FB1100 Product Data Sheet
D301781X012 January 2021
Remote Automation Solutions
FB1100 Flow Computer
The FB1100 is a cost-effective, low-power explosion-proof
flow computer that measures and monitors gas flow for a
single differential pressure meter run. As well as bringing a
new level of measurement confidence, the FB1100 can run
independently without external power, for up to one year,
making it an ideal replacement for chart recorders.
The FB1100 is part of Emerson’s new field mount flow
computer family that delivers a convenient approach to
remote oil and gas sites by addressing challenges to power,
safety, measurement reliability, and accuracy.
Designed for simple configuration and ease of use, the cost
effective FB1100 flow computer is focused on metering
applications where control is not required.
The FB1100 provides a full audit trail, including enhanced
history, alarm and event logs as well as providing a discrete
output that can be used to drive an odorizer.
The FB1100 includes power options for the most remote
sites and has flexible communication capabilities, including
FBxWifi™, for both remote and networked sites.
The new flow computers also come with the latest
Rosemount™ multivariable measurement sensor
technology, providing high accuracy differential pressure
and static pressure measurement with long term stability to
help improve measurement confidence and production
efficiency.
Features
The FB1100 flow computer includes the following key
features:
▪ Increased measurement confidence, reduced
measurement uncertainty
▪ Measurement and I/O capability focused on metering
applications
▪ Industry leading differential and static pressure
measurement including 5-year stability
▪ High accuracy temperature measurement including
curve matching via the Callendar-Van Dusen equation
▪ Reduced need to re-calibrate resulting in less time spent
on site
▪ Simplified configuration and set-up with the
FBxConnectTM configuration software tool
▪ Cost-effective alternative to chart recorders
▪ Flexible design with power and communication options
to meet site needs
▪ Standard firmware supports global calculations for DP
metering including orifice, cone, Venturi, nozzle, and
conditioning orifice
▪ Standard firmware supports Properties Calculations for
Natural Gas and Pure Gas
▪ Simple selection of engineering units to suit local
requirements
▪ Global Hazardous Area Approvals – Class 1 Div 1 & 2,
ATEX & IEC Ex d & Ex nA
▪ FBxWifi allows secure local wireless access from safe area
▪ Ease of integration with support for Modbus, ROC, BSAP
and DNP3 protocols
▪ Enhanced security helps prevent unauthorized access
▪ Enhanced alarming and historical data storage, improved
audit trail
▪ Superior performance gives better control of your
operations and maximizes profits
▪ API 21.1 compliant
FBxWifi™
The optional FBxWifi communications enables you to
connect your laptop or tablet to the flow computer through
a secure wireless connection. Once connected wirelessly,
you can use FBxConnect configuration software to view
process values, edit configuration parameters, and collect
logs stored in the flow computer – all from within the safe
area.
FB1100
Aluminum Housing
Stainless Steel Housing
FB1100 January 2021
2 www.Emerson.com/FlowComputers
Power Options
The FB1100 has the following power options:
▪ External DC supply
▪ External DC supply with internal battery back-up
▪ Solar panel charging internal battery, FB1100 has
internal solar regulator
▪ Autonomous mode with internal battery powering the
FB1100 for 12 months
In "autonomous mode" the FB1100 runs from a single
battery for up to 12 months without recharging. The 12month battery life is based on the FB1100 running in low
power mode on a typical remote application with a local
collection of history and the use of the optional display for
up to 30 minutes per month. This option is an ideal
replacement for chart recorders, significantly reducing
measurement uncertainty and providing a complete
electronic audit trail. The 12-month battery life is achieved
under an ambient temperature of 25˚C/77˚F; refer to the
table on page 10.
The solar powered option provides up to 25 days of
autonomous operation without charge.
Internal battery option is not available with ATEX and IEC
approvals.
Firmware
The base firmware in the FB1100 flow computer measures
static pressure, differential pressure, and temperature for a
single meter run. The flow computer performs gas flow
calculations based on those inputs in either U.S., metric, or
other user-selectable units based on the calculation type.
