EPSON® ELPDC04
High Resolution Document Camera
User’s Guide
Important Safety Information
WARNING: Never open any cover on the document camera. Dangerous electrical voltages inside the document
camera can severely injure you. Do not attempt to service this product yourself. Refer all servicing to qualified
service personnel.
WARNING: The document camera and its accessories come packaged in plastic bags. Keep plastic bags away from
small children to avoid any risk of suffocation.
Caution: Never attempt to replace the lamps. Refer all lamp servicing to qualified service personnel.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of SEIKO EPSON CORPORATION. The information contained herein is designed only for
use with this EPSON product. EPSON is not responsible for any use of this information as applied to other
products.
Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third
parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse,
or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the
U.S.) failure to strictly comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.
SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original EPSON Products or EPSON
Approved Products by SEIKO EPSON CORPORATION.
EPSON is a registered trademark of SEIKO EPSON CORPORATION.
PrivateLine and Presenters Club are registered trademarks and EPSON Connection is a service mark of Epson
America, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. EPSON disclaims any and all rights in those marks.
Copyright © 2002 by Epson America, Inc. 1/02
Printed on recycled paper. CPD-13518
ii
Contents
C
1
2
Welcome
Getting the Most from Your Document Camera . . . . . . . . . . 2
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . . 3
Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting Up the Document Camera
Unpacking the Document Camera . . . . . . . . . . . . . . . . . . . . . 6
Installing Batteries in the Remote Control . . . . . . . . . . . . . . . 7
Positioning the Document Camera. . . . . . . . . . . . . . . . . . . . . 8
Unfolding the Document Camera . . . . . . . . . . . . . . . . . . . . . 9
Connecting to a Projector or TV/Computer Monitor. . . . . . 11
Connecting the RGB Video Cable . . . . . . . . . . . . . . . . . 11
Connecting the RCA Cable . . . . . . . . . . . . . . . . . . . . . . 12
Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting a Mouse to the Document Camera . . . . . . . . . . 14
Adjusting the Camera DIP Switches. . . . . . . . . . . . . . . . . . . 15
Using the Document Camera
Turning On Your Equipment. . . . . . . . . . . . . . . . . . . . . . . . 18
Turning On the Document Camera . . . . . . . . . . . . . . . 18
What To Do If You See a Blank Screen . . . . . . . . . . . . . 19
Switching Between Picture Sources. . . . . . . . . . . . . . . . . . . . 20
Adjusting the Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . 5
. . . . . . . . . . . . . . . 17
iii
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Zooming and Focusing Your Image. . . . . . . . . . . . . . . . 22
Adjusting the Brightness . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the White Balance . . . . . . . . . . . . . . . . . . . . . 23
Using the Pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Pausing the Main Display. . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Adjusting Settings with the On-Screen Display . . . . . . . . . . 24
Using the Camera Head as a Conventional Video Camera . . 26
Using the Image Mate Software . . . . . . . . . . . . . . . . . . . . . . 26
Turning Off and Storing the Document Camera . . . . . . . . . 27
3
4
5
Maintaining and Transporting the
Document Camera
Cleaning the Lenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Cleaning the Document Camera Case . . . . . . . . . . . . . . . . . 33
Transporting the Document Camera . . . . . . . . . . . . . . . . . . 34
Solving Problems
Solving Problems with the Image . . . . . . . . . . . . . . . . . . . . . 36
Solving Problems with the Remote Control . . . . . . . . . . . . . 37
Where to Get Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Telephone Support Services . . . . . . . . . . . . . . . . . . . . . . 38
Technical Specifications
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Compatible Video Formats . . . . . . . . . . . . . . . . . . . . . . . . . 41
. . . . . . . . . . . . . . . . . . . . . . . . . . 31
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
. . . . . . . . . . . . . . . . . . . . . 39
iv
6
Notices
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 43
Remote Control Information . . . . . . . . . . . . . . . . . . . . . . . . 46
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . 47
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . 48
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
v
Welcome
W
Y
our versatile EPSON® ELPDC04 High Resolution Document
Camera can be connected to most types of projectors and display
devices. From boardrooms to auditoriums, you can show fine detail
with a large variety of presentation materials.
Your document camera captures images at a resolution of
1024 × 768 pixels with a maximum shooting area of 13.4 × 9.9 in.
(340 × 252 mm). With its 10× zoom capability and true XGA
resolution, even 10 point type can be read clearly. And the document
camera’s support for RGB and composite video provides additional
versatility.
You can connect the document camera to a wide range of computers,
including IBM
Power Macintosh
PowerBook
high-end workstations such as the Sun
®
computers, many iMac™ and iBook™ series systems, and
®
compatible PCs and laptops, Apple® Macintosh,®
™
series (including G3 and G4 systems),
®
SPARCstation.
™
Welcome
1
Getting the Most from Your Document Camera
Depending on your presentation, you can take advantage of any or all
of these options:
■
Connecting to a projector or TV/computer monitor
The document camera requires an output device, such as a
projector or TV/computer monitor, to display its image. To
connect the document camera to these devices, see page 11.
■
Connecting to a laptop or desktop computer
You can connect a video output source, such as a laptop or
desktop computer, to the document camera. This is especially
useful if your projector has only one video input port. See page 13
for more information.
■
Using the remote control
The remote control lets you control the lamps, zoom and focus
your image, and switch the display from the camera to a
computer. See Chapter 2 for details.
2
Welcome
Using Your Documentation
This book contains all the information you need to set up and use
your document camera. Please follow these guidelines as you read
through it:
■
Warnings must be followed carefully to avoid bodily injury.
■
Cautions must be observed to avoid damage to your equipment.
