General information
3
1 General information
Support for cleaning and maintenance
This document helps support you with the cleaning
and maintenance of the boiler. The required steps are
listed in detail here.
Take note of the date of the cleaning or maintenan ce
and any faults that may have occurred. This facilitates
troubleshooting for the expert (system operator,
heating technician...).
For services (such as commissioning, mainte-
nance, fault fixing provided by ETA customer
service), the service reports are provided in digital
form. For clarity , you should staple these re ports to this
document or enclose them.
Commissioning data
Enter the boiler number (printed on the type plate), the
date of commissioning as well as the heating
technician who commissioned the system.
Commissioning data
Boiler number:
________________________________________
Commissioned on:
_________________________________________
Commissioned by (company):
_________________________________________
Explanation of symbols
Instructions and information
Layout of safety instructions
SIGNAL WORD!
Type and source of danger
Possible effects
• Measures for avoiding the danger
Types of safety instruction
CAUTION!
On non-compliance with this safety instruction, there is
a risk of material damage.
WARNING!
On non-compliance with this safety instruction, there is
a risk of physical injury.
DANGER!
On non-compliance with this safety instruction, there is
a risk of major physical injury.
_________________________________________
_________________________________________
Copyright
All contents of this document are property of ETA
Heiztechnik GmbH and are protected by copyright.
Any reproduction, transfer to third parties or use for
other purposes is prohibited without written permission
from the owner.
Subject to technical alterations
We reserve the right to make technical modifications
without notice. Printing and typesetting errors or
changes of any kind made in the interim are not cause
for claims. Individual configurations depicted or
described here are only optionally available. In the
event of contradictions betw een individua l documents
regarding delivery scope, the information in our current
price list applies.
2 Cleaning and maintenance
Maintenance openings and components
Cleaning and maintenance
1 Draught fan of flue gas recirculation
2 Maintenance cover for flue gas recirculation piping
3 Draught fan
4 Heat exchanger cover
5 Maintenance cover for reversing chamber on heat
exchanger
6 Combustion chamber door
7 Maintenance cover for flue gas recirculation
(behind panel)
8 Ignition fan
9 Actuator for primary air
10 Maintenance cover for secondary combustion
zone
4 www.eta.co.at
Cleaning and maintenance
5
1 Drive of heat exchanger cleaner
2 Temperature sensor of combustion chamber
3 Actuator for flue gas recirculation flap
4 Maintenance cover for flue gas recirculation
(behind panel)
5 Boiler mains switch
6 Maintenance cover for reversing chamber on heat
exchanger
The conveyor depicted here is the standard configuration.
Cleaning and maintenance
1 Drop chute maintenance cover
2 Rotary valve maintenance cover
3 Safety switch for rotary valve maintenance cover
4 Drop chute safety switch
Fig. 2-1: Rotary valve position sensor
6 www.eta.co.at
Cleaning and maintenance General information
7
2.1 General information
Operation only by trained personnel
The product may be operated by trained adults only.
Training may be provided by the heating technician or
our customer service. Please read the associated documentation carefully in order to avoid errors during
operation and maintenance.
Persons who lack experience and knowledge as well
as children may not operate, clean, or maintain the
product.
Performing regular cleaning and maintenance
To ensure satisfactory functioning, cleaning and
maintenance must be performed at regular intervals.
Carry out this work within the intervals stated here.
All tasks where the maintenance table reads
"Customer" or "Customer or expert" in the column
"To be carried out by" can be carried out by any trained
adult. Instructions can be provided by the heating
technician or our customer service.
Steps that are marked with "Expert" only can only be
carried out by the heating technician or our customer
service.
Checking the boiler counters
The counters can be seen in the boiler's text menu.
Counter [Full load hours since maint.] is used for the
service intervals. If it has reached one of the listed
intervals, maintenance is required. This counter is in:
Counters
Full load hours since maint.
