project, you can see the project tree. Figure 3-2

shows the different worksheets in the project tree.

3-6 Configuration and Commissioning Revised October 2021

The ACTIVE_DEVICES_ARRAY, The DevData function block definition is in this

other software.

The Act_List function block definition is in this

other software.

The Clist program definition is in this worksheet.

You set the Network ID,

The wireless program definition is in this

In the Global_Variables worksheet,

(COMM_LIST_SIZE).

The ErrorCatch function

block definition is in this worksheet. ErrorCatch allows you to capture error codes that only appear for a single task execution before they are reset.

(IEC62591_NETID) and Slot Number (IEC62591_SLOT) in the CONSTANTS section of this variables worksheet.

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

COMMISSION_ARRAY, INACTIVE_STAT_ARRAY, and LAST_STATE_ARRAY are defined/modified in this worksheet.

worksheet. It copies data from one of the internal structures used by the program to a LIST that you can collect with DataView, Harvester, or

worksheet. It copies data from the Active List to a LIST that you can collect with DataView, or

It initializes the Commission List. You must edit this program. For each device, you must enter tag names and set the decommission flag FALSE.

worksheet. You must specify the Join Key “strJoinKey” here. The statistics list is defined here too. This is also where function block calls to DevData, ErrorCatch, and Act_List occur.

you specify the list number of the Active List (ACTIVE_LISTNUM), the list size for the Active List (ACTIVE_LIST_SIZE) as well as the list size for the Commission List

Figure 3-2. IEC 62591 Example – Project Tree

The next several sections outline how to modify the various worksheets in the project tree to meet the needs of your wireless network.

3.2.3 Modifying the IEC62591_STRUCTS Datatypes Worksheet

The IEC62591_STRUCTS datatypes worksheet defines the data types used by the program. Double-click the IEC62591_STRUCTS worksheet to open it.

Caution

Revised October 2021 Configuration and Commissioning 3-7

Do not modify the datatypes themselves or your IEC 62591 program will not function correctly. You should define only the sizes of specific arrays (which may vary based on the number of devices in the wireless network.

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

3.2.3.1 ACTIVE_DEVICES_ARRAY_V1_20 datatype

The ACTIVE_DEVICES_ARRAY_V1_20 datatype defines an array of active points that make up the Active List structure for transmitters with adapter type and identification in the live list for firmware version

05.80.00 and later. The Active List maintains identification information on each wireless device discovered by the 781S.

Specify the array size to be equal to the maximum number of wireless devices you expect to exist in the network. This number should match the value of the ACTIVE_LIST_SIZE variable in the Global_Variables sheet.

TYPE ACTIVE_DEVICES_ARRAY_V1_20 : ARRAY [1..?] OF ACTIVE_POINT_V1_20; END_TYPE

3.2.3.2 ACTIVE_DEVICES_ARRAY datatype

The ACTIVE_DEVICES_ARRAY datatype defines an array of active points that make up the Active List structure. The Active List maintains identification information on each wireless device discovered by the 781S.

TYPE ACTIVE_DEVICES_ARRAY : ARRAY [1..?] OF ACTIVE_POINT; END_TYPE

3.2.3.3 COMMISSION_ARRAY_V1_20/COMMISSION_ARRAY_ DISCRETE/COMMISSION_ARRAY datatypes

These datatypes define an array of commission points that make up the Commission List structure. Which datatype you use depends on your application:

 COMMISSION_ARRAY_V1_20 and COMMISSION_POINT_ V1_20

datatypes are used in the IEC62591_V1_20_Example.zwt project. These structures provide for new transmitter controls (used in 5.80 or newer ControlWave Micro firmware).

 COMMISSION_ARRAY_DISCRETE and

COMMISSION_POINT_DISCRETE datatypes are used in the

IEC62591_DIO_Example.zwt project. These structures are required for discrete I/O control (used in 5.70 or newer ControlWave Micro firmware).

 The COMMISSION_ARRAY and COMMISSION_POINT datatypes

are used in the original IEC62591_Example.zwt project (used in

5.60 or earlier ControlWave Micro firmware).

The Commission List holds a long tag name and a decommission flag for each device from which you intend to collect data in your network. For any wireless device in the Commission List that has a matching tag name to a device in the Active List (meaning it was detected by the

3-8 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

781S) and its decommission flag is FALSE, the Commission List also stores configuration information and actual process variable data.

Specify the commission array size to be equal to the maximum number of commissioned devices you expect to exist in the network. This number should match the value of the COM_LIST_SIZE variable in the Global_Variables sheet.

TYPE

END_TYPE

TYPE

END_TYPE

TYPE COMMISSION_ARRAY : ARRAY [1..?] OF COMMISSION_POINT; END_TYPE

COMMISSION_ARRAY_V1_20:ARRAY [1..?] OF COMMISSION_POINT_V1_20;

COMMISSION_ARRAY_DISCRETE:ARRAY [1..?] OF COMMISSION_POINT_DISCRETE;

where ? is the maximum expected number of devices (including future expansion) for your network.

3.2.3.4 INACTIVE_STAT_ARRAY and LAST_STATE_ARRAY datatypes

The INACTIVE_STAT_ARRAY and LAST_STATE_ARRAY are a pair of optional arrays that hold statistics about transmitter communication failures. Both these arrays (if used) should be sized to be equal to the maximum number of commissioned devices you expect to exist in the network. This number should match the value of the COM_LIST_SIZE variable in the Global_Variables sheet.

