Epson Artisan 837 User's Guide

Artisan
®
837 User's Guide

Contents

Artisan 837 User's Guide.......................................................................................................................... 15
Product Basics .......................................................................................................................................... 16
Loading Paper ........................................................................................................................................... 26
Setting Up the Control Panel.............................................................................................................. 16
Touch Panel Buttons and Lights.................................................................................................... 16
Changing LCD Screen Language.................................................................................................. 18
Product Parts Locations..................................................................................................................... 18
Product Parts - Top........................................................................................................................ 19
Product Parts - Front ..................................................................................................................... 21
Product Parts - Inside.................................................................................................................... 22
Product Parts - Back...................................................................................................................... 23
Selecting Wireless Network Settings From the Touch Panel ............................................................. 23
Loading Paper in the Main Tray ......................................................................................................... 26
Loading Paper in the Photo Tray........................................................................................................ 32
Loading Envelopes............................................................................................................................. 36
Paper Loading Capacity..................................................................................................................... 42
Available Epson Papers..................................................................................................................... 43
Borderless Paper Type Compatibility................................................................................................. 45
Paper or Media Type Settings............................................................................................................ 46
Placing Originals on the Product............................................................................................................. 47
Placing Originals on the Scanner Glass............................................................................................. 47
Placing Originals in the Automatic Document Feeder........................................................................ 48
Copying...................................................................................................................................................... 52
Copying Documents........................................................................................................................... 52
Copying Photos.................................................................................................................................. 54
Paper Type Settings - Copying........................................................................................................... 56
Paper Size Settings - Copying............................................................................................................ 57
Copying Options................................................................................................................................. 58
3
Printing From a Computer........................................................................................................................ 60
Printing with Windows........................................................................................................................ 60
Selecting Basic Print Settings - Windows...................................................................................... 60
Basic Print Options - Windows.................................................................................................. 62
Selecting Advanced Print Settings - Windows............................................................................... 63
Advanced Print Quality Settings - Windows.............................................................................. 65
Advanced Print Options - Windows........................................................................................... 65
Color Management Options - Windows .................................................................................... 66
Selecting Print Layout Options - Windows..................................................................................... 66
Double-sided Printing Options - Windows................................................................................. 70
Print Density Adjustments - Windows....................................................................................... 71
Selecting a Printing Preset - Windows........................................................................................... 71
Printing Your Document or Photo - Windows ................................................................................ 72
Checking Print Status - Windows.............................................................................................. 73
Changing the Language of the Printer Software Screens......................................................... 75
Changing Automatic Update Options ............................................................................................ 77
Printing with Mac OS X 10.5, 10.6, or 10.7......................................................................................... 78
Selecting Basic Print Settings - Mac OS X 10.5/10.6/10.7............................................................. 78
Print Quality Settings - Mac OS X 10.5/10.6/10.7 ..................................................................... 82
Print Options - Mac OS X 10.5/10.6/10.7.................................................................................. 82
Selecting Page Setup Settings - Mac OS X 10.5/10.6/10.7........................................................... 83
Selecting Print Layout Options - Mac OS X 10.5/10.6/10.7........................................................... 83
Selecting Double-sided Printing Settings - Mac OS X 10.5/10.6/10.7 ........................................... 84
Double-sided Printing Options and Adjustments - Mac OS X ................................................... 86
Managing Color - Mac OS X 10.5/10.6/10.7.................................................................................. 87
Color Matching and Color Options - Mac OS X 10.5/10.6/10.7................................................. 88
Printing Your Document or Photo - Mac OS X 10.5/10.6/10.7....................................................... 88
Checking Print Status - Mac OS X 10.5/10.6/10.7 .................................................................... 89
Selecting Printing Preferences - Mac OS X 10.5/10.6/10.7........................................................... 90
Printing Preferences - Mac OS X 10.5/10.6/10.7...................................................................... 91
Printing with Mac OS X 10.4............................................................................................................... 92
4
Selecting Page Setup Settings - Mac OS X 10.4........................................................................... 92
Selecting Basic Print Settings - Mac OS X 10.4............................................................................. 94
Print Quality Settings - Mac OS X 10.4 ..................................................................................... 96
Print Options - Mac OS X 10.4.................................................................................................. 96
Selecting Print Layout Options - Mac OS X 10.4........................................................................... 97
Selecting Double-sided Printing Settings - Mac OS X 10.4 ........................................................... 97
Managing Color - Mac OS X 10.4.................................................................................................. 98
Color Options - Mac OS X 10.4................................................................................................. 99
Selecting Printing Preferences - Mac OS X 10.4........................................................................... 99
Printing Preferences - Mac OS X 10.4.................................................................................... 100
Printing Your Document or Photo - Mac OS X 10.4..................................................................... 100
Checking Print Status - Mac OS X 10.4 .................................................................................. 101
Cancelling Printing Using a Product Button...................................................................................... 102
Scanning.................................................................................................................................................. 103
Starting a Scan................................................................................................................................. 103
Starting a Scan Using the Product Control Panel........................................................................ 103
Scan to Memory Card Options................................................................................................ 105
Changing Default Scan Button Settings.................................................................................. 105
Starting a Scan Using the Epson Scan Icon................................................................................ 106
Starting a Scan from a Scanning Program .................................................................................. 108
Selecting Epson Scan Settings........................................................................................................ 110
Scan Modes ................................................................................................................................ 110