The firmware supports the following flow calculations:
▪ AGA 3 1992/2013 (volume, mass/density, and
mass/relative density)
▪ ISO 5167 1991/1998/2003 (orifice, Venturi, and nozzle)
▪ Rosemount 405C Compact Orifice and 1595
Conditioning Orifice Plate
▪ McCrometer V-Cone® and Wafer Cone®
▪ NUFLO™ Cone
▪ AGA 9 (Multipath Ultrasonic)
The firmware supports the following property calculations:
▪ AGA 8 1994 (Detailed, Gross 1 and Gross 2)
▪ AGA8 2017 Part 1 and Part 2 (GERG 2008)
Note: AGA8 Part 2 / GERG 2008 provides support for the
following pure gases: Nitrogen, Carbon Dioxide,
Hydrogen, Oxygen, Carbon Monoxide, Water
Vapor, Hydrogen Sulfide, Helium, and Argon
▪ Speed of Sound calculated via AGA 10 and AGA 8 2017
Part 2
▪ NX-19 1962, MOD, VDI/VDE 2040
▪ ISO 12213 2009 (parts 2 and 3)
▪ SGERG 1991 (Std., Alt 1, Alt 2 and Alt 3)
▪ GPA 2172 2009 (including saturated vapor calculation)
▪ ISO 6976 1995 (superior and inferior, incorporating
Technical Corrigendum 2 [1997] and 3 [1999])
Regarding gas composition, the flow computer can:
▪ Receive updated gas composition from SCADA;
▪ Receive manual updates for gas composition through
FBxConnect; or
▪ Use a fixed gas composition
The firmware includes the following flow rates and totals:
▪ Indicated volume
▪ Corrected (standard) volume
▪ Mass
▪ Energy
The firmware supports a fallback mode when a process
variable's value is questionable. The fallback options can be
one of the following:
▪ Use last good value
▪ Use a fixed fallback value
Alarms and Events
The flow computer supports extensive alarming capability to
enhance operational efficiency and improve the audit trail.
Alarms are pre-allocated to meter runs for standard values
such as pressure, temperature, and differential pressure as
well as meter run flow rates. In addition to these standard
alarms, the FB1100 provides a number of user alarms that
you can assign to other database parameters simply by
“filling in the blanks” in user alarm templates in the
FBxConnect configuration tool. Storage is provided for the
most recent 1000 alarms in the alarm log.
The event log stores the significant events during operation
and can be configured to either store all events in a single log
of 2000 events or the user can select to store the
metrology/legal events in a separate log from the
operational events. With the latter option the event log
capacity is 1000 metrology events and 1000 operation
events.
History
The FB1100 features expanded and flexible history capability
to ensure measurement confidence and meet the increasing
demands for secure data.
The flow computer has four standard periodic logs available
providing hourly, daily, weekly, and monthly history. These
logs can contain up to 35 variables including flow weighted
average data, totals, and gas composition. For averaging,
the FB1100 supports either flow weighted or flow
dependent which can be linear or formulaic.
The FB1100 can store the following:
▪ Hourly logs 62 days
▪ Daily logs 12 months
▪ Weekly logs 12 months
▪ Monthly logs 60 months
January 2021 FB1100
www.Emerson.com/FlowComputers 3
The flow computer also supports two user periodic logs, the
duration or period of each is user selectable between 1
minute and 200 hours. The first user periodic logs include 10
parameters over 4,000 periods and the second contains 20
parameters over 500 periods.
The flow computer with FBxConnect provides pre-formatted
EFM reports for hours and days. The format of the reports
can be .csv, .pdf or secure pdf.
In addition to the above reports, the flow computers can
produce FLOWCAL-complaint. cfx files through the
FBxConnect tool as well as calibration reports which contain
U.S. Bureau of Land Management specific parameters.
Housing
The FB1100 includes an explosion-proof and flame-proof
enclosure made of die-cast aluminum or stainless steel that
can operate in an unprotected outdoor environment. Wiring
for I/O, communications, and power enters the enclosure
through the four conduit fittings. The front end cap provides
a viewing window for the optional LCD. The rear end cap
provides access to the screw terminals. The end caps can
also be fitted with wire security seals.
Hazardous Area Certifications
The FB1100 has the following Global Hazardous Area
Approvals:
▪ North American certification for Class I Division 1 Groups
C and D (explosion proof) and Class I Division 2 Groups A,
B, C and D
▪ ATEX and IECEx certification for Exd Zone 1 (flame proof)
and Exn Zone 2 hazardous locations
Configuration Software
Emerson’s new FBxConnect tool is a Microsoft® Windows®-
based tool that enables you to easily monitor, configure,
service, and calibrate the FB1100 flow computer. Designed
for ease of use, FBxConnect provides at-a-glance monitoring,
quick access to commonly performed tasks, and a guided
configuration process to quickly get your measurement up
and running.