TYPE INACTIVE_STAT_ARRAY : ARRAY [1..?] OF INT; END_TYPE

TYPE LAST_STATE_ARRAY : ARRAY [1..?] OF BOOL; END_TYPE

3.2.4 ErrorCatch Function Block (Optional)

The ErrorCatch function block is called from within the Wireless worksheet. It maintains counts for different types of configuration errors and status conditions. There is no need to modify it. The ErrorCatch function block stores the error counts in the list specified by the ERROR_CATCH_LISTNUM variable in the Global_Variables worksheet.

3.2.5 Modifying the DevData Function Block (Optional)

The various structures in the IEC 62591 program are maintained internally; they cannot be collected by external utilities such as DataView. To support this sort of data collection, the IEC 62591 program does include a special function block (DevData) that copies

Revised October 2021 Configuration and Commissioning 3-9

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Item

Description

characters)

bActive

A flag which indicates communication with the device

Primary process variable from the device (1st variable)

Secondary process variable from the device (2nd variable)

Tertiary process variable from the device (3rd variable)

Quaternary process variable from the device (4th variable)

which variables.

specific device data from the Commission array to a LIST structure that can be collected by an external program such as DataView.

As written in the original IEC62591_Example.zwt project, the DevData function block copies the following ten items from the COMMISSION_ARRAY.

TagName

Slot0Var, Slot1Var, Slot2Var, Slot3Var

The unique long tag name assigned to the device (up to 32

Wireless devices include a series of variables called “slots” which hold process data for the device such as temperature, pressure, scaling factors, altitude, flow, and so on. You can use the SlotxVar items to specify up to four of these slots for collection from the device. Consult the documentation for the particular wireless device for information on which slots hold

If you decide that you do not want all these items in the LIST structure, or you want to choose one or more different items from the list, you can modify the DevData function block definition.

To do this, double-click the DevData worksheet to open it.

For example, if you decided that you didn’t want the Slot3Var, and instead you wanted the serial number of the device you would do the following:

Change the ianyElement10 entry in the LIST structure to reference SerialNum instead of slot3Var. (To see the exact names of the different items you can choose for entries in the LIST structure, click on the IEC62591_STRUCTS worksheet and review the COMMISSION_POINT_DISCRETE or COMMISSION_POINT structure definitions.)

LIST010_1(iiListNumber:= inputListNum,

ianyElement1:= TagName, ianyElement2:= bActive, ianyElement3:= PV, ianyElement4:= SV, ianyElement5:= TV, ianyElement6:= QV, ianyElement7:= slot0Var, ianyElement8:= slot1Var, ianyElement9:= slot2Var, ianyElement10:= SerialNum); listStatus:=LIST010_1.odiStatus;

Now change the DEMUX function call for the tenth item to reference the serial number parameter of the COMMISSION_POINT structure instead of the iorSlot3 parameter:

DEMUX_10(ianyInput := commissionList[inputDevNum].odiSerialNumber,

3-10 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

iiSelect := 10, iiOutlist := inputListNum); demuxStat := DEMUX_10.odiStatus;

Now, instead of the slot3var value, the device serial number is copied.

Another possible modification you could make, if you wanted to copy more than ten items, would be to use a larger size LIST definition, say LIST30 or LIST100. Remember that if you do this, you must define the destination list to be the same type.

You may also choose to replace these LIST function blocks with the lists defined using ControlWave Designer’s Variable Extension Wizard and its resulting _LIST.INI file.

3.2.6 Modifying the ACT_LIST Function Block (Optional)

The Active List is a list maintained by the IEC62591 function block of all wireless devices detected by the 781S. The purpose of the ACT_LIST function block is to copy the contents of the Active List to another LIST that can be collected by external software such as DataView.

Note: In the IEC62591_V1_20_Example.zwt and the

IEC62591_DIO_Example.zwt projects, the ACT_LIST function block is called ActiveList.

The only thing you might modify for this is the LIST function block that is part of the ACT_LIST function block. By default, it uses a LIST020 function block which can have up to 20 elements – this allows a maximum of ten devices (defined by two elements for the tag name and device ID) in the active list. You can change this if you need to.

To do this, double-click the Act_List worksheet to open it.

LIST020_1( iiListNumber := inputListNum, ianyElement1 := Tag_1,

listStatus := LIST020_1.odiStatus;

ianyElement2 := DevId_1, ianyElement3 := Tag_2, ianyElement4 := DevId_2, ianyElement5 := Tag_3, ianyElement6 := DevId_3, ianyElement7 := Tag_4, ianyElement8 := DevId_4, ianyElement9 := Tag_5, ianyElement10 := DevId_5, ianyElement11 := Tag_6, ianyElement12 := DevId_6, ianyElement13 := Tag_7, ianyElement14 := DevId_7, ianyElement15 := Tag_8, ianyElement16 := DevId_8, ianyElement17 := Tag_9, ianyElement18 := DevId_9, ianyElement19 := Tag_10, ianyElement20 := DevId_10);

Suppose, for example, that you needed to allow up to 50 devices in the active list?

