eQ 3 KS300US User Manual
Operating Instructions
Combination Weather Sensor
KS 300-2US
ELV Electronics Ltd. · Hongkong
1
These operating instructions belong with this product. They contain important information
for putting it into service and operating it. This should be noted also when this product is
passed on to a third party.
Therefore look after these operating instructions for future reference!
A list of contents with the corresponding page numbers can be found in the index on page 4.
1st English edition May 2006
Documentation © 2006 ELV Electronics Limited
All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or
duplicated or processed using electronic, mechanical or chemical procedures without written
permission of the publisher.
This handbook may contain mistakes and printing errors. The information in this handbook is
regularly checked and corrections made in the next issue. We accept no liability for technical
mistakes or printing errors, or their consequences.
All trademarks and patents are acknowledged.
Printed in Hong Kong
Modifications due to technical improvements may be made without prior notification.
00066932 Y2006 V1.0
2
Introduction
Dear Customer,
Thank you for purchasing this product.
The product has been EMC-tested and thus meets the requirements of the valid national
guidelines. See also FCC-Information.
In order to maintain this condition and ensure safe operation, you, as the user, have to observe
this operating manual.
Prior to using the product for the first time, please read the entire operating manual and observe
all operating and safety instructions.
We should already like to point out now the correct order for commissioning the
F
All company names and product descriptions listed herein are the trademarks of the respective manufacturers. All rights are reserved.
products. Please also observe the installation and calibration instructions in this
operating manual as well as the information about impairment of radio transmission
between the sensors and base station.
3
Table of Contents
Page
1. Intended use ..........................................................................................................................5
2. Scope of delivery ...................................................................................................................6
3. Terminology ...........................................................................................................................6
4. Features and functions ..........................................................................................................6
5. Safety instructions .................................................................................................................6
6. Battery and environment instructions ....................................................................................7
7. Preparation for operation, commissioning ............................................................................7
8. Changing battery ...................................................................................................................9
9. Troubleshooting ...................................................................................................................10
10. Range ..................................................................................................................................11
11. Maintenance and cleaning ...................................................................................................12
a) General ............................................................................................................................12
b) Cleaning combination sensor ..........................................................................................12
12. Handling ..............................................................................................................................14
a) General ............................................................................................................................14
b) Combination sensor ........................................................................................................14
13. Disposal ...............................................................................................................................15
a) General ............................................................................................................................15
b) Disposing of batteries and accumulators ........................................................................15
14. Technical data ......................................................................................................................16
15. FCC-Information ..................................................................................................................17
4
1. Intended use
The combination weather sensor is a high-quality universal weather measuring system which
processes a large quantity of weather data and additional information.
All relevant data are transmitted to an optional base unit.
The forecasts of the base station serve only the purpose of orientation. They do not represent
an absolutely true forecast. The manufacturer does not assume any responsibility for incorrect
displays, measuring values or weather forecasts or any consequences which may result from
these.
The product is intended for private use. It is not suited for medical purposes or public information.
The components of this product are not toys. Install all components in such a way that children
have no access to them.
The product is battery-operated. All external sensors transmit their data per radio to the base
station (433 MHz, range up to 100 m in open space, see chapter 10 on page 11).
Any other use than that described above may lead to damage to the product or to
other danger.
Read the complete operating manual carefully. It contains much important information
about the installation and operation.
5
2. Scope of delivery
• Combination sensor KS 300-2US
• Metal rods/pegs for the combination sensors
• Operating manual
3. Terminology
An exclamation mark in a triangle indicates important instructions in the operating
manual which must be observed under all circumstances.
You will see the „hand” symbol for special tips and instructions concerning operation.
F
4. Features and functions
• Radio transmission of:
- rain quantity
- immediate rain detection
- wind velocity
- temperature
- humidity
5. Safety instructions
Damage caused by non-observance of this operating manual can lead to forfeiture of the warranty! We shall not assume any liability for subsequent damage!
We shall not assume any liability for damage to items or persons caused by
improper handling or non-observance of the safety instructions! In such cases,
any guarantee claims shall become null and void .
Dear Customer, the following safety and hazard notices not only serve the protection
of your health but also the protection of the appliance. Please read the following points
carefully!
Do not use this product in hospitals or medical institutions. Although the outdoor sensor only
emits relatively weak radio signals, these may cause interference to life-support systems. The
same can also apply in other areas.
If used correctly, the rain/wind detector is suited on the other hand to unprotected outdoor
locations.
For safety and licensing reasons (CE), it is not permitted to convert or modify the product.
6
