Emerson 1700 User Manual

Configuration and Use Manual
MMI-20021712, Rev AB
April 2013
Micro Motion® Model 1700 Transmitters with Analog Outputs
Includes the Chinese-Language Display Option
Safety messages are provided throughout this manual to protect personnel and equipment. Read each safety message carefully before proceeding to the next step.

Micro Motion customer service

Email
• Worldwide: flow.support@emerson.com
• Asia-Pacific: APflow.support@emerson.com
North and South America Europe and Middle East Asia Pacific
United States 800-522-6277 U.K. 0870 240 1978 Australia 800 158 727
Canada +1 303-527-5200 The Netherlands +31 (0) 318 495 555 New Zealand 099 128 804
Mexico +41 (0) 41 7686 111 France 0800 917 901 India 800 440 1468
Argentina +54 11 4837 7000 Germany 0800 182 5347 Pakistan 888 550 2682
Brazil +55 15 3238 3677 Italy 8008 77334 China +86 21 2892 9000
Venezuela +58 26 1731 3446 Central & Eastern +41 (0) 41 7686 111 Japan +81 3 5769 6803
Russia/CIS +7 495 981 9811 South
Egypt 0800 000 0015 Singapore +65 6 777 8211
Oman 800 70101 Thailand 001 800 441 6426
Qatar 431 0044 Malaysia 800 814 008
Kuwait 663 299 01
South Africa 800 991 390
Saudia Arabia 800 844 9564
UAE 800 0444 0684
Korea
+82 2 3438 4600

