Epson EB-X20, EB-W22, EB-S17 User Manual

User’s Guide

Notations Used in This Guide

• Safety indications

The documentation and the projector use graphical symbols to show how to use the projector safely. Please understand and respect these caution symbols in order to avoid injury to persons or property.

Warning

Caution

• General information indications

Attention

s Indicates a page where detailed information regarding a topic can be found.

[Name] Indicates the name of the buttons on the remote control or the control panel.

Menu Name Indicates Configuration menu items.

This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to incorrect handling.

This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.

Indicates procedures which may result in damage or injury if sufficient care is not taken.

Indicates additional information and points which may be useful to know regarding a topic.

Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary" section of the "Appendix".

s "Glossary" p.140

Example: [Esc] button

Example: Select Brightness from Image. Image - Brightness

Notations Used in This Guide ........................ 2

Introduction

Projector Features .......................................... 8

Quick and Easy Set up, Projection, and Storage.......................... 8

Connecting with a USB cable and projecting (USB Display)................8

Detecting projector movements and automatically correcting image distortion

.........................................................8

Horizontal keystone adjuster....................................8

Useful Functions for Projecting Images................................ 8

Increasing projection content in wide (WXGA) screen (EB-W22 only) .......... 8

Connect a USB storage device and project movies or images (PC Free) . . . . . . . . 9

Various functions for excellent power saving ..........................9

Making the most of the remote control.............................9

Enlarge and project your files with the Document Camera .................9

Enhanced security functions ..................................... 9

Taking Full Advantage of a Network Connection .........................9

Connecting to a network and projecting images from the computer's screen

........................................................ 10

Easy connection to a computer with Quick Wireless Connection (Windows only)

........................................................ 10

Projecting images from portable devices over a network.................10

Projecting images from multiple computers simultaneously (EB-X25/EB-W22/EB-

X22/EB-X20 only) ............................................10

Part Names and Functions .................................. 11

Front/Top...................................................11

Rear.......................................................13

Base...................................................... 14

Control Panel................................................15

Remote Control...............................................16

Replacing the remote control batteries .............................19

Remote control operating range................................. 20

Preparing the Projector

Installing the Projector ..................................... 22

Installation Methods...........................................22

Installation methods.........................................23

Screen Size and Approximate Projection Distance.......................23

Connecting Equipment ..................................... 25

Connecting a Computer ......................................... 25

Connecting Image Sources .......................................26

Connecting USB Devices .........................................27

Connecting External Equipment ...................................28

Connecting a LAN Cable .........................................30

Installing the Wireless LAN Unit.................................... 31

Installing the Quick Wireless Connection USB Key ......................32

Basic Usage

Projecting Images ......................................... 34

From Installation to Projection.....................................34

Automatically Detect Input Signals and Change the Projected Image (Source Search)

.......................................................... 35

Switching to the Target Image by Remote Control.......................36

Projecting with USB Display......................................36

System requirements ......................................... 36

Connecting for the first time....................................37

Uninstalling...............................................39

Adjusting Projected Images ................................ 40

Correcting Keystone Distortion ....................................40

Correcting automatically......................................41

Correcting manually.........................................41

Adjusting the Image Size........................................ 44

Adjusting the Image Position .....................................45

Adjusting the Horizontal Tilt ...................................... 45

Correcting the Focus ........................................... 45

Adjusting the Volume..........................................46

Contents

Selecting the Projection Quality (Selecting Color Mode)...................46

Setting Auto Iris .............................................. 47

Changing the Aspect Ratio of the Projected Image ....................... 47

Changing methods ..........................................48

Changing the aspect mode..................................... 48

Useful Functions

Projection Functions ....................................... 52

Projecting Without a Computer (PC Free)............................. 52

Specifications for files that can be projected using PC Free...............52

PC Free examples........................................... 52

PC Free operating methods .....................................53

Projecting the selected image ...................................55

Projecting image files in a folder in sequence (Slideshow)................56

Image file display settings and Slideshow operation settings..............57

Hiding the Image and Sound Temporarily (A/V Mute) .....................57

Freezing the Image (Freeze)......................................58

Pointer Function (Pointer)........................................58

Enlarging Part of the Image (E-Zoom)................................ 59

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse) . . . . . . 60

Saving a User's Logo ...........................................61

Saving User Pattern ............................................63

Security Functions ......................................... 65

Managing Users (Password Protect) .................................65

Kinds of Password Protect ......................................65

Setting Password Protect ...................................... 65

Entering the Password........................................66

Restricting Operation (Control Panel Lock)............................ 67

Anti-Theft Lock............................................... 69

Installing the wire lock........................................69

Monitoring and Controlling ................................ 70

EasyMP Monitor ..............................................70

Changing Settings Using a Web Browser (Web Control).................... 70

Projector setup............................................. 70

Displaying the Web Control screen...............................70

Displaying the Web Remote screen...............................71

Using the Mail Notification Function to Report Problems................... 72

Reading Error Notification Mail..................................72

Management Using SNMP.......................................73

ESC/VP21 Commands........................................... 73

Command list.............................................. 73

Cable layouts.............................................. 74

About PJLink (EB-X25/EB-W22/EB-X22/EB-X20 Only) ......................75

About Crestron RoomView

Operating a projector from your computer ..........................76

(EB-X25/EB-W22/EB-X22/EB-X20 only) ...........75

About Event ID ............................................ 80

Configuration Menu

Using the Configuration Menu .............................. 82

List of Functions ........................................... 83

Configuration Menu Table.......................................83

Network menu ............................................. 84

Image Menu................................................. 85

Signal Menu ................................................. 86

Settings Menu ................................................88

Extended Menu ...............................................89

Network Menu ...............................................91

Notes on operating the Network menu............................. 91

Soft keyboard operations ......................................92

Basic menu................................................93

Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only) . . . . . . . . . . . . . . . . 93

Security menu (EB-X21/EB-S21/EB-X17/EB-S17 only) ....................95

Wired LAN menu (EB-X25/EB-W22/EB-X22/EB-X20 only).................96

Mail menu................................................97

Others menu ..............................................98

Reset menu ...............................................99

ECO Menu .................................................. 99

Info Menu (Display Only)........................................100

Contents

Reset Menu.................................................101

Troubleshooting

Using the Help ........................................... 103

Problem Solving .......................................... 104

Reading the Indicators ......................................... 104

When the Indicators Provide No Help............................... 108

Problems Relating to Images.....................................109

No images appear.......................................... 109

Moving images are not displayed ................................ 110

Projection stops automatically.................................. 110

The message Not supported is displayed...........................110

The message No Signal is displayed .............................. 111

Images are fuzzy, out of focus, or distorted ......................... 111

Interference or distortion appear in images......................... 112

The image is truncated (large) or small, the aspect is not suitable, or the image has

been reversed ............................................. 113

Image colors are not right .....................................113

Images appear dark......................................... 114

Problems when Projection Starts.................................. 115

The projector does not turn on................................. 115

Other Problems .............................................. 115

No sound can be heard or the sound is faint........................ 115

There is noise in the audio (when projecting EasyMP Network Projection, EasyMP

MultiPC Projection, USB Display, or Quick Wireless Connection)........... 116

The remote control does not work ............................... 116

I want to change the language for messages and menus................ 117

Mail is not received even if a problem occurs in the projector............. 117

Cannot change settings using a Web browser....................... 117

Maintenance

Cleaning the Lens ............................................ 119

Cleaning the Air Filter .......................................... 119

Replacing Consumables ................................... 121

Replacing the Lamp........................................... 121

Lamp replacement period.....................................121

How to replace the lamp ......................................121

Resetting the lamp hours..................................... 124

Replacing the Air Filter......................................... 124

Air filter replacement period................................... 124

How to replace the air filter.................................... 124

Appendix

Optional Accessories and Consumables .................... 127

Optional Accessories .......................................... 127

Consumables............................................... 127

Screen Size and Projection Distance ........................ 128

Projection Distance (For EB-X25).................................. 128

Projection Distance (For EB-X22/EB-X21/EB-X20/EB-X17).................. 129

Projection Distance (For EB-W22).................................. 130

Projection Distance (For EB-S21/EB-S17)............................. 131

Supported Monitor Displays ............................... 133

Supported Resolutions ......................................... 133

Computer signals (analog RGB) ................................. 133

Component video.......................................... 133

Composite video........................................... 134

Input signal from the HDMI port ................................ 134

Specifications ............................................ 135

Projector General Specifications ...................................135

Cleaning ................................................. 119

Cleaning the Projector's Surface ...................................119

Contents

Appearance .............................................. 139

Glossary ................................................. 140

General Notes ............................................ 142

About Notations............................................. 142

General Notice:.............................................. 143

Index .................................................... 144

Introduction

This chapter explains the projector's features and the part names.

Projector Features

Quick and Easy Set up, Projection, and Storage

• Turn the projector on and off by simply plugging in or unplugging.

• Project onto large screens from a short distance.

• Make easy height adjustments with one lever.

• No cool down delay makes it easy to put away.

Connecting with a USB cable and projecting (USB Display)

By simply connecting a USB cable, you can project images from a computer's screen without a computer cable.

s "Projecting with USB Display" p.36

Detecting projector movements and automatically correcting image distortion

This projector automatically corrects vertical keystone distortion which occurs when positioning or moving the projector.

"Correcting automatically" p.41

Horizontal keystone adjuster

This allows you to quickly correct horizontal distortion in the projected image. This is useful if you cannot install the projector parallel to the screen.

"Correcting manually" p.41

Useful Functions for Projecting Images

Increasing projection content in wide (WXGA) screen (EB-W22 only)

With a computer that has a 16:10 WXGA wide LCD display, the image can be projected in the same aspect. You can use whiteboards and other landscape format screens.

s "Changing the Aspect Ratio of the Projected Image" p.47

Projector Features

Connect a USB storage device and project movies or images (PC Free)

Only EB-X21/EB-S21/EB-X17/EB-S17 are supported.

You can connect USB storage devices or digital cameras to the projector and project saved images.

A wide range of file formats are supported such as movies or images.

"Projecting Without a Computer (PC Free)" p.52

Various functions for excellent power saving

• Various functions to prevent wasting electricity The projector comes with a number of built-in functions to save power such as dimming the projected image, an auto power off timer, and adjusting power consumption while the projector is standing by.

"ECO Menu" p.99

• Function for displaying the power-saving status on the projected screen When ECO Display is set to On from the Configuration menu, leaf icons (

) that indicate the power-saving status are displayed at the bottom-

left of the projected screen when the lamp brightness has switched to low brightness.

ECO - ECO Display p.99

Enlarge and project your files with the Document Camera

You can project paper documents and objects using the optional Document Camera.

By connecting to a computer and using the software supplied, you can make full use of the projector's capabilities.

"Optional Accessories" p.127

Enhanced security functions

• Password Protect to restrict and manage users

By setting a Password you can restrict who can use the projector.

"Managing Users (Password Protect)" p.65

• Control Panel Lock to restrict button operation on the control panel

You can use this to prevent people changing projector settings without permission at events, in schools, and so on.

"Restricting Operation (Control Panel Lock)" p.67

• Equipped with various anti-theft devices

The projector is equipped with the following types of anti-theft security devices.

• Security slot

• Security cable installation point

s "Anti-Theft Lock" p.69

Making the most of the remote control

You can use the remote control to perform operations such as enlarging part of the image. You can also use the remote control as a pointer during presentations or as a mouse for the computer.

"Pointer Function (Pointer)" p.58

"Enlarging Part of the Image (E-Zoom)" p.59

"Using the Remote Control to Operate the Mouse Pointer (Wireless

Mouse)" p.60

Taking Full Advantage of a Network Connection

By connecting a LAN cable (EB-X25/EB-W22/EB-X22/EB-X20 only), or the optional Wireless LAN unit (EB-X21/EB-S21/EB-X17/EB-S17 only), you can connect to a network and access the following functions.

"Connecting a LAN Cable" p.30

"Installing the Wireless LAN Unit" p.31

Projector Features

Connecting to a network and projecting images from the computer's screen

You can project your computer's screen over a network by using EasyMP Network Projection. Sharing the projector over the network allows you to project data from different computers without changing the signal cable. Even if the projector is away from the computer, you can still project data over a network.

You can find Easy Network Projection on the EPSON Projector Software CD-ROM.

Easy connection to a computer with Quick Wireless Connection (Windows only)

By simply connecting the optional Quick Wireless Connection USB Key to a computer, you can automatically setup a wireless LAN connection.

s "Installing the Quick Wireless Connection USB Key" p.32

You can download "Epson iProjection" for free from the App Store or from Google play. Any fees incurred when communicating with the App Store or Google play are the responsibility of the customer.

Projecting images from multiple computers simultaneously (EBX25/EB-W22/EB-X22/EB-X20 only)

By using EasyMP Multi PC Projection, up to four screens from multiple computers connected to the network, or from smartphones or tablets with Epson iProjection installed, can be projected simultaneously adding a touch of dynamism to conferences that use projectors. By making yourself the host of a meeting, you can control the projected screens from other connected computers allowing you to advance the meeting smoothly.

You can also project the same screen from remote projectors on the network.

You can find EasyMP Multi PC Projection on the EPSON Projector Software CD-ROM.

Projecting images from portable devices over a network

If "Epson iProjection" is installed on your smart phone or tablet device, you can wirelessly project data from the device. Because you can operate these devices from any location, you can vary the way in which conferences or presentations are made.

Part Names and Functions

All of the features in this guide are explained using illustrations of EB-X21 unless otherwise mentioned.

Front/Top

EB-S21/EB-S17

Air exhaust vent

Name Function

Exhaust vent for air used to cool the projector internally.

Caution

While projecting, do not put your face or hands near the air exhaust vent, and do not place objects that may become warped or damaged by heat near the vent. Hot air from the air exhaust vent could cause burns, warping, or accidents to occur.

Part Names and Functions

Name Function

A/V mute slide knob

Foot adjust lever

Front adjustable foot

A/V mute slide

Remote receiver

Focus ring

Zoom ring

(EB-X25/EB-W22/EBX22/EB-X21/EB-X20/ EB-X17 only)

Air intake vent

(air filter)

Slide the knob to open and close the A/V mute slide.

Press the foot adjust lever to extend and retract the front adjustable foot.

s "Adjusting the Image Position" p.45

When setup on a surface such as a desk, extend the foot to adjust the position of the image.