The wizard-driven approach simplifies configuration and
ensures that you only need to enter the required data once.
Whether you are an experienced engineer or a new
technician, you can be confident configuration is done
correctly the first time.
FBxConnect runs on a Windows PC or tablet. You connect
securely to the flow computer using one of its serial ports or
optionally through the FBxWifi wireless connection. For
more information, refer to product data sheet FBxConnect
(D301789X012).
Multivariable Sensor
Enabled by superior sensor technology and engineered for
optimal flow performance, the MVS on the FB1100 delivers
unparalleled accuracy over a wide range of operating
conditions and industry leading stability. Pressure inputs on
the sensor are used to measure differential (up to 1000” of
water) and static (absolute or gauge) pressure with an
operating range of up to 3600 psi and accuracies of up to
0.075%.
Monitor Screen
DP Meter
Temperature Input (RTD/PRT)
With industry-leading measurement accuracy, the
temperature measurement of the FB1100 will ensure that
you minimize your measurement uncertainty in all operating
conditions. The input accepts two-, three-, or four-wire
connections reducing any field wiring induced errors and
also supports sensor curve matching utilizing the optional
Callendar Van-Dusen constants to define the unique
characteristics of the RTD/PRT to further improve process
temperature measurement uncertainty.
The FB1100 flow computer’s superior static pressure,
differential pressure (DP) and temperature measurement
performance and stability ensures you meet standards and
regulations so you can avoid fines, penalties, leaseholder
disputes, and lost revenue. With the advanced
measurement, you’re getting the most accurate flow
reading to ensure you meet your company and regulatory
performance requirements.
FB1100 January 2021
4 www.Emerson.com/FlowComputers
Discrete Output
The FB1100 includes a single discrete output (DO) which
provides the ability to control various discrete output field
devices. The DO channel is a solid-state, normally open
switch rated at 500 mA, enough to directly drive most
odorizers or samplers. The DO channel can be software
configured as a latched, toggled, momentary, timed
duration output (TDO), or scaled pulse output.
Communications
The FB1100 has three serial communications ports with
support for RS-232, RS-422, and/or RS-485 operation, and
one port that supports optional FBxWifi (802.11 b/g)
communications using DNP3 protocol.
▪ COM1 – 4-wire serial communications. Software
selectable for EIA-232 (RS-232), EIA-422 (RS-422), or EIA485 (RS-485) operation.
▪ COM2 – 2-wire serial communications. Software
selectable for EIA-232 (RS-232) or EIA-485 (RS-485)
operation.
▪ COM3 – 2-wire serial communications. Software
selectable for EIA-232 (RS-232) or EIA-485 (RS-485)
operation.
▪ COM4 –FBxWifi (802.11 b/g) communications
(optional).
The FB1100 supports DNP3, Modbus slave (ASCII and RTU),
BSAP, and ROC protocols on the three serial ports and DNP3
on the FBxWifi port.
Mounting Options
The flow computer supports either direct mount to a
manifold on the pipeline or indirect mounting on a two-inch
pipe or pole. A mounting bracket and bolts are available for
use with a traditional flange or coplanar flange.
Security
To secure your valuable process and data, the FB1100
provides multi-level role-based access, user account
authentication, and password encryption.
The system administrator can set a minimum password
length (up to 20 characters) that accommodates lower case,
upper case, numbers, and symbols, as well as configure a
user lock-out feature that locks out invalid users after a
defined number of failed login attempts.
January 2021 FB1100
www.Emerson.com/FlowComputers 5
FB1100 Flow Computer
CPU Module
Processor
The central processing unit (CPU) of the flow computer is an NXP® Kinetis® K61 series CPU with an
ARM® Cortex® M4 processor.
Memory
SRAM
8 MB, holds current states of all variables and historical archives.
Flash
128 MB, holds firmware image and configuration files.
Clock
Type
Real-time clock
Accuracy
0 °C to 40 °C
60 seconds/year
−40 °C to 80 °C
110 seconds/year
Watchdog Timer
1175 milliseconds
Diagnostics
Battery voltage monitor, external voltage monitor, SRAM battery status
Communications
Ports
COM1
4-wire serial communications.
