Figure 1. Typical MR95 Series Industrial Pressure Regulators
P1753
TYPE MR95H
www.fisherregulators.com
D103742X012
Bulletin 71.1:MR95
Specications
This section lists the specications for the MR95 Series regulators. Factory specication such as type, maximum inlet
pressure, maximum temperature, maximum outlet pressure, spring range, orice size and seat material are stamped on the
nameplate fastened on the regulator at the factory.
Available Constructions
Type MR95L: Low-pressure regulator for 2 to 30 psig /
0.14 to 2.1 bar outlet pressures
Type MR95H: High-pressure regulator for 5 to
150 psig / 0.34 to 10.3 bar outlet pressures
Type MR95HP: High-pressure regulator for 15 to
400 psig / 1.0 to 27.6 bar outlet pressures (soft-seated)
Type MR95HT: High-pressure/high-temperature
regulator for 15 to 300 psig / 1.0 to 20.7 bar outlet
pressures (metal seat) and up to 650°F / 343°C
Type MR95LD: Low-pressure differential regulator for
2 to 30 psi / 0.14 to 2.1 bar differential pressures with
handwheel and packing box
Type MR95HD: High-pressure differential regulator for
5 to 150 psi / 0.34 to 10.3 bar differential pressures with
handwheel and packing box
Body and Orice Sizes
1/4 NPT body:
0.284 in. / 7.22 mm orice
1/2 in. / DN 15 body:
0.416 in. / 10.56 mm orice
3/4 and 1 in. / DN 20 and 25 bodies:
0.631 in. / 16.02 mm orice
1-1/2 and 2 in. / DN 40 and 50 bodies
(not available for Types MR95L and MR95LD):
1.142 in. / 29 mm orice
End Connection Styles
NPT, SWE and Welded and Integral CL150 RF,
CL300 RF, CL600 RF and PN 16/25/40 RF;
all sizes are fabricated with slip-on anges (for welded
end connections) and are 14 in. face-to-face
(EN anged-356 mm face-to-face)
See Tables 1 and 2
Maximum Cold Working Pressures of Body Size
and Material
(1)
See Table 4
Outlet or Differential Pressure Ranges
(1)
See Table 3
Maximum Temperature Ranges of Diaphragm and
Seat Materials
-40 to 180°F / -40 to 82°C
0 to 300°F / -18 to 149°C
20 to 275°F / -7 to 135°C
0 to 425°F / -18 to 218°C
-40 to 400°F / -40 to 204°C
-40 to 650°F / -40 to 343°C
Maximum Temperature Ranges of
Body Materials
SPRING CASE MATERIALS
Aluminum-Bronze
(1)(2)
BODY AND
Gray Cast Iron
WCC steel
LCC steel
Stainless steel
®
Monel
Hastelloy® C
TEMPERATURE RANGE
(4)
(4)
(4)
-20 to 406°F / -29 to 208°C
-20 to 650°F / -29 to 343°C
-40 to 650°F / -40 to 343°C
-40 to 550°F / -40 to 288°C
-40 to 550°F / -40 to 288°C
-40 to 550°F / -40 to 288°C
-40 to 500°F / -40 to 260°C
Spring Case Construction
Drilled Untapped Hole:
Standard for Types MR95L, MR95H, MR95HP
and MR95HT
1/4 NPT Vent:
Standard for Types MR95LD and MR95HD
Optional for Types MR95L, MR95H, MR95HP
and MR95HT
Pressure Setting Adjustment
Adjusting screw:
Standard for Types MR95L, MR95H, MR95HP
and MR95HT only
Handwheel:
Standard for Types MR95LD and MR95HD
Optional for 1/2 in. / DN 15 body size of
Types MR95L, MR95H, MR95HP and MR95HT
Tee handle:
Optional for other body sizes (except 1/2 in. /
DN 15) of Types MR95L, MR95H, MR95HP
and MR95HT
Pressure Registration
Internal or External
Typical Regulating Capacities
Air: See Tables 10, 11, 12, 13 and 14
Steam: See Tables 15, 16, 17, 18 and 19
Water: See Tables 20, 21, 22, 23 and 24
Shutoff Classication Per ANSI/FCI 70-3-2004
Metal Seats: Class IVElastomer Seats: Class VI or better
PTFE: Class lV
Flow and Sizing Coefcients
See Table 5
Relief Sizing Coefcients for MR95 Series Regulators
with Reduced Flow Orices
See Table 6
1. The pressure/temperature limits in this Bulletin, and any applicable standard or code limitation for this regulator should not be exceeded.
2. Pressures and/or the body end connection may decrease these maximum temperatures.
3. Fluorocarbon (FKM) is limited to 200°F / 93°C hot water.
4. Meets API 614 requirements (with Stainless steel trim).
- continued -
Monel® is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
2
Specications (continued)
Bulletin 71.1:MR95
Main Valve Construction Materials
See Table 8
Trim Materials
See Table 7
Product Dimension
See Figure 3
Common Services and Material Compatibility
See Table 9
Introduction
The MR95 Series regulators are compact, large-capacity,
direct-operated pressure regulators (see Figure 1). The units
are available in 1/4 NPT through 2 in. / DN 50 sizes and are
offered in several different end connection congurations.
They are designed to handle pressures up to 1000 psig /
68.9 bar and temperatures up to 650°F / 343°C.
These products can help solve the toughest pressure control
applications. Typical applications include superheated steam,
steam injection, steam tracing, nitrogen purging, boiler feed
water, process chemicals, cooling water, test xtures, wash
tanks, sterilizers/autoclaves, fuel lines, pneumatic supply and
many others.
Features
• Handwheels/Tee Handles—Allow easy pressure
setting changes and are standard on Types MR95LD
and MR95HD, and optional on the Types MR95L,
MR95H, MR95HP and MR95HT regulators.
• Versatile—Can be used with all process media
including air, steam, gas, water, liquids (oils and
process chemicals) and oxygen.
• Tight Shutoff With Elastomer Seats—Metal seats
available for high temperatures.
• Direct-Operated—Design maximizes speed
of response.
• Robust—Up to 1000 psig / 68.9 bar inlet pressure.
• P1 = P2—Inlet equals outlet rating in Types MR95H and
MR95HD up to 300 psig / 20.7 bar.