"Adjusting the Image Position" p.45

Close when not using the projector to protect the lens. By closing during projection you can hide the image and the sound.

s "Hiding the Image and Sound Temporarily (A/V Mute)" p.57

Receives signals from the remote control.

Adjusts the image focus. s "Correcting the Focus" p.45

Adjusts the image size. s "Adjusting the Image Size" p.44

Takes in air to cool the projector internally. s "Cleaning the Air Filter" p.119

Name Function

Lamp cover

Lamp Cover Fixing

Screw

Open when replacing the projector's lamp. s "Replacing the Lamp" p.121

Screw to fix the lamp cover in place.

Air filter cover

Security slot

Control panel

Horizontal keystone

adjuster

Opens and closes the air filter cover. s "Replacing the Air Filter" p.124

The security slot is compatible with the Microsaver Security System manufactured by Kensington.

s "Anti-Theft Lock" p.69

Operates the projector. s "Control Panel" p.15

Corrects horizontal distortion in the projected image. s "Correcting manually" p.41

Part Names and Functions

Rear

EB-X21/EB-S21/EB-X17/EB-S17

EB-X25/EB-W22/EB-X22/EB-X20

The ports vary depending on the model being used.

Name Function

Power inlet

S-Video port

RS-232C port

Video port

Audio-L/R port

Monitor Out port

Audio1 port

Audio Output port

Audio2 port

Connects the power cord to the projector. s "From Installation to Projection" p.34

For S-video signals from video sources.

When controlling the device from a computer, connect it to the computer with an RS-232C cable. This port is for control use and should not normally be used.

s "ESC/VP21 Commands" p.73

Inputs composite video signals from video sources.

Inputs audio from equipment connected to the S-Video port or the Video port.

Outputs analog RGB signals input from the Computer1 port to an external monitor. You cannot output signals input from other ports or component video signals.

Inputs audio from equipment connected to the Computer1 port.

Outputs audio from the currently projected image to an external speaker.

Inputs audio from equipment connected to the Computer2 port.

Speaker

Remote receiver

HDMI port

Computer2 port

Computer1 port

Outputs audio.

Receives signals from the remote control.

Inputs video signals from HDMI compatible video equipment and computers. This projector is compatible with

HDCPg.

s "Connecting Image Sources" p.26

Inputs image signals from a computer and component video signals from other video sources.

Part Names and Functions

Name Function

LAN port (EB-X25/EB-

W22/EB-X22/EB-X20 only)

USB-B port

USB-A port (EB-X21/

EB-S21/EB-X17/EBS17 only)

Connects a LAN cable to connect to a network.

• Connects the projector to a computer using a USB cable, and projects the images on the computer.

"Projecting with USB Display" p.36

• Connects the projector to a computer using a USB cable to use the Wireless Mouse function. s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

• Connects a USB memory device or a digital camera, and projects images using PC Free.

"Projecting Without a Computer (PC Free)"

p.52

• Connects the optional Document Camera.

• Connects the optional Wireless LAN unit.

s "Installing the Wireless LAN Unit" p.31

• Connects the optional Quick Wireless Connection USB Key. s "Installing the Quick Wireless Connection USB Key" p.32

Base

Wireless LAN unit

fixing screw (EB-X21/ EB-S21/EB-X17/EBS17 only)

This screw secures the wireless LAN unit cover.

Name Function

Ceiling mount fixing

points (three points)

Security cable

installation point

Attach the optional Ceiling Mount here when suspending the projector from a ceiling.

s "Installing the Projector" p.22 s "Optional Accessories" p.127

Pass a commercially available wire lock through here and lock it in place.

s "Installing the wire lock" p.69

Part Names and Functions

Name Function

Rear feet

Front adjustable foot

When setup on a surface such as a desk, turn to extend and retract to adjust the horizontal tilt.

s "Adjusting the Horizontal Tilt" p.45

When setup on a surface such as a desk, extend the foot to adjust the position of the image.

s "Adjusting the Image Position" p.45

Control Panel

Name Function

[Source Search]

button

[Enter] button

[

]

Changes to the next input source that is sending an image. s "Automatically Detect Input Signals and Change the

Projected Image (Source Search)" p.35

• When the Configuration menu or the Help screen is displayed, it accepts and enters the current selection and moves to the next level.

• If pressed while projecting analog RGB signals from the Computer port, you can automatically optimize Tracking, Sync., and Position.

[w][v] buttons

• Displays the Keystone screen allowing you to correct keystone distortion in vertical and horizontal directions. s "Correcting manually" p.41

• If pressed when the Configuration menu or the Help screen is displayed, these buttons select menu items and setting values.

s "Using the Configuration Menu" p.82 s "Using the Help" p.103

Part Names and Functions

[Help] button

[Esc] button

[a][b] buttons

or [Wide][Tele] buttons

Name Function

Displays and closes the Help screen which shows you how to deal with problems if they occur.

s "Using the Help" p.103

• Stops the current function.

• If pressed when the Configuration menu is displayed, it

moves to the previous menu level. s "Using the Configuration Menu" p.82

• For EB-X25/EB-W22/EB-X22/EB-X21/EB-X20/EBX17 [a] Decreases the volume. [b] Increases the volume. s "Adjusting the Volume" p.46

• For EB-S21/EB-S17 [Wide]: Enlarges the size of the projected image. [Tele]: Reduces the size of the projected image. s "Adjusting the Image Size" p.44

• Corrects keystone distortion in the horizontal direction when the Keystone screen is displayed. s "H/V-Keystone" p.42

• If pressed when the Configuration menu or the Help screen is displayed, these buttons select menu items and setting values.

"Using the Configuration Menu" p.82

s s "Using the Help" p.103

Remote Control

[Menu] button

Power button

[t]

Indicators

Displays and closes the Configuration menu. s "Using the Configuration Menu" p.82

Turns the projector power on or off. s "From Installation to Projection" p.34

Indicates the projector's status. s "Reading the Indicators" p.104

Part Names and Functions

Name Function

Power button

[t]

[Computer] button

[Video] button

Numeric buttons

[Auto] button

[Aspect] button

[Num] button

[Menu] button

[ ][ ][ ][ ]

buttons

Turns the projector power on or off. s "From Installation to Projection" p.34

Each time you press the button, the input changes between images from the Computer1 port and the Computer2 port.

Each time the button is pressed, the image cycles through the S-Video, Video, and HDMI ports.

Enter the Password. s "Setting Password Protect" p.65

If pressed while projecting analog RGB signals from the Computer port, you can automatically optimize Tracking, Sync., and Position.

Each time the button is pressed, the aspect mode changes. s "Changing the Aspect Ratio of the Projected Image"

p.47

Hold down this button and press the numeric buttons to enter passwords and numbers.

s "Setting Password Protect" p.65

Displays and closes the Configuration menu. s "Using the Configuration Menu" p.82

• When the Configuration menu or the Help screen is displayed, pressing these buttons selects menu items and setting values. s "Using the Configuration Menu" p.82

• When projecting using PC Free, pressing these buttons displays the previous/next image, rotates the image, and so on. s "PC Free operating methods" p.53

• During Wireless Mouse function, the mouse pointer moves in the direction of the button that was pushed. s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

Name Function

[ ] button

[User] button

[Page] buttons

[[][]]

[E-Zoom] buttons

[z][x]

• When the Configuration menu or the Help screen is displayed, it accepts and enters the current selection and moves to the next level. s "Using the Configuration Menu" p.82

• Acts as a mouse's left button when using the Wireless Mouse function. s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

Select any frequently used item from the five available Configuration menu items, and assign it to this button. By pressing the [User] button, the assigned menu item selection/adjustment screen is displayed, allowing you to make one-touch settings/adjustments.

s "Settings Menu" p.88 Power Consumption is assigned as the default setting.

Changes pages in files such as PowerPoint files when using the following projection methods.

• When using the Wireless Mouse function s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

• When using USB Display s "Projecting with USB Display" p.36

• When using Network connection

When projecting images using PC Free, pressing these buttons displays the previous/next screen.

Enlarges or reduces the image without changing the projection size.

s "Enlarging Part of the Image (E-Zoom)" p.59

Part Names and Functions

Name Function

[A/V Mute] button

[Help] button

[Freeze] button

[Volume] buttons

[a][b]

[Pointer] button

[Esc] button

• Turns the video and audio on or off.

s "Hiding the Image and Sound Temporarily (A/V Mute)" p.57

• You can change the Projection mode as follows by pressing the button for about five seconds.

FrontWFront/Ceiling RearWRear/Ceiling

Displays and closes the Help screen which shows you how to deal with problems if they occur.

s "Using the Help" p.103

Images are paused or unpaused. s "Freezing the Image (Freeze)" p.58

[a] Decreases the volume. [b] Increases the volume.

"Adjusting the Volume" p.46

Displays the on-screen pointer. s "Pointer Function (Pointer)" p.58

• Stops the current function.

• If pressed when the Configuration menu is displayed, it

moves to the previous level. s "Using the Configuration Menu" p.82

• Acts as a mouse's right button when using the Wireless Mouse function. s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

Name Function

[USB] button

[Source Search]

button

Remote control light-

emitting area

Each time the button is pressed, it cycles through the following images:

• USB Display

• Images from the device connected to the USB-A port

Changes to the next input source that is sending an image. s "Automatically Detect Input Signals and Change the

Projected Image (Source Search)" p.35

Outputs remote control signals.

[Color Mode] button

[LAN] button

Each time the button is pressed, the Color Mode changes. s "Selecting the Projection Quality (Selecting Color

Mode)" p.46

Switches to the image from the network connected device.

Part Names and Functions

Replacing the remote control batteries

If delays in the responsiveness of the remote control occur or if it does not operate after it has been used for some time, it probably means that the batteries are becoming flat. When this happens, replace them with new batteries. Have two AA size manganese or alkaline batteries ready. You cannot use other batteries except for the AA size manganese or alkaline.

Attention

Make sure you read the following manual before handling the batteries. s Safety Instructions

Remove the battery cover.

While pushing the battery compartment cover catch, lift the cover up.

Caution

Check the positions of the (+) and (-) marks inside the battery holder to ensure the batteries are inserted the correct way.

If the batteries are not used correctly, they could explode or leak causing a fire, injury, or damage to the product.

Replace the battery cover.

Press the battery compartment cover until it clicks into place.

Replace the old batteries with new batteries.

Part Names and Functions

Remote control operating range

Preparing the Projector

This chapter explains how to install the projector and connect projection sources.

Installing the Projector

Installation Methods

The projector supports the following four different projection methods. Install the projector according to the conditions of the installation location.

• Project images from in front of the screen. (Front projection)

• Suspend the projector from the ceiling and project images from in front of a screen. (Front/Ceil‐ ing projection)

• Project images from behind a translucent screen. (Rear projec‐ tion)

• Suspend the projector from the ceiling and project images from behind a translucent screen. (Rear/Ceiling projection)

Warning

• A special method of installation is required when suspending the projector from a ceiling (ceiling mount). If it is not installed correctly, it could fall causing an accident and injury.

• If you use adhesives on the Ceiling mount fixing points to prevent the screws from loosening, or if you use things such as lubricants or oils on the projector, the projector case may crack causing it to fall from its ceiling mount. This could cause serious injury to anyone under the ceiling mount and could damage the projector. When installing or adjusting the ceiling mount, do not use adhesives to prevent the screws from loosening and do not use oils or lubricants and so on.

• Do not cover the projector's air intake vent or air exhaust vent. If either of the vents are covered, the internal temperature could rise and cause a fire.

Attention

Do not use the projector on its side. This may cause malfunctions to occur.

• An optional Ceiling mount is required when suspending the

projector from a ceiling. s "Optional Accessories" p.127

• The default Projection setting is Front. You can change from Front to Rear from the Configuration menu.

s Extended - Projection p.89

• You can change the Projection mode as follows by pressing down the [A/V Mute] button on the remote control for about five seconds.

FrontWFront/Ceiling RearWRear/Ceiling

Installing the Projector

Installation methods

Install the projector as follows.

• Install the projector so that it is parallel to the screen. If the projector is installed at an angle to the screen, keystone distortion occurs in the projected image.

• Place the projector on a level surface. If the projector is tilted the projected image is also tilted.

• See the following if you cannot install the projector parallel to the

screen. s "Correcting Keystone Distortion" p.40

• See the following if you cannot install the projector on a level surface.

s "Adjusting the Horizontal Tilt" p.45 s "Correcting Keystone Distortion" p.40

Screen Size and Approximate Projection Distance

Projection size is determined by the distance from the projector to the screen. See the illustrations on the right to select the best position according to the screen size. The illustrations show the approximate shortest distance at maximum zoom. See the following for more information on the projection distance.

"Screen Size and Projection Distance" p.128

When you correct keystone distortion, the projected image may be

reduced.

Installing the Projector

16:10 Screen Size

For EB-W22

150”

100”

80”

50”

4:3 Screen Size

For EB-X22/EB-X21/EB-S21/EB-X20/EB-X17/EB-S17

150”

For EB-X25

150”

100”

80”

50”

100”

80”

Connecting Equipment

Illustrations in this section are of EB-X21.

The port name, number, location, and connector orientation differ depending on the source being connected.

Connecting a Computer

To project images from a computer, connect the computer using one of the following methods.

When using the supplied computer cable

Connect the computer's display output port to the projector's Computer port. You can output audio from the projector's speaker by connecting the computer's audio output port to the projector's Audio1 or Audio2 port using a commercially available audio cable.

When using the supplied or commercially available USB cable

Connect the computer's USB port to the projector's USB-B port. You can send the computer's audio with the projected image.

When using a commercially available HDMI cable

Connect the computer's HDMI port to the projector's HDMI port. You can send the computer's audio with the projected image.

• You can change the audio input source in Audio Output.

s Extended - A/V Settings - Audio Output p.89

• You can use a USB cable to connect the projector to a computer to project images from the computer. This function is called USB Display.

s "Projecting with USB Display" p.36

Connecting Equipment

Connecting Image Sources

To project images from DVD players or VHS video and so on, connect to the projector using one of the following methods.

When using a commercially available video or S-video cable

Connect the video output port on the image source to the projector's Video port. Or, connect the S-video output port on the image source to the projector's S-Video port. You can output audio from the projector's speaker by connecting the audio output port on the image source to the projector's Audio-L/R port using a commercially available audio cable.

