Emerson MS9700 User Manual

HOME AUDIO SYSTEM
with 6 CD CHANGER
and CASSETTE RECORDER
OWNER'S MANUAL
MS9700
Visit our web site at www.emersonradio.com
MS9700_ib021903.p65 19/2/2003, 9:2331
!
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow­head symbol, within an equi­lateral triangle is intented to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK ), NO USE R SERVICEABLE PARTS INSIDE REFER SERVICIN G TO Q U A L I F I ED S E R V I C E PERSONNEL.
The exclamation point within an equilateral triangle is in­tended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompany­ing the appliance.
IMPORTANT SAFETY INSTRUCTIONS
1.) Read these instructions.
2.) Keep these instructions.
3.) Heed all warnings.
4.) Follow all instructions.
5.) Do not use this apparatus near water.
6.) Clean only with dry cloth.
7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11.) Only use attachments / accessories specified by the manufacturer.
12.) Unplug this apparatus during lightning storms or when unused for long periods of time.
13.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14.) This appliance shall not be exposed to dripping or splashing water and no object filled with liquids such as vases shall be placed on the apparatus.
15.) Do not overload wall outlet. Use only power source as indicated.
16.) Use replacement parts as specified by the manufacturer.
17.) The product may be mounted to a wall only if recommended by the manufacturer.
18.) Upon completion of any service or repairs to this product, ask the service technician to perform safety checks.
1
MS9700_ib021903.p65 19/2/2003, 9:231
BEFORE WE BEGIN
Thank you for purchasing this Emers on product. The Emerson brand is your assurance of quality, performance and value.
Our engineers have included many useful and convenient features in this product. Please be sure to read this Owner's Manual completely to make s ure you are getting the maximum benefit from each feature.
This product was manufactured using the highest quality components and standards of workmanship. It was tested by Emerson inspectors and found to be in perfect working order before it left our factory. However, there is always the chance that some problem may occur because of rough handling during shipment to the retail store or to the final consumer.
If, after reading this Manual, you experience any problems with the operation of this product, please refer to the instructions for obtaining service at the end of this Manual. Emerson and Emerson retailers are committed to your satisfaction. Once again, thanks for purchasing this Emerson audio product.
For future reference, record the serial number in the space below.
Model: MS9700 Serial Number :
MS9700_ib021903.p65 19/2/2003, 9:232
2
IMPORTANT NOTES
Avoid installing the unit in locations described below :
• Places exposed to direct sunlight or close
to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/ or humid or moist areas.
• Do not attempt to clean this unit with
chemical solvents as this might damage the finish. Use a clean dry cloth.
CLASS 1 LASER PRODUCT
• Operate controls and switches as described in the manual.
• Before turning ‘On’ the power, make certain that the speakers are properly installed.
• Store your cassette tapes and CDs in a cool area to avoid damage from heat.
• When mov ing the set, be sure to first dis connect the power cord and remove cords connected to other equipment.
CLASS 1 LASER PRODUCT APPAREIL Á LASER DE CLASSE 1 PRODUCTO LASER DE CLASE 1
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
AVOID EXPOSURE TO BEAM
CAUTION
DEFEATED.
This product contains a low power Laser Device.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, purs uant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may
cause undesired operation.
MS9700_ib021903.p65 19/2/2003, 9:233
3
PREPARA TION FOR USE
UNPACKING
• Remove the main unit and the speakers from the carton and remove all packing materials from the components.
• Remove any descriptive labels from the fronts of the main unit and speakers.
• Remove any small strips of tape that may have been used to secure the cassette door or CD drawer in transit.
PLACEMENT
• Place the unit on a stable, level table, shelf or stand c onvenient to an AC outlet.
• The unit should not be exposed to direct sunlight or sources of ex cess heat, moisture, dust, vibration, or humidity.
• The speakers may be positioned along side the main unit, or separated as far as the cords will allow for maximum stereo separation. You should maintain a gap of at least one inch between the main unit and the speak ers to prevent any skipping of the CD player when the unit operated at high volume.
PROTECT YOUR FURNITURE !!