Selecting the Scan Mode............................................................................................................. 110
Scanning in Home Mode ............................................................................................................. 111
Selecting a Scan Area - Home Mode...................................................................................... 114
Available Image Adjustments - Home Mode........................................................................... 117
Selecting a Scan Size - Home Mode....................................................................................... 118
Scanning in Office Mode.............................................................................................................. 120
Selecting a Scan Area - Office Mode...................................................................................... 122
Available Image Adjustments - Office Mode ........................................................................... 124
Scanning in Professional Mode................................................................................................... 125
Available Image Types - Professional Mode........................................................................... 128
Selecting a Scan Area - Professional Mode............................................................................ 128
5
Available Image Adjustments - Professional Mode................................................................. 131
Selecting a Scan Size - Professional Mode ............................................................................ 133
Image Preview Guidelines........................................................................................................... 136
Scan Resolution Guidelines ........................................................................................................ 136
Selecting Scan File Settings........................................................................................................ 137
Available Scanned File Types and Optional Settings.............................................................. 138
Scanning with Mac OS X 10.6/10.7.................................................................................................. 139
Scanning Special Projects................................................................................................................ 140
Scanning to a PDF File................................................................................................................ 141
Restoring Photo Colors as You Scan .......................................................................................... 144
Convert Scanned Documents to Editable Text (OCR)................................................................. 145
Scanning Using OCR - Windows............................................................................................ 145
Scanning Using OCR - Mac OS X 10.4 or 10.5....................................................................... 147
Faxing....................................................................................................................................................... 149
Connecting a Telephone or Answering Machine.............................................................................. 149
Setting Up Fax Features .................................................................................................................. 151
Setting Up Fax Features Using the Product Control Panel.......................................................... 152
Selecting Your Country or Region........................................................................................... 152
Selecting the Date and Time................................................................................................... 153
Entering Fax Header Information............................................................................................ 155
Entering Numbers and Characters for Faxing......................................................................... 158
Selecting Fax Send and Receive Settings.............................................................................. 159
Selecting Fax Communication Settings .................................................................................. 160
Printing Fax Reports............................................................................................................... 161
Restoring Default Fax Settings ............................................................................................... 163
Fax Sending Options .............................................................................................................. 164
Fax Receive Options............................................................................................................... 164
Fax Communications Options................................................................................................. 165
Fax Report Options................................................................................................................. 166
Restore Default Settings Options............................................................................................ 166
Setting Up Fax Features Using the Fax Utility - Windows............................................................ 167
Setting Up Fax Features Using the Fax Utility - Mac OS X.......................................................... 169
Setting Up Speed Dial and Group Dial Lists..................................................................................... 170
6
Setting Up Speed/Group Dial Lists Using the Product Control Panel.......................................... 171
Creating Speed Dial List Entries............................................................................................. 171
Printing Your Speed Dial List.................................................................................................. 173
Creating Group Dial List Entries.............................................................................................. 175
Printing Your Group Dial List................................................................................................... 177
Setting Up Speed/Group Dial Lists Using the Fax Utility - Windows............................................ 178
Setting Up Speed/Group Dial Lists Using the Fax Utility - Mac OS X.......................................... 182
Sending Faxes................................................................................................................................. 183
Sending Faxes from the Product Control Panel........................................................................... 184
Manually Dialing or Redialing Fax Numbers........................................................................... 184
Selecting Fax Numbers from Speed or Group Dial Lists......................................................... 186
Dialing Fax Numbers from a Connected Telephone............................................................... 187
Fax Send Options................................................................................................................... 189
Sending Faxes Using the Fax Utility - Windows .......................................................................... 190
Sending Faxes Using the Fax Utility - Mac OS X......................................................................... 192
Receiving Faxes............................................................................................................................... 195
Fax Reception ............................................................................................................................. 196
Receiving Faxes Automatically (Auto Answer)............................................................................ 196
Receiving Faxes Manually........................................................................................................... 196
Using Memory Cards With Your Product .............................................................................................. 198
Inserting a Memory Card.................................................................................................................. 198
Memory Card Types.................................................................................................................... 199
Memory Card File Specifications................................................................................................. 201
Removing a Memory Card........................................................................................................... 201
Printing from a Memory Card ........................................................................................................... 202
Viewing and Printing Photos........................................................................................................ 202
Viewing and Printing Individual Photos................................................................................... 202
Printing All Photos................................................................................................................... 205
Printing Photos by Date .......................................................................................................... 207
Viewing and Printing Photos from a Slide Show ..................................................................... 210
Cropping Photos Displayed on the LCD Screen..................................................................... 211
Modifying Photos Displayed on the LCD Screen .................................................................... 211
Photo Adjustment Options...................................................................................................... 212
7
Selecting Print Settings for Photos Displayed on the LCD Screen.......................................... 213
Print Setting Options - Photo Mode......................................................................................... 214
Printing Photo Layouts from a Memory Card............................................................................... 215
Photo Layout Options ............................................................................................................. 217
Printing Photo Greeting Cards..................................................................................................... 218
Creating and Printing a Greeting Card Template.................................................................... 218
Printing a Greeting Card from a Template .............................................................................. 220