■
Notes contain important information about your document
camera.
Getting More Information
Need tips on giving presentations or more information about your
document camera? Here’s where you can look for help:
■
http://www.presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art, and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club
■
http://support.epson.com
Download FAQs and e-mail your questions to EPSON support.
If you still need help after checking this User’s Guide and the sources
listed above, you can use the EPSON PrivateLine
get help fast. Call (800) 637-7661 and enter the PIN on the card
included with your document camera. Or take advantage of EPSON’s
electronic support services 24 hours a day. See page 38 for more
information.
®
—and it’s free.
®
Support service to
Registration
To register, simply fill out and return the enclosed registration card.
Registering allows EPSON to better understand and meet your needs.
If you want, you can also receive special updates on new accessories,
products, and services.
Welcome
3
4
Welcome
Setting Up the
1
Document Camera
T
his chapter explains how to set up the document camera for a video
presentation. You’ll find instructions for:
■
Unpacking the document camera
■
Installing batteries in the remote control
■
Positioning the document camera
■
Unfolding the document camera
■
Connecting to a projector or TV/computer monitor
■
Connecting to a computer
■
Connecting a mouse to the document camera
■
Adjusting the document camera’s DIP switches
Setting Up the Document Camera
5
Unpacking the Document Camera
After unpacking the document camera, make sure you have all the
items shown below:
batteries
™
remote control
Image Mate
CD-ROM
document camera
RGB video cable
mouse
RCA cable
power cord
USB cable
Save all the packaging in case you need to ship the document camera
later. Always use the original packaging (or equivalent) when you need
to send the document camera to another location. For transportation
instructions, see page 34.
6
Setting Up the Document Camera
Installing Batteries in the Remote Control
Before using the remote control, install its batteries.
1. Press down on the battery
cover and slide it off.
2. Insert two AAA batteries as
shown.
3. Replace the battery
compartment cover.
caution
When replacing batteries,
take the following
precautions:
Don’t mix old and new
■
batteries.
Replace batteries as soon as
■
they run out. If the
batteries leak, wipe away
battery fluid with a soft
cloth. If fluid gets on your
hands, wash them
immediately.
Don’t expose batteries to
■
heat or flame.
Dispose of used batteries
■
according to local
regulations.
Remove batteries if you
■
won’t be using the
document camera for a
long period of time.
Setting Up the Document Camera
7
caution
Don’t hold or lift the
document camera by the
camera head arm or lighting
unit arms; this may damage
them.
Positioning the Document Camera
Before connecting the document camera, you need to decide where to
place it. Wherever you place it, be sure to follow these guidelines:
■
Place the document camera on a sturdy, level surface.
■
Make sure there is plenty of space for ventilation around and
under the document camera.
■
Make sure the document camera is within 10 feet (3 m) of a
grounded electrical outlet or extension cord, and within 5 feet
(1.5 m) of your output source.
■
Make sure you are within 23 feet (7 m) of the front or back of the
document camera to use the remote control.
■
With the control panel facing you, place the document camera
directly in front of you. Otherwise, items you place on the stage
may appear upside-down.
head arm
8
Setting Up the Document Camera
lighting arm
stage
lighting arm
control panel
Most presenters find it convenient to place the document camera in
front of the audience. This lets the presenter stand in the front of the
room, face the audience, and remain close enough to the equipment to
be able to control it.
Unfolding the Document Camera
Follow these steps to unfold the document camera:
1. Raise the camera arm until you hear a click, then lower it slightly
until it locks into place.
2. Rotate the camera head so that the lens faces the stage
(downward).
3. Raise the right lighting arm, as shown, until it stops.
camera head
lighting arm
stage
Setting Up the Document Camera
9
4. Rotate the lighting units forward, as shown, until they stop.
lighting unit
lighting unit
5. Tilt the lighting arms outward until they stop; then position the
lighting units so that they face the stage (downward).
10
Setting Up the Document Camera
Connecting to a Projector or TV/Computer Monitor
You can connect the document camera to any projector or monitor
that has a standard RGB video or composite video input port.
EPSON projectors support both connections. Most computer
monitors support only RGB video, while many television monitors
support composite video. Follow the instructions below to connect
the document camera to your output device with an RGB video cable
or an RCA cable.
Connecting the RGB Video Cable
Before you start, make sure your document camera and projector or
computer monitor are turned off.
1. Connect one end of the RGB video cable to the document
camera’s
AC IN
ON
OFF
RGB OUT
POWER
RS-232C
port.
RGB OUT
RGB OUT
RGB IN
projector
VIDEO
OUT
USB
0
1
B
C
A
monitor
or
2. Connect the other end of the RGB video cable to the RGB video
input port on the projector or computer monitor.
3. Tighten the screws on the connectors.
note
The RGB video input port on
the projector or monitor may
be labeled “computer,” or
“video in.”
Setting Up the Document Camera
11
Connecting the RCA Cable
Before you start, make sure your document camera and projector or
TV are turned off.
1. Connect one end of the RCA cable to the document camera’s
VIDEO OUT
port.
video out
AC IN
POWER
ON
OFF
RS-232C
RGB OUT
RGB IN
VIDEO
OUT
USB
0
1
B
C
A
or
projector
TV
2. Connect the other end of the RCA cable to the RCA input port
on the projector or TV.
12
Setting Up the Document Camera
Connecting to a Computer
The document camera comes with one RGB video input port. This
can be used to connect a laptop or desktop computer to the document
camera.
This is especially useful if your projector has only one input port. You
can connect a computer to the document camera’s RGB input port as
described below, and connect the document camera to the projector’s
input port as described on page 11. This way, you can use the
camera’s remote control to switch between picture sources. Follow the
instructions on page 20 to switch between the sources.
