Ericsson C3607w User Manual

4/1424-LZT 108 9714/01 Uen Rev B

Technical Description and User Guide

C3607w

PRINTING ORIGINAL

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

2 (28)

© Ericsson AB, 2009. All Rights Reserved.

Disclaimer

All rights reserved. The information in this document is the property of Ericsson.
Unless specifically authorized in writing by Ericsson, the receiver of this document
shall keep the information contained herein confidential and shall protect the same
in whole or in part from disclosure and dissemination to third parties. Disclosure and
disseminations to the receiver's employees shall only be made on a strict need to
know basis. The information in this document is subject to change without notice
and Ericsson assumes no responsibility for factual inaccuracies or typographical
errors.

Abstract

This document describes the Ericsson Mobile Broadband Module C3607w. End­user value, functionality, characteristics and basic building blocks are described.

Trademark and Acknowledgements
Ericsson is a trademark of Telefonaktiebolaget LM Ericsson.
All trademarks are the property of their respective owners. All other product or

service names mentioned in this document are trademarks of their respective
companies.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

3 (28)

Contents

1 About this Document ............................................................................5

1.1 Purpose...................................................................................................5

1.2 Audience.................................................................................................. 5

2 Product Overview..................................................................................6

2.1 Key features and benefits........................................................................6

3 C3607w Communication.......................................................................7

3.1 Network Technologies............................................................................. 7

3.1.1 UMTS ...................................................................................................... 7

3.1.2 GSM ........................................................................................................ 7

3.2 Applications.............................................................................................8

3.2.1 SMS.........................................................................................................8

3.2.2 GPS......................................................................................................... 8

3.2.3 Browsing and internet access.................................................................. 8

4 Technical Specifications....................................................................... 9

4.1 General....................................................................................................9

4.2 Exterior Description .................................................................................9

4.3 Environment .......................................................................................... 10

4.4 Electrical Characteristics .......................................................................10

4.5 Operating System Support ....................................................................10

4.6 UMTS Technical Data ........................................................................... 11

4.7 HSPA Technical Data............................................................................11

4.8 GSM Performance and Technical Characteristics................................. 12

4.9 Supported GSM Features...................................................................... 12

4.10 GPRS Maximum Data Rates................................................................. 13

4.11 EDGE Technical Data ........................................................................... 13

4.12 EDGE Maximum Data Rates................................................................. 14

4.13 SMS Technical Data..............................................................................14

5 C3607w Hardware Overview............................................................... 15

5.1 General..................................................................................................15

5.2 Dimensions............................................................................................16

5.3 Functional Block Diagram...................................................................... 16

6 Host Software Overview ..................................................................... 17

6.1 Drivers ...................................................................................................17

6.2 Connection Manager .............................................................................17

7 Related Information and references ..................................................18

7.1 Documents Available.............................................................................18

8 Operational and Regulatory information........................................... 19

8.1 Operational Information......................................................................... 19

8.1.1 Wireless Interoperability........................................................................19

8.1.2 Safety .................................................................................................... 19

8.1.3 Recommendations................................................................................. 20

8.1.4 Children.................................................................................................20

8.1.5 Disposal of old electrical & electronic equipment ..................................20

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

4 (28)

8.1.6 Emergency calls....................................................................................21

8.2 Regulatory Information ..........................................................................21

8.2.1 United States, FCC Notices................................................................... 21

8.2.2 European Union, EU Declaration of Conformity....................................22

9 Environmental Declaration.................................................................23

10 C3607w Material Declaration..............................................................24

10.1 Banned Substances .............................................................................. 24

10.2 Restricted Substances........................................................................... 24

10.3 Disposal.................................................................................................25

11 Terminology and Abbreviations......................................................... 26

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

5 (28)

1 About this Document

1.1 Purpose

This user guide gives the reader a deeper technical understanding of the features,
applications and configuration of C3607w. A simplified technical explanation of
GSM/GPRS/EDGE and WCDMA/HSPA data services is also included in this
document.