Software selectable for RS-232, RS-422, or RS-485 operation.
COM2
2-wire serial communications.
Software selectable for RS-232 or RS-485 operation.
COM3
2-wire serial communications.
Software selectable for RS-232 or RS-485 operation.
COM4
FBxWifi (optional) 802.11 b/g
Protocols
Serial ports support DNP3, Modbus slave (ASCII and RTU), BSAP, and ROC
Wi-Fi supports DNP3
DNP3 includes level 3 protocol subset
Inputs/Outputs
The base FB1100 includes the following I/O:
▪ 1 multivariable sensor, measures differential pressure and static pressure
▪ 1 process temperature input (PRT/RTD)
▪ 1 discrete output (DO)
The I/O of the FB1100 is focused on a standard metering application with a DO that is typically used to drive an odorizer.
Multivariable Sensor
The standard Rosemount™ MultiVariable™ sensor has a stainless steel coplanar flange, a stainless steel (316L) diaphragm, and
silicone fill fluid. Optional versions include:
▪ A Hastelloy
®
C-276 sensor diaphragm, a Hastelloy C-276 coplanar flange, with either NACE MRO175/ISO 15156 or MRO103
certification
▪ Stainless steel traditional flange, a stainless steel diaphragm, and silicon fill fluid.
Differential Pressure
Input
DP Range 1
−25 to 25 Inches H2O (−62.16 to 62.16 mbar)
Reference
Accuracy
± 0.1% span;
For spans less than 5:1, ± (0.025+0.015 [USL/Span]) % span
Stability
±0.2% USL for 1 year
FB1100 January 2021
6 www.Emerson.com/FlowComputers
Ambient
Temperature
Effect per 50°F
(28°C)
from 1:1 to
30:1
± (0.2% USL + 0.25% span)
from 30:1
to 50:1
± (0.24% USL + 0.15% span)
Static Pressure
Effects
Zero Error
± 0.25% USL per 1000 psi (69 bar)
Span Error
± 0.4% USL per 1000 psi (69 bar)
Over Pressure
Limit
SP Range 3
2000 psi (137.89 bar)
Burst Pressure
Limit
10,000 psi (689.47 bar)
Notes:
▪ 25-inch sensor is only available with static pressure SP Range 3, maximum
pressure limited to 2000 psi.
▪ 25-inch sensor is only available with stainless steel sensor and coplanar
flange.
DP Range 2:
Standard
0 to 250 Inches H2O (623 mbar)
Reference
Accuracy
± 0.1% span;
For spans less than 10:1, ± (0.01 [USL/Span]) % span
Stability
±0.1% USL for 1 year
Ambient
Temperature
Effect per 50°F
(28°C)
from 1:1 to
30:1
± (0.15% USL)
from 30:1
to 50:1
± (0.20% USL)
Static Pressure
Effects
Zero Error
± 0.1% USL per 1000 psi (69 bar)
For Static Pressures above 2000 psi:
± [0.2 + 0.0001 * (Ps - 2000)] % /1000 psi
Span Error
± 0.2% USL per 1000 psi (69 bar)
Over Pressure
Limit
SP Range 1
1600 psi (110.32 bar)
SP Range 2
3626 psi (250.00 bar)
SP Range 3
3626 psi (250.00 bar)
Burst Pressure
Limit
10,000 psi (689.47 bar)
Note: 0.1% Accuracy is not available on traditional flange.
