Extron electronic IN1508 User Manual 2

IN1508 – Setup Guide

N For full installation, configuration, and operation details, refer to the

IN1508 User’s Manual, available at www.extron.com.

This guide provides quick start instructions for an experienced installer to set up and
operate the Extron IN1508 Scaling Presentation Switcher.

Installation and cabling

100-240V 50-60Hz

Connections

1

3

VID

I

N

P

VIDYCYC

U

T

50/60Hz

1 6 12117

2 4

2 5 9843

Y

R-Y

B-Y

5

6

RGB

RGB

7

LISTED

1T23

C

U S

I.T.E.

DVI

8

OUTPUT

RGB

Y, B-Y, R-Y

AUDIO INPUT

1 2 3 4 5

L

R

OUTPUT

A

6

L

B

L R

8

7

R

10

RS-232

AC power connector

a

Inputs 1 and 2 composite video BNC connectors

b

Inputs 3 and 4 S-video mini-DIN connectors

c

Input 5 component video BNC connectors

d

Inputs 6 and 7 RGB video 15-pin HD connectors

e

Input 8 DVI video connector (DVI-D only)

f

Output 15-pin HD connector

g

Audio Inputs 1 through 5 RCA connectors

h

Audio Inputs 6 through 8 3.5 mm mini stereo jacks

i

Audio Output A RCA connectors

j

Audio Output B captive screw connector

k

RS-232 9-pin D connector

l

Step 1 — Mounting

Turn off or disconnect all equipment power sources. For tabletop use, affix the rubber feet. For
optional rack mounting, secure the supplied brackets (see image at right) and mount in a rack.

Step 2 — Video inputs and output

1

a. Inputs 1 and 2 — Connect composite video

sources to these female BNC connectors.

b. Inputs 3 and 4 — Connect S-video sources

to these 4-pin mini DIN connectors.

I

N

P

U

T

3

VID

YC

YC

VID

YC

2

4

c. Input 5 — Connect a component video

(YUVi, YUVp, HDTV) source to these

Y

female BNC connectors.

d. Inputs 6 and 7 — Connect RGB video sources to

these 15-pin HD connectors.

R-Y

B-Y

5

6

RGB

e. Input 8 — Connect a single link of DVI-D video

to this DVI-I connector.

f. Output — Connect an RGB or component video

display to this 15-pin HD output female connector.

Step 3 — Audio inputs and outputs

RGB

OUTPUT

RGB

Y, B-Y, R-Y

DVI

7

8

AUDIO INPUT

1 2 3 4 5

L

R

a. Audio Inputs 1 through 5 RCA connectors —

Connect stereo or mono audio sources.

b. Audio Inputs 6 through 8 3.5 mm mini jacks — Connect computer

audio sources.

c. Output A RCA audio connectors — Connect a stereo or mono audio

device (receiver, amplifier, or the like).

— OR —

Tip

Ring

Tip

Ring

CAUTION

Output B audio captive screw connector — Connect a stereo or mono

audio device (receiver, amplifier, or the like); wire the connector as shown
at right.

OUTPUT

A

R

B

L

L

6

5

R

8

7

AUDIO INPUT

2 3 4

L

OUTPUT

RGB

R

LISTED
1T23

Y, B-Y, C-Y

U S

I.T.E.

C

6

DVI

RGB

7

RGB

3

YC

C-Y

1

VID

5

B-Y

I

Y

N

VID

100-240V 50-60Hz

P

U

2 4

T

OUTPUT

6

7 8

L R

A

L

R

NO GROUND HERE.

Sleeve(s)

NO GROUND HERE.

L R

Tip

Tip

B

Unbalanced Stereo OutputBalanced Stereo Output

For unbalanced audio output, connect
the sleeve(s) to the ground contact.
DO NOT connect the sleeve(s) to the
negative (-) contacts).

68-791-50

Rev. A 04 10

L R

IN1508 — Setup Guide (cont'd)

Step 4 — RS-232

RS-232

a. RS-232 —Connect a control system or

computer to the rear panel RS-232 port.
The IN1508 User's Manual, at www.extron.com
details Simple Instruction Set (SIS™) commands.

Front Panel and Remote Control Controls and Indicators

Many of the switcher’s functions are available via simple controls on the front panel. Front panel LEDs provide indications
of some of the basic system functions. For more complex tasks, such as system configuration, the switcher has a menu system
that is operated by using the front panel buttons. The menu system reports via an on-screen display on the connected output
device.

Input buttons and LEDs —

a

Press to select an input to scale and

IR

INPUT OUTPUT RATE PIP

output. The lit Input LED indicates
the selected input.

Output Rate button and LEDs —

b

Press to cycle through 12 common
resolutions at the 60 Hz refresh rate. The LEDs indicate the selected resolution.

N Some rates cannot be selected using this button. Use the menu system for additional rates.

PIP On (picture-in-picture) button and LED — Press to toggle the PIP feature on and off. The LED lights when PIP

c

mode is on.