Printing Photo Proofsheets from a Memory Card........................................................................ 222
Transferring Photos on a Memory Card........................................................................................... 223
Transferring Photos from a Memory Card to Your Computer...................................................... 223
Transferring Photos from a Memory Card to an External Device................................................. 224
Using an External Device with Your Product........................................................................................ 227
Wireless Printing from a Mobile Device............................................................................................ 227
Printing from a Camera Connected to Your Product ........................................................................ 227
Connecting and Printing From a Camera .................................................................................... 228
Selecting Print Settings for Printing from a Camera..................................................................... 229
Print Settings - Camera........................................................................................................... 231
Photo Adjustments - Camera.................................................................................................. 232
Viewing or Printing from a USB Flash Drive or External Device....................................................... 234
USB Device File Specifications ................................................................................................... 234
Connecting and Using a USB Flash Drive or External Device..................................................... 234
Charging a USB Device Using Your Product.................................................................................... 235
Printing Personalized Projects............................................................................................................... 237
Printing Coloring Book Pages .......................................................................................................... 237
Printing Personalized Note Paper.................................................................................................... 239
Printing Lined Paper and Graph Paper ............................................................................................ 240
Printing on CDs/DVDs............................................................................................................................. 242
CD/DVD Printing Features............................................................................................................... 242
Loading a CD/DVD........................................................................................................................... 242
Removing a Printed CD/DVD........................................................................................................... 244
Placing a CD/DVD on the Scanner Glass......................................................................................... 245
Copying onto a CD/DVD .................................................................................................................. 246
Printing Photos from a Memory Card Onto a CD/DVD..................................................................... 247
8
Printing a Jewel Case Insert from a Memory Card........................................................................... 249
Printing on CDs/DVDs from a Computer.......................................................................................... 251
Printing on a CD/DVD with Windows........................................................................................... 252
Designing a CD/DVD - Windows............................................................................................. 252
Printing Your CD/DVD Design - Windows............................................................................... 253
Adjusting CD/DVD Print Position - Windows........................................................................... 253
Adjusting CD/DVD Print Quality - Windows ............................................................................ 255
Printing on a CD/DVD with Mac OS X ......................................................................................... 256
Designing a CD/DVD - Mac OS X .......................................................................................... 257
Printing Your CD/DVD Design - Mac OS X............................................................................. 258
Adjusting CD/DVD Print Position - Mac OS X......................................................................... 259
Adjusting CD/DVD Print Quality - Mac OS X........................................................................... 260
Replacing Ink Cartridges........................................................................................................................ 262
Check Cartridge Status.................................................................................................................... 262
Checking Cartridge Status on the LCD Screen ........................................................................... 262
Checking Cartridge Status with Windows.................................................................................... 263
Checking Cartridge Status with Mac OS X.................................................................................. 266
Purchase Epson Ink Cartridges........................................................................................................ 267
Ink Cartridge Part Numbers......................................................................................................... 267
Removing and Installing Ink Cartridges............................................................................................ 268
Conserving Low Black Ink with Windows......................................................................................... 272
Adjusting Print Quality............................................................................................................................ 274
Print Head Maintenance................................................................................................................... 274
Print Head Nozzle Check............................................................................................................. 274
Checking the Nozzles Using the Product Control Panel ......................................................... 274
Checking the Nozzles Using a Computer Utility...................................................................... 277
Print Head Cleaning .................................................................................................................... 280
Cleaning the Print Head Using the Product Control Panel...................................................... 280
Cleaning the Print Head Using a Computer Utility................................................................... 282
Print Head Alignment ....................................................................................................................... 285
Aligning the Print Head Using the Product Control Panel............................................................ 286
Aligning the Print Head Using a Computer Utility......................................................................... 288
Cleaning the Paper Path.................................................................................................................. 291
9
Cleaning and Transporting Your Product ............................................................................................. 292
Cleaning Your Product..................................................................................................................... 292
Transporting Your Product............................................................................................................... 292
Solving Problems.................................................................................................................................... 295
Checking for Software Updates........................................................................................................ 295
Product Status Messages ................................................................................................................ 296
Running a Product Check ................................................................................................................ 297
Resetting Control Panel Defaults..................................................................................................... 299
Solving Setup Problems................................................................................................................... 300
Noise After Ink Installation........................................................................................................... 301
Software Installation Problems.................................................................................................... 301
Control Panel Setup Problems .................................................................................................... 302
Solving Network Problems............................................................................................................... 302
Product Cannot Connect to a Wireless Router or Access Point .................................................. 302
Network Software Cannot Find Product on a Network................................................................. 303
Product Does Not Appear in Mac OS X Printer Window.............................................................. 303
Cannot Print Over a Network....................................................................................................... 304
Cannot Scan Over a Network...................................................................................................... 304
Printing a Network Status Sheet.................................................................................................. 305
Solving Copying Problems............................................................................................................... 306
Product Makes Noise, But Nothing Copies.................................................................................. 306
Product Makes Noise When It Sits for a While ............................................................................ 306
Solving Paper Problems................................................................................................................... 306