1.2 Audience

People who can benefit from this document include:

• End-users

• Notebook vendors

• IT professionals

• Software developers

• Support engineers

• Business decision-makers

• Mobile operators

More information can be found on the World Wide Web at

http://www.ericsson.com/mobilebroadbandmodules

.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

6 (28)

2 Product Overview

Ericsson’s C3607w is a high performance Mobile Broadband Module capable of
providing wide area wireless data access at speeds up to 7.2 Mbps downlink and up
to 2.0 Mbps uplink in a 192-lead LGA package. It offers both triple band
WCDMA/HSPA and quad-band EDGE/GPRS/GSM mobile access to the internet or
corporate networks worldwide with flexibility including “always online” capability.

C3607w uses USB as the main system interface for data and control
communication. In addition, it is capable of providing a 26MHz system clock signal
to be used by an external GPS receiver residing on the host platform.

The module is hardware prepared for voice functionality. Later on when voice is
supported SPI will be used as main system interface. The voice data communication
will be done through the PCM interface.

The hardware is also prepared to support HSUPA category 6, which can deliver
uplink data rates up to 5.76 Mbps.

2.1 Key features and benefits

• The C3607w Mobile Broadband Module is a self-contained 192-pin LGA
component with radio, associated baseband plus memory and power
management biased from only one voltage.

• The module is a dual mode device which offers quad-band
EDGE/GPRS/GSM and triple-band WCDMA/HSPA with handover between
the different technologies.

• The module has receiver diversity, GRAKE2 (equalization and RX diversity
simultaneously) which enhances the radio link performance.

• The module supports clock synchronization for an external GPS chip set.

• The device has outstanding low current consumption in various host states

and at different network connection usage.

• The C3607w is a true always connected device which supports wake on
wireless.

• To ensure regulated radio performance and component life length the
module has an in-built over temperature protection.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

7 (28)

3 C3607w Communication

The C3607w Mobile Broadband Module keeps end-users up to date by giving them
the best available mobile service wherever they are.

C3607w is a dual mode device, able to connect via WCDMA/HSPA and
GSM/GPRS/EDGE. The handover between the two systems and network
technologies are automatically managed by the C3607w allowing the user to remain
connected seamlessly.

The C3607w comes with tri-band WCDMA/HSPA (Band I, II, and V) and quad-band
(850/900/1800/1900 MHz) GSM/GPRS/EDGE support.

3.1 Network Technologies

3.1.1 UMTS

3G (third-generation) services combine high-speed radio access with IP-based
(Internet Protocol) services. This not only offers the possibility for fast mobile
connection to the World Wide Web, but also a totally new way to communicate,
access information, conduct business, learn and be entertained.

Compared to 2G mobile networks, 3G significantly boosts network capacity, a much
needed feature in densely populated areas and allows operators to support more
users and offer them more sophisticated services.

3.1.1.1 WCDMA

The initial implementation of UMTS networks enables Internet or corporate network
access at bidirectional data rates of up to 384 kbps.

3.1.1.2 HSPA

HSPA (High Speed Packet Access) is available in all most UMTS markets. With its
HSDPA solution, C3607w is capable of downlink-speeds of up to 7.2 Mbps. In
addition, with its antenna diversity, the C3607w has a fast and reliable downlink.
C3607w uses HSUPA which enables uplink speeds of up to 2 Mbps. With HSPA,
users can enjoy faster download and upload capability while network operators
benefit from increased capacity.

3.1.2 GSM

GSM/GPRS coverage is available almost everywhere, and provides a secure fall
back so that network connection is maintained.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

8 (28)

3.1.2.1 GPRS

GPRS is an enhancement to GSM networks and provides packet data transmission.
The connection setup is fast and, once connected, applications may send and
receive data whenever required.

C3607w can achieve communication speeds through GPRS up to a theoretical
maximum of 85.6 kbps downlink and 42.8kbps uplink.

3.1.2.2 EDGE

EDGE (Enhanced Data rates for Global Evolution) is an integral part of the GSM
family of open mobile standards. EDGE improves GPRS by increasing data
throughput by a factor of three. GPRS networks enhanced with EDGE are often
referred to as E-GPRS (Enhanced GPRS) networks.

C3607w can achieve communication speeds up to a theoretical maximum of 247.4
kbps downlink and 123.7 kbps uplink; MCS-9). Typical end-user speeds are in the
range of 120 kbps under average conditions, with burst speeds around 200 kbps in
strong signal conditions.

3.2 Applications

3.2.1 SMS

C3607w can send and receive text messages.