Revised October 2021 Configuration and Commissioning 3-11

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

ControlWave Designer supports LIST010, LIST020, LIST030, LIST050, and LIST100 function blocks. The easiest way to accommodate 50 devices is to replace the LIST020 function block with a single LIST100 function block. In the code, below, we don’t show devices 11 through 45 for space reasons:

LIST100_1( iiListNumber := inputListNum,

listStatus := LIST100_1.odiStatus;

ianyElement1 := Tag_1, ianyElement2 := DevId_1, ianyElement3 := Tag_2, ianyElement4 := DevId_2, ianyElement5 := Tag_3, ianyElement6 := DevId_3, ianyElement7 := Tag_4, ianyElement8 := DevId_4, ianyElement9 := Tag_5, ianyElement10 := DevId_5, ianyElement11 := Tag_6, ianyElement12 := DevId_6, ianyElement13 := Tag_7, ianyElement14 := DevId_7, ianyElement15 := Tag_8, ianyElement16 := DevId_8, ianyElement17 := Tag_9, ianyElement18 := DevId_9, ianyElement19 := Tag_10, ianyElement20 := DevId_10 : : ianyElement91 := Tag_46, ianyElement92 := DevId_46, ianyElement93 := Tag_47, ianyElement94 := DevId_47, ianyElement95 := Tag_48, ianyElement96 := DevId_48, ianyElement97 := Tag_49, ianyElement98 := DevId_49, ianyElement99 := Tag_50, ianyElement100 := DevId_50);

To support the maximum number of devices (100), you chain two LIST100 function blocks together. To do this, use the same iiListNumber parameter for each; that connects the two to allow for a 200-element list.

3.2.7 Configuring the Commission List

When the 781S detects a wireless device that can be included in the network, it adds information about that device to the Active List. Process data from the device is collected only if it has a matching tag name in the Commission List and if its decommission flag is FALSE.

Notes:

 The Commission List structure in the IEC62591 V1

20_Example.zwt project uses the COMMISSION_ARRAY_V1_20 datatype, the CommishList POU worksheet, and the CommissionList array (use with ControlWave Micro firmware 5.80 or newer).

 The Commission List structure in the IEC62591_DIO_Example.zwt

project uses the COMMISSION_ARRAY_DISCRETE datatype, the

3-12 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

the CommishList POU worksheet, and the CommissionListDiscrete array (use with ControlWave Micro firmware 5.70 or newer).

 The Commission List structure in the IEC62591_Example.zwt

project uses the COMMISSION_ARRAY datatype, the Clist POU worksheet, and the CommissionList array (use with ControlWave Micro firmware 5.60 or earlier)

You must create an entry in the Commission List that includes the long tag name for the device and decommission flag (set to FALSE) for each device you want the IEC 62591 module to access.

To do this, double-click the CommisList (or Clist) worksheet to open it, then add or modify Commission List definitions to include a valid long tag name for each iostrTagName and specify FALSE for the ibDecommission flag for each device you want to commission. Specify TRUE for the ibDecommission flag only if you don’t want to commission the device (for example, it is not yet ready to be added to your system).

In the code below, devices DEV_0001, DEV_0002, DEV_0003 and DEV_0004 all have their ibDecommission flag set to FALSE, so they all can be commissioned and have process variable data collected over the network. DEV_0005 has a decommission flag set to TRUE, so it cannot be commissioned and its process data is not collected unless that decommission flag is changed to FALSE.

IF (bInitCommList = TRUE) THEN bInitCommList := FALSE;

commissionList[1].iostrTagName := 'DEV_0001'; (* Tagname in wireless transmitter. *) commissionList[1].ibDecommission := FALSE; (* Commission the device when found. *)

commissionList[2].iostrTagName := 'DEV_0002'; commissionList[2].ibDecommission := FALSE;

commissionList[3].iostrTagName := 'DEV_0003'; commissionList[3].ibDecommission := FALSE; c commissionList[4].iostrTagName := 'DEV_0004'; commissionList[4].ibDecommission := FALSE;

commissionList[5].iostrTagName := 'DEV_0005'; commissionList[5].ibDecommission := TRUE; (* Device is commissioned only after * this is changed to FALSE. *)

END_IF;

There are other parameters in the Commission List that populate automatically when the program sees a match between the long tag names in the Commission List, and the long tag names in the Active List – the iostrTag Name and ibDecommission flag are the only portions you create or modify.

If, for some reason, you want to temporarily prevent data collection from a device in your wireless network, you can just set that device’s decommission flag to TRUE.

3.2.8 Specifying the Join Key

Revised October 2021 Configuration and Commissioning 3-13

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Specify the Network ID here.

Specify the slot that

module here.

All wireless devices in your wireless network share the same Join Key.

You must also specify the same Join Key in your ControlWave project. You specify the Join Key in the Wireless worksheet.

Double-click on the Wireless worksheet and specify the Join Key using the strJoinKey variable.

strJoinKey := '12345678-00000000-00000000-00000000';

3.2.9 Specifying the Network ID and Slot Number

The wireless network of devices detected by the 781S has a Network ID.

You must specify the Network ID in the IEC62591_NETID variable in the WirelessV worksheet of your ControlWave project.

In the same worksheet you use the IEC62591_SLOT variable to specify the slot number of the ControlWave Micro controller that holds the IEC 62591 module. The IEC 62591 module can reside in any open I/O slot (slot 3 or higher) except for the last slot in the chassis.

Double-click on the WirelessV worksheet and specify the Network ID and slot number.

holds the IEC 62591

Figure 3-3. Editing the WirelessV Worksheet

3.2.10 Configuring the Statistics List (Optional)

The optional Statistics List maintains information on the health of IEC 62591 communications for debugging purposes.