DP Range 2:
Enhanced
0 to 250 Inches H2O (623 mbar)
Reference
Accuracy
± 0.075% span;
For spans less than 10:1, ± (0.025 +0.005 [USL/Span]) %
span
Stability
±0.125% USL for 5 years;
For ±50 °F (28 °C) temperature changes, up to 1000 psi
(68.9 bar) line pressure
January 2021 FB1100
www.Emerson.com/FlowComputers 7
Ambient
Temperature
Effect per 50°F
(28°C)
± (0.0175% USL + 0.1% span) from 1:1 to 5:1,
± (0.035% USL + 0.125% span) from 5:1 to 100:1
Static Pressure
Effects
Zero Error
± 0.05% USL per 1000 psi (69 bar)
For Static Pressures above 2000 psi:
± [0.1 + 0.0001 * (Ps - 2000)] % /1000 psi
Span Error
± 0.2% USL per 1000 psi (69 bar)
Over Pressure
Limit
SP Range 1
1600 psi (110.32 bar)
SP Range 2
3626 psi (250.00 bar)
SP Range 3
3626 psi (250.00 bar)
Burst Pressure
Limit
10,000 psi (689.47 bar)
DP Range 3:
Standard
0 to 1000 Inches H2O (2.5 bar) DP
Reference
Accuracy
± 0.1% span;
For spans less than 10:1, ± (0.01 [USL/Span]) % span
Stability
±0.1% USL for 1 year
Ambient
Temperature
Effect per 50°F
(28°C)
from 1:1 to
30:1
± (0.15% USL)
from 30:1
to 50:1
± (0.20% USL)
Static Pressure
Effects
Zero Error
± 0.1% USL per 1000 psi (69 bar)
For Static Pressures above 2000 psi:
± [0.2 + 0.0001 * (Ps - 2000)] % /1000 psi
Span Error
± 0.2% USL per 1000 psi (69 bar)
Over Pressure
Limit
SP Range 2
3626 psi (250.00 bar)
SP Range 3
3626 psi (250.00 bar)
Burst Pressure
Limit
10,000 psi (689.47 bar)
Notes:
▪ 0.1% Accuracy is not available on traditional flange.
▪ 1000" DP range with 0.1% accuracy only available with stainless steel sensor
and coplanar flange.
▪ 1000" DP range is not available with 300 psi static pressure (SP Range 1).
FB1100 January 2021
8 www.Emerson.com/FlowComputers
DP Range 3:
Enhanced
0 to 1000 Inches H2O (2.5 bar) DP
Reference
Accuracy
± 0.075% span;
For spans less than 10:1, ± (0.025 +0.005 [USL/Span]) %
span
Stability
±0.125% USL for 5 years;
For ±50 °F (28 °C) temperature changes, up to 1000 psi
(68.9 bar) line pressure
Ambient
Temperature
Effect per 50°F
(28°C)
± (0.0175% USL + 0.1% span) from 1:1 to 5:1,
± (0.035% USL + 0.125% span) from 5:1 to 100:1
Static Pressure
Effects
Zero Error
± 0.05% USL per 1000 psi (69 bar)
For Static Pressures above 2000 psi: ± [0.1 +
0.0001 * (Ps - 2000)] % /1000 psi
Span Error
± 0.2% USL per 1000 psi (69 bar)
Over Pressure
Limit
SP Range 2
3626 psi (250.00 bar)
SP Range 3
3626 psi (250.00 bar)
Burst Pressure
Limit
10,000 psi (689.47 bar)
Note: 1000" DP range is not available with 300 psi static pressure (SP Range
1).
Static Pressure Input
SP Range 1
Gauge
−14.2 to 300 psig (−0.98 to 20.68 bar)
Absolute
0.5 to 300 psia (0.03 to 20.68 bar)
Reference
Accuracy
Standard
± 0.1% span;
For spans less than 5:1, ± [0.017 (USL/Span)]
% span
Enhanced
± 0.075% span;
For spans less than 5:1, ±[0.013(USL/Span)]
% span
SP Range 2
Gauge
−14.2 to 1500 psig (−0.98 to 103.42 bar)
Absolute
0.5 to 1500 psia (0. 03 to 103.42 bar)
Reference
Accuracy
Standard
± 0.1% span;
For spans less than 5:1, ± [0.017 (USL/Span)]
% span
Enhanced
± 0.075% span;
For spans less than 5:1, ±[0.013(USL/Span)]
% span
SP Range 3
Gauge
−14.2 to 3626 psig (−0.98 to 250.00 bar)
Absolute
0.5 to 3626 psia (0.03 to 250.00 bar)
Note: When used with 25” H2O DP sensor, maximum static pressure is 2000
psi.