3.2.2 GPS

The C3607w does not have an onboard GPS receiver, but is prepared to support an
external GPS receiver chipset mounted on the host system. The C3607w generates
signals for GPS system clock and RF PA blanking.

3.2.3 Browsing and internet access

C3607w is aimed for hosts running GNU/Linux. The first distribution supported is
Moblin. The drivers stack will be included in the GNU/Linux kernel for easy
integration.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

9 (28)

4 Technical Specifications

4.1 General

Technical Data

Product name C3607w
Card type 192-lead LGA package
System GSM 850

E-GSM 900
GSM 1800
GSM 1900
UMTS 850 (band V and VI)
UMTS 1900
UMTS 2100

Services Available GSM: Packet-Switched data GPRS/EDGE, SMS

UMTS: Packet-Switched data, HSPA, SMS
Multiple Primary PDP Context
Voice services are not supported

SIM Card USIM, GPRS-aware and Regular (non-GPRS-aware)

supported
3 V and 1.8 V type

Certification and
Type Approval

CE, R&TTE, FCC, IC, GCF and PTCRB

Product Number KRD 131 17/01
FCC ID VV7-MBMC3607W
IC ID 287AG-MBMC3607W

4.2 Exterior Description

Attribute Data

Form factor 28.5x33.5x2.3 mm
Weight <7 g

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

10 (28)

4.3 Environment

Attribute Data

Ambient Temperature: Storage -40°C to 85°C
Directives WEEE (Waste Electrical and Electronic

Equipment Directive)
RoHS (Restriction of use of certain

Hazardous Substances)

4.4 Electrical Characteristics

Attribute Data

Supported Voltage Range 3.2 V – 4.2 V
Nominal Operating Voltage 3.6 V
Average Standby Power (Radio off) < 20 mW
Average Idle Power (Attached to network) < 20 mW
Data Transfer Peak Average Power < 2.8 W

4.5 Operating System Support

Attribute Data

Supported Operating Systems Moblin based on GNU/Linux

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

11 (28)

4.6 UMTS Technical Data

Attribute Data

Power Class Class 3
Frequency bands Band V

(850)

Band II (1900) Band I (2100)

Frequency Range
(MHz)

TX: 824­849

RX:
869-894

TX: 1850­1910

RX: 1930­1990

TX: 1920-1980
RX: 2110-2170

Duplex spacing 45 MHz 80 MHz 190 MHz
Advanced

Receiver

Type I, Type II, Type III

Maximum
Downlink speed

384 kbps (Packet-Switched)

Maximum Uplink
speed

384 kbps (Packet-Switched)

Features Inter-RAT Handover (UMTS/EDGE/GPRS)

Inter-RAT Reselection (UMTS/EDGE/GPRS)
Quality Of Service UMTS classes supported via AT Command
Modes PDP type IP
IP Allocation Dynamic

4.7 HSPA Technical Data

Attribute Data

Maximum Downlink Speed 7.2 Mbps
Maximum Uplink Speed 2.0 Mbps
HSDPA Categories Categories up to 7.2 Mbps (Category 1-8)
HSUPA Categories Categories up to 2.0 Mbps (Category 1, 3, 5)

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

12 (28)

4.8 GSM Performance and Technical Characteristics

Parameter GSM 850 E-GSM 900 GSM 1800 GSM 1900

Frequency
range (MHz

TX: 824 –
849

RX: 869 –
894

TX: 880 – 914
RX: 925 –

959

TX: 1710 –
1785

RX: 1805 –
1880

TX: 1850 – 1910
RX: 1930 – 1990

Duplex spacing 45 MHz 45 MHz 95 MHz 80 MHz
Channel

Spacing

200kHz

Number of
channels

123 Carriers
x 8 (TDMA)

175 Carriers x
8 (TDMA)

374 Carriers
x 8 (TDMA)

299 Carriers x 8
(TDMA)

Modulation GMSK

8-PSK

Power Class
GSM/GPRS;
EGPRS
MCS1-4

(GMSK)

Class 4

Class 1

Power Class
EGPRS
MCS5-9
(8-PSK)

Class E2

Class E2

4.9 Supported GSM Features

Attribute Data

SIM Personalization Locks Network
SIM Application Toolkit

USIM Application Toolkit

Supported by AT commands (Release 99)
Supported by AT commands (Release 6)