3-14 Configuration and Commissioning Revised October 2021

 In the IEC62591_V1_20_Example.zwt and the

IEC62591_DIO_Example.zwt projects, the Statistics list is defined in the StatsList worksheet.

 In the IEC62591_Example.zwt project, the Statistics list is defined

in the Wireless worksheet.

LIST020_1(iiListNumber:= SWFL_STATISTICS_LISTNUM, ianyElement1:= swflBytesXmtd, (* IEC62591 Interface # bytes transmitted *) ianyElement2:= swflBytesRcvd, (* IEC62591 Interface # bytes received *) ianyElement3:= swflBytesDiscarded, (* IEC62591 Interface # bytes discarded *) ianyElement4:= swflMsgsXmtd, (* IEC62591 Interface # messages transmitted *)

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

ianyElement5:= swflMsgsRcvd, (* IEC62591 Interface # messages received *) ianyElement6:= swflNacksXmtd, (* IEC62591 Interface # NAKs transmitted *) ianyElement7:= swflNacksRcvd, (* IEC62591 Interface # NAKs received *) ianyElement8:= swflMsgRetriesRcvd, (* IEC62591 Interface # of message retries *) ianyElement9:= swflSessionInitRcvd, (* IEC62591 Interface # session Initializations received *) ianyElement10:= swflSessionRestartXmtd, (* IEC62591 Interface # session restarts transmitted *) ianyElement11:= swflSetTimeMsgsXmtd, (* IEC62591 Interface # Set Time messages transmitted *) ianyElement12:= swflSetTimeMsgsRcvd, (* IEC62591 Interface # Set Time messages received *) ianyElement13:= swflResetApmMsgsXmtd, (* IEC62591 Interface # reset APM messages transmitted *) ianyElement14:= swflResetApmMsgsRcvd, (* IEC62591 Interface # reset APM transmitted *) ianyElement15:= swflTunnelMsgsXmtd, (* IEC62591 Interface # Tunnel messages transmitted *) ianyElement16:= swflTunnelMsgsRcvd, (* IEC62591 Interface # Tunnel messages received *) ianyElement17:= swflOtherHARTMsgsXmtd, (* IEC62591 Interface # other HART messages transmitted *) ianyElement18:= swflOtherHARTMsgsRcvd,(* IEC62591 Interface # other HART messages received *) ianyElement19:= swflRadioMsgsXmtd, (* IEC62591 Interface # Radio messages transmitted *) ianyElement20:= swflRadioMsgsRcvd); (* IEC62591 Interface # Radio messages received *)

diStatisticsListStatus := LIST020_1.odiStatus;

The number of the Statistics List is set in the Global_Variables worksheet and using the SWFL_STATISTICS_LISTNUM variable.

3.2.11 Generating Alarms Based on IEC62591 Function Block Status (Optional)

The IEC 62591 function block includes an odiStatus parameter which reports error and status codes for the IEC 62591 wireless interface. The ControlWave Designer online help provides descriptions of what the error and status codes mean. You may choose to implement control logic to generate an alarm for certain odiStatus values.

For example, beginning with 1.01 IEC 62591 module firmware, odiStatus codes in the range -51120 to -51129 indicate the IEC 62591 Wireless Interface Module had to re-start and cannot provide live data updates until the re-start process is complete. You could add the code below to your ControlWave project to implement an alarm for that range of values:

(* Execute IEC62591 Function Block Instance.*) IEC62591_1(…); (* Save the FB processing status. *) IEC62591Status := IEC62591_1.odiStatus; (* Set/Reset the alarm condition. *) bXMTRFrozen := (IEC62591Status <= DINT#-51120) AND (IEC62591Status >= DINT#-51129); (* Execute the ALARM FB when variable is TRUE/ON *) ALARM_LOGICAL_ON_1 ( : iaAlarmVar:=bXMTRFrozen, : );

3.2.12 Additional Programming Notes

The IEC 62591 example program includes two required program type POUs. InitList initializes the Commission List and WiLess uses the Wireless worksheet definitions and includes the actual IEC62591 function block. Both these program POUs reside within a CYCLIC task called “WirLess.”

Revised October 2021 Configuration and Commissioning 3-15

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 3-4. CYCLIC Task Running Wireless Program

Note: The WirLess task in the example program executes once per

second to ensure processing of data from the wireless network. Do not change the task Interval setting from 1000 ms (1 second).

Once programming is complete, compile and build the ControlWave project and download it into the ControlWave Micro.

3.3 Commissioning Wireless Devices

Once you download the completed project with the configured IEC 62591 program to the ControlWave Micro, the project executes and commissioning begins automatically.

Note: The 781S detects only those wireless devices that you have

already individually configured with a unique long tag name, a common Network ID, and common Join Key. You perform this configuration separately using the AMS Device Configurator and a HART modem or an Emerson 375/475 Field Communicator. For information on configuring these devices using the AMS Device Configurator, see the AMS Device Configurator documentation.

The 781S detects any configured wireless devices and reports them to the IEC 62591 module.

The executing program adds these devices to the Active List and checks for each device to see whether a matching device tag exists in the Commission List. Each device that has a matching tag along with an ibDecommission flag set to FALSE automatically becomes an active commissioned device in the network.

3.3.1 Active Advertising

In addition to the normal mode for detecting wireless devices, the system supports active advertising. In active advertising, the IEC 62591 module sends messages to the wireless network to keep radios active for a longer period of time to facilitate quicker detection of new (or replaced) wireless devices. Because leaving radios on consumes power, active advertising is only used under certain conditions:

3-16 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 When the IEC 62591 module is first powered on, or is restarted after

being powered off, it automatically remains in active advertising mode for a period of time to detect wireless devices.