Before you start, make sure your document camera and computer are
turned off.
1. Connect one end of the RGB video cable to the document
camera’s
RGB IN
port.
AC IN
POWER
ON
OFF
RS-232C
RGB OUT
RGB IN
VIDEO
OUT
USB
0
1
B
C
A
or
computer
2. Connect the other end of the RGB video cable to your computer’s
RGB video output (monitor) port.
3. Tighten the screws on the connectors.
laptop
Setting Up the Document Camera
13
Connecting a Mouse to the Document Camera
The included mouse functions as a pointing device. It also gives you
access to the document camera’s on-screen display, which controls
many of the features that are selectable from the remote control. To
connect the mouse, follow the instructions below.
1. Make sure your document camera is turned off.
2. Connect the mouse cable to the
RS-232C
port on the back of the
document camera.
3. Make sure DIP switch C is set to 0 (up). If it is not, follow the
instructions on page 15 to change the DIP switch setting.
AC IN
POWER
ON
OFF
RS-232C port
RS-232C
RGB OUT
RGB IN
USB
VIDEO
OUT
B
A
0
1
C
14
Setting Up the Document Camera
Adjusting the Camera DIP Switches
The document camera has four DIP switches that control special
settings. Refer to the table below to make sure they are set correctly for
your configuration.
DIP switches
0
1
B
C
A
AC IN
POWER
ON
OFF
RS-232C
RGB OUT
RGB IN
VIDEO
OUT
USB
0
1
B
C
A
DIP Switch 0 1 Function
———Factory use only.
ANTSC
*
PAL Selects the TV video output
format. Select NTSC for US
model TV sets and PAL
European TV sets.
B60 Hz
*
50 Hz Selects the shutter frequency. If
the image starts to flicker, try
setting the shutter frequency
to 50.
C Mouse*RS-232C Selects the communication
mode of the RS-232C port. To
use a mouse, set the switch to
0. To use control codes, set the
switch to 1.
*
Default setting
for
note
For a list of control codes, go
to http://support.epson.com.
After selecting your product
from the list, you can access
technical information on
controlling your document
camera from your computer.
Setting Up the Document Camera
15
16
Setting Up the Document Camera
Using the
2
Document Camera
O
nce you have set up the document camera, you’re ready to turn it
on, adjust the image, and give your presentation. This chapter covers
the following:
■
Turning on the document camera and other equipment
■
Switching between picture sources
■
Adjusting the lighting
■
Adjusting the image
■
Using the pointer
■
Pausing the Main display
■
Adjusting settings with the on-screen display
■
Using the camera head as a conventional video camera
■
Using the Image Mate software
■
Turning off and storing the document camera
Using the Document Camera
17
Turning On Your Equipment
Make sure your document camera and other equipment are set up and
connected correctly, as described in Chapter 1. Always turn on your
projector or monitor first. Then turn on your document camera, as
described below, followed by any other equipment you’ve connected
to it.
You can turn on your computer and video equipment in any order. If
you have both a computer and video source connected, you may have
to switch to the desired source to see its image, as described on
page 20.
Turning On the Document Camera
Follow these steps to plug in and turn on the document camera:
1. Connect one end of the power cord to the document camera’s
power inlet.
AC IN
POWER
ON
OFF
RS-232C
RGB OUT
RGB IN
VIDEO
OUT
USB
0
1
B
C
A
power
inlet
2. Connect the other end to a grounded electrical outlet.
3. Turn on the projector or monitor.
4. Turn on the document camera.
AC IN
POWER
ON
OFF
power switch
RS-232C
RGB OUT
RGB IN
VIDEO
OUT
USB
0
1
B
C
A
After a few moments, the upper lamps turn on.
5. Place your presentation material on the stage. You should see an
image on screen.
18
Using the Document Camera
Once you see your image, turn to page 22 for instructions on making
adjustments.
If your image doesn’t appear, see the next section for help.
When you’re done with your presentation, turn off the document
camera as described on page 27.
What To Do If You See a Blank Screen
If an image doesn’t appear, try the following:
■
Make sure the cables are connected correctly, as described on
page 11 for a projector or monitor or page 13 for a computer.
■
Make sure everything is turned on.
■
Make sure the lighting unit lamps are on.
■
If you are using a video source, such as a laptop or desktop
computer, you may need to switch video sources. Press the
button as shown on page 20.
■
If an image still doesn’t appear, refer to Chapter 4 for more help.
RGB1
note
If you turn off the document
camera, always wait a few
seconds before turning it
back on.
Using the Document Camera
19
Switching Between Picture Sources
If you have an external video source connected to the document
camera, such as a laptop or desktop computer, you can switch between
the video source and the camera. Press the
remote control to switch the video source. Press the
switch back to the camera.
Main RGB1
RGB1
button on the
Main
button to
20
Using the Document Camera
Adjusting the Lighting
If you are presenting printed material or 3-D objects, the two upper
lamps provide ample light. If the ambient lighting in the room is
sufficient, however, you may obtain a better image with the upper
lamps off.
Press the
one at a time from right to left (when facing the unit’s control panel).
Press it a third time to turn the lamps back on. There will be a slight
delay before the lamps turn back on.
Lamp
button on the remote control to turn off the lamps
Turn upper lamps
off or on
Using the Document Camera
21
Adjusting the Image
Once you see your image, you may need to make certain adjustments:
■
To zoom or focus your image, see the next section.
■
If the image is too light or dark, see page 23.
■
If the image has a color cast, see page 23.
