1.0 INTRODUCTION
The Liebert Liqui-tect Monitoring System is the ultimate in leak detection and retrofitting capabilities for computer rooms and other large areas. The Liqui-tect Monitoring System provides direct-read
at the control unit location, as well as the ability to communicate with the Liebert SiteScan Web
enterprise monitoring system or a building management system.
The Liqui-tect Monitoring System features an easy-to-use liquid crystal display (LCD) panel with
readout of normal and alarm conditions, as well as leak location. Display and measurement modules
are contained in a single compact package.
The Liqui-tect Monitoring System can monitor up to 10,000 ft. (3048m) of Liebert LT500Y leak detection cable. Points along the cable may be mapped by one person, making it easy to configure within
the critical space and pinpoint the location of leaks when they occur. The system determines the location of the water on the detection cable and reports the distance from the Liqui-tect panel in feet or
meters. To ensure proper protection, the system continuously monitors operation, signaling system
normal, leak detected and cable fault.
The Liqui-tect panel offers these and other features to protect your installation from leak damage:
• audible and visual alarms
• adjustable sensitivity setpoints for leaks and contamination
• continuous scrolling of data
• history logs
• connection to a building management system
• automatic detection of broken cables and contaminated cables
• password protection
• retention of configuration after a power failure
Introduction
Two interfaces permit easy access and configuration of the Liqui-tect panel:
• LCD on the front of the enclosure
• Liebert’s SiteScan Web enterprise monitoring system through a dedicated connection port
1.1 Equipment Inspection
Upon arrival of the unit, inspect all items for visible and concealed damage. Damage should be immediately reported to the carrier and a damage claim filed with a copy sent to Liebert or to your sales
representative.
1
1.2 Outside Enclosure Overview
Liqui-tect
Monitoring System
The enclosure for the Liqui-tect panel’s controller board comes in two sizes:
•The large enclosure is designed to accommodate the Transformer Module and future compo-
nents, in addition to the controller board.
•The small enclosure is built to hold the controller board only.
Both enclosures are 2-3/4" deep.
Both enclosures have a built-in liquid crystal display (LCD) and a key lock, as shown in the example
below. The metal enclosures accommodate secure conduit fittings and protect components against
external forces and debris.
Figure 1 Small enclosure—external features
The enclosure
has knockouts
and access slots
on top and
bottom for
cables and wires.
ESC
LIQUI-TECT PANEL
05-SEP-02 14:04:13
V5.100.0
PRESS =STATUS/SETUP
Introduction
LCD for configuration
and operation
Key lock
R
Liqui-tect
Monitoring System
The enclosure must be secured to a wall, either flush-mounted or recessed in the wall, as described in
2.0 - Installation. Knockouts and access slots on the top and bottom allow easy connection of wires
and cables (see 3.0 - Connections and Configuration) with either mounting type.
Figure 2 Large enclosure—internal features
Transformer
Back of LCD
Module
R1
Controller Board
DS1
O N
O N
SW2
SW1
R4
Pwr On
345678
2345678
1
1
2
K1
R15
K2
R16
DS3
R17
K4
DS4
R18
K5
U24
C27
C26
R38
U15
U16
R40
DS6
FaultLEDO
C33
Reset
C32
U23
C40
DS7
DS8
U24
U22
R44
C46
U29
ON
TXRX
On/Off switch
for Transformer
Module
Ground wire
for LCD
Power
receptacle
Knockouts and
access slots
(top and bottom)
2
1.3 Typical Sequence
ESC
ESC
Figure 3 shows a typical sequence of how the Liqui-tect Monitoring System functions after detecting
a leak, contamination or cable break in either Zone 1 or Zone 2. Responses depend on configuration
settings. This example shows what happens when a leak is detected.
Figure 3 Example of typical sequence: Analog input reaches high setpoint
RESPONSES TO AN ALARM RETURN-TO-NORMAL SEQUENCE
Introduction
LIQUI-TECT PANEL
05-SEP-02 14:04:13
V5.100.0
PRESS =STATUS/SETUP
ESC
ZONE 1
LEAK @ 3495ft
29-AUG-03 09:29:10
ALARM CONDITION DETECTED
A leak is sensed along the cable
defining Zone 1.
The horn sounds (audible horn on
the controller board—silence horn by
pressing any key on the LCD keypad)
The LCD flashes
Entry in Alarm History Log
LIQUI-TECT PANEL
05-SEP-02 14:04:13
V5.100.0
PRESS =STATUS/SETUP
ESC
ZONE 1
ALARM RESET - LCD
29-AUG-03 09:42:11
ZONE 1
NO LEAK
29-AUG-03 09:42:11
RETURN TO NORMAL
The leak is controlled.
The alarm is cleared
(automatically if Unlatched; must be
cleared manually if Latched)
The horn stops sounding
(if user hasn’t silenced it)
The LCD stops flashing
Entry in Alarm History Log
(if alarms defined as Latched)
Entry in Zone Trend Log
(if alarms defined as Unlatched)
3
1.4 Controller Board Overview
The Liqui-tect panel’s controller board, as shown below, has connectors for two digital outputs for leak
detection alarms, two digital outputs for cable break alarms, two inputs for leak detection cables and
two analog outputs for connecting to a building management system. The board comes complete with
light-emitting diodes (LEDs) to display the status of monitored zones, power connections and other
features necessary to monitor and protect your operation.
A-Power On/Off
Z-Transformer
Module
Y- 24VAC power
connector
X-Reset
switch
W- LCD contrast
adjustment
V-LCD
connector
U-24VAC
connector
T-Power On/
Off switch
S-Power
receptacle
R-RS485
connector
(not used)
LED
ON
Q-RS485
LEDs
A
LCD Interlface
P-SiteScan
Web LEDs
B-DIP
switch 1
TX RX
C-DIP
switch 2
R1
DS1
Pwr On
O N
O N
SW2
SW1
R4
2345678
1
1
2
345678
C26
R38
U15
R40
DS6
FaultLEDO
C33
Reset
C32
U23
DS7
DS8
U22
R44
C46
U29
N-RS232
connector
O-SiteScan
Web connector
U24
C27
U16
C40
U24
D-Audible
horn
K1
K2
R16
DS3
R17
K4
DS4
R18
DS5
K5
TB3
C28
M-RS232
LEDs
Introduction
E-Digital alarm
outputs (Zone 1)
F-Alarm output
LEDs (Zones 1& 2)
G-Digital alarm
outputs (Zone 2)
H-Status LEDs
I-4/20mA output
(Zone 2)
J-4/20mA output
(Zone 1)
K-Input cable
connector (Zone 2)
L-Input cable
connector (Zone 1)
Table 1 Controller board components
Item Description More Information
A-Power On/Off LED Indicates when power is supplied to the panel.
B-DIP switch 1
DIP switch used for resetting password to default
and disabling the audible alarm.
C-DIP switch 2 Not used. N/A
D-Audible horn Provides audible notification when an alarm occurs. 3.5: Disable the Audible Horn
The Cable Break output connection is a two-state
point (ON/OFF, energized/de-energized). When the
cable is broken or becomes contaminated, an alarm
E-Digital alarm
outputs (Zone 1)
and
G-Digital alarm
outputs (Zone 2)
is created and the contact is energized.
The Leak Detected output connection is a two-state
point (ON/OFF, energized/de-energized). When
water is detected, an alarm is created and the
contact is energized.
Each output can be used to connect to a secondary
warning device such as a horn, light or building
management system.
F-Alarm output
LEDs (Zones 1&2)
G-Digital alarm
outputs (Zone 2)
Indicates the status of the alarm outputs. 1.5: LED Indicators
(See description and references for E - Digital alarm outputs (Zone 1) above)
2.4: Connect Power to the Liqui-tect Panel
1.5: LED Indicators
3.5: Disable the Audible Horn
6.8.1: Change Password
3.0: Connections and Configuration
3.2: Connecting Alarm Outputs
5.1: View Cable Status
6.5: Setup System - Setup Alarm Outputs
4
Table 1 Controller board components
Item Description More Information
H-Status LEDs Indicates the operational status of the panel. 1.5: LED Indicators
I-4/20mA output
(Zone 2)
J-4/20mA output
(Zone 1)
K-Input cable
connector (Zone 2)
L-Input cable
connector (Zone 1)
M-RS232 LEDs
N-RS232 connector
O-SiteScan Web
connector
P-SiteScan Web
LEDs
Q-RS485 LEDs Not presently used. N/A
R-RS485 connector Not presently used. N/A
S-Power receptacle
(Transformer Module)
T-Power On/Off
switch (Transformer
Module)
U-24VAC connector
(Transformer Module)
V-LCD connector Connection for the LCD located on the front door. N/A
W-LCD contrast
adjustment
X-Reset switch
Y-24VAC power
connector
Z-Transformer
Module
Provides the distance liquid is detected, normal
status and cable fault. Used to provide status to a
building management system or remote monitoring
system.
Provides the distance liquid is detected, normal
status and cable fault. Used to provide status to a
building management system or remote monitoring
system.
Connection to Liebert leak detection cable.
Connection to Liebert leak detection cable.
Indicates the connection status between the
Liqui-tect panel and an RS232 device.
Connection for a laptop. Used by factory personnel.
Requires a null modem cable for connectivity
(P/N 201258P1).
Connection to monitor Liqui-tect panel from Liebert’s
SiteScan Web enterprise monitoring system.
Indicates the connection status between the
Liqui-tect panel and SiteScan Web.
115VAC power receptacle to power laptop during
configuration and diagnostics. Receptacle not
available on 230VAC Transformer Module.
Power switch to turn power On/Off to both
Transformer Module 24VAC connectors and power
receptacle.
One of the two 24VAC connectors for power (the
second is also on the right side of the Transformer
Module near the top). Each connector is rated for
40VA.
Adjustment contrast for the LCD located on the front
door.
Reset switch to reset the panel. Same as repowering the panel.
Power connection for the controller. Requires
24VAC.
Transformer Module used to convert 115VAC or
230VAC to 24VAC. Available only in the large
enclosure.