January 2021 FB1100
www.Emerson.com/FlowComputers 9
Reference
Accuracy
Standard
± 0.1% span;
For spans less than 5:1, ± [0.017 (USL/Span)]
% span
Enhanced
± 0.075% span;
For spans less than 5:1, ±[0.013(USL/Span)]
% span
Stability
Standard
Accuracy
±0.1% USL for 1 year
Enhanced
Accuracy
±0.125% USL for 5 years
Ambient
Temperature
Effects per 28°C
(50°F)
Standard
Accuracy
± (0.175% USL) from 1:1 to 10:1,
± (0.225% USL) from 10:1 to 25:1
Enhanced
Accuracy
± (0.050% USL + 0.125% span) from 1:1 to 10:1,
± (0.060% USL + 0.175% span) from 10:1 to 25:1
Inputs
Temperature Input
(RTD/PRT)
Type
2-, 3-, or 4-wire (software selectable)
Measuring Range
−200 to +850°C (−328 to +1562 °F)
Reference
Accuracy
+/- 0.1°C from −60 to 200 °C (±0.18 °F from −76 to +392 °F)
+/- 0.07°C from −30 to 60 °C (±0.126 °F from −22 to +140 °F)
Ambient
Temperature
Effect
−30 to 60 °C
+/- 0.017 °C per 10 °C (+/- 0.03 °F per 18 °F) from the
calibration temperature
−60 to 200 °C
+/- 0.034 °C per 10 °C (+/- 0.06 °F per 18 °F) from the
calibration temperature
Calculation Type
User selectable
between
Callendar–Van Dusen
IEC 751/DIN 43760 (α 0.00385/°C)
IEC (α 0.003920/°C)
Resolution
24 bits
Scan Rate
1 second
Voltage Input
Impedance
Greater than 3 MΩ DC
Excitation Current
205 µA
Surge Suppression
36 Vdc
Common Mode
Rejection
100 dB at DC
Normal Mode
Rejection
100 dB at 50/60 Hz
FB1100 January 2021
10 www.Emerson.com/FlowComputers
Outputs
Discrete Output
Type
Open drain
Current Mode
500 mA maximum
Operating Voltage
Range
30 Vdc maximum
Frequency
50 Hz maximum
Output Type
Latched, momentary, toggle, TDO, or scaled pulse
Surge Suppression
30 Vdc
Fault Mode
User-entered default value or last good value
Power
External DC Power
Supply
5.7 Vdc to 30 Vdc external supply (Max power at 10 watts)
Optional Rechargeable
Lead Acid Battery
Internal mounted 4.5 Ah 6.0 Vdc battery
The battery can power the unit for up to 25 days without any solar charging depending on display and
communications usage, and can be charged by a 6-watt solar panel or from a DC supply for backup
Note: This option is available with Class 1 Div1 and Class 1 Div 2 approvals only.
Lithium Battery Pack
10 Vdc, 41 Ah
Required when using autonomous measurement mode
Allows operation for one year in autonomous measurement mode with monthly data collection and
30 minutes per month of display use. Battery life is affected by ambient temperature, as shown in the
following table:
Ambient Temperature
Typical Impact on Battery Life
25˚C
0%
-30˚C
23%
0˚C
19%
55˚C
34%
72˚C
38%
Note: This option is available only with Class 1 Div1 and Class 1 Div 2 approvals.
Lithium battery shipping restrictions apply.
Solar Panel
If ordered with the rechargeable battery option, the FB1100 includes an integral solar regulator
Can be supplied with an optional 6-watt 6 Vdc solar power
The solar panel input is rated to a maximum of 30V and 1.5A. A minimum of 8V is required to charge
the battery.
Note: This option is available only with Class 1 Div1 and Class 1 Div 2 approvals.
SRAM Battery
Lithium coin cell type BR2335 or BR2330
Typical battery life 5-7 years with power; 10,000 hours without power
January 2021 FB1100
www.Emerson.com/FlowComputers 11
Power Modes
To keep power consumption to a minimum, especially for remote sites, the FB1100 can run in two different power modes, low
and standard. The FB1100 normally runs in low power mode for standard metering applications.
When running in low power mode, the radio power control function is used to switch to standard power mode and enable the
serial ports. During communication periods, the unit uses the standard power mode and then automatically reverts to low power
mode when the communication period is over.
The local display and FBxWifi can be configured to switch off after a period of inactivity (configurable between 1 and 60 minutes)
or be permanently left on.
When running in low power mode, if you need to use more than the default number of data points for logging, consult the
Emerson FB1100 Flow Computer Instruction Manual (D301752X012) to determine the possible impact on power consumption.
The figures below are typical power values in mW measured at room temperature.