• Rugged Construction—Available in a variety of body
and spring case materials to address the toughest service
conditions. Severe service elastomers and corrosion
resistant trims are also available and provide excellent
uid compatibility.
Approximate Weights
MR95H Series
1/4 NPT body: 5 lbs / 2.3 kg1/2 in. / DN 15 body: 10 lbs / 4.5 kg3/4 and 1 in. / DN 20 and 25 bodies:
22 lbs / 10 kg1-1/2 and 2 in. / DN 40 and 50 bodies:
55 lbs / 25 kg
MR95L Series
1/4 NPT body: 7 lbs / 3.2 kg1/2 in. / DN 15 body: 15 lbs / 6.8 kg3/4 and 1 in. / DN 20 and 25 bodies:
35 lbs / 16 kg
• Differential Pressure Capability—Spring-loaded
Polytetrauoroethylene (PTFE) packing and
tapped connections permit pressure loading of the
Types MR95LD and MR95HD spring cases.
• Special Service Capabilities—Optional materials
are available for applications handling sour gases,
cryogenics and superheated steam.
• Large Turndown Ratio—No need for low Cv trims at
low ows.
• Graphite Gaskets—For high temperature applications
up to 650°F / 343°C (optional).
• Set Pressures up to 400 psig / 27.6 bar
• Multiple End Connection Options—To match
your application.
• Easy Maintenance—Seating parts are easily accessible
by removing the plug on the bottom of the regulator.
• API 614 Compliant—Steel and Stainless steel
constructions meet API 614 requirements.
Principle of Operation
The MR95 Series (refer to Figure 2) is a direct-operated
regulator. Downstream pressure is registered internally
or externally through a control line to the under side of
the diaphragm. When the downstream pressure is at or
above the set pressure, the disk is held against the orice,
restricting uid ow through the regulator. When demand
increases, downstream pressure drops slightly allowing the
spring to extend, moving the stem down and the disk away
from the orice. This allows uid ow through the body to
the downstream system. Types MR95H, MR95L, MR95HP
and MR95HT use spring force to regulate outlet pressure.
Types MR95HD and MR95LD use spring force to maintain
a differential pressure between spring case loading
pressure and outlet pressure.
Type 95HD Differential Pressure Reducing Regulator
M1006
October 2006
Type 95HD
HANDWHEEL
CONTROL SPRING
PRESSURE A*
(SPRING CASE
LOADING
PRESSURE)
Bulletin 71.1:MR95
DIAPHRAGM
PITOT TUBE
STEM
ORIFICE
VALVE PLUG
FRONT AND INTERNAL VIEW OF
TYPE MR95HD WITH INTERNAL PRESSURE REGISTRATION
PRESSURE A +
SPRING SETTING =
PRESSURE B
PRESSURE B
(OUTLET
PRESSURE)
TYPE MR95HD WITH EXTERNAL PRESSURE REGISTRATION
BACK VIEW OF
SPRING
GASKET
TYPE MR95H WITH 2 METAL DIAPHRAGMS (ALSO TYPICAL OF
TYPES MR95HT AND MR95L EXCEPT FOR TYPE MR95L WITH 1/4 NPT
BODY SIZE, 2 to 6 psi / 0.14 to 0.41 bar RANGE)
METAL DIAPHRAGMS
SPRING
GASKET
TYPE MR95L (1/4 NPT, 2 to 6 psi / 0.14 to 0.41 bar RANGE)
WITH METAL DIAPHRAGM
CONTROL LINE TAP
METAL DIAPHRAGM
INLET PRESSURE
OUTLET PRESSURE
LOADING PRESSURE
*PRESSURE A MAY BE SUPPLIED BY ANOTHER PRESSURE SYSTEM OR A MANUAL LOADING REGULATOR.
Figure 2. MR95 Series Operational Schematics (continued)
5
Bulletin 71.1:MR95
Table 1. Types MR95L and MR95LD Regulators Body Constructions
BODY SIzEBODY CONSTRUCTIONEND CONNECTION
1/4 NPTWithout Control Line and Gauge PortNPT
Without Control Line and Gauge Port
1/2 in. / DN 15
With Control Line but Without Gauge Port
Without Control Line and Gauge Port
3/4 in. / DN 20
1 in. / DN 25
- Shaded areas indicate that the construction is available.
- Blank areas indicate that you need to contact your local Sales Ofce for the availability of the constructions.
With Control Line but Without Gauge Port
With Gauge Port but Without Control Line
Without Control Line and Gauge Port
With Control Line but Without Gauge Port
With Gauge Port but Without Control Line
NPT
SWE
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
SWE
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
SWE
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
BODY MATERIAL
Gray Cast Iron
LCC or WCC Steel
CF8M Stainless Steel
CF3M Stainless Steel
C
®
or Hastelloy
®
Monel
®
is a mark owned by Special Metals Corporation.
Monel
Hastelloy® C is a mark owned by Haynes International, Inc.
6
Table 2. Types MR95H, MR95HD, MR95HT and MR95HP Regulators Body Constructions
BODY SIzE
1/4 NPTWithout Gauge Port and Control LineNPT
Without Control Line and Gauge Port
1/2 in. / DN 15
With Control Line but Without Gauge Port
Without Gauge Port and Control Line
3/4 in. / DN 20
With Control Line but Without Gauge Port
With Gauge Port but Without Control Line
1 in. / DN 25Without Gauge Port and Control Line
- Shaded areas indicate that the construction is available.
- Blank areas indicate that you need to contact your local Sales Ofce for the availability of the constructions.
1. Gray cast iron body material is available for Types MR95H and MR95HD only.
BODY
CONSTRUCTION
END CONNECTION
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/40 RF
Integral CL150 RF
Integral CL300 RF
Integral CL600 RF
Integral PN 16/25/40 RF
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/60 RF
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/40 RF
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/60 RF
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/60 RF
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/40 RF
Integral CL150 RF
Integral CL300 RF
Integral CL600 RF
Integral PN 16/25/40 RF
Bulletin 71.1:MR95
BODY MATERIAL
C
®
or Hastelloy
®
CF8M Stainless Steel
CF3M Stainless Steel
Monel
NPT
SWE
NPT
NPT
SWE
NPT
NPT
NPT
SWE
(1)
Gray Cast Iron
LCC or WCC Steel
Aluminum-Bronze
®
Monel
is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
- continued -
7
Bulletin 71.1:MR95
Table 2. Types MR95H, MR95HD, MR95HT and MR95HP Regulators Body Constructions (continued)
BODY SIzE
With Control Line but Without Gauge Port
1 in. / DN 25
With Gauge Port but Without Control Line
Without Gauge Port and Control Line
1-1/2 in. / DN 40
With Control line but Without Gauge Port
With Gauge Port but Without Control Line
Without Gauge Port and Control Line
2 in. / DN 50
With Control Line but Without Gauge Port
With Gauge Port but Without Control Line
- Shaded areas indicate that the construction is available.