Zooming and Focusing Your Image
note
The auto focus function
works up to a height of
approximately 5.9 in.
(15 cm) above the stage
surface
.
Remote Control
Use the
the image, and use the
Tele
button on the control panel or remote control to enlarge
Wide
button to reduce it. The document
camera will automatically focus the image.
Your document camera is equipped with a double speed zoom feature.
Press
Tele
or
Wide
briefly to zoom at normal speed. Press and hold in
either button to zoom at a higher rate of speed.
If you change items on the stage, press the
Auto Focus
button to
focus the image. The indicator light flashes until the image is focused.
The following objects may not focus well using the auto focus feature:
■
Objects with little contrast
■
Objects with a bright background or excessive contrast
■
Objects with fine repeated patterns or stripes
■
Objects that glitter or reflect bright light
■
Objects with varying depths of field
To manually focus these objects, use the
Near
or
Far
button on the
remote control.
Control Panel
Far
ReduceEnlarge
Enlarge Reduce Near
22
Using the Document Camera
Auto
Focus
Auto Focus
Adjusting the Brightness
The document camera is initially set to auto iris. You can manually
adjust the iris to control the amount of light that reaches the camera.
Open
If the screen looks dark, press the
button on the remote control
to open the iris so that more light reaches the camera. If the screen
looks too bright, press the
default setting, press the
Close
button. To return to the auto iris
Auto Iris
button.
Adjusting the White Balance
In different lighting conditions it may be necessary to adjust the
document camera’s white balance. This setting automatically corrects
for color shifts in different lighting environments.
Remote control
direction
buttons
correct
color cast
If the displayed image has a color cast, press the
AWB
button on the
remote control to automatically adjust the white balance. See page 24
for manual white balance adjustments using the document camera’s
on-screen display.
Using the Pointer
The pointer lets you direct attention to specific sections of your
presentation material. You can choose from two types of pointers in
four colors.
To make the pointer appear on the screen, press the
on the remote control. When the mouse is connected to the document
camera, pressing the left mouse button will also display the cursor.
To move the pointer, use the direction buttons on the remote control.
The mouse also allows you to move the pointer as you would on a
computer.
To remove the pointer from the screen, press the
the remote control or click the left mouse button three times (this
brings up an on-screen display before the pointer is removed).
For information on selecting different types of pointers, see page 24.
Pointer
Pointer
button
button on
increase
brightness
reduce
brightness
note
The pointer feature only
works when the document
camera is in the Main
display mode. It does not
work then the document
camera is in the RGB1
display mode.
Using the Document Camera
23
note
The pause feature only works
when the document camera is
in the Main display mode. It
does not work then the
document camera is in the
RGB1 display mode.
Pausing the Main Display
During a presentation, it may be necessary to change the material you
are displaying. Press the
Pause
button before switching your material.
This freezes the image on screen, allowing you to change your
material. When you are ready to display the next item, press the
Pause
button again.
Adjusting Settings with the On-Screen Display
The on-screen display allows access to many of the settings available
with the document camera’s remote control. To access the on-screen
display, you must have the mouse connected to the document
camera’s
Camera” on page 14). When the left mouse button is clicked, the
on-screen display and the pointer appears. The table below lists the
various functions and their descriptions.
RS-232C
port (See “Connecting a Mouse to the Document
Icon Name Function
Lighting Unit
On/Off
Color/B&W Switches the display from Color to B&W (black and white).
Pause
On/Off
24
Using the Document Camera
Turns off the lamps individually. Click once to turn off the right
lamp. Click a second time to turn off the left lamp. Click a third
time to turn on both lamps (this may take a few seconds).
Switches the screen from Live to Still.
Icon Name Function
Auto Focus Automatically brings objects on the stage into focus.
Zoom
Tele/Wide
Focus
Near/Far
Iris
Open/Close
Pointer Changes the shape and color of the on-screen pointer.
White balance
Automatic
White balance
Manual
Aperture
selection
On/Off
Zooms in or out.
Manually focuses objects that do not work with the auto focus
feature.
Increases or reduces image brightness.
Automatically adjusts the white balance and corrects color casts.
Enables manual white balance adjustment. Click the arrows below
to adjust the colors individually to compensate for color casts.
Turns image enhancement (contour) on and off. This setting is on
by default.
Gamma
selection
Save settings Saves change made to the document camera.
Restore
defaults
Changes the gamma setting from 1.0 to 0.6. The default gamma
setting is 1.0.
Restores settings to factory defaults.
Using the Document Camera
25
note
The camera’s shutter operates
at 15 frames per second.
Using the Camera Head as a Conventional Video Camera
By rotating the camera head to a horizontal position, you can use the
document camera as a conventional video camera. To view walls or
distant objects, flip down the close-up lens. The document camera can
resolve images from 3.6 feet (1.1 m) to infinity.
camera head in
horizontal position
close-up
lens
26
Using the Document Camera
Using the Image Mate Software
The Image Mate software allows you to transfer images from the
document camera to the PC. You can also use the virtual remote
control feature to control the document camera and change its
settings. For more information on installing and using the Image
Mate software, see the manual.pdf file in the US folder on the Image
Mate CD-ROM. To view the PDF file, you will need to have Adobe
Acrobat
installed, run ar500enu.exe in the Acrobat US folder on the
CD-ROM.
®
Reader® installed on your computer. If it’s not already
®
Turning Off and Storing the Document Camera
When you’ve finished using the document camera, follow these steps
to turn off and store it. If you’re using a monitor or projector, shut it
down last.
1. Turn off the document camera.
2. Unplug the power cord and disconnect any attached video cables.
3. If the close-up lens is flipped down, close it.
4. Place the remote control inside the remote control storage
compartment and close the tray.
remote control
Using the Document Camera
27
caution
Be careful not to let the
camera arm drop, or you may
damage it.
