Installation Guide
English – February 2014
D103074X014
Type HSR
Introduction
This Installation Guide provides instructions for
installation, startup and adjustment. To receive a copy of
the Instruction Manual, contact your local Sales Ofce or
view a copy at www.sher.com. For further information
refer to: Type HSR Instruction Manual D103074X012.
PED Categories
This product may be used as a safety accessory with
pressure equipment in the following Pressure Equipment
Directive categories. It may also be used outside of the
Pressure Equipment Directive using sound engineering
practice (SEP) per table below. For information on the
current PED revision see Bulletin: D103053X012.
SIZE,
DN / NPS
20, 25 /
3/4, 1
BODY
MATERIAL
All All - - - - SEP
END
CONNECTION
STYLE
PED
LIMITATION
PED
CATEGORY
Specications
Body Sizes (Inlet x Outlet) and
End Connection Styles
3/4, 3/4 x 1 and 1 NPT
All sizes available in Globe or Angle body
Allowable Inlet Pressures
Emergency: 10.3 bar / 150 psig
Maximum Operating Pressure: See Table 1
Allowable Outlet Pressures
Emergency (Casing): 1.7 bar / 25 psig
Maximum Operating Pressure to Avoid Internal
Parts Damage: 0.21 bar / 3 psi differential above
outlet pressure setting
Outlet Pressure Ranges
See Table 2
Proof Test Pressure
All Pressure Retaining Components have been
proof tested per Directive
Temperature Capabilities
-29 to 71°C / -20 to 160°F
(1)
(1)
(1)
Table 1. Maximum Operating Inlet Pressure
ORIFICE SIZE
mm In. bar
3.2
4.8
6.4
9.5
13
1/8
3/16
1/4
3/8
1/2
MAXIMUM OPERATING INLET
PRESSURE TO OBTAIN GOOD
REGULATING PERFORMANCE
8.6
6.9
4.1
2.1
1.4
Installation
WARNING
Personal injury, equipment damage
or leakage due to escaping gas or
bursting of pressure-containing parts
might result if these regulators are
overpressured or installed where service
conditions could exceed the limits for
which the regulators were designed,
or where conditions exceed any
ratings of the adjacent piping or piping
connections. To avoid such injury or
damage, provide pressure-relieving or
pressure-limiting devices (as required
by the appropriate code, regulation or
standard) to prevent service conditions
from exceeding those limits.
Additionally, physical damage to a
regulator could cause personal injury
and property damage due to escaping
gas. To avoid such injury and damage,
install the regulator in a safe location.
A regulator may vent some gas to the
atmosphere in hazardous or ammable
gas service, vented gas might
accumulate and cause personal injury,
death or property damage due to re or
explosion. Vent a regulator in hazardous
gas service to a remote, safe location
away from air intakes or any hazardous
location. The vent line must be protected
against condensation or clogging.
psig
125
100
60
30
20
1. The pressure/temperature limits in this installation guide and any applicable standard or code limitation should not be exceeded.
!
!
!
Type HSR
Before installing the regulator, check for damage
which might have occurred in shipment. Also check
for dirt or foreign matter which may have accumulated
in the regulator body or in the pipeline. Apply pipe
compound to the male threads of the pipeline
and install the regulator so that the ow is in the
direction of the arrow cast on the side of the body.
The diaphragm actuator assembly can be rotated to
any position relative to the body, in 90° increments.
Remove the two cap screws that hold the body
to the actuator in order to rotate the diaphragm
actuator assembly.
Do not install the regulator in a location where there
can be excessive water accumulation, such as directly
beneath a downspout or in an undrained pit.
To obtain the maximum ow capacities or other
performance characteristics, the length of pipe from
the regulator outlet to the meter should have no bends
and should be the same size as the regulator outlet.
Replace the regulator if water gets into the spring case
or the lower casing of the regulator.
CAUTION
You are advised to use new vent
piping because defective threads on
the relief vent piping may interfere
with the venting assembly if the
piping obstructs the movement of the
vent apper.