- Blank areas indicate that you need to contact your local Sales Ofce for the availability of the constructions.
1. Gray cast iron body material is available for Types MR95H and MR95HD only.
BODY
CONSTRUCTION
END CONNECTION
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
SWE
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
SWE
Welded CL150 RF
Welded CL300 RF
Welded CL600 RF
Welded PN 16/25/40 RF
Integral CL150 RF
Integral CL300 RF
Integral CL600 RF
Integral PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
NPT
Welded CL150 RF
Welded CL300 RF
Welded PN 16/25/40 RF
BODY MATERIAL
(1)
Gray Cast Iron
LCC or WCC Steel
CF8M Stainless Steel
C
®
or Hastelloy
®
Aluminum-Bronze
CF3M Stainless Steel
Monel
®
Monel
is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
8
Bulletin 71.1:MR95
Table 3. Body Sizes, Pressure Ranges and Spring Information
TYPE
MR95L
and
MR95LD
MR95H
and
MR95HD
MR95HT
MR95HP
1. For Types MR95LD and MR95HD regulators, the pressure ranges indicate the differential pressure that can be obtained with the indicated spring. The differential pressure
(spring setting) is added to the spring case loading pressure to determine the actual outlet pressure.
2. Springs meet NACE MR0175-2002 and NACE MR0103 requirements only for applications in which the spring is not exposed to the sour gas.
BODY SIzE
In.DNpsi/psigbarIn.mmIn.mm
1/4- - - -
1/215
3/4
and 1
3/4
and 1
1/4- - - -
1/215
3/4
and 1
3/4
and 1
1-1/2
and 2
1/4- - - -
1/215
3/4
and 1
1-1/2
and 2
1/4- - - -
1/215
3/4
and 1
1-1/2
and 2
OUTLET OR DIFFERENTIAL
PRESSURE RANGE
2 to 6 0.14 to 0.41 0.1483.762.00 50.8Zinc-plated steel1E392527022Yellow
5 to 15 0.34 to 1.00.1704.322.0050.8Zinc-plated steelERAA01888A0Green
13 to 30 0.90 to 2.10.2075.261.9449.2Powder-coated steelERAA01889A0 Red
2 to 6 0.14 to 0.41 0.2075.262.50 63.5Powder-coated steelERCA04288A0Yellow
5 to 15 0.34 to 1.00.2345.942.6065.9Powder-coated steelERAA01910A0Green
13 to 30 0.90 to 2.10.2837.192.4462.0Powder-coated steelERAA01911A0Red
2 to 6 0.14 to 0.41 0.3067.774.00 102Powder-coated steel1E398927022 Yellow
20
and 25
and 25
and 25
and 25
and 50
and 25
and 50
and 25
and 50
5 to 15 0.34 to 1.00.3438.714.00102Powder-coated steel1E399027142Green
13 to 30 0.90 to 2.10.406 10.314.00102Powder-coated steel1E399127162Red
2 to 6 0.14 to 0.41 0.3067.774.00 102Powder-coated Stainless steel1E3989X0052 Yellow
20
5 to 15 0.34 to 1.00.3759.533.8898.6Stainless steel1K762537022Unpainted
13 to 30 0.90 to 2.10.43711.14.00102Stainless steel11A8269X012Unpainted
15 to 301.0 to 2.10.1483.762.00 50.8Zinc-plated steel1E392527022Yellow
25 to 751.7 to 5.2 0.1704.322.00 50.8Zinc-plated steelERAA01888A0 Green
70 to 1504.8 to 10.30.2075.261.9449.2Powder-coated steelERAA01889A0Red
15 to 301.0 to 2.10.2075.262.50 63.5Powder-coated steelERCA04288A0 Yellow
25 to 751.7 to 5.20.2345.942.6065.9Powder-coated steelERAA01910A0 Green
70 to 1504.8 to 10.30.2837.192.4462.0Powder-coated steelERAA01911A0Red
15 to 301.0 to 2.10.3067.774.00 102Powder-coated steel1E398927022 Yellow
20
25 to 751.7 to 5.20.3438.714.00102Powder-coated steel1E399027142Green
70 to 1504.8 to 10.30.406 10.314.00102Powder-coated steel1E399127162Red
15 to 301.0 to 2.10.3067.774.00 102Powder-coated Stainless steel1E3989X0052 Yellow
20
25 to 751.7 to 5.20.3759.533.8898.6Stainless steel1K762537022Unpainted
70 to 1504.8 to 10.30.43711.14.00102Stainless steel11A8269X012Unpainted
5 to 800.34 to 5.50.50012.76.50165Powder-coated steelERCA04290A0
40
60 to 1204.1 to 8.30.56214.36.56167Powder-coated steelERAA01893A0Light Gray
100 to 1406.9 to 9.70.59415.16.56167Enamel-coated steelERAA01894A0 Yellow
120 to 1508.3 to 10.30.62515.96.57167Powder-coated steel1P7888X0022Black
15 to 1001.0 to 6.90.1924.882.00 50.8Inconel
80 to 3005.5 to 20.70.2817.142.0050.8Inconel
15 to 1001.0 to 6.90.2817.142.50 63.5Inconel
80 to 3005.5 to 20.70.3759.532.6066.0Inconel
15 to 1001.0 to 6.90.43711.14.08 10417-4 PH Stainless steelERCA04295A0Unpainted
20
80 to 3005.5 to 20.70.56214.34.0810417-4 PH Stainless steelERCA04296A0Unpainted
15 to 1001.0 to 6.90.62515.9
40
60 to 2604.1 to 17.90.81220.66.7017017-4 PH Stainless steelERCA04298A0 Unpainted
15 to 100 1.0 to 6.90.1924.882.00 50.8Inconel
80 to 4005.5 to 27.60.2817.142.0050.8Inconel
15 to 100 1.0 to 6.90.2817.142.50 63.5Inconel
80 to 4005.5 to 27.60.3759.532.6066.0Inconel
15 to 100 1.0 to 6.90.43711.14.08 10417-4 PH Stainless steelERCA04295A0Unpainted
20
80 to 4005.5 to 27.60.56214.34.0810417-4 PH Stainless steelERCA04296A0 Unpainted
15 to 1001.0 to 6.90.62515.96.7017017-4 PH Stainless steelERCA04297A0 Unpainted
40
60 to 3004.1 to 20.70.81220.66.7017017-4 PH Stainless steelERCA04298A0Unpainted
1. The pressure/temperature limits in this Bulletin and any applicable standard or code limitation should not be exceeded.