5. Turn the lighting units toward the lighting arms until they stop;
then tilt the lighting arms toward the stage (inward).
lighting unit
lighting arm
lighting unit
lighting arm
stage
6. Rotate the lighting units backward, as shown, until they stop.
28
Using the Document Camera
7. Lower the right lighting arm and rotate the camera head to its
original position.
8. Raise the camera arm until you hear a click, then lower
until it stops.
s
the arm
Using the Document Camera
29
30
Using the Document Camera
3
warning
Before you clean any part of
the document camera, turn it
off and unplug the power
cord. Never open any cover
on the document camera.
Dangerous electrical voltages
in the document camera can
injure you severely. Don’t try
to service this product
yourself. Refer all servicing to
qualified service personnel.
Maintaining and
Transporting the
Document Camera
Y
our document camera needs little maintenance. All you need to do
on a regular basis is keep the lenses and stage clean. Any dirt or smears
on the lenses or stage may show up on your presented image.
You should not replace the lamps or any other parts. If any part needs
replacing, contact your dealer or a qualified servicer.
This chapter covers the following:
■
Cleaning the lenses
■
Cleaning the document camera case
■
Transporting the document camera
Maintaining and Transporting the Document Camera
31
Cleaning the Lenses
Clean the lenses whenever you notice dirt or dust on the surface.
■
Use a canister of compressed air to remove dust.
■
To remove dirt or smears on the lenses, use lens-cleaning paper. If
necessary, moisten a soft cloth with lens cleaner and gently wipe
the lens surface.
■
Clean both sides of the close-up lens.
main lens
close-up lens
32
Maintaining and Transporting the Document Camera
Cleaning the Document Camera Case
Before you clean the case, first turn off the document camera and
unplug the power cord.
■
To remove dirt or dust, wipe the case with a soft, dry, lint-free
cloth.
■
To remove stubborn dirt or stains, moisten a soft cloth with water
and a neutral detergent. Then wipe the case.
■
Do not use wax, alcohol, benzene, thinner, or other chemical
detergents. These can damage the case.
■
Take special care when cleaning the stage, or you may scratch it.
Scratches on the stage may appear on your image.
stage
Maintaining and Transporting the Document Camera
33
Transporting the Document Camera
f
note
EPSON shall not be liable
or any damages incurred
during transportation.
The document camera contains many glass and precision parts. If you
need to transport it, follow these guidelines to prevent damage to the
document camera:
■
Make sure to turn off and fold the document camera as described
on page 27.
■
When shipping the document camera for repairs, use the original
packaging material if possible. If you do not have the original
packaging, use equivalent materials, placing plenty of cushioning
around the document camera.
■
When transporting the document camera a long distance, pack it
in a firm box, using cushioning around the document camera.
■
When you are hand-carrying the document camera, be sure to use
the carrying handle.
■
When transporting the document camera, you may leave the
remote control inside the remote control storage compartment.
remote control
storage
compartment
carrying handle
34
Maintaining and Transporting the Document Camera
Solving Problems
4
T
his chapter helps you solve problems with your document camera,
and tells you how to contact technical support for problems you can’t
solve yourself. This chapter explains the following:
■
Solving problems with the image
■
Solving problems with the remote control
■
Contacting technical support
Solving Problems
35
Solving Problems with the Image
No image appears on the screen.
■
Check that all cables are properly connected (see Chapter 1) and
everything is turned on.
■
Make sure the projector or computer is not in sleep mode. Check
the projector documentation, or try pressing a key on the
computer keyboard.
■
The document camera may have been turned on too quickly after
it was turned off. Turn the document camera off, wait a few
seconds, and then turn it on again.
■
The wrong source may be selected. Try pressing the
RGB1
button on the remote control.
■
You may need to change the NTSC or PAL DIP switch setting on
Main or
the document camera. See page 15 for instructions.
The image contains static or noise.
■
If you’re using cables that are longer than 6 feet (2 m), or an
extension cable, the image quality may be reduced. Try using the
cables supplied with the document camera.
■
Keep your projector, computer, and video cables away from the
power cord as much as possible to prevent interference.
■
The camera’s DIP switches may be set incorrectly. Try adjusting
the switches as described on page 15.
The image is blurry.
■
There may be dirt on the lenses. Clean the lenses as described on
page 32.
■
Try pressing the
Auto Focus
button.
36
Solving Problems
■
Some objects do not auto focus well (see page 22). Manually focus
these objects using the
Near
and
Far
buttons.
■
The presentation material may be too close to the lens. Make sure
the close-up lens is closed.
■
The presentation material may be too far from the lens. Open the
lens by flipping it down.
■
Make sure there is no condensation on the lenses. You may need
to wait before using the document camera after moving it from a
cold environment to a warm environment.
Solving Problems with the Remote Control
■
Make sure you are within 23 feet (7 m) of the document camera,
and within range of the document camera’s front or back sensor
(approximately 30° to the left or right and 15° above or below).
■
The remote control batteries may not be installed correctly or may
be low on power. Try changing the batteries as described on
page 7.
■
Dim the room lights and turn off any fluorescent lighting. Make
sure the document camera is not in direct sunlight. Strong
lighting, especially fluorescent lights, may affect the document
camera’s infrared receivers.
■
Turn off any nearby equipment that emits infrared energy, such
as a radiant room heater.
Solving Problems
37
Where to Get Help
EPSON provides technical assistance through electronic support
services 24 hours a day, as listed in the following table:
Service Access
World Wide Web From the internet, you can reach EPSON’s product support at
http://support.epson.com. After selecting your product, you can access
troubleshooting information, download product documentation, and receive
technical advice through e-mail.