 Whenever a new device is added to the network, active advertising

is activated for a period of time in case additional devices are also added.

 Whenever a device leaves the network (becomes unreachable) active

advertising is activated for a period of time to allow communications to be re-established.

 Beginning with ControlWave firmware version 5.70, the application

programmer can force active advertising using the ioaiMode parameter in the IEC62591 function block. See the ACCOL3 online help in ControlWave Designer for details.

3.4 Decommissioning or Replacing Wireless Devices

If you want to temporarily remove a wireless device from the network, modify the ControlWave project to edit the Commission List and set the ibDecommission flag for that device to TRUE, then compile and download the revised project.

If you want to permanently remove a wireless device from the network, modify the ControlWave project to remove the device from the Commission List, then compile and download the revised project.

If you only want to replace a device, for example, because it failed and you want to put an identical device in the same location, there is no need to decommission the device; simply use the AMS Device Configurator or a hand-held configuration device to specify the same long tag name, join key, and network ID in the replacement device, then install the new device normally, and it will join the network in place of the failed device.

3.5 WirelessHART Data Access and Statistics

The IEC 62591 Wireless Interface collects both WirelessHART data and statistics.

3.5.1 WirelessHART Data Access

The IEC62591 function block is pre-configured to return the Universal and Common HART parameters including:

 Long Tag  User Defined Message  User Defined Descriptor  Extended Device Type  Device ID  Manufacturer ID  Device Serial Number

Revised October 2021 Configuration and Commissioning 3-17

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 Adapter Type – THUM’s Expanded Device Type  Adapter ID – THUM’s Device ID  PV, SV, TV and QV Variable Units  Slot 0, 1, 2 and 3 Variable Units  PV, SV, TV and QV Variable Value  Slot 0, 1, 2 and 3 Variable Value  Primary Variable Loop Current  Device Status  Battery Life (you may want to generate an alarm when this falls

below a certain threshold; see Section 3.2.11 for information on generating alarms.)

 PV Loop current  Burst Rate

The following parameters require the discrete control version of the application and associated structures:

 Number of discrete channels

 Set class, Live Class, Set Point, and Live Value for each of up to

four (4) discrete channels

 Failsafe mode (hold last value or use failsafe value)

 Failsafe value for PV, SV, TV, and QV

 PV validity flags – such as NAN (Not a Number)

The following parameters require ControlWave firmware 5.80 or newer to support the application and associated structures:

 Displays the Min Update Time

 Max Update Time

 Trigger Mode

 Trigger Level

 Device Variable Classification

 Unit Code

 HART Command Execution Status.

Notes:

 The Commission List structure holds these items. You use the

DEV_DATA function block to access the parameters you need. See Section 3.2.5 for more information.

 The application you create must handle the PV validity flags. For

example, the IEC 62591 module reports the flag but does not set the PVs to NAN. It is up to the application to choose whether to force a NAN value, use the failsafe value, or use the last reported good value.

 Usage of the primary value (PV), secondary value (SV), tertiary

value (TV) and quaternary value (QV) vary depending on the type

3-18 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

of wireless device. For some devices, the primary value might be battery voltage, whereas for a different device it might be the loop current.

3.5.2 WirelessHART Communication Statistics

Detailed communication statistics are accumulated for the wireless network and optionally stored in the Statistics List (see Section 3.2.10). Transmit and receive data is accumulated for byte, message, session, tunnel, radio and other HART messages.

3.6 Upgrading Module Firmware

If a new version of firmware is released for the IEC 62591 module, either to support new features or correct problems, you can install it in the field through the module’s USB port.

Caution

Do not use the USB port unless the area is known to be non-hazardous.

To do this, you must know the name of the variable associated with the ioaiMode parameter of the IEC62591 function block.

1. Create a folder named upgrade in the root of a USB drive.

2. Copy the firmware file to the upgrade folder.

3. Insert the USB drive into the USB port of the IEC 62591 Wireless

Interface Module.

4. Using DataView or through ControlWave Designer in online

operation, change the value of the ioaiMode parameter to 2 to start the firmware download.

5. Monitor the odiStatus parameter on the IEC62591 function block.

While the download progresses, status code 51005 is reported. When the download completes the success code of 51006 appears momentarily; then 0 appears which means the firmware upgrade is complete. The upgrade takes approximately five minutes.

Revised October 2021 Configuration and Commissioning 3-19

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

3-20 Configuration and Commissioning Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Chapter 4 – Troubleshooting

In This Chapter

4.1 Troubleshooting Guidelines ............................................................. 4-1

4.2 Common Troubleshooting Techniques ............................................ 4-2

4.2.1 Identify which Components of the System Are Working ...... 4-2

4.2.2 Basic Items to Check for Hardware ...................................... 4-3

4.2.3 Checking Error/Status Codes in the Standard IEC 62591

Application ............................................................................ 4-3

4.3 Troubleshooting Checklist ............................................................... 4-7

4.4 Best Practices .................................................................................. 4-8

4.5 Data Updates ................................................................................... 4-9

This chapter includes some general troubleshooting guidelines, as well as tips on certain common problems and how to overcome them.

4.1 Troubleshooting Guidelines

Before you begin to trouble-shoot the interface, you should observe the following guidelines.