3.0: Connections and Configuration
3.3: Connecting to a Building Maintenance
System or External Alarm System
5.1: View Cable Status
6.5: Setup System - Setup Alarm Outputs
3.0: Connections and Configuration
3.3: Connecting to a Building Maintenance
System or External Alarm System
5.1: View Cable Status
6.5: Setup System - Setup Alarm Outputs
3.0: Connections and Configuration
3.1: Connecting Leak Detection Cable
Inputs
5.1: View Cable Status
6.4: Setup System - Setup ZN2 Zone 2
3.0: Connections and Configuration
3.1: Connecting Leak Detection Cable
Inputs
5.1: View Cable Status
6.3: Setup System - Setup ZN1 Zone 1
1.5: LED Indicators
N/A
3.0: Connections and Configuration
3.4: RS422 SiteScan Web Connector
1.5: LED Indicators
2.4.2: Input and Output Power Connections Large Enclosure
3.0: Connections and Configuration
2.4.2: Input and Output Power Connections Large Enclosure
3.0: Connections and Configuration
2.4.2: Input and Output Power Connections Large Enclosure
3.0: Connections and Configuration
N/A
N/A
2.4: Connect Power to the Liqui-tect Panel
2.4.2: Input and Output Power Connections Large Enclosure
Introduction
5
1.5 LED Indicators
The Liqui-tect panel’s controller board has LED indicators that show the status of inputs, outputs and
other board components.
Power On/Off
LED
Introduction
Alarm output LEDs
(Zones 1&2)
R1
DS1
Pwr On
A
O N
O N
SW2
SW1
R4
2345678
1
1
2
345678
DS2
K1
K2
K3
K4
K1
K2
R16
DS3
R17
K4
DS4
R18
DS5
K5
LCD Interlface
C32
U22
C46
U29
U24
C27
C26
R38
U15
U16
R40
DS6
FaultLEDO
C33
Reset
U23
C40
DS7
DS8
U24
R44
TB3
C28
Status LEDs
FaultLEDO
ON
TX RX
R44
RS232 LEDsSiteScan Web RS422 LEDsRS485 LEDs
DS13
RX TX
R81
R82
DS14
R77
DS9
R79
R78
DS11
DS10
TX RXRX TX
DS12
R80
Table 2 LED indicators summary
LED Color Description
Power On/Off LED
Pwr On Green Indicates whether power is connected
Zone 1 & 2 Alarm Outputs LEDs
K1 – Zone 1 Leak Detected Green Indicates leak detected for Zone 1
K2 – Zone 1 Cable Break Green Indicates cable problem for Zone 1
K3 – Zone 2 Leak Detected Green Indicates leak detected for Zone 2
K4 – Zone 2 Cable Break Green Indicates cable problem for Zone 2
Status LEDs
LEDO Green Indicates the panel is working properly – will flash slowly when working
Fault Red Indicates an alarm is present
Reset Red Indicates the panel is being reset
RS232 LEDs
RS232 TX Green Liqui-tect panel is transmitting information via the RS232 port
RS232 RX Green Liqui-tect panel is receiving information via the RS232 port
RS422 LEDs
RS422 TX Green Liqui-tect panel is transmitting information over the RS422 port
RS422 RX Green Liqui-tect panel is receiving information over the RS422 port
RS485 LEDs
RS485 TX Green Not presently used
RS485 RS Green Not presently used
DS3
DS4
DS5
R38
R15
DS7
DS6
TB2
DS8
R16
R17
R18
R40
Reset
6
2.0 INSTALLATION
2.1 Installation Considerations
The Liqui-tect panel must be installed indoors and may be mounted on the surface of a wall or flushmounted, depending on the user’s application and the type of wall the unit will be mounted on. The
unit’s location must meet the following criteria:
• The panel must be placed close enough to the areas to be monitored to permit proper connection of
the leak detection cable. The panel will monitor two zones; each zone can accommodate up to
5,000 ft. (1524m) of leak detection cable.
• The Liqui-tect panel should be mounted where it can be easily accessed. Personnel would access
the unit through the LCD on its front cover or through SiteScan.
• The site also must have electrical service and must permit connection of the panel’s four digital
outputs, two inputs for leak detection cables and two analog outputs for connecting to a building
management system or external alarm.
• The wall material must be capable of supporting the weight of the Liqui-tect panel: see 7.0 -
Specifications.
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
Installation
2.1.1 Unpacking and Preliminary Inspection
• Before unpacking the Liqui-tect panel, inspect the shipping carton for damage or signs of mishandling, such as gashes or holes in the carton or severely flattened corners.
• Open the shipping container carefully. Use care to avoid puncturing the container with sharp
objects that might damage the contents.
• Inspect the Liqui-tect panel and all included components for damage.
• If any damage from shipping or mishandling is observed, immediately file a damage claim with
the shipping agency and forward a copy to:
Liebert Corporation
1050 Dearborn Drive
P.O. Box 29186
Columbus, OH 43229
Packing Contents
Table 3 Packing manifest
Standard Components
Liqui-tect panel - large or small enclosure
User Manual
Keys (2) to panel door lock
Connection cables (2) (CONNECT10)
End terminators (2) (LT500-ET)
7
2.2 Surface-Mounting the Liqui-tect Panel
NOTE
Removing the conduit knockouts before mounting the Liqui-tect panel on the wall will ease
installation and prevent strain on the mounting hardware and wall. It is imperative to remove
the knockouts if the unit is to be flush-mounted.
After determining where to place the unit, check to ensure that you have all the hardware required to
install the panel on the surface of a wall. Obtain the needed tools and material.
Required tools
• Electric drill (if surface is too hard to drive screws without pilot holes)
• Screwdriver
• Marker to denote layout of holes
• Four screws, each #10
2.2.1 Mounting the Panel
CAUTION
!
Check building plans and other relevant documents to determine whether mounting the
Liqui-tect panel at the selected location might cause cutting or otherwise damaging electrical
or communication wiring or pipes.
1. Mark the wall for mounting holes, using the back of the unit as a template (see Figure 4).
2. Drill holes, if required, to install the four #10 screws that will secure the Liqui-tect panel to the
wall. Clean up the debris.
3. If the wall material is not strong enough to hold the screws securely, use wall anchors.
4. Install the top two screws—the screw heads must be small enough to slip through the larger,
bottom portion of the pear-shaped mounting slot in the Liqui-tect panel (see inset in illustration
at right). The screws must also be large enough to extend over the edges of the top of the
mounting slot.
5. Hang the Liqui-tect panel on the screws, letting the panel slip down until the screws are in the
smaller, upper portion of the slot.
6. Tighten the screws until they are snug.
7. Insert the remaining two screws in the bottom holes on the back of the panel and tighten.
Figure 4 Mounting dimensions
Installation
LARGE ENCLOSURE
0.213"
(5.4mm)
0.375"
(9.6mm)
Mounting Slot
SMALL ENCLOSURE
12.5"
(317.5mm)
Liqui-tect panel
back plate
0.213" (5.4mm)
Bottom hole diameter
10"
(254mm)
12"
(304.8mm)
0.213"
(5.4mm)
16"
(406.4mm)
Liqui-tect panel
back plate
0.375"
(9.6mm)
Mounting Slot
0.213" (5.4mm)
Bottom hole diameter
8
2.3 Flush-Mounting the Liqui-tect Panel
NOTE
Removing the conduit knockouts before mounting the Liqui-tect panel on the wall will ease
installation and prevent strain on the mounting hardware and wall. It is imperative to remove
the knockouts if the unit is to be flush-mounted.
The rectangular access doors on the top and bottom of the Liqui-tect panel must be removed
from the outside of the panel and reinstalled on the inside of the panel. Leaving the doors as
shipped from the factory prevents them from being opened when the panel is flush mounted in
a wall.
The Liqui-tect panel may be flush mounted according to company practices—either with screws
through the sides of the panel into wall supports or with hanging hardware that attaches to the back
of the panel. After determining how and where to place the unit, check to ensure that you have all the
hardware required to install the panel in the wall. Obtain the needed tools.
Required tools
•Saw
• Electric drill
• Screwdriver
• Marker to denote layout of the hole to accommodate the Liqui-tect panel
• Trim ring and associated hardware
• Mounting hardware
Installation
2.3.1 Mounting the Panel
CAUTION
!
Check building plans and other relevant documents to determine whether mounting the
Liqui-tect panel at the selected location might cause cutting or otherwise damaging electrical
or communication wiring or pipes.
1. Mark the wall for the cutout to accommodate the panel, using the back of the unit as a template.
2. Drill a pilot hole for the saw blade, if required.
3. Use the saw to cut out the marked section of the wall (if not new construction).
4. Rest the Liqui-tect panel in the wall and mark where mounting screws will be inserted into the
wall studs or other support member.
5. Remove the panel and drill the holes for the mounting screws or wall anchors. Clean up the
debris.
6. Reverse the slide direction of the rectangular access doors on the top and bottom of the Liqui-tect
panel. Leaving the access doors as shipped from the factory prevents them from being opened
when the panel is flush mounted in a wall.
7. Attach any field-supplied mounting hardware.
8. Reinsert the assembly into the wall.
9. Insert and tighten the screws or wall anchors.
9
2.4 Connect Power to the Liqui-tect Panel
The Liqui-tect panel requires 24VAC for proper operation. Liebert recommends using the optional
Transformer Module manufactured by Liebert or another UL-approved Class 2 power unit to obtain
proper voltage. If the power unit is not a Class 2 circuit, it must be protected with an IEC 5 x 20mm
time lag 2A fuse. For information, consult your local dealer, Liebert representative or the Liebert
Worldwide Support Group.
WARNING
!
Check that power is removed from wires prior to installation.
CAUTION
!
The Liqui-tect panel is designed for use on properly grounded (earthed) 24VAC power, 50Hz
or 60Hz. The ground wire for the power lead must be wired to the earth ground terminal (stud
located next to the 24VAC terminal block).
This equipment is intended to be installed by a qualified and certified electrician who must
review and approve customer supplied wiring and circuit breakers, verify correct input and
grounded (earthed) connections to ensure compliance with technical standards and national
and local electrical codes.
WARNING
!
Be sure that the power wiring is disconnected from the Liqui-tect panel before installing any
wiring to this unit.
Installation
2.4.1 Input Power Connections - Small Enclosure
To connect electrical power:
1. Run conduit and electrical wiring from building to the Liqui-tect panel.
2. Use copper wires only; proper wiring to use for 24VAC power is 18-22 AWG stranded and shielded
(18 AWG is recommended—see Table 4). Strip wires 1/2".
Figure 5 Electrical connections to panel
External wiring
through knockout
Ground wire
(black)
Earth ground
terminal
TB1
24V Power
EGND1
TVS3
FB2
Reset
SW3
24VAC wiring
(red & white)
24VAC input
connector
3. Secure the incoming electrical service wires to the Liqui-tect panel’s 24VAC input by sliding the
wires into TB1, the 24VAC input terminal block. There is no polarity requirement when
connecting to TB1. The ground wire must be connected to the earth ground terminal located on
the side of the panel (see Figure 5).
10
2.4.2 Input and Output Power Connections - Large Enclosure
CAUTION
!