Contents

Contents
Part I Getting Started
Chapter 1 Before you begin ............................................................................................................2
1.1 About this manual ....................................................................................................................... 2
1.2 Transmitter model code .............................................................................................................. 2
1.3 Communications tools and protocols .......................................................................................... 2
1.4 Additional documentation and resources .................................................................................... 3
Chapter 2 Quick start .....................................................................................................................5
2.1 Power up the transmitter .............................................................................................................5
2.2 Check flowmeter status ...............................................................................................................5
2.3 Make a startup connection to the transmitter ..............................................................................7
2.4 Characterize the flowmeter (if required) ......................................................................................8
2.5 Verify mass flow measurement ................................................................................................. 11
2.6 Verify the zero ........................................................................................................................... 12
Part II Configuration and commissioning
Chapter 3 Introduction to configuration and commissioning ....................................................... 17
3.1 Configuration flowchart ............................................................................................................ 17
3.2 Default values and ranges ..........................................................................................................19
3.3 Enable access to the off-line menu of the display ....................................................................... 19
3.4 Disable write-protection on the transmitter configuration ........................................................ 19
3.5 Restore the factory configuration .............................................................................................. 20
Chapter 4 Configure process measurement ..................................................................................21
4.1 Configure mass flow measurement ........................................................................................... 21
4.2 Configure volume flow measurement for liquid applications ..................................................... 27
4.3 Configure gas standard volume (GSV) flow measurement ......................................................... 32
4.4 Configure Flow Direction .............................................................................................................. 38
4.5 Configure density measurement ............................................................................................... 44
4.6 Configure temperature measurement .......................................................................................49
4.7 Configure pressure compensation .............................................................................................52
Chapter 5 Configure device options and preferences ....................................................................58
5.1 Configure the transmitter display .............................................................................................. 58
5.2 Enable or disable operator actions from the display ................................................................... 64
5.3 Configure security for the display menus .................................................................................. 66
5.4 Configure response time parameters ........................................................................................ 68
5.5 Configure alarm handling .......................................................................................................... 71
5.6 Configure informational parameters ......................................................................................... 76
Chapter 6 Integrate the meter with the control system ................................................................80
6.1 Configure the transmitter channels ........................................................................................... 80
6.2 Configure the mA output .......................................................................................................... 81
6.3 Configure the frequency output ................................................................................................ 88
Configuration and Use Manual i
Contents
6.4 Configure the discrete output ................................................................................................... 93
6.5 Configure events ....................................................................................................................... 99
6.6 Configure digital communications .......................................................................................... 102
Chapter 7 Completing the configuration .................................................................................... 112
7.1 Test or tune the system using sensor simulation ......................................................................112
7.2 Back up transmitter configuration ........................................................................................... 114
7.3 Enable write-protection on the transmitter configuration ....................................................... 115
Part III Operations, maintenance, and troubleshooting
Chapter 8 Transmitter operation ................................................................................................117
8.1 Record the process variables ................................................................................................... 117
8.2 View process variables .............................................................................................................118
8.3 View transmitter status using the status LED ........................................................................... 120
8.4 View and acknowledge status alarms ...................................................................................... 121
8.5 Read totalizer and inventory values ......................................................................................... 128
8.6 Start and stop totalizers and inventories ..................................................................................129
8.7 Reset totalizers ........................................................................................................................130
8.8 Reset inventories ..................................................................................................................... 132
Chapter 9 Measurement support ............................................................................................... 133
9.1 Options for measurement support .......................................................................................... 133
9.2 Use Smart Meter Verification ...................................................................................................133
9.3 Zero the flowmeter ................................................................................................................. 152
9.4 Validate the meter ...................................................................................................................159
9.5 Perform a (standard) D1 and D2 density calibration .................................................................161
9.6 Perform a D3 and D4 density calibration (T-Series sensors only) .............................................. 166
9.7 Perform temperature calibration ............................................................................................. 170
Chapter 10 Troubleshooting ........................................................................................................ 173
10.1 Status LED states ..................................................................................................................... 174
10.2 Status alarms ...........................................................................................................................174
10.3 Flow measurement problems .................................................................................................. 186
10.4 Density measurement problems ............................................................................................. 188
10.5 Temperature measurement problems .....................................................................................189
10.6 Milliamp output problems ....................................................................................................... 190
10.7 Frequency output problems .................................................................................................... 191
10.8 Use sensor simulation for troubleshooting .............................................................................. 192
10.9 Check power supply wiring ...................................................................................................... 192
10.10 Check sensor-to-transmitter wiring ......................................................................................... 193
10.11 Check grounding ..................................................................................................................... 193
10.12 Perform loop tests ................................................................................................................... 194
10.13 Trim mA outputs ..................................................................................................................... 201
10.14 Check the HART communication loop ..................................................................................... 203
10.15 Check HART Address and Loop Current Mode ................................................................................ 204
10.16 Check HART burst mode ..........................................................................................................204
10.17 Check Lower Range Value and Upper Range Value ......................................................................... 204
10.18 Check mA Output Fault Action ...................................................................................................... 204
10.19 Check for radio frequency interference (RFI) ............................................................................205
10.20 Check Frequency Output Maximum Pulse Width ...............................................................................205
10.21 Check Frequency Output Scaling Method ........................................................................................ 205
ii Micro Motion® Model 1700 Transmitters with Analog Outputs
Contents
10.22 Check Frequency Output Fault Action .............................................................................................206
10.23 Check Flow Direction .................................................................................................................. 206
10.24 Check the cutoffs .................................................................................................................... 206
10.25 Check for slug flow (two-phase flow) ....................................................................................... 207
10.26 Check the drive gain ................................................................................................................ 207
10.27 Check the pickoff voltage ........................................................................................................ 208
10.28 Check for electrical shorts ....................................................................................................... 209
10.29 Check the core processor LED ..................................................................................................212
10.30 Perform a core processor resistance test ................................................................................. 215
Appendices and reference
Appendix A Using the standard transmitter display ...................................................................... 218
A.1 Components of the transmitter interface ................................................................................ 218
A.2 Use the optical switches .......................................................................................................... 219
A.3 Access and use the display menu system .................................................................................220
A.4 Display codes for process variables ..........................................................................................224
A.5 Codes and abbreviations used in display menus ...................................................................... 225
A.6 Menu maps for the transmitter display .................................................................................... 229
Appendix B Using the Chinese-language display ........................................................................... 240
B.1 Components of the transmitter interface ................................................................................ 240
B.2 Use the optical switches .......................................................................................................... 241
B.3 Access and use the display menu system ................................................................................. 242
B.4 Menu maps for the transmitter display .................................................................................... 247
Appendix C Using ProLink II with the transmitter ..........................................................................259
C.1 Basic information about ProLink II ........................................................................................... 259
C.2 Connect with ProLink II ............................................................................................................260
C.3 Menu maps for ProLink II ......................................................................................................... 273
Appendix D Using ProLink III with the transmitter .........................................................................281
D.1 Basic information about ProLink III ...........................................................................................281
D.2 Connect with ProLink III ........................................................................................................... 282
D.3 Menu maps for ProLink III ........................................................................................................ 295
Appendix E Using the Field Communicator with the transmitter ................................................... 302
E.1 Basic information about the Field Communicator ....................................................................302
E.2 Connect with the Field Communicator .................................................................................... 303
E.3 Menu maps for the Field Communicator ..................................................................................306
Appendix F Default values and ranges .......................................................................................... 320
F.1 Default values and ranges ........................................................................................................320
Appendix G Transmitter components and installation wiring ........................................................325
G.1 Installation types ..................................................................................................................... 325
G.2 Power supply terminals and ground ........................................................................................ 329
G.3 Input/output (I/O) wiring terminals ......................................................................................... 330
Appendix H NE 53 history ..............................................................................................................331
H.1 NE 53 history ........................................................................................................................... 331
Index ................................................................................................................................................336
Configuration and Use Manual iii
Contents
iv Micro Motion® Model 1700 Transmitters with Analog Outputs
Part I

