Epson® SureLab® D700 Series

4 Remove all the packaging materials and tape from inside the roll paper

Start Here

IMPORTANT: Before using this product, make sure you read these instructions
and the safety instructions in the online Operation Guide.

Choose a location for the printer

Choose a location for the printer that is near a wall outlet where the power cord
can be easily unplugged. Avoid places subject to rapid changes in temperature
and humidity. Also keep the printer away from direct sunlight, strong light, or
heat sources.

Make sure to place the printer on a flat, stable surface with enough space on
all sides.

5 Grip the handle to release the roll paper feeder and pull it out.

feeder.

13.9 in.

(354 mm)

1.2 in.

(30 mm)

16.9 in.

(430 mm)

1.2 in.

(30 mm)

(460 mm)

Unpack

1 Make sure you have these items:

18.1 in.

1.2 in.

(30 mm)

6 Remove the spindle and set it aside.

11.8 in.

(300 mm)

7 Push the roll paper feeder back into the printer.
8 Reattach the scrap paper box.

Limited

warranty

Printer

Power cord

2 Remove all of the packaging materials and tape from the outside of the

printer.

3 Remove the scrap paper box.

9 Open the ink cartridge covers and remove the packaging materials and

tape from inside the printer.

Install ink cartridges

7 The printer starts charging the ink. This takes

about 20 minutes.

1 Remove the ink cartridges from their packages.

Caution: Do not touch the green chip on top of the cartridge.

2 Insert each cartridge into the correct slot for its color.

3 Remove and reinsert the maintenance cartridge.

Caution: Do not turn off or unplug the printer while

the power light is flashing. Also, do not open the ink
cartridge covers during the charging process.

Note: The first time you install ink cartridges, the printer uses some ink to

charge the printing system, so print yields may be lower with the first cartridges.
Subsequent ink cartridges will last for their full rated yield.

Load paper

1 Make sure the printer is on.
2 Stand the spindle on its side and remove the gray adapter.

4 Close the ink cartridge covers.

3 Remove the paper roll from its packaging. Remove any tape and

protective paper from the end of the roll.

4 Stand the paper roll on its side and wipe the edge of the paper roll with

a soft, clean cloth several times to remove any dust. Flip the paper roll
and repeat the process.

5 Place the paper roll on the spindle unit so that the paper winds

clockwise.

5 Connect the power cord.

6 Press the power button on the printer.

6 Insert the gray adapter onto the spindle and press down until there is no

gap between the adapter and the roll paper.

7 Remove the scrap paper box.

8 Grip the handle to release the roll paper feeder and pull it out.

12 Insert the leading edge of the paper into the paper feed slot until the

paper light turns on.

Note: Make sure the leading edge is cut straight across to avoid paper

feeding problems.

13 Push the roll paper feeder back into the printer.

9 Lift the inner edge guide towards you and slide it to the width of the

roll paper.

10 Load the roll paper spindle into the printer with the gray adapter on the

left.

Note: Make sure the spindle fits between the rollers as shown.

14 Carefully roll the paper into the printer to remove any slack.

Note: If there is any slack in the paper, print quality may decline and paper jams

could occur.

15 Reattach the scrap paper box.

11 Lift the end of the front edge guide and slide it to the width of the roll

paper.

16 Check that the power light is on.

Install the driver

Product support

1 Turn off the printer.
2 Connect a USB cable to the printer and your computer.
3 Download and run your product’s software package:

www.epson.com/support/d700 (U.S.) or
www.epson.ca/support/d700 (Canada).

4 Follow the instructions on the screen to run the setup program.

Removing the paper

If you need to remove the roll paper from the product, make sure you follow
these steps.

1 Check that the printer’s power light is on and not flashing.
2 Remove the scrap paper box and reattach it.

Epson technical support

Visit www.epson.com/support/d700 (U.S.) or

www.epson.ca/support/d700 (Canada) to download software and utilities,

view manuals, get FAQs, or contact Epson.

Epson provides technical support and information on the installation,
configuration, and operation of professional printing products through the
Epson PreferredSM Limited Warranty Plan. Dial [phone], 6 am to 6 pm,
Pacific Time, Monday through Friday. Days and hours of support are subject to
change without notice. Before you call, make sure you have your:

• Printer serial number: _______________________________

• Proof of purchase and date: ___________________________

Note: If you experience difficulty with the toll-free line, call [phone].

Online guides

Instructions for using your printer and maintenance tools.

The power light flashes, then remains lit.

3 Remove the scrap paper box again.
4 Grip the handle to release the roll paper feeder and pull it out.

Recycling

Epson offers a recycling program for end of life hardware and ink cartridges.
Please go to www.epson.com/recycle (U.S.) or www.epson.ca/recycle
(Canada) for information on how to return your products for proper disposal.

Need ink?

You can purchase ink from an Epson authorized reseller. To find the nearest
reseller, call 800-GO-EPSON (800-463-7766).

Epson SureLab D700 replacementinkcartridges

Color Part number

Black

Cyan

Magenta

C13T782100

C13T782200

C13T782300

5 Turn the knor on the left of the roll paper feeder counter clockwise until

the leading edge comes out of the paper feed slot.

You can now remove the roll paper spindle from the printer.

Yellow

Light Cyan

Light Magenta

C13T782400

C13T782500

C13T782600

EPSON and SureLab are registered trademarks and EPSON Exceed Your Vision is a registered logomark
of Seiko Epson Corporation. Epson Preferred is a service mark of Epson America, Inc.

General Notice: Other product names used herein are for identification purposes only and may be
trademarks of their respective owners. Epson disclaims any and all rights in those marks.

This information is subject to change without notice.

© 2018 Epson America, Inc., 7/18

Printed in U.S.A. CPD-56246