When using the optional component video cable

s "Optional Accessories" p.127

Connect the component output port on the image source to the projector's Computer input port. You can output audio from the projector's speaker by connecting the audio output port on the image source to the projector's Audio1 or Audio2 port using a commercially available audio cable.

When using a commercially available HDMI cable

Connect the HDMI port on the image source to the projector's HDMI port. You can send the image source's audio with the projected image.

S-VIDEO

Connecting Equipment

Attention

If the orientation or shape of the plug differs, do not try to force it in. The device could be damaged or could malfunction.

• You can change the audio input source in Audio Output.

s Extended - A/V Settings - Audio Output p.89

• If the source you want to connect to has an unusually shaped port, use the cable supplied with the device or an optional cable to connect to the projectors.

• When using a commercially available 2RCA(L/R)/stereo mini-pin audio cable, make sure it is labeled "No resistance".

Connecting USB Devices

Only EB-X21/EB-S21/EB-X17/EB-S17 are supported.

You can connect devices such as USB memory, the optional Document Camera, and USB compatible hard disks and digital cameras.

Using the USB cable supplied with the USB device, connect the USB device to the USB-A port on the projector.

When the USB device is connected, you can project image files on the USB memory or digital camera using PC Free.

"PC Free examples" p.52

Connecting Equipment

Attention

• If you use a USB hub, the connection may not operate correctly. Devices such as digital cameras and USB devices should be connected to the projector directly.

• When connecting and using a USB-compatible hard disk, make sure you connect the AC adaptor supplied with the hard disk.

• Connect a digital camera or hard disk to the projector using the USB cable provided with the device.

• Use a USB cable less than three meters in length. If the cable exceeds three meters, PC Free may not function correctly.

Removing USB devices

After finishing projecting, remove USB devices from the projector. For devices such as digital cameras or hard disks, turn off the device and then remove it from the projector.

Connecting External Equipment

You can output images and audio by connecting an external monitor or speaker.

When outputting images to an external monitor

Connect the external monitor to the projector's Monitor Out port using the cable supplied with the external monitor.

When outputting audio to an external speaker

Connect the external speaker to the projector's Audio Out port using a commercially available audio cable.

Connecting Equipment

• If you set Standby Mode to Communication On, you can perform the following operations even if the projector is off.

- Outputting images to an external monitor (only when A/V Output is set to Always On).

- Outputting audio from an externally connected speaker (audio from USB or LAN cannot be output).

s ECO - Standby Mode p.99 s Extended - A/V Settings p.89

• Only analog RGB signals from the Computer1 port can be output to an external monitor. You cannot output signals input from other ports or component video signals.

• Setting gauges for functions such as Keystone, Configuration Menu, or Help screens are not output to the external monitor.

• When the audio cable jack is inserted into the Audio Out port, audio stops being output from the projector's built-in speakers and switches to external

output.

Connecting Equipment

Connecting a LAN Cable

Only EB-X25/EB-W22/EB-X22/EB-X20 are supported.

Connect a LAN port on network hubs or other equipment to the projector's LAN port with a commercially available 100BASE-TX or 10BASE-T LAN cable.

By connecting a computer to the projector over a network, you can project images and check the status of the projector.

To prevent malfunctions, use a category 5 or higher shielded LAN cable.

Connecting Equipment

Installing the Wireless LAN Unit

Only EB-X21/EB-S21/EB-X17/EB-S17 are supported.

By installing the optional Wireless LAN unit, you can project a computer screen over a network.

Connect the wireless LAN unit to the projector's USB-A port.

• When connecting to the network using wireless LAN, make sure you

make network settings from the Configuration menu. s "Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only)"

p.93

• If you normally leave the wireless LAN unit installed, make sure you attach the supplied wireless LAN unit cover as a theft deterrent.

• When moving the projector, make sure you remove the wireless LAN unit and cover for safety reasons.

Use a cross-head screwdriver to remove the screw that secures the wireless LAN unit cover.

Connect the wireless LAN unit to the USB-A port.

Attach the wireless LAN unit cover, and secure it in place with the screw.

Connecting Equipment

Installing the Quick Wireless Connection USB Key

When installing the optional Quick Wireless Connection USB Key, you need to remove the Wireless LAN unit first, and then connect the Quick Wireless Connection USB Key to the USB-A port.

Turn on the projector, and then press the [LAN] button on the remote control.

The LAN standby screen is displayed.

Check that the SSID and IP address information are displayed on the LAN standby screen, and then remove the Wireless LAN unit.

Connect the Quick Wireless Connection USB Key to the USB-A port.

Connect the Quick Wireless Connection USB Key to the computer you are using.

For the steps from here on, see the User's Guide supplied with the Quick Wireless Connection USB Key.

When the message "Network information update complete. Remove the Quick Wireless Connection USB Key Adapter." is displayed, remove the Quick Wireless Connection USB Key.

Reinstall the Wireless LAN unit on the projector.

Basic Usage

This chapter explains how to project and adjust images.

Projecting Images

From Installation to Projection

This section explains the procedure for connecting the projector to a computer with the computer cable and projecting images.

Attention

Be sure to connect the cable of the source to the projector first, and then connect the power cord to the projector.

Turn on the projector.

Open the A/V mute slide.

Turn on your computer.

If the image is not projected, you can change the projected image using one of the following methods.

• Press the [Source Search] button on the control panel or the remote

Change the computer's screen output.

When using a laptop computer, you need to change the screen output from the computer.

Hold down the Fn key (function key), and press the b key.

• The method for changing differs depending on the computer

control.

"Automatically Detect Input Signals and Change the Projected Image

(Source Search)" p.35

being used. See the documentation supplied with the computer.

• When turning off the projector, press the [t] power button

twice.

a b

Connect the projector to the computer with the computer cable.

Connect the projector to an electrical outlet with the power cord.

• Press the button for the target port on the remote control.

"Switching to the Target Image by Remote Control" p.36

After projecting the image, adjust the image if necessary.

s "Correcting Keystone Distortion" p.40 s "Correcting the Focus" p.45

Projecting Images

Automatically Detect Input Signals and Change the Projected Image (Source Search)

Press the [Source Search] button to project images from the port currently receiving an image.

Using the remote control Using the control panel

For EB-X21/EB-S21/EB-X17/EB-S17

The following screen is displayed while no image signals are input.

Example: For EB-X21/EB-S21/EB-X17/EB-S17

For EB-X25/EB-W22/EB-X22/EB-X20

When two or more image sources are connected, press the [Source Search] button until the target image is projected.

When your video equipment is connected, start playback before beginning this operation.

Projecting Images

Switching to the Target Image by Remote Control

You can change directly to the target image by pressing the following buttons on the remote control.

Remote control

Each time the button is pressed, it cycles through the images being input

from the following sources.

• Computer1

• Computer2

Each time the button is pressed, it cycles through the images being input

from the following sources.

• S-Video port

• Video port

• HDMI port

Each time the button is pressed, it cycles through the images being input

from the following sources.

• USB Display

• Images from the device connected to the USB-A port (EB-

X21/EB-S21/EB-X17/EB-S17 only)

Switches to the image from the network connected device.

Projecting with USB Display

You can use a USB cable to connect the projector to a computer to project images from the computer.

You can project images and send audio with one USB cable.

System requirements

For Windows

Windows 2000

Windows XP

Windows Vista Ultimate 32bit

Windows 7 Ultimate 32/64bit

Windows 8 Windows 8 32/64 bit

Professional 32bit Home Edition 32bit Tablet PC Edition 32bit

Enterprise 32bit Business 32bit Home Premium 32bit Home Basic 32bit

Enterprise 32/64bit Professional 32/64bit Home Premium 32/64bit Home Basic 32bit Starter 32bit

Windows 8 Pro 32/64 bit Windows 8 Enterprise 32/64 bit

CPU

Amount of Memory

Mobile Pentium III 1.2 GHz or faster Recommended: Pentium M 1.6 GHz or faster

256 MB or more Recommended: 512 MB or more

Projecting Images

Hard Disk Space

Display

*1 Service Pack 4 only *2 Except for Service Pack 1

For Mac OS

CPU

Amount of Memory

Hard Disk Space

Display

20 MB or more

Resolution of no less than 640x480 and no higher than 1600x1200.

Display color in 16-bit color or greater

Mac OS X 10.5.x 32 bit Mac OS X 10.6.x 32/64 bit Mac OS X 10.7.x 32/64 bit Mac OS X 10.8.x 32/64 bit

Power PC G4 1GHz or faster Recommended: Core Duo 1.83GHz or faster

512 MB or more

20 MB or more

Resolution of no less than 640x480 and no higher than 1680x1200.

Display color in 16-bit color or greater

Connecting for the first time

The first time you connect the projector and the computer using the USB cable, the driver needs to be installed. The procedure is different for Windows and Mac OS.

• You do not need to install the driver the next time you connect.

For Windows

• When inputting images from multiple sources, change the input source to USB Display.

• If you use a USB hub, the connection may not operate correctly. Connect the USB cable directly to the projector.

• You cannot change option settings while using USB Display.

Connect the computer's USB port to the projector's USB-B port using a USB cable.

For Windows 2000 or Windows XP, a message asking you if

For Windows 2000

Double-click Computer, EPSON PJ_UD, and then EMP_UDSE.EXE.

you want to restart your computer may be displayed. Select No.

For Windows XP

Driver installation starts automatically.

For Windows Vista/Windows 7/Windows 8

When the dialog box is displayed, click Run EMP_UDSE.exe.

When the License Agreement screen is displayed, click Agree.

Projecting Images

Computer images are projected.

It may take a while before computer images are projected. Until computer images are projected, leave the equipment as it is and do not disconnect the USB cable or turn off the power to the projector.

Disconnect the USB cable when you finish projection.

When disconnecting the USB cable, there is no need to use Safely Remove Hardware.

• If it is not installed automatically, double-click My Computer

- EPSON_PJ_UD - EMP_UDSE.EXE on your computer.

• If nothing is projected for some reason, click All Programs EPSON Projector - Epson USB Display - Epson USB Display Vx.xx on your computer.

• When using a computer running Windows 2000 under user authority, a Windows error message is displayed and you may not be able to use the software. In this case, try updating Windows to the latest version, restart, and then try to connect again.

For more details, contact your local dealer or the nearest address provided in the following document.

s Epson Projector Contact List

When the License Agreement screen is displayed, click Agree.

Enter the administrator authority password and start the installation.

When the installation is complete, the USB Display icon is displayed in the Dock and menu bar.

Computer images are projected.

It may take a while before computer images are projected. Until computer images are projected, leave the equipment as it is and do not disconnect the USB cable or turn off the power to the projector.

When you finish projection, select Disconnect from the USB Display icon menu on the menu bar or Dock, and then remove

the USB cable.

• If the USB Display setup folder is not displayed automatically

in the Finder, double-click EPSON PJ_UD - USB Display Installer on your computer.

• If nothing is projected for some reason, click the USB Display icon in the Dock.

• If there is no USB Display icon in the Dock, double-click USB Display from the Applications folder.

• If you select Exit from the USB Display icon menu on the Dock, USB Display does not start automatically when you connect the USB cable.

For Mac OS

Connect the computer's USB port to the projector's USB-B port using a USB cable.

The Setup folder of USB Display is displayed in the Finder.

Double-click the USB Display Installer icon.

b c

Follow the on-screen instructions to install.

Projecting Images

Uninstalling

For Windows 2000

Click Start, select Settings, and then click Control Panel.

Double-click Add/Remove Programs.

Click Change or Remove Programs.

Select Epson USB Display and click Change/Remove.

For Windows XP

Click Start, and then click Control Panel.

Double-click Add or Remove Programs.

Select Epson USB Display and click Remove.

For Windows Vista/Windows 7

Click Start, and then click Control Panel.

Click Uninstall a program under Programs.

Select Epson USB Display and click Uninstall.

Follow the on-screen instructions to uninstall.

For Mac OS

Open the Applications folder, double-click USB Display, and then double-click Tool.

Run USB Display UnInstaller.

For Windows 8

Open Charms, and then select Search. Right-click (press and hold) Epson USB Display Ver.XXX.

Select Uninstall from the app bar.

b c

Select Epson USB Display, and then select Uninstall.

Adjusting Projected Images

Correcting Keystone Distortion

You can correct keystone distortion using one of the following methods.

• Correcting automatically (Auto V-Keystone) Automatically corrects vertical keystone distortion.

• Correcting manually (H-Keystone Adjuster) Manually corrects horizontal keystone distortion using the horizontal keystone adjuster.

• Correcting manually (H/V-Keystone) Manually correct distortion in the horizontal and vertical directions independently.

• Correcting manually (Quick Corner) Manually correct the four corners independently.

When you correct keystone distortion, the projected image may be

reduced.

Adjusting Projected Images

Correcting automatically

Auto V-Keystone

When the projector detects any movement, for example when it is installed, moved, or tilted, it automatically corrects vertical keystone distortion. This function is called Auto V-Keystone.

When the projector remains still for about two seconds after it detects movement, it displays a screen for adjustment and then automatically corrects the projected image.

You can use Auto V-Keystone to correct the projected image under the following conditions.

Correction angle: approx. 30˚ up and down

• Auto V-Keystone works only when Projection is set to Front from

the Configuration menu. s Extended - Projection p.89

• If you do not want to enable Auto V-Keystone, set Auto V- Keystone to Off.

s Settings - Keystone - H/V-Keystone - Auto V-Keystone

p.88

Correcting manually

You can manually correct keystone distortion.

You can use H/V-Keystone to correct the projected image under the following conditions.

Correction angle: approx. 30˚ right and left/approx. 30˚ up and down

H-Keystone Adjuster

Move the horizontal keystone adjuster to the right or left to perform horizontal keystone correction.

EB-X25/EB-W22/EB-X22 /EB-X21/EB-X20/EB-X17

EB-S21/EB-S17

• When using horizontal keystone adjuster, set H-Keystone Adjuster to On.

s Settings - Keystone - H/V-Keystone - H-Keystone Adjuster

p.88

• You can also correct keystone distortion in the horizontal direction using H/V-Keystone.

Adjusting Projected Images

H/V-Keystone

Manually correct distortion in the horizontal and vertical directions independently.

Press the [w] or [v] button on the control panel during projection to display the Keystone screen.