Speech Coding Not applicable (C3607w does not support speech

services)
SMS over GPRS Mobile Originated and Mobile Terminated
Data Rates Multislot class 10 supported (see table below)

GPRS Coding Schemes: CS-1, CS-2, CS-3, CS-4

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

13 (28)

Attribute Data

Mode of Operation Class B (attaches to both GSM and GPRS at the

same time

4.10 GPRS Maximum Data Rates

4 + 1 3 + 2

Coding
Scheme

Data Rate
per slot

Rx Tx Rx Tx

CS-1 9.05 36.2 9.05 27.15 18.1
CS-2 13.4 53.6 13.4 40.2 26.8
CS-3 15.6 62.4 15.6 46.8 31.2
CS-4 21.4 85.6 21.4 64.2 42.8

Speed achieved depends on the Coding Scheme supported by the GSM Network.
Data rate is the payload per slot, headers plus data.

4.11 EDGE Technical Data

Attribute Data

Device Class EDGE Class Multislot 10
Modulation Coding Schemes MCS-1 to MCS-9
EDGE features Link Adaptation

Incremental Redundancy
Extended Uplink TBF
Network Assisted Cell Change (NACC)

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

14 (28)

4.12 EDGE Maximum Data Rates

4 + 1 3 + 2

Coding

Scheme

Type of

coding

Data Rate

per slot

Rx Tx Rx Tx

MCS-1 GMSK 10.60 42.40 10.60 31.80 21.20
MCS-2 GMSK 13.00 52.00 13.00 39.00 26.00
MCS-3 GMSK 16.60 66.40 16.60 49.80 33.20
MCS-4 GMSK 19.40 77.60 19.40 58.20 38.80
MCS-5 8-PSK 24.05 96.20 24.05 72.15 48.10
MCS-6 8-PSK 31.25 125.00 31.25 93.75 62.50
MCS-7 8-PSK 47.45 189.80 47.45 142.35 94.90
MCS-8 8-PSK 57.05 228.20 57.05 171.15 114.10
MCS-9 8-PSK 61.85 247.40 61.85 185.55 123.70

Speed achieved depends on the Coding Schemes supported by the GSM/EDGE
Network. Data rate is the payload per slot (headers plus data).

4.13 SMS Technical Data

Attribute Data

Concatenated SMS Yes, up to 10 messages
Character set 7-bit, 8-bit, Unicode
SMS Cell Broadcast Supported by AT Command

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

15 (28)

5 C3607w Hardware Overview

5.1 General

C3607w is a 28.5x33.5x2.3 mm 192-lead LGA package surface mounted
component, see chapter 7 for Related Information and references. C3607w is an
integrated solution using the host’s antenna system and UICC reader.

It is designed as an add-in option for integrators of MID and ultra-portable personal
computers. The product HW comprises of the following component parts:

1. HSPA and GSM wireless network adapter with system clock support for
external GPS receiver.

2. Voltage regulation circuitry which converts power from the battery to the
regulated voltage for the system’s components.

3. Baseband circuitry, which provides the signal processing, control, and micro­processing of the system.

4. Onboard flash memory for autonomous operation.

All components are covered by EMC shields. All power, baseband communication
and antenna signals are routed via the LGA pads of the module.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

16 (28)

5.2 Dimensions

The dimensions of the card are given in the figure below.

5.3 Functional Block Diagram

A function representation of C3607w Mini Card is included in the figure below.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

17 (28)

6 Host Software Overview

6.1 Drivers

The C3607w Mobile Broadband Module is initially aimed for hosts running Moblin
based GNU/Linux OS. The only supported API provided to host applications for
accessing module services is AT commandsError! Reference source not found..

The USB drivers are open source and part of the Linux kernel. The drivers are thus
included as preloaded modules in Moblin 2 kernel delivered by Intel.

The module firmware provides a WDM interface for device management and an
ACM interface for control and data traffic. Upon start-up the drivers export TTY ports
to the /dev directory. Two ACM and one WDM port is created. The IP traffic is routed
to the network interface provided in the kernel, which belongs to the USB CDC
class. The interface is based on the USBnet architecture.