Presenters Online Access tips, templates, and training for developing successful presentations at
http://www.presentersonline.com.
Telephone Support Services
To use the EPSON PrivateLine Support service, call (800) 637-7661
and enter the PIN on the EPSON PrivateLine Support card included
with your document camera. This is the fastest way of speaking to a
live representative, and it’s free. This service is available 6
Pacific Time, Monday through Friday, for the duration of your
warranty period.
You may also speak with an EPSON document camera support
specialist by dialing one of these numbers:
to 6PM,
AM
38
Solving Problems
■
U.S.: (562) 276-4394, 6AM to 6PM, Pacific Time, Monday
through Friday
■
Canada: (905) 709-3839, 6AM to 6PM, Pacific Time, Monday
through Friday
Toll or long distance charges may apply.
Before you call, please have the following information ready:
■
Product name (EPSON ELPDC04 High Resolution Document
Camera)
■
Product serial number (located on the rear panel of the document
camera)
■
Computer configuration, if applicable
■
Description of the problem
Technical Specifications
5
General
CCD 1/3 inch (848,676 progressive square pixels)
Resolution 1024 × 768 pixels
Lens F=2.8, f=5.8 to 58 mm
Frame speed 15 frames per second
Shooting area 13.4 × 9.9 in. (340 × 252 mm) max.
Limit of focus
adjustment 5.9 in. (150 mm) from the stage surface
Zoom 10× optical with double speed function
Focus Automatic/manual
Iris Automatic/manual
1.5 × 1.1 in. (38 × 28 mm) min.
using the close-up lens
1.6 feet (.5 m) to infinity with the camera
positioned horizontally and without using
the close-up lens
White balance Automatic/manual
Gamma selection ON (
Frequency selection 50 or 60 Hz
Video output NTSC or PAL
Lighting
Lamps High frequency fluorescent, 9 W × 2
γ
=0.6), OFF (γ=1.0)
Technical Specifications
39
Remote Control
Range 23 feet (7 m)
Batteries Alkaline AAA (2)
Dimensions
Weight 14.3 lb (6.5 kg)
Folded (h × w × d) 3.9 × 19.7 × 24.1 in.
(99 × 500 × 612 mm)
Unfolded (h × w × d) 22.6 × 27.8 × 15.9 in.
(575 × 706 × 403 mm)
Electrical
Rated frequency 50/60 Hz
Power supply 100 to 120 VAC
Power consumption 100 to 120 VAC: 55 W
Environmental
40
Technical Specifications
Temperature Operating: 41 to 104 °F (5 to 40 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Humidity Operating: 30 to 85% RH,
non-condensing
Storage: 20 to 90% RH,
non-condensing
Safety
United States FCC 47CFR Part 15B Class B (DoC)
UL1950 3rd Edition
Canada ICES-003
CSA C22.2 No.950-95 (cUL)
Compatible Video Formats
The document camera supports NTSC and PAL video standards, as
well as the monitor display formats listed below.
Mode Refresh Rate (Hz) Resolution
VGA1 85.08 640 × 350
VGA2 85.08 640 × 400
VGA3 85.039 720 × 400
VGA—60 59.94 640 × 480
VGA—72 72.809 640 × 480
VGA—75 75 640 × 480
VGA—85 85.008 640 × 480
SVGA—56 56.25 800 × 600
SVGA—60 60.317 800 × 600
SVGA—72 72.188 800 × 600
SVGA—75 75 800 × 600
SVGA—85 85.061 800 × 600
XGA—60 60.004 1024 × 768
XGA—70 70.069 1024 × 768
XGA—75 75.029 1024 × 768
XGA—85 84.997 1024 × 768
SXGA1 75 1152 × 864
SXGA2 60 1280 × 960
SXGA3 85.002 1280 × 960
SXGA—60 60.02 1280 ×
1024
Technical Specifications
41
Mode Refresh Rate (Hz) Resolution
SXGA—75 75.025 1280 × 1024
SXGA—85 85.024 1280 × 1024
UXGA—60 60 1600 × 1200
UXGA—65 65 1600 × 1200
UXGA—70 70 1600 × 1200
UXGA—75 75 1600 × 1200
UXGA—85 85 1600 × 1200
MAC 13 66.667 640 × 480
MAC 16 74.55 832 × 624
MAC 19 74.927 1024 × 768
MAC 21 75.062 1152 × 870
PC98 56.42 640 × 400
42
Technical Specifications
Notices
6
T
his chapter includes safety instructions and other important information
about your EPSON document camera.
Important Safety Instructions
Follow these safety instructions when setting up and using the document
camera:
■
Read Instructions – All the safety and operating instructions should be
read before the appliance is operated.
■
Retain Instructions – The safety and operating instructions should be
retained for future reference.
■
Heed Warnings – All warnings on the product appliance and in the
operating instructions should be adhered to.
■
Follow Instructions – All operating and use instructions should be
followed.
■
Cleaning – Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
■
Attachments – Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
■
Water and Moisture – Do not use this product near water—for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool, and the like.
■
Accessories – Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a child or adult, and serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or
sold with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
Notices
43
■
Ventilation – Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to protect
it from overheating, and these openings must not be blocked or covered.
The openings should never be blocked by placing the product on a bed,
sofa, rug, or other similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation
is provided or the manufacturer’s instructions have been adhered to.
■
Place the document camera near a wall outlet where the plug can be
easily unplugged.
Placez l’appareil près d’une prise de courant où la fiche peut être débranchée
facilement.
