Epson PowerLite 737c Projector
Projector Parts
Lens cap
Audio port
Focus ring
Video port
S-Video port
Card slot
Exhaust air vent
Foot adjust lever
USB port
(Type B)
Zoom ring
I/R receiver
Computer/
Component
Video port
Control panel
Security lock
USB port
(Type A)
Projection Front, rear, upside-down (ceiling mount)
methods
Internal 1 W monaural
sound system
Optical aspect 4:3 (horizontal:vertical)
ratio
Zoom ratio 1:1.2
Noise level 36 dB (Low Brightness mode)
Mouse Supports USB (type B)
compatibility
Projection Lamp
Type UHE (Ultra High Efficiency)
Power 170 W
consumption
Lamp life High Brightness mode: about 2000 hours
Low Brightness Mode: about 3000 hours
Part number V13H010L32
Remote Control
Range 20 feet (6 meters)
Batteries (2) Alkaline AAA
foot
Power inlet
SpeakerRear adjustable
Specifications
General
Type of display Poly-silicon TFT active matrix
Resolution 1024
(native format)
Color 24-bit, 16.8 million colors
reproduction
Brightness 2000 lumens (High Brightness mode)
(ANSI) 1500 lumens (Low Brightness mode)
Contrast ratio 400:1
Image size 30 to 300 inches (0.8 to 7.6 meters)
(diagonal)
Projection 3.2 to 39.7 feet (1.0 to 12.1 meters)
distance
× 768 pixels (XGA)
Dimensions
Height 2.7 inches (70 mm), feet retracted
Width 10.9 inches (276 mm)
Depth 7.6 inches (193 mm)
Weight 3.9 lb (1.8 kg)
Electrical
Rated frequency 50/60 Hz AC
Power supply 100 to 120 VAC, 2.7 A
200 to 240 VAC, 1.1 A
Power Operating: 240 W
consumption
Environmental
Temperature Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Humidity Operating: 20 to 80% RH,
(non-condensing) Storage: 10 to 90% RH
2/05 Epson PowerLite 737c Projector - 1
Epson PowerLite 737c Projector
Safety and Approvals
United States FCC 47CFR Part15B Class B (DoC)
UL60950 Third Edition
Canada ICES-003 Class B
CSA C22.2 No. 60950
CE Marking Directive 73/23/EEC, 89/336/EEC
IEC60950 Third Edition
EN 55022, EN 55024
Compatible Video Formats
The projector supports the video display formats listed below:
Mode Refresh Rate (Hz)
NTSC
NTSC 4:43
PAL
N—PAL
M—PAL
PAL—60
SECAM
HDTV (720p)
HDTV (720p)
HDTV (1080i)
HDTV (1080i)
SDTV (480p)
SDTV (480p)
TV480i
TV480i
Compatible Computer Display Formats
To project images from a computer, set the computer’s video
card at a refresh rate (vertical frequency) compatible with the
projector; see the following table for compatible formats. Some
images are automatically resized to display in the projector’s
“native” format (XGA). The frequencies of some computers
may not allow images to display correctly; see your computer’s
documentation for details.
60
60
50
50
60
60
50
60
50
60
50
60
50
60
50
Mode Refresh Rate (Hz) Resolution
VGA EGA
VGA—60
VESA—72
VESA—75
VESA—85
SVGA—56
SVGA—60
SVGA—72
SVGA—75
SVGA—85
XGA—60
XGA—70
XGA—75
XGA—85
SXGA1—70
SXGA1—75
SXGA1—85
SXGA2—60
SXGA2—75
SXGA2—85
SXGA+60
SXGA+75
SXGA+85
SXGA3—60
SXGA3—75
SXGA3—85
UXGA—60 60 1600
iMAC VGA
iMAC SVGA
iMAC XGA
MAC13
MAC16
MAC19—60
MAC19
MAC21
*The image is resized using Epson’s SizeWise™ Technology.
70
60
72
75
85
56
60
72
75
85
60
70
75
85
70
75
85
60
75
85
60
75
85
60
75
85
117
95
75
67
75
59
75
75
640
× 350*
640
× 480*
640
× 480*
640
× 480*
640
× 480*
800
× 600*
800
× 600*
800
× 600*
800
× 600*
800
× 600*
1024
× 768
1024 × 768
1024 × 768
1024 × 768
1152
× 864*
1152
× 864*
1152
× 864*
1280
× 960*
1280
× 960*
1280
× 960*
1400
× 1050*
1400
× 1050*
1400
× 1050*
1280
× 1024*
1280
× 1024*
1280
× 1024*
× 1200*
640
× 480*
800
× 600*
1024
× 768
640 × 480*
832
× 624*
1024
× 768
1024 × 768
1152 × 870*
2 - Epson PowerLite 737c Projector 2/05
Epson PowerLite 737c Projector
Positioning the Projector
Before connecting the projector, you need to decide where to
place it. The location you choose depends on the size of the
room and what you are projecting.