The 115VAC/230VAC Transformer Module must be connected to a branch circuit with 15A
branch circuit protection.
This equipment is intended to be installed by a qualified and certified electrician who must
review and approve customer supplied wiring and circuit breakers, verify correct input and
grounded connections to ensure compliance with the technical standards and national and
local electrical codes.
The Transformer Module shall be used only as indicated by the manufacturer.
WARNING
!
Be sure that the power wiring is disconnected from the Liqui-tect panel before installing any
wiring to this unit.
Input Power Connections
To connect electrical power to the Transformer Module:
1. Install electrical wiring from utility power to the Transformer Module.
2. Use copper wires only; proper wiring to use for power is 14/2 AWG copper wire with ground.
3. For the TM230 only: strip wires 3/8" (9.6mm).
Note: For the TM115, wires are pre-stripped 0.4" (10.2mm) at the factory.
4. Connect the wiring as follows:
Installation
TM115 TM230 Connection Type
White wire Neutral (L2) Neutral
Black wire Line (L1) Power (Line)
Green wire Ground lead Ground
5. Secure the incoming electrical service wires to the TM115 input wires with wire nuts as shown in
Figure 6 or to the TM230 connectors as shown in Figure 7.
24 VAC Output Power Connections
To connect to the 24VAC outputs:
1. Install electrical wiring from device requiring 24VAC power to the Transformer Module.
2. Use copper wire only; proper wiring to use for power is 18, 20 or 22 AWG copper wire. Strip wire 1/4".
3. There are two 24 VAC output connectors (TB1 and TB2). Terminate wires to the connector as
shown in Figures 6 and 7. TB1 and TB2 are NOT polarity sensitive.
4. Secure the wires to the connector.
Figure 6 Power wiring to TM115 Figure 7 Power wiring to TM230
TM115
Wire nuts
connecting
electrical
wiring
Knockout for
external wiring
Ground
TM230
Neutral
(L2)
Knockout for
external wiring
Ground
Line (L1)
24VAC output
(TB1)
24VAC output
(TB1)
Troubleshooting - Transformer Module
A common problem and possible solution are shown in the table below. For further information or if
you have other problems with the unit, consult your local dealer, Liebert representative or the Liebert
Worldwide Support Group.
Problem Possible Solution Replacement Fuse Part Numbers
24VAC power not available
from TB1 or TB2
Check fuse for respective
output (TB1 or TB2).
11
• LITTLEFUSE 218002
• BUSSMANN GDC-2A
3.0 CONNECTIONS AND CONFIGURATION
CAUTION
!
Be sure that the power wiring is disconnected from the Liqui-tect panel before installing any
wiring to this unit or changing input or output connections.
Input and output connections to the Liqui-tect panel may be made in any order—it is not necessary,
for example, to make all input connections before making any output connections. Use copper conductors only for all wiring.
Table 4 Wiring specifications
Connection Supported Wire Type Maximum Wire Length Rating
Cable
Input
Alarm
Output
Analog
Output
Communication
RS232
Communication
IGM422
SiteScan
24VAC Power
Connection
(TB7)
* Recommended
4 wire Liebert Connection Cable
(CONNECT10) - furnished with
Liqui-tect panel
18-22 AWG Stranded & Unshielded
18 AWG* (recommended)
Non Plenum - Belden 9740
Plenum - Belden 89740
18-22 AWG Stranded & Unshielded
18 AWG* (recommended)
Non Plenum - Belden 9740
Plenum - Belden 89740
Null Modem Cable 50 ft. (15m) N/A
18-22 AWG Stranded & Shielded
22 AWG* (recommended)
Non Plenum - Belden 9461
Plenum - Belden 88761
18-22 AWG Stranded & Unshielded
18 AWG* (recommended)
Non Plenum - Belden 8770
Plenum - Belden 88770
Connections and Configuration
Connection cable - 10 ft. (3m)
Leak detection cable - 5000 ft. (1524m)
18 AWG* @ 1A 200 ft. (60m)
22 AWG @ 1A 75 ft. (23m)
750 ft. (225m)
1000 ft. (300m) N/A
150 ft. (45m) 24VAC @ 1A
N/A
24VAC @ 1A20 AWG @ 1A 100 ft. (30m)
4-20mA
Signal
Output
12
3.1 Connecting Leak Detection Cable Inputs
The leak detection cable inputs are found on the lower right side of the Liqui-tect panel’s printed wiring assembly board. There are two terminal blocks for the inputs; the lower terminal block is for the
Zone 1 cable and the terminal block above it is for a second leak detection cable, Zone 2.
To determine the proper wire size, see Table 4 - Wiring specifications.
NOTE
Each terminal block is a removable, two-part assembly to permit easier connection of more
than one input at a time. If making multiple connections, grasp the upper portion of a block
and pull firmly to the right until the assembly pulls apart.
After making the connections, push the removed piece back into the portion attached to the
printed wiring assembly until the terminal block pieces lock together.
3.1.1 Attaching Leak Detection Connection Cable to the Panel
To attach a leak detection connection cable:
1. Disconnect electrical power to the Liqui-tect
panel.
2. Locate the Zone 1 and Zone 2 cable connectors
on the controller board. They can be found on
the lower right corner of the board (see 1.4 -
Controller Board Overview). The Zone 1
connector is Cable 1 or TB9. The Zone 2
connector (Cable 2 or TB6) is just above it.
3. If necessary, remove a conduit knockout to
permit wire entry into the Liqui-tect panel
enclosure.
4. Bring the white connection cable
(CONNECT10) into the Liqui-tect panel
enclosure through a conduit knockout or
access slot.
5. Loosen a screw on the terminal block and slip
the stripped end of the appropriate wire into
the terminal block according to the color-coded
wiring key (see illustration at right).
Note that the WHITE wire connects to the “Y”
slot. The red wire connects to the “R” slot, the
green wire connects to the “G” slot and the black wire to the “B” slot.
6. Tighten the screw until it holds the wire snugly.
7. Repeat for each of the four wire strands in the connection cable.
TB6
X6
Cable 1
TB9
Connections and Configuration
R
G
B
Leak Detection Cable
Terminal Blocks:
Zone 2
Zone 1
Y
WIRING
CONNECTIONS
R
G
B
Y
Red Wire
Green Wire
Black Wire
WHITE Wire
13
Connections and Configuration
3.1.2 Connecting Leak Detection Cable to the Connection Cable
The connection cable has a black fitting on one end that will fasten securely to the fitting on one end
of the leak detection cable—see Figure 8. Push these ends together, being careful to insert the protruding ends of the leak detection cable into the holes in the connection cable connector. Twist the
connector ring to securely link the cables.
NOTE
Make sure the male end of the LT500Y leak detection cable is installed close enough to the
Liqui-tect panel to reach the fitting on the CONNECT10 connection cable.
Figure 8 Fittings on leak detection cable (LT500Y) and connection cable (CONNECT10)
Connect to
Liqui-tect
panel
Leak detection connection cable
(CONNECT10)
Connect
to leak
detection
cable
Connection fittings on connection
cable and leak detection cable
After making this connection, lay the leak detection cable around the area to be monitored.
The monitored area would include any equipment or objects that might be damaged by water.
Figure 9 shows one possible layout. In the example, the detection cable crosses between air conditioning units and computers to alert personnel when the electronic equipment is threatened by a leak.
If there is a liquid source in the ceiling, the cable can be placed there. If a raised floor is used for cooling, the cable can be placed underneath the raised surface.
Figure 9 Typical leak detection cable layout
Liqui-tect Monitoring
System
Leak detection cable
(yellow)
A/C
A/C
Follow these steps in laying the detection cable:
1. Attach the end terminator to the last length of leak detection cable required to monitor the
selected area.
2. Verify power is connected and test the detection cable by touching the detection cable with a
clean, moist cloth or paper towel.
If the cables are connected properly, the audible horn should sound and the LCD screen should
flash. Dry the detection cable to remove the alarm condition. (A hair dryer can be used to speed up
the drying.)
Note: Do not try to saturate the detection cable for testing! It requires only a small amount of
water to alarm. The detection cable will have to dry for the alarm condition to clear.
Leak detection cable
(LT500Y)
A/C
Computer
Computer
A/C
Leak detection
cable terminus
(attach end terminator here)
A/C
14
Connections and Configuration
3. Once the cable passes the test, lay it in the pattern desired. Pay special attention to the following
cable placement precautions.
DETECTION CABLE PLACEMENT PRECAUTIONS
• Do not use detection cable that is damaged or dirty—for example, from plaster, spackle or debris.
• Detection cable should not be dragged through contaminants (dirty or greasy areas). Floor must be clean
for the detection cable to function properly and for the hold-down clips to adhere to the floor surface.
• Careful consideration should be taken to place detection cable out of the direct discharge airflow path of
environmental equipment. This type of equipment can discharge moisture into the airflow. Place cable
6 ft. (1.8m) from discharge to avoid nuisance alarms during humidification.
• Tools or heavy objects can do permanent damage when dropped, rolled, or set on the detection cable.
Avoid foot traffic on the detection cable as well.
• Do not use any type of adhesive tape to secure the detection cable.
• Do not allow soldering or welding near the detection cable without providing protection from heat and
contaminants. (Also avoid installing the detection cable in or near these type of areas.)
• Mild dishwashing liquid can be used to clean the detection cable of many contaminants.
4. Install the hold-down clips in pairs, as shown in Figure 10, with the following considerations:
a. The adhesive used to install the hold-down clips must NOT come in contact with the detection
cable.
b. One pair every 6 to 8 ft. (1.8-2.4m) in straight patterns (see Figure 11).
c. One pair every 3 to 4 ft. (0.9-1.2m) in circular patterns (see Figure 12).
d. One pair at the beginning and end of the arc when turning 90 degrees (see Figure 13).
e. One pair as needed to maintain consistent uniform contact between the floor and detection
cable.
Figure 10 Installation of hold-
down clips in pairs
5. Once adhesive is completely dry, snap the cable into each hold-down clip.
6. Check that there are no gaps between the floor and detection cable. (Add clips as required.)
7. Be certain there are no alarms present on the module.
8. Do final testing as per instruction in Step 2.
Figure 11 Cable laid in straight
patterns
Hold-down clips
every 6-8 ft.
(1.8-2.4m)
along straight
sections
Figure 12 Cable laid in circular
patterns
Hold-down clips
every 3-4 ft.