■
Power Sources – This product should be operated only from the type of
power source indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your appliance dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
■
Grounding or Polarization – This product may be equipped with either
a polarized 2-wire AC line plug (a plug having one blade wider than the
other) or a 3-wire grounding type plug (a plug having a third grounding
pin). The 2-wire polarized plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug still fails to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug. The 3-wire grounding type plug will fit
into a grounding type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the
grounding type plug.
■
Power-Cord Protection – Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
■
Lightning – For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning and
power-line surges.
■
Overloading – Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric
shock.
44
Notices
■
A product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the product and
cart combination to overturn.
■
Object and Liquid Entry – Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.
■
Servicing – Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
■
Damage Requiring Service – Unplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
■
When the power-supply cord or plug is damaged.
■
If liquid has been spilled, or objects have fallen into the product.
■
If the product has been exposed to rain or water.
■
If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls
may result in damage and will often require extensive work by a
qualified technician to restore the product to its normal operation.
■
If the product has been dropped or damaged in any way.
■
When the product exhibits a distinct change in performance—this
indicates a need for service.
■
Replacement Parts – When replacement parts are required, be sure the
service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other
hazards.
■
Safety Check – Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to determine
that the product is in proper operating condition.
■
Heat – The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products (including amplifiers)
that produce heat.
Notices
45
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
THIS IS A CLASS B PRODUCT. IN A DOMESTIC
ENVIRONMENT THIS PRODUCT MAY CAUSE
RADIO INTERFERENCE IN WHICH CASE THE USER
MAY BE REQUIRED TO TAKE ADEQUATE
MEASURES.
Remote Control Information
You can operate the document camera by remote control via a line-of-sight
infrared (IR) receiver at the front and rear of the document camera. The
document camera may not respond to remote control commands under the
following conditions:
■
There is an object between the remote control IR emitter and the IR
receiver on the document camera.
■
Ambient light is too bright.
■
Certain types of fluorescent lighting are used.
■
A strong light source shines into the IR receiver.
■
Other equipment that emits infrared energy, such as a radiant room
heater, is in the room.
46
Notices
These conditions commonly cause problems for most infrared-controlled
equipment. Try the following:
■
The remote control batteries may be low on power; replace them.
■
Dim the ambient lighting and/or turn off any fluorescent lights.
■
Close any window coverings and/or move the document camera out of
direct sunlight.
■
Turn off other equipment that emits infrared energy.
If the remote control still does not work properly, you can always use the
buttons located on the document camera control panel, even in an
environment containing one of the conditions listed above.
Declaration of Conformity
According to 47CFR, Part 2 and 15 Class B Personal Computers and
Peripherals; and/or CPU Boards and Power Supplies used with Class B
Personal Computers
We: EPSON AMERICA, INC.
Located at: 3840 Kilroy Airport Way
MS: 3-13
Long Beach, CA 90806-2469
Telephone: (562) 290-5254
Declare under sole responsibility that the product identified herein, complies
with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each
product marketed, is identical to the representative unit tested and found to
be compliant with the standards. Records maintained continue to reflect the
equipment being produced can be expected to be within the variation
accepted, due to quantity production and testing on a statistical basis as
required by 47CFR §2.909. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
Trade Name: EPSON
Type of Product: Image Presentation Camera
Model: ELPDC04
Notices
47
FCC Compliance Statement
For United States Users
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio and television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
■
Reorient or relocate the receiving antenna.
■
Increase the separation between the equipment and receiver.
■
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
■
Consult the dealer or an experienced radio/TV technician for help.
WARNING
The connection of a non-shielded equipment interface cable to this
equipment will invalidate the FCC Certification of this device and may cause
interference levels which exceed the limits established by the FCC for this
equipment. It is the responsibility of the user to obtain and use a shielded
equipment interface cable with this device. If this equipment has more than
one interface connector, do not leave cables connected to unused interfaces.
Changes or modifications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
48
For Canadian Users
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement
sur le materiel brouilleur du Canada.
Notices
Warranty
Epson America, Inc. Limited Warranty
What Is Covered
customer of the EPSON product enclosed with this limited warranty
statement that the product, if purchased and used in the United States or
Canada, conforms to the manufacturer’s specifications and will be free from
defects in workmanship and materials for a period of two (2) years from the
date of original purchase (except that the warranty period is 90 days for
lamps). For warranty service, you must provide proof of the date of original
purchase.
What Epson Will Do To Correct Problems
prove defective during the warranty period, please bring the product securely
packaged in its original container or an equivalent, along with proof of the
date of original purchase, to your EPSON Dealer or EPSON Customer Care
Center. Epson will, at its option, repair or replace on an exchange basis the
defective unit, without charge for parts or labor. When warranty service
involves the exchange of the product or of a part, the item replaced becomes
EPSON property. The exchanged product or part may be new or previously
repaired to the EPSON standard of quality. Exchange or replacement
products or parts assume the remaining warranty period of the product
covered by this limited warranty. However, each replacement lamp carries
the limited 90-day warranty stated above.
What This Warranty Does Not Cover
the United States and Canada. For lamps, 24-hour-per-day use causes
unusual strain and is not considered normal use. This warranty is not
transferable and will not apply to products purchased from an end user. This
warranty does not cover consumables (e.g., fuses), other than lamps. EPSON
is not responsible for warranty service should the EPSON label or logo or the
rating label or serial number be removed or should the product fail to be
properly maintained or fail to function properly as a result of misuse, abuse,
improper installation, neglect, improper shipping, damage caused by disasters
such as fire, flood, and lightning, improper electrical current, software
problems, interaction with non-EPSON products, or service other than by an
EPSON Authorized Servicer. Postage, insurance, or shipping costs incurred
in presenting your EPSON product for carry-in warranty service are your
responsibility. If a claimed defect cannot be identified or reproduced in
service, you will be held responsible for costs incurred.
