Introduction
After you have set up your Epson printer as described on the Start Here sheet, turn
here to:
■ Make a copy of a document or photo
■ Print photos from a memory card
■ Get the basic steps for printing from your computer
■ Scan a document or photo and restore or correct the color
■ Perform routine maintenance and solve simple problems
This book tells you how to do most of these things without ever turning on your
computer! For additional instructions, see the on-screen Epson Information Center
(which includes your user’s guide) by double-clicking its icon on your desktop.
Please follow these guidelines as you read the instructions:
Warning:
Warnings must be followed carefully to avoid bodily injury.
Caution:
Cautions must be observed to avoid damage to your equipment.
Note:
Notes contain important information about your printer.
Tip:
Tips contain hints for better copying, scanning, and printing.
4 Introduction
Loading Paper
You can print documents and photos on a variety of paper types and sizes. For
details, see page 7.
1. Open the paper support and pull up the extensions. Then open the output
tray, pull out the extensions, and raise the stopper.
2. Flip the feeder guard forward, then squeeze the edge guide and slide it left.
Loading Paper 5
3. Insert the paper, glossy or printable side up, against the right edge and behind
the tab. (Load letterhead or pre-printed paper top edge first.)
Always load paper short edge
first, even for landscape printing.
You can load up to 100 sheets of letter-size plain paper, 80 sheets of matte, or
20 sheets of photo paper. Load other papers one sheet at a time. See your onscreen Epson Information Center for more information.
Note:
The type of paper you choose affects the way your printout looks. If you are just
making a copy or printing a rough draft, plain paper is fine. However, for the best
results, you’ll want to use one of Epson’s special ink jet papers designed for your
printer. For example, your photos will look great printed on Epson Ultra Premium
Photo Paper Glossy (see page 7 for more information).
4. Slide the edge guide against the paper, but not too tightly.
Note:
For instructions on loading envelopes, see your on-screen Epson Information Center.
6 Loading Paper
Using Special Papers
Epson offers a wide array of high quality papers, making it easy to maximize the
impact of your photos, presentations, and creative projects.
You can purchase genuine Epson ink and paper at Epson Supplies Central
www.epson.com/ink3 (U.S. sales) or www.epson.ca (Canadian sales). You can
also purchase supplies from an Epson authorized reseller. To find the nearest one,
call 800-GO-EPSON (800-463-7766).
SM
at
Part
Paper type Size
Epson Ultra Premium Photo Paper
Glossy
Epson Premium Photo Paper
Glossy
Epson Premium Photo Paper
Semi-gloss
Epson Photo Paper Glossy Borderless 4 × 6 inches S041809
Epson Bright White Paper Letter (8.5 × 11 inches) S041586 500
Epson Premium Presentation
Paper Matte
Epson Premium Presentation
Paper Matte Double-sided
Epson Presentation Paper Matte Letter (8.5 x 11 inches) S041062 100
Borderless 4 × 6 inches S042181
Borderless 5 × 7 inches S041945 20
Borderless 8 × 10 inches S041946 20
Letter (8.5 × 11 inches) S042182
Borderless 4 × 6 inches S041808
Borderless 5 × 7 inches S041464 20
Borderless 8 × 10 inches S041465 20
Letter (8.5 × 11 inches) S042183
Borderless 4 × 6 inches S041982 40
Letter (8.5 × 11 inches) S041331 20
Letter (8.5 × 11 inches) S041141
Borderless 8 × 10 inches S041467 50
Letter (8.5 × 11 inches) S041257
Letter (8.5 × 11 inches) S041568 50
Legal (8.5 x 14 inches) S041067 100
number
S04217460100
S0421752550
S04172740100
S0416672550
S04203850100
S041649
S041271
S04218050100
Sheet
count
20
50
100
Using Special Papers 7
Part
Paper type Size
Epson Photo Quality Self-adhesive
Sheets
Epson Iron-on Cool Peel Transfer Letter (8.5 x 11 inches) S041153 10
A4 (8.3 × 11.7 inches) S041106 10
number
Sheet
count
8 Loading Paper
Copying a Document or Photo
Follow the instructions in this section to position your originals correctly on the
scanner glass and make color or black-and-white copies.
