Esatto ECG6F User Manual
Model Code/s:
Product:
Document:
ECG6F
Gas
Cooktop
60cm
User Manual
Page:
User Manual:
02
Dear Customer, Congratulations on purchasing your new gas
cooktop. The Esatto brand is proudly distributed
within Australia by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this
manual for information regarding your product’s
parts and labour warranty, or visit us online at
www.residentiagroup.com.au.
At Residentia Group, we are customer obsessed
and our Support Team are there to ensure you get
the most out of your appliance. Should you want
to learn more about recommended cooking
temperatures, the various features of your cooktop,
and importantly taking care of your appliance when
cleaning, our Support Team are here to help. You can
use our online Support Centre at anytime by visiting
http://support.residentiagroup.com.au, or you can
contact us via phone by dialling 1300 11 HELP (4357).
It is important that you read through the following
use and care manual thoroughly to familiarise yourself
with the installation and operation requirements of
your appliance to ensure optimum performance.
Again, thank you for choosing an Esatto appliance
and we look forward to being of service to you.
Kind Regards,
The Residentia Team
T 1300 11 4357
E info@residentiagroup.com.au
W residentiagroup.com.au
ACN
600 546 656
Residentia Group
PO Box 341
Mt Eliza, Victoria
Australia 3930
User Manual:
Contents: Page:
Safety Instructions 04
Your Esatto Cooktop 06
Installation Instructions 08
Cleaning & Maintenance 14
Technical Data 14
Purchase Details 15
Warranty Information 16
Notes 18
Page:
03
User Manual:
Safety Instructions
Page:
04
Your safety is of the utmost importance to. Please
make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained
in this booklet, please contact the Retailer where you
purchased your unit from.
The appliance should only be installed and connected
by a suitably qualified and authorised person, strictly
in accordance with the manufacturer's instructions.
Please see the specific section of this user manual that
refers to installation.
IMPORTANT!
The gas supply to the cooktop must be cut off before
any adjustments or maintenance work is undertaken.
WARNING
When using this product, basic precautions should always
be taken including the following:
► The appliance is designed for domestic household use
and for the cooking and frying of domestic foodstuffs.
► Care should be taken to ensure that the units and work
surfaces that you build the appliance into, meet with
the relevant standards.
► Not for use in Marine craft, caravans or mobile homes.
IMPORTANT!
The adjacent furniture and all materials used in the
installation must be able to withstand a minimum
temperature of 65°C above the ambient temperature
of the room it is located in, whilst in use.
► Certain types of vinyl or laminate kitchen cabinetry
are particularly prone to heat damage or discolouration
at temperatures above the guidelines given.
► Any damage caused by the cooktop being installed
in contravention of this temperature limit, will be the
liability of the owner.
► Your new cooktop is guaranteed against electrical or
mechanical defects, subject to certain exclusions that
are noted in the Warranty Terms and Conditions (at the
rear of this user manual). The foregoing does not affect
your statutory rights.
► The use of this cooktop for any other purpose or in
any other environment, without the express agreement
of Residentia Group, will invalidate any warranty or
liability claim.
► You should not use this appliance to store items on
or as a work surface.
► No modifications to the appliance are permitted by
Residentia Group.
► You should not store or place flammable or highly
flammable liquids/materials on top of or near the
appliance. Items made from aluminium, plastic
or plastic film should also be kept away from the
appliance, as they may fuse to the surface.
► Repairs may only be carried out by authorised
service agents.
► Your Esatto cooktop is not to be used by children or
persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
► Any film or stickers that are present on the cooktop
when it is delivered should be removed before use.
► Care should be used when utilising the cooktop,
otherwise there is a risk of burns being caused.
► You should not allow the electrical connection cables
to come into contact with the cooktop surface when
it is hot or any hot cookware.
► If fat and oil overheats, then it can ignite extremely
quickly. For this reason, when cooking with fat and
oil the appliance should not be left unattended.
► Make sure that all of the cooking zones are switched
off after use.
► Cleaning of the cooktop should be carried out on a
regular basis, once the cooktop has cooled down.
► Great care should be taken whilst using this appliance
and when following the cleaning procedure.
► You should not use a steam jet or any other high
pressure cleaning equipment to clean the appliance.
User Manual:
Page:
05
DECLARATION OF CONFORMITY
This appliance complies with the following
European Directives:
— 2006/95/CE General regulations / Low tension
— 2009/142/CE Concerning gas appliances
— 1935/2004/CE 90/128/EEC This appliance is suitable
to come in contact with food
— 2004/108/CE Electromagnetic compatibility
— AS4551- Domestic gas cooking appliances
— Low voltage – 73/23
— Safety standards – EN 60335-1, EN30-1-1,
AS/NZS 3350-1,3350-2-6
The manufacturer declares that the cooktop is built using
certified materials and requires the appliance to be installed
in accordance with the standards currently in force. This
cooktop should only be used by a trained person and for
domestic purposes only.
UNPACKING
During transportation, protective packaging was used to
protect the appliance against any damage. After unpacking,
please dispose of all elements of packaging in a way that
will not cause damage to the environment. All materials
used for packaging the appliance are environmentally
friendly; they are 100% recyclable and are marked with
the appropriate symbol.
► During unpacking, the packaging materials (polythene
bags, polystyrene pieces, etc.) should be kept out of
reach of children.
DISPOSAL OF THE APPLIANCE
Old appliances should not simply be disposed of with
normal household waste, but should be delivered to a
collection and recycling centre for electric and electronic
equipment. A symbol shown on the product, the instruction
manual or the packaging shows that it is suitable for
recycling.
Materials used inside the appliance are recyclable and
are labelled with information concerning this. By recycling
materials or other parts from used devices you are
making a significant contribution to the protection
of our environment.
Information on appropriate disposal centres for used
devices can be provided by your local authority.
User Manual:
Your Esatto Cooktop
SPECIFICATIONS
W
Page:
06
D
Connection points diagram above:
1. Front of cooktop
2. Gas connection point
3. Electrical connection point.
MODEL PRODUCT DIMENSIONS
ECG6F
MODEL BURNERS NG OTHER
ECG6F
W×D×H
600mm,
510mm,
40mm
1 x 10.8 MJ/h rapid burner
2 x 6.5 MJ/h semi-rapid burners
1 x 3.6 MJ/h auxiliary burner
CUTOUT DIMENSIONS
W×D
560mm x
480mm
CONNECTION POINT LOCATIONS
DIAGRAM ABOVE
Gas: XXmm (from left), XXmm (from rear)
Electrical: XXmm (from right), XXmm (from rear)
Front control operation, Automatic ignition, Enamel trivets
COOKTOP COMPONENTS
Your Esatto cooktop is supplied with:
► LPG conversion jets (optional use)
► Regulator
► Sealing strip