PIP Swap button — Press when the PIP feature is on to swap the main and PIP images.

d

Picture Control buttons — Press to change the centering, size, contrast, brightness, color, or tint.

e

Menu control buttons

f

Menu button — Press to activate the on-screen display menu system (shown below) or to back up one level from the



currently selected menu or submenu.

, , , and buttons — Press to move the highlight bar over submenus or selections and to adjust selected settings.



Enter button — Press to select a highlighted submenu or selection.



Menu system operation

At right is a a flowchart of the submenus in the
main menu system. Each submenu leads to a series
of submenus or to a “slider” type status indicator
for individual settings.

No

menu

display

Menu

EXTRON ELECTRONICS IN1508 SCALING PRESENTATION SWITCHER

INPUT

Setup

Use the front panel menu controls and the
connected display's on-screen display to set up the
IN1508 using the following procedures.

N If no image can be seen on the display, use

the front panel Output Rate button to select
1024x768 or 720p.

You can toggle between an RGBHV and high

definition component video output by pressing
and holding the PIP On button while you
cycle the IN1508 power.

Set output signal settings


OUTPUT

AUDIO

ADVANCED

Step 5 — Power

AC power connector — Plug in a standard IEC
power cord from a 100 to 240 VAC, 50-60 Hz
power source into this receptacle. Turn on the
input and output devices after you power up
the switcher.

PICTURE CONTROLS

CONT/

1024x852

1024x1024

1366x768

1365x1024

ON 7 6 5 4 3 2 1 SWAP 8 CENTER SIZE

UXGA

720p

1080i

1080p

VGA

SVGA

XGA

SXGA

COL/

MENU ENTER

BRT

TNT

1 2 43 5 6

Menu Timeout

Enter

Enter

Select

Enter

Enter

Enter

CenterCenter

SizeSize

BrightnessBrightness

ContrastContrast

ColorColor

TintTint

SharpnessSharpness

ResolutionResolution

Refresh RateRefresh Rate

Output VolumeOutput Volume Audio DelayAudio Delay

Input Gain/AttenInput Gain/Atten

FreezeFreeze

BlankBlank PIP ModePIP Mode

ZoomZoom

PanPan

+64

+45

+64

+64

+64

Sync PolaritySync Polarity

Signal TypeSignal Type

SwapSwap

AspectAspect

AdvancedAdvanced

Fade SwitchFade Switch

Blue ModeBlue Mode

SCALING PRESENTATION SWITCHER

100-240V 50-60Hz

50/60Hz

IN1508

Input 5Input 5

Test PatternTest Pattern

ResetReset

1. Navigate to the Output submenu selection boxes.

2. Press and to select among the Resolution, Refresh Rate, Signal Polarity, and Signal Type selection boxes.

3. For each selection box, press and to select the settings that match the display's native settings.

N Some resolutions such as 1920x1200 and 1080p Sharp are only available via SIS command; refer to the IN1508 User’s

Manual, available at www.extron.com, for the associated commands.

2

IN1508 • Setup Guide

Set up the display

N You may need to first set the display's aspect ratio to 1:1, pixel for pixel, or "true" mode to eliminate overscan.

1. Navigate to Advanced > Test Pattern to access the Test Pattern selection box.

2. Press and to select the Alt. Pixels test pattern. Press Enter. Adjust the display's clocking and phase as follows:

3. Navigate again to Advanced > Test Pattern to access the Test Pattern selection box.

4. Press and to select the switcher's Crop test pattern. Adjust the display's horizontal and vertical shift controls until

5. Disable the crop pattern. No further adjustments or Auto-Image should be performed at the display.

Input 5 setup

Input 5 can accept interlaced, progressive, or HDTV component video. You need to configure the switcher to properly
process input 5 as follows:

1. Navigate to Input > Input 5 to select Input 5 selection box.

2. Press and to select the correct setting for the video source connected to input 5. Press Enter.

Test patterns are available on IN1508 units that shipped after March 2007 and are firmware version 2.30 or higher. Earlier
units may show the test pattern submenu, but it is not selectable.

a. Use the display's clocking or coarse sync controls to eliminate vertical banding or "jail bars".
b. Use the display's phase or fine sync controls to eliminate horizontal noise.

all four crop lines are visible.

• Interlaced — NTSC (480i) and PAL (576i)

• Progressive — 480p and 576p

• HDTV — 720p, 1080i, and 1080p

Aspect ratio setup

Each input has a unique aspect ratio setting, either 4:3 (default) or 16:9. The aspect ratio is applied to all video signals that are
applied to that input. If necessary, change the aspect ratio for an input as follows:

1. If necessary, press the Input button to select the input to be set.

2. Navigate to Input > Aspect Ratio to access the Aspect selection box.

3. Press and to select the desired aspect ratio. Press Enter.

4. Repeat steps 1 through 3 as necessary for the remaining inputs.

Input 8 EDID emulation

If the desired output resolution is not available from the DVI video source connected to input 8, you can use the switcher's
SIS commands to set the EDID emulation for input 8. Connect a PC to the switcher's RS-232 port (l) and issue the following
command:

nn*y*41#

where:

nn = Switcher resolution (EDID): y = Video refresh rate:
00 = Match output resolution (default) 0 = Match output rate (default)
01 = 640 x 480 (VGA) 12 = 576p 1 = 50 Hz 3 = 75 Hz (24 Hz for 1080p)
02 = 800 x 600 (SVGA) 13 = 720p 2 = 60 Hz 4 = 59.94 Hz
03 = 1024 x 768 (XGA) 14 = 1080i
04 = 1280 x 1024 (SXGA) 15 = 1080p
05 = 1024 x 852 16 = 1280 x 768
06 = 1024 x 1024 17 = 1440 x 900
07 = 1366 x 768 18 = 1680 x 1050
08 = 1365 x 1024 19 = 1280 x 800
09 = 1400 x 1050 20 = 852 x 480
10 = 1600 x 1200 (UXGA) 21 = 1080p Sharp
11 = 480p 22 = 1920 x 1200

The switcher responds with "DDCnn*y]", where ] is carriage return and line feed characters.
N For more information and a complete list of SIS commands, refer to the IN1508 User's Manual, at www.extron.com.

IN1508 • Setup Guide

3

Extron USA - West

Extron USA - East

Extron Europe

Extron Asia

Extron Japan

Extron China

Extron Middle East

SWAP

3

8

3

8

wap.

INPUT

7

654321

8

Low Resolution

Input Group

High Resolution

Input Group

In this example, input 5 is configured
as progressive component video, so
it is in the high resolution group.

NOTE

IN1508 — Setup Guide (cont'd)

Inputs 6 and 7 setup

RGB inputs 6 and 7 may need minor horizontal and vertical start, active pixels (horizontal), active lines (vertical), total pixels,
and phase adjustments for best image quality.

1. Press the Input button to select the input to be optimized.

2. Execute the Auto-Image™ function by pressing and holding the Input 6 or Input 7 button for approximately 4 seconds.

Release the button. Evaluate the resulting image. If it is satisfactory, this portion of the setup is complete. If the image
is not satisfactory, additional adjustment is necessary; perform steps 3 through 5.

3. Navigate to Input > Advanced to access the Advanced submenu selection boxes.

4. For soft text , vertical banding, or both, adjust the Total Pixels.

For fine horizontal noise, adjust the Phase.
For centering, adjust the Horizontal Start and Vertical Start.
For sizing, adjust the Horizontal Active and Vertical Active.

5. Press and to adjust the highlighted setting.

Operations (PIP mode)

Each of the eight inputs is assigned to one of two operational groups:

• Low resolution — Inputs 1 through 4 (and input 5 if it is configured as
interlaced in the menu system)

• High resolution — Inputs 6 through 8 (and input 5 if it is configured as
progressive or HDTV in the menu system)

Input selection operation

Input selection acts differently, depending on whether PIP mode is on or off:

• PIP mode off — If the PIP mode is off (the PIP On LED is off), the input button selects a new input for the main window.

• PIP mode on — Pushing the input button selects a new input for either the main window or the PIP window, depending
on the group (high resolution or low resolution) the input is in. The selected input replaces the previously selected input
from the same group in whichever window
the replaced input had been displayed.

° In the figure at right, input 3 replaces

input 1 in the PIP window (a).

° In the figure at right, input 8 replaces

input 6 in the main window (b).

Picture-in-picture mode operation

Press

1 2 3

Red

Press

Green

Rolloff

2050100

Uneven Frequency
Response

10k

1000

Frequency (Hz)

Press

10

Rolloff

8

6

4

2

Output

100k

75k

Voltage

Green

Uneven Frequency

Rolloff

Response

10

Rolloff

8

6

4

2

Output

2050100

10k

100k

1000

75k

Voltage

Frequency (Hz)

Images and
Input 3/
Input 8
LEDs s

The two images displayed when the PIP feature is on (the PIP On LED is lit) must come from different input groups (one high
resolution and one low resolution) and you cannot toggle (swap) between two inputs in the same group.

• If the primary input (the main window) is high-resolution, the secondary input (the PIP window) must be low-resolution.

• If the primary input is low-resolution, the secondary input must be high-resolution.

Picture-in-picture swap

The PIP swap function swaps the main and PIP inputs. In the figure above right, when you push the Swap button:

• Input 3 replaces input 8 in the main window (c).

• Input 8 replaces input 3 in the PIP window (c).

If PIP mode is off (the PIP Mode On LED is off), the PIP swap function
toggles between the most recently selected low-resolution and high­resolution inputs. Unlike when PIP mode is on, however, the input
remains full screen.

PIP Mode

Navigate to Advanced > PIP Mode and press and buttons to select among the

1/25 1/9 1/4

Side by Side

Full Screen

image size and position modes shown at right.

N If either side-by-side option is selected, the PIP size adjustment does not work.

Side by Side

Normal Aspect

Red