(0.9-1.2m)
Figure 13 90° turn in cable
Hold-down clips
at beginning &
end of arc
15
3.2 Connecting Alarm Outputs
The Zone 1 and Zone 2 alarm outputs, found in the top right corner
of the Liqui-tect panel, provide a contact output for a leak and a
cable break for each zone. As an example, the outputs may provide
alarms to an auxiliary alarm panel or building management system. To determine the proper wire size, see Table 4 - Wiring spec-
ifications.
A wiring key beside each terminal block indicates whether the connected output is wired for Normally Open (NO) or Normally Closed
(NC).
An alarm relay wired as an unsupervised point (energized for
alarm) must be wired to the Normally Open (NO) and Common (C)
contacts.
An alarm relay wired as a supervised point (de-energized for alarm)
must be wired to the Normally Closed (NC) and Common (C) contacts.
To connect an output:
1. Disconnect electrical power to the Liqui-tect panel.
2. If necessary, remove a conduit knockout to permit wire entry into the Liqui-tect panel enclosure.
3. Bring the wire(s) into the Liqui-tect panel enclosure through a conduit knockout or access slot.
4. Loosen the appropriate screw and slip the stripped end of the wire into the terminal block.
5. Tighten the screw until it holds the wire snugly.
Connections and Configuration
C
NO
NC
C
NO
NC
Alarm outputs
R17
K4
DS4
C
NO
NC
C
NO
NC
Zone 1
Zone 2
Key to
output
status
3.3 Connecting to a Building Maintenance System or External Alarm System
Two analog output connector blocks permit the user to connect auxiliary notification equipment to monitor the distance of the leak and
cable fault alarms. The terminal blocks are on the right side of the
Liqui-tect panel printed circuit board, just above the leak detection
cable connectors. To determine the proper wire size, see Table 4 -
Wiring specifications.
To connect an input:
1. Disconnect electrical power to the Liqui-tect panel.
R18
2. If necessary, remove a conduit knockout to permit wire entry
into the Liqui-tect panel enclosure.
3. Bring the wire(s) into the Liqui-tect panel enclosure through a conduit knockout or access slot.
4. Loosen the appropriate screw and slip the stripped end of the wire into the terminal block.
5. Tighten the screw until it holds the wire snugly.
TB4
-
+
lout Cable 2
C42
C38
TB5
-
+
lout Cable 1
Analog
output
connectors
16
3.4 RS422 SiteScan Web Connector
The Liqui-tect panel will interface with Liebert’s SiteScan Web enterprise
monitoring system. SiteScan can be used to monitor the Liqui-tect panel from
a host computer and silence the audible alarm. The terminal block connector,
TB8, is on the bottom edge of the board, near the left corner.
To connect the SiteScan Web to the Liqui-tect panel:
1. Disconnect electrical power to the Liqui-tect panel.
2. If necessary, remove a conduit knockout to permit wire entry into the
Liqui-tect panel enclosure.
3. Bring the wire(s) into the Liqui-tect panel enclosure through a conduit
knockout or access slot.
4. Loosen the appropriate screw and slip the stripped end of the wire into the
terminal block. Note that the wires are polarity sensitive.
5. Tighten the screw until it holds the wire snugly.
3.5 Disable the Audible Horn
The panel’s audible horn is enabled by default. You may disable it as follows:
1. Set DIP switch 1, the first switch, to the ON position (up) to disable the audible horn.
2. Press the reset button to initiate the change.
DIP switch 1 Audible horn
Connections and Configuration
AB
RS422 SiteScan
Web connector
R1
Reset
switch
DS1
Pwr On
A
O N
O N
SW2
SW1
R4
2345678
1
1
2
345678
K1
K2
R16
DS3
R17
K4
DS4
To re-enable the horn, set DIP switch 1, the first switch, to the OFF position (down) and press the
reset button.
17
4.0 OVERVIEW OF MENUS
The Liqui-tect panel displays the Opening Screen at startup, as shown in Figure 14.
If any alarms are active, the Current Alarm screen appears. (Pressing any key on the LCD keypad
will silence the audible alarm.)
If no alarms are present, the LCD screen will alternately display the Opening Screen and a screen
showing NO ALARMS PRESENT.
If no alarms are present and the Enter ↵ (Return) key is pressed, the Main Menu appears and pre-
sents two choices that lead to all functions within the panel:
• View Status (see 5.0 - View Status Options for step-by-step instructions)
• System and Control (see 6.0 - System and Control Options for detailed instructions)
4.1 View Status Overview
The View Status features are available to all users—no password is required. This permits all personnel to check on the status of any equipment or location being monitored. From this menu, any user
may:
• View cable status, the monitored cable length and the amount of current present (both zones)
• View data stored in the Alarm History Log
• View data stored in the Zone Trend Log
4.2 System and Control Overview
The System and Control options require a password. Authorized users may:
• Configure the Liqui-tect panel
• Reset any latched alarms
• Delete all records from the Alarm History Log
• Delete all records from the Zone Trend Log
Overview of Menus
Figure 14 Menu overview
“View Status” selected
> VIEW STATUS
SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
View Status Menu
(All users - no password)
VIEW CABLE STATUS
VIEW ALARM HISTORY
VIEW ZONE TREND
Opening Screen
LIQUI-TECT PANEL
DD-MON-YY HR:MM:SS
VERSION X.X.X
PRESS
↵=STATUS/SETUP
Main Menu
VIEW STATUS
SYSTEM AND CONTROL
↑↓=NEXT
See Section
5.0
See Section
5.1
5.2
5.3
↵=SELECT
(If any alarm is detected,
it appears automatically)
“System & Control” selected
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
System & Control Menu
(Password required)
SETUP SYSTEM
RESET LATCHED ALARM
CLEAR ALARM HISTORY
CLEAR ZONE TREND
See Section
6.0
See Section
6.2
6.9
6.10
6.11
18
5.0 VIEW STATUS OPTIONS
The View Status menu allows any user to view the status of cables in both zones, an alarm history log
and a trend log for both zones. The arrows
used to select the menu item.
This section presents step-by-step instructions for each of the following options:
•View Cable Status
• View Alarm History
• View Zone Trend
Figure 15 shows the main options available from the View Status menu.
Figure 15 Menu overview - View Status menu
Opening Screen
LIQUI-TECT PANEL
DD-MON-YY HR:MM:SS
VERSION X.X.X
PRESS
Main Menu
> VIEW STATUS
↵=STATUS/SETUP
SYSTEM AND CONTROL
View Status Options
↑↓ are used to scroll through the menu. The Enter ↵ key is
View Cable Status
STATUS ZN1 ZONE 1
↑↓=NEXT
STATUS ZN1 ZONE 1
LENGTH: 1000FT
CURRENT: 0UA
↑↓=NEXT
STATUS ZN2 ZONE 2
↑↓=NEXT
STATUS ZN2 ZONE 2
LENGTH: 3500FT
CURRENT: 0UA
↑↓=NEXT
NORMAL
↵=DONE
NORMAL
↵=DONE
See
Section
5.1
↑↓=NEXT
↵=SELECT
View Status
VIEW CABLE STATUS
VIEW ALARM HISTORY
VIEW ZONE TREND
↑↓=NEXT
View Status options
↵=SELECT
View Alarm History
> ALARM RECORD 100/100
ZONE 1
CABLE OK
29-AUG-03 12:04:00
ZONE 1
ALARM SILENCED - LCD
29-AUG-03 12:00:00
ZONE 1
LEAK @ 2007ft
29-AUG-03 11:48:03
ZONE 1
H/W RESET
29-AUG-03 10:32:22
ZONE 2
CABLE BREAK
29-AUG-03 09:08:07
See
Section
5.2
View Zone Trend
> ZONE TREND 288/288
ZONE 1 0 UA
ZONE 2 0 UA
29-AUG-03 12:04:00
See
Section
5.3
ZONE 1
LOSS OF POWER
29-AUG-03 07:15:41
19
View Status Options
5.1 View Cable Status
The Cable Status screens display the overall status of the cable connected to each of the two zones monitored by the Liqui-tect panel, as
well as the length of the cable being monitored and the amount of current present in each cable.
To view the status of the cable:
• From the Main Menu, use the arrows
shown at right, and then press Enter ↵.
• From the View Status Menu, use the arrows
Cable Status and press Enter ↵.
5.1.1 Cable Status Screens
Each Cable Status screen displays the zone name (ZN1 or ZN2) and its
label (for example,
Viewing Additional Screens
There are four Cable Status screens—two for each zone.
• To view additional screens, use the arrows
• To return to the previous screen, press the ESC key.
• When finished viewing the last screen, press Enter ↵.
Overall Condition
The first screen for each zone shows:
• the zone name (
ZONE 2)
• the current overall condition of the cable (for example,
ZONE 1 or ZONE 2) at the top.
ZN1 or ZN2) and its label (for example, ZONE 1 or
↑↓ to choose View Status, as
↑↓ to choose View
↑↓.
NORMAL)
Main Menu
> VIEW STATUS
SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
View Status Menu
> VIEW CABLE STATUS
VIEW ALARM HISTORY
VIEW ZONE TREND
↑↓=NEXT
↵=SELECT
Overall Condition (ZN1)
STATUS ZN1 ZONE 1
↑↓=NEXT
NORMAL
Length & Current (ZN1)
STATUS ZN1 ZONE 1
LENGTH: 1000FT
CURRENT: 0UA
↑↓=NEXT
↵=DONE
Overall Condition (ZN2)
STATUS ZN2 ZONE 2
↑↓=NEXT
NORMAL
The cable conditions tracked by the Liqui-tect panel appear in Table 5.
Table 5 Overall cable conditions
SOURCE Cable
CONDITIONS
RECORDED
NORMAL
CABLE BREAK
LEAK DETECTED (& location, e.g., LEAK @ 99 FT)
CONTAMINATED (& location, e.g., CONTAM @ 44 FT)
NOT INSTALLED
Length & Current (ZN2)
STATUS ZN2 ZONE 2
LENGTH: 3500FT
CURRENT: 0UA
↑↓=NEXT
Cable Length & Current Value
The second screen for each zone shows:
• the zone name (
• the length of cable being monitored (for example,
up to 0.5% as the panel is continuously calculating the distance of the connected cable
• the current reading (
ZN1 or ZN2) and its label (for example, ZONE 1 or ZONE 2)
1000FT)—this value may change dynamically by
0UA, where UA represents µA or microAmps)
↵=DONE
20
View Status Options
5.2 View Alarm History
The Alarm History Log contains up to 100 records of alarms that have
occurred. Records are added to this log as alarms occur.
To view the Alarm History Log:
• From the Main Menu, use the arrows
then press Enter ↵.
• From the View Status Menu, use the arrows
Alarm History, then press Enter ↵.