Paper Feeding Problems............................................................................................................. 307
Paper Jam Problems Inside the Product ..................................................................................... 307
Paper Jam Problems in the Main Tray......................................................................................... 310
Paper Jam Problems in the Auto Duplexer.................................................................................. 314
Paper Jams in the Automatic Document Feeder......................................................................... 318
Paper Ejection Problems............................................................................................................. 321
Solving Problems Printing from a Computer .................................................................................... 321
Nothing Prints.............................................................................................................................. 321
Product Icon Does Not Appear in Windows Taskbar................................................................... 322
Error After Cartridge Replacement.............................................................................................. 323
10
Printing is Slow............................................................................................................................ 323
Solving Page Layout and Content Problems.................................................................................... 324
Inverted Image ............................................................................................................................ 324
Too Many Copies Print................................................................................................................ 325
Blank Pages Print........................................................................................................................ 325
Incorrect Margins on Printout....................................................................................................... 326
Border Appears on Borderless Prints.......................................................................................... 326
Incorrect Characters Print............................................................................................................ 327
Incorrect Image Size or Position.................................................................................................. 327
Slanted Printout........................................................................................................................... 328
Solving Print Quality Problems......................................................................................................... 328
White or Dark Lines in Printout.................................................................................................... 328
Blurry or Smeared Printout.......................................................................................................... 329
Faint Printout or Printout Has Gaps............................................................................................. 330
Grainy Printout............................................................................................................................. 331
Incorrect Colors........................................................................................................................... 332
Solving Scanning Problems ............................................................................................................. 332
Scanning Software Does Not Operate Correctly ......................................................................... 332
Cannot Start Epson Scan............................................................................................................ 333
Solving Scanned Image Quality Problems....................................................................................... 333
Image Consists of a Few Dots Only............................................................................................. 334
Line of Dots Appears in All Scanned Images............................................................................... 334
Straight Lines in an Image Appear Crooked................................................................................ 335
Image is Distorted or Blurry......................................................................................................... 335
Image Colors are Patchy at the Edges........................................................................................ 335
Image is Too Dark ....................................................................................................................... 335
Back of Original Image Appears in Scanned Image .................................................................... 336
Ripple Patterns Appear in an Image............................................................................................ 336
Scanned Image Colors Do Not Match Original Colors................................................................. 336
Scan Area is Not Adjustable in Thumbnail Preview..................................................................... 337
Scanned Image Edges are Cropped ........................................................................................... 337
Solving Memory Card Problems....................................................................................................... 337
Memory Card Does Not Fit Into a Slot......................................................................................... 338
11
Cannot View or Print Photos from a Memory Card...................................................................... 338
Cannot Transfer Photos To or From a Memory Card .................................................................. 338
Solving Faxing Problems.................................................................................................................. 339
Cannot Send or Receive Faxes................................................................................................... 339
Cannot Receive Faxes with a Telephone Connected to Your Product........................................ 340
When to Uninstall Your Product Software ........................................................................................ 340
Uninstalling Product Software - Windows.................................................................................... 340
Uninstalling Product Software - Mac OS X.................................................................................. 341
Where to Get Help............................................................................................................................ 342
Technical Specifications ........................................................................................................................ 344
Windows System Requirements ...................................................................................................... 344
Mac System Requirements.............................................................................................................. 345
Printing Specifications...................................................................................................................... 345
Scanning Specifications................................................................................................................... 345
Automatic Document Feeder (ADF) Specifications.......................................................................... 346
Fax Specifications............................................................................................................................ 346
Paper Specifications ........................................................................................................................ 347
Printable Area Specifications ........................................................................................................... 348
Ink Cartridge Specifications.............................................................................................................. 351
Memory Card Specifications ............................................................................................................ 352
Dimension Specifications................................................................................................................. 354
Electrical Specifications ................................................................................................................... 354
Environmental Specifications........................................................................................................... 355
Interface Specifications.................................................................................................................... 355
External USB Device Specifications................................................................................................. 355
Network Interface Specifications...................................................................................................... 356
Safety and Approvals Specifications................................................................................................ 356
Notices ..................................................................................................................................................... 358
FCC Compliance Statement............................................................................................................. 358
Software Notices.............................................................................................................................. 360
Trademarks...................................................................................................................................... 365
Copyright Notice............................................................................................................................... 366
libTIFF Software Acknowledgment.............................................................................................. 367
12
A Note Concerning Responsible Use of Copyrighted Materials................................................... 367
Default Delay Times for Power Management for Epson Products............................................... 367
Copyright Attribution.................................................................................................................... 367
13
Artisan 837 User's Guide
Welcome to the Artisan 837 User's Guide.
15