 Don’t overlook the obvious. With all the activity involved in

setting up a wireless network, it is easy to accidentally unplug an antenna or disconnect power from a device. Check those things first. (For a list of common problems, see the Troubleshooting Checklist at the end of this chapter.)

 If something worked previously, but now has stopped working,

did you change something? If, for example, you change the

application running in the ControlWave Micro and re-download it, and now it stopped working, it’s possible that the change you made to the application might have caused a problem.

 Adopt a systematic approach. Don’t try to solve the problem by

changing several different things at once. Change one thing, see if it causes an improvement, then make notes about what you did, then you can try to make other changes. If you haphazardly begin swapping hardware modules, re-routing cables, and changing software parameters, you may end up in worse shape than when you started, or you may end up masking symptoms of an underlying problem.

 Try to isolate the problem. If, for example, you can communicate

with some wireless devices but not others, then concentrate on what’s different with the non-functional wireless devices, or their configuration parameters. If you can’t communicate with any wireless devices, your might not have correctly configured network parameters in the application, or there may be a problem at the 781S.

Revised October 2021 Troubleshooting 4-1

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 Use the hardware and software diagnostic tools provided with

the product. The ControlWave Micro process automation controller

includes status LEDs on both the CPU and PSSM modules; see the ControlWave Micro instruction manual for explanations of what these status LEDs mean. The IEC 62591 wireless application running in the ControlWave Micro includes error codes which you can check; often these will identify configuration problems for you.

 Collect and save as much relevant information as you can. If

possible, make notes concerning what steps you took leading up to the initial occurrence of the problem. Save printouts, screen captures, error codes, and so on so you can refer to them if you need to call for technical assistance.

The remainder of this section includes:

 Troubleshooting Techniques  Troubleshooting Checklist

4.2 Common Troubleshooting Techniques

4.2.1 Identify which System Components are Working

The wireless interface has several different pieces of hardware and software. A failure in any one of them can cause problems, so you should consider all the different pieces to try to identify the source of your problem.

For hardware you have:

 ControlWave Micro controller with IEC 62591 module installed in a

slot (other than slot 3)

 Emerson Wireless 781S Smart Antenna (“781S”)

 PC or laptop connected the ControlWave Micro

 Cable between the IEC 62591 module and the 781S  One or more wireless devices in the wireless network

 Hand-held Field Communicator (optional)

For software you have:  The IEC 62591 application (ControlWave project) running in the

ControlWave Micro

 ControlWave Designer and AMS Device Configurator software

running in the PC or laptop

 IEC 62591 protocol software running in the 781S and in all the

wireless devices

4-2 Troubleshooting Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 4-1. Wireless Interface

4.2.2 Basic Items to Check for Hardware

 Ensure power is connected.  Check that all modules are properly seated in slots.  Ensure cable connections are good between the 781S and controller,

and between the PC/laptop and the controller.

 Check status LEDs on the controller. For information on what the

LEDs mean, see the ControlWave Micro Instruction Manual (part D301392X012).

 Check for indications on the 781S. See its accompanying

documentation for details.

4.2.3 Checking Error/Status Codes in the IEC 62591 Application

This procedure assumes that:

 You have ControlWave Designer installed on the PC/laptop.  You are running the standard IEC 62591 application (ControlWave

project) in the ControlWave Micro and have an identical copy of the project on the PC/laptop.

 You have a successful communication connection between the

PC/laptop and the ControlWave Micro.

1. Start ControlWave Designer (if it is not already running).

2. Click File >Open Project/Unzip Project

3. If not already there, navigate to the OpenBSI/Projects area and open

the file IEC62591_Example.mwt. When you open the project, you can see the project tree. (See Figure 4-2.)

Revised October 2021 Troubleshooting 4-3

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Wireless* program

worksheet

Figure 4-2. IEC 62591 Example – Project Tree

4. Click Online > Debug.

5. Double-click on the wireless* program worksheet.

6. Scroll down through the worksheet until you see the IEC 62591

function block. (In Debug Mode, a column of live values sits to the left of the program statements; these are the actual parameter values in the program as it executes in the ControlWave Micro.)

4-4 Troubleshooting Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Column of live values

odiStatus value of IEC62591 function block

odiStatus parameter

Figure 4-3. Wireless Program Worksheet

7. Find the odiStatus parameter for the IEC62591 function block (see

Figure 4-3). In this example, the odiStatus parameter has the

variable name IEC62591Status; if your programmer used a different name, then the name will be different but the parameter is the same.

8. Look for the value of the odiStatus parameter value in the column of

live values. In Figure 4-3 that value is –51012; the negative value indicates an error.

9. To find out what the –51012 error means, go to the project tree and

right-click on the ACCOL3 library icon, and choose Help on ‘ACCOL3’ library.

Figure 4-4. Calling Up the ACCOL3 Help Files

Revised October 2021 Troubleshooting 4-5

10. Go to the ACCOL3 Function Blocks help and scroll down (or

expand the tree item) until you get to the IEC62591 help topic, then click on it.

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 4-5. Selecting the IEC62591 Help Topic

11. Scroll down in the IEC62591 help topic until you find the

odisStatus description and click on the status code link to bring up a list of status codes. (You may want to print out this list for reference as you’re troubleshooting.)

Figure 4-6. Status Code Link

12. Find the code you’re looking for (here, –51012) and you’ll see what

the error means. For “-51012” the error says:

Figure 4-7. Example of Error Message

That means the IEC 62591 function block does not detect an IEC 62591 Wireless Interface module in the specified slot. This happens if you specify an incorrect slot number in the application or if the module is missing entirely.