Low Power Mode
Base unit with integral multivariable DP and pressure sensor
and temperature measurement
36 mW @ 6Vdc
Additional Load
Options
Display and Backlight active
296 mW @ 6Vdc
FBxWifi
315 mW @ 6Vdc
FBxWifi and Display active
340 mW @ 6Vdc
DO active (1 Hz, 50:50 duty cycle, no
load)
10 mW @ 6Vdc
Standard Power Mode
Base unit with integral multivariable
DP and pressure sensor and
temperature measurement
209 mW @ 6Vdc
224 mW @ 12Vdc
265 mW @ 24Vdc
Additional Load
Options
Display and
Backlight active
162 mW @ 6Vdc
168 mW @ 12Vdc
178 mW @ 24Vdc
FBxWifi
189 mW @ 6Vdc
185 mW @ 12Vdc
200 mW @ 24Vdc
FBxWifi and
Display active
204 mW @ 6Vdc
207 mW @ 12Vdc
221 mW @ 24Vdc
DO active (1 Hz,
50:50 duty cycle,
no load)
21 mW @ 6Vdc
23 mW @ 12Vdc
20 mW @ 24Vdc
Physical
Construction
Die-cast aluminum, painted, with wire sealable end caps, or
Stainless steel (AISI 316/ASTM CF8M), unpainted, with wire sealable end caps
Ingress Protection
IEC 60529 IP66 & NEMA 4X
Dimensions
11.715 in. H by 6.0 in. W by 9.426 in. D (297.7 mm H by 152.4 mm W by 239.4 mm D)
Mounting
2 in. pipe or direct manifold
Wiring
Size 12 to 28 American Wire Gauge (AWG) (0.3 to 2.0 mm diameter)
Wiring Access
4 conduit entry points
3/4 in. NPT (standard) M20 (optional)
Weight
FB1100 aluminum housing with MVS coplanar flange sensor: 6.75 Kg (14.9 lb)
FB1100 stainless steel housing with MVS coplanar flange sensor: 13.27 Kg (29.5 lb)
Optional Lead Acid battery: 0.86 Kg (1.9 lb)
Optional Lithium Battery: 0.95 Kg (2.1 lb)
FB1100 January 2021
12 www.Emerson.com/FlowComputers
Display
Optional backlit liquid crystal display
HMI
20 characters per line; 4 lines in display
Environmental
Operating Temperature
−40 °C to +80 °C (−40°F to +176 °F) (see ambient temps in Approvals section)
Note: Please check Approvals section for any restrictions. The display exhibits increased response time and
decreased contrast at temperatures below -30C (–22 F).
Storage Temperature
−40 °C to +85 °C (−40°F to +185 °F)
Operating Humidity
5 to 95%, non-condensing
Conformal Coating
All boards are conformal coated with a coating that complies with ANSI/ISA 71.04 Class G3
environments.
Environmental Rating
Product conforms to ANSI/ISA 71.04 Class G3 environmental standards with all conduit openings
sealed.
Electro Magnetic
Compatibility
The following EMC Emissions and Immunity are evaluated per EMC directive 2014/30/EU. Harmonized
standards used:
EN 61326-2-3-2013 Immunity
EN 61326-1-2013 Emissions
Immunity
EN 61000-4-2 (Electro Static Discharge)
EN 61000-4-3 (Radiated Immunity) *
EN 61000-4-4 (Fast Transients)
EN 61000-4-5 (Surges)
EN 61000-4-6 (Conducted RF)
EN 61000-4-8 (Power Frequency Magnetic Field)
EN 61000-4-17 (Voltage Ripple)
EN 61000-4-29 (Voltage Dips and Interrupts)
*Meets CE compliance 10V/m industrial requirements (deviations < 1% span for RTD and Pressure readings in
addition to original specification)
Radiated Emissions
EN 55022 Class A
Vibration
2g over 10 to 150 Hz
1g over 150 to 200 Hz
Approvals
Product Markings for
Hazardous Locations
UL
Class 1, Div 1 Groups C, D, Temperature Code, T6
Class 1, Div 2 Groups A, B, C, D, Temperature Code T4
Ambient Temperature
Aluminum enclosure
-40 °C to +80°C (-40 °F to +176 °F) (no battery)
-40 °C to +80°C (-40 °F to +176 °F) (with
rechargeable lead acid battery)
-40 °C to +80°C (-40 °F to +176 °F) (with integral
lithium battery)
January 2021 FB1100
www.Emerson.com/FlowComputers 13
Evaluated per Approval
Standards
Per Class 1, Div 1:
UL 1203 5th Ed.