❏ Place the projector on a sturdy, level surface, between
3.2 and 39.7 feet from the screen.
❏ Make sure there is plenty of space for ventilation around and
under the projector. Do not set the projector on top of
anything that could block the vents under the projector.
❏ Make sure the projector is within 10 feet of an electrical
outlet or extension cord and within 5 feet of your computer
and/or video source, unless you are projecting wirelessly or
from a memory card.
❏ Place the projector directly in front of the center of the
screen, facing the screen squarely. Otherwise, your image
will not be rectangular.
Note:
It’s easier to position the projector when the screen is directly in
front of the room.
Use the figure below as a guideline to help you determine how
far from the screen to place the projector. Image size generally
increases with distance, but may vary depending on how you
position the zoom ring and whether you have adjusted the
image size with other settings.
33.1 to 39.7 feet 6.6 to 7.9 feet 3.2 to 3.9 feet
To calculate exact measurements, use the following formulas:
❏ To find the projection distance when you know the screen’s
diagonal dimension:
Wide (inches) = ((33.696
21.717) / 25.4
Tele (inches) = ((40.453
22.52) / 25.4
❏ To find how large a screen’s diagonal dimension will be
when you know the projection distance:
Wide (inches) = (Projection distance [inches]
0.02171) / 0.033696
Tele (inches) = (Projection distance [inches]
0.02252) / 0.040453
× diagonal screen size [inches]) –
× diagonal screen size [inches]) –
× 0.0254 +
× 0.0254 +
If you place the projector below the level of the screen, you’ll
have to tilt it up by extending the front adjustable foot, as
shown. Tilting the projector upward causes the image to lose its
rectangular shape, but you can correct the distortion by pressing
the
Sync buttons on the projector. See page 6 for detailed
information about correcting the image shape.
If you place the projector level with the bottom of the screen,
the image will be rectangular and you won’t have to adjust it. If
you place the projector higher than the bottom of the screen,
the image will still be rectangular, but you won’t be able to fill
the whole screen with the image.
Starting Up the Projector
Make sure your projector and other equipment are set up and
connected correctly. Then turn on your projector, as described
below.
If you turn on your connected computer or video equipment
before starting the projector, the projector automatically detects
and displays the image source. If you turn on the projector first,
or have multiple pieces of connected equipment, you may have
to select the image source manually. See “Selecting the Image
Source” on page 5.
Follow these steps to plug in and turn on the projector:
1. Remove the lens cap.
Caution
Do not use the projector with the lens cap in place. The heat
generated by the lamp can damage the cap.
2. Connect one end of the power cord to the projector’s power
inlet. Then connect the other end to an electrical outlet.
The P
Power light on top of the projector turns orange,
indicating that the projector is receiving power but not yet
turned on.
2/05 Epson PowerLite 737c Projector - 3
Epson PowerLite 737c Projector
3. Press the P
Power button on top of the projector or on the
remote control.
Power button
Remote controlProjector
The projector beeps once and the P
Power light flashes
green as the projector warms up, then an image begins to
appear. When the P
Power light stops flashing and remains
green, the projector is ready for use.
Warning:
Never look into the lens when the lamp is on. This can damage
your eyes, and is especially dangerous for children.
❏ If you’ve connected a Windows
®
-based computer to the
projector, you may see a New Hardware Wizard saying
your computer has found a plug-and-play monitor; if so,
click
Cancel.
❏ If you don’t see the image you want, press the
Search button on the projector or the Search button on
Source
the remote control until you see the image you want to
project.
❏ If you are prompted to enter a password, see “Starting the
Projector with a Password” on page 10.
Note:
You can also use the Source buttons on the remote control to
switch between devices connected to the ports identified on each
button. For details, see page 5.
If a projected image fails to appear, see “What To Do If You See
a Blank Screen” in the next column.
When you’re done with your presentation, shut down the
projector as described on page 7. Shutting down the projector
correctly prevents premature lamp failure and possible damage
from overheating.
What To Do If You See a Blank Screen
If you see a blank screen or the No Signal message after turning
on your computer or video source, try the following:
❏ Make sure the cables are connected correctly.
