EPSON Perfection 1650/1650 PHOTO
Scanner Parts
Photo Print
button
Start button
and
indicator light
E-mail
button
document
cover
Scan to Web
(EPSON
PhotoCenter)
button
document
table
carriage and lamp
(in the home
position)
Scanner Specifications
Basic Specifications
Scanner type Flatbed, color
Photoelectric Color CCD line sensor
device
Effective pixels 13600 × 18720 pixels at 1600 dpi,
100% scaling
Maximum US letter or A4 size
document size (8.5 × 11.7 inches [216 × 297 mm])
Optical resolution 1600 dpi
Maximum 1600 dpi (main scan) × 3200 dpi hardware
(sub scan)
resolution*
* The maximum hardware resolution of 1600 × 3200 dp i is achieved
using EPSON’s Micro Step Drive
Maximum 12,800 dpi
interpolated
resolution
Output resolution 50 to 12,800 dpi
(50 to 6400 dpi in 1 dpi increments,
9600 dpi and 12,800 dpi performed with
zoom function)
Speed (1600 dpi, Color: 10 msec/line
draft mode) Grayscale: 3.3 msec/line
™
technology.
USB port DC inlet
transparency unit
(TPU) connector
transportation lock
(in unlocked position)
The EPSON Perfection 1650 PHOTO has a transparency unit
built into the scanner lid and holder for 35 mm film and slides:
EPSON Perfection 1650
owners can purchase an
optional transparency unit
(B813172):
Command level ESC/I-B8, FS
Zoom 50 to 200% in 1% increments
Pixel depth 16 bits per pixel
Brightness 7 levels
Line art settings Fixed threshold
TET (Text Enhancement Technology,
enable/disable selectable)
Digital halftoning AAS (Auto Area Segmentation), enable/
disable selectable
3 error diffusion modes (A, B, and C) and
4 dither patterns (A, B, C, and D) for
bi-level and quad-level data
(2 downloadable dither patterns)
Gamma correction 2 type for CRT display
3 types for printer output
1 type for user-defined
7/01 EPSON Perfection 1650/1650 PHOTO - 1
EPSON Perfection 1650/1650 PHOTO
Color correction 1 type for CRT display
3 types for printer output
1 type for user-defined (only user-defined
color correction is available in EPSON
TWAIN)
Interface
USB (Type B receptacle connector)
Light source White cold cathode fluorescent lamp
Reliability 30,000 cycles of carriage movements (main
unit MCBF)
Dimensions EPSON Perfection 1650
Width: 10.9 inches (27.6 cm)
Depth: 17.7 inches (45.0 cm)
Height: 3.7 inches (9.3 cm)
EPSON Perfection 1650 PHOTO
Width: 10.9 inches (27.6 cm)
Depth: 17.7 inches (45.0 cm)
Height: 4.6 inches (11.6 cm)
Weight EPSON Perfection 1650
Approx. 5.7 lb (2.6 kg)
EPSON Perfection 1650 PHOTO
Approx. 6.8 lb (3.1 kg)
Electrical
Input voltage DC 24 V
range
Rated input 0.8 A
current
Power EPSON Perfection 1650
consumption Approx. 15 W operating
approx. 17 W with optional TPU
approx. 6 W in power saving mode
EPSON Perfection 1650 PHOTO
Approx. 15 W operating
approx. 6 W in power saving mode
Note: Check the label on the back of the scanner for voltage
information.
Environmental
Temperature Operation: 41 to 95 °F (5 to 35 °C)
Storage: –13 to 140 °F (–25 to 60 °C)
Humidity Operation: 10% to 80%
(without Storage: 10% to 85%
condensation)
Operating Ordinary office or home conditions; avoid
conditions extreme dust, direct sunlight, and strong
light sources.