2. The pressure limits given are based on the body size and body materials only. Actual pressure limits of the assembled regulator may decrease and vary depending on the temperature,
body end connection, diaphragm, seat and/or trim material of the regulator.
3. See Tables 1 and 2 for all available body sizes.
4. Not available for 1/4 NPT body size.
Table 5. Flow and Sizing Coefcients for all MR95 Series Regulators
BODY SIzE
In.DNC
1/4- - - -1.1371.8533.60.740.7150.620.86
1/2152.91035.1535.50.790.7970.700.89
3/4 and 120 and 256.022111.0536.80.880.8570.680.94
1-1/2 and 240 and 5018.170035.0038.70.880.9450.650.94
2
K
= F
m
L
Table 6. Relief Sizing Coefcients for MR95 Series Regulators with Reduced Flow Orices
In.DNC
1/4- - - -2828
1/2157067
3/4 and 120 and 25156156
1-1/2 and 240 and 50482475
1. The reduced ow orice option offers similar ow capacity as the equivalent 95 series conguration.
Monel® is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
1. Two Diaphragms are used for metal diaphragm except Types MR95L and MR95LD 1/4 NPT Body, range 2 to 6 psig / 0.14 to 0.41 bar.
2. Two Diaphragms are used.
(1)
Monel®
(1)
, Fluorocarbon (FKM)
(1)
, Fluorocarbon (FKM)
Neoprene (CR) and Fluorocarbon (FKM)
(2)
, Ethylenepropylene (EPDM)
(2)
, Ethylenepropylene (EPDM)
®
®
®
®
®
, Hastelloy® C or Alloy 6
®
®
, Hastelloy® C or Alloy 6
®
17-4 PH Stainless steel
or Hastelloy® C
or Hastelloy® C
or Hastelloy® C
or Hastelloy® C
(2)
diaphragm
or Hastelloy® C
or Hastelloy® C
Steel (standard)
302 Stainless steel
(2)
, Monel
(2)
or PTFE protector available with
Inconel
®(1)
, Hastelloy® C
(2)
diaphragm
®
(1)
or
Inconel® is a mark owned by Special Metals Corporation.
Monel® is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
Hastelloy® C is a mark owned by Haynes International, Inc.
12
Bulletin 71.1:MR95
Installation
The MR95 Series regulators may be installed in any
position, as long as ow will be in the same direction as that
indicated by the body arrow. The Types MR95H, MR95L,
MR95HT and MR95HP regulators should be installed so
that their spring case vents are protected from anything that
might clog them.
Emerson Process Management Regulator Technologies, Inc.
(Emerson™) provides an instruction manual with every regulator
shipped. Refer to this for complete installation, operation and
maintenance instructions. Included is a complete list of individual
parts and recommended spare parts.
Universal NACE Compliance
Optional materials are available for applications handling sour
gases. These constructions comply with the recommendations
of NACE International sour service standards.
The manufacturing processes and materials used by
Emerson assure that all products specied for sour gas
service comply with the chemical, physical and metallurgical
requirements of NACE MR0175 ISO-2002 and/or
NACE MR0103. Optional materials are available to meet
ANSI/NACE MR0175/ISO 15156, please contact your local
Sales Ofce for special ordering instructions. Customers have
the responsibility to specify correct materials. Environmental
limitations may apply and shall be determined by the user.
Capacity Data
The capacity information on the following pages is based on
three droop factors, 10%, 20% and 40%. Droop is deviation
from the setpoint of the regulator, and is usually stated in
percentage of setpoint value.
For highest capacity and the most accurate control within a
particular type of the MR95 Series regulators, use the lowest
range spring that can be adjusted to the desired setpoint
(see Table 3 for part numbers of appropriate springs for
each body size).
If closer control is necessary, a regulator of larger capacity
or different design should be selected, so that the necessary
ow can be obtained with a smaller droop factor.
Sometimes it may be necessary to interpolate the capacity
table data to determine capacity for outlet settings not given.
To maintain accuracy, it is important when interpolating to
stay within a spring range if possible. The following is a
procedure for interpolating the data to calculate ow:
1. Determine which spring is to be used.
2. Find the two outlet settings (P2a and P2b) that bracket
the actual outlet pressure P2.
3. For a given body size and inlet pressure, nd the
capacity Qa for P2a and Qb for P2b.
4. Use the following formula to determine the interpolated
capacity (Q):
Qb - Qa Qb - Q
P
b - P2a
Example:
P1 = 100 psig / 6.9 bar
1/4 NPT Type MR95H with 15 to 30 psig / 1.0 to 2.1 bar
spring range
P
= 20 psig / 1.4 bar
2
Determine air capacity, Q
Solution:
Qa = 1100 SCFH / 28.8 Nm3/h
P2a = 15 psig / 1.0 bar
Qb = 1700 SCFH / 46.5 Nm3/h
b = 30 psig / 2.1 bar
P
2
Q = 1300 SCFH
Q = 35 Nm
The same interpolation procedure can be
used for different inlet pressures.
Contact your local Sales Ofce if you should have any
questions about selecting the proper regulator.
2
1700 - 1100 1700 - Q
30 - 15 30 - 20
46.5 - 28.8 46.5 - Q
2.1 - 1.0 2.1 - 1.4
3
/h
=
Note
P2b - P
=
=
2
Air Capacities
Regulating capacities at selected pressures and outlet
pressure ows are given in SCFH (60°F and 14.7 psia)
of air. To determine the equivalent capacities for other gases,
multiply the table capacities by the following appropriate
conversion factors: 1.29 for 0.6 specic gravity natural gas,
0.808 for propane, 0.707 for butane or 1.018 for nitrogen.