Getting Started

Chapters covered in this part:
• Before you begin
• Quick start
Getting Started
Configuration and Use Manual 1

Before you begin

1 Before you begin
Topics covered in this chapter:

• About this manual

• Transmitter model code

• Communications tools and protocols

• Additional documentation and resources
1.1 About this manual
This manual provides information to help you configure, commission, use, maintain, and troubleshoot the Micro Motion transmitter.
Important
This manual assumes that the transmitter has been installed correctly and completely, according to the instructions in the transmitter installation manual, and that the installation complies with all applicable safety requirements.
1.2 Transmitter model code
Your transmitter can be identified by the model number on the transmitter tag.
The transmitter has a model number of the following form:
1700(I/R/C/B)**A******
I Integral mount
R 4-wire remote-mount
C 9-wire remote-mount
B Remote core processor with remote transmitter
A Analog outputs option board
1.3 Communications tools and protocols
You can use several different communications tools and protocols to interface with the transmitter. You may use different tools in different locations or for different tasks.
2 Micro Motion® Model 1700 Transmitters with Analog Outputs
Before you begin
Communications tools, protocols, and related informationTable 1-1:
Communica­tions tool Supported protocols Scope In this manual For more information
Display (stand­ard)
Chinese-lan­guage display
ProLink II • HART/RS-485
ProLink III • HART/RS-485
Field Commu­nicator
Not applicable Basic configuration and
commissioning
Not applicable Basic configuration and
commissioning
(1)
• HART/Bell 202
• Modbus/RS-485
• Service port
(1)
• HART/Bell 202
• Modbus/RS-485
• Service port
HART/Bell 202 Complete configuration
Complete configuration and commissioning
Complete configuration and commissioning
and commissioning
Complete user informa­tion. See Appendix A.
Complete user informa­tion. See Appendix B.
Basic user information. See Appendix C.
Basic user information. See Appendix D.
Basic user information. See Appendix E.
Not applicable
Not applicable
User manual
• Installed with soft-
ware
• On Micro Motion
user documentation CD
• On Micro Motion
web site (www.mi-
cromotion.com
User manual
• Installed with soft-
ware
• On Micro Motion
user documentation CD
• On Micro Motion
web site (www.mi-
cromotion.com
User manual on Micro Motion web site (www.micromo-
tion.com
Tip
You may be able to use other communications tools from Emerson Process Management, such as AMS Suite: Intelligent Device Manager, or the Smart Wireless THUM™ Adapter. Use of AMS or the Smart Wireless THUM Adapter is not discussed in this manual. The AMS interface is similar to the ProLink II interface. For more information on the Smart Wireless THUM Adapter, refer to the documentation available at www.micromotion.com.

1.4 Additional documentation and resources

Micro Motion provides additional documentation to support the installation and operation of the transmitter.
(1) Devices with the Chinese-language display do not support HART/RS-485.
Configuration and Use Manual 3
Before you begin
Additional documentation and resourcesTable 1-2:
Topic Document
Sensor Sensor documentation
Transmitter installation
Hazardous area installation See the approval documentation shipped with the transmitter, or
download the appropriate documentation from the Micro Motion web site at www.micromotion.com.
All documentation resources are available on the Micro Motion web site at
www.micromotion.com or on the Micro Motion user documentation CD.
4 Micro Motion® Model 1700 Transmitters with Analog Outputs
2 Quick start
Topics covered in this chapter:

• Power up the transmitter

• Check flowmeter status

• Make a startup connection to the transmitter
• Characterize the flowmeter (if required)
• Verify mass flow measurement
• Verify the zero
2.1 Power up the transmitter
The transmitter must be powered up for all configuration and commissioning tasks, or for process measurement.
1. Ensure that all transmitter and sensor covers and seals are closed.