Placing the Original on the Glass
1. Open the document cover and place your original face-down on the scanner
glass, with the top facing into the front right corner.
2. Close the cover gently so you don’t move the original.
Copying a Document or Photo 9
Copying a Document
You can copy documents onto letter- or A4-size plain paper or Epson special paper
just like you would on a copy machine.
1. Load letter- or A4-size plain paper or Epson special paper in the sheet feeder
(see page 5).
2. Place your original document on the scanner glass (see page 9).
3. Press the
Copy button.
4. Flip up the LCD screen, if necessary.
5. To print more than 1 copy, press
+ or – to select the
number (up to 99).
6. Press l or r to select
Color or B&W copies.
7. Press d, then press r to change the layout.
Select
With Border to leave a small margin
around the image or select
Borderless to expand
the image all the way to the edge of the paper
(slight cropping may occur).
Note:
You cannot print borderless on plain paper.
8. To change any other print settings, press Menu
and select your settings (see page 13 for details).
When you’re done, press
9. Press
x Start to begin copying.
To cancel copying, press
OK.
y Stop/Clear Settings.
10 Copying a Document or Photo
Copying a Photo
You can copy photos onto 4 × 6-inch, 5 × 7-inch, letter-size, or A4-size Epson
special paper (various types available) for instant photo reprints. You can also print
with or without borders and convert color photos to black and white.
1. Load 4 × 6-inch, 5 × 7-inch, letter-size, or A4-size Epson special paper in the
sheet feeder (see page 5).
2. Place your original photo on the scanner glass (see page 9).
3. Press the
Copy button.
4. Flip up the LCD screen, if necessary.
5. To print more than 1 copy, press
6. Press l or r to select
Color or B&W copies.
+ or – to select the number (up to 99).
7. Press d, then press r to change the layout.
Select
With Border to leave a small margin around the image or select
Borderless to expand the image all the way to the edge of the paper (slight
cropping may occur).
Note:
You cannot print borderless on plain paper.
8. To change any other print settings, press Menu
and select your settings (see page 13 for details).
When you’re done, press
9. Press x
Start to begin copying.
To cancel copying, press
OK.
y Stop/Clear Settings.
Copying a Photo 11
Restoring and Cropping Photos
You can restore old, faded photos to their original brilliance. You can also crop
your photos to zoom in on the subject.
Note:
To restore photos larger than 5 × 7 inches, use the NX510 Series software on your
computer.
1. Load 4 × 6-inch, 5 × 7-inch, letter-size, or A4-size Epson special paper.
2. Place your original photo on the scanner glass.
3. Press the
4. To turn on
photo is not faded, do not turn on
5. Press
Photo button, then press OK.
Color Restoration, press r, select On, then press OK. (If your
Color Restoration.)
OK again to prescan your photo. You see these
settings over a preview of your photo:
6. To print more than 1 copy, press
+ or – to select the
number.
7. If you want to crop your photos and enlarge the
resulting image area to fit onto your paper, press
Display/Crop.
■ To resize the image area, press + or –.
■ To move the image area, use the arrow buttons.
■ To check the zoomed image, press OK.
After you are done cropping your photo, press
8. To change print settings, press Menu and select
your settings (see page 13). When you’re done,
press
OK.
9. Press x
Clear Settings
Start to begin copying. If you need to cancel copying, press y Stop/
.
OK.
12 Copying a Document or Photo
Copy and Restore Print Settings
Press the Menu button to change settings. When you’re done, press OK.
■ To adjust the copy size, select Reduce/Enlarge (reduction/enlargement) and
choose
(to automatically size the image to fit your paper).
■ To change the paper type, select Paper Type and choose the type of paper
you loaded.
■ To change the paper size, select Paper Size and choose the size you loaded.
Actual (to select a percentage using + or –) or Auto Fit Page
Paper type Paper Type setting
Plain paper Plain Paper
Epson Bright White Paper
Epson Presentation Paper Matte
Epson Premium Presentation Paper Matte Matte
Epson Premium Photo Paper Glossy Prem. Glossy
Epson Premium Photo Paper Semi-gloss
Epson Ultra Premium Photo Paper Glossy Ultra Glossy
Epson Photo Paper Glossy Glossy
Note:
Paper Size options depend on the Paper Type you choose.