Maintenance table Cleaning and maintenance
2.2 Maintenance table
Every
Tasks
Check fill level of ash bins X X X Customer
Check heating system's water pressure X X X Customer
Check air intake in installation room X X Customer
Clean flue tube X X Customer
Clean combustion chamber X X Customer
Check lining of the combustion chamber X X Customer
Check the firebed switch X X Customer
Visual check of the stoker screw X X Customer
Clean ignition fan and openings X X Customer
Check protective elements and grate elements X X Customer
Visual check of the ash cross screw X X Customer
Check grate ash screw X X Customer
Clean roller guide of the moving grate X X Customer
Remove ash from the reversing chamber X X Customer
Check turbulators X X Customer
Clean flue gas recirculation ducts X X Customer/expert
Clean the heat exchanger X X Customer/expert
Clean connection pipe to draught fan X X Customer/expert
Visual check of the heat exchanger screw X X Customer/expert
Clean flue gas temperature sensor X X Customer/expert
Clean flue gas recirculation piping, check flue gas recirculation
flap
Clean draught fan of the flue gas recirculation X X Customer/expert
Lubricate heat exchanger cleaner drive X X Customer/expert
Check stoker drive chain X X Customer/expert
Check the seal of the ash bin or the transfer coupling X X Customer/expert
Check heat exchanger ash screw X X Customer/expert
Clean the lambda probe X X Customer/expert
Visually check safety valves X X Customer/expert
Visually check thermal relief valves X X Customer/expert
Check operational readiness of safety devices in fu el pa th X X Customer/expert
Clean the upper area of the heat exchanger X Expert
Clean draught fan X Expert
Check seal on heat exchanger cover X Expert
Check safety switch of the discharge X Expert
Check rotary valve stop X Expert
Check silicon hoses for differential pressure switch and
transmitter
Check air valve X Expert
Check automatic closing of the actuators X Expert
Regular
ly
3,000 h
or once
a year
X X Customer/expert
Every
6,000 h
or
every
2years
X Expert
to be done by
8 www.eta.co.at
Cleaning and maintenance Maintenance table
9
Every
Tasks
Check seal on combustion chamber door X Expert
Calibrate lambda probe X Expert
Perform heating test X Expert
Reset maintenance counter X Expert
Regular
ly
3,000 h
or once
a year
Every
6,000 h
or
every
2years
to be done by
Regular maintenance Cleaning and maintenance
2.3 Regular maintenance
Check fill level of ash bins
The boiler does not have to be switched off to
empty the ash bins or container.
Before starting the de-ashing emptying, press the
[De-ash] button. This prevents the ash screw
from switching on during the emptying process. If the
ash screw already has a malfunction, first empty the
ash bins or the container and then acknowledge the
fault.
De-ashing with transfer flap
1. Lift the protective mat from the underside. Move
the container to the side and empty.
De-ashing with ash bins
1. Turn the locks on the ash bin lid upwards by 90°.
Fig. 2-4: Open the locks
2. Push the lid up and fix in "Park position".
Fig. 2-2: Protective mat
2. Before placing the protective mat, make sure the
adhesive seal is in a good condition to prevent ash
from escaping.
Fig. 2-3: Seal on the sealing plate
Fig. 2-5: Park position
3. Empty the ash bins. Unhook the lid from "Park
position" and fix to the ash bin with the locks.
DANGER!
Risk of injury from the ash screw
If only one ash bin or none at all is
connected, the ash screw is accessible
from below.
For this reason, operation with only one ash
bin or none at all is prohibited. In addition,
the boiler would take in leak air and hot ash
would fall to the ground, increasing the fire
risk.
The boiler may not be operated for more than
2 minutes without ash bins or an ash container.
10 www.eta.co.at
Cleaning and maintenance Regular maintenance
11
Check heating system's water pressure
The heating system's water pressure is
measured by the control system and displayed
on the screen. A visual check is still necessary though.
In buildings with up to three storeys, the optimum
water pressure in a cold heating system is between 1
and 2 bar. For a warm heating system, the optimum
water pressure is between 1.5 and 2.5 bar.
If the water pressure is too low, fill the cold heating
system to approx. 2 bar. Do not fill to a higher
pressure, as water expands with increasing
temperature and the water pressure als o rises when
the boiler is heating. The safety valve triggers at
approx. 2.8 bar.
If the boiler is operated at maximum 6 ba r water
pressure, the values listed above must be
increased accordingly.
Every 3000 hours / annually Cleaning and maintenance
2.4 Every 3000 hours / annually
Before this maintenance, perform all steps for the
preceding maintenance intervals
Before this maintenance, all steps for the
preceding maintenance intervals must be
performed.
Stop heating
End the boiler's heating mode with the On/Off switch
in the boiler overview window. The boiler
performs an ember burnout and then changes to
[Switched off] mode. Press the [De-ash] button to
make the boiler perform a final de-ashing.
Switch off boiler via mains switch
WARNING!
Switch off the electricity to the boiler via the mains
switch. This prevents injuries caused by switching
the boiler on inadvertently.
