CWPAC Product Data Sheet
D301303X012 October 2012
ControlWave® PAC
Process Automation Controller
The ControlWave® PAC is a highly adaptable Process
Automation Controller with exceptional networking
capability. Designed with an emphasis on scalability and
modularity, the ControlWave PAC can be configured to
maximize the performance of a wide range of control
systems. Emerson has developed this innovative controller
to provide cost-effective solutions by minimizing the time
required for installation and configuration.
The ControlWave PAC combines the elements of a PLC and
an RTU without compromising the unique features and
capabilities of each device. The ControlWave PAC provides a
modular architecture, expandable I/O capacity, and
Ethernet networking capability that introduces the
possibilities of open architecture for emerging
communication standards and provides a simple solution for
existing networks.
Features
Powerful, high-performance processor
Up to three 10/100 MB Ethernet ports
Up to four serial communication ports
4- and 8-slot I/O base unit
Hot-swappable I/O
Security key-lock
Analog outputs maintain last/preset value on CPU
watchdog
Discrete outputs maintain last or zero value on CPU
watchdog
Wide temperature range (-40 to +70°C)
Class I, Div. 2 hazardous location and CE approval
Open industry standards for programming,
configuration, and communication
memory. The CPU module is available with the following onboard communication port configurations:
One Ethernet port and two RS-232 ports
One Ethernet port, three RS-232 ports, and one RS-485
port
Three Ethernet ports, three RS-232 ports, and one
RS-485 port
Three Ethernet ports, two RS-232 ports, and two
RS-485 ports
Power Modules
The power module is installed in the first slot of the
ControlWave PAC base unit and provides power to the rest
of the device. Two power modules are available including:
24 volt input power supply sequencer module
24 volt redundant power supply sequencer module
Open Network Connectivity
By embracing the open systems network technologies
available through TCP/IP, Ethernet, OPC, and Microsoft DNA
(as well as pseudo standards such as Modbus and Open
Modbus) the ControlWave PAC provides a total process
automation management solution for in-plant LAN-based
and wide area network SCADA systems. Access to real-time
data and operating conditions, historical data, maintenance,
and performance data stored in the ControlWave PAC is
available to the global network.
Base Unit
The ControlWave PAC base unit is constructed of an
aluminum housing that contains the CPU, power supply,
and is available with a 4 or 8 I/O slots. These slots are used to
add optional I/O modules.
CPU Options
The ControlWave PAC has a 100 MHz CPU module that
contains 2 MB of SRAM, 64 MB of SDRAM, and 32 MB of flash
Remote Automation Solutions
ControlWave PAC
CWPAC October 2012
Communications
The ControlWave PAC supports up to seven communication
ports. The base CPU module has two RS-232 serial ports and
one Ethernet port. Two additional RS-232 or RS-485 serial
ports and two additional Ethernet ports are optional.
Communication Protocols
ControlWave PAC supports BSAP (Bristol Standard
Asynchronous Protocol), Modbus, DF1, CIP, DNP3, and serial
ASCII communication protocols as standard features.
ControlWave PAC also supports the following Modbus
protocols:
Modbus serial and TCP/IP Open Modbus (Ethernet)
Master and Slave
Modbus RTU and ASCII
Function Codes 1–7, 8, 15, and 16
Integer and IEEE 4-byte floating point
Inputs and Outputs
Input and output (I/O) modules are designed to maximize
usability while minimizing installation, maintenance, and
system down-time costs. A pull-down door provides front
panel wiring terminal access for technicians. The bezel and
the terminations can be easily removed from the I/O
module to make wiring even easier. In addition, a wide
range of applications is supported by the availability of both
local terminations and remote DIN-rail terminations.
To minimize field wiring and eliminate the need for
marshalling strips, the analog input (AI) and discrete input
(DI) modules are capable of supplying loop power to twowire transmitters and dry contacts.
Status indicators offer instant visual notification of I/O
conditions. Each I/O module has a two-color Pass/Fail LED
that displays the online diagnostic status. Discrete I/O
modules provide status LEDs for each point on the module.
AI modules provide two LEDs on each input point to indicate
input under/over range conditions.
The ControlWave PAC supports a wide variety of I/O
modules. Available I/O modules include:
Analog Input (AI) module with 8 or 16 points
Analog Output (AO) module with 8 points
Discrete Input (DI) module with 16 or 32 points
Discrete Output (DO) module with 16 or 32 points
Resistance Temperature Detector (RTD) module with 4
points
Thermocouple (TC) module with 6 points
UDI Counter module with 6 points
Note: Modules are hot-swappable. All I/O is frozen for 300
milliseconds when any module is replaced.
