Product Data Document
420DS-6d / D301311X012
June 2011 - Page 1
ControlWave® Express
SCADA RTU
ControlWave® Express SCADA RTU, from Emerson Process Management, provides exceptional performance and unique functionality for applications requiring low installation cost, very low power consumption, and space efficiency.
As an integrated RTU in a SCADA system, ControlWave Express has the unique attributes required for wide area networks, without sacrificing process control performance.
•Multiple serial communication ports for network, local and multi-vendor connectivity
•Built-in BSAP, Modbus & DNP protocols for broad network compatibility
•Report-By-Exception for communication efficiency
•Modbus Store and Forward capability for geographic flexibility with radio networks
•Ultra low power modes for solar applications and reduced solar panel and battery costs
•Wide operating temperature range for remote outdoor locations
Application Suitability
Based on years of experience in water, gas and SCADA related industries, ControlWave Express has the technology, functional benefits and open architecture to excel in many applications.
Water distribution: Pump, tank, well and reservoir control
Wastewater: Lift station and storm water monitoring and control
Natural Gas: Gas well, storage and plunger lift control
Features
•ARM processor provides exceptional performance and low power consumption
•IEC 61131-3 programming with ACCOL III process control function block library
•Optional 100/10 MB Ethernet port
•Three serial communication ports
•Flexible fixed I/O configurations
•4 Digital inputs
•2 Digital outputs
•2 selectable Digital inputs/outputs
•2 selectable Digital inputs/counters
•2 selectable Digital/Pulse inputs on CPU
•3 optional Analog inputs
•1 optional Analog output
•Wide temperature range (-40 to +70ºC)
•Class I, Div. 2 hazardous location and CE approval
•Open standards for programming, network configuration and communication
Remote Automation Solutions
Website: www.EmersonProcess.com/Remote
Product Data Document
420DS-6d / D301311X012
June 2011 - Page 2 ControlWave® Express
Scalability
ControlWave Express can also be combined seamlessly with other members in the ControlWave family of products. For remote applications requiring more I/O flexibility, ControlWave Micro provides a modular RTU/PLC expandable up to 14 I/O modules.
For natural gas well site and measurement station automation, ControlWave single and multi-run flow computers share a common architecture with the ControlWave family of products and all meet API
21.1 requirements for multiple meter runs.
For in-plant control applications, ControlWave and
ControlWave Micro are powerful, flexible PLCs.
ControlWave offers the greatest local and remote I/O expansion to hundreds of I/O points, up to three Ethernet ports for network segmentation, plus CPU, communication and I/O redundancy capability.
IEC 61131-3 process languages for batch, continuous and discrete control: Function Block Diagram, Structured Text, Sequential Function Chart, Ladder
Logic Diagram and Instruction List.
ControlWave Designer includes an extensive library of more than 200 basic IEC 61131-3 functions and function blocks common to many IEC 61131-3 based products. These include:
•Flip-flops, Counters & Timers
•Ladder diagram functions – coils and contacts, etc.
•Numerical, Arithmetic & Boolean functions
– Sine, Cosine, Add, Sub, Square Root, And,
Or, etc.
•Selection & Comparison – Min, Max, Greater than, Equal, Less than, etc.
• Type conversions – Integer to Real, Boolean to
The combined benefits of the ControlWave family Word, etc. of products integrates your wide area network with
your local area network.
Open Standards For Programming, Network Configuration and Communication
Only ControlWave brings the perfect combination of industry standards to minimize learning, engineering and implementation costs.
By adhering to such industry standards as Ethernet, TCP/IP, Microsoft Windows®, COM/DCOM, FTP, OLE and ActiveX, ControlWave is able to achieve the highest degree of openness in control system architecture and bring the optimal process efficiency and productivity needed to ensure a successful system implementation.
ControlWave Designer with ACCOL III
To minimize your engineering and development time, we have adopted the international standard for PLC programming, IEC 61131-3. ControlWave
Designer is a fully IEC 61131-3 compliant programming environment for the ControlWave family of products. ControlWave Designer includes all five
ACCOL III
In addition to the basic functions and function blocks, ControlWave Designer brings the benefit of over twenty years of SCADA and plant control experience in Emerson’s Bristol ACCOL III function block library. ACCOL III includes over sixty function blocks valuable for use in oil & gas, water & waste and process measurement & control applications. Further,
ACCOL III is designed to take full advantage of the significant features offered by ControlWave.
Briefly, this library includes function blocks for:
•Average, Compare, Totalize
•Scheduling & Sequencing
•PID & Lead/Lag
•AGA gas flow and liquids calculations
•File handling
In addition, ControlWave ensures data integrity, in the event of a communication interruption, by storing critical time-stamped alarm and historical data in the controller memory. This data is then securely retrieved when communication is restored.