For gases of other specic gravities, divide by the square root
of the appropriate specic gravity.
Then, if capacity is desired in Nm3/h at 0°C and 1.01325 bar,
multiply SCFH by 0.0268.
Capacities in Tables 10, 11, 12, 13 and 14 are for regulators
using elastomer diaphragms. Depending on regulator
construction, a multiplier must be used to convert to capacities
for regulators using metal diaphragms.
13
Bulletin 71.1:MR95
Table 10. Air Capacities
(1)(2)
in SCFH / Nm3/h for 1/4 NPT and 1/2 through 1 in. / DN 15 through 25 Types MR95L and MR95LD
Regulators with Elastomer Diaphragm
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE
RANGE,
psig/psi / bar
2 to 6 /
0.14 to 0.41
5 to 15 /
0.34 to 1.0
13 to 30 /
0.90 to 2.1
1. To obtain capacities for regulators using metal diaphragms, multiply the table values by 0.8.
2. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
To determine wide-open ow capacity for relief valve sizing of air
at a temperature of 60°F, use the equation for critical pressure
drops (absolute outlet pressure equal to one-half or less than
one-half the absolute inlet pressure).
Q = P
1(abs)Cg
where,
Q = Gas ow, SCFH (60°F and 14.7 psia)
P
= Absolute inlet pressure, psia (add 14.7 psi
1(abs)
to gauge inlet pressure to obtain absolute
inlet pressure)
C
= Wide-open gas sizing coefcient from
g
Table 5
For pressure drops lower than critical (absolute outlet
pressure greater than one-half the absolute inlet pressure),
use the sizing nomographs in Fisher
®
Catalog 10, or the
Fisher Sizing Program.
To obtain capacities in Nm3/h at 0°C and 1.01325 bar,
multiply the capacity determined in SCFH by 0.0268.
14
Steam Capacities
Capacities in Tables 15, 16, 17, 18 and 19 are in lbs/h
of saturated steam. To obtain capacities in kg/h, multiply
the capacities given in the table by 0.4535. Capacities
have been calculated for stainless steel diaphragms only
since steam service exceeds the elastomer diaphragm
temperature limits.
To determine wide-open ow capacity for relief valve sizing
of steam, use the equation for critical pressure drops
(absolute outlet pressure equal to one-half or less than onehalf absolute inlet pressure).
Q = P
1(abs)Cs
where,
Q = Steam ow, lbs/h
P
Cs = Wide-open steam sizing coefcient from
= Absolute inlet pressure, psia (add 14.7 psi
1(abs)
to gauge inlet pressure to obtain absolute
inlet pressure)
Table 5
Bulletin 71.1:MR95
Table 11. Air Capacities
(1)(2)
in SCFH / Nm3/h for 1/4 NPT and 1/2 through 1 in. / DN 15 through 25Types MR95H and MR95HD
Regulators with Elastomer Diaphragm
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE
RANGE,
psig/psi / bar
15 to 30 /
1.0 to 2.1
25 to 75 /
1.7 to 5.2
70 to 150 /
4.8 to 10.3
1. To obtain capacities for Type MR95HT (metal diaphragm), multiply the table values by 0.6.
2. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
For pressure drops lower than critical (absolute outlet
pressure greater than one-half absolute inlet pressure),
use the sizing nomographs in the Fisher® Sizing Program.
Water Capacities
All water capacities in Tables 20, 21, 22, 23 and 24 are in
gallons per minute (GPM). Capacities in Tables 20, 21 and
23 are for regulators using only elastomer diaphragms.
Depending on regulator size, a multiplier, given in these
tables, must be used to convert to capacities for regulators
using metal diaphragms.
To determine ow capacity for liquid relief valve sizing, refer
to the Fisher Sizing Program using the C
in Table 5. The K
values listed in Table 5 can be used to
m
coefcients given
v
predict choked ow on liquid service.
To convert capacities to m
3
/h, multiply GPM by 0.2271.
15
Bulletin 71.1:MR95
Table 12. Air Capacities
(1)
in SCFH / Nm3/h for 1-1/2 through 2 in. / DN 40 through 50 Types MR95H and MR95HD Regulators with
Elastomer or Stainless Steel Diaphragm
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE
RANGE,
psig/psi / bar
5 to 80 /
0.34 to 5.5
60 to 120 /
4.1 to 8.3
100 to 140 /
6.9 to 97
120 to 150 /
8.3 to 10.3
1. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
in SCFH / Nm3/h for 1/4 NPT and 1/2 through 1 in. / DN 15 through 25 Type MR95HP
(Elastomer Diaphragm) Regulator
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE
RANGE,
psig/psi / bar
15 to 100 /
1.0 to 6.9
80 to 300 /
5.5 to 20.7
80 to 400 /
5.5 to 27.6
Type MR95HP Only
1. To obtain capacities for Type MR95HT (metal diaphragm), multiply the table values by 0.6. Capacity data for 1000 psig / 69.0 bar inlet is not applicable for Type MR95HT (Type MR95HT
max. inlet = 600 psig / 41.4 bar).
2. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
in GPM / L/min for 1/4 NPT and 1/2 through 1 in. / DN 15 through 25 Type MR95HP
(Elastomer Diaphragm) Regulator
PRESSUREREGULATOR BODY SIZE, IN. / DN
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE RANGE,
psig/psi / bar
15 to 100 /
1.0 to 6.9
80 to 300 /
5.5 to 20.7
80 to 400 /
5.5 to 27.6
Type MR95HP Only
1. To obtain capacities for regulators with metal diaphragms or for Type MR95HT, multiply the table values by 0.6. Capacity data for 1000 psig / 69.0 bar inlet is not applicable for
Type MR95HT (Type MR95HT max. inlet = 600 psig / 41.4 bar).
2. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
- Capacities not tested due to cavitation regime.