Press the following buttons to correct keystone distortion.

Press the [

] or [v] button to correct vertical distortion.

You can also set H/V-Keystone from the Configuration menu.

Quick Corner

This allows you to manually correct each of the four corners of the projected image separately.

s Settings - Keystone - H/V-Keystone p.88

Press the [Menu] button while projecting.

"Using the Configuration Menu" p.82

Using the remote control Using the control panel

Press the [a]/[b] buttons or the [Wide]/[Tele] buttons to correct horizontal distortion.

Adjusting Projected Images

Select Keystone from Settings.

Select Quick Corner, and then press the [ ] button.

Using the [ ], [ ], [ ], and [ ] buttons on the remote control,

or the [ on the control panel, select the corner to correct, and then press

the [

], [v], [a], and [b] buttons (or the [Wide]/[Tele] buttons)

] button.

Adjusting Projected Images

Using the [ ], [ ], [ ], and [ ] buttons on the remote control,

or the [ on the control panel, correct the position of the corner.

When you press the [ displayed.

If the message "Cannot adjust any further." is displayed while adjusting, you cannot adjust the shape any further in the direction indicated by the gray triangle.

], [v], [a], and [b] buttons (or the [Wide]/[Tele] buttons)

] button, the screen shown in step 4 is

If the [Esc] button is held down for about two seconds while

the corner selection screen from step 4 is displayed, the following screen is displayed.

Reset Quick Corner: Resets the result of Quick Corner corrections.

Switch to H/V-Keystone: Switches the correction method to H/V-Keystone.

s "Settings Menu" p.88

Adjusting the Image Size

For EB-X25/EB-W22/EB-X22/EB-X21/EB-X20/EB-X17

Repeat procedures 4 and 5 as needed to adjust any remaining corners.

When you are done, press the [Esc] button to exit the correction menu.

Because Keystone was changed to Quick Corner, the corner selection screen shown in step 4 is displayed the next time you press the [

] or [v] button on the control panel. Change Keystone to

H/V-Keystone if you want to perform horizontal and vertical

correction using the [

Settings - Keystone - H/V-Keystone p.88

] or [v] button on the control panel.

Turn the zoom ring to adjust the size of the projected image.

For EB-S21/EB-S17

Adjust by using the [Wide]/[Tele] buttons on the control panel.

Wide: Enlarges the size of the projected image.

Tele: Reduces the size of the projected image.

Adjusting Projected Images

EB-X25/EB-W22/EB-X22 /EB-X21/EB-X20/EB-X17

EB-S21/EB-S17

Adjusting the Image Position

Press the foot adjust lever to extend the front adjustable foot. You can adjust the position of the image by tilting the projector up to 12 degrees.

Adjusting the Horizontal Tilt

Extend and retract the rear feet to adjust the projector's horizontal tilt.

Extend the rear foot.

Retract the rear foot.

Correcting the Focus

You can correct the focus using the focus ring.

EB-X25/EB-W22/EB-X22 /EB-X21/EB-X20/EB-X17

EB-S21/EB-S17

The larger the angle of tilt, the harder it becomes to focus. Install the projector so that it only needs to be tilted at a small angle.

Adjusting Projected Images

Adjusting the Volume

You can adjust the volume using one of the following methods.

• Press the [Volume] button on the control panel or the remote control to adjust the volume. [

] Decreases the volume.

] Increases the volume.

[

Using the remote control Using the control panel

(EB-X25/EB-W22/EB-X22/EB-X21/EB-X20/EB-X17

only)

• Adjust the volume from the Configuration menu.

Settings - Volume p.88

Selecting the Projection Quality (Selecting Color Mode)

You can easily obtain the optimum image quality simply by selecting the setting that best corresponds to your surroundings when projecting. The brightness of the image varies depending on the mode selected.

Mode Application

Dynamic

Presentation

Theatre


Sports

sRGB

Ideal for use in a bright room. This is the brightest mode, and reproduces shadow tones well.

Ideal for making presentations using color materials in a bright room.

Ideal for watching films in a dark room. Gives images a natural tone.

Ideal for projecting still pictures, such as photos, in a bright room. The images are vivid and brought into contrast.

Ideal for watching TV programmes in a bright room. The images are vivid and brought to life.

Ideal for images that conform to the standard.

sRGBg color

Caution

Do not start at high volume. A sudden excessive volume may cause loss of hearing. Always lower the volume before powering off, so that you can power on and then gradually increase the volume.

Blackboard

Whiteboard

*1 This selection is only available when the input signal is RGB or when the

source is USB Display or USB.

*2 This selection is only available when the input signal is component video, or

when the input source is Video or S-Video.

Even if you are projecting onto a blackboard (greenboard), this setting gives your images a natural tint, just like when projecting onto a screen.

Ideal for making presentations using a whiteboard.

Adjusting Projected Images

Each time you press the [Color Mode] button, the Color Mode name is displayed on the screen and the Color Mode changes.

Remote control

You can set Color Mode from the Configuration menu.

s Image - Color Mode p.85

Setting Auto Iris

By automatically setting the luminance according to the brightness of the displayed image, it lets you enjoy deep and rich images.

Select Auto Iris from Image.

Select Normal or High Speed.

The setting is stored for each Color Mode.

When set to High Speed, the brightness of the image is

adjusted as soon as the scene changes.

Press the [Menu] button.

"Using the Configuration Menu" p.82

Using the remote control Using the control panel

Press the [Menu] button to finish making settings.

Auto Iris can only be set when the Color Mode is Dynamic or

Changing the Aspect Ratio of the Projected Image

You can change the Aspect Ratiog of the projected image to suit the type, the ratio of height and width, and the resolution of the input signals.

Theatre.

Adjusting Projected Images

Available aspect modes vary depending on the image signal currently being projected.

Changing methods

Each time you press the [Aspect] button on the remote control, the aspect mode name is displayed on the screen and the aspect ratio changes.

Remote control

You can set the aspect ratio from the Configuration menu.

s Signal - Aspect p.86

Normal or Auto

16:9

Full

Zoom

Native

Changing the aspect mode

Projecting images from video equipment or from the HDMI port (for EB-W22)

Each time the [Aspect] button is pressed, the aspect mode changes in the order Normal or Auto, 16:9, Full, Zoom, and Native.

Example: 1080p signal input (resolution: 1920x1080, aspect ratio: 16:9)

Projecting images from video equipment (for EB-X25/EB-X22/EB-X21/EB-S21/EB-X20/ EB-X17/EB-S17)

Each time the [Aspect] button is pressed, the aspect mode changes in the order 4:3 and 16:9.

When inputting a 720p/1080i signal and the aspect mode is set to 4:3, a 4:3 zoom is applied (the right and left sides of the image are cut off).

Example: 720p signal input (resolution: 1280x720, aspect ratio: 16:9)

Adjusting Projected Images

Projecting images from a computer

The following shows projection examples for each aspect mode.

For EB-W22

Aspect Mode Input Signal

XGA 1024X768(4:3) WXGA 1280X800(16:10)

4:3

16:9

Projecting images from the HDMI port (for EB-X25/EB-X22/EB-X21/EB-S21/EB-X20/ EB-X17/EB-S17)

Each time the Aspect button is pressed, the aspect mode changes in the order Auto, 4:3, and 16:9.

Example: 1080p signal input (resolution: 1920x1080, aspect ratio: 16:9)

Auto

4:3

16:9

Normal

16:9

Full

Zoom

Native

Adjusting Projected Images

For EB-X25/EB-X22/EB-X21/EB-S21/EB-X20/EB-X17/EB-S17

Aspect Mode Input Signal

XGA 1024X768(4:3) WXGA 1280X800(16:10)

Normal

4:3

16:9

If parts of the image are missing, set the Resolution setting to Wide or Normal from the Configuration menu, according to the size of the computer panel.

s Signal - Resolution p.86

Useful Functions

This chapter explains useful tips for giving presentations, and the Security functions.

Projection Functions

Projecting Without a Computer (PC Free)

Only EB-X21/EB-S21/EB-X17/EB-S17 are supported.

By connecting a USB storage device such as a USB flash drives or a USB hard disk to the projector, you can project the files stored on the device without using a computer. This function is called PC Free.

• You may not be able to use USB storage devices that incorporate

Specifications for files that can be projected using PC Free

Type File Type (Ex‐

Image .jpg The following cannot be projected.

security functions.

• You cannot correct keystone distortion while projecting in PC Free,

even if you press the [w] and [v] buttons on the control panel.

Notes

tension)

- CMYK color mode formats

- Progressive formats

- Images with a resolution greater than 8192 x 8192 Due to the characteristics of JPEG files, images may

not be projected clearly if the compression ratio is too high.

Type File Type (Ex‐

tension)

Movie .avi • Cannot project images with a resolution greater

• When connecting and using a USB-compatible hard disk, make sure

you connect the AC adaptor supplied with the hard disk.

• The projector does not support some file systems, so use media that has been formatted in Windows.

• Format the media in FAT16/32.

Notes

than 1280 x 720.

• The audio format can only playback linear PCM and ADPCM.

PC Free examples

Projecting images stored on USB storage

.bmp Cannot project images with a resolution greater

than 1280 x 800.

.gif • Cannot project images with a resolution greater

than 1280 x 800.

• Cannot project animated GIFs.

.png Cannot project images with a resolution greater

than 1280 x 800.

"Projecting the selected image" p.55

"Projecting image files in a folder in sequence (Slideshow)" p.56

Projection Functions

PC Free operating methods

Although the following steps are explained based on the remote control, you can perform the same operations from the control panel.

Starting PC Free

Change the source to USB.

"Switching to the Target Image by Remote Control" p.36

Connect the USB storage device to the projector.

"Connecting USB Devices" p.27

PC Free starts and the file list screen is displayed.

• The following files are displayed as thumbnails (file contents are displayed as small images).

- JPEG files

- AVI files (displays the image at the start of the movie)

• Other files or folders are displayed as icons as shown in the following table.

Icon File Icon File

JPEG files

BMP files

• You can also insert a memory card into a USB card reader and then connect the reader to the projector. However, some commercially available USB card readers may not be compatible with the projector.

• If the following screen (Select Drive screen) is displayed, press the

[

], [ ], [ ], or [ ] buttons to select the drive you want to

use, and then press the [

• To display the Select Drive screen, position the cursor on Select Drive at the top of the file list screen, and then press the [

button.

] button.

]

GIF files PNG files

AVI (Motion JPEG)

files

* When it cannot be displayed as a thumbnail, it is displayed as an icon.

Projection Functions

Projecting images

Press the [ ], [ ], [ ], or [ ] buttons to select the file or folder

you want to project.

If not all of the files and folders are displayed on the current screen, press the []] button on the remote control, or position the cursor on Next Page at the bottom of the screen and press the [

] button.

Rotating images

You can rotate the played images in 90˚ increments. The rotating function is also available during Slideshow.

Play images, or run Slideshow.

While projecting, press the [ ] or [ ] button.

To return to the previous screen, press the [[] button on the remote control, or position the cursor on Previous Page at the top of the screen and press the [

Press the [ ] button.

The selected image is displayed.

When a folder is selected, the files in the selected folder are displayed. To return to the previous screen, position the cursor on

] button.

Stopping PC Free

To close PC Free, disconnect the USB device from the USB port on the projector. For devices such as digital cameras or hard disks, turn off the device and then remove it from the projector.

Projection Functions

Projecting the selected image

Attention

Do not disconnect the USB storage device while it is being accessed. PC Free may not operate correctly.

Start PC Free.

The file list screen is displayed.

"Starting PC Free" p.53

Press the [ ], [ ], [ ], and [ ] buttons to select the image file

you want to project.

To finish projecting, perform one of the following operations.

Press the [ ][ ] buttons to move to the next or previous

image file.

• Projecting an image: Press the [Esc] button.

• Projecting a movie: Press the [Esc] button to display the message

screen, select Exit, and then press the [

When projection is finished, you are returned to the file list screen.

] button.

Press the [ ] button.

The image is displayed or the movie is played back.

Projection Functions

Projecting image files in a folder in sequence (Slideshow)

You can project the image files in a folder in sequence, one at a time. This function is called Slideshow. Use the following procedure to run Slideshow.

To change files automatically when you run Slideshow, set Screen

Switching Time from Option in Slideshow to anything other than No. The default setting is 3 seconds.

s "Image file display settings and Slideshow operation settings"

p.57

Start PC Free.

The file list screen is displayed.

"Starting PC Free" p.53

Press the [ ], [ ], [ ], or [ ] buttons to position the cursor

over the folder for the Slideshow that you want to run, and then press the [

] button.

If Screen Switching Time on the Option screen is set to No, files do

You can use the following functions when projecting a file with PC Free.

• Freeze

• A/V Mute

• E-Zoom

• Pointer

not change automatically when you select Play Slideshow. Press the

[

] button, the [ ] button, or the []] button to continue to the

next file.

"Freezing the Image (Freeze)" p.58

"Hiding the Image and Sound Temporarily (A/V Mute)" p.57

"Enlarging Part of the Image (E-Zoom)" p.59

"Pointer Function (Pointer)" p.58

Select Slideshow at the bottom right of the file list screen, and then press the [

Slideshow starts, and the image files in the folder are automatically projected in sequence, one at a time.

When the last file is projected, the file list is displayed again automatically. If you set Continuous Play to On in the Option window, projection starts again from the beginning when it reaches the end.

"Image file display settings and Slideshow operation settings"

p.57

You can proceed to the next screen, return to the previous screen, or stop playback while projecting a Slideshow.

] button.

Projection Functions

Image file display settings and Slideshow operation settings

You can set the file display order and Slideshow operations on the Option screen.

Select Option at the bottom of the file list screen, and then press the [

When the following Option screen is displayed, set each of the items.

Select any of the options as necessary and press the [

The following table shows the details for each item.

] button.

Screen Switch‐ ing Time

Effect

When you have finished making settings, use the [ ], [ ], [ ],

You can set the time for a single file to be displayed in Slideshow. You can set a time between No (0) to 60 Seconds. When you set Off, auto play is disabled.

You can set the screen effects when changing slides.

or [

] buttons to position the cursor over OK, and then press the

[

] button.

The settings are applied.

If you do not want to apply the settings, position the cursor on Cancel, and then press the [

Hiding the Image and Sound Temporarily (A/V Mute)

You can use this when you want to focus the audience's attention on what you are saying, or if you do not want to show details such as when you are changing between files during presentations from a computer.