Remote Termination Modules
The remote termination option for the ControlWave PAC
modules provides a convenient alternative to the standard
direct connect termination. All remote termination modules
are standard DIN-rail mountable, and connect to the I/O
module with pre-wired connector cables. To simplify
installation, all I/O modules use the same cable.
I/O Expansion Rack
The I/O Expansion Rack allows for the addition of I/O
modules to multiple local and remote mounted racks. The
I/O Expansion Rack consists of a 4- or 8-slot ControlWave
chassis. This chassis contains an Ethernet communication
engine dedicated to communications between the main
processor and the I/O Expansion Rack. The communication
engine also supports battery backed RAM to retain output
values during short power outages.
The I/O Expansion Rack is connected to the main
ControlWave via an Ethernet physical link using TCP/IP. The
process control application program resides in the main
ControlWave. The main ControlWave controls both local I/O
as well as the I/O located in the I/O Expansion Rack.
ControlWave Redundant Systems
Redundant systems are ideal for use in critical processes and
harsh applications that require maximum operational
readiness and system availability. The ControlWave PAC
redundant systems are designed to prevent a single point of
failure from shutting down the entire system. Two types of
redundant systems are available for the ControlWave PAC:
the redundant process control and communications system,
and the redundant input/output (I/O) system. For more
information on the ControlWave PAC redundant systems,
refer to Product Data Sheet CWPAC:RDN.
Key Switch
The ControlWave PAC is available with a three-position front
panel key switch. The front panel key switch provides a high
level of manual security by controlling three modes of
operation.
In Run Mode, the ControlWave PAC rejects any attempt to
download or modify the running program, either locally or
over the network.
In Remote Mode, the ControlWave PAC allows downloading
and online program modification through the network
provided the security access requirements have been met.
Local download and online modification of the running
program is prohibited.
In Local Mode, the ControlWave PAC allows download and
online modification through either the network connection
or through a local serial communication port provided the
security access requirements have been met.
2 www.EmersonProcess.com/Remote
October 2012
Multi-User Security Access
The ControlWave PAC employs a user name/password
access system protected by a 56-bit encryption technique
through the TCP connection. There can be up to 240 users
who sign in with their user name and password. Both the
user name and the password can be up to sixteen characters
in length.
You can customize the security level for each user based on
64 access rights including the ability to read and write data
values and files via FTP, access and configure historical and
audit data information, edit configuration, run internal
diagnostics, and read and reset system status.
Data Reliability
The ControlWave PAC is designed to provide the optimum
level of data reliability using a distributed database
architecture. All data, including time stamped alarms, alarm
limits, and historical data is stored locally in non-volatile
flash memory in each ControlWave PAC.
When historical data is collected from the ControlWave
PAC, it is converted and appended to a .CSV and ODBC
compliant database. The original historical data is not
changed and is stored in the device flash memory.
Historical Data Collection
The ControlWave Historical Data Collection system provides
time-stamped historical data storage in ControlWave flash
memory. The historical data is collected through OpenBSI
software on a scheduled or on-demand basis. After the data
is collected, it is converted to CSV and ODBC compliant file
formats for use in spreadsheets and reports. If any data is
missed due to a communication failure, it is collected and
the PC historical database is backfilled when the
communication is reestablished. This distributed historical
database architecture provides data reliability and integrity
during communication or PC failure.
Another important historical feature is the audit system. The
audit logs are files stored in ControlWave flash memory that
contain significant events and time-stamped alarms. In
addition to the real-time alarm reporting system, the alarms
stored in the audit alarm log provide a reportable historical
alarm archive.
These files are collected through OpenBSI software and
presented as text files in the PC. This functionality is
extremely useful in providing an event trail during
communication interruption, PC downtime, or other system
problem.
OpenBSI
Emerson’s OpenBSI (Open Bristol System Interface) is an
optional set of network setup, communication, diagnostic,
and data viewing software utilities for use with ControlWave
RTUs, flow computers, and controllers. At the core of
OpenBSI is the communication interface. The interface is
CWPAC
written as a Windows communication server API through
which other client applications communicate. OpenBSI
supports both serial BSAP protocol and Ethernet IP
communication to ControlWave devices.
ControlWave Designer
ControlWave Designer is an optional, fully IEC 61131-3
compliant programming environment for the ControlWave
PAC. ControlWave Designer includes all five IEC 61131-3
process languages for batch, continuous, and discrete
control. These languages are: Function Block Diagram,
Structured Text, Sequential Function Chart, Ladder Logic
Diagram, and Instruction List.
ControlWave Designer includes an extensive library of more
than 200 basic IEC 61131-3 functions and function blocks
common to many IEC 61131-3 based products. These
include:
Flip-flops, counters, and timers
Ladder diagram functions – coils and contacts, etc.