Clean combustion chamber
Carefully pull the temperature sensor of the
combustion chamber out by loosening the screw on
the boiler.
Fig. 2-6: Temperature sensor of combustion chamber
Take off the maintenance cover of the secondary
combustion zone by loosening the 4 screws.
WARNING!
Burns caused by hot parts
Even after the boiler has been switched of f,
there will still be a danger of burns caused
by the cleaning and maintenance covers of
the combustion chamber and the heat
exchanger, and by the combustion chamber door.
These parts cool off more slowly, so they may still be
hot.
Allow the boiler cool off long enough, or wear
appropriate protective clothing .
Air intake in installation room must be clear
Air intake for the boiler in installation room must be
clear. It may not be shut or closed.
Cleaning the flue pipe
Sweep the flue pipe from the flue outlet to the chimney,
and remove flue ash from the chimney using a vacuum
cleaner.
Sweep the ash into the chimney, not into the
boiler.
Fig. 2-7: Maintenance cover
12 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
13
Using the poker , remo ve loose and b aked on ash from
the upper part of the combustion chamber. Sweep the
ash backwards into the heat exchanger or forwards
onto the moving grate.
Fig. 2-8: Upper part of the combustion chamber
A thin coating of ash (~ 5 mm) may remain on the
lining. This does not adversely affect operation
and acts as an additional protective layer. Significant
discolouration of the lining is normal.
CAUTION!
Never treat the lining with force, as this may cause
parts of it to be knocked off.
Open the combustion chamber door and remove
baked on ash deposits from around the opening and
from the combustion chamber door
Next, using the poker, remove baked on ash deposits
from inside the combustion chamber and sweep onto
the moving grate.
Fig. 2-10: Lower part of the combustion chamber
A thin coating of ash (~ 5 mm) may remain on the
lining. This does not adversely affect operation
and acts as an additional protective layer. Significant
discolouration of the lining is normal.
Then re-insert the combustion chamber temperature
sensor in the opening and secure with the screw.
Removing ash deposits near the opening of the
secondary combustion zone
Remove ash deposits around the opening of the
secondary combustion zone and also from the
maintenance cover.
Fig. 2-9: Combustion chamber door
Fig. 2-11: Opening of secondary combustion zone
Otherwise, the maintenance cover will not seal
tightly when it is subsequently closed.
Every 3000 hours / annually Cleaning and maintenance
Fit maintenance cover for secondary combustion
zone
Remove the ash from the opening for the
maintenance cover with a vacuum cleaner so the
maintenance cover can form a proper seal.
Attach the maintenance cover for the secondary
combustion zone to the boiler using the 4 screws.
Tighten the screws evenly and cross-wise.
Significant discolouration of the lining is normal.
Fig. 2-14: Discolourations
Check the firebed switch
Manually actuate the firebed switch and check that it
moves easily.
Fig. 2-12: Maintenance cover
Cleaning openings in the lining
Clean the openings on both sides of the lining and
remove any baked on ash deposits. Then vacuum the
openings with an ash or vacuum cleaner
Fig. 2-13: Openings in the lini ng
Check lining of the combustion chamber
After cleaning, check the combustion chamber lining
for cracks or damage.
Fig. 2-15: Firebed switch
In the combustion chamber, check the position of the
firebed switch actuating lever.
Fig. 2-16: Firebed switch actuating lever
14 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
15
Visual check of the stoker screw
Visually check the stoker screw for da mage from the
combustion chamber. It can be a bit burnt on the ends
due to the high levels of heat.
It must be replaced if the stoker screw is partially
burnt on the ends.
Fig. 2-17: Stoker screw
Clean ignition fan and photocell
Remove both ignition fans from the boiler.
Clean the visible photocell with a soft cloth. Then
reattach the ignition tube.
Also clean the openings in the boiler for the ignition
tube.
Fig. 2-18: Removing the ignition fan
Fig. 2-19: Ignition openings
Re-install both ignition fans and attach them to the
boiler with the chain.
Detach the ignition tube by loosening the 4 screws and
remove the ignition rod.
Every 3000 hours / annually Cleaning and maintenance
Check protective elements and grate elements
Check the protective elements for damage or warping
on both sides of the moving grate.
Fig. 2-20: Protective elements
Also check the individual grate elements for damage.
Checking the grate ash screw
Lift up the panel slightly and remove from the boiler.
Fig. 2-23: Cover panel
Take off the maintenance cover by loosening the
screws and nuts.