On indoor installations, the vent should be piped
outside the building. Remove the screen from the
regulator vent connection and connect vent piping
from that connection to the outdoors. Install a weather
and insect resistant vent assembly on the outside
end of the pipe. Inspect the vent opening regularly.
On some installations, it may be necessary to install
the regulator beneath a protective hood. The vent
should be pointing or sloping down sufciently to allow
any condensate to drain. Also check the regulator
periodically for external or internal corrosion.
Overpressure Protection
Type HSR regulators provide internal relief that limits the
total outlet pressure buildup over setpoint. This internal
relief may be adequate for the application, if not, provide
additional pressure relief or a pressure-limiting device
downstream. Regulators should be inspected for damage
after any overpressure condition.
WARNING
To avoid personal injury or property
damage due to explosion or damage to
regulator or downstream components
during startup, release downstream
pressure to prevent an overpressure
condition on the diaphragm of
the regulator.
In order to avoid an overpressure
condition and possible equipment
damage, pressure gauges should
always be used to monitor pressures
during startup.
Startup
With proper installation completed, slowly open the
shutoff valve. Check all connections for leaks. Check
the downstream equipment for proper operations.
Adjustment
To increase the outlet pressure setting, turn
the adjusting screw clockwise. To reduce the
outlet pressure setting, turn the adjusting screw
counterclockwise. A pressure gauge should always
be used to monitor downstream pressure while
adjustments are being made. Do not adjust the spring
to produce an outlet pressure setting above the limit
identied on the information label. If the required
pressure setting is not within the range of the spring
being used, substitute with the correct spring. When
changing the spring, also change the range identied
on the information label to indicate the actual pressure
range of the spring in use. After the spring adjustment
has been completed, replace the closing cap.
WARNING
Some type of overpressure protection
is needed if actual inlet pressure can
exceed the outlet pressure rating.
Overpressuring any portion of this
equipment may cause damage to
regulator parts, leaks in the regulator
or personal injury due to bursting of
pressure-containing parts or explosion
of accumulated gas.
2
Taking Out of Service (Shutdown)
WARNING
To avoid personal injury resulting from
sudden release of pressure, isolate
the regulator from all pressure before
attempting disassembly.
T80573
Type HSR
27
9
17
Figure 1. Type HSR Regulator Assembly
mbar In. w.c.
10 to 15 4 to 6 Orange
15 to 20 6 to 8 Yellow
20 to 25 8 to 10 Black
25 to 31 10 to 12.5 Silver
31 to 50 12.5 to 20 Gray
50 to 87 20 to 35 Pink
0.09 to 0.15 bar 1.25 to 2.2 psig Light Blue
Parts List
Key Description
1 Spring Case Assembly
2 Lower Casing
3 Screen
4 Lever
5 Stem
6 Straight Pin
7 Machine Screw
8 Closing Cap
9 Machine Screw
10 Relief Valve Spring
11 Diaphragm
12 Pusher Post
Table 2. Outlet Pressure Ranges
OUTLET PRESSURE RANGE
SPRING COLOR
Key Description
13 Lower Spring Seat
14 Relief Spring Retainer
15 Body
16 O-ring
17 Cap Screw
22* Orice
23* Disk
25 Spring
26 Adjusting Screw
27 Information Label
31 Closing Cap O-ring (only CSA)
*Recommended spare part
3
Type HSR
Emerson Automation Solutions
Americas
McKinney, Texas 75070 USA
T +1 800 558 5853
+1 972 548 3574
Europe
Bologna 40013, Italy
T +39 051 419 0611
Asia Pacic
Singapore 128461, Singapore
T +65 6777 8211
Middle East and Africa
Dubai, United Arab Emirates
T +971 4 811 8100
L1
15
23
5
10
14
25
1
26
8
L2
31
3
2
22
T80573
APPLY LUBRICANT(1)
L1 = ANTI-SEIZE COMPOUND
L2 = MULTI-PURPOSE POLYTETRAFLUOROETHYLENE (PTFE) LUBRICANT
NOTE: KEY 31 ONLY USED ON UNITS WITH CSA APPROVAL.
1. Lubricants must be selected such that they meet the temperature requirements.
L1 L2
16
Figure 1. Type HSR Regulator Assembly (continued)