Numerical, arithmetic, and Boolean functions – Sine,
Cosine, Add, Sub, Square Root, And, Or, etc.
Selection and comparison – Min, Max, Greater Than,
Equal, Less Than, etc.
Type conversions – Integer to Real, Boolean to Word,
etc.
ACCOL III
In addition to the basic functions and function blocks,
ControlWave Designer brings the benefit of over twenty
years of SCADA and plant control experience in Emerson’s
ACCOL III function block library. ACCOL III includes over sixty
function blocks valuable for use in oil and gas, water and
waste, and process measurement and control applications.
ACCOL III is designed to take full advantage of the significant
features offered by ControlWave.
The library consists of many function blocks including:
Average, Compare, Totalize
Scheduling and Sequencing
PID and Lead/Lag
AGA Gas Flow and Liquids Calculations
File Handling
ObjectServer
ObjectServer is an optional OPC-compliant server that
provides direct communication to the ControlWave family
of controllers, RTUs, PLCs, and flow computers through the
OpenBSI Communications Interface. ObjectServer supports
serial multi-drop, remote telemetry, and Ethernet
communication networks. Unlike traditional OPC servers,
ObjectServer provides reliable access to RTUs that are
connected via low-bandwidth, high-latency, and poorquality networks such as radio, satellite, and cellular
modems.
www.EmersonProcess.com/Remote 3
CWPAC October 2012
ControlWave PAC
CPU Module
Processor Type 586 CPU, 100 MHz
Memory Boot 512 kB
Flash 32 MB on-board
SRAM 2 MB, battery backed
SDRAM 64 MB (66MHz SDRAM coupled to a 32-bit bus)
Clock Accuracy 2 second/day at 25°C
Communications
COM1 Type RS-232
Connector PC/AT 9-pin male D-sub
Baud Up to 115.2 KB
COM2 Type RS-232
Connector PC/AT 9-pin male D-sub
Baud Up to 115.2 KB
COM3 (optional) Type RS 232 or RS 485
Connector RJ45
Baud Up to 115.2 KB
Isolation 500 Vdc (RS-485 only)
COM4 (optional) Type RS-485
Connector PC/AT 9-pin male D-sub
Isolation 500 Vdc
Ethernet Port 1 Type 10/100 Base-T Ethernet port
Connector RJ45
Isolation 500 Vdc
Inputs/Outputs
I/O Modules AI 8 or 16 AI with local or remote automations. For more information, refer to
Product Data Sheet CWPAC:AIO
AO 4 or 8 AO with local or remote automations. For more information, refer to
Product Data Sheet CWPAC:AIO
AO with Read-Back
(for redundant I/O
systems only)
DI 16 or 32 DI with local or remote automations. For more information, refer
DO 16 or 32 DI with local or remote automations. For more information, refer
8 AO with local or remote automations. For more information, refer to
Product Data Sheet CWPAC:AIO
to Product Data Sheet CWPAC:DIO
to Product Data Sheet CWPAC:DIO
4 www.EmersonProcess.com/Remote
October 2012
DO with Read-
Back (for
redundant I/O
systems only)
CWPAC
16 DI with local or remote automations. For more information, refer to
Product Data Sheet CWPAC:DIO
Universal Digital
Input Module and
Counter (UDI)
RTD 4 DI with local or remote automations. For more information, refer to
Thermocouple 6 DI with local or remote automations. For more information, refer to
Remote Terminal Blocks AI and AO Number of
Dimensions 89.7 mm H x 45 mm W x 67.1 mm D (3.53 in. H x
DI and DO Number of
Dimensions 89.7 mm H x 55.9 mm W x 65.5 mm D (3.53 in. H x
Relay 99 mm H x 82.6 mm W x 94 mm D (3.9 in. H x 3.25
UDI Number of
Dimensions 89.7 mm H x 45 mm W x 67.1 mm D (3.53 in. H x
Cable Lengths 0.46 m (18 in.)
6 or 12 DI with local or remote automations. For more information, refer to
Product Data Sheet CWPAC:DIO
Product Data Sheet CWPAC:TEMP
Product Data Sheet CWPAC:TEMP
AI, 4 channels; AO, 2 channels; TC, 8 channels
Channels
1.77 in. W x 2.64 in. D)
8 channels
Channels
2.2 in. W x 2.58 in. D)
in. W x 3.7 in. D)
4 channels
Channels
1.77 in. W x 2.64 in. D)
1.0 m (39 in.)
2.0 m (6.5 ft.)
4.0 m (13 ft.)