] button.

Display Order

Sort Order

Continuous Play

You can select to display the files in Name Order or Date Order.

You can select to sort the files In Ascending or In Descending order.

You can set whether to repeat the Slideshow.

Projection Functions

Each time you press the [A/V Mute] button or open/close the lens cover, A/V Mute turns on or off.

Remote control Projector

• When projecting moving images, the images and sound continue to

be played back while A/V Mute is on. It is not possible to resume projection from the point where A/V Mute was activated.

• You can select the screen displayed when the [A/V Mute] button is pressed from the Configuration menu.

s Extended - Display - A/V Mute p.89

• When A/V mute is enabled with the [A/V Mute] button, A/V Mute Timer activates and the power is automatically turned off after approximately 30 minutes. If you do not want to enable A/V Mute Timer, set A/V Mute Timer to Off.

ECO - A/V Mute Timer p.99

• When the A/V mute slide is closed for approximately 30 minutes, Lens Cover Timer activates and the power is automatically turned off. If you do not want Lens Cover Timer to activate, set Lens Cover Timer to Off.

s ECO - Lens Cover Timer p.99

• The lamp is still lit during A/V Mute, so the lamp hours continue to accumulate.

Freezing the Image (Freeze)

When Freeze is activated on moving images, the frozen image continues to project on the screen, so you can project a moving image one frame at a time like a still photo. Also, you can perform operations such as changing between files during presentations from a computer without projecting any images if the Freeze function is activated beforehand.

Each time you press the [Freeze] button, Freeze turns on or off.

Remote control

• Audio does not stop.

• When projecting moving images, the images continue to be played back while the screen is frozen. It is not possible to resume projection from the point where the screen was frozen.

• If the [Freeze] button is pressed while the Configuration menu or the Help screen is displayed, the menu or the Help screen that is displayed is closed.

• Freeze still works while E-Zoom is being used.

Pointer Function (Pointer)

This allows you to move a Pointer icon on the projected image, and helps you draw attention to the area you are talking about.

Projection Functions

You can select the shape of the pointer icon from the

Configuration menu. s Settings - Pointer Shape p.88

Enlarging Part of the Image (E-Zoom)

Display the Pointer.

Each time you press the [Pointer] button, the pointer appears or disappears.

Remote control

Move the Pointer icon ( ).

Remote control

This is useful when you want to expand images to see them in greater detail, such as graphs and tables.

Start E-Zoom.

Press the [

] button to display the Cross ( ).

Remote control

When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are

pressed at the same time, the pointer can be moved diagonally.

Projection Functions

Move the Cross ( ) to the area of the image that you want to

enlarge.

Remote control

When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are

pressed at the same time, the pointer can be moved diagonally.

Enlarge.

Remote control

[z] button: Expands the area each time it is pressed. You can expand quickly by holding the button down.

[x] button: Reduces images that have been enlarged.

[Esc] button: Cancels E-Zoom.

Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)

You can control the computer's mouse pointer from the projector's remote control. This function is called Wireless Mouse.

The following operating systems are compatible with Wireless Mouse.

Windows Mac OS

* It may not be possible to use the Wireless Mouse function under some

versions of the operating systems.

Use the following procedure to enable the Wireless Mouse function.

Connect the projector to the computer with the USB cable.

"Connecting a Computer" p.25

Change the source to one of the following.

• USB Display

Windows 2000 Windows XP Windows Vista Windows 7 Windows 8

Mac OS X 10.3.x Mac OS X 10.4.x Mac OS X 10.5.x Mac OS X 10.6.x Mac OS X 10.7.x Mac OS X 10.8.x

• The enlargement ratio appears on the screen. The selected area can be enlarged to between 1 to 4 times in 25 incremental steps.

• During enlarged projection, press the [

[

] buttons to scroll the image.

], [ ], [ ], or

• Computer

• HDMI

"Switching to the Target Image by Remote Control" p.36

Projection Functions

Once set, the mouse pointer can be controlled as follows.

Moving the mouse pointer

[ ][ ][ ][ ] buttons:

Moves the mouse pointer.

Mouse clicks

[Esc] button: Right click.

[

] button: Left click. Press quickly

twice to double-click.

Drag and drop

While holding down the [ ] button,

press the [

button.

Release the [ desired location.

Page Up/Down

[[] button: Moves to the previous page. []] button: Moves to the next page.

], [ ], [ ], or [ ]

] button to drop at the

• When any pair of adjacent [ ], [ ], [ ], or [ ] buttons are

pressed at the same time, the pointer can be moved diagonally.

• If the mouse button settings are set to reverse on the computer, the operation of the remote control buttons will also be reversed.

• The Wireless Mouse function does not work under the following conditions.

- When the Configuration menu or a Help screen is displayed

- When operating functions other than the Wireless Mouse function (such as adjusting the volume)

However, when using the E-Zoom or Pointer function, the page up or down function is available.

Saving a User's Logo

You can save the image that is currently being projected as a User's Logo.

Once a User's Logo has been saved, the logo cannot be returned to the

factory default.

Project the image you want to save as the User's Logo, and then press the [Menu] button.

"Using the Configuration Menu" p.82

Using the remote control Using the control panel

Projection Functions

Select User's Logo from Extended.

• When User's Logo Protect from Password Protect is set to

On, a message is displayed and the User's Logo cannot be changed. You can make changes after setting User's Logo Protect to Off.

s "Managing Users (Password Protect)" p.65

• If User's Logo is selected when Keystone, E-Zoom, Aspect, or

Adjust Zoom are being performed, the function currently being performed is temporarily cancelled.

Move the box to select the part of the image to use as the User's Logo.

You can perform the same operations from the projector's control panel.

Remote control

You can save at 400x300 dots in size.

When you press the [ ] button and the message "Select this image?" is displayed, select Yes.

Select the zoom factor from the zoom setting screen.

When the message "Choose this image as the User's Logo?" is displayed, select Yes.

When you press the [ ] button on the remote control or the

control panel, the screen size may change depending on the signal to match the actual resolution of the image signal.

Projection Functions

When the message "Save this image as the User's Logo?" is displayed, select Yes.

The image is saved. After the image has been saved, the message "Completed." is displayed.

• When a User's Logo is saved, the previous User's Logo is

erased.

• It takes a while to save. Do not operate the projector or any connected equipment while it is saving, otherwise malfunctions may occur.

Saving User Pattern

You can save the image that is currently being projected as a User Pattern.

When a User Pattern is saved, the previous User Pattern is erased.

Project the image you want to use as the User Pattern, and then press the [Menu] button.

"Using the Configuration Menu" p.82

Select User Pattern.

Using the remote control Using the control panel

Select Pattern from Settings.

If User Pattern is selected when one of the Keystone, E-Zoom, Aspect, Progressive, and Zoom Adjustment functions is being used, the function currently being used is cancelled temporarily.

Projection Functions

When "Do you want to use the currently projected image as the User Pattern?" is displayed, select Yes.

When you press the [Enter] button, the message "Do you save this image as the User Pattern?" is displayed. Then, select Yes.

The image is saved. After the image has been saved, the message "The User Pattern setting is complete". is displayed.

• Once a User Pattern has been saved, User Pattern cannot be

returned to the factory default.

• Saving the User Pattern may take approximately 15 seconds. Do not operate the projector or any connected equipment while it is saving, otherwise malfunctions may occur.

Security Functions

The projector has the following enhanced security functions.

• Password Protect You can limit who can use the projector.

• Control Panel Lock You can prevent people changing the settings on the projector without

permission.

"Restricting Operation (Control Panel Lock)" p.67

• Anti-Theft Lock The projector is equipped with the following anti-theft security device.

"Anti-Theft Lock" p.69

Managing Users (Password Protect)

When Password Protect is activated, people who do not know the password cannot use the projector to project images even if the projector power is on. Furthermore, the user's logo that is displayed when you turn on the projector cannot be changed. This acts as an anti-theft function as the projector cannot be used even if it is stolen. At the time of purchase, Password Protect is not activated.

• User's Logo Protection

Even if someone tries to change the User's Logo set by the owner of the projector, it cannot be changed. When User's Logo Protect is set to On, the following setting changes for the User's Logo are prohibited.

• Capturing a User's Logo

• Setting Display Background, Startup Screen, or A/V Mute from

Display

Extended - Display p.89

• Network Protection

When Network Protect is set to On, changing the settings for Network is prohibited.

"Network Menu" p.91

Setting Password Protect

Use the following procedure to set Password Protect.

During projection, hold down the [Freeze] button for about five seconds.

The Password Protect setting menu is displayed.

Kinds of Password Protect

The following two kinds of Password Protect settings can be made according to how the projector is being used.

• Power On Protect

When Power On Protect is On, you need to enter a preset password after the projector is plugged in and turned on (this also applies to Direct Power On). If the correct password is not entered, projection does not start.

Remote control

Security Functions

• If Password Protect is already activated, you must enter the

password. If the password is entered correctly, the Password Protect setting menu is displayed.

s "Entering the Password" p.66

• When the password is set, stick the password protect sticker in a visible position on the projector as a further theft deterrent.

s Password Protect Sticker

(2)

When the message "Change the password?" is displayed, select Yes and then press the [ this to your own desired Password. If you select No, the screen displayed in step 2 is displayed again.

(3) While holding down the [Num] button, enter a four digit number using

the numeric buttons. The number entered is displayed as "* * * *". When you enter the fourth digit, the confirmation screen is displayed.

] button. The default password is set to "0000". Change

Remote control

Select the type of Password Protect you want to set, and then press the [

Select On, and then press the [ ] button.

Press the [Esc] button, the screen displayed in step 2 is displayed again.

Set the password.

(1)

Select Password, and then press the [

] button.

(4) Re-enter the password.

"The message Password accepted." is displayed. If you enter the password incorrectly, a message is displayed prompting

you to re-enter the password.

Entering the Password

When the password entry screen is displayed, enter the password using the remote control.

While holding down the [Num] button, enter the password by pressing the numeric buttons.

Security Functions

When you enter the correct password, Password Protect is temporarily released.

Attention

• If an incorrect password is entered three times in succession, the message "The projector's operation will be locked." is displayed for approximately five minutes, and then the projector switches to standby mode. If this happens, disconnect the power plug from the electrical outlet and then reinsert it and turn the projector's power back on. The projector displays the password entry screen again so that you can enter the correct password.

• If you have forgotten the password, make a note of the "Request Code: xxxxx" number that appears on the screen and contact the nearest address provided in the Epson Projector Contact List.

s Epson Projector Contact List

• If you continue to repeat the above operation and enter the wrong password thirty times in succession, the following message is displayed and the projector does not accept any more password entries. "The projector's operation will be locked. Contact Epson as described in your documentation."

s Epson Projector Contact List

Restricting Operation (Control Panel Lock)

Perform one of the following to lock the operation buttons on the control panel.

• Full Lock All of the buttons on the control panel are locked. You cannot perform

any operations from the control panel, including turning the power on or off.

• Partial Lock All of the buttons on the control panel, except for the [ are locked.

This is useful at events or shows when you want to deactivate all buttons during projection or at schools when you want to limit button operation. The projector can still be operated using the remote control.

Press the [Menu] button while projecting.

"Using the Configuration Menu" p.82

Using the remote control Using the control panel

] power button,

Security Functions

Select Control Panel Lock from Settings.

Select either Full Lock or Partial Lock according to your purpose.

You can release the control panel lock by one of the following two methods.

• Select Off from Control Panel Lock. Settings - Control Panel Lock p.88

• Press and hold down the [

for about seven seconds, a message is displayed and the lock is released.

] button on the control panel

Select Yes when the confirmation message is displayed.

The control panel buttons are locked according to the setting you chose.

Security Functions

Anti-Theft Lock

The projector is equipped with the following types of anti-theft security devices.

• Security slot The security slot is compatible with the Microsaver Security System

manufactured by Kensington. See the following for more details on the Microsaver Security System.

http://www.kensington.com/

• Security cable installation point A commercially available theft-prevention wire lock can be passed

through the installation point to secure the projector to a desk or pillar.

Installing the wire lock

Pass an anti-theft wire lock through the installation point.

See the documentation supplied with the wire lock for locking instructions.

Monitoring and Controlling

EasyMP Monitor

By using EasyMP Monitor, you can display the status of multiple Epson network projectors on your computer. This allows you to check the status of the projectors and control them from your computer. The Message Broadcasting plugin for EasyMP Monitor can be used to simultaneously send JPEG files to registered projectors. You can download EasyMP Monitor from the following Web site.

http://www.epson.com

Download the Message Broadcasting plugin from the Web site.

Changing Settings Using a Web Browser (Web Control)

By using a Web browser of a computer connected to the projector on a network, you can make settings and control the projector. This function allows you to perform setup and control operations remotely. In addition, since you can use the computer's keyboard, entering characters required for the setup is easier.

Use Microsoft Internet Explorer 8.0 or later as the Web browser. If using a Mac OS X, use Safari.

Projector setup

In a Web browser, you can set items that are usually set in the projector's Configuration menu. The settings are reflected in the Configuration menu. There are also items that can only be set in the Web browser.

Items in the Configuration menu that cannot be set by the Web browser

• Settings Menu - Pointer Shape

• Settings Menu - Pattern

• Settings Menu - User Button

• Extended Menu - User's Logo

• Extended Menu - Language

• Extended Menu - Operation - High Altitude Mode

• Reset Menu - Reset All and Reset Lamp Hours

The settings for items on each menu are the same as the projector's Configuration menu.

"Configuration Menu" p.81

Items that can only be set with a Web browser

• SNMP Community Name (up to 32 single-byte alphanumeric characters)

• Monitor Password (up to 16 single-byte alphanumeric characters)

If you set Standby Mode to Communication On, you can use the Web browser to make settings and perform control even if the projector is in standby mode (when the power is off).

s ECO - Standby Mode p.99

Displaying the Web Control screen

Use the following procedure to display the Web Control screen.

Make sure the computer and projector are connected to the network. When communicating with a wireless LAN, connect in Advanced mode.

If your Web browser is set up to connect via a proxy server, the Web

Control screen cannot be displayed. To display Web Control, you need to make settings so that a proxy server is not used for a connection.

Monitoring and Controlling

a b

Start a Web browser on the computer.

