Epson TWD1 Product Sheet

All you need to watch a big movie in your home

All you need for a great show

No more wires! Just you, your family
and friends and Epson’s great sound
and vision. Simply connect your
Epson EMP-TWD1 to the power,
insert your chosen DVD and watch
movies the way they were meant to
be seen – on the big screen.

Cinema quality

With its 1200 ANSI lumens, developed
through Epson Cinema Filter
Technology, the Epson EMP-TWD1
delivers bright, natural colour images
that stay crisp and clear in a variety of
lighting conditions. Four preset colour
modes automatically adjust the
brightness and contrast level to
ensure the best image quality.

Big screen, small space

You don’t need a large room to
project a big screen. You can create
an amazing 60" image at just about

1.5m from the screen. Horizontal
and vertical lens shift and keystone
correction allow you to position your
projector off centre and the image
will still be aligned correctly.

Enjoy superb Epson images with the built
in JVC DVD player and sound system. The
Epson EMP-TWD1 is all you need to watch
movies, TV, play games and listen to music.

Two built-in 10W JVC speakers
for amazing sound quality

High quality, DVD player
powered by JVC for movies
or music

EMP

TWD1

The Epson EMP-TWD1 – user-friendly,
quality viewing

• Compact, stylish home entertainment
solution – projector, DVD and
surround-sound

• Exceptional image quality thanks to
Epson exclusive Cinema Filter

• Accurate, natural images thanks to
3LCD technology

• Brilliant picture quality in any light
with 1200ANSI lumens and a choice
of 4 colour modes

• True cinematic feel 16:9 resolution –
854 x 480 pixels

Movies and much more

You can also connect your Epson
EMP-TWD1 to your games console or
your digital camera. Imagine battling
it out on the latest video game on a
big screen, or hosting high quality
slideshows of your holiday snaps. You
can even listen to CDs and MP3s and
sing along to your favourite songs
with JVC sound technology.

Take the movies wherever you want

The Epson EMP-TWD1 is so compact
and quick to set up that you can
simply unplug it and carry it to another
room. Or if you want to really impress
your friends, don’t just arrive with the
latest movie, bring your own home
cinema to watch it on.

Horizontal and vertical
lens shift

Connection to TV, Video, digital
camera and games consoles

Epson® is a registered trademark of Seiko Epson® Corporation. All other product names and other company
names used herein are for identification purposes only and may be trademarks or registered trademarks of their
respective owners. Errors and omissions excepted, all specifications are subject to change without notice.

EMP TWD1-EN-07/05

Model

)

e

e

y

A

y

y

Adj

;

A

A

A

A

A

A

A

A

A

A

A

g

e

e

y

Telephone: [phone]
E-mail: [e-mail]

Fax: [phone]
www.epson.co.uk

Projection System
Projection Method
Specification of Main Parts

LCD Size: 0.55-inch wide panel with MLA; Driving Method: Poly-silicon TFT active matrix;

Projection Lens

Lamp Type: 135 W UHE (E-TORL); Life: 2000H (Color mode: Dynamic, Living room, Theatre),

Screen Size (Projected distance

Lens Shift Range

Brightness

High Brightness Mod
Low Brightness Mod

Contrast
Brightness Uniformit
Color Reproduction
Video Quality

Sound Output

udio Amp Qualit

Dynamic range More than 70 dB
Total Harmonic Distortion Less than 0.5%

Function
Color Mode
Remote Control Infrared
Receiver Position / Distance /
Directivit

ustment Functions

Video I/O

Display Performance NTSC: 480 lines, PAL: 480 lines (Depends on observation of the multi-burst pattern)
Input Signal
Video Standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Video Signal Composite Video (1.0 Vp-p / Sync.negative, 75 ohm) / S-Video (Luminous 0.714 Vp-p, Chrominous 0.286 Vp-p, 75 ohm)

udio Signal 2.0 Vrms / 47 k-ohm
Input Terminal
Video Composite Video: RCA (Yellow) x 1; S-Video: Mini DIN