Product Basics

See these sections to learn about the basic features of your product.
Setting Up the Control Panel Product Parts Locations Selecting Wireless Network Settings From the Touch Panel

Setting Up the Control Panel

See these sections to set up the control panel for use.
Touch Panel Buttons and Lights Adjusting Control Panel Position Changing LCD Screen Language Turning Off Control Panel Sounds
Parent topic: Product Basics

Touch Panel Buttons and Lights

1 The On light 2
The On button
3
The Homebutton
16
4 The Display/Crop button 5 The LCD screen 6 The + and – buttons (increase or decrease the number of copies) 7 The arrow buttons and the OK button 8 The auto answer light 9 The Reset button 10 The WiFi light 11
The CD Tray button
12 The blue status light 13 The Menu button 14
The Back button
15 The Start button
Parent topic: Setting Up the Control Panel

Adjusting Control Panel Position

You can adjust the position of the control panel to make it easier to access. Raise or lower it to the desired angle as shown.
17
Parent topic: Setting Up the Control Panel

Changing LCD Screen Language

You can change the language used on the LCD screen.
1. Press the Home button, if necessary.
2. Press the arrow buttons and then select Setup.
3. Select Printer Setup.
4. Press the arrow buttons and then select Language.
5. Select a language.
6. Press the Home button to exit.
Parent topic: Setting Up the Control Panel

Turning Off Control Panel Sounds

You can turn off the sound heard when you press buttons on the control panel.
1. Press the Home button, if necessary.
2. Press the arrow buttons and then select Setup.
3. Select Printer Setup.
4. Select Sound.
5. Select Button Press.
6. Select the Off setting.
7. Press the Home button to exit.
Parent topic: Setting Up the Control Panel