Enter the IP address of the projector in the address input box of the Web browser, and press the Enter key on the computer's keyboard.

The Web Control screen is displayed.

When Web Control Password is set from the Configuration menu, the password entry screen is displayed.

Enter the user ID and password.

Enter "EPSONWEB" as the user ID.

The initial password is "admin".

• Enter the user ID even if a password has not been set. You

cannot change the user ID.

• You can change the password on the Network menu from the Configuration menu.

s Network - Basic - Web Control Password p.93

The Web Remote screen is displayed.

Displaying the Web Remote screen

The Web Remote function allows you to perform projector remote control operations with a Web browser.

Display the Web Control screen.

Click Web Remote.

Name Function

Power button

[t]

[Computer] button

[Video] button

[Freeze] button

Turns the projector power on or off. s "From Installation to Projection" p.34

Each time you press the button, the input changes between images from the Computer1 port and the Computer2 port.

Each time the button is pressed, the image cycles through the Video, S-Video, and HDMI ports.

Images are paused or unpaused. s "Freezing the Image (Freeze)" p.58

Monitoring and Controlling

Name Function

[A/V Mute] button

[Page] buttons

[[][]]

[Source Search]

button

[LAN] button

Turns the video and audio on or off. s "Hiding the Image and Sound Temporarily (A/V

Mute)" p.57

Changes pages in files such as PowerPoint files when using the following projection methods.

• When using the Wireless Mouse function

s "Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)" p.60

• When using USB Display

s "Projecting with USB Display" p.36

• During a network connection

When projecting images or scenarios using PC Free, pressing these buttons displays the previous/next screen.

Changes to the next input source that is sending an image. s "Automatically Detect Input Signals and Change the

Projected Image (Source Search)" p.35

Changes to the image projected with EasyMP Network Projection. When projecting using the optional Quick Wireless Connection USB Key, this button switches to that image.

s "Switching to the Target Image by Remote Control"

p.36

Using the Mail Notification Function to Report Problems

When you set Mail Notification, notification messages are sent to the preset email addresses when a problem or warning occurs with a projector. This will enable the operator to be notified of problems with projectors even at locations away from the projectors.

Network - Mail - Mail Notification p.97

• Up to a maximum of three notification destinations (addresses) can

Reading Error Notification Mail

be registered, and notification messages can be sent to all three destinations at once.

• If a projector develops a critical problem and suddenly stops working, it may not be able to send a message notifying an operator of the problem.

• If you set Standby Mode to Communication On, you can control the projector even if it is in standby mode (when the power is off).

s ECO - Standby Mode p.99

[USB] button

[Volume] buttons

[a][b]

Each time the button is pressed, it cycles through the following images:

• USB Display

• Images from the device connected to the USB port

s "Switching to the Target Image by Remote Control"

p.36

[a] Decreases the volume. [b] Increases the volume. s "Adjusting the Volume" p.46

When the Mail Notification function is set to On and a problem or warning occurs in the projector, the following email will be sent.

Mail sender: Address for Address 1

Subject: EPSON Projector

Line 1: The projector name where the problem has occurred

Line 2: The IP address set for the projector where the problem has occurred.

Line 3 and on: Details of the problem

Monitoring and Controlling

The details of the problem are listed line by line. The messages are listed below.

• Internal error

• Fan related error

• Sensor error

• Lamp cover is open

• Lamp timer failure

• Lamp out

• Internal temperature error

• High-speed cooling in progress

• Lamp replacement notification

• No-signal

No Signal is input to the projector. Check the connection status or check that the power for the signal source is turned on.

• Auto Iris Error

• Power Err. (Ballast)

See the following to deal with problems or warnings.

"Reading the Indicators" p.104

• SNMP should be managed by a network administrator or someone

who is familiar with the network.

• To use the SNMP function to monitor the projector, you need to install the SNMP manager program on your computer.

• The SNMP Agent for this projector complies with version 1 (SNMPv1).

• The managing function using SNMP cannot be used via wireless LAN in Quick mode.

• Up to two destination IP addresses can be saved.

ESC/VP21 Commands

You can control the projector from an external device using ESC/VP21.

Command list

When the power ON command is transmitted to the projector, the power turns on and it enters warm-up mode. When the projector's power has turned on, a colon ":" (3Ah) is returned.

When a command is input, the projector executes the command and returns a ":", and then accepts the next command.

If the command being processed terminates abnormally, an error message is output and a ":" is returned.

Management Using SNMP

By setting SNMP to On in the Configuration menu, notification messages are sent to the specified computer when a problem or warning occurs. This will enable the operator to be notified of problems with projectors even at locations away from the projectors.

Network - Others - SNMP p.98

Item Command

Power ON/OFF On PWR ON

Off PWR OFF

Signal selection Computer1 Auto SOURCE 1F

RGB SOURCE 11

Component SOURCE 14

Computer2 Auto SOURCE 2F

Monitoring and Controlling

Item Command

RGB SOURCE 21

Component SOURCE 24

HDMI SOURCE 30

Video SOURCE 41

S-Video SOURCE 42

USB Display SOURCE 51

USB SOURCE 52

LAN SOURCE 53

A/V Mute On/Off On MUTE ON

Off MUTE OFF

A/V Mute selection Black MSEL 00

Blue MSEL 01

Logo MSEL 02

Add a Carriage Return (CR) code (0Dh) to the end of each command and transmit.

For more details, contact your local dealer or the nearest address provided in the Epson Projector Contact List.

Epson Projector Contact List

• Projector input port name: RS-232C

<At the projector> (PC serial cable) <At the computer>

Signal Name Function

GND Signal wire ground

TD Transmit data

RD Receive data

Cable layouts

Serial connection

• Connector shape: D-Sub 9-pin (male)

Communications protocol

• Default baud rate setting: 9600 bps

• Data length: 8 bit

• Parity: None

• Stop-bit: 1 bit

• Flow control: None

Monitoring and Controlling

About PJLink (EB-X25/EB-W22/EB-X22/EB-X20 Only)

PJLink Class1 was established by the JBMIA (Japan Business Machine and Information System Industries Association) as a standard protocol for controlling network-compatible projector's as part of their efforts to standardize projector control protocols.

The projector complies with the PJLink Class1 standard established by the JBMIA.

See the Network menu for more information on PJLink network settings.

"Network Menu" p.91

It complies with all commands except for the following commands defined by PJLink Class1, and agreement was confirmed by the PJLink standard adaptability verification.

URL:http://pjlink.jbmia.or.jp/english/

• Non-compatible commands

Function PJLink Command

Mute settings Image muting set AVMT 11

Audio muting set AVMT 21

• Input names defined by PJLink and corresponding projector sources

Source PJLink Command

Computer1 INPT 11

Computer2 INPT 12

Video INPT 21

S-Video INPT 22

HDMI INPT 32

Source PJLink Command

USB INPT 41

LAN INPT 52

USB Display INPT 53

• Manufacturer name displayed for "Manufacture name information query"

EPSON

• Model name displayed for "Product name information query"

EPSON 25 EPSON 22

EPSON 20

About Crestron RoomView® (EB-X25/EB-W22/EBX22/EB-X20 only)

Crestron RoomView® is an integrated control system provided by Crestron connected on a network.

The projector supports the control protocol, and can therefore be used in a system built with Crestron RoomView

Visit the Crestron

http://www.crestron.com

The following provides an overview of Crestron RoomView

• Remote operation using a Web browser

You can operate a projector from your computer just like using a remote control.

. It can be used to monitor and control multiple devices

Web site for details on Crestron RoomView®.

Monitoring and Controlling

• Monitoring and control with application software

You can use Crestron RoomView Server Edition provided by Crestron® to monitor devices in the system, to communicate with the help desk, and to send emergency messages. See the following Web site for details.

http://www.crestron.com/getroomview

This manual describes how to perform operations on your computer using a Web browser.

• You can only enter single-byte alphanumeric characters and symbols.

• The following functions cannot be used while using Crestron RoomView

s "Changing Settings Using a Web Browser (Web Control)"

p.70

Message Broadcasting (EasyMP Monitor plug-in)

• If you set Standby Mode to Communication On, you can control the projector even if it is in standby mode (when the power is off).

s ECO - Standby Mode p.99

Express or Crestron RoomView

Start a Web browser on the computer.

Using the operation window

Enter the IP address of the projector in the address field of the Web browser, and press the Enter key on the keyboard.

The operation window is displayed.

Operating a projector from your computer

Displaying the operation window

Check the following before carrying out any operations.

• Make sure the computer and projector are connected to the network. When communicating with a wireless LAN, connect in Advanced mode.

"Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only)" p.93

• Set Crestron RoomView to On from the Network menu.

Network - Others - Crestron RoomView p.84

You can perform the following operations when you click the buttons.

Button Function

Power Turns the projector power on or off.

Vol-/Vol+ Adjusts the volume.

Monitoring and Controlling

Button Function

A/V Mute Turns the video and audio on or off.

s "Hiding the Image and Sound Temporarily (A/V Mute)" p.57

Switch to the image from the selected input source. To display input sources that

are not shown in Source List, click (a) or (b) to scroll up or down. You can change the source name if necessary.

You can perform the following operations when you click the buttons. To display

buttons that are not shown in Source List, click (c) or (d) to scroll left or right.

Button Function

Freeze Images are paused or unpaused.

s "Freezing the Image (Freeze)" p.58

Contrast You can adjust the difference between light and dark in

the images.

Brightness You can adjust the image brightness.

Color You can adjust the color saturation for the images.

Sharpness You can adjust the image sharpness.

Zoom

Click the [z] button to enlarge the image without changing the projection size. Click the [x] button to reduce an image that was enlarged with the [z] button. Click the [ position of an enlarged image.

"Enlarging Part of the Image (E-Zoom)" p.59

], [ ], [ ], or [ ] buttons to change the

Button Function

Menu Displays and closes the Configuration menu.

Auto If clicked while projecting analog RGB signals from

Search Changes to the next input source that is sending an

Esc Performs the same operation as the [Esc] button on the

You can perform the following operations when you click the tabs.

Tab Function

Contact IT Help Displays the Help Desk window. Used to send messages

Info Displays information on the projector that is currently

Tools Changes settings in the projector that is currently

Performs the same operation as the [ remote control.

s "Remote Control" p.16

Computer1 port or Computer2 port, automatically optimizes the image by adjusting the Tracking, Sync., and Position.

image. s "Automatically Detect Input Signals and Change the

Projected Image (Source Search)" p.35

remote control. s "Remote Control" p.16

to, and receive messages from, the administrator using Crestron RoomView

connected.

connected. See the next section.

Express.

] button on the

The [ ], [ ], [ ], and [ ] buttons perform the same operations as the [ ],

], [ ], and [ ] buttons on the remote control. You can perform the

[

following operations when you click the other buttons.

Using the tools window

The following window is displayed when you click the Tools tab on the operation window. You can use this window to change settings in the projector that is currently connected.

Monitoring and Controlling

Crestron Control

Make settings for Crestron

central controllers.

Item Function

DHCP Select the Enabled check box to use DHCP. You cannot

enter an IP address if DHCP is enabled.

IP Address Enter the IP address to assign to the currently connected

projector.

Subnet Mask Enter a subnet mask for the currently connected

projector.

Default Gateway Enter the gateway address for the currently connected

projector.

Send Click this button to confirm the changes made to the

Projector.

Admin Password

Select the Enabled check box to require a password to open the Tools window. The following items can be set.

Projector

The following items can be set.

Item Function

Projector Name Enter a name to differentiate the projector that is

currently connected from other projectors on the network. (The name can contain up to 15 single-byte alphanumeric characters.)

Location Enter an installation location name for the projector

that is currently connected on the network. (The name can contain up to 32 single-byte alphanumeric characters and symbols.)

Assigned To Enter a user name for the projector. (The name can

contain up to 32 single-byte alphanumeric characters and symbols.)

Item Function

New Password Enter the new password when changing the password to

open the Tools window. (The name can contain up to 26 single-byte alphanumeric characters.)

Confirm Enter the same password as you entered in New

Password. If the passwords are not the same, an error is

displayed.

Send Click this button to confirm the changes made to the

Admin Password.

User Password

Select the Enabled check box to require a password to open the operation window on the computer. The following items can be set.

Monitoring and Controlling

Item Function

New Password Enter the new password when changing the password to

open the operation window. (The name can contain up to 26 single-byte alphanumeric characters.)

Confirm Enter the same password as you entered in New

Password. If the passwords are not the same, an error is

displayed.

Send Click this button to confirm the changes made to the

User Password.

About Event ID

Check the numbers and then apply the following countermeasures. If you cannot resolve the problem, contact your network administrator, or contact your local dealer or the nearest address provided in the Epson Projector Contact List.

Epson Projector Contact List

Event ID Cause Remedy

0432 0435

Failed to startup EasyMP Network Projection. Restart the projector.

0434 0481 0482 0485

0433 Cannot play transferred images. Restart EasyMP Network Projection.

0484 Communication was disconnected from the computer.

0483 04FE

0479 04FF

0891 Cannot find an access point with the same SSID. Set the computer, the access point, and the projector to the same SSID.

0892 The WPA/WPA2 authentication type does not match. Check that the wireless LAN security settings are correct.

0893 The WEP/TKIP/AES encryption type does not match.

0894 Communication was disconnected because the projector connected to an

0898 Failed to acquire DHCP. Check that the DHCP server is operating correctly. If you are not using DHCP,

0899 Other communication errors If restarting the projector or EasyMP Network Projection does not solve the

Network communication is unstable. Check the network communication status, and reconnect after waiting for a

while.

EasyMP Network Projection ended unexpectedly. Check the network communication status, and then restart the projector.

A system error occurred in the projector. Restart the projector.

s Security p.95

Contact your network administrator for more information.

unauthorized access point.

turn off the DHCP setting. s Wireless LAN - IP Settings p.93

problem, contact your local dealer or the nearest address provided in the Epson Projector Contact List.

s Epson Projector Contact List

Configuration Menu

This chapter explains how to use the Configuration menu and its functions.

Using the Configuration Menu

This section explains how to use the Configuration menu.

Although steps are explained using the remote control as an example, you can perform the same operations from the control panel. Check the guide under the menu for the available buttons and their operations.

Display the Configuration menu screen.

Select a top menu item.

Select a submenu item.

Change settings.