UL/IEC 61010-1 Part 1 3rd Ed.
CSA C22.2 No. 30-M1986
CSA C22.2 No. 61010-1-12 Part 1 3rd Ed.
Per Class 1, Div 2:
ANSI/ISA 12.12.01-2015
CSA C22.2 No. 213-15
CSA C22.2 NO. 61010-1-12 Part 1 3rd Ed
UL61010-1 Part 1 3rd Ed
UL
ATEX Cert: DEMKO 15 ATEX 1349X
IECEx Cert: IECEx UL 15.0024X
Ex db IIB T4 Gb, −40°C to +80°C
Ambient Temperature
II 2 G.
−40 °C to +80 °C (−40 to +176 °F)
Evaluated per Approval
Standards:
Directive 2014/34/EU
EN 60079-0:2012+A11:2013
EN 60079-1:2014
ATEX Cert: DEMKO 15 ATEX 1367X
IECEx Cert: UL 15.0044X
Ex nA IIC T4 Gc
Ambient Temperature
II 3 G.
−40 °C to +80 °C (−40 to +176 °F)
Evaluated per Approval
Standards:
Directive 2014/34/EU
EN 60079-0:2012+A11:2013
EN 60079-15:2010
Note: ATEX and IECEx approval requires the use of an external DC power
supply.
Miscellaneous
Approvals
Customs Union
TR CU 004/2011, TR CU 020/2011
Conforms to the requirements of the technical regulations of the Customs Union
RoHS2
Device with integral MVS or SP Sensor:
RoHS (2) EU Directive 2011/65/EU: This product may be considered out-of-scope
when used for the intended design purpose in a Large Scale Fixed Installation
(LSFI). Consult https://www.emerson.com/compliance for up-to-date product
information.
RoHS
NIMTT
China National Institute of Measurement and Testing Technology
Test Report: 201801001329
FB1100 January 2021
14 www.Emerson.com/FlowComputers
NEPSI China
National Supervision and Inspection Centre for Explosion Protection and Safety
of Instrumentation
Cert. No. GYJ18.1015X
Ex d IIB T4 Gb
Cert. No. GYJ17.1350X
Ex Na IIC T4 Gc
CCOE India
Chief Controller of Explosives
Approval No. A/P/HQ/MH/104/5885 (P420948)
Ex db IIB T4 Gb
Approval No. A/P/HQ/MH/104/5887 (P420946)
Ex Na IIC T4 Gc
NMi
Report Number: NMi-1901499-02
API Chapter 21.1:2013 compliance for “Flow measurement using Electronics
Metering Systems – Electronic Gas Measurement” and independent verification
for natural gas properties and flow calculations
January 2021 FB1100
For customer service and technical support,
visit www.EmersonProcess.com/Remote/Support.
Global Headquarters,
North America, and Latin America:
Emerson Automation Solutions
Remote Automation Solutions
6005 Rogerdale Road
Houston, TX 77072 U.S.A.
T +1 281 879 2699 | F +1 281 988 4445
www.EmersonProcess.com/Remote
© 2019-2021 Remote Automation Solutions, a business unit of Emerson Automation
Solutions. All rights reserved.
This publication is for informational purposes only. While every effort has been made to ensure
accuracy, this publication shall not be read to include any warranty or guarantee, express or
implied, including as regards the products or services described or their use or applicability.
Remote Automation Solutions (RAS) reserves the right to modify or improve the designs or
specifications of its products at any time without notice. All sales are governed by RAS terms
and conditions which are available upon request. RAS accepts no responsibility for proper
selection, use or maintenance of any product, which remains solely with the purchaser and/or
end-user.
Europe:
Emerson Automation Solutions
Remote Automation Solutions
Unit 8, Waterfront Business Park
Dudley Road, Brierley Hill
Dudley UK DY5 1LX
T +44 1384 487200 | F +44 1384 487258
Middle East/Africa:
Emerson Automation Solutions
Remote Automation Solutions
Emerson FZE
P.O. Box 17033
Jebel Ali Free Zone – South 2
Dubai U.A.E.
T +971 4 8118100 | F +971 4 8865465
Asia-Pacific:
Emerson Automation Solutions
Remote Automation Solutions
1 Pandan Crescent
Singapore 128461
T +65 6777 8211| F +65 6777 0947
Remote Automation Solutions
Loading...