Fig. 2-21: Grate elements
Visual check of the ash cross screw
From the combustion chamber, visually check the ash
cross screw for damage.
Fig. 2-24: Maintenance cover
Carry out a visual check and remove any possible
foreign bodies (nails, stones...).
Fig. 2-25: Grate ash screw
Inspect the seal of the maintenance cover to ensure it
is in good order, and replace if necessary.
WARNING!
Never operate the boiler with defective seals.
Clean roller guide of the moving grate
Clean the 4 rollers as well as the guides of the moving
grate and check for any possible foreign bodies.
Fig. 2-22: Ash cross screw
16 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
17
For better checking and cleaning, remove the
panel as well as the maintenance cover on the
opposite side.
Check the seals on both maintenance covers to
ensure they are in good condition, replace if
necessary.
Cleaning the turbulators
Check the ends of the turbulators for deposits and
remove them if necessary.
Fig. 2-26: Roller guide of the moving grate
Finally, replace the seals of the maintenance cover,
reinstall it on the boiler and hook in the panel.
Remove ash from the reversing chamber
The maintenance covers for the reversing chamber
are situated on each side of the heat exchanger. Take
off both maintenance covers by unscrewing the four
screws on each one and remove the ash with the
poker.
Fig. 2-29: Turbulators
Clean flue gas recirculation ducts
Remove the panels on both sides of the boiler by
unscrewing the screws on the top and bottom.
Fig. 2-30: Cover panel
Fig. 2-27: Maintenance cover of the reversing chamber
Fig. 2-28: Maintenance cover of the reversing chamber
Every 3000 hours / annually Cleaning and maintenance
Remove the two maintenance covers of the flue gas
recirculation ducts on both sides of the boiler.
Fig. 2-31: Maintenance cover for flue gas recirculation
Using an ash vacuum cleaner, remove ash from the
ducts. Likewise, clean the round openings of the flue
gas recirculation on both sides.
CAUTION!
Never operate the boiler with damaged seals.
Reinstall the maintenance cover for the flue gas recir-
culation and also the panels.
Clean the heat exchanger
First, loosen the two knurled nuts of the heat
exchanger covers by turning them anti-clockwise.
Fig. 2-32: Clean ducts
Fig. 2-34: Knurled nut
Next, turn each of the ball knobs by 180°.
Fig. 2-35: Ball knob
Fig. 2-33: Clean ducts
Check the seals of both maintenance covers to ensure
they are in good condition, replace if necessary.
18 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
19
Lift the two heat exchanger covers and open fully.
Fig. 2-36: Heat exchanger cover
WARNING!
Injuries caused by heavy moving parts
Possible crushing injuries due to the two
heavy heat exchanger covers.
When this is removed, the first tube of the heat
exchanger is visible. Clean it with the poker. Sweep
ash that has collected at the top down into the
reversing chamber.
Fig. 2-38: First tube of the heat exchanger
Work carefully around the open heat exchanger
covers so that they do not accidentally fall shut.
Remove the flue cover by unscrewing the two screws.
Fig. 2-37: Flame pipe cover
Clean connection pipe to draught fan
Check the connection pipe from the heat exchanger to
the draught fan for contamination and remove if
necessary.
Fig. 2-39: Connection pipe to draught fan
Every 3000 hours / annually Cleaning and maintenance
Visual check of the heat exchanger ash screw
Perform a visual check of the cyclone tubes. You
should be able to see the heat exchanger ash screw
below them.
Fig. 2-40: Heat exchanger ash screw
If it is not visible, close the heat exchanger
covers, switch on the boiler via the mains switch
and press [De-ash] to begin de-ashing. Perform th e
visual check once again and again switch off the
electricity to the boiler via the mains switch.
Close heat exchanger cover
Carefully close both heat exchanger covers. Next, turn
the two ball knobs clockwise until the stop.
Then tighten the two knurled nuts evenly and crosswise by turning them clockwise.
Clean flue gas temperature sensor
The temperature sensor is located in the flue
connection. To clean, loosen the screw and pull out the
flue gas temperature sensor.
Fig. 2-41: Flue gas temperature sensor
Clean the sensor with a soft cloth and then re-install it.
When fixing the temperature sensor in place, only
tighten the screw hand-tight so as not to damage the
sensor.
20 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
21
Clean flue gas recirculation piping
Take off the two maintenance covers of the piping and
remove ash from the piping using an ash vacuum
cleaner.