Outlet/
Differential
Setting
psig bar psig bar GPM l/min GPM l/min GPM l/min GPM l/min GPM l/min GPM l/min GPM l/min GPM l/min
151.0
755.2
1006.9
1258.6
200 13.8
300 20.7
400 27.6
30
40
50
75
100
150
200
250
300
400
500
600
1000
100
125
150
200
250
300
400
500
600
1000
125
150
175
200
250
300
400
500
600
1000
150
175
200
225
250
300
400
500
600
1000
225
250
300
400
500
600
1000
350
400
500
600
1000
500
600
1000
Inlet
2.1
2.8
3.4
5.2
6.9
10.3
13.8
17.2
20.7
27.6
34.5
41.4
69.0
6.9
8.6
10.3
13.8
17.2
20.7
27.6
34.5
41.4
69.0
8.6
10.3
12.1
13.8
17.2
20.7
27.6
34.5
41.4
69.0
10.3
12.1
13.8
15.5
17.2
20.7
27.6
34.5
41.4
69.0
15.5
17.2
20.7
27.6
34.5
41.4
69.0
24.1
27.6
34.5
41.4
69.0
34.5
41.4
69.0
1/4 NPT1/2 / 153/4 / 201 / 25
DroopDroopDroopDroop
10%20%10%20%10%20%10%20%
0.8
3.0
1.3
4.9
2.4
9.1
3.7
14.0
6.0
22.7
8.0
30.3
6.0
1.3
1.8
2.2
2.5
2.9
3.3
3.6
3.9
4.2
5.5
6.7
9.2
10.2
11.1
12.5
13.0
14.0
4.9
6.17
7.43
8.7
10.3
11.9
14.2
16
17.4
1.9
2.4
2.9
3.2
3.5
4.1
5.0
5.7
6.3
2.6
3.1
4.0
5.4
6.5
7.4
9.9
4.6
5.3
6.7
7.4
9.1
6.7
7.7
10.6
4.9
6.8
8.1
9.5
11.0
12.5
13.6
14.8
15.9
20.6
25.3
34.8
38.4
42.0
47.3
49.2
53.0
18.5
23.3
28.1
32.9
39.0
45.0
53.6
60.4
65.9
7.2
9.1
11.0
12.1
13.2
15.5
18.9
21.6
23.8
9.8
11.6
15.1
20.4
24.6
27.9
37.4
17.2
19.9
25.2
27.8
34.4
25.2
29.1
40.3
1.9
2.5
3.3
4.1
4.6
5.0
5.3
5.6
7.0
8.5
10.0
12.9
14.7
16.4
17.0
18.0
18.0
7.0
8.9
10.9
12.8
14.9
17.0
20.4
23.0
25.1
3.5
4.1
4.7
5.2
5.6
6.5
7.7
8.6
9.4
5.0
5.7
7.0
9.0
10.6
11.8
15.4
8.1
9.1
11.2
12.3
15.8
11.2
13.0
17.9
7.2
9.5
12.5
15.5
17.2
18.9
20.0
21.2
26.5
32.1
37.6
48.8
55.4
62.0
64.3
68.1
68.1
26.5
33.8
41.1
48.4
56.4
64.3
77.2
86.9
94.9
13.2
15.5
17.8
19.5
21.2
24.6
29.0
32.6
35.6
18.9
21.4
26.5
34.0
39.9
44.8
58.3
30.5
34.4
42.4
46.3
59.6
42.4
49.0
67.5
2.9
3.4
4.3
5.1
5.8
6.5
7.6
8.7
8.0
9.0
10.0
12.0
13.0
14.0
14.5
15.0
15.0
9.0
10.7
12.3
14.0
15.0
16.0
16.0
16.0
18.0
18.0
6.0
7.0
8.0
8.8
9.5
11.0
11.5
12.0
14.0
14.0
8.0
9.3
12.0
15.0
18.0
19.0
20.0
13.0
15.0
19.0
21.0
26.0
19.0
22.0
30.4
11.0
12.9
16.1
19.3
21.9
24.6
28.8
32.9
30.3
34.0
37.8
45.4
49.2
53.0
54.9
56.7
56.7
34.0
40.4
46.7
53.0
56.7
60.5
60.5
60.5
68.1
68.1
22.7
26.5
30.3
33.1
35.9
41.6
43.5
45.4
53.0
53.0
30.3
35.3
45.4
56.7
68.1
71.9
75.7
49.2
56.7
71.9
79.4
98.4
71.9
83.2
115
4.3
4.9
6.1
7.2
8.1
9.0
10.2
11.3
14.0
15.5
17.0
20.0
21.5
23.0
23.0
23.0
23.0
16.0
18.0
20.0
22.0
23.5
25.0
26.0
27.0
28.0
28.0
10.0
12.0
14.0
15.0
16.0
18.0
19.0
20.0
22.0
22.0
15.0
17.0
21.0
25.0
29.0
31.0
32.0
23.0
26.0
32.0
35.0
45.0
32.0
37.0
51.0
16.3
18.5
22.9
27.2
30.6
34.0
38.4
42.7
53.0
58.6
64.3
75.7
81.3
87.0
87.0
87.0
87.0
60.5
68.1
75.7
83.2
88.9
94.6
98.4
102
106
106
37.8
45.4
53.0
56.7
60.5
68.1
71.9
75.7
83.2
83.2
56.7
64.3
79.4
94.6
110
117
121
87.0
98.4
121
132
170
121
140
193
6.5
7.0
8.5
10.0
11.5
13.0
14.0
15.0
16.8
16.0
18.0
20.0
24.0
26.5
29.0
30.3
30.3
30.3
19.0
22.7
26.3
30.0
31.0
32.0
33.5
37.1
37.1
37.1
10.0
13.5
17.0
18.5
20.0
23.0
26.0
29.0
29.3
32.5
16.0
19.0
25.0
29.5
34.0
37.0
40.0
24.0
28.0
36.0
42.0
50.0
32.0
40.0
53.0
24.6
26.5
32.2
37.8
43.5
49.2
53.0
56.7
63.6
60.5
68.1
75.7
90.8
100
110
115
115
115
71.9
85.7
99.6
113
117
121
127
140
140
140
37.8
51.1
64.3
70.0
75.7
87.0
98.4
110
111
123
60.5
71.9
94.6
112
129
140
151
90.8
106
136
159
189
121
151
200
8.5
9.0
11.5
14.0
15.5
17.0
18.0
19.0
19.0
25.0
28.8
32.5
40.0
43.0
46.0
53.0
53.0
53.0
32.0
36.7
41.3
46.0
50.0
54.0
56.7
59.5
59.5
59.5
19.0
24.0
29.0
31.0
33.0
37.0
39.5
42.0
43.2
51.0
30.0
34.7
44.0
49.0
54.0
57.0
60.0
44.0
49.0
59.0
65.0
77.0
55.0
65.0
84.0
32.2
34.0
43.5
53.0
58.6
64.3
68.1
71.9
71.9
94.6
109
123
151
163
174
200
200
200
121
139
156
174
189
204
214
225
225
225
71.9
90.8
110
117
125
140
149
159
163
193
113
131
166
185
204
216
227
166
185
223
246
291
208
246
318
7.0
8.0
9.5
11.0
13.5
16.0
18.5
21.0
24.0
18.0
21.5
25.0
32.0
35.5
39.0
41.0
41.0
41.0
21.0
26.7
32.3
38.0
42.0
46.0
51.5
57.0
57.0
57.0
12.0
16.0
20.0
22.0
24.0
28.0
36.0
44.0
45.0
50.0
19.0
23.0
31.0
37.5
44.0
45.0
75.0
27.0
33.0
45.0
59.0
70.0
43.0
52.0
84.0
22.7
26.5
30.3
35.9
41.6
51.1
60.5
70.0
79.4
90.8
68.1
81.3
94.6
121
134
148
155
155
155
79.4
101
122
144
159
174
195
216
216
216
45.4
60.5
75.7
83.2
90.8
106
136
166
170
189
71.9
87.0
117
142
166
170
284
102
125
170
223
265
163
197
318
10.0
11.0
12.0
13.5
15.0
20.0
25.0
30.7
36.4
37.0
31.0
37.3
43.5
56.0
62.5
69.0
80.0
80.0
80.0
36.0
44.0
52.0
60.0
68.5
77.0
81.0
85.0
85.0
85.0
25.0
30.0
35.0
38.0
41.0
47.0
57.5
68.0
72.0
85.0
37.0
42.3
53.0
65.0
77.0
82.0
125
53.0
63.3
84.0
98.0
127
73.0
92.0
135
37.8
41.6
45.4
51.1
56.7
75.7
94.6
116