Quick start

CAUTION!
To prevent ignition of flammable or combustible atmospheres, ensure that all covers and seals are tightly closed. For hazardous area installations, applying power while housing covers are removed or loose can cause an explosion.
2. Turn on the electrical power at the power supply.
The transmitter will automatically perform diagnostic routines. During this period, Alarm 009 is active. The diagnostic routines should complete in approximately 30 seconds. For transmitters with a display, the status LED will turn green and begin to flash when the startup diagnostics are complete. If the status LED exhibits different behavior, an alarm condition is present.
Postrequisites
Although the sensor is ready to receive process fluid shortly after power-up, the electronics can take up to 10 minutes to reach thermal equilibrium. Therefore, if this is the initial startup, or if power is been off long enough to allow components to reach ambient temperature, allow the electronics to warm up for approximately 10 minutes before relying on process measurements. During this warm-up period, you may observe minor measurement instability or inaccuracy.
2.2 Check flowmeter status
Check the flowmeter for any error conditions that require user action or that affect measurement accuracy.
Configuration and Use Manual 5
Quick start
1. Wait approximately 10 seconds for the power-up sequence to complete.
Immediately after power-up, the transmitter runs through diagnostic routines and checks for error conditions. During the power-up sequence, Alarm A009 is active. This alarm should clear automatically when the power-up sequence is complete.
2. Check the status LED on the transmitter.
Transmitter status reported by status LEDTable 2-1:
LED state Description Recommendation
Green No alarms are active. Continue with configuration or process meas-
urement.
(3)
(1)
(2)
No alarms are active. One or more previously active alarms have not been acknowledged.
and have been acknowledged.
One or more low-severity alarms are active and have not been acknowledged.
and have been acknowledged.
One or more high-severity alarms are active and have not been acknowledged.
Continue with configuration or process meas­urement. If you choose, you can acknowledge the alarms.
A low-severity alarm condition does not affect measurement accuracy or output behavior. You can continue with configuration or proc­ess measurement. If you choose, you can iden­tify and resolve the alarm condition.
A low-severity alarm condition does not affect measurement accuracy or output behavior. You can continue with configuration or proc­ess measurement. If you choose, you can iden­tify and resolve the alarm condition. You may also acknowledge the alarm.
A high-severity alarm condition affects meas­urement accuracy and output behavior. Re­solve the alarm condition before continuing.
A high-severity alarm condition affects meas­urement accuracy and output behavior. Re­solve the alarm condition before continuing. You may also acknowledge the alarm.
Flashing green
Yellow One or more low-severity alarms are active,
Flashing yellow
Red One or more high-severity alarms are active,
Flashing red
Postrequisites
For information on viewing the list of active alarms, see Section 8.4.
For information on individual alarms and suggested resolutions, see Section 10.2.
(1) If Status LED Blinking is disabled, the LED will show solid green rather than flashing. (2) If Status LED Blinking is disabled, the LED will show solid yellow rather than flashing. (3) If Status LED Blinking is disabled, the LED will show solid red rather than flashing.
6 Micro Motion® Model 1700 Transmitters with Analog Outputs
Quick start

2.3 Make a startup connection to the transmitter

For all configuration tools except the display, you must have an active connection to the transmitter to configure the transmitter. Follow this procedure to make your first connection to the transmitter.
Identify the connection type to use, and follow the instructions for that connection type in the appropriate appendix. Use the default communications parameters shown in the appendix.
Communications tool Connection type to use Instructions
ProLink II HART/RS-485
ProLink III HART/RS-485
Field Communicator HART Appendix E
Postrequisites
(Optional) Change the communications parameters to site-specific values.
(4)
(4)
Appendix C
Appendix D
To change the communications parameters using ProLink II:
• To change the protocol, baud rate, parity, or stop bits, choose ProLink > Configuration >
RS-485.
• To change the address, choose ProLink > Configuration > Device.
To change the communications parameters using ProLink III, choose Device Tools > Configuration > Communications.
To change the communications parameters using the Field Communicator, choose On-Line Menu > Configure > Manual Setup > Inputs/Outputs > Communications.
Important
If you are changing communications parameters for the connection type that you are using, you will lose the connection when you write the parameters to the transmitter. Reconnect using the new parameters.
(4) Devices with the Chinese-language display do not support HART/RS-485. The default connection to use for these devices is Modbus/RS-485.
Configuration and Use Manual 7
Quick start

