Esotec Design Operating Manual

olar House Number Lighting „Design“

S

GB

Customer support:

If you have problems or questions regarding this product, simply contact us!

Monday to Friday 8 am to 12 noon and 1 pm to 4 pm.

y phone: [phone]

B

y e-mail for ordering spare parts: [e-mail]

B

y e-mail for questions about the product: [e-mail]

B

Product: Manufacturer Item No.: 102037

hese instructions relate ONLY to this product and contain important information for

T
using the product for the first time. Please keep these instructions for later reference
and should always accompany the product in the event of transference to a new user.

1. Introduction

ear Costumer,

D
Thank you for purchasing the solar light. With this solar light you purchased a product
manufactured according to the current state of technology.

his product fulfils all requirements of the valid European and national regula-

T

ions. The conformity was proved. The relevant declarations and documentati-

t
on are deposited with the manufacturer.

To maintain this state and guarantee a safe operation, you as the user will have to fol-

ow this operating manual!

l

5. Exchange of the battery pack

The capacity of the batteries will diminish after one to two years and they will have to
be exchanged. The battery pack is available at your local retailer or from the manu-

acturer. The battery type used is the following:

f

piece battery pack NiMh 3.6 V/ 1300 mAh.

1

Supplier: www.esotec.de - Art.-No: 901021

. Unscrew the screw on the bottom of the house

1

umber light and take off the upper part to the

n

ront.

f

. Disconnect the battery pack and remove it from

2

he battery compartment. The battery compart-

t

ent is opened by pressing the two lugs

m
inwards (pictures 2 and 3).

. Exchange the battery pack by an identical type

3

f battery and re-assemble the house number

o
in reverse order.

ote: Used batteries or accumulators must be dis-

N

posed of in an environmentally sound manner.
They do not belong into the domestic waste. Your

ealer is legally obliged to take back.

d

p

p

ic. 2

ic. 3

2. Safety Instructions

In case of damages caused by not

­ollowing this operating manual, the

f

arranty rights will expire! We exclude

w
liability for any consequential damages!
We exclude liability for property or

!

- In these cases any guarantee rights will expire.

Due to safety and admission reasons (CE) it is not allowed to arbitrarily reconstruct
and/or change the solar light.

herefore, please keep to the operating manual.

T
The accident prevention rules of the association of the industrial trade cooperative

ssociation for electric plants and working material are to be considered in industrial

a

nvironments.

e

-

ersonal damages caused by inappropriate

p
handling or not following the safety instructions.

3. Intended Use

The light is automatically switched on at darkness and switched off at morning light.
Depending on the charging condition of the rechargeable batteries, the luminosity
may decrease after a certain operating time. This enables a longer operating time in
case of bad insolation.
The maximum duration of illumination with full (rechargeable) battery and without
recharge is approx. 100 hours. The ASI solar module which is made in Germany
installed in the upper part of the housing charges the battery pack at sunlight. The
installed light-emitting diode (LED) is activated at dawn and will be illuminated accor­ding to the charging condition of the battery.
Up to 3-figure numbers or letters may be stuck on the luminous surface on the front
side.

Note: Please make sure that the solar light is installed on a shadow-free south-, east­or west side. The product cannot be used if installed on north sides, under bushes or
similar. In winter, the solar cell shall always be free of snow.

4. Initiation

1. Please carefully take all parts out of the package.

2. Stick your house number on the luminous surface by means of the attached figu­re sheets.

3. Unscrew the screw on the bottom of the house number light and take off the upper
part to the front.

4. Screw the back wall of the house number to the wall using the enclosed fixing
material. In doing so, make sure that you mount the house number light on a sha­dow-free wall facing the south, east or west. Walls facing the north are not suitab­le for solar products!

5. Now insert the socket of the battery pack - with correct polarity - on the plugs on
the circuit board (see picture 1).
Note: The plug is protected against inverse polarity. Please, do not apply force.

6. Now, re-mount the front part on the back all and re-tighten the screw on the bot­tom side of the house number.

The house number is now activated!

Note: During the winter months the duration of

illumination will generally be shorter. If the lamp
should not yet start working on the first evening,
please wait for a sunny day.

pic. 1

6. Malfunctions

Light is not activated when it gets dark

- an ambient light source (e.g. street lamp) simulates daylight on the solar module and
revents the activation of the light. Move the light to a darker place.

p

Light is not activated at darkness or deactivated after a short time.

- Check whether you inserted the batteries with incorrect polarity.

-Battery weak or defective?

Note: The batteries should be exchanged in a two year interval.

7. Technical Data

perating voltage: 3.6 V

O
Protection class: IP 44
Rechargeable batteries: battery pack: NiMh 3.6 V/ 1300 mAh

amp/illuminant: 1 white light-emitting diode (LED)

L
Duration/battery life: max. 100 hours with fully charged set of

rechargeable batteries

Battery take-back

- Batteries must not be discarded into domestic waste.

- The consumer is legally required to return batteries after
use, e.g. to public collecting centers or to battery distribu­tors.

- Contaminant-containing batteries are labeled with the sign
“crossed-out trashcan“ and one of the chemical symbols.
Used batteries should be disposed environmentally friend­ly and should not be discarded into domestic waste. Your
dealer is legally required to take back old batteries.

Rechargeable battery notes

- Rechargeable batteries should not be played with by children. Never leave rechar­geable batteries lying around; they could be swallowed by children or pets.

- Rechargeable batteries must never be short-circuited, disassembled or thrown into
fire. This leads to a danger of explosion!

- Leaking or damaged rechargeable batteries can cause chemical burns when they
come into contact with skin. For this reason, please make use of suitable protecti­ve gloves.

- Rechargeable batteries should only be replaced by structurally identical recharge­able batteries from the same manufacturer. Normal batteries must not be used
since these are not rechargeable.

- Make sure the rechargeable batteries are inserted with the correct polarity.

- For long periods of time of non-use (for example, storage), remove the inserted
rechargeable batteries to avoid damages via the leaking rechargeable batteries.

Manufacturer / Importer

esotec GmbH - Gewerbegebiet Weberschlag 9 - D-92729 Weiherhammer

Tel.-Nr: [phone] - Fax.-Nr: [phone] - Internet: www.esotec.de

Disposal:

Dear customer,
please cooperate in avoiding waste. When you intend to dispose of the product in
future, please consider that it contains valuable raw materials suited for recycling.
Therefore, do not dispose it of with domestic waste but bring it to a collection point for
the recycling of waste electrical and electronic equipment.
Thank you very much for your cooperation!

NiMh

Copyright, esotec GmbH