To change the print quality, select Quality and choose Draft, Standard, or
■
Best.
Note:
You can only adjust the Quality setting when you select Plain Paper as your Paper
Type setting; otherwise, the setting will be Standard. When you are restoring or
cropping photos, the Quality setting is set to Standard and you cannot adjust it.
To adjust the darkness or lightness of the print, select Density and choose a
■
higher (darker) or lower (lighter) setting.
■ To adjust the amount of image expansion when printing borderless photos,
Expansion and choose Standard, Medium, or Minimum.
select
Note:
You may see white borders on your printed photo if you use the Minimum setting.
Copy and Restore Print Settings 13
Printing From a Memory Card
Your printer lets you print photos directly from your digital camera’s memory card;
just insert it into one of the memory card slots and you’re ready to print.
See the on-screen Epson Information Center for instructions on copying memory
card files between your printer and a computer; printing photos by date; printing
photos from a slideshow; printing photos directly from your camera; and printing
photos pre-selected in your camera (DPOF
Compatible Cards and Image Formats
You can use the following types of cards with your Epson printer:
Slot Type of card
™
or Digital Print Order Format).
Left slot SD™
SDHC™
miniSD™*
miniSDHC*
microSD*
microSDHC*
MultiMediaCard™
MMplus™
MMCmobile™*
MMCmicro™*
Memory Stick™
Memory Stick Duo™*
Right slot CompactFlash
Microdrive™
* Adapter required
14 Printing From a Memory Card
®
Type I and II
Memory Stick PRO™
Memory Stick PRO Duo™*
Memory Stick PRO-HG Duo™*
Memory Stick Micro*
MagicGate™ Memory Stick
MagicGate Memory Stick
Duo™*
xD-Picture Card™
xD-Picture Card Type H
xD-Picture Card Type M
xD-Picture Card Type M+
Your Epson printer supports image files that meet the following requirements:
Media format DCF version 1.0 or 2.0 compliant*
File format JPEG
Supports Exif version 2.21
Image size 80 × 80 pixels to 9200 × 9200 pixels
Number of files Up to 999
* DCF is the “Design rule for Camera File system” standard
Inserting the Card
1. Make sure your Epson printer is turned on.
2. Insert your card into the correct slot as shown:
Insert just one card at a time (it won’t go in all the way)
Left slot
Right slot
Memory card
access light
The memory card access light flashes, then stays lit. Now you can:
■ View your photos on the LCD screen and print them (page 16)
■ Print an index sheet so you can select which photos to print (see page 18)
Inserting the Card 15
When you want to remove the card, make sure the memory card access light is not
flashing, then pull the card straight out of its slot. If your printer is connected to
your computer, first prepare the card for removal:
■ If the computer is running Windows
bar and select
Safely remove USB Mass Storage Device. Once you see a
®
, click the or icon on the task
confirmation message, remove the card.
■ If your computer is a Macintosh
®
, drag the removable disk icon from your
desktop into the trash. Then remove the card.
Caution:
Do not remove the card or turn off your Epson printer while the memory card access
light is flashing; you may lose data on the card.
Selecting Individual Photos for Printing
You can select individual photos for printing as you view them on the LCD screen.
1. Press the
2. Press
Memory Card button. You see this screen:
OK to select View and Print Photos.
3. Press l or r to move through your photos and
display one that you want to print.
4. Press the
+ or – button to select the number of
copies you want of that photo.
5. If you want to crop your photo and enlarge the resulting image area to fit onto
your paper, press
■ To resize the image area, press + or –.
■ To move the image area, use the arrow buttons.
■ To check the zoomed/cropped image, press OK.
■ To rotate the image area, press Menu.
After you finish cropping your photo, press
Display/Crop.
OK.
6. Repeat steps 3 through 5 to select more photos, if you want.
7. To change any of the print settings displayed on the screen, press
select your settings (see page 20). When you’re done, press
Menu and
OK.
16 Printing From a Memory Card
Loading...