2.4 Characterize the flowmeter (if required)

Display (standard) Not available
Chinese-language display
ProLink II • ProLink > Configuration > Device > Sensor Type
ProLink III Device Tools > Calibration Data
Field Communicator Configure > Manual Setup > Characterize
Overview
Characterizing the flowmeter adjusts your transmitter to match the unique traits of the sensor it is paired with. The characterization parameters (also called calibration parameters) describe the sensor’s sensitivity to flow, density, and temperature. Depending on your sensor type, different parameters are required. Values for your sensor are provided by Micro Motion on the sensor tag or the calibration certificate.
Offline Maintain > Configuration > Calibrate Sensor
• ProLink > Configuration > Flow
• ProLink > Configuration > Density
• ProLink > Configuration > T Series
Tip
If your flowmeter was ordered as a unit, it has already been characterized at the factory. However, you should still verify the characterization parameters.
Procedure
1. Specify Sensor Type.
• Straight-tube (T-Series)
(5)
• Curved-tube (all sensors except T-Series)
2. Set the flow characterization parameters. Be sure to include all decimal points.
• For straight-tube sensors, set FCF (Flow Cal or Flow Calibration Factor), FTG, and
(5)
FFQ.
• For curved-tube sensors, set Flow Cal (Flow Calibration Factor).
3. Set the density characterization parameters.
• For straight-tube sensors, set D1, D2, DT, DTG, K1, K2, FD, DFQ1, and DFQ2.
(5)
• For curved-tube sensors, set D1, D2, TC, K1, K2, and FD. (TC is sometimes shown
as DT.)
(5) Devices with the Chinese-language display do not support T-Series sensors.
8 Micro Motion® Model 1700 Transmitters with Analog Outputs
2.4.1 Sample sensor tags
Tag on older curved-tube sensors (all sensors except T-Series)Figure 2-1:
Quick start
Tag on newer curved-tube sensors (all sensors except T-Series)Figure 2-2:
Configuration and Use Manual 9
Quick start
Tag on older straight-tube sensor (T-Series)Figure 2-3:
Tag on newer straight-tube sensor (T-Series)Figure 2-4:
2.4.2 Flow calibration parameters (FCF, FT)
Two separate values are used to describe flow calibration: a 6-character FCF value and a 4­character FT value. They are provided on the sensor tag.
Both values contain decimal points. During characterization, these may be entered as two values or as a single 10-character string. The 10-character string is called either Flowcal or FCF.
If your sensor tag shows the FCF and the FT values separately and you need to enter a single value, concatenate the two values to form the single parameter value.
If your sensor tag shows a concatenated Flowcal or FCF value and you need to enter the FCF and the FT values separately, split the concatenated value:
• FCF = The first 6 characters, including the decimal point
• FT = The last 4 characters, including the decimal point
10 Micro Motion® Model 1700 Transmitters with Analog Outputs
Quick start
Example: Concatenating FCF and FT
FCF = x.xxxx FT = y.yy Flow calibration parameter: x.xxxxy.yy
Example: Splitting the concatenated Flowcal or FCF value
Flow calibration parameter: x.xxxxy.yy FCF = x.xxxx FT = y.yy
2.4.3 Density calibration parameters (D1, D2, K1, K2, FD, DT, TC)
Density calibration parameters are typically on the sensor tag and the calibration certificate.
If your sensor tag does not show a D1 or D2 value:
• For D1, enter the Dens A or D1 value from the calibration certificate. This value is the
line-condition density of the low-density calibration fluid. Micro Motion uses air. If you cannot find a Dens A or D1 value, enter 0.001 g/cm3.
• For D2, enter the Dens B or D2 value from the calibration certificate. This value is the
line-condition density of the high-density calibration fluid. Micro Motion uses water. If you cannot find a Dens B or D2 value, enter 0.998 g/cm3.
If your sensor tag does not show a K1 or K2 value:
• For K1, enter the first 5 digits of the density calibration factor. In the sample tag, this
value is shown as 12500.
• For K2, enter the second 5 digits of the density calibration factor. In the sample tag,
this value is shown as 14286.
If your sensor does not show an FD value, contact Micro Motion customer service.
If your sensor tag does not show a DT or TC value, enter the last 3 digits of the density calibration factor. In the sample tag, this value is shown as 4.44.