Power
Input Voltage 22.1 – 30.0 Vdc
Isolation 500 Vdc
Status Indication Active, Fail, and Power OK
Physical
Dimensions 4 I/O Slot Chassis Panel Mount 300.73 mm W by 177.03 mm H by 125.98 mm D
(11.84 in. W by 6.97 in. H by 4.96 in. D)
8 I/O Slot Chassis Panel Mount or
19-inch Rack
Mount
Weight 4 I/O Slot Chassis 3.18 kg (7 lbs.)
8 I/O Slot Chassis 5.9 kg (13 lbs)
Wiring Up to 14 American Wire Gauge (AWG)
481.58 mm W by 177.03 mm H by 125.98 mm D
(18.96 in. W by 6.97 in. H by 4.96 in. D)
www.EmersonProcess.com/Remote 5
CWPAC October 2012
Environmental
Operating Temperature –40°C to 70°C (–40°F to 158°F)
Storage Temperature –40°C to 85°C (–40°F to 185°F)
Operating Humidity 15 to 95% (non-condensing)
Conformal Coating All circuit boards are conformal coated to meet IPC-A-610 Class 3
Vibration 1.0 g acceleration over 10 to 150 Hz; 0.5 g acceleration over 150 to 2000 Hz
Immunity 3 V/m – 80 MHz to 1000Mhz (EN50082-2)
Electro-Static Discharge IEC-1000-4-2-EVT
Radiated Emissions EN-55011-EVT
Surge Suppression IEEE 472 - 1974
Approvals
Product Markings for
Hazardous Locations
Certification Standard UL Standards UL 1604-1994
EMC Standards EN 55011 (Emissions)
UL CUL Class I, Division 2, Groups A, B, C, and D T4A
CE
0081
UL 508-2008
CSA C22.2 No. 213-M1987
CSA C22.2 No. 142-M1987
EN 61000-4-2 (Electrostatic Discharge Immunity)
EN 61000-4-3 (Electromagnetic Field Immunity)
EN 61000-4-4 (Electrical Fast Transients Immunity)
EN 61000-4-5 (Surge Immunity)
EN 61000-4-6 (Conducted Immunity)
6 www.EmersonProcess.com/Remote
Headquarters:
Emerson Process Management
www.EmersonProcess.com/Remote
Europe:
Emerson Process Management
www.EmersonProcess.com/Remote
North American/Latin America:
Emerson Process Management
www.EmersonProcess.com/Remote
Middle East/Africa:
Emerson Process Management
www.EmersonProcess.com/Remote
Asia-Pacific:
Emerson Process Management
www.EmersonProcess.com/Remote
October 2012
Remote Automation Solutions
6005 Rogerdale Road
Houston, TX 77072 U.S.A.
T +1 281 879 2699 | F +1 281 988 4445
CWPAC
Remote Automation Solutions
Emerson House
Kirkhill Drive Kirkhill Industrial Estate
Aberdeen UK AB21 OEU
T +44 1224 215700 | F +44 1224 215799
Remote Automation Solutions
6005 Rogerdale Road
Houston TX USA 77072
T +1 281 879 2699 | F +1 281 988 4445
Remote Automation Solutions
Emerson FZE
P.O. Box 17033
Jebel Ali Free Zone – South 2
Dubai U.A.E.
T +971 4 8118100 | F +971 4 8865465
Remote Automation Solutions
1 Pandan Crescent
Singapore 128461
T +65 6777 8211| F +65 6777 0947
© 2007-2012 Remote Automation Solutions, a business unit of Emerson Process
Management. All rights reserved.
Bristol, Inc., Bristol Canada, BBI SA de CV and Emerson Process Management Ltd, Remote
Automation Solutions division (UK), are wholly owned subsidiaries of Emerson Electric Co.
doing business as Remote Automation Solutions, a business unit of Emerson Process
Management. FloBoss, ROCLINK, Bristol, Bristol Babcock, ControlWave, TeleFlow, Helicoid,
OpenEnterprise, and METCO are trademarks of Remote Automation Solutions. AMS,
PlantWeb and the PlantWeb logo are marks of Emerson Electric Co. The Emerson logo is a
trademark and service mark of the Emerson Electric Co. All other marks are property of their
respective owners.
The contents of this publication are presented for informational purposes only. While every
effort has been made to ensure informational accuracy, they are not to be construed as
warranties or guarantees, express or implied, regarding the products or services described
herein or their use or applicability. Remote Automation Solutions reserves the right to modify
or improve the designs or specifications of such products at any time without notice. All sales
are governed by Remote Automation Solutions’ terms and conditions which are available
upon request. Remote Automation Solutions does not assume responsibility for the
selection, use or maintenance of any product. Responsibility for proper selection, use and
maintenance of any Remote Automation Solutions product remains solely with the purchaser
and end-user.
Remote Automation Solutions
Loading...