Safety Approvals
Safety Standards
120 V model UL 1950
EMC FCC part 15 subpart B class B
CSA C108.8 class B
USB Interface
Interface type Universal Serial Bus Specification
Revision 1.1
Configuration
Element Description
Configuration Characteristics: Self-powered
Remote wake up feature: Not supported
Maximum power consumption from VBUS: 2mA (5V)
Interface No alternate setting
Class: Vendor specific
Endpoint 1 Bulk IN transfer
Maximum data transfer size: 64 bytes
Endpoint 2 Bulk OUT transfer
Maximum data transfer size: 64 bytes
String
Descriptor
Electrical Full Speed mode (12Mbit/s) of Universal
standard Serial Bus Specification Revision 1.1
Connector type One receptacle (Type B)
Connector pin arrangement
Pin number Signal Connector
1VCC
2
3+DATA
4 GND
Initialization The scanner can be initialized (returned to
methods a fixed set of conditions) in the following
Hardware
initialization
Software
initialization
Language ID: US English
1: Manufacturer: “EPSON”
2: Product: “EPSON Scanner”
DATA
–
ways:
❏ The scanner is plugged in.
❏ The USB cable is unplugged, then plugged into the
USB port on the scanner.
❏ Software sends the ESC @ (initialize the scanner)
command.
❏ The scanner receives a Bus Reset from the USB
interface.
2 - EPSON Perfection 1650/1650 PHOTO 7/01
EPSON Perfection 1650/1650 PHOTO
AC Adapter Specifications
Basic Specifications
Temperature Operation: 41 to 95 °F (5 to 35 °C)
Dimensions 2.3 × 4.3 × 3.4 inches
(5.8 × 10.8 × 3.4 cm)
Electrical
Rated input 100 to 120 V
voltage
Rated input 0.7 A
current
Rated output DC 24 V
voltage
Rated output 0.8 A (1.0 A max.)
current
Rated frequency 50 to 60 Hz
Input frequency 49.5 to 60.5 Hz
range
Safety Approvals
Safety standards UL 1950
UL 1310
CSA C22.2 No. 950, No 223
EMC FCC part 15 subpart B class B
CSA C108.8 class B
Integrated Transparency Unit Specifications
If you have the EPSON Perfection 1650 PHOTO, the
transparency unit is built into the scanner lid.
Electrical Supply voltage: DC 24 V ±10% V
Rated current: 0.5 A
Optional Transparency Unit Specifications
If you have the EPSON Perfection 1650, you can purchase a
separate transparency unit (B813172) to scan positive and
negative transparent materials—35 mm slides, filmstrips, and
film up to 4 × 5 inches in size.
This transparency unit is a separate piece; it is not part of
the scanner lid as it is with the EPSON Perfection 1650
PHOTO.
Dimensions Width: 8.7 inches (222 mm)
Depth: 12.0 inches (305 mm)
Height: 1.4 inches (36 mm)
Weight 1.5 lb (0.7 kg)
Maximum 3.6 × 4.6 inches ([93 × 118 mm]
readable area size of 4 × 5-inch film holder opening)
Electrical Supply voltage: DC 24 V ±10% V
Rated current: 0.5 A
Reliability 10,000 hours for light source
Temperature Operation: 41 to 95 °F (5 to 35 °C)
Storage: –13 to 140 °F (–25 to 60 °C)
Humidity Operation: 10% to 80%
(without Storage: 10% to 85%
condensation)
Operating Ordinary office or home conditions; avoid
conditions extreme dust, direct sunlight, and
strong light sources.
Document Transparencies up to 4 × 5 inches
specifications (negative film, positive film)
35 mm strip film (negative, positive)
35 mm slides (negative, positive)
Brownie size strip film (120/220 size,
6 × 9 cm)
Scanner Buttons
Temperature Operation: 41 to 95 °F (5 to 35 °C)
Storage: –13 to 140 °F (–25 to 60 °C)
Humidity Operation: 10% to 80%
(without Storage: 10% to 85%
condensation)
Document 35 mm strip film (negative, positive)
specifications 35 mm slides (negative, positive)
Readable area 1.9 × 9.1 inches (48.26 × 231.1 mm)
The scanner’s buttons let you perform one-touch scanning with
™
EPSON Smart Panel.