Fig. 2-42: Maintenance cover
Check the flue gas recirculation flap in the piping. It
must always be closed when there is no electricity
supplied to the boiler.
Manually actuate the flap actuator. Unlock th e actuator
on the red button and actua te manually with an Allen
key.
Fig. 2-44: Actuator
Clean draught fan of the flue gas recirculation
Remove the draught fan of the flue gas recirculation by
loosening the wing screws.
Fig. 2-45: Draught fan
With a soft brush (not a wire brush) or with compressed
Fig. 2-43: Flue gas recirculation flap
air, clean the d raught fan's impeller carefully so that the
impeller does not become unbalanced.
Every 3000 hours / annually Cleaning and maintenance
Replace the seal on the draught fan.
Fig. 2-46: Seal
Lubricate the screws with heat-resistant lubricant and
reattach the draught fan to the fan housing. Tighten the
screws evenly.
Lubricate the heat exchanger cleaning drive
Push the drive cover upwards and remove from the
boiler.
Finally, re-attach the cover to the boiler.
Check stoker drive chain
WARNING!
Switch off the electricity to the boiler via the mains
switch. This prevents injuries caused by switching
the boiler on inadvertently.
Lubricate the spring, guide and bearing with heatresistant lubricant.
Remove the drive chain cover by loosening the acorn
nuts.
Check the tension of the stoker drive chain. The chain
may sag by 1 - 2 cm without effort.
22 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
23
If it sags more, the chain must be tensioned with the
two set screws on the side.
Fig. 2-47: Levelling screws
Lubricate the drive chain with chain spray and replace
the cover.
Check the seal of the ash bin or the transfer
coupling
For external de-ashing with ash bins, check the seal on
the ash bin lid to ensure it is in good condition and
replace it if necessary.
On the external de-ashing with transfer coupling,
check the flap for tightness.
Fig. 2-49: Flap in transfer coupling
Check heat exchanger ash screw
Take off the maintenance cover on the discharge
connection of the ash screw.
Fig. 2-50: Maintenance cover
Fig. 2-48: Seals
Every 3000 hours / annually Cleaning and maintenance
Check whether the fork of the heat exchanger ash
screw is evenly flush on the sealing ring. Also check
the movement by pushing the ash screw in the axis
direction.
1Washer
2 Fork of the heat exchanger ash screw
Let the lambda probe cool off and clean it with a
vacuum cleaner. Take special care to clean the
openings in the head of the lambda probe.
Fig. 2-52: Lambda probe
Clean the lambda probe's seal seat in the boiler.
It must be absolutely clean. Check it with a torch
and clean out the coupling with a vacuum clea ner.
The washer for sealing the lambda probe's metal
flange and the seat in the boiler must be replaced
when installing the probe.
Clean the lambda probe
Use a pipe wrench to unscrew the lambda probe's
retaining tube.
Fig. 2-51: Retaining tube
Remove the lambda probe and the enclosed sealing
ring from the boiler.
Fig. 2-53: Washer
Tighten the lambda probe's retaining tube firmly with a
pipe wrench (with 20 kg at 20 cm lever length).
Checking the safety valves
Perform a visual inspection of all safety valves of the
heating system. The outlets of the safety valves may
not drip.
Fig. 2-54: Safety valve
Perform this step only on weekdays, never on
weekends during a cold winter, as there will
probably be no heating technician available if the seal
is defective.
If the safety valve drips, open it with a quarter turn of
the red cap and rinse it out (danger of scalding). If the
safety valve still cannot be sealed effectively after
being rinsed several times, it must be cleaned by a
technician or replaced.
24 www.eta.co.at
Cleaning and maintenance Every 3000 hours / annually
25
Checking the thermal discharge valves
Perform a visual inspection of the two thermal
discharge valves. The outlets of the thermal discharge
valves must not drip.
Check function of safety devices in fuel path
Check the safety devices in the fuel path, such as the
temperature-monitoring system, the manually
operated extinguishing system or the automatic extinguishing system.
Also check malfunction indicators and alarms, for
example if messages from the boiler room are
displayed elsewhere.
Switch the boiler on via the mains switch and start
de-ashing.
Establish the boiler's power supply at the mains switch.
Press the [De-ash] button to de-ash the boiler.
Switch the boiler back on with the On/Off
switch.
Every 6,000 hours / 2 years Cleaning and maintenance
2.5 Every 6,000 hours / 2 years
WARNING!