Alternatively, if you know the complete error number, you can use the Search tab to type in the error code, then click List Topics, and double-click on the results to see the error.

4-6 Troubleshooting Revised October 2021

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Figure 4-8. Search Tab

Note: You can follow this same basic procedure to look up any

odiStatus parameter value. In addition, if you specified a list for storing error totals in the application, you can view statistics on what types of errors are occurring. To do this, you should double-click on the ErrorCatch worksheet. Alternatively, you could use DataView to view the ErrorCatch list.

4.3 Troubleshooting Checklist

 Does the IEC 62591 Wireless Interface support your wireless

device(s)? Check the product data sheet (available on

www.Emerson.com) to verify that your devices have been tested

with the interface.

 Did you assign a unique Long Tag Name to each wireless device

and specify the exact same long tag names in the IEC 62591 application running in the ControlWave Micro? If not, use the AMS Device Configurator software or a 375/475 Field Communicator to set the long tag name in the device, and use ControlWave Designer to set the long tag names within the IEC 62591 application running in the ControlWave Micro.

 Did you assign a Network ID which must be the same in each

wireless device in this network, and must also match the Network ID defined in the IEC 62591 application running in the ControlWave Micro? If not, use the AMS Device Configurator software or a 375/475 Field Communicator to set the Network ID in the devices, and use ControlWave Designer to set the Network ID within the IEC 62591 application running in the ControlWave Micro.

 Did you assign a Join Key which must be the same in each and

every wireless device in this network, and must also match the Join Key defined in the IEC 62591 application running in the ControlWave Micro? If not, use the AMS Device Configurator software or a 375/475 Field Communicator to set the Join Key in the devices, and use ControlWave Designer to set the Join Key within the IEC 62591 application running in the ControlWave Micro.

Revised October 2021 Troubleshooting 4-7

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

 Is the IEC62591 module in the ControlWave Micro in the proper

slot as specified in the IEC 62591 application running in the ControlWave Micro? If not, place the module in the proper slot or change the slot number defined in the IEC 62591 application to match the slot in which the module resides.

 Are you using the proper datatypes for the Commission List and

Commission Point?

 Is the decommission flag for each device set to FALSE in the IEC

62591 application running in the ControlWave Micro?

 Does each device in the network have power? If not, connect power.  Are cables connected properly between the 781S and the

ControlWave Micro?

 Are any status LEDs lit on the ControlWave Micro PSSM module?

If so, consult the ControlWave Micro Instruction Manual (D301392X012) for more information.

 Did you check for error/status codes in the IEC 62591 application?

If not, follow the instructions in Section 4.2.3.

4.4 Best Practices

While the IEC62591 function block makes device data available to the application and SCADA it does not take independent action unless the application is designed to do so. The best recommended practice to ensure that the end device is operating optimally is to either configure the SCADA system to monitor the status of the field devices or develop application solutions using the RTU's alarm, event, or Report By Exception features. Information needed to make these decisions is available in following elements of the commission list entry and the IEC62591 function block status:

 odiStatus: IEC6259 function block status output parameter  obActive: Device is actively communicating  ousDeviceStatus: Device status bits  ouiBatteryDays: Status of the device's lithium battery  ousDevCommishStatus: Device commissioning status  iousiFailSafeMode: Device failsafe mode  obyteNaNFlag: Whether slot or process variable(s) are Not-A-

Number

 obyte'xx'Status: Four process variable status bits  obyteLive'n'Status: Four live value status bits

4-8 Troubleshooting Revised October 2021

4.5 Data Updates

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

If you notice that data updates for process variables are slow, this can occur if the IEC 62591 device cannot process a data request fast enough. This can generate a delayed response message, causing the RTU to rerequest the data.

To see if you are receiving delayed response messages, look for a 9 (Delayed Response Received) status on the ousDevCommishStatus parameter of the Commission List entry.

Revised October 2021 Troubleshooting 4-9

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

[This page is intentionally left blank.]

4-10 Troubleshooting Revised October 2021

Index

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

Commissioning ................................................... 3-1

Configuration ...................................................... 3-1

Emerson Wireless 781S Smart Antenna ............ 1-2

Field Devices ...................................................... 1-4

Figures

1-1. IEC 62591 Field Installation .................... 1-2

1-2. IEC 62591 Wireless Interface Module .... 1-3

1-3. Emerson Wireless 781S Smart Antenna 1-4

2-1. Mounting the 781S .................................. 2-2

2-2. 781S Mounting ........................................ 2-3

2-3. 781S Power and Data Wiring .................. 2-4

2-4. Power & Data Wiring (781S to IEC 62591

Module) ...................................................... 2-5

2-5. IEC 62591 Module - Connecting

Termination Jumpers ................................. 2-6

3-1. Wireless Interface ................................... 3-2

3-2. IEC 62591 Example – Project Tree ........ 3-7

3-3. Editing the WirelessV Worksheet .......... 3-14

3-4. CYCLIC Task Running Wireless Program 3-

4-1. Wireless Interface ................................... 4-3

4-2. IEC 62591 Example – Project Tree ........ 4-4

3-2. Wireless Program Worksheet ................. 4-5

4-4. Calling Up the ACCOL3 Help Files ......... 4-5

4-5. Selecting the IEC62591 Help Topic ........ 4-6

4-6. Status Code Link ..................................... 4-6

4-7. Example of Error Message ...................... 4-6

4-8. Search Tab .............................................. 4-7

Hardware ............................................................ 1-2

IEC 62591 Wireless Interface module ................ 1-2

Installation

IEC 62591 Wireless Interface module ............ 2-1

Lists

connecting multiple List function blocks together

to make long lists ..................................... 3-12

Module

Description ...................................................... 1-3

Related technical information ............................. 1-5

Table 1-1. Additional Technical Information ....... 1-5

Tables

2-1. RS-485 Cable Connections ..................... 2-5

3-1. IEC 62591 Sample Programs ................. 3-5

USB port ............................................................. 1-3

Wiring .................................................................. 2-3

Revised October 2021 Index I-1

IEC 62591 Wireless Interface Instruction Manual (for ControlWave Micro)