: Epson America, Inc. (“Epson”) warrants to the first end user
: Should your EPSON product
: This warranty covers only normal use in
THE WARRANTY AND REMEDY PROVIDED ABOVE ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS OR IMPLIED
WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
Notices
49
FOR A PARTICULAR PURPOSE. SOME LAWS DO NOT ALLOW
SM
THE EXCLUSION OF IMPLIED WARRANTIES. IF THESE LAWS
APPLY, THEN ALL EXPRESS AND IMPLIED WARRANTIES ARE
LIMITED TO THE WARRANTY PERIOD IDENTIFIED ABOVE.
UNLESS STATED HEREIN, ANY STATEMENTS OR
REPRESENTATIONS MADE BY ANY OTHER PERSON OR FIRM
ARE VOID. EXCEPT AS PROVIDED IN THIS WRITTEN
WARRANTY, NEITHER EPSON AMERICA, INC. NOR ITS
AFFILIATES SHALL BE LIABLE FOR ANY LOSS, INCONVENIENCE,
OR DAMAGE, INCLUDING DIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, RESULTING FROM THE USE OR
INABILITY TO USE THE EPSON PRODUCT, WHETHER
RESULTING FROM BREACH OF WARRANTY OR ANY OTHER
LEGAL THEORY. IF THE REMEDY ABOVE FAILS, EPSON’S
ENTIRE LIABILITY SHALL BE LIMITED TO A REFUND OF THE
PRICE PAID FOR THE EPSON PRODUCT COVERED BY THIS
LIMITED WARRANTY.
In Canada, warranties include both warranties and conditions.
Some jurisdictions do not allow limitations on how long an implied warranty
lasts and some jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitations and exclusions
may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights which vary from jurisdiction to jurisdiction.
To locate an Authorized EPSON Servicer nearest you, call the EPSON
Connection at (562) 276-4394 in the U.S. and (905) 709-3839 in Canada
or write to: Epson America, Inc., P. O. Box 93012, MS: 6-33, Long Beach,
CA 90809-3012.
50
Notices
Index
Numerics
3-D objects, presenting, 21
A
Adjusting settings, 24 to 25
Auto Focus button, 22
Auto Iris button, 23
B
Batteries, installing, 7
Blank screen, 19
Blurry image, 36 to 37
Brightness, adjusting, 23
Buttons
focus, 22
iris, 23
lamp, 21
main, 20
pause, 24
RGB1, 20
zoom, 22
C
Cables, 6, 36
Cleaning, 31 to 33
Close button, 23
Close-up lens, 26, 32
Computer, connecting to, 13
Connecting document camera
to a computer, 13
to a monitor, 11 to 12
to a mouse, 14
to a projector, 11 to 12
Control codes, 15
D
Declaration of Conformity, 47
DIP switches, adjusting, 15
Document camera
cleaning, 31 to 33
connecting, 11 to 14
folding, 27 to 29
positioning, 8
specifications, 39 to 42
storing, 27 to 29
transporting, 34
turning off, 27
turning on, 18 to 19
unfolding, 9 to 10
E
Electrical specifications, 40
Enlarging, image, 22
Environmental specifications, 40
EPSON technical support, 3, 38
F
Far button, 22
FCC compliance statement, 48
Focusing image, 22
Folding document camera, 27 to 29
Frame speed, 26, 39
G
Gamma, 39
H
Help, 3, 38
Index
51
I
brightness, 23
focusing, 22
resolution, 39
shooting area, 39
shooting speed, 26, 39
sources, selecting, 20
troubleshooting, 19, 36 to 37
white balance, 23, 25
zooming, 22
Image Mate Software, 26
Iris, adjusting, 23
L
Lamp
selecting, 21
specifications, 39
Lens
cleaning, 31 to 32
specifications, 39
Lighting, adjusting, 21
M
Main button, 20
Monitor, connecting, 11 to 12
Mouse, connecting, 14
N
Near button, 22
O
On-screen display, adjusting settings, 24 to 25
Open button, 23
P
Picture, see Image
Pointer, using, 23
Positioning, document camera, 8
Power
specifications, 40
switch, 18
PrivateLine Support, 3, 38
Problems
blank screen, 19
image, 36 to 37
remote control, 37, 46
Projector, connecting, 11 to 12
R
Reducing, image, 22
Registration, 3
Remote control
batteries, 7
specifications, 40
storing, 34
troubleshooting, 37, 46
Resolution, 39
RGB1 button, 20
S
Safety
instructions, 43 to 45
specifications, 41
Screen image, see Image
Service, see Technical support
Shooting speed, 26, 39
Software, 26
Specifications
dimensions, 40
electrical, 40
environmental, 40
general, 39
lamp, 39
lens, 39
remote control, 40
safety, 41
video formats, 41 to 42
Support, see Technical support
T
Technical support, 3, 38
Tele button, 22
Television, connecting, 11 to 12
Temperature requirements, 40
52
Index
Transporting, 34
Troubleshooting
image, 19, 36 to 37
remote control, 37, 46
Turning off document camera, 27
Turning on document camera, 18 to 19
U
Unfolding, document camera, 9 to 10
Unpacking, document camera, 6
V
Video camera, using camera as, 26
Video formats supported, 41 to 42
W
Warranty, 49 to 50
White balance, adjusting, 23, 25
Wide button, 22
Z
Zooming image, 22
Index
53
Loading...