2.5 Verify mass flow measurement

Check to see that the mass flow rate reported by the transmitter is accurate. You can use any available method.
• Read the value for Mass Flow Rate on the transmitter display.
• Connect to the transmitter with ProLink II and read the value for Mass Flow Rate in the
Process Variables window (ProLink > Process Variables).
• Connect to the transmitter with ProLink III and read the value for Mass Flow Rate in
the Process Variables panel.
Configuration and Use Manual 11
Quick start
• Connect to the transmitter with the Field Communicator and read the value for Mass
Flow Rate in the Process Variables menu (On-Line Menu > Overview > Primary Purpose Variables).
Postrequisites
If the reported mass flow rate is not accurate:
• Check the characterization parameters.
• Review the troubleshooting suggestions for flow measurement issues. See
Section 10.3.

2.6 Verify the zero

Verifying the zero helps you determine if the stored zero value is appropriate to your installation, or if a field zero can improve measurement accuracy.
The zero verification procedure analyzes the Live Zero value under conditions of zero flow, and compares it to the Zero Stability range for the sensor. If the average Live Zero value is within a reasonable range, the zero value stored in the transmitter is valid. Performing a field calibration will not improve measurement accuracy.
2.6.1 Verify the zero using ProLink II
Verifying the zero helps you determine if the stored zero value is appropriate to your installation, or if a field zero can improve measurement accuracy.
Important
In most cases, the factory zero is more accurate than the field zero. Do not zero the flowmeter unless one of the following is true:
• The zero is required by site procedures.
• The stored zero value fails the zero verification procedure.
Prerequisites
ProLink II v2.94 or later
Important
Do not verify the zero or zero the flowmeter if a high-severity alarm is active. Correct the problem, then verify the zero or zero the flowmeter. You may verify the zero or zero the flowmeter if a low­severity alarm is active.
Procedure
1. Prepare the flowmeter:
a. Allow the flowmeter to warm up for at least 20 minutes after applying power.
12 Micro Motion® Model 1700 Transmitters with Analog Outputs
Quick start
b. Run the process fluid through the sensor until the sensor temperature reaches
the normal process operating temperature.
c. Stop flow through the sensor by shutting the downstream valve, and then the
upstream valve if available.
d. Verify that the sensor is blocked in, that flow has stopped, and that the sensor is
completely full of process fluid.
2. Choose ProLink > Calibration > Zero Verification and Calibration > Verify Zero and wait until
the procedure completes.
3. If the zero verification procedure fails:
a. Confirm that the sensor is completely blocked in, that flow has stopped, and that
the sensor is completely full of process fluid.
b. Verify that the process fluid is not flashing or condensing, and that it does not
contain particles that can settle out.
c. Repeat the zero verification procedure.
d. If it fails again, zero the flowmeter.
For instructions on zeroing the flowmeter, see Zero the flowmeter.
Postrequisites
Restore normal flow through the sensor by opening the valves.
2.6.2 Verify the zero using ProLink III
Verifying the zero helps you determine if the stored zero value is appropriate to your installation, or if a field zero can improve measurement accuracy.
Important
In most cases, the factory zero is more accurate than the field zero. Do not zero the flowmeter unless one of the following is true:
• The zero is required by site procedures.
• The stored zero value fails the zero verification procedure.
Prerequisites
ProLink III v1.0 with Patch Build 31, or a later release
Important
Do not verify the zero or zero the flowmeter if a high-severity alarm is active. Correct the problem, then verify the zero or zero the flowmeter. You may verify the zero or zero the flowmeter if a low­severity alarm is active.
Procedure
1. Prepare the flowmeter:
a. Allow the flowmeter to warm up for at least 20 minutes after applying power.
Configuration and Use Manual 13
Quick start
b. Run the process fluid through the sensor until the sensor temperature reaches
the normal process operating temperature.
c. Stop flow through the sensor by shutting the downstream valve, and then the
upstream valve if available.
d. Verify that the sensor is blocked in, that flow has stopped, and that the sensor is
completely full of process fluid.
2. Choose Device Tools > Device Calibration > Zero Verification and Calibration > Verify Zero and
wait until the procedure completes.
3. If the zero verification procedure fails:
a. Confirm that the sensor is completely blocked in, that flow has stopped, and that
the sensor is completely full of process fluid.
b. Verify that the process fluid is not flashing or condensing, and that it does not
contain particles that can settle out.
c. Repeat the zero verification procedure.
d. If it fails again, zero the flowmeter.
For instructions on zeroing the flowmeter, see Zero the flowmeter.
Postrequisites
Restore normal flow through the sensor by opening the valves.
2.6.3 Terminology used with zero verification and zero calibration
Terminology used with zero verification and zero calibrationTable 2-2:
Term Definition
Zero In general, the offset required to synchronize the left pickoff and the right pickoff under
conditions of zero flow. Unit = microseconds.
Factory Zero The zero value obtained at the factory, under laboratory conditions.
Field Zero The zero value obtained by performing a zero calibration outside the factory.
Prior Zero The zero value stored in the transmitter at the time a field zero calibration is begun. May
be the factory zero or a previous field zero.
Manual Zero The zero value stored in the transmitter, typically obtained from a zero calibration proce-
dure. It may also be configured manually. Also called “mechanical zero” or “stored zero.”
Live Zero The real-time bidirectional mass flow rate with no flow damping or mass flow cutoff ap-
plied. An adaptive damping value is applied only when the mass flow rate changes dra­matically over a very short interval. Unit = configured mass flow measurement unit.
Zero Stability A laboratory-derived value used to calculate the expected accuracy for a sensor. Under
laboratory conditions at zero flow, the average flow rate is expected to fall within the range defined by the Zero Stability value (0 ± Zero Stability). Each sensor size and model has a unique Zero Stability value. Statistically, 95% of all data points should fall within the range defined by the Zero Stability value.
Zero Calibration The procedure used to determine the zero value.
14 Micro Motion® Model 1700 Transmitters with Analog Outputs
Quick start
Terminology used with zero verification and zero calibration (continued)Table 2-2:
Term Definition
Zero Time The time period over which the Zero Calibration procedure is performed. Unit = seconds.
Field Verification Zero A 3-minute running average of the Live Zero value, calculated by the transmitter. Unit =
configured mass flow measurement unit.
Zero Verification A procedure used to evaluate the stored zero and determine whether or not a field zero
can improve measurement accuracy.
Configuration and Use Manual 15