138
140
117
141
165
212
236
261
303
303
303
136
166
197
227
259
291
306
322
322
322
94.6
113
132
144
155
178
218
257
272
322
140
160
200
246
291
310
473
200
240
318
371
480
276
348
511
27
Bulletin 71.1:MR95
Table 24. Water Capacities
RECOMMENDED
OUTLET/
DIFFERENTIAL
PRESSURE
RANGE,
psig/psi / bar
15 to 100 /
1.0 to 6.9
60 to 260 /
4.1 to 17.9
60 to 300 /
4.1 to 20.7
Type MR95HP Only
1. To obtain capacities for Type MR95HT (metal diaphragm), multiply the table values by 0.6. Capacity data for 1000 psig / 69.0 bar inlet is not applicable for Type MR95HT (Type MR95HT
max. inlet = 600 psig / 41.4 bar).
2. To obtain capacities for regulators with reduced ow orices, multiply the table values by 0.7.
- Denotes capacities limited by boost.
- Capacities not tested due to cavitation regime.
(1)(2)
in GPM / L/min for 1-1/2 through 2 in. / DN 40 through 50 Type MR95HP (Elastomer Diaphragm) Regulator
When ordering, complete the ordering guide on this page.
Refer to the Specications section on pages 2 and 3.
Ordering Guide
Type (Select One)
MR95L (Low pressure) MR95LD (Low pressure differential) MR95H (High pressure) MR95HD (High pressure differential, must be Steel or
Stainless steel construction)
MR95HP (High pressure, soft-seated) MR95HT (High pressure/temperature, must be Steel or
Stainless steel construction)
Body Size (Select One)
1/4 NPT 1/2 in. / DN 15 3/4 in. / DN 20 1 in. / DN 25 1-1/2 in. / DN 40 (not available for MR95L Series) 2 in. / DN 50 (not available for MR95L Series)
1. Available in threaded (NPT) end connection only.
2. Integral anges are available for MR95H Series only.
3. Gray cast iron spring case not available for Types MR95LD and MR95HD.
Monel® is a mark owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
(1)
(2)
Review the description to the right of each specication and
the information in each referenced table or gure. Specify
your choice whenever a selection is offered.
Body Material and End Connection Style
(2)
(See Tables 1 and 2, Select One) (continued)
CF3M Stainless steel (continued) Welded CL600 RF*** Welded PN 16/25/40 RF*** Integral CL150 RF* Integral CL300 RF* Integral CL600 RF* Integral PN 16/25/40 RF*Hastelloy® C
NPT*
Integral CL150 RF* Integral CL300 RF* Integral CL600 RF* Integral PN 16/25/40 RF*Monel
®
NPT*
Integral CL150 RF*
Integral CL300 RF*
Integral CL600 RF*
Integral PN 16/25/40 RF*Aluminum-Bronze Integral CL150 RF* Integral CL300 RF* Integral CL600 RF* Integral PN 16/25/40 RF*
Spring Case Material (Select One)
Gray cast iron (standard for gray cast iron bodies)
(3)
***
WCC Steel (standard for steel or
Stainless steel bodies)***
LCC Steel*** CF8M Stainless steel (optional for
Stainless steel bodies)**
Hastelloy® C
Monel®
Trim Material (See Table 7, Select One)
Metal Seat
416 Stainless steel
Trim 1 Trim 2
Trim 22
316 Stainless steel
Trim 3
Trim 23Hastelloy® C
Trim 5
- continued -
30
Ordering Guide (continued)
Bulletin 71.1:MR95
Trim Material (See Table 7, Select One) (continued)
Metal Seat (continued)Monel
®
Trim 6Alloy 6
(1)
Trim 4
Trim 24
Elastomer SeatNitrile (NBR)
Trim 7
Trim 8
Trim 9
Trim 10
Trim 11
Fluorocarbon (FKM)
Trim 12
Trim 13
Trim 14
Trim 15
Peruoroelastomer (FFKM) Trim 16Polytetrauoroethylene (PTFE)
Outlet or Differential Pressure Range (Select One)
Type MR95L or MR95LD
Steel Spring 2 to 6 psig/psi / 0.14 to 0.41 bar, Yellow*** 5 to 15 psig/psi / 0.34 to 1.0 bar, Green***
13 to 30 psig/psi / 0.90 to 2.1 bar, Red***
302 Stainless steel Spring
2 to 6 psig/psi / 0.14 to 0.41 bar, Yellow***
5 to 15 psig/psi / 0.34 to 1.0 bar, Unpainted***
13 to 30 psig/psi / 0.90 to 2.1 bar, Unpainted***
Outlet or Differential Pressure Range
(Select One) (continued)
Type MR95H or MR95HD
1/4 NPT and 1/2 to 1 in. / DN 15 to 25 body sizes
Steel Spring
15 to 30 psig/psi / 1.0 to 2.1 bar, Yellow***
25 to 75 psig/psi / 1.7 to 5.2 bar, Green*** 70 to 150 psig/psi / 4.8 to 10.3 bar, Red***
302 Stainless steel Spring
(3)
15 to 30 psig/psi / 1.0 to 2.1 bar, Yellow*** 25 to 75 psig/psi / 1.7 to 5.2 bar, Unpainted*** 70 to 150 psig/psi / 4.8 to 10.3 bar, Unpainted***
1-1/2 and 2 in. / DN 40 and 50 body sizes
Steel Spring
5 to 80 psig/psi / 0.34 to 5.5 bar,
Black with light blue stripe***
60 to 120 psig/psi / 4.1 to 8.3 bar, Light Gray***
100 to 140 psig/psi / 6.9 to 9.7 bar, Yellow*** 120 to 150 psig/psi / 8.3 to 10.3 bar, Black***
Type MR95HT
1/4 NPT and 1/2 in. / DN 15 body size
Inconel® Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 80 to 300 psig / 5.5 to 20.7 bar, Unpainted***
3/4 and 1 in. and DN 20 and 25 body sizes