Press the [Menu] button to finish making settings.

List of Functions

Configuration Menu Table

Settable items vary depending on the model being used and the image signal and source being projected.

Top Menu Name Submenu Name Items or Setting Values

Image menu s p.85

Signal menu s p.86

Color Mode Dynamic, Presentation, Theatre,

Photo, Sports, sRGB, Blackboard, and Whiteboard

Brightness -24 - 24

Contrast -24 - 24

Color Saturation -32 - 32

Tint -32 - 32

Sharpness -5 - 5

Abs. Color Temp. 5000K to 10000K

Color Adjustment Red: -16 to 16

Green: -16 to 16 Blue: -16 to 16

Auto Iris Off, Normal, High Speed

Auto Setup On and Off

Resolution Auto, Wide, and Normal

Tracking -

Sync. 0 - 31

Top Menu Name Submenu Name Items or Setting Values

Video Signal Auto, NTSC, NTSC4.43, PAL,

M-PAL, N-PAL, PAL60, and SECAM

Aspect Normal, Auto, 4:3, 16:9, Full,

Zoom, and Native

Overscan Auto, Off, 4%, and 8%

Image Processing Fine, Fast

Settings menu s p.88

Extended menu s p.89

Keystone H/V-Keystone and Quick Corner

Zoom (EB-S21/EB-S17 only)

Control Panel Lock Full Lock, Partial Lock, and Off

Pointer Shape Pointer 1, 2, and 3

Volume 0 - 10

Remote Receiver Front/Rear, Front, Rear, and Off

User Button Power Consumption, Info,

Pattern Pattern Display, Pattern Type,

Display Messages, Display Background,

User's Logo -

Progressive, Resolution, and Pattern Display

User Pattern, and Test Pattern

Startup Screen, and A/V Mute

Position Up, Down, Left, and Right

Progressive Off, Video, and Film/Auto

Noise Reduction Off, NR1, and NR2

HDMI Video Range Auto, Normal, and Expanded

Input Signal Auto, RGB, and Component

Projection Front, Front/Ceiling, Rear, and

Rear/Ceiling

Operation Direct Power On, High Altitude

Mode, Startup Source Search

A/V Settings A/V Output, Audio Output,

HDMI Audio Output

Language 15 or 36 languages

ECO menu Power Consumption Normal and ECO

List of Functions

Top Menu Name Submenu Name Items or Setting Values

s p.99

Info menu s p.100

Reset menu s p.101

*1 The number of supported languages differs depending on the region where the

projector is used.

Light Optimizer On and Off

Sleep Mode On and Off

Sleep Mode Timer 0 - 30

Lens Cover Timer On and Off

A/V Mute Timer On and Off

Standby Mode Communication On and

Communication Off

ECO Display On and Off

Lamp Hours -

Source -

Input Signal -

Resolution -

Video Signal -

Refresh Rate -

Sync Info -

Status -

Serial Number -

Version -

Event ID -

Reset All -

Reset Lamp Hours -

Network menu

Top Menu Name Submenu Name Setting Values

Basic menu s p.93

Wireless LAN menu (EB-X21/EB-S21/EB-

X17/EB-S17 only) s p.93

Security menu (EB-X21/EB-S21/EB-

X17/EB-S17 only) s p.95

Projector Name -

PJLink Password (EB-X25/EB-W22/EB-

X22/EB-X20 only)

Web Control Password -

Projector Keyword On and Off

Wireless LAN Power On and Off

Connection Mode Quick, Advanced

Channel 1ch, 6ch, 11ch

Wireless LAN Sys. 802.11b/g and 802.11b/g/n

SSID Auto Setting On and Off

SSID -

IP Settings DHCP, IP Address, Subnet Mask,

SSID Display On and Off

IP Address Display On and Off

Security No, WEP, WPA-PSK, and WPA2-

WEP Encryption 128Bit and 64Bit

Format ASCII and HEX

Key ID 1, 2, 3, 5

Encryption Key 1, En‐ cryption Key 2, Encryp‐ tion Key 3, and Encryp‐ tion Key 4

and Gateway Address

PSK

Authentication Type Open and Shared

Passphrase -

List of Functions

Top Menu Name Submenu Name Setting Values

Wired LAN menu (EB-X25/EB-W22/

EB-X22/EB-X20 only) s p.96

IP Settings DHCP, IP Address, Subnet Mask,

and Gateway Address

IP Address Display On and Off

"Automatically Detect Input Signals and Change the Projected Image

(Source Search)" p.35

Mail menu s p.97

Others menu s p.98

Mail Notification On and Off

SMTP Server -

Port Number -

Address 1 Setting, Ad‐ dress 2 Setting, and Ad‐ dress 3 Setting

SNMP On and Off

Trap IP Address 1 and Trap IP Address 2

AMX Device Discovery On and Off

Crestron RoomView (EB-X25/EB-W22/EB-

X22/EB-X20 only)

Bonjour On and Off

Message Broadcasting On and Off

On and Off

Image Menu

Settable items vary depending on the image signal and source currently being projected. Setting details are saved for each image signal.

Submenu Function

Color Mode

Brightness

Contrast

Color Saturation

Tint

You can select the quality of the image to suit your surroundings. s "Selecting the Projection Quality (Selecting Color Mode)"

p.46

You can adjust the image brightness.

You can adjust the difference between light and dark in the images.

You can adjust the color saturation for the images.

(Adjustment is possible when a component video signal is being input. If a composite video or S-video signal is input, adjustment is only possible when NTSC signals are being input.)

You can adjust the image tint.

Sharpness

Abs. Color Temp.

You can adjust the image sharpness.

(This item cannot be selected if Color Mode is set to Adjusts the tint for the images. The image is tinted blue when you

raise the color temperature, and tinted red when you lower it.

sRGBg.)

List of Functions

Submenu Function

Color Adjust‐ ment

(This item cannot be selected if Color Mode is set to You can adjust the color strength for Red, Green, and Blue

individually.

sRGBg.)

"Automatically Detect Input Signals and Change the Projected Image

(Source Search)" p.35

Auto Iris

Reset

(This item can be set only if Color Mode is set to Dynamic or Theatre.)

Set to Normal or High Speed to adjust the iris to obtain the optimum light for images being projected. Select High Speed to make faster iris corrections to match the speed of the scene.

The setting is stored for each Color Mode. s "Setting Auto Iris" p.47

You can reset all adjustment values for the Image menu to their default settings. See the following to return all menu items to their default settings.

s "Reset Menu" p.101

Signal Menu

Settable items vary depending on the image signal and source currently being projected. Setting details are saved for each image signal.

You cannot make settings on the Signal menu when the source is USB Display, USB, or LAN.

Submenu Function

Auto Setup

Resolution

Tracking

Set to On to automatically adjust Tracking, Sync., and Position to the optimum state when the input signal changes.

Set to Auto to automatically identify the resolution of the input signal. If images are not projected correctly when set to Auto, for example if some of the image is missing, adjust to Wide for wide screens, or set to Normal for 4:3 or 5:4 screens depending on the connected computer.

You can adjust computer images when vertical stripes appear in the images.

Sync.

Position

You can adjust computer images when flickering, fuzziness, or interference appear in the images.

You can adjust the display position up, down, left, and right when a part of the image is missing so that the whole image is projected.

List of Functions

Submenu Function

Progressive

Noise Reduction

HDMI Video Range

Input Signal

(When a component video or RGB video is being input, this setting can only be adjusted if the signal being input is an interlaced signal (480i/576i/1080i). This cannot be set when a digital RGB signal is being input.)

Interlaceg (i) signal is converted to Progressiveg (p). (IP conversion)

Off: Ideal for images with a large amount of movement. Video: Ideal for general video images. Film/Auto: This is ideal for movie films, computer graphics, and

animation.

(This cannot be set when a digital RGB signal is input or when projecting an interlaced signal while Progressive is set to Off.)

Smoothes out rough images. There are two modes. Select your favorite setting. It is recommended that this is set to Off when viewing image sources in which noise is very low, such as for DVDs.

When the projector's HDMI port is connected to a DVD player, set the projector's video range according to the DVD player's video range setting.

You can select input signal from Computer port. If set to Auto, the input signal is set automatically according to

the connected equipment. If colors do not appear correctly when set to Auto, select the

appropriate signal according to the connected equipment.

Submenu Function

Overscan

Image Process‐ ing

Reset

Changes the output image ratio (the range of the projected image). You can set the cropping range to Off, 4%, or 8%. When the source is HDMI, Auto is available. When Auto is selected, it automatically changes to Off or 8% according to the input signal.

Changes settings for image processing. Fast: Images are displayed quicker. The pen's tracking delay is

improved when using the optional interactive unit. Fine: Images are displayed in higher quality.

You can reset all adjustment values on the Signal menu to their default settings, except for Input Signal and Image Processing.

See the following to return all menu items to their default settings.

s "Reset Menu" p.101

Video Signal

Aspect

You can select the input signal from the Video port. If set to Auto, video signals are recognized automatically. If interference appears in the image or a problem occurs such as no image is being projected when set to Auto, select the appropriate signal according to the connected equipment.

You can set the s "Changing the Aspect Ratio of the Projected Image" p.47

aspect ratiog for projected images.

List of Functions

Settings Menu

Submenu Function

Keystone

You can correct keystone distortion.

• When H/V-Keystone is selected: Adjust V-Keystone and H-Keystone to correct horizontal and vertical keystone distortion. You can also set H-Keystone Adjuster and Auto VKeystone to On or Off.

• When Quick Corner is selected: Select and correct the four corners of the projected image. s "Quick Corner" p.42

Submenu Function

Pointer Shape

Volume

Remote Receiver

User Button

You can select the shape of the pointer.

Pointer 1:

Pointer 2:

Pointer 3:

"Pointer Function (Pointer)" p.58

You can adjust the volume. Setting values are saved for each source.

You can limit the reception of the operation signal from the remote control.

When set to Off, you cannot perform any operations from the remote control. If you want to make operations from the remote control, hold down the [Menu] button on the remote control for at least 15 seconds to reset the setting to its default value.

You can select and assign an item from the Configuration menu with the remote control's [User] button. Pressing the [User] button directly displays the assigned menu item selection/ adjustment screen, allowing you to make one-touch changes to settings/adjustments. You can assign one of the following items to the [User] button.

Power Consumption, Info, Progressive, Resolution, and Pattern Display

Zoom (EB-S21/EB-S17 only)

Control Panel Lock

Adjusts the size of the projected image.

You can use this to restrict operation of the projector's control panel.

s "Restricting Operation (Control Panel Lock)" p.67

List of Functions

Submenu Function

Pattern

Pattern Display: Display a pattern. Pattern Type: You can select from Patterns 1 to 4 or User

Pattern. Patterns 1 to 4 display projection lines such as ruled lines or a grid.

Pattern 1:

Pattern 3:

User Pattern: Captures a user pattern.

"Saving User Pattern" p.63

Test Pattern: When the projector is set up, a test pattern is displayed so that you can adjust the projection status without connecting equipment. While the test pattern is displayed, zoom, focus adjustments, and keystone correction can be performed. To cancel the test pattern, press the [Esc] button on the remote control or the control panel.

Pattern 2:

Pattern 4:

Attention

If a pattern is displayed for a long time, a residual image may be visible in projected images.

Reset

You can reset all adjustment values on the Settings menu to their default settings, except for Zoom (EB-S21/EB-S17 only) and User Button.

See the following to return all menu items to their default settings.

"Reset Menu" p.101

Extended Menu

Submenu Function

Display

User's Logo

You can make settings related to the projector's display. Messages: When set to Off, the following items will not be

displayed. Item names when the Source, Color Mode, or Aspect Ratio

is changed, messages when no signal is being input, and warnings such as High Temp Warning.

Display Background to Black, Blue, or Logo when no image signal is available.

Startup Screen

when projection starts.

A/V Mute remote control's [A/V Mute] button is pressed to Black, Blue, or Logo.

You can change the user's logo that is displayed as a background during Display Background, A/V Mute, and so on.

s "Saving a User's Logo" p.61

: You can set the screen displayed when the

: You can set the screen background

: Set to On to display the User's Logo

List of Functions

Submenu Function

Projection

Operation

Select from one of the following projection methods depending on how the projector is installed.

Front, Front/Ceiling, Rear, and Rear/Ceiling You can change the setting as follows by pressing down

the [A/V Mute] button on the remote control for about five seconds.

FrontWFront/Ceiling RearWRear/Ceiling

s "Installation Methods" p.22

Direct Power On: Set to On to turn on the projector simply by plugging it in.

When the power cord is plugged in, note that the projector turns on automatically in cases such as a power outage being restored.

High Altitude Mode: Set to On when using the projector above an altitude of 1500 m.

Startup Source Search: Set to On to project images from the port currently receiving an image when the projector starts.

Submenu Function

A/V Settings

A/V Output: (This item can be set only if Standby Mode is set to Communication On.)

Set to Always On to output audio and images to external equipment when the projector is in standby status. Audio is output from the speaker.

The fan may rotate in standby status. Also,

Audio Output: Select the audio output when projecting images from the Computer1, Computer2, S-Video, or Video input ports. When set to Auto, the audio from the audio input port that matches each image input port is output. In standby status, the audio from the last selected source is output.

s "Connecting Equipment" p.25 HDMI Audio Output: Select the audio source when

projecting images from the HDMI input port. Select HDMI to output the image's audio as it is.

when the projector wakes from standby status, the fan may make a loud noise as it rotates, but this is not a malfunction.

Language

Reset

*1When User's Logo Protect is set to On in Password Protect, settings related

to user's logo cannot be changed. You can make changes after setting User's Logo Protect to Off.

s "Managing Users (Password Protect)" p.65

*2 Except for High Altitude Mode and Startup Source Search. *3Except for A/V Output.

You can set the language for messages and menus.

You can reset the adjustment values for Display

Operation

to their default settings. See the following to return all menu items to their default

settings. s "Reset Menu" p.101

, and A/V Settings*3 from the Extended menu

List of Functions

Network Menu

When Network Protect is set to On in Password Protect, a message is displayed and the network settings cannot be changed. Set Network Protect to Off and then configure the network.

"Setting Password Protect" p.65

Submenu Function

Net. Info. - Wire‐ less LAN

(EB-X21/EB-S21/ EB-X17/EB-S17 only)

Displays the following network setting status information.