Configuration and commissioning

Part II
Configuration and commissioning
Chapters covered in this part:
• Introduction to configuration and commissioning
• Configure process measurement
• Configure device options and preferences
• Integrate the meter with the control system
• Completing the configuration
16 Micro Motion® Model 1700 Transmitters with Analog Outputs

Introduction to configuration and commissioning

3 Introduction to configuration and
commissioning
Topics covered in this chapter:

• Configuration flowchart

• Default values and ranges
• Enable access to the off-line menu of the display
• Disable write-protection on the transmitter configuration
• Restore the factory configuration
3.1 Configuration flowchart
Use the following flowchart as a general guide to the configuration and commissioning process.
Some options may not apply to your installation. Detailed information is provided in the remainder of this manual. If you are using the Weights & Measures application, additional configuration and setup are required.
Configuration and Use Manual 17
Introduction to configuration and commissioning
Configuration flowchartFigure 3-1:
Configure process measurement
Configure device options and preferences
Test and move to production
Configure mass flow
measurement
Configure volume flow
meaurement
Volume flow type
Liquid
Configure flow direction
Configure density
measurement
Configure temperature
measurement
Gas
Define gas properties
Configure display
parameters
Configure fault handling
parameters
Configure sensor
parameters
Configure device
parameters
Integrate device with control system
Configure the channels
Configure the mA
output(s)
Test or tune transmitter using sensor simulation
Back up transmitter
configuration
Enable write-protection on
transmitter configuration
Done
Configure pressure
compensation (optional)
Configure the frequency
output(s)
Configure the discrete
output(s)
Configure events
Configure digital communications
18 Micro Motion® Model 1700 Transmitters with Analog Outputs
Introduction to configuration and commissioning

3.2 Default values and ranges

See Section F.1 to view the default values and ranges for the most commonly used parameters.