5.2.1 Alarm History Log
The Alarm History Log screen displays up to 100 records showing
alarms generated from the cable, panel operations, return from alarm
and loss of power. If the log contains any alarm records, the Alarm History Log screen displays details for each alarm:
• the source of the alarm (for example,
• a brief description of the problem (
• the date and time the alarm occurred
Table 6 shows conditions that the alarm history log records for analog inputs and the panel itself.
Table 6 Alarm History Log conditions
Source Cable Input Panel
CONDITIONS
RECORDED
CABLE BREAK
LEAK DETECTED (& location, e.g., LEAK @ 99 FT)
CONTAMINATED (& location, e.g., CONTAM @ 44 FT)
NO LEAK
CABLE OK
↑↓ to choose View Status,
↑↓ to choose View
ZONE 1 or ZONE 2)
CABLE OK)
Main Menu
> VIEW STATUS
SYSTEM AND CONTROL
↑↓=NEXT
View Status Menu
VIEW CABLE STATUS
> VIEW ALARM HISTORY
VIEW ZONE TREND
↑↓=NEXT
Alarm History Log
> ALARM RECORD 01/100
ZONE 1
CABLE OK
29-AUG-03 12:04:00
LOSS OF POWER
ALARM SILENCED
H/W RESET
ALARM RESET
↵=SELECT
↵=SELECT
If there are no alarms in the log, the screen displays the message:
HISTORY LOG EMPTY
Viewing Additional Screens
There may be up to 100 records of alarm data.
• To view additional records, use the arrows
• To return to the previous screen, press the ESC key.
↑↓.
21
View Status Options
5.3 View Zone Trend
The Zone Trend Log contains up to 288 records that are recorded at
regular intervals (every 24 hours) to assist users with verifying operational and troubleshooting problems. Records are added the beginning
of the log as they occur.
To view the Zone Trend Log:
• From the Main Menu, use the arrows
then press Enter ↵.
• From the View Status Menu, use the arrows
Zone Trend, then press Enter ↵.
5.3.1 Zone Trend Log
The Zone Trend Log screen displays up to 288 recent readings for each
zone. If the log contains any records, the Zone Trend Log screen displays details for each zone:
• the name of the zone (for example,
• the value for the amount of current present on each cable (for
example,
• the date and time of the reading
If there are no records in the log, the screen displays the message:
TREND DATA EMPTY
0UA, where UA represents µA or microAmps)
↑↓ to choose View Status,
↑↓ to choose View
ZONE 1 or ZONE 2)
Main Menu
> VIEW STATUS
SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
View Status Menu
VIEW CABLE STATUS
VIEW ALARM HISTORY
> VIEW ZONE TREND
↑↓=NEXT
↵=SELECT
Zone Trend Log
> ZONE TREND 01/288
ZONE 1 0UA
ZONE 2 0UA
29-AUG-03 12:04:00
Viewing Additional Screens
There may be up to 288 records of trend data for each zone.
• To view additional records, use the arrows
• To return to the previous screen, press the ESC key.
↑↓.
22
6.0 SYSTEM AND CONTROL OPTIONS
The System and Control menu allows you to configure the Liqui-tect panel—setting up inputs and
outputs and system features such as date and time. This menu also provides a vehicle for mapping
points, clearing latched alarms and deleting records from the Liqui-tect panel’s alarm and trend logs.
The arrows
and enter new information. Table 7 shows characters that may be entered in labels and values.
Table 7 Valid characters for data entry
Alphanumeric Special characters
A-Z, 0-9 space ! " # $ % & ( ) * + - / , . ; < = > @
The System and Control options require a password to prevent unauthorized users from making
changes to the system.
This section presents step-by-step instructions for each of the following:
• Login - enter the password
• Setup System - configure the Liqui-tect panel, system features
• Reset Latched Alarm - clear and reset any latched alarms
• Clear Alarm History - delete all records from the Alarm History Log
• Clear Zone Trend - delete all records from the Zone Trend Log
↑↓ are used to scroll through the menu. The Enter ↵ key is used to select the menu item
System and Control Options
6.1 Login
Users must enter a password to access any of the system and control
options. The password consists of four characters (see Table 7 for
valid characters).
The default password is AAAA. Changing the password to “0000”
eliminates the login requirement and prevents the login screen from
appearing. (To set up or change the password, see 6.8.1 - Change
Password.)
To log in:
• From the Main Menu, use the arrows
Control, then press Enter ↵, as shown at right.
• Use the arrows
Enter ↵. The Login menu appears.
• To enter your password:
• Use the arrows
• Press Enter ↵ to advance to the next character position.
• When finished, press Enter ↵ again.
The System and Control Menu appears next, with these options that are described in the following
sections:
• Setup System (Section 6.2 - Section 6.8)
• Reset Latched Alarm (Section 6.9)
• Clear Alarm History (Section 6.10)
• Clear Zone Trend (Section 6.11)
↑↓ to choose System and
↑↓ to choose System and Control, and press
↑↓ to choose a character.
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
Login
LOGIN
↑↓=SELECT ↵=NEXT/END
AAAA
System & Control Menu
> SETUP SYSTEM
RESET LATCHED ALARM
CLEAR ALARM HISTORY
↑↓=NEXT ↵=SELECT
CLEAR ZONE TREND
NOTE
If, after logging in, you press the ESC key to return to a previous screen that is not passwordprotected, you must log in again, including entering your password if you wish to access
password-protected functions.
23
Figure 16 shows the main options available from the System & Control menu.
Figure 16 Menu overview - System and Control menu
Opening Screen
LIQUI-TECT PANEL
DD-MON-YY HR:MM:SS
VERSION X.X.X
PRESS
↵=STATUS/SETUP
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
Login Screen
LOGIN
↑↓=SELECT ↵=NEXT/END
System & Control options
AAAA
System and Control Options
↵=SELECT
Setup System
>SETUP SYSTEM
RESET LATCHED ALARM
CLEAR ALARM HISTORY
CLEAR ZONE TREND
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Setup System options
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: N
LABEL: ZONE 1
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
Setup Zone 2 Menu
SETUP ZN2 ZONE 2
CONNECTED: N
LABEL: ZONE 2
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
See
Section
6.2
See
Section
6.3
Reset Latched Alarm
SETUP SYSTEM
>RESET LATCHED ALARM
CLEAR ALARM HISTORY
CLEAR ZONE TREND
Reset Latched Alarms
RESET LEAK & FAULT
LATCHED ALARMS? Y
↑↓=Y/N ↵=END
Setup Alarm Outputs
SELECT LONGEST
CABLE CONNECTED
>0-500FT (0-152.4 M)
0-1000FT (0-304.8M)
0-1500FT (0-472.2M)
0-2000FT (0-609.6M)
0-2500FT (0-762.0M)
0-3000FT (0-914.4M)
0-4000FT(0-1219.2M)
0-5000FT(0-1524.0M)
See
Section
6.4
Normally Open / Closed
ARE LEAK & FAULT
RELAYS NORMAL OPEN
OR NORMAL CLOSED? NO
↑↓=NO/NC ↵=END
Latched / Unlatched
IS LEAK & FAULT
ALARM LATCHED? Y
↑↓=Y/N ↵=END
See
Section
6.9
Clear Alarm History
SETUP SYSTEM
RESET LATCHED ALARM
>CLEAR ALARM HISTORY
CLEAR ZONE TREND
Clear Alarm History
CLEAR ALARM HISTORY
ARE YOU SURE? Y
↑↓=Y/N ↵=END
Setup Mapmode
See
Section
6.5
>ZN1 ZONE 1
Mapping Options
MAPPING ZN1 ZONE 1
CURRENT: 0UA
DISTANCE: ---ENTRIES:0 ESC=EXIT
Change Realarm Delay
CHANGE REALARM DELAY
5
MINUTES
↑↓=SELECT
Clear Zone Trend
See
Section
6.10
SETUP SYSTEM
RESET LATCHED ALARM
CLEAR ALARM HISTORY
>CLEAR ZONE TREND
Clear Zone Trend
CLEAR ZONE TREND
ARE YOU SURE? Y
↑↓=Y/N ↵=END
SELECT ZONE TO MAP
ZN2 ZONE 2
VIEW LAST MAP
See
Section
↵=END
6.6
Setup System Info
SETUP SYSTEM INFO
CHANGE PASSWORD
CHANGE DATE & TIME
FACTORY DEFAULTS
See
Section
6.7
See
Section
6.11
See
Section
6.8
Setup System Info options
Change Password Change Date & Time Factory Defaults
CHANGE PASSWORD
AAAA
See
Section
6.8.1
CHANGE DATE & TIME
DAYLIGHT SVG TIME: Y
18
-MAY-02 10:56:30
See
Section
6.8.2
RESTORE ALL DEFAULTS
ARE YOU SURE? N
24
See
Section
6.8.3
6.2 Setup System - Overview
The Setup System screen displays six options that allow you to configure zones with cable, alarm
outputs, the re-alarm delay time, log points to create a map and system details, such as changing the
login password or the system date and time:
• Setup ZN1 Zone 1
• Setup ZN2 Zone 2
• Setup Alarm Outputs
• Setup Re-Alarm Delay
• Setup Mapmode
• Setup System Info
System and Control Options
6.3 Setup System - Setup ZN1 Zone 1
The Liqui-tect panel has two independent zones—ZN1 and ZN2—that
may be configured individually. Each zone can monitor up to 5,000 ft.
(1524m) of cable.
If neither zone is configured as connected, the screen displays the
message:
WARNING! NO ZONES ARE INSTALLED
To configure the first zone:
Log In and Choose Setup System
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Setup System, then press Enter ↵.
Select Zone 1 to Configure
• From the Setup System Menu, shown at right, use the arrows
and press Enter ↵.
• Use the steps following Table 8 to change the default settings for Zone 1.
Table 8 shows the features you may change for Zone 1, along with the default settings. By default,
Zone 1 is not connected.
↑↓ to choose System and
↑↓ to choose
Setup System Menu
> SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
> CONNECTED: N
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
↑↓ to choose Setup ZN1 Zone 1
To activate Zone 1, you must specify it as connected. Other features that may be altered include the
name of the zone, the measurement units, and the sensitivity for detection of water and of contamination. You may also initiate automatic calibration, during which the Liqui-tect panel determines the
length of cable and parameters.