For customer service and technical support,

Global Headquarters, North America, and Latin America:

end-user.

Europe:

Middle East/Africa:

Asia-Pacific:

T +65 6777 8211| F +65 6777 0947

visit www.Emerson.com/SupportNet.

Emerson Automation Solutions Remote Automation Solutions 6005 Rogerdale Road Houston, TX 77072 U.S.A. T +1 281 879 2699 | F +1 281 988 4445

www.Emerson.com/RemoteAutomation

Emerson Automation Solutions Remote Automation Solutions Unit 1, Waterfront Business Park Dudley Road, Brierley Hill Dudley DY5 1LX UK T +44 1384 487200 | F +44 1384 487258

Emerson Automation Solutions Remote Automation Solutions Emerson FZE P.O. Box 17033 Jebel Ali Free Zone – South 2 Dubai U.A.E. T +971 4 8118100 | F +971 4 8865465

Emerson Automation Solutions Remote Automation Solutions 1 Pandan Crescent Singapore 128461

This publication is for informational purposes only. While every effort has been made to ensure accuracy, this publication shall not be read to include any warranty or guarantee, express or implied, including as regards the products or services described or their use or applicability. Remote Automation Solutions (RAS) reserves the right to modify or improve the designs or specifications of its products at any time without notice. All sales are governed by RAS terms and conditions which are available upon request. RAS accepts no responsibility for proper selection, use or maintenance of any product, which remains solely with the purchaser and/or

Remote Automation Solutions

Fisher IEC62591 Wireless Interface Instruction Manual (for ControlWave Micro) - D5139 Manuals & Guides

Specifications and Main Features

Frequently Asked Questions

User Manual

Chapter 1 – General Information

1.1 Overview

1.2 Scope of Manual

1.3 Hardware

1.3.1 IEC 62591 Wireless Interface Module

1.3.2 Emerson Wireless 781 Smart Antenna

1.3.3 WirelessHART Field Devices

1.4 Configuration/Commissioning Software

1.5 Additional Technical Information

Chapter 2 – Installation

2.1 Installing the IEC 62591 Module

2.2 Installing the Wireless 781S Smart Antenna

2.2.1 Optimizing the Location

2.2.2 Positioning the 781S

2.2.3 Mounting the 781S

2.3 Wiring the Module and 781S

2.3.1 Wiring the 781S

2.3.2 Wiring the IEC 62591 Module to the 781S

2.4 Configuring Wireless Devices for the Network

2.5 Preparing for Configuration and Commissioning

Chapter 3 – Configuration and Commissioning

3.1 Overview

3.1.1 Configuring Devices and Planning the Network

3.1.2 Network ID and Join Key

3.1.3 Rosemount THUM™ Adapter

3.1.4 Active List and Commission List

3.2 IEC 62591 Sample Program(s)

3.2.1 Before You Begin

3.2.2 Accessing the IEC 62591 Sample Program(s)

3.2.3 Modifying the IEC62591_STRUCTS Datatypes Worksheet

3.2.3.1 ACTIVE_DEVICES_ARRAY_V1_20 datatype

3.2.3.2 ACTIVE_DEVICES_ARRAY datatype

3.2.3.3 COMMISSION_ARRAY_V1_20/COMMISSION_ARRAY_ DISCRETE/COMMISSION_ARRAY datatypes

3.2.3.4 INACTIVE_STAT_ARRAY and LAST_STATE_ARRAY datatypes

3.2.4 ErrorCatch Function Block (Optional)

3.2.5 Modifying the DevData Function Block (Optional)

3.2.6 Modifying the ACT_LIST Function Block (Optional)

3.2.7 Configuring the Commission List

3.2.8 Specifying the Join Key

3.2.9 Specifying the Network ID and Slot Number

3.2.10 Configuring the Statistics List (Optional)

3.2.11 Generating Alarms Based on IEC62591 Function Block Status (Optional)

3.2.12 Additional Programming Notes

3.3 Commissioning Wireless Devices

3.3.1 Active Advertising

3.4 Decommissioning or Replacing Wireless Devices

3.5 WirelessHART Data Access and Statistics

3.5.1 WirelessHART Data Access

3.5.2 WirelessHART Communication Statistics

3.6 Upgrading Module Firmware

Chapter 4 – Troubleshooting

4.1 Troubleshooting Guidelines

4.2 Common Troubleshooting Techniques

4.2.1 Identify which System Components are Working

4.2.2 Basic Items to Check for Hardware

4.2.3 Checking Error/Status Codes in the IEC 62591 Application

4.3 Troubleshooting Checklist

4.4 Best Practices

4.5 Data Updates

Index

Revised October 2021 Index I-1