The following activities may only be performed by
qualified specialist personnel.
If you carry out these activities without the corresponding specialist training, and above all without the
required experience, safe operation is no longer
guaranteed. The resulting defects and consequential
damage are excluded from the guarantee and
warranty.
Equally an incorrect performance of these activities
can lead to serious injuries.
Before this maintenance, perform all steps for the
preceding maintenance intervals
Before this maintenance, all steps for the
preceding maintenance intervals must be
performed.
Stop heating
End the boiler's heating mode with the On/Off switch
in the boiler overview window. The boiler
performs an ember burnout and then changes to
[Switched off] mode. Press the [De-ash] button to
make the boiler perform a final de-ashing.
Clean the upper area of the heat exchanger
Remove and detach the rail by loosening both nuts.
Fig. 2-55: Rail
Loosen the screws on the cyclone tubes and carefully
remove the cyclone tubes from the boiler.
Switch off boiler via mains switch
WARNING!
Switch off the electricity to the boiler via the mains
switch. This prevents injuries caused by switching
the boiler on inadvertently.
WARNING!
Burns caused by hot parts
Even after the boiler has been switched of f,
there will still be a danger of burns caused
by the cleaning and maintenance covers of
the combustion chamber and the heat
exchanger, and by the combustion chamber door.
These parts cool off more slowly, so they may still be
hot.
Allow the boiler cool off long enough, or wear
appropriate protective clothing .
Fig. 2-56: Cyclone tubes
Loosen the screws to detach the cover .
Fig. 2-57: Cover
26 www.eta.co.at
Cleaning and maintenance Every 6,000 hours / 2 years
27
Remove contamination in the upper area of the heat
exchanger.
Fig. 2-58: Cleaning the area
Vacuum out the head of the lambda probe using a
vacuum cleaner. Do not dismantle the lambda probe.
The draught fan weighs about 32 kg. Secure it
against falling down during removal and later re-
installation.
Fig. 2-60: Draught fan
With a soft brush (not a wire brush) or with compressed
air, clean the d raught fan's impeller carefully so that the
impeller does not become unbalanced.
Replace the seal on the draught fan.
Fig. 2-59: Lambda probe
Subsequently re-install the cover, the cyclone tubes
and the rail.
Clean draught fan
Loosen the screws on the draught fan and carefully
pull it out of the fan housing.
Fig. 2-61: Seal
Lubricate the screws with heat-resistant lubricant and
reattach the draught fan to the fan housing. Tighten the
screws evenly.
Every 6,000 hours / 2 years Cleaning and maintenance
Check seal on heat exchanger cover
Check the seals on both heat exchanger covers to
ensure they are in good condition and replace them if
necessary.
Fig. 2-62: Check seal
WARNING!
The boiler must not be operated with defective
seals.
Check safety switch of the discharge
Check the safety switches on the drop chute and the
maintenance opening.
Check rotary valve stop
WARNING!
Danger of crushing from stoker drive chain
The boiler must be switched off. This prevents
injuries caused by switching the boiler on inadvertently.
WARNING!
Accidental remote switch-on
When performing maintenance work on the boiler,
remote access to the ETAtouch control system
must be prevented. Therefore, deactivate the
"meinETA" and further ETAtouch control screens
as well as disconnecting possibly connected
control systems from the ETAtouch controller.
In the factory configuration, the discharge screw
and the rotary valve (or stoker screw) alternate in
operation. This alternating operation of the screws is
controlled by the sensor that monitors the position of
the rotary valve.
If the rotary valve cannot reach the position of the
sensor, a warning is displayed on the screen. The
warning can be acknowledged but does not stop
heating. It is therefore helpful to check the boiler
control system's error log to see whether the error has
occurred in the past.
Fig. 2-64: Rotary valve position sensor
If the discharge screw and the stoker screw are in
operation simultaneously, the setting for the [Rot-
Fig. 2-63: Safety switch
1 Drop chute safety switch
2 Safety switch for rotary valve maintenance cover
ValveStop] function needs to be checked in the boiler's
text menu.
It can be deliberately set to [No] if the used fuel
requires it. The function can be seen with the [Service]
access level under:
Conveying system
Stoker unit
RotValveStop
28 www.eta.co.at
Cleaning and maintenance Every 6,000 hours / 2 years
29
If the discharge screw and the stoker screw are in
operation simultaneously and the function is set to
[Yes], either the sensor is faulty or the gap betwe en the
screw in the gear and the sensor is too lar ge and must
be adjusted. The gap should be about 1 - 2 mm.