Table 8 Default settings - Zone 1
Feature Default Other Options
CONNECTED N (Not connected) Y (Connected)
LABEL ZONE 1 Any name (up to eight characters)
UNITS FT (feet) M (meters)
AUTO CALIBRATE Automatically calculates cable length Allows adjustment to calculated length of cable
SENSITIVITY FOR
WATER DETECT
SENSITIVITY FOR
CONTAMINATED
150 UA Can define between 25µA and 300µA
50 UA Can define between 20µA and 300µA
25
System and Control Options
6.3.1 Identify the Zone as Connected
To make use of the zone ZN1, you must specify it as Connected (Y). By
default, ZN1 is Not connected (N). See 3.1 - Connecting Leak Detec-
tion Cable Inputs for instructions on connecting the cable to this
zone.
• From the Setup Zone 1 Menu, choose Connected, as shown at
right, and press Enter ↵.
• To change this feature, use the arrows
nected) or N (No - Not connected), then press Enter ↵.
6.3.2 Change Zone Label
ZN1 has a default label (Zone 1) that you may change to a more
descriptive name, such as “SRVR RM1.” The label may consist of up to
eight characters (see Table 7 for valid characters).
• From the Setup Zone 1 Menu, choose Label, then press Enter ↵.
• To change the label, which may consist of up to eight characters:
• Use the arrows
• Press Enter ↵ to advance to the next character position.
• When finished, press Enter ↵ again.
↑↓ to choose a character.
↑↓ to choose Y (Yes - Con-
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
> CONNECTED: N
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
Zone Connected
IS CABLE CONNECTED
TO THIS ZONE? Y
↑↓=Y/N ↵=END
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: Y
> LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
Change Zone Label
CHANGE ZONE LABEL
6.3.3 Change Units Label
You may specify measurement units as feet (FT) or meters (M). The
default designation is FT (feet). The same measurement unit will
apply to both zones. For example, if you choose FT for Zone 1, Zone 2
will display in FT also.
• From the Setup Zone 1 Menu, choose Units, then press Enter ↵.
• To change the units label:
• Use the arrows
• Press Enter ↵.
LABEL: ZONE 1
↑↓=SELECT ↵=NEXT/END
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: Y
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
> UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
↑↓ to choose FT (feet) or M (meters).
Change Units Label
CHANGE UNITS
UNITS: FT
↑↓=FT/M ↵=END
26
System and Control Options
6.3.4 Auto Calibration
The auto calibration feature is designed to allow compensation for the
resistance tolerances in the two legs of the sensing wires.
As soon as cable is connected, the panel begins calculating the cable
length. Initiating the auto calibration feature allows the user to modify the distance to account for any discrepancies. Once the new distance is entered, the panel adjusts for the required offset between the
calculated value and the user value.
To initiate automatic calibration for ZN1:
• From the Setup Zone 1 Menu, choose Auto Calibrate, as shown
at right, and press Enter ↵.
• At the Change Maximum Length screen, you may change the
maximum length of cable protecting this zone:
• To begin calibration without changing this value, press
Enter ↵.
• To change the value, press and hold one of the arrow keys
to scroll through the numbers, then press Enter ↵.
• The next screen displays the progress of calibration.
6.3.5 Set Up Sensitivity for Water Detection
Each zone may be set up with a sensitivity level at which water is
detected.
• The most sensitive setting is 25 µA—minimal water is required to
trigger an alarm.
• The least sensitive setting is 300 µA. At this setting, the cable will
be submerged in water for a longer period before an alarm is triggered.
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: Y
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
> AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
Change Maximum Length
CHANGE MAX LENGTH
↑↓=SELECT
1000
Auto Calibration Progress
↑↓
THIS SCREEN WILL SHOW
AUTO CALIBRATION
TAKING PLACE
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: Y
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
> WATER DETECT:150 UA
CONTAMINATED:050 UA
FT
↵=ACCEPT
To change the setting:
• From the Setup Zone 1 Menu, choose Water Detect, as shown at
right, and press Enter ↵.
• The Water Detection Sensitivity screen displays the value for
detection of water (in the example at right,
150 UA, where UA rep-
resents µA or microAmps):
• To change the value, press and hold one of the arrow keys
to scroll through the numbers 25-300.
• Press Enter ↵.
Water Detection
Sensitivity
↑↓
CHANGE SENSITIVITY
FOR WATER DETECT
150
↑↓=SELECT ↵=END
UA
27
System and Control Options
6.3.6 Set Up Sensitivity for Contamination Detection
Each zone may be set up with a sensitivity level at which contamination on the cable is detected. Examples are construction debris and
dust.
• The most sensitive setting is 20 µA—light contamination will trigger an alarm.
• The least sensitive setting is 300 µA. This setting requires heavy
contamination to activate an alarm.
Increase the setting if nuisance alarms occur.
NOTE
Do not set this setting greater than the sensitivity for water
detection setting—for example, if the water detection setting is
50 µA, do NOT set the contamination sensitivity level at 60 µA,
or any value greater than 50 µA. If the contamination setting is
greater than the water detection setting, contamination alarms
will never occur.
• From the Setup Zone 1 Menu, choose Contaminated, as shown above right, and press Enter ↵.
• The Contaminated Detection Sensitivity screen displays the value for detection of contamination
(in the example at right,
• To change the value, press and hold one of the arrow keys
20-300.
• Press Enter ↵.
50 UA, where UA represents µA or microAmps):
Setup Zone 1 Menu
SETUP ZN1 ZONE 1
CONNECTED: Y
LABEL: ZONE 1
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
> CONTAMINATED:050 UA
Contamination Detection
Sensitivity
CHANGE SENSITIVITY
FOR CONTAMINATED
↑↓=SELECT ↵=END
↑↓ to scroll through the numbers
50
UA
28
System and Control Options
6.4 Setup System - Setup ZN2 Zone 2
NOTE
The setup options are identical for both zones, except the
name of the zone differs.
The Liqui-tect panel has two independent zones—ZN1 and ZN2—that
may be configured individually. Each zone can monitor up to 5,000 ft.
(1524m) of leak detection cable.
To configure the second zone:
• In the Setup System Menu, choose Setup ZN2 Zone 2 (see above
right).
• Follow the same procedures used in setting up Zone 1, as
described in the previous section, 6.3 - Setup System - Setup
ZN1 Zone 1.
Setup System Menu
SETUP ZN1 ZONE 1
> SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Setup Zone 2 Menu
SETUP ZN2 ZONE 2
> CONNECTED: N
LABEL: ZONE 2
↑↓=NEXT ↵=SELECT
UNITS: FT
AUTO CALIBRATE
WATER DETECT:150 UA
CONTAMINATED:050 UA
29
6.5 Setup System - Setup Alarm Outputs
The Liqui-tect panel has six alarm outputs—three types for each zone:
• Digital alarm output for cable break detection - a change in state indicates a broken cable or contamination on the cable
• Digital alarm output for leak detection - a change in state indicates a leak on the cable
• Analog alarm output for 4-20mA - the signal may indicate normal operation, the location of a
leak, a cable break or contamination
These outputs may have a wide variety of Liebert or other manufacturers’ equipment connected to
receive alarm notification.
To configure all alarm outputs:
Log In and Choose Setup System
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Setup System, then press Enter ↵.
Select Setup Alarm Outputs
• From the Setup System Menu, shown at right, use the arrows
choose Setup Alarm Outputs and press Enter ↵.
Table 9 shows alarm output features and their default settings: you
may specify the maximum cable length of analog alarm outputs, define
digital alarm output relays as Normally Open or Closed, and set up
alarms as Latched or Unlatched.
To change the default settings, use the steps following Table 9.
Table 9 Default settings - alarm outputs
Feature Default Other Options
LONGEST CABLE LENGTH 0-1000 ft. (0-304.8m) Up to 5000 ft. (1524m)
LEAK & FAULT RELAYS:
NORMALLY OPEN/CLOSED
LEAK & FAULT ALARM:
LATCHED/UNLATCHED
NO (Normally Open) NC (Normally Closed)
Y (Latched) N (Unlatched)
↑↓ to choose System and
↑↓ to choose
↑↓ to
System and Control Options
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
> SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Maximum Cable Length
SELECT LONGEST
CABLE CONNECTED
> 0-500FT (0-152.4 M)
↑↓=NEXT ↵=SELECT
0-1000FT (0-304.8M)
0-1500FT (0-472.2M)
0-2000FT (0-609.6M)
0-2500FT (0-762.0M)
0-3000FT (0-914.4M)
0-4000FT(0-1219.2M)
0-5000FT(0-1524.0M)
Normally Open / Closed
ARE LEAK & FAULT
RELAYS NORMAL OPEN
OR NORMAL CLOSED? NO
↑↓=NO/NC ↵=END
30
Latched / Unlatched
IS LEAK & FAULT
ALARM LATCHED? Y
↑↓=Y/N ↵=END
6.5.1 Specify Longest Cable Length
You may specify the length of the longest cable connected to either of the 4-20mA alarm outputs. The
default value is 0-1000 ft. (0-304.8m). Valid entries range from 0-500 ft. (0-152.4m) to 0-5000 ft.
(0-1524m), as shown in the Maximum Cable Length screen, below right.
Select the longer cable length installed on either zone. For example, if Zone 1 has 2000 ft. (609.6m) of
cable and Zone 2 has 3500 ft. (1066.8m), select 0-4000 ft. (0-1219.2m).
The chosen setting applies to both zones and is correlated to the 4-20mA output of each zone to provide the distance of the leak. Once the range is selected, the following correlation will be applied:
5mA = 0 ft. (0m)
19mA = 4000 ft. (1219.2m)
Table 10 shows the operation of the 4-20mA outputs.
Table 10 Operation of 4-20mA outputs
Signal Operation
0mA Indicates cable cannot be monitored
4mA Indicates normal operation
5mA 0 ft. (0m)
19mA Longest cable length (ft.)—for example, 4000 ft. (1219.2m)
20mA Indicates cable fault / contamination
System and Control Options
To specify the maximum cable length:
• From the Maximum Cable Length screen, below right, use the
arrows
↑↓ to choose the correct range—for example,
0-4000FT(0-1219.2M).
• Press Enter ↵.
6.5.2 Define Relays as Normally Open or Normally Closed
All four digital alarm outputs may be set up as Normally Open (NO) or
Normally Closed (NC). The default setting is NO (Normally Open). The
chosen setting applies to all cable fault/contamination and leak relays
for both zones.
To change the normal state:
• From the Normally Open / Closed screen, below right, use the
arrows
↑↓ to choose NO (Normally Open) or NC (Normally Closed).
• For a non-supervised mode, select Normally Open. The
relays energize for an alarm condition.
• For a supervised mode, select Normally Closed. The relays
de-energize for an alarm condition or loss of power.
• Press Enter ↵.