• Connection Mode

• Antenna Level

• Projector Name

• SSID

• DHCP

• IP Address

• Subnet Mask

• Gateway Address

• MAC Address

• Region Code

Submenu Function

Net. Info. Wired LAN

(EB-X25/EB-W22/ EB-X22/EB-X20 only)

Network Config‐ uration

* Displays available region information for the Wireless LAN unit being used.

For more details, contact your local dealer or the nearest address provided in the Epson Projector Contact List.

s Epson Projector Contact List

• By using a Web browser of a computer connected to the projector

on a network, you can set functions and control the projector. This function is called Web Control. You can easily enter text using a keyboard to make settings for Web Control such as Security settings.

s "Changing Settings Using a Web Browser (Web Control)"

p.70

• Contact your network administrator for details on network settings.

Displays the following network setting status information.

• Projector Name

• DHCP

• IP Address

• Subnet Mask

• Gateway Address

• MAC Address

The following menus are available for setting Network items.

Basic, Wireless LAN, Security, Wired LAN, Mail, Others, Reset, and Complete

Notes on operating the Network menu

Selecting from the top menu and sub menus, and changing selected items is the same as making operations from the Configuration menu.

When done, make sure you go to the Complete menu, and select Yes, No, or Cancel. When you select Yes or No, you are returned to the Configuration menu.

List of Functions

Yes: Saves the settings and exits the Network menu.

No: Does not save the settings and exits the Network menu.

Cancel: Continues displaying the Network menu.

Soft keyboard operations

The Network menu contains items that require input of alphanumerics during setup. In this case, the following software keyboard is displayed.

Press the [

a][b

] buttons (or the [Wide][Tele]) on the control panel. Use the buttons

[ to move the cursor to the desired key, and then press the [ Enter figures by holding down the [Num] button on the remote control, and pressing the numeric buttons. After inputting, press Finish on the keyboard to confirm your input. Press Cancel on the keyboard to cancel your input.

][ ][ ][ ] buttons on the remote control or the [w][v]

] button.

• Each time the CAPS key is selected and the [ ] button is pressed, it

sets and changes between upper case and lower case letters.

• Each time the SYM1/2 key is selected and the [

sets and changes the symbol keys for the section enclosed by the frame.

] button is pressed, it

List of Functions

Basic menu

Submenu Function

Projector Name

Displays the projector name used to identify the projector when connected to a network.

When editing, you can enter up to 16 single-byte alphanumeric characters.

Submenu Function

Projector Key‐ word

When set to On, you have to enter the keyword when you try to connect the projector to a computer via a network. As a result, you can prevent presentations from being interrupted by connections from other computers. Normally this should be set to On.

s EasyMP Network Projection Operation Guide s EasyMP Multi PC Projection Operation Guide

Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only)

PJLink Password

(EB-X25/EB-W22/ EB-X22/EB-X20 only)

Web Control Password

Set a password to use when you access the projector using compatible PJLink software. You can enter up to 32 single-byte alphanumeric characters.

Set a password to use when making settings and controlling the projector using Web Control. Enter no more than eight singlebyte alphanumeric characters. Web Control is a computer function that allows you to set up and control the projector by using the Web browser on a computer connected on a network.

s "Changing Settings Using a Web Browser (Web Control)"

p.70

Submenu Function

Wireless LAN Power

Turn On when connecting the projector to the computer over wireless LAN.

If you do not want to connect via wireless LAN, turn it Off to prevent unauthorized access by others.

The default value is On.

List of Functions

Submenu Function

Connection Mode

Channel

Wireless LAN Sys.

SSID Auto Set‐ ting

SSID

Set the connection mode to use when connecting the projector and a computer via a wireless LAN.

If you select Quick, a small network is created automatically by the projector and computer. It is used with EasyMP Network Projection. If SSID Auto Setting is set to On, the projector becomes an easy access point; if it is set to Off, the network is created in

If you select Advanced, the connection is established in Infrastructure modeg.

(This can only be set if Connection Mode is set to Quick.) Select the frequency band used by the wireless LAN from 1ch,

6ch, or 11ch. The default value is 11ch.

Set the Wireless LAN system to either 802.11b/g or

802.11b/g/n.

The default value is 802.11b/g/n.

(This can only be set if Connection Mode is set to Quick.) When you set this to On, you can search for the projector more

quickly from among multiple projectors. SSID is set automatically.

When connecting to multiple projectors from one computer in Quick mode, set this to Off, and set the same SSID in all the projectors that will connect.

(This item can only be set when SSID Auto Setting is set to Off.)

Enter an system in which the projector participates, enter the SSID.

You can enter up to 32 single-byte alphanumeric characters.

Ad hoc modeg.

SSIDg. When an SSID is provided for the wireless LAN

Submenu Function

IP Settings

SSID Display

IP Address Dis‐ play

(This item can only be set if Connection Mode is set to Advanced.)

You can make network settings. DHCP: Set to On to make network settings using

is set to On, you cannot set any more addresses. IP Address: You can input the

projector. You can enter a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

Subnet Mask: You can input the You can enter a number from 0 to 255 in each field of the address. However, the following subnet masks cannot be used.

0.0.0.0, 255.255.255.255 Gateway Address: You can input the IP address for the gateway

for the projector. You can enter a number from 0 to 255 in each field of the address. However, the following cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

To prevent the screen, set this to Off.

To prevent the Standby screen, set this to Off.

SSIDg from being displayed on the LAN Standby

IP addressg from being displayed on the LAN

DHCPg. If this

IP addressg assigned to the

subnet maskg for the projector.

Gateway addresses

List of Functions

Security menu (EB-X21/EB-S21/EB-X17/EB-S17 only)

Available when the Wireless LAN unit is installed.

Submenu Function

Security

WEP Encryption

Format

Select the security type from the items that are displayed. When setting up Security, follow the instructions from the

administrator of the network system you are about to access.

You can set the encryption for WEP encryption.

128Bit: Uses 128 (104) bit encoding. 64Bit: Uses 64 (40) bit encoding.

You can set the input method for the WEP encryption key.

ASCII: Input text. HEX: Input in HEX (hexadecimal).

Submenu Function

Encryption Key 1/Encryption Key 2/Encryption Key 3/Encryption Key 4

Authentication Type

Passphrase

You can enter the key used for WEP encryption. Enter the key in single-byte characters following instructions from the network administrator for the network in which the projector participates. The type of character and the number that can be entered differ according to the WEP Encryption and Format settings.

128Bit - ASCII: Single-byte alphanumeric, 13 characters. 64Bit - ASCII: Single-byte alphanumeric, 5 characters. 128Bit - HEX: 0 to 9 and A to F, 26 characters 64Bit - HEX: 0 to 9 and A to F, 10 characters

Set the WEP authentication type.

Open: Uses open system authentication. Shared: Uses shared key authentication.

Enter the passphrase. You can enter at least 8 and up to 63 singlebyte alphanumeric characters.

When using it with EasyMP Network Projection, you do not need to input the passphrase in the computer if it is the initial (default) passphrase.

In the interests of security, we recommended that you change the passphrase periodically. If the network settings are initialized, it returns to the initial passphrase.

s "Reset menu" p.99 You can enter up to 32 characters on the Configuration menu.

When entering more than 32 characters, use your Web browser to enter the text.

s "Changing Settings Using a Web Browser (Web Control)"

p.70

In Quick mode, the initial passphrase is set.

Key ID

Selects the WEP encryption ID key.

Type of security

When the Wireless LAN unit is installed and you are using Advanced, it is strongly recommended that you set security. Select one of the following security methods.

List of Functions

• WEP

Data is encrypted with a code key (WEP key). This mechanism prevents communication unless the encrypted keys for the access point and the projector match.

• WPA

This is an encryption standard that improves security which is a weak point of WEP. Although there are multiple kinds of WPA encryption methods, this projector uses TKIP and AES.

WPA also includes user authentication functions. WPA authentication provides two methods: using an authentication server, or authenticating between a computer and an access point without using a server. This projector supports the latter method, without a server.

For setting details, follow the directions from the network

administrator of your network.

Wired LAN menu (EB-X25/EB-W22/EB-X22/EB-X20 only)

Submenu Function

IP Settings

You can make settings related to the following addresses. DHCPg: Set to On to configure the network using DHCP. If this

is set to On, you cannot set any more addresses. IP Addressg: You can input the IP address assigned to the

projector. You can input a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

Subnet Maskg: You can input the subnet mask for the projector. You can input a number from 0 to 255 in each field of the address. However, the following subnet masks cannot be used.

0.0.0.0, 255.255.255.255 Gateway Addressg: You can input the IP address for the gateway

for the projector. You can input a number from 0 to 255 in each field of the address. However, the following gateway addresses cannot be used.

0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

List of Functions

Submenu Function

IP Address Dis‐ play

To prevent the IP address from being displayed on Network Info in the Network Menu and on the LAN Standby screen, set this to Off.

Mail menu

When this is set, you receive an email notification if a problem or warning occurs in the projector.

"Using the Mail Notification Function to Report Problems" p.72

Submenu Function

Port Number

Address 1 Set‐ ting/Address 2 Setting/Address 3 Setting

You can input the port number for the SMTP server. The default value is 25. You can input numbers between 1 to 65535.

You can input the email address of the destination to send the notification email to. You can register up to three destinations. You can enter up to 32 single-byte alphanumeric characters for the email addresses.

You can select the problems or warnings to be notified about by email. When the selected problem or warning occurs in the projector, an email is sent to the specified destination address notifying that a problem or warning has occurred. You can select multiple items from the displayed items.

Submenu Function

Mail Notification

SMTP Server

Set to On to send an email to the preset addresses when a problem or warning occurs with a projector.

You can input the projector.

You can enter a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used.

127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from

0 to 255)

IP addressg for the SMTP server for the

List of Functions

Others menu

Submenu Function

SNMP

Set to On to monitor the projector using SNMP. To monitor the projector, you need to install the SNMP manager

program on your computer. SNMP should be managed by a network administrator.

The default value is Off.

Submenu Function

Crestron Room‐ View

(EB-X25/EB-W22/ EB-X22/EB-X20 only)

Bonjour

Message Broad‐ casting

Set this to On only when monitoring or controlling the projector over the network using Crestron RoomView this to Off.

s "About Crestron RoomView EB-X20 only)" p.75

When this is set to On, the following functions are not available.

• Web control

• Message Broadcasting (EasyMP Monitor plugin)

Set this to On when connecting to the network using Bonjour. See Apple's Web site for more information on the Bonjour

service. s http://www.apple.com/

You can switch the EPSON Message Broadcasting function to enable or disable.

. Otherwise, set

(EB-X25/EB-W22/EB-X22/

Trap IP Address 1/Trap IP Ad‐ dress 2

AMX Device Dis‐ covery

You can register up to two IP addresses for the SNMP trap notification destination. You can enter a number from 0 to 255 in each field of the address. However, the following IP addresses cannot be used. 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a number from 0 to 255)

When the projector is connected to a network, set this to On to allow the projector to be detected by Set this to Off if you are not connected to an environment controlled with a controller from AMX or AMX Device Discovery.

AMX Device Discoveryg.

List of Functions

Reset menu

Resets all of the network settings.

Submenu Function

Reset network settings.

To reset all of the Network settings, select Yes.

ECO Menu

When you make ECO menu settings, the projector performs functions to save power. When power saving settings have been enabled, a leaf icon is displayed next to each submenu.

Submenu Function

Power Consump‐ tion

You can set the lamp brightness to one of two settings. Select ECO if the images being projected are too bright, such as when projecting images in a dark room or onto a small screen. When ECO is selected, power consumption during projection decreases, and fan rotation noise is reduced.

When using at high altitude or in locations subject to high temperatures, you may not be able to change settings.

Light Optimizer

(This item can only be set when Power Consumption is set to Normal.)

When set to On, the lamp brightness is adjusted according to the image being projected. This helps to reduce the amount of electricity being used by lowering the lamp's brightness according to the scene being projected.

The setting is stored for each Color Mode.

List of Functions

100

Submenu Function

Sleep Mode

Sleep Mode Tim‐ er

Lens Cover Timer

A/V Mute Timer

Standby Mode

ECO Display

Reset

When set to On, this automatically stops projection when no image signal is being input and no operations are carried out for a specified length of time. Also, if no image signal is input for approximately five minutes, the lamp dims until the power turns off. When an image signal is input, the projector returns to normal operating status.

When Sleep Mode is set to On, you can set the time before the projector automatically turns off within a range of 1 to 30 minutes.

When set to On, this turns off the power automatically 30 minutes after the lens cover is closed. Also, if the lens cover is closed for approximately five minutes, the lamp dims until the power turns off. When the lens cover is opened, the projector returns to normal operating status.

When set to On, this turns off the power automatically 30 minutes after A/V mute is enabled. Also, if A/V mute is enabled, the lamp dims until the power turns off. When A/V mute is disabled, the projector returns to normal operating status.

If you set Communication On, you can perform the following operations even if the projector is in standby mode.

• Monitoring and controlling the projector over a network.

• Outputting audio and images to external equipment. (Only

when A/V Output is set to Always On.)

When set to On, when the lamp brightness changes from normal to low or low to normal, leaf icons are displayed at the bottomleft of the projected screen to indicate the power-saving status.

You can reset all adjustment values for the ECO menu to their default settings. See the following to return all menu items to their default settings.

s "Reset Menu" p.101

Info Menu (Display Only)

Lets you check the status of the image signals being projected and the status of the projector. Items that can be displayed vary depending on the source currently being projected. Depending on the model used, some input sources are not supported.

"Automatically Detect Input Signals and Change the Projected Image

(Source Search)" p.35

Submenu Function

Lamp Hours

Source

Input Signal

You can display the cumulative lamp operating time When the lamp replacement time is reached, the characters

are displayed in yellow.

You can display the source name for the connected equipment currently being projected.

You can display the content of Input Signal set in the Signal menu according to the source.

Resolution

Refresh Rate

You can display the resolution.

You can display the

refresh rateg.

Epson EB-X20, EB-W22, EB-S17 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Notations Used in This Guide

Contents

Introduction

Projector Features

Quick and Easy Set up, Projection, and Storage

Connecting with a USB cable and projecting (USB Display)

Detecting projector movements and automatically correcting image distortion

Horizontal keystone adjuster

Useful Functions for Projecting Images