Product Parts Locations

See these sections to identify the parts on your product.
Product Parts - Top Product Parts - Front Product Parts - Inside Product Parts - Back
Parent topic: Product Basics
18

Product Parts - Top

1 Automatic Document Feeder (ADF) 2 Edge guide 3 ADF paper support 4 ADF output tray 5 ADF cover 6 Control panel 7 Front cover
19
1 Scanner glass 2 Memory card access light 3 Memory card slots 4
USB Type A port for external devices
5 CD/DVD tray
Parent topic: Product Parts Locations
20

Product Parts - Front

1 Output tray 2 Output tray extension 3 Paper stopper 4 Photo tray 5 Photo tray edge guides 6 Main tray 7 Main tray edge guides
Parent topic: Product Parts Locations
21

Product Parts - Inside

1 Scanner unit 2 Print head 3 Ink cartridge holder
Parent topic: Product Parts Locations
22

Product Parts - Back

1 USB port 2 LINE port 3 LAN port 4 EXT port 5 Auto duplexer 6 AC inlet
Parent topic: Product Parts Locations

Selecting Wireless Network Settings From the Touch Panel

You can select or change wireless network settings using your product touch panel. To install your product on a wireless network, follow the instructions on the Start Here sheet and install
the necessary software from the product CD. The installer program guides you through network setup.
23
Note: Breakdown or repair of this product may cause loss of fax and network data and settings. Epson is
not responsible for backing up or recovering data and settings during or after the warranty period. We recommend that you make your own backup or print out your fax and network data and settings.
1. Press the Home button, if necessary.
2. Press the arrow buttons and then select Setup.
3. Press the arrow buttons and then select Wi-Fi/Network Settings.
4. Select Wi-Fi Setup. You see this screen:
5. Select Wi-Fi Setup Wizard. Note: If you need to disable the wireless network to set up your product on an Ethernet network,
press the arrow buttons and select Disable Wi-Fi instead. Then follow the instructions on the Start Here sheet to set up your producton a wired network and install the necessary software from the product CD. The installer program guides you through network setup.
6. Select the name of your wireless network or enter the name manually.
Note: To enter the wireless network name manually, press the arrow buttons and then select Other SSIDs. Use the displayed keypad to enter your network name, as described in the next step.
24
7. Enter your wireless password (or network name and then password) using the displayed keypad.
• Press the arrow buttons to move the cursor to the previous or next space.
• Press the number buttons repeatedly to select uppercase letters (ABC), lowercase letters (abc), or
numbers (123) and symbols (*!#&).
• To enter a space, select .
• To delete characters, select .
• When you finish entering characters, press the OK button.
8. Confirm the displayed network settings and press the OK button to save them. Note: If you need to change a setting, press the Back button.
9. If you want to print a network setup report, press the Start button. (Otherwise, select Cancel.)
10. Press the Home button to exit. The WiFi light should now be on, but not flashing.
Note: If the WiFi light is off, youmay have selected the wrong network name or entered the password incorrectly. Repeat these steps to try again.
Parent topic: Product Basics
25

Loading Paper

Before you print, load paper for the type of printing you will do.
Loading Paper in the Main Tray Loading Paper in the Photo Tray Loading Envelopes Paper Loading Capacity Available Epson Papers Borderless Paper Type Compatibility Paper or Media Type Settings

Loading Paper in the Main Tray

You can load larger-size paper in the main tray in the paper cassette. Note: Make sure the CD/DVD tray is closed.
1. Close the output tray, if necessary.
26
2. Open the front cover.
3. Pull out the paper cassette.
27
4. Remove any paper loaded in the photo tray on top, if necessary.
5. Slide in the main tray extension (if it is extended) and flip back the photo tray.
6. Pinch the tabs on the main tray edge guides and slide them outward.
28
7. Load a stack of paper, printable side down, in the main tray as shown.
8. Slide the left edge guide to the edge of the paper.
Note: Make sure the paper fits beneath the top edges of the guide.
9. Slide the front edge guide to the position marked for your paper size.
29
1 Various paper sizes are marked on the tray
Note: Make sure the paper fits beneath the top of the edge guide and does not flip up at the back end of the tray.
10. Lower the photo tray.
11. If you need to load paper in the photo tray, see the instructions for that section.
30
Loading...
+ 338 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
