NetSpan™ FDP Series
Integrated Fiber Distribution Pedestal Solution
Outside Plant for
Business-Critical Continuity
™
Features & Benefits
n
Unique internal back-to-back
dual compartment configuration (fiber splice and drops
housed in separate sides) —
for good housekeeping
n
Splices can be housed
in either an open or weathertight non-metallic closure —
for a low cost, field-upgradeable
open-to-closed solution
n
Choice of standard or
environmentally hardened
SC/APC adapters — to simplify
servicing
n
Full perimeter flange —
provides buffer tube protection
n
Up to 10.5 feet midspan slack
storage (144-fiber loose tube) —
for easy service access
n
Grommets for up to 20
individual drop cables —
maximize drop capacity
n
Independent cable strain relief
for secured pull-out strength —
maintains fiber cable integrity
n
Radius limiting spools —
improve fiber management and
reduce chance of signal loss
n
Adjustable splice tray brackets
hold up to nine splice trays
5.1" wide by 12.0" high —
to maximize the amount of
splices in one pedestal
Emerson Network Power offers a variety of
NetSpan
™
Series Fiber Distribution Pedestals
and Closures to meet your needs.
Description
The NetSpan™ FDP Integrated Fiber
Distribution Pedestal Solution series of
optical splice and distribution products
permits fiber splicing and improves cable
organization. Fiber Distribution Closures
come in two sizes to fit into an 8 or 10inch ProFORM
against the elements, debris and insects,
snap-on covers can be added to the
closures (closed architecture). Both size
closures have the following capabilities:
n
Single-sided optical splicing, open
or closed architecture
n
Double-sided optical splicing, open/
open, open/closed or closed/closed
architecture
n
Back-to-back optical splicing and
terminated drops, open/open, open/
closed or closed/closed architecture
n
Our Fiber Distribution Pedestal
solution includes the Fiber Distribution
Closure factory-installed in the
ProFORM
These pedestals and closures are
RDUP approved.
®
pedestal. For protection
®
pedestal.
Front – Spliced-Drop Side
NetSpan FDP Series
Integrated Fiber Distribution Pedestal Solution
Rear – Spliced Side
2
Application
NetSpan™ Fiber Distribution Pedestals
and Closures provide a configurable
platform for diverse FTTP deployment.
Emerson Network Power —
a complete spectrum of best-in-class reliable
power, precision environmental and connectivity
solutions for today’s telecommunications
and data network infrastructure
Fiber Distribution Closure
(shown with environmentally hardened drops)
NetSpan™ Fiber Distribution Closure
n
Fiber splices and drops are housed in
separate compartments
n
Environmentally hardened or standard
SC/APC adapters are available
n
An optional weather-tight cover can be
snapped on for added environmental
protection
n
Full perimeter flange to protect fiber
n
Accommodates up to nine splice trays
n
Internal radius limiting spools
n
Up to 10.5 feet midspan slack storage
(144-fiber loose tube)
n
Grommets for up to 12 individual
drop cables
n
Independent cable strain relief
NetSpan™ Integrated
Fiber Distribution Pedestal
n
Factory pre-configured Fiber
Distribution Closure and ProFORM
pedestal solution
n
Back-to-back configuration eliminates
the need for a hand hole/vault and
splice case
®
3
Fiber Distribution Closure Specifications
Pro8 Pro10
Optical Splicing
Open Configuration
Number of cable tie points
Closed-Drop Configuration
Grommets for up to 0.75" OD cable
Grommets for flat drop cable (or up to 0.45" OD cable)
Splice tray capacity
Midspan fiber storage
Drop Capabilities
Terminated Drops
Number of hardened drop ports
Number of standard SC/APC drop ports
SC APC pigtail, 3mm
Spliced Drops
Back-to-Back Optical Splicing
Open Back-to-Back Splice Configuration
Number of cable tie points 8 12
Closed Back-to-Back Drop Configuration
Grommets for up to 0.75" OD cable
Grommets for flat drop cable (or up to 0.45" OD cable)
Splice tray capacity
6
2
4
6 (or up to 2.50" stack)
up to 12.0"H x 4.5"W
10.5 feet (up to 96-fiber loose tube)
2, 4 or 6 ports
2, 4, 6 or 8 ports
3 meter
Up to 8
0
8
6 (or up to 2.50" stack)
up to 12.0"H x 4.5"W
10
2
8
9 (or up to 3.60" stack)
up to 12.0"H x 5.1"W
10.5 feet (up to 144-fiber loose tube)
2, 4, 6, 8 or 12 ports
2, 4, 6, 8 or 12 ports
3 meter
Up to 12
0
12
9 (or up to 3.60" stack)
up to 12.0"H x 5.1"W
Splice Tray Specifications
NSST1248 (F1008532) NSST2448 (F1008103) NSST1224 (F1008261)
Dimensions (H x W x D) 7.13" x 4.30" x 0.37" 11.88" x 4.33" x 0.40" 12.00" x 5.1" x 0.50"
Splice Capacity 12 single fusion or 4 mass fusion 24 single fusion or 4 mass fusion 12 single drop or 24 single fusion