6.5.3 Define Alarms as Latched or Unlatched
All four digital alarm outputs may be set up as Latched (Y) or
Unlatched (N). When configured as Latched, alarms must be manually
reset by an operator after they are cleared, as described in 6.9 - Reset
Latched Alarms. The default setting is Latched (Y). The chosen setting applies to cable fault and leak relays for both zones.
To change this setting:
• From the Latched / Unlatched screen, shown at right, use the
arrows
• Press Enter ↵.
↑↓ to choose Y (Latched) or N (Unlatched).
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
> SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Maximum Cable Length
SELECT LONGEST
CABLE CONNECTED
> 0-500FT (0-152.4 M)
↑↓=NEXT ↵=SELECT
0-1000FT (0-304.8M)
0-1500FT (0-472.2M)
0-2000FT (0-609.6M)
0-2500FT (0-762.0M)
0-3000FT (0-914.4M)
0-4000FT(0-1219.2M)
0-5000FT(0-1524.0M)
Normally Open / Closed
ARE LEAK & FAULT
RELAYS NORMAL OPEN
OR NORMAL CLOSED? NO
↑↓=NO/NC ↵=END
Latched / Unlatched
IS LEAK & FAULT
ALARM LATCHED? Y
↑↓=Y/N ↵=END
31
System and Control Options
Following are some similarities and differences between Latched and Unlatched alarms.
Liqui-tect System’s Response to Alarms - Both Latched and Unlatched
When a leak or cable break is detected:
• An alarm occurs,
• A record is created in the Alarm History Log and
• The leak-detected or cable-break alarm output contact changes state.
Latched Alarms Only
The user must reset latched alarms before another leak or cable break alarm can occur.
NOTE
A contaminated cable alarm will never latch. Because this type of alarm serves only as a
warning, it allows leak or cable break alarms to occur.
Unlatched Alarms Only
When an alarm output returns to its normal state, the alarms automatically clear and the system
returns to normal.
If two leaks occur simultaneously on the same cable, the system creates a record with the distance of
the first leak and displays an average distance for the two leaks. Always check the Alarm History Log
(see 5.2 - View Alarm History) when leak detected alarms occur in unlatched mode.
6.6 Setup System - Setup Re-Alarm Delay
The re-alarm delay may be set to provide an audible, reminder alarm notification after an alarm has
been silenced. The timer begins when the original alarm is silenced; the reminder alarm will occur
after the specified delay time has expired. The default setting is 5 minutes. The delay time ranges
from 0 to 999 minutes.
To set up the re-alarm delay:
Log In and Choose Setup System
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Setup System, then press Enter ↵.
Select Setup Re-Alarm Delay
• From the Setup System Menu, shown at right, use the arrows
to
choose Setup Realarm Delay and press Enter ↵.
• From the Change Realarm Delay screen, shown at right, press
and hold one of the arrow keys
↑↓ to scroll through the numbers,
then press Enter ↵.
↑↓ to choose System and
↑↓ to choose
↑↓
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
> SETUP REALARM DELAY
SETUP MAPMODE
SETUP SYSTEM INFO
Change Realarm Delay
CHANGE REALARM DELAY
MINUTES
↑↓=SELECT
5
↵=END
32
6.7 Setup System - Setup Mapmode
Mapping involves measuring the exact location of various points along the leak detection cable. This
greatly simplifies the use of the Liqui-tect Monitoring System to quickly pinpoint the location of a leak.
The Liqui-tect Monitoring System determines the location of a leak by computing its distance along the
leak detection cable. By setting off alarms with a damp paper towel or sponge and marking each reading
on a map of the floor, you can define various points along the cable for later reference in finding a leak.
Up to 254 points can be mapped.
NOTE
You must perform the automatic calibration steps in 6.3.4 - Auto Calibration before mapping
can commence. The leak detection cable is 12 in. (30.48cm) to 18 in. (45.72cm) longer than the
nominal length, which allows a service loop should the cable need to be replaced. Automatic
calibration enables the Liqui-tect system to determine the cable’s exact length.
After the leak detection cable has been laid and properly connected, as described in 3.1 - Connecting
Leak Detection Cable Inputs, follow these steps to map the system:
1. Draw a floor plan that shows the routing of the leak detection cable, including any jumpers used
(non-sensing cable).
2. Using the LCD on the front panel of the Liqui-tect Monitoring System:
Log In and Choose Setup System
a. From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
b. Enter your password at the Login screen.
c. From the System and Control Menu, use the arrows
choose Setup System, then press Enter ↵.
Select Setup Mapmode
d. From the Setup System Menu, shown at right, use the
arrows
e. Use the following instructions to set up the mapping of each zone.
Set Up Mapping for Zone 1 or Zone 2
f. Use the arrows
ZN2 Zone 2—from the Select Zone to Map Menu, and press
Enter ↵.
The Liqui-tect Monitoring System is now ready for you to short the
cable, as described in steps 3 through 6.
3. Select the first point to be mapped and mark it on the floor map as
point “X” (where X represents 1 for the first point, 2 for the second,
and so on, up to 254). Determine the exact location of the point by
measuring the distance from the panel to the point or otherwise
describing its location (for example, “at front of chiller”).
4. Wrap a damp paper towel or sponge around the selected point on
the cable to cause a short in the cable and trigger an alarm.
5. After about 30 seconds, the Liqui-tect panel annunciates a short beep. The LCD displays the
computed distance to the leak.
6. Remove the paper towel and dry the cable. In approximately 20 seconds, the Liqui-tect panel
annunciates a long beep indicating the short has been removed.
7. Go to the next point and repeat this process (steps 3 through 6) until the entire cable has been
mapped. Up to 254 points can be mapped.
When complete, press the ESC key on the LCD to exit mapping mode and return to the previous screen.
Table 11 shows the default mapping settings for each zone.
Table 11 Default mapping values
Option Default setting
Current 0UA, where UA represents µA or microAmps
Distance (none)
↑↓ to choose Setup Mapmode and press Enter ↵.
↑↓ to choose a zone—either ZN1 Zone 1 or
↑↓ to choose System and
↑↓ to
System and Control Options
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
> SETUP MAPMODE
SETUP SYSTEM INFO
Select Zone to Map
SELECT ZONE TO MAP
> ZN1 ZONE 1
ZN2 ZONE 2
↑↓=NEXT ↵=SELECT
VIEW LAST MAP
Mapping Options
MAPPING ZN1 ZONE 1
CURRENT: 0UA
DISTANCE: ---ENTRIES:0 ESC=EXIT
33
System and Control Options
6.7.1 View Last Map
The View Last Map option allows you to review the mapped points
from the last mapping of a zone. This feature is the data logger for the
mapmode process described in the previous section, 6.7 - Setup Sys-
tem - Setup Mapmode.
In the View Last Map mode, the Liqui-tect panel shows the mapped
distance to a particular point along the leak detection cable, identifying each point with an entry number that corresponds to point “X”
(where X represents 1 for the first point, 2 for the second, and so on).
The user may view the entry number for point “X” and see the corresponding distance to that point. This may be used either to record that
distance on the floor map or to verify the distance already recorded on
the map.
When a leak occurs, the Liqui-tect Monitoring System displays the
distance of the leak. By referring to the final floor map, you can easily
determine the location of the leak.
To view the last map:
• From the Setup System Menu, shown at right, use the arrows
to
choose Setup Mapmode and press Enter ↵.
• Use the arrows
to Map Menu, and press Enter ↵.
(If no points have been mapped, the screen displays a message, as
shown below right.)
• If you haven’t already done so, record the distance for each point
on the final floor map next to the respective positions of each short
labeled “X” (for points 1, 2, 3 and so on as described in step 3 in the
previous section).
• Use the arrows
• When finished, press Enter ↵.
↑↓
↑↓ to choose View Last Map from the Select Zone
↑↓ to display the mapping data for the next point.
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
> SETUP MAPMODE
SETUP SYSTEM INFO
Select Zone to Map
SELECT ZONE TO MAP
ZN1 ZONE 1
ZN2 ZONE 2
↑↓=NEXT ↵=SELECT
> VIEW LAST MAP
Mapping for Last Map
MAPPING FOR LAST MAP
CURRENT: 0UA
DISTANCE: ---ENTRIES:0 ESC=EXIT
Message if No Mapping
THERE ARE NO
MAPPED POINTS
LOGGED
ESC=EXIT
34
6.8 Setup System - Setup System Info
The Setup System Info options allow users to:
• Change Password—used for access to system setup functions
• Change Date & Time/Automatic Daylight Saving Time—used to set the Liqui-tect panel’s
date and time and to enable automatic time change for Daylight Saving Time
• Restore Defaults—returns the Liqui-tect panel to its factory settings
To change any Setup System Info features:
System and Control Options
Log In and Choose Setup System
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Setup System, then press Enter ↵.
Select Setup System
• From the Setup System Menu, shown at right, use the arrows
to
choose Setup System Info and press Enter ↵.
• Use the following steps to access any of the Setup System Info options.
6.8.1 Change Password
A password is required to access the Liqui-tect panel’s system and
control options, as described in 6.1 - Login. The password consists of
four characters (see Table 7 for valid characters). The default password is AAAA.
Changing the password to “0000” eliminates the login requirement
and prevents the login screen from appearing.
Change the Password
To change the password:
• From the Setup System Info Menu, use the arrows
Change Password, then press Enter ↵.
• To change your password:
• Use the arrows
• Press Enter ↵ to advance to the next character position.
• When finished, press Enter ↵ again.
↑↓ to choose System and
↑↓ to choose a character.
↑↓ to choose
↑↓ to choose
Setup System Menu
SETUP ZN1 ZONE 1
SETUP ZN2 ZONE 2
SETUP ALARM OUTPUTS
↑↓=NEXT ↵=SELECT
SETUP REALARM DELAY
SETUP MAPMODE
> SETUP SYSTEM INFO
↑↓
Setup System Info Menu
SETUP SYSTEM INFO
> CHANGE PASSWORD
CHANGE DATE & TIME
↑↓=NEXT ↵=SELECT
FACTORY DEFAULTS
Change Password
CHANGE PASSWORD
AAAA
↑↓=SELECT ↵=NEXT/END
Reset Password to the Factory Default (“AAAA”)
To reset the password to the factory default of AAAA:
• Locate DIP switch 1 on the unit’s circuit board (see 1.4 - Controller Board Overview) and move
switches 2, 7 and 8 to the OFF position (down).
• Move the second switch to the ON position, then to the OFF position.
• Move the seventh switch to the ON position, then to the OFF position.
• Move the eighth switch to the ON position, then to the OFF position.
The password should now be AAAA.