❏ Make sure the P
the lens cover is off.
❏ Press the
Search button on the remote control repeatedly until you
Source Search button on the projector or the
see the image you want to project. See page 5 for more
information about selecting the image source.
If you’re using a Windows computer:
❏ Hold down the Fn key and press the function key that lets
you display on an external monitor. It may have an icon such
as or it may be labelled
for the projector to sync up after pressing it. Check your
computer’s manual or online help for details.
On most systems, the or
between the LCD screen and the projector, or display on
both at the same time.
❏ Depending on your computer’s video card, you might need
to use the Display utility in the Control Panel to make sure
that both the LCD screen and external monitor port are
enabled. See your computer’s documentation or online help
for details.
If you’re using a Macintosh® with OS X:
You may need to set up your system to display on the projector
screen as well as the LCD screen. Follow these steps:
1. From the Apple menu, select
click
Displays.
2. Select
If you’re using a Macintosh with OS 8.6 to 9.x:
VGA Display or Color LCD, click Arrange or
Arrangement, and make sure Mirror Displays is checked.
You may need to set up your system to display on the projector
screen as well as the LCD screen. Follow these steps:
1. From the Apple menu, select
Monitors or Monitors and Sound.
2. Click the
Arrange icon.
3. Drag one monitor icon on top of the other.
If the
Arrange option isn’t available, try selecting one of the
Simulscan resolution settings. Click the
necessary, and then select a
seconds for the projector to sync up after making the selection.)
Power light is green and not flashing and
CRT/LCD. Allow a few seconds
CRT/LCD key lets you toggle
System Preferences, then
Control Panels, then click
Monitor icon, if
Simulscan resolution. (Allow a few
4 - Epson PowerLite 737c Projector 2/05
Epson PowerLite 737c Projector
Selecting the Image Source
If multiple devices are connected to the projector, the easiest
way to select the image source is to press the
the remote control or the
Source Search button on the
Search button on
projector until the correct image is projected.
You can also press one of the following buttons on the
remote control:
❏
Computer to select the device connected to the projector’s
Computer/Component Video port.
❏
S-Video to select the device connected to the
S-Video port.
❏
Video button to select the device connected to the
Video port.
❏
EasyMP button to project wirelessly or from a memory
card.
After you select a source, the screen goes dark for a moment
before the image appears.
Adjusting the Image
Once you see your image, you may need to make certain
adjustments, as described in this section.
Focusing and Zooming Your Image
Rotate the focus ring to sharpen the image.
You can also change the image size by moving the projector
closer to or farther away from the screen. You can use the
E-Zoom buttons on the remote control to zoom in on a portion
of the image. See “Zooming Your Image” on page 7 for
instructions.
Adjusting the Height of Your Image
If the image is too low, you can raise it by extending the
projector’s front adjustable foot.
1. Stand behind the projector. Press up on the blue foot release
lever and lift the front of the projector to extend the front
adjustable foot.
2. Once the image is positioned where you want it, release the
lever to lock the foot in position.
3. If the projector is not level, rotate the
foot at the back of the projector.
If the image is no longer rectangular after
raising it, see the next section.
Focus ring
Rotate the zoom ring to reduce or enlarge the image.
Zoom ring
Correcting Computer Images
If you’ve connected a computer and the image doesn’t look
right, or it doesn’t fit properly on the screen, press the
button on the remote control or the
Enter button on the
projector. This automatically resets the projector’s tracking,
sync, resolution, and position settings. You must be projecting
an image for this button to have any effect. Additionally, if the
Auto Setup option in the Signal menu is set to OFF, the Auto
function will not work.
2/05 Epson PowerLite 737c Projector - 5
Auto
Epson PowerLite 737c Projector
Adjusting the Image Shape
The projector automatically corrects images that are distorted
when the projector is tilted up or down (up to a 15° tilt). The
Keystone window appears on the screen while the projector
makes the correction. If the projected image still isn’t
rectangular or has a “keystone” shape, do one or more of the
following:
❏ If your image looks like or , you’ve placed the
projector off to one side of the screen, at an angle. Move it
directly in front of the center of the screen, facing the screen
squarely.
❏ If your image looks like or , you may need to
manually adjust the keystone correction value. Follow the
directions below:
❏ To make keystone corrections using the projector’s
Setting menu, press the
remote control. Select the
Enter. Select Keystone and press Enter. Use the
Menu button on the projector or
Setting menu, then press
pointer button on the remote control (or the arrow
buttons on the projector) to adjust the keystone setting as
needed.