Fig. 2-65: Gap between sensor and screw
Check silicon hoses for differential pressure
switch and transmitter
If necessary , blow out the silicon hoses and re-connect
them. Ensure the correct position during connection.
The hoses must not be kinked or crossed over.
Fig. 2-67: Silicon hoses in control cabinet
Fig. 2-66: Differential pressure switch and transmitter in the
control cabinet
Fig. 2-68: Differential pressure transmitter
Check air valve
Manually actuate the primary air valve actuator and
check movement.
Fig. 2-69: Primary air valve
Every 6,000 hours / 2 years Cleaning and maintenance
For manual operation, push the release button (red
button) and manually turn the actuator through 90°
with the set screw.
Fig. 2-70: Manual operation of actuator
1 Set screw
2 Release button
Also manually actuate the secondary air valve actuator
and check movement.
Manually open primary air valve
1. Establish the boiler's power supply at the mains
switch.
2. With the [Service] access level, switch to the
outputs and inputs menu in the boiler's function
block.
3. Select output [Primary air] and tap on the
symbol. A window for manual mode opens. Press
the [On] key so that the primary air valve mo ves to
the open position.
4. Close the window.
Next, manually open the control flap in the flue gas re-
circulation.
Manually open control flap
1. In the boiler function block, switch to the text menu.
2. Open the sub-menu for the control flap:
Outputs
Regulator flap
Demand
Output
3. Set control flap demand [Demand] to [On].
4. Select parameter [Output] and enter the value
10.0 V (=completely open).
If both drives are in the open position, switch off
the boiler power supply on the mains switch. Both
drives must automatically turn back to the closed
position.
Fig. 2-71: Secondary air valve
Check automatic closing of the actuators
The additional circuit board [NS-A] provides an
emergency power supply for the actuator and the
primary air, as well as for the control flap in the flue gas
recirculation. They close the control flap drives or the
primary air valve respectively in the event of a power
failure.
Carry out the following steps to check automatic
closing.
Check seal on combustion chamber door
Open and then close the combustion chamber door.
When closing, make sure that it closes tightly and with
force. The sealing edges of the door frame must leave
a clear indentation in the sealing cord of the
combustion chamber door.
30 www.eta.co.at
Cleaning and maintenance Every 6,000 hours / 2 years
31
Leaks can be detected by variations in the colouration
of the sealing cord. If leaks are found, it usually suffices
to adjust the hinges. If the hinges cannot be adjusted
any further, the sealing cord must be replaced.
Fig. 2-72: Sealing cord of combustion chamber door
To adjust the hinges, you must first remove the panel
next to the combustion chamber door. To do so,
unscrew both screws and remove the panel.
Next, tighten the two rear nuts for fixing the eye bolts.
Fig. 2-75: Re-attach the eye bolts
Adjust the front hinges by slackening the two nuts on
both hinges. Next, push both hinges uniformly approx
0.5 - 1 mm towards the boiler and tighten the nuts
once more.
Fig. 2-73: Remove panel
On the two eye bolts, first slacken the front nut and
adjust it by rotating a 1/4 turn anti-clockwise.
Fig. 2-74: Rotating nuts a 1/4 turn
Fig. 2-76: Adjusting the front hinges
Finally, re-attach the panel next to the combustion
chamber door.
Calibrating the lambda probe
The boiler's built-in lambda probe checks the
residual oxygen content of the flue gas and uses
it to control the combustion. To ensure reliability, the
control system autonomously pe rforms an automatic
calibration after every 500 hours of operation.
If you wish to perform an additional lambda probe calibration, the control system features the [Addl. calibration] function. This function can be selected with the
[Service] access level and can be found under:
Inputs
Residual O2
Addl. calibration
Every 6,000 hours / 2 years Cleaning and maintenance
Switch on this function and the additional calibration
will now start. If the boiler is heating, it is automatically
stopped first. De-ashing begins, then the boiler is
purged with fresh air. After this, the residual oxygen
content is measured and the lambda probe is automatically calibrated. Altogether , these ste ps can last a few
hours. When the calibration is complete, the boiler
goes back into operation and starts heating, if
necessary.
After another 100 hours of operation, the control
system automatically performs another calibra-
tion.
Perform heating test
To perform the heating test, put the boiler into
emissions measurement mode. To do this, carry out
the following steps. In the boiler overview window,
press the [Measurement] button in order to enter
the emissions measurement settings window.