6.2 Connection Manager

Within Moblin there is an open source project for developing a daemon program for
managing internet connections called ConnMan. Contact Moblin for more
information.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

18 (28)

7 Related Information and references

Web Site Information

http://www.ericsson.com/
mobilebroadbandmodules

Product information and information about mobile

network infrastructure

http://www.gsmworld.com/ General information on GSM, GPRS and EDGE
http://www.umts-forum.org General information on UMTS

7.1 Documents Available

Product Languages

AT Command Manual English
Technical Description & User Guide English and Russian
Integrator’s Guide English
Data Sheet C3607w English
MBM Customer Cradle Manual English

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

19 (28)

8 Operational and Regulatory information

Please read this information before using your Wireless Mobile Broadband Module.

8.1 Operational Information

8.1.1 Wireless Interoperability

The Wireless Mobile Broadband Module is designed to be interoperable with the
specific wireless service providers and their roaming partners.

8.1.2 Safety

The Mobile Broadband Module, like other radio devices, emits radio frequency
electromagnetic energy. The Mobile Broadband module operates within the
guidelines found in radio frequency safety and recommendations. These standards
and recommendations reflect the consensus of the scientific community and result
from deliberations of panels and committees of scientists who continually review and
interpret the extensive research literature. In some situations or environments, the
use of the Mobile Broadband module may be restricted by the proprietor of the
building or responsible representatives of the applicable organization.

Examples of such situations include the following:

• Using the Mobile Broadband equipment on board airplanes, or

• Using the Mobile Broadband equipment in any other environment where the risk

of interference with other devices or services is perceived or identified as being
harmful.

If you are uncertain of the policy that applies to the use of wireless devices in a
specific organization or environment (an airport, for example), you are encouraged
to ask for authorization to use the Mobile Broadband device before you turn it on.

WARNING: Explosive Device Proximity Warning – Do not operate a portable
transmitter (such as a wireless network device) near unshielded blasting caps or in
an explosive environment unless the device has been modified to be qualified for
such use.

CAUTION: Use on Aircraft – Regulations of the FCC and FAA prohibit airborne
operation of radio-frequency wireless devices because their signals could interfere
with critical aircraft instruments.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

20 (28)

8.1.3 Recommendations

• Always treat your product with care and keep it in a clean and dust-free place.

• Do not expose your product to liquid, moisture or humidity.

• Do not expose your product to extreme high or low temperatures.

• Do not expose your product to open flames or lit tobacco products.

• Do not drop, throw or try to bend your product.

• Do not paint your product.

• Do not use your product near medical equipment without requesting permission

from your treating physician or authorized medical staff.

• Do not use your product when in or around aircraft or in areas displaying a “turn
off two-way radio” sign.

• Do not use your product in an area where a potentially explosive atmosphere
exists.

• Do not place your product or install wireless equipment in the area above your
car’s airbag.

• Do not attempt to disassemble your product. Only authorized personnel should
perform service.

8.1.4 Children

Do not allow children to play with your Mobile Broadband Module. They could hurt
themselves or others, or could accidentally damage the Mobile Broadband Module.
Your Mobile Broadband Module may contain small parts that could be detached and
create a choking hazard.

8.1.5 Disposal of old electrical & electronic equipment

All electrical and electronic equipment included should not be treated as household
waste. It should instead be left at the appropriate collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to conserve natural
resources. For more detailed information about the recycling of this product, please
contact your local city office, your household waste disposal service or the store
where you purchased your Mobile Broadband Module.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

21 (28)

8.1.6 Emergency calls

This Mobile Broadband Modules do not support voice calls or voice services, nor
emergency calls and should not be relied upon for essential communications.

8.2 Regulatory Information

The Mobile Broadband module must be installed and used in strict accordance with
the manufacturer's instructions as described in the user documentation that comes
with the product The device manufacturer is not responsible for any radio or
television interference caused by unauthorized modification of the devices included
with the Mobile Broadband, or the substitution or attachment of connecting cables
and equipment other than that specified by the device manufacturer.. The correction
of interference caused by such unauthorized modification, substitution or attachment
is the responsibility of the user. The device manufacturer and its authorized
resellers or distributors are not liable for any damage or violation of government
regulations that may arise from the user failing to comply with these guidelines.