udio RCA (White/Red) x 1 (for Composite Video and S-Video)
Output Signal

udio Analog Head phone: 11 mW / 32 ohm (16 ohm - 1 k-ohm available), Subwoofer: 650 mVrms / 10 k-ohm

udio Digital -21 dBm ϡ -15 dBm
Output Terminal

udio Analog Head phone: Stereo jack (3.5ĭ) x 1 / Subwoofer: RCA x 1

udio Digital Optical square connector

DVD Unit

Loading Tray
Media DVD Video, DVD-R/-RW (Video format), Video CD, Super Video CD,

udio Format DTS, Dolby 5.1
Function Tray Lock, Sleep timer, Auto standby. Dimmer (2 step, On/Off/Auto)

Operating Temperature
Start-up Period
Cool-down Period
Power Supply Voltage
Power Consumption
230V Area
Dimension

Exclude Feet (D x W x H) 310mm x 340mm x 180mm
Maximum Dimension (D x W x H) 310mm x 340mm x 200mm

Weight
Fan Noise

htness Mode

Low Bri
Destination: Western Europe

DVD Menu Languag
Projector Menu Languag
DVD Region 2

Supplied Accessories
Optional Accessories
Warrant

Epson EMP-TWD1
RGB liquid crystal shutter projection system
Front

Pixel Number: 409,920 dots (854 x 480) x 3; Native Resolution: 480p; Aspect Ratio: 16:9;
Pixel Arrangement: Stripe; Refresh Rate: 50Hz - 60Hz;
Type: Manual zoom / Manual focus; F-number: 1.7 - 2.1; Focal Length: 13.7 mm - 20.5 mm;
Zoom Ratio:1 - 1.5; Lens Cover: Yes

3000H (Color mode: Theatre Black)
30" to 300" (0.73m to 7.75m) (Wide: 16:9 image)
30" to 300" (1.11m to 11.37m) (Tele: 16:9 image)
Vertical: 50% max. (upward), 50% max. (downward)
Horizontal: 25% max. (left and right)

1200 ANSI lumens (Color mode: Dynamic, Zoom: Wide, Lens Shift: Center)
350 ANSI lumens (Color mode: Theatre Black, Zoom: Wide, Lens Shift: Center)
1000:1 (Color mode: Dynamic, Zoom: Tele, Lens Shift: Full)
90%
Full Color (16.77 million Colors)
Direct progressive & Interlace-Progressive conversion
(3-2 film detection, motion detection, only for internal DVD)
Stereo DD (Direct Drive) speaker (10 W x 2 / 4 ȍ)
Subwoofer 15 W (option)

Muting, Image On / Off, Break
Dynamic, Living room, Theatre, Theatre Black
Front & Rear: 7 m,
Right / Left: -30 degrees to +30 degrees,
Upper / Lower: -15 degrees to +15 degrees
Projector / Remote Control: Keystone / Brightness / Contrast / Tint / Saturation / Sound / Input Signal;
Tilt Angle: 0 degree; Keystone Correction: Vertical: -15 degrees to +15 degrees (Zoom: Tele)
Cinema Filter: Controlled automatically with color mode ON: Theatre / Theatre Black, OFF: Living Room / Dynamic.

udio CD, MP3 (CD-R/RW), WMA (CD-R/RW), JPEG (CD-R/RW)

5 °C to 35 °C <41 °F to 95 °F> (20% - 80% humidity)

pprox. 8 seconds (Image ON)
pprox. 9 seconds

100 - 240V AC ±10%, 50/60Hz

Lamp On: 220W; Lamp Off: 70W; Standby 9W

pprox. 15.4lbs / 7.0kg

28dB

English / French / German / Spanish, (English / Spanish / French / English) for Italy
English / French / German / Spanish, (English / Spanish / French / Italian) for Italy

Power Cable: 3 m White cable; Remote Control: With self-luminous buttons; Battery: Mangan, Size AA x 2; User's Manual Set: attached
Spare Lamp: ELPLP33; Air Filter: ELPAF09; Powered Subwoofer: ELPSP01
UK - 3 year next day on site repair or replace
Ireland - 3 year next day on site repair or loan
