HOME AUDIO SYSTEM
with CD PLAYER
and CASSETTE RECORDER
IMPORTANT
Call toll-free 1-800-210-2281 for exciting information
and special discounts on Extended Service Plans.
OWNER'S MANUAL
MS7 625BL
Visit our web site at www.emersonradio.com
MS7625_ib.p6502/19/2001, AM 11:0019
Thank you………………………………..
for purchasing this Emerson audio system. This compact unit has been designed
to take up a minimum of space, while still provi ding an AM/FM stereo radio, a compact
disc player and a c assette player/recorder. The CD player has a 19-track
programmable memory and high-speed music search. The cassette player/recorder
will record directly from the radio, or from the CD player. There is a pair of matching
stereo speakers for when you want to share the music with others, and a stereo
headphone jack for private listening.
Please read and review this manual completely to familiarize yourself with all the
features of your new audio system and please be sure to save this manual for
future reference. Your Warranty is located on the back page of this manual.
The serial number of your unit is located on a label on the back panel. We suggest
that you record the serial number in the space below for future reference.
Model No. MS7625BL
Serial No.
CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a low power Laser Device.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER(OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product's enclos ure.
ATTENTION
The Owner's Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
MS7625_ib.p6502/19/2001, AM 10:581
1
IMPORTANT NOTES
• Avoid installing this unit in places
exposed to direct sunlight or
close to hea t radi ating
appliances such as electric
heaters, on top of other stereo
equipment that radiates heat,
places lacking ventilation or
dusty areas, places subject to
constant vibration and/or humid
or moist areas.
• Do not attempt to clean this unit
with chemical solvents as this
might damage the finish. Use a
• Operate controls and switches
as described in the manual.
• Before turning on the power,
make certain that the connecting
cords and power cord are
properly installed.
• Store your cassette tapes and
CDs in a cool area to avoid
damage from heat.
• When moving the set, be sure
to first disconnect the power cord
and remove cords connected to
other equipment.
clean dry cloth.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reas onable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions , may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technic ian for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
2
MS7625_ib.p6502/19/2001, AM 10:582
PREPARATION FOR USE
UNPACKING AND SET-UP
• Remove the main unit and speakers from the carton and remove all pack ing
materials from the components. Please save the carton and packing materials,
if possible, in case the unit ever needs to be returned for service. The original
carton and packing materials are the only way to protect the unit from damage
in transit.
• Remove any descriptive labels or stickers from the front or top of the units. Do
not remove any labels from the back or bottom of the units.
• Some systems are shipped with a paper/cardboard “disc” in the CD compartment.
The purpose of this “disc” is to prevent the delicate laser from moving during
shipment. Press the CD OPEN button to open the CD door. If there is any paper/
cardboard disc in the compartment, carefully remove and discard it now.
• Remove the twist-tie from the AC power cord and extend it to its full length.
• Unwind the FM lead wire antenna and extend it to its full length.
• Place the main unit in the desired loc ation. It should be on a level surface,
convenient to an AC outlet, and away from direct sunlight or sources of heat,
dust, moisture or humidity. Do not block the ventilation slots on the back of the
main unit.
• Set the FM MODE (BEAT CUT) switch on the back panel to the STEREO
position, if necessary.
SPEAKER CONNECTION
• Connect the speakers before you plug the unit in.
• Unwind the speaker cords completely and connect the speaker plugs to the left/
right speaker jacks on the back panel.
• You may place the speakers alongside the main unit or separate them as far as
the cords will allow for maximum stereo separation.
Note:If you do place the speakers alongside the main unit, it is recommended to
allow a small gap between the unit and the speakers. This will reduce the
possibility of the CD player skipping when the set is played at high volume.
3
MS7625_ib.p6502/19/2001, AM 10:583
• You may wrap any excess speaker wire around the wire holders on the back of
each speaker cabinet.
POWER SUPPLY
• After connecting the speak ers and extending the FM lead wire antenna as
described above, you are ready to connect the AC plug to a 110 -120V 60Hz AC
outlet.
• This unit has a polarized AC plug with one wide blade and one narrow blade.
This plug will only fit into a matching polarized AC outlet. This is a safety feature
to reduce the possibility of electric shock. If this plug will not fit in your AC outlet,
you probably have an outdated non-polarized outlet. You should hav e your
outdated outlet changed by a qualified, licensed electrician. Do not file the wide
blade on the plug, or use an adapter to mak e the plug fit into your outlet. This
defeats the safety feature and could expose you to electric shock.
• This set is designed to operate on 110 -120V 60Hz AC house current only.
Operating this set on any other power supply may cause damage to the unit
which is not covered by your warranty.
4
MS7625_ib.p6502/19/2001, AM 10:584
LOCATION OF CONTROLS AND INDICATORS
12
13
14
11
10
9
8
7
6
5
4
3
2
1
15
16
17
18
19
20
21
22
23
26
17
16
24
25
FRONT PANEL
1.Cassette Keys (Behind Door)
REC; PLAY; REWIND; F.FWD;
STOP/EJECT; PAUSE.
2.Cassette Door.
3.Function Selector.
(CD; TAPE; RADIO)
4.VOLUME Control.
5.Band Selector (AM; FM)
6.CD REPEAT Button.
7.CD SKIP/SEARCH / Buttons.
8.CD STOP Button.
9.TUNING Dial.
10.CD PROGRAM Indicator.
11. FM STEREO Indic ator.
12.CD Door.
13.CD Door OPEN Button.
MS7625_ib.p6502/19/2001, AM 10:595
14.CD Track Number Display.
15.POWER ‘On’ Indicator.
16.CD PLAY/PAUSE Indicator.
17.CD REPEAT Indicator.
18.CD PLAY/PAUSE Button.
19.TUNING Knob.
20.CD PROGRAM Button.
21.POWER On/Off Button.
BACK PANEL
22.FM MODE (STEREO/MONO);
BEAT CUT Switch.
23.External FM Wire Antenna.
24.SPEAKER Jacks.
25.PHONES(Stereo Headphone) Jack.
26.AC Power Cord.
5