17-4 PH Stainless steel Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 80 to 300 psig / 5.5 to 20.7 bar, Unpainted***
1-1/2 and 2 in. and DN 40 and 50 body sizes
17-4 PH Stainless steel Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 60 to 260 psig / 4.1 to 17.9 bar, Unpainted***
Type MR95HP
1/4 NPT and 1/2 in. / DN 15 body size
Inconel® Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 80 to 400 psig / 5.5 to 27.6 bar, Unpainted***
3/4 and 1 in. / DN 20 and 25 body sizes
17-4 PH Stainless steel Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 80 to 400 psig / 5.5 to 27.6 bar, Unpainted***
1-1/2 and 2 in. / DN 40 and 50 body sizes
17-4 PH Stainless steel Spring
15 to 100 psig / 1.0 to 6.9 bar, Unpainted*** 60 to 300 psig / 4.1 to 20.7 bar, Unpainted***
Replacement Parts Kit (Optional)
Yes, send one replacement parts kit to match this order.
1. Alloy 6 is not available for 1/4 in. size.
2. Only available with Stainless steel seat, orice/valve plug, valve plug guide and stem/stem guide.
3. Available for 3/4 and 1 in. / DN 20 and 25 body sizes only.
Monel® and Inconel® are marks owned by Special Metals Corporation.
Hastelloy® C is a mark owned by Haynes International, Inc.
- continued -
31
Bulletin 71.1:MR95
Ordering Guide (continued)
Regulators Quick Order Guide
* * *Readily Available for Shipment
* *Allow Additional Time for Shipment
Special Order, Constructed from Non-Stocked Parts.
*
Consult your local Sales Ofce for Availability.
Availability of the product being ordered is determined by the component with the
longest shipping time for the requested construction.
Specication Worksheet
Application:
Specic Use __________________________________
Line Size ____________________________________
Fluid Type and Specic Gravity ___________________
Fluid Temperature _____________________________
Does the Application Require Overpressure Protection?
Yes No If yes, which is preferred: Relief Valve Monitor Regulator Shutoff Device
Is overpressure protection equipment selection
assistance desired?
Pressure:
Maximum Inlet Pressure (P
Minimum Inlet Pressure (P
) __________________
1max
) ___________________
1min
Downstream Pressure Setting(s) (P2) ______________
Maximum Flow (Q
) __________________________
max
Performance Required:
Accuracy Requirements? _______________________
Need for Extremely Fast Response? _______________
Other Requirements: __________________________
____________________________________________
Industrial Regulators
Emerson Process Management
Regulator Technologies, Inc.
USA - Headquarters
McKinney, Texas 75070 USA
Tel: +1 800 558 5853
Outside U.S. +1 972 548 3574
Asia-Pacic
Shanghai 201206, China
Tel: +86 21 2892 9000
Europe
Bologna 40013, Italy
Tel: +39 051 419 0611
Middle East and Africa
Dubai, United Arab Emirates
Tel: +971 4811 8100
For further information visit www.fisherregulators.com
The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are the property of their prospective owners. Fisher is a mark owned by Fisher Controls International LLC,
a business of Emerson Process Management.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they are not to be construed as warranties or
guarantees, express or implied, regarding the products or services described herein or their use or applicability. We reserve the right to modify or improve the designs or specications of such
products at any time without notice.
Emerson Process Management Regulator Technologies, Inc. does not assume responsibility for the selection, use or maintenance of any product. Responsibility for proper selection, use and
maintenance of any Emerson Process Management Regulator Technologies, Inc. product remains solely with the purchaser.
Natural Gas Technologies
Emerson Process Management
Regulator Technologies, Inc.
USA - Headquarters
McKinney, Texas 75070 USA
Tel: +1 800 558 5853
Outside U.S. +1 972 548 3574
Asia-Pacic
Singapore 128461, Singapore
Tel: +65 6770 8337
Europe
Bologna 40013, Italy
Tel: +39 051 419 0611
Chartres 28008, France
Tel: +33 2 37 33 47 00
Middle East and Africa
Dubai, United Arab Emirates
Tel: +971 4811 8100
TESCOM
Emerson Process Management
Tescom Corporation
USA - Headquarters
Elk River, Minnesota 55330-2445, USA
Tels: +1 763 241 3238
+1 800 447 1250
Europe
Selmsdorf 23923, Germany
Tel: +49 38823 31 287
Asia-Pacic
Shanghai 201206, China
Tel: +86 21 2892 9499
The distinctive diamond shape cast into every
spring case uniquely identifies the regulator
as part of the Fisher® brand and assures you
of the highest-quality engineering, durability,
performance, and support.