(48 fibers) (48 fibers)
Entry Ports (10) buffer tube ports (10) buffer tube ports (14) buffer tube ports
Material Molded plastic base, clear plastic cover Molded plastic base, clear plastic cover Molded plastic base, clear plastic cover
Accessories (included) (2) 6-position single fusion splice holder (1) 24 single fusion splice holder (4) 6 single fusion splice holder
(2) 4-position mass fusion splice holder (1) 4-position mass fusion holder (14) tie wraps
(10) tie wraps (10) tie wraps
4
Ordering Matrix: NS a b c d
a) Pedestal Options FDP8 = Pro8 integrated Fiber Distribution Pedestal (short base) with Fiber Distribution Closure
FDC8 = Pro8 Fiber Distribution Closure only (8-in ProFORM pedestal sold separately)
FDP10 = Pro10 integrated Fiber Distribution Pedestal (short-base) with Fiber Distribution Closure
FDC10 = Pro10 Fiber Distribution Closure only (10-in ProFORM pedestal sold separately)
FDP10V = Pro10 integrated Fiber Distribution Vault Pedestal with Fiber Distribution Closure*
b) Rear-Side Configuration SO = Splice, open
SC = Splice, closed
X = Empty (for front side splicing only)
c) Front-Side Configuration SO = Splice, open
SC = Splice, closed
2O = Open, 2-port environmentally hardened adapter
4O = Open, 4-port environmentally hardened adapter
6O = Open, 6-port environmentally hardened adapter
8O = Open, 8-port environmentally hardened adapter (available in Pro10 size only)
12O = Open, 12-port environmentally hardened adapter (available in Pro10 size only)
2C = Closed**, 2-port environmentally hardened adapter
4C = Closed**, 4-port environmentally hardened adapter
6C = Closed**, 6-port environmentally hardened adapter
8C = Closed**, 8-port environmentally hardened adapter (available in Pro10 size only)
12C = Closed**, 12-port environmentally hardened adapter (available in Pro10 size only)
2OB = Open, 2-port standard SC/APC adapter
4OB = Open, 4-port standard SC/APC adapter
6OB = Open, 6-port standard SC/APC adapter
8OB = Open, 8-port standard SC/APC adapter
12OB = Open, 12-port standard SC/APC adapter (available in Pro10 size only)
2CB = Closed*, 2-port standard SC/APC adapter
4CB = Closed*, 4-port standard SC/APC adapter
6CB = Closed*, 6-port standard SC/APC adapter
8CB = Closed*, 8-port standard SC/APC adapter
12CB = Closed*, 12-port standard SC/APC adapter (available in Pro10 size only)
U = Universal mounting plate (for mounting a fiber terminal block; terminal block not included)
d) Splice Tray Option 1 = One splice tray included [NSST2448 (F1008103) for Pro8; NSST1224 (F1008261) for Pro10]
X = No splice tray included
**
**
* See Table A for recommended vault manufacturers.
Includes door and bottom plate to create a weather-tight enclosure.
* *
Example: Catalog number NSFDP10SC4OX represents a NetSpan™ Pro10 integrated fiber distribution closure with short-base pedestal
configured for closed splicing, opened 4-port environmentally hardened adapter drops, no splice tray included.
5
Table A: Vault Manufacturers
Manufacturer Description
Carson Industries 2200 Series Hand-Hole Vault (22002003)
1730 Series Vault (1730244HCBOU6UE)
2436 Series Vault (2436244HCBOU6IO)
Channell Communications Shutter Box Series Grade Level Box
1620 and 1730 Series with plug option covers
Quazite (Hubbell) Any 1730 Series Vault with PG1730C528 lid/cover
NOTE: Emerson does not sell or provide these vaults.
ProFORM® Pedestals (Empty)
Catalog No. Part No. Description
PRO8HIRNGE F1006564 8-in. non-metallic split base pedestal with integral spade, empty
PRO8HSRNGE F1006565 8-in. non-metallic split base pedestal, empty
PRO10HIRNGE F1006527 10-in. non-metallic split base pedestal with integral spade, empty
PRO10HSRNGE F1006528 10-in. non-metallic split base pedestal, empty
PRO10NEVP F1008255 10-in. fiber vault pedestal, empty
ProFORM® Pedestal
6
Accessories
Catalog Part Std.
Number Number Description UOM Package Qty.
NSST1248 F1008532 Universal splice tray, 12 single fusion Each 10
or 4 mass fusion (48 fibers) (for PRO8 and PRO10)
NSST2448 F1008103 Universal splice tray, 24 single fusion Each 10
or 4 mass fusion (48 fibers) (for PRO8 and PRO10)
NSST1224 F1008261 Splice tray, 12 single drop or 24 single fusion (for PRO10 only) Each 10
NSEHAAKIT F1007858 Environmentally hardened adapter kit includes: Each 10
(1) OptiTap™ style adapter and (1) 3mm SC/APC fiber pigtail 3m long
NSASCKIT3 F1008253 Standard SC/APC adapter kit includes: Each 10
(1) Standard SC/APC adapter and (1) 3mm SC/APC fiber pigtail 3m long
MS1332 F602132 32-in. mounting stake for pedestal Each 10
MS1342 F604080 42-in. mounting stake for pedestal Each 10
7