8.2.1 United States, FCC Notices

FCC Radiation Exposure Statement:
CAUTION: The radiated output power of the Wireless Mobile Broadband module is

far below the FCC radio frequency exposure limits. Nevertheless, the Wireless
Mobile Broadband module should be used in such a manner that the potential for
human contact during normal operation is minimized. Details of the authorized
configurations can be found at

https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm

by entering the FCC ID

number on the device.
CAUTION: This device has been evaluated for and shown compliant with the FCC

RF exposure limits under portable exposure conditions (antennas are within 20 cm
of a person's body) when installed in certain specific OEM configurations. This
device has also been evaluated and shown compliant with the FCC RF Exposure
limits under mobile exposure conditions (antennas are greater than 20cm from a
person's body). Details of the authorized configurations can be found at

https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm

by entering the FCC ID

number on the device.Interference Statement:
This device complies with Part 15 of the Federal Communications Commission

(FCC) Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

22 (28)

This equipment has been tested to, and found to be within the acceptable limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment generates radio
frequency energy and is designed for use in accordance with the manufacturer's
user manual. However, there is no guarantee that interference will not occur in any
particular installation. If this equipment causes harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
you are encouraged to try to correct the interference by one or more of the following
measures:

Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected
Consult the dealer or an experienced radio/television technician for help
Note: This Mobile Broadband device must be installed and used in strict accordance

with the manufacturer's instructions as described in the user documentation that
comes with the product. Any other installation or use will violate FCC Part 15
regulations. Modifications not expressly approved by the device manufacturer could
void your authority to operate the equipment.

8.2.2 European Union, EU Declaration of Conformity

European Union, R&TTE Compliance Statement
Hereby, the device manufacturer declares that this Mobile Broadband device is in

compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

23 (28)

9 Environmental Declaration

Ericsson has a responsibility to the community to provide products which are safe to
use and which have minimal impact upon the environment. Ericsson's Design for
Environment program is designed to meet legislative and market requirements in the
countries where Ericsson sell C3607w.

Ericsson's Design for Environment program lists chemical substances that are
banned or restricted for use in Ericsson’s products and manufacturing operations.
Ericsson works with its suppliers to eliminate such substances in procured material.

Restrictions on the use of substances in Ericsson products are divided into two
categories; banned substances and restricted substances.

Banned substances are prohibited for use in specified applications in Ericsson
products in accordance with relevant legislation.

Restricted substances may only be used where no technically and/or economically
acceptable alternatives exist and will be replaced as soon as possible.

The ban or restriction does not apply where the presence of a substance is
unintentional and in the form very small concentrations derived from natural
impurities.

Note: Legislation regulating the use of banned substances includes exemptions
allowing limited use where no technically acceptable alternatives exist. Ericsson
makes use of some of these exemptions in order to maintain product quality.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

24 (28)

10 C3607w Material Declaration

Laboratory reports indicate the following content of substances on Ericsson’s
banned and restricted list in the C3607w product.

10.1 Banned Substances

Substance Allowed C3607w

Cadmium Not present
Mercury Not present
Chromium (VI) compounds Not present
Lead TBD g *
Halogenated hydrocarbons PBB/PBDE Not present
Organo-tin compounds Not present

*This product is lead-free soldered but makes use of RoHS exemptions 5 & 7a

10.2 Restricted Substances

Substance Allowed C3607w

Antimony TBD g
Beryllium Not present
Bismuth TBD g
Phthalates Not present
Chlorinated polymers Not present
Halogenated hydrocarbons (TBBE and other

non-prohibited BFR's)

TBD g

C3607w is RoHS (Restrictions on Hazardous Substances) compliant. A full report
can be obtained from Ericsson upon request.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

25 (28)

10.3 Disposal

C3607w is compliant with WEEE (Waste Electrical and Electronic Equipment
Directive).

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

26 (28)

11 Terminology and Abbreviations

2G Generic term for the second generation of cellular networks,

when digital technology was used. GSM is a 2G network.

3G Generic term for the third generation of cellular

networks such as UMTS.

APN Access Point Name. Used in GPRS to define services to

which the terminal can connect, for example, Internet, WAP,
MyCompany.

bps Bits per second – rate of data flow.
CS Circuit Switched. Connection from A to B which has a fixed

bandwidth and is maintained over a period of time, for
example a voice telephone call.