35
6.8.2 Change Date & Time/Automatic Daylight Saving Time
The Liqui-tect panel has a built-in, real-time clock that is backed up by an encapsulated lithium battery and set up to adjust automatically for daylight saving time twice a year. The Setup System Info
menu allows you to change the date or time or automatic adjustment at any time.
System and Control Options
To change the daylight saving time setting, date or time:
• From the Setup System Info Menu, use the arrows
Change Date & Time, then press Enter ↵.
• To change the daylight saving time setting:
• To the right of Daylight Svg Time?
choose Y (Yes - automatically adjust for daylight saving time)
or N (No), then press Enter ↵.
• The format of the date and time is DD-MMM-YY HR:MM:SS.
To change the date or time:
• Press Enter ↵ to advance to the next character position you
want to change.
• Use the arrows
Date Day (DD) 0-31
Time Hour (HR) 00-23
• Press Enter ↵ to advance to the next character position.
• When finished, press Enter ↵ again.
6.8.3 Factory Defaults
At any time, you may restore all default values for settings in the
Liqui-tect panel as it was shipped, as shown in Table 12.
The password is the sole exception when reverting to the factory
default settings. The password can be reset to the factory default of
AAAA only through the DIP switches. For details, see Change
Password on page 35.
Table 12 Factory default settings
Feature Default
Zones
1 & 2
Alarm
outputs
Mapping
values
Re-alarm
delay
CONNECTED N (Not connected)
LABEL ZONE 1
UNITS FT (feet)
AUTO CALIBRATE Automatic
SENSITIVITY FOR
WATER DETECT
SENSITIVITY FOR
CONTAMINATED
LONGEST CABLE LENGTH 0-1000 ft. (0-304.8m)
LEAK & FAULT RELAYS:
NORMALLY OPEN/CLOSED
LEAK & FAULT ALARM:
LATCHED/UNLATCHED
Current
Distance (none)
Delay in minutes 5 minutes
use the arrows ↑↓ to
↑↓ to choose from available entries:
Month (MMM) JAN-DEC
Year (YY) 00-99
Minutes (MM) 00-59
Seconds (SS) 00-59
150 UA
50 UA
NO (Normally Open)
Y (Latched)
0UA, where UA represents µA
or microAmps
↑↓ to choose
Setup System Info Menu
SETUP SYSTEM INFO
CHANGE PASSWORD
> CHANGE DATE & TIME
↑↓=NEXT ↵=SELECT
FACTORY DEFAULTS
Change Date & Time
CHANGE DATE & TIME
DAYLIGHT SVG TIME? Y
30-APR-03 10:56:30
↑↓=SELECT
↵=NEXT/END
Setup System Info Menu
SETUP SYSTEM INFO
CHANGE PASSWORD
CHANGE DATE & TIME
↑↓=NEXT ↵=SELECT
> FACTORY DEFAULTS
Factory Defaults
RESTORE ALL DEFAULTS
ARE YOU SURE? Y
↑↓=Y/N ↵=END
36
System and Control Options
6.9 Reset Latched Alarms
The Reset Latched Alarms menu allows you to clear any leak or fault
alarms that have been defined as latched.
To clear latched alarms:
Log In and Choose Reset Latched Alarm
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Reset Latched Alarm, then press Enter ↵.
Choose Y to Reset Alarms
• From the Reset Latched Alarms Menu, use the arrows
choose Y (Yes - reset all latched alarms) or N (No - do not reset
alarms).
(If no alarms have been set up as latched, the screen displays a
message, as shown below right.)
• Press Enter ↵.
This is the only way to reset latched alarms. This step is required to
return latched points to their normal state. (To set up digital alarm
outputs as latched, see 6.5.3 - Define Alarms as Latched or
Unlatched.)
↑↓ to choose System and
↑↓ to choose
↑↓ to
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
Login
LOGIN
↑↓=SELECT ↵=NEXT/END
AAAA
System & Control Menu
SETUP SYSTEM
> RESET LATCHED ALARM
CLEAR ALARM HISTORY
↑↓=NEXT ↵=SELECT
CLEAR ZONE TREND
Reset Latched Alarms
RESET LEAK & FAULT
LATCHED ALARMS? Y
↑↓=Y/N ↵=END
Message if No Latched
Alarms
ALARMS ARE NOT SET
FOR LATCHING
ESC=EXIT
37
System and Control Options
6.10 Clear Alarm History
The Clear Alarm History menu allows you to delete all records from
the Alarm History Log, which contains up to 100 records of alarms
that have occurred.
To delete all records from the Alarm History Log:
Log In and Choose Clear Alarm History
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Clear Alarm History, then press Enter ↵.
Choose Y to Clear the Log
• From the Clear Alarm History Menu, use the arrows
choose Y (Yes - clear the Alarm History Log) or N (No - do not
clear the log).
(If there are no alarms or trends, the screen displays a message, as
shown below right.)
• Press Enter ↵.
↑↓ to choose System and
↑↓ to choose
↑↓ to
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
Login
LOGIN
↑↓=SELECT ↵=NEXT/END
AAAA
System & Control Menu
SETUP SYSTEM
RESET LATCHED ALARM
> CLEAR ALARM HISTORY
↑↓=NEXT ↵=SELECT
CLEAR ZONE TREND
Clear Alarm History
CLEAR ALARM HISTORY
ARE YOU SURE? Y
↑↓=Y/N ↵=END
Message if No Alarms
THERE ARE NO ALARMS
ESC=EXIT
Message if No Trends
THERE ARE NO TRENDS
ESC=EXIT
38
System and Control Options
6.11 Clear Zone Trend
The Clear Zone Trend menu allows you to delete all records from the
Zone Trend Log, which contains up to 288 records. These records are
created every 24 hours to assist in troubleshooting.
To delete all records from the Zone Trend Log:
Log In and Choose Clear Zone Trend
• From the Main Menu, use the arrows
Control, then press Enter ↵ (see 6.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
Clear Zone Trend, then press Enter ↵.
Choose Y to Clear the Log
• From the Clear Zone Trend Menu, use the arrows
choose Y (Yes - clear the Zone Trend Log) or N (No - do not clear
the log).
• Press Enter ↵.
↑↓ to choose System and
↑↓ to choose
↑↓ to
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑↓=NEXT
↵=SELECT
Login
LOGIN
↑↓=SELECT ↵=NEXT/END
AAAA
System & Control Menu
SETUP SYSTEM
RESET LATCHED ALARM
CLEAR ALARM HISTORY
↑↓=NEXT ↵=SELECT
> CLEAR ZONE TREND
Clear Zone Trend
CLEAR ZONE TREND
ARE YOU SURE? Y
↑↓=Y/N ↵=END
39
7.0 SPECIFICATIONS
7.1 Liqui-tect Panel Specifications
Specifications
Small Enclosure Large Enclosure
Power
Requirements
Dimensions
W x D x H, in. (mm)
Weight (Assembled) 7.68 lb. (3.48 kg) 20.56 lb. (9.33 kg)
Enclosure Type NEMA 1
Liquid Crystal Display (LCD) Four line, 20 character, backlit
Mounting Surface Building Wall or Structural Member
Ambient Operating
Environment
Processor Specifics
Model MC68HC16Z1
Clock speed 20MHz
Total RAM 128Kb
Total FLASH 256Kb
Total NVRam 32Kb
A/D Resolution (Analog IN) 14 bits
Clock Type Real-Time Clock
Clock battery backup type Internal
Clock battery life 10 years, constant, no power
Communications
SiteScan Web IGM Protocol, 422
Agency Listings
UL UL3121
CSA C22.2 No. 1010
CE Yes Yes
FCC Compliance CFR 47 Part 15
Inputs & Outputs (Quantity)
Cable Input (2) N/A
Analog Output (2) 4-20mA signal output
Alarm Output (4) 24VAC, 1A
No Transformer Module With Transformer Module
LPS0240
24VAC ±10%
of nominal;
50/60 Hz, 0.3A,
8VA
14-1/4 x 2-3/4 x 12
(361.95 x 69.85 x 304.8)
32°F to 104°F (0°C to 40°C)
0% RH to 95% RH (non-condensing)
115VAC
LPL1150
115VAC ±10%
of nominal;
60 Hz, 4A,
460VA
18 x 2-3/4 x 18
(457.2 x 69.85 x 457.2)
UL3121,
UL1012
C22.2 No. 1010,
C22.2 No. 66
230VAC
LPL2300
230VAC ±10%
of nominal;
50 Hz, 0.5A,
115VA
UL3121,
UL1585
C22.2 No. 1010,
C22.2 No. 107.1
NOTE
If the equipment is
used in a manner
not specified by the
manufacturer, the
protection provided
by the equipment
may be impaired.
40
NOTES
Specifications
41
Specifications
42
LIQUI-TECT MONITORING SYSTEM
MONITORING
USER MANUAL
The Company Behind the Products
With over a million installations around the globe,
Liebert is the world leader in computer protection
systems. Since its founding in 1965, Liebert has
developed a complete range of support and
protection systems for sensitive electronics:
• Environmental systems—close-control air
conditioning from 1 to 60 tons
• Power conditioning and UPS with power
ranges from 300 VA to more than 1000 kVA
• Integrated systems that provide both
environmental and power protection in a
single, flexible package
• Monitoring and control—from systems of any
size or location, on-site or remote
• Service and support through more than 100
service centers around the world and a 24/7
Customer Response Center
While every precaution has been taken to ensure
the accuracy and completeness of this literature,
Liebert Corporation assumes no responsibility and
disclaims all liability for damages resulting from
use of this information or for any errors or
omissions.
© 2004 Liebert Corporation
All rights reserved throughout the world.
Specifications subject to change without notice.
® Liebert and the Liebert logo are registered
trademarks of Liebert Corporation. All names
referred to are trademarks or registered
trademarks of their respective owners.
SL-31000 (9/04) Rev. 0
Technical Support/ Service
Web Site
www.liebert.com
Monitoring
800-222-5877
monitoring@liebert.com
Outside the US: 614-841-6755
Single-Phase UPS
800-222-5877
upstech@liebert.com
Outside the US: 614-841-6755
Three-Phase UPS
800-543-2378
powertech@liebert.com
Environmental Systems
800-543-2778
Outside the United States
614-888-0246
Locations
United States
1050 Dearborn Drive
P.O. Box 29186
Columbus, OH 43229
Italy
Via Leonardo Da Vinci 8
Zona Industriale Tognana
35028 Piove Di Sacco (PD)
+39 049 9719 111
Fax: +39 049 5841 257
Asia
23F, Allied Kajima Bldg.
138 Gloucester Road
Wanchai
Hong Kong
+852 2 572 2201
Fax: +852 2 831 0114
Loading...