Reset maintenance counter
When maintenance is complete, reset the counter.
With the [Service] access level, it will be visible in the
boiler text menu under:
Counters
Full load hours since maint.
Reset counter?
Fig. 2-77: Settings window for emissions measurement
Press the [Start now] bu tton so the boiler will start
immediately. The control system ensures that
sufficient heat is channelled to the buffer, the heating
circuits and the hot water tank.
After about 20 to 30 minutes in heating mode, the
residual oxygen content should reach 6% to 9%. The
current residual oxygen content is displayed in the
boiler overview.
If the value does not drop below 12% residual
oxygen, the boiler is receiving leak air. The
reason (leaky combustion chamber door, heat
exchanger cover, etc.) must be identified and
corrected.
If possible, perform a flue gas measurement
during the heating test.
After the heating test, switch the boiler back to normal
mode. To do this, press the [Deactivate measurement]
button in the settings window.
32 www.eta.co.at
Cleaning and maintenance Every 6,000 hours / 2 years
33
Cleaning (customer) Records
3 Records
3.1 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
34 www.eta.co.at
Records Cleaning (customer)
35
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.2 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
36 www.eta.co.at
Records Maintenance (expert)
37
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.3 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
38 www.eta.co.at
Records Cleaning (customer)
39
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.4 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
40 www.eta.co.at
Records Maintenance (expert)
41
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.5 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
42 www.eta.co.at
Records Cleaning (customer)
43
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.6 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
44 www.eta.co.at
Records Maintenance (expert)
45
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.7 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
46 www.eta.co.at
Records Cleaning (customer)
47
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.8 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
48 www.eta.co.at
Records Maintenance (expert)
49
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.9 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
50 www.eta.co.at
Records Cleaning (customer)
51
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.10 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
52 www.eta.co.at
Records Maintenance (expert)
53
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.1 1 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
54 www.eta.co.at
Records Cleaning (customer)
55
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.12 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
56 www.eta.co.at
Records Maintenance (expert)
57
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.13 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
58 www.eta.co.at
Records Cleaning (customer)
59
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.14 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
60 www.eta.co.at
Records Maintenance (expert)
61
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.15 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
62 www.eta.co.at
Records Cleaning (customer)
63
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.16 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
64 www.eta.co.at
Records Maintenance (expert)
65
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.17 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
66 www.eta.co.at
Records Cleaning (customer)
67
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.18 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
68 www.eta.co.at
Records Maintenance (expert)
69
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
Cleaning (customer) Records
3.19 Cleaning (customer)
This cleaning is to be carried out onc e a year or
after 3000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
70 www.eta.co.at
Records Cleaning (customer)
71
Comments:
performed on: _________________________
performed by: _________________________
Maintenance (expert) Records
3.20 Maintenance (expert)
This cleaning is to be carried out every 2 years or
after 6000 hours.
Tasks Notes
Check fill level of ash bins
Check heating system's water pressure _________ bar
Check air intake in installation room
Clean flue tube
Clean combustion chamber
Check lining of the combustion chamber
Check the firebed switch
Visual check of the stoker screw
Clean ignition fan and openings
Check protective elements and grate elements
Visual check of the ash cross screw
Check grate ash screw
Clean roller guide of the moving grate
Remove ash from the reversing chamber
Check turbulators
Clean flue gas recirculation ducts
Clean the heat exchanger
Clean connection pipe to draught fan
Visual check of the heat exchanger screw
Clean flue gas temperature sensor
Clean flue gas recirculation piping, check flue gas recirculation flap
Clean draught fan of the flue gas recirculation
Lubricate heat exchanger cleaner drive
Check stoker drive chain
Check the seal of the ash bin or the transfer coupling
Check heat exchanger ash screw
Clean the lambda probe
Visually check safety valves
Visually check thermal relief valves
Check operational readiness of safety devices in fu el pa th
Clean the upper area of the heat exchanger
Clean draught fan
72 www.eta.co.at
Records Maintenance (expert)
73
Tasks Notes
Check seal on heat exchanger cover
Check safety switch of the discharge
Check rotary valve stop
Check silicon hoses for differential pressure switch and transmitter
Check air valve
Check automatic closing of the actuators
Check seal on combustion chamber door
Calibrate lambda probe
Perform heating test
Reset maintenance counter
performed on: _________________________
performed by: _________________________
Comments:
www.eta.co.at
www.eta.co.at
Loading...