CS-1 to CS-4 Coding Scheme. Determines the data rate per timeslot in

GPRS.

E-GPRS Enhanced GPRS. A GPRS network enhanced with EDGE

technology to provide greater speed and capacity.

EGSM Extended GSM. New frequencies specified by the European

Radio Communications Committee (ERC) for GSM use when
additional spectrum is needed (Network-dependent). It allows
operators to transmit and receive just outside GSM’s core 900
frequency band. This extension gives increased network
capability.

EAP Extensible Authentication Protocol.
EDGE Enhanced Data Rates for Global Evolution.

Technology which improves the throughput of a GPRS
network by a factor of 3.

GMSK Gaussian Minimum Shift Keying. A method of modulating

data, used in GPRS and EDGE.

GPRS General Packet Radio Services.
GPS Global Positioning System.
GSM Global System for Mobile Communications. GSM is the

world’s most widely-used digital mobile phone system. At the
end of Jan 2004 there were over one billion GSM subscribers
across more than 205 countries.

GSM850 GSM network operating in the 850MHz band. Used in the

USA.

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

27 (28)

GSM 900 GSM network operating in the 900MHz band. Used mainly in

Europe, Australia and South Africa.

GSM 1800 Also known as DCS 1800 or PCN. A GSM network operating

in the 1800 MHz band. Used in Europe and Asia-Pacific.

GSM 1900 Also known as PCS. A GSM network operating in the

1900MHz band. Used in the USA and Canada.

HSPA High Speed Packet Access.
HSDPA High Speed Downlink Packet Access.
HSUPA High Speed Uplink Packet Access.
ISP Internet Service Provider.
kbps Kilobits per second – rate of data flow.
LAN Local Area Network
LGA Land Grid Array
MCS Modulation Coding Scheme. MCS-1 to MCS-9 are used in

EDGE.

NACC Network Assisted Cell Change. Feature which reduces the

time taken to perform a cell reselection.

NDIS Network Driver Interface Specification. A Windows Device

Driver specification, used for Ethernet cards, ISDN Adaptors
and GPRS WAN adaptors.

PC Personal Computer.
PCS Personal Communications Services, often used to describe

GSM1900 networks.
PDP Packet Data Protocol.
Phone book A memory in the SIM card where phone numbers can be

stored and accessed by name or position.
RoHS Restriction of use of certain Hazardous Substances.
Rx Receive.
SDK Software Developer’s Kit.
Service Provider A company that provides services and subscriptions to mobile

services (phones, mobile broadband, etc.).

Technical Description and User Guide C3607w

4/1424-LZT 108 9714/01 Uen Rev B 2009-12-11

© Ericsson AB 2009

Commercial in confidence

28 (28)

SIM card Subscriber Identity Module card – a card that must be

inserted in any GSM-based mobile terminal. It contains

subscriber details, security information and memory for a

personal directory of numbers. The card can be a small plug-

in type or credit card-sized, but both types have the same

functions.
SMS Short Message Service. Allows messages of up to 160

characters to be sent and received via the network operator's

message center to a mobile phone.

TBD To be defined.
TBF Temporary Block Flow.
TCP/IP Transmission Control Protocol/Internet Protocol.
TCP/IPv4 TCP/IP Version 4. Most widely implemented form of TCP/IP

today having a 4 byte address format such as

212.161.127.136.

TE Terminal Equipment. Generic term for GSM terminals such as

phones and Mobile Broadband Modules.
TLS Transport Layer Security. Used, for example, by Web

browsers

Tx Transmit.
UICC UMTS Integrated Circuit Card.
UMTS Universal Mobile Telecommunications System. 3G network

technology using WCDMA methods.
USIM UMTS Subscriber Identity Module.
VPN Virtual Private Network.
WAP Wireless Application Protocol. A global standard

specified in order to make Internet services available for

mobile users.
WCDMA Wideband Code Division Multiple Access. A modulation

technique using a wide bandwidth (5MHz in the case of

UMTS). All terminals transmit in the entire bandwidth and the

signals from each are differentiated via the use of unique

codes assigned to each transmission.

WEEE Waste Electrical and Electronic Equipment Directive.
WWW World Wide Web.