] Start Press the ] Start button on the scanner to start
{ Photo Print Press the { Photo Print button to automatically scan
The buttons are described below:
EPSON Smart Panel (default).
and print a photo.
| E-Mail Press the | E-Mail button to scan your image and
send it as an e-mail attachment.
} Scan to Web Press the } Scan to Web button to scan an image
and upload it to the EPSON photo-sharing site,
EPSON PhotoCenter
SM
.
7/01 EPSON Perfection 1650/1650 PHOTO - 3
EPSON Perfection 1650/1650 PHOTO
Using EPSON Smart Panel
Follow these steps to use EPSON Smart Panel to scan
documents or photos:
1. Place the original document(s) face down on the document
table.
2. Do one of the following to open the Smart Panel:
❏ Press the ] Start button on your scanner.
❏ Click the Smart Panel icon on the desktop.
®
❏ On a Macintosh,
and select
The
Start button is set to open EPSON Smart Panel by
]
default. However, you can assign the
automatically open any of the Smart Panel applications.
you can also open the Apple® menu
EPSON SMART PANEL
.
]
Start button to
3. Click the icon for your desired scanning application. The
window for that option appears and lets you adjust settings
for your scan. Follow the on-screen steps for each option.
Keep the following in mind when using Smart Panel:
❏ If you select Copy or Photo Print, make sure your printer is
turned on and the correct paper type and size is loaded in
your printer.
❏ Scan to E-mail requires a MAPI-compliant e-mail program
(AOL is not MAPI compliant).
For instructions on using each of the Smart Panel applications,
see the electronic manual for EPSON Smart Panel.
Selecting TWAIN Settings
The illustration below shows
the different settings you can
adjust in the EPSON TWAIN
window, and the preferred
order you should adjust them
in. Detailed descriptions are
given in the electronic Reference
Guide. Manually adjust settings
in the EPSON TWAIN
window in the following order:
The most important
thing to remember
when scanning is to
select the correct
image type and best
resolution for your scan.
For more detailed
information on making
settings in EPSON
TWAIN driver, see the
electronic Reference
Guide.
1 Select the basic settings:
Document Source
Image Type
Destination
Resolution
2 Preview your image
(default)
3 Automatically set the scan
area for your image using
Auto Locate
4 Size or scale the image
5 Customize your settings
and configuration, and
use color management
6 Scan the image into your
application
7 Close EPSON TWAIN
4 - EPSON Perfection 1650/1650 PHOTO 7/01
Scanner Light
The scanner has one indicator light. (The indicator light is part
of the ] Start button.)
The ] light indicates the status of the scanner, as described
below.
Light Color Status
On Green The scanner is ready to scan images.
Flashing Green The scanner is initializing or is busy
scanning.
Flashing Red If you are using the EPSON Perfection
1650 PHOTO and are scanning
transparencies, make sure you’ve removed
the reflective document mat.
The scanner may not be properly
connected to the computer. Unplug the
scanner from its power source, remove the
USB cable, and then plug them back in.
If this does not eliminate the error, one of
the following may be the problem and you
need to consult your dealer or EPSON:
❏ The fluorescent lamp needs to be
replaced.
❏ The scanner is malfunctioning.
Off — The scanner or AC adapter is unplugged.
EPSON Perfection 1650/1650 PHOTO
Related Documentation
CPD-12466 EPSON Perfection 1250/1650 Start Here
poster
CPD-12467 EPSON Perfection 1250/1650 Scanner
Basics
CPD-12468 EPSON Perfection 1250/1650 scanner
software CD-ROM
— Reference Guide (HTML)
— EPSON Smart Panel User’s Manual
(HTML)
TM-PERF1650 EPSON Perfection 1650/1650 PHOTO
Service Manual
PL-PERF1650 EPSON Perfection 1650 Parts List
PL-PHOTO1650 EPSON Perfection 1650 PHOTO Parts
List
PL-B813172 Optional Transparency Unit Parts List
7/01 EPSON Perfection 1650/1650 PHOTO - 5