Remote Automation Solutions
Website: www.EmersonProcess.com/Remote
Product Data Document
420DS-6d / D301311X012
June 2011 - Page 3 ControlWave® Express
Specifications
CPU
•32-bit ARM processor: 14 & 33 MHz CPUs
•Sleep mode for low power applications
•Real time clock/memory battery backup: 9000 hours
•Program execution and Data Memory : 2 MB battery backed SRAM memory
•Data and file storage memory: 8 MB Flash for
Program source, historical Archive and Audit storage
•Optional solar power regulator
•LED status indicators – 6 failure status LEDs, Watchdog and CPU Idle and communication LEDs
Communication
•Two RS-232 and one selectable RS-232/RS-
485 serial communication port supporting baud rates up to 115.2 KB
•One optional 100/10 Base-T Ethernet port with
RJ45 connector
•One RJ45 connector for interface to
ControlWave LCD display/keypads
Power Input
•5.4 to 16 Vdc power input with 14 MHz CPU
-Surge suppression 16 V transorb
•11.4 to 28.0 Vdc power input with 33 MHz CPU
-Surge suppression 30 V transorb
•Power-fail detection and recovery sequencer
•Battery voltage monitor
•Reverse voltage protection
Housing
•Mounting base plate: 10.75” H x 5.5” H x 2.0”D (27.3 cm x 14.0 cm x 5.0 cm)
•Mounting: Flat or edge panel mounting, or optional DIN mount
Environmental Specifications
•Operating Temperature range:
-40 to 70oC (-40 to 158oF), storage up to 85oC
•Relative Humidity:
15-95% non-condensing
•Vibration:
1.0g for 10-150 Hz - 0.5g for 150Hz to 2000Hz
•Hazardous Area Approvals:
non-incendive for operation in Class I, Division 2
CPU RFI
•Immunity: ENV 50140 Radio-frequency
•electromagnetic field amplitude modulated EMC
•Emissions: EN 55022:1998 Class A ITE emissions requirements (EU)
•ICES-003 Issue 3 Class A Digital Apparatus emissions requirements (Canada)
•AS/NZS3548:1995/CISPR Class A ITE emissions requirements (Australia)
I/O RFI Susceptibility
•3V/m – 80 MHz to 1000Mhz (IEC 1000-4-3)
Power consumption
14 MHz CPU: 0.036 watt
33 MHz CPU w/o Ethernet: 0.12 watt
33 MHz CPU with Ethernet: 1.0 watt DIO card: 0.018 watt
DIO plus AIO card: 0.021 watt
Remote Automation Solutions
Website: www.EmersonProcess.com/Remote
Product Data Document
420DS-6d / D301311X012
June 2011 - Page 4 ControlWave® Express
ControlWave Express Process I/O
ControlWave Express I/O module is designed to maximize usability while minimizing installation and maintenance.
The I/O module (bottom card) provides a mix of analog and digital inputs and outputs that are a perfect fit for small RTU applications.
•2 DI/PI (on CPU)
•1 RTD input on 14 MHz CPU
•4 DI
•2 DO
•2 selectable DI or DO
•2 selectable DI or HSC
•Optional 3 AI or 3 AI and 1 AO
Features
•Convenient pluggable local terminations
•All configuration jumpers and switches accessible without disassembly of circuit boards
•Termination points for external loop power supply
Specifications
All I/O
•I/O access: 50 ms with 33 MHz CPU, 250 ms with 14 MHz CPU
•1 second for 2 DI/PI inputs on CPU board
•Surge protection: Meets C37.90-1978
•30 Vdc transorb between signal and ground
•Terminations are pluggable and accept a maximum wire size of 16 gauge
•Power consumption is stated for each I/O module type measured at the input supply and does not include loop power
Pulse/Digital Inputs
•Inputs located on base CPU board
•Number of points: up to 2 non-interrupting inputs
•Internally sourced, dry contact single ended inputs
•Scan rate: Once per second
•Input filter: 20 microSec
•Voltage Range: Internally sourced dry contact input - 3.3 Vdc
•On state: >1.6 V, Off state <1.3V
•Input current : 200 µA for low power applications
•Power consumption:
200 µA input, all inputs ON: 0.002 watt
Used as Pulse Input:
•Frequency Range: 0-10 kHz
•Debounce: None
•Accumulator: 16 bit
RTD Input
•Input available on 14 MHz Ultra Low Power
CPU only
Specifications are for the interface only, not including the RTD probe or wiring
•RTD Conversion Accuracy: ± 0.1°C, or ± 0.1% of reading, whichever is greater
Remote Automation Solutions