❏ To manually adjust the keystone correction value, press
the or button on the projector to correct the
shape of the image. After correction, your image will be
slightly smaller.
Adjusting the Color Mode
You may want to adjust the color mode to select a setting
that is appropriate for the image you’re projecting and the
environment in which you’re projecting it.
The following table lists the available color modes.
Color mode Description
sRGB
Dynamic
Presentation
Theater
Living Room
Blackboard
To change the color mode, press the
the remote control until you see the mode you want. The
currently selected setting appears in the upper right corner of
the screen. You can also use the projector menu system to select
the Color Mode setting in the Image menu.
For matching the color palette of standard sRGB
computer displays.
For increased brightness in bright rooms (the
default for non-computer display).
For computer presentations (the default when
projecting from a computer with analog video).
For optimizing movie images with increased
contrast.
For increased brightness when playing video
games or watching TV in a bright room.
For projecting accurate colors on a green
chalkboard (adjusts the white point).
Color Mode button on
Adjusting the Brightness
The brightness of an image depends on the source you are
projecting and the amount of light in the room. If the image is
too bright or not bright enough, do one of the following:
❏ Change the
❏ Select
the Setting menu. Low Brightness mode extends the life of
the lamp and decreases the fan noise.
Brightness setting in the Image menu.
Low or High for the Brightness Control option in
Sleep Mode
When the projector has not received any input signals for
30 minutes, it automatically turns off the projector lamp and
enters “sleep mode.” This conserves electricity, cools the
projector, and extends the life of the lamp. If you are done using
the projector, unplug the power cord. If you want to start
projecting again, press the P
You can enable sleep mode in the Extended menu under
Operation.
Power button.
6 - Epson PowerLite 737c Projector 2/05
Epson PowerLite 737c Projector
Using Direct Power On
The Direct Power On function enables faster setup. The
projector will start up automatically when you plug it in; you
won’t have to press the P
Power button.
Follow these steps to enable Direct Power On:
1. Press the
Extended menu.
2. Choose
3. Choose
4. Highlight
5. Press
Menu button on the remote control and select the
Operation and press Enter.
Direct Power On and press Enter.
ON and press Enter.
Esc or Menu to exit.
Note:
When Direct Power On is enabled, shut down the projector as you
normally would. Follow the instructions in the next section. (The
projector will start automatically when power is restored after a
power failure if it is plugged in.)
Shutting Down the Projector
When you’ve finished using the projector, follow the
recommended procedure to shut it down. This extends the
lamp life and protects the projector from possible overheating.
1. Turn off any equipment plugged into the projector.
2. To turn off the projector, press the P
projector or remote control. You see a confirmation message.
(If you don’t want to turn it off, press any other button.)
3. Press the P
Power button again. The P Power light flashes
orange as the projector cools down. When the projector
beeps twice, it’s safe to unplug it.
To turn the projector on again, wait until the P
stops flashing. Then press the P
4. Press up on the blue foot release lever and lower the
projector to retract the front adjustable foot, as shown.
Power button on the
Power light
Power button.
Caution
To avoid damaging the projector or lamp, never unplug the
power cord when the P
Power light is green or flashing orange.
Using the Remote Control
Before using the remote control, insert the two AAA alkaline
batteries, as described on page 8.
When using the remote control, stand within 20 feet of the
projector. Point the remote control either at the projector or at
the screen (the projector’s front sensor can detect signals
bounced off the screen). Press the button for the function you
want to use.
Turning Off the Picture and Sound
You can use the A/V Mute button on the remote control to turn
off the image and sound. This is useful if you want to
temporarily redirect your audience’s attention.
❏ To turn off the picture and sound, press the
button. The screen turns blue.
❏ To turn the image and sound back on, press the
button again.
You can create an image, such as a company logo or a picture, to
display on the screen whenever you press the
See the User’s Guide for more information.
Stopping Action
Press the Freeze button to stop the action in your video or
computer image and keep the current image on the screen. The
sound will continue.
To restart the action, press the
press
Esc.
Freeze button again or
Zooming Your Image
Follow these steps to zoom in on a portion of the image:
1. Press the
a crosshair indicating the center of the zoom-in area.
2. Use the pointer button to position the crosshair in the
area you want to enlarge.
3. Continue pressing the
selected area up to 4 times.
E-Zoom button on the remote control. You see
E-Zoom button to enlarge the
A/V Mute
A/V Mute
A/V Mute button.
5. Replace the lens cap and unplug the power cord.
2/05 Epson PowerLite 737c Projector - 7
Loading...