This model is equipped with non-skid rubber 'feet' to prevent the product from moving when you operate the controls. These 'feet' are made from non-migrating rubber material specially formulated to avoid leaving any marks or stains on your furniture. However certain types of oil based furniture polishes, wood preservatives, or c leaning sprays may cause the rubber 'feet' to soften, and leave marks or a rubber residue on the furniture. To prevent any damage to your furniture we strongly recommend that you purchase small self-adhesive felt pads, available at hardware stores and home improvement centers everywhere, and apply these pads to the bottom of the rubber 'feet' before you place the product on fine wooden furniture.
4
MS9700_ib021903.p65 19/2/2003, 9:234
SPEAKER CONNECTION
Black
The speaker cables and the speaker terminals on the back of the main unit are color coded for your convenience. Connect the cables from the left speaker to the “LEFT” terminals, and the cables from the right speaker to the “RIGHT” terminals.
To connect the speaker cable to the terminal depres s the plastic tab below the terminal, insert the bare wire at the end of the cable into the terminal opening, and release the plastic tab to lock the wire in place.
Red
RIGHT
LEFT
Be sure to connect the Red cables to the Red terminals and the Black cables to the Black terminals. If the speakers are connected incorrectly the sound may be “muddy” and distorted.
RIGHT LEFT
5
MS9700_ib021903.p65 19/2/2003, 9:235
AC Outlet
CONNECTING THE AC POWER CORD
After connecting the speakers unwind the AC power cord fully and connect it to any convenient household AC outlet. This system is designed to operate on 120V 60Hz AC power only. Connecting this system to any other power supply may cause damage to the unit which is not covered by your warranty.
This unit has a polarized AC plug with one wide blade and one narrow blade.This plug will only fit into a matc hing polarized AC outlet. This is a safety feature to reduce the possibility of electric shock. If this plug will not fit in your AC outlet, you probably have an outdated non-polarized outlet. You should have your outdated outlet changed by a qualified, licensed electrician. Do not file the wide blade on the plug, or use an adapter to make the plug fit into your outlet. This defeats the safety feature and could expose you to electric shock.
MS9700_ib021903.p65 19/2/2003, 9:236
AC Plug
6
ANTENNA INFORMATION
RIGHT
FM
This unit has an external lead wire FM antenna permanently attached to the back of the main cabinet. Unwrap this antenna wire, extend it to its full length, and allow it to hang down from the back of the set. In some cases you may have to vary the direction of this antenna until you find the position that provides the best reception, and then use a small piece of tape to secure the antenna in that position.
LEFT
FM WIRE ANTENNA
AM
This system has a built in AM ferrite bar antenna. You may have to vary the position and direction of this main unit until you find the position that provides the clearest reception for each of your favorite AM stations.
7
MS9700_ib021903.p65 19/2/2003, 9:237
LOCATION OF CONTROLS AND INDICATORS
FRONT
REAR
REMOTE
SENSOR
1
12
26252423222120191718151614
13
FRONT PANEL
2
3 4
5 6
7 8 9
10
11
SKIP/SEARCH
1.) CD DIRECT ACCESS Buttons.
2.) Multifunction LCD Display.
3.) 6 CD Changer Tray.
4.) POWER ON Indicator.
5.) SURROUND ( ON / OFF)
Button.
6.) POWER (On/Off) Button.
7.) VOLUME (UP/DN) Buttons.
8.) PHONES Jack.
9.) X-BASS ( ON / OFF) Button.
10.) FUNCTION (CD/TUNER/TAPE)
Selector.
11.) Cassette Door.
12.) Cassette Deck Control Keys.
(RECORD-PLAY-REWIND-F. FWD
-STOP/EJECT-PAUSE)
MS9700_ib021903.p65 19/2/2003, 9:238
13.) DISC SCAN Button.
14.) CD Reverse SKIP/SEARCH Button.
15.) CD Forward SKIP/SEARCH Button.
16.) CD STOP Button.
17.) CD PLAY/PAUSE Button.
18.) REPEAT Button.
19.) BAND (FM ST/FM/AM) Selector.
20.) TUNING Control.
21.) PROGRAM Button.
22.) OPEN/CLOSE (FRONT) Button.
23.) OPEN/CLOSE (REAR) Button.
24.) FM STEREO Indicator.
25.) REMOTE SENSOR.
26.) Dial Scale & Pointer.
8
RIGHT
BACK PANEL
27
LEFT
28
27.) FM Wire ANTENNA.
28.) Speaker Terminals.
29.) AC Power Cord.
MS9700_ib021903.p65 19/2/2003, 9:239
29
