NetReach™ XC LC Swing-Out Series
Integrated Cross Connect Solution
Key Features
n
50-pair RLS50 terminal blocks
provide rapid pair-at-a-time
no-strip jumpering
The NetReach™ XC LC Swing-Out Series from
Emerson is an economical integrated solution
for low pair-count applications.
n
Dual “toolbox” latches on doors
provide door alignment and
security
n
May be pad or stake-mounted
to accommodate all mounting
requirements
n
Rugged metal housing for
durability and low
maintenance costs
n
Treated with a powder-coat
paint process on the interior and
exterior for extended life
These single-access interface cabinets,
formerly known as the ERLS/ECQF
Series, accommodate 100 to 900 pair
using 50-pair RLS50 blocks and provide
rapid pair-at-a-time no-strip jumpering.
The metal enclosure is powder-coated
with a gray-green or off-white paint
finish and equipped with a hinged-grill,
test cord, wire spool, two stakes and
recessed pad-mounting BA12 brackets.
Security latches are accessed using a
216-type tool.
Application
The NetReach™ XC LC Swing-Out
Series is an above-ground line of
outdoor cabinets used in pad or stakemounted applications. The cabinet
provides convenient pair-at-a-time
connections, and accommodates
RSL50 terminal blocks.
The LC Swing-Out Series can be
flush mounted to the pad with the
PADMT200300 kit, which includes
two brackets that can be attached
either inside or outside of the base.
This kit must be ordered separately.
NetReach™ XC LC Swing-Out Series
shown with 400 pair of RLS50 blocks
2
Emerson Network Power —
a complete spectrum of best-in-class reliable
power, precision environmental and connectivity
solutions for today’s telecommunications
and data network infrastructure
Dimensions
Cabinet Size H W D
100-900 pair 56.50-in. 23.75-in. 11.30-in.
NOTE: Base is 14-in. tall.
Ordering Information
Catalog Part
Number Number Description In Out
FSERLS200 F010559 200-pair installed, RLS block 100 100
FSERLS400 F010561 400-pair installed, RLS block 200 200
FSERLS600 F010543 600-pair installed, RLS block 300 300
FSERLS900 F957241 900-pair installed, RLS block 300 600
FSE900 F016934 Empty cabinet, hinged grill, no blocks, tester dish without tester
FSERLS200CF F1002323 200-pair installed, RLS50 block with 710 CF connector 100 100
FSERLS200DPM F010533 200-pair installed, RLS50 block with 3M® 4005-DPM connectors 100 100
FSEFLS400CF F010541 400-pair installed, RLS50 block with 710 CF connector 200 200
FSERLS400DPM F010539 400-pair installed, RLS50 block with 3M® 4005-DPM connectors 200 200
FSERLS600CF F1002324 600-pair installed, RLS50 block with 710 CF connector 300 300
FSERLS60DPM F010534 600-pair installed, RLS50 block with 3M® 4005-DPM connectors 300 300
FSERLS900CF F010536 900-pair installed, RLS50 block with 710 CF connector 300 600
FSERLS900DPM F010538 900-pair installed, RLS50 block with 3M® 4005-DPM connectors 300 600
NOTE 1: Cabinet is expandable to 900-pair.
NOTE 2: Terminal blocks can also be equipped with filled bridge connectors, 4005-GBM.