3.3 Enable access to the off-line menu of the display

Display (standard) OFF-LINE MAINT > OFF-LINE CONFG > DISPLAY
Chinese-language display
ProLink II ProLink > Configuration > Display > Display Options
ProLink III Device Tools > Configuration > Transmitter Display > Display Security
Field Communicator Configure > Manual Setup > Display > Offline Variable Menu Features
Offline Maintain > Configuration > Display
Overview
By default, access to the off-line menu of the display is enabled. If it is disabled, you must enable it if you want to use the display to configure the transmitter.
Restriction
You cannot use the display to enable access to the off-line menu. You must make a connection from another tool.

3.4 Disable write-protection on the transmitter configuration

Display (standard) OFF-LINE MAINT > CONFG > LOCK
Chinese-language display
ProLink II ProLink > Configuration > Device > Enable Write Protection
ProLink III Device Tools > Configuration > Write-Protection
Field Communicator Configure > Manual Setup > Info Parameters > Transmitter Info > Write Protect
Offline Maintain > Configuration > Lock
Overview
If the transmitter is write-protected, the configuration is locked and you must unlock it before you can change any configuration parameters. By default, the transmitter is not write-protected.
Configuration and Use Manual 19
Introduction to configuration and commissioning
Tip
Write-protecting the transmitter prevents accidental changes to configuration. It does not prevent normal operational use. You can always disable write-protection, perform any required configuration changes, then re-enable write-protection.

3.5 Restore the factory configuration

Display (standard) Not available
Chinese-language display
ProLink II ProLink > Configuration > Device > Restore Factory Configuration
ProLink III Device Tools > Configuration Transfer > Restore Factory Configuration
Field Communicator Not available
Overview
Not available
Restoring the factory configuration returns the transmitter to a known operational configuration. This may be useful if you experience problems during configuration.
Tip
Restoring the factory configuration is not a common action. You may want to contact Micro Motion to see if there is a preferred method to resolve any issues.
20 Micro Motion® Model 1700 Transmitters with Analog Outputs

Configure process measurement

4 Configure process measurement
Topics covered in this chapter:

• Configure mass flow measurement

• Configure volume flow measurement for liquid applications
• Configure gas standard volume (GSV) flow measurement
• Configure Flow Direction
• Configure density measurement
• Configure temperature measurement
• Configure pressure compensation
4.1 Configure mass flow measurement
The mass flow measurement parameters control how mass flow is measured and reported.
The mass flow measurement parameters include:
• Mass Flow Measurement Unit
• Flow Damping
• Mass Flow Cutoff
4.1.1 Configure Mass Flow Measurement Unit
Display (standard) OFF-LINE MAINT > OFF-LINE CONFG > UNITS > MASS
Chinese-language display
ProLink II ProLink > Configuration > Flow > Mass Flow Unit
ProLink III Device Tools > Configuration > Process Measurement > Flow
Field Communicator Configure > Manual Setup > Measurements > Flow > Mass Flow Unit
Overview
Mass Flow Measurement Unit specifies the unit of measure that will be used for the mass flow rate. The unit used for mass total and mass inventory is derived from this unit.
Procedure
Offline Maintain > Configuration > Units > Mass Flow Rate
Set Mass Flow Measurement Unit to the unit you want to use.
The default setting for Mass Flow Measurement Unit is g/sec (grams per second).
Configuration and Use Manual 21
Configure process measurement
Tip
If the measurement unit you want to use is not available, you can define a special measurement unit.
Options for Mass Flow Measurement Unit
The transmitter provides a standard set of measurement units for Mass Flow Measurement Unit, plus one user-defined special measurement unit. Different communications tools may
use different labels for the units.
Options for Mass Flow Measurement UnitTable 4-1:
Label
Display (stand-
Unit description
Grams per second G/S g/sec g/sec g/sec g/s
Grams per minute G/MIN g/min g/min g/min g/min
Grams per hour G/H g/hr g/hr g/hr g/h
Kilograms per second KG/S kg/sec kg/sec kg/sec kg/s
Kilograms per minute KG/MIN kg/min kg/min kg/min kg/min
Kilograms per hour KG/H kg/hr kg/hr kg/hr kg/h
Kilograms per day KG/D kg/day kg/day kg/day kg/d
Metric tons per minute T/MIN mTon/min mTon/min mTon/min MetTon/min
Metric tons per hour T/H mTon/hr mTon/hr mTon/hr MetTon/h
Metric tons per day T/D mTon/day mTon/day mTon/day MetTon/d
Pounds per second LB/S lbs/sec lbs/sec lbs/sec lb/s
Pounds per minute LB/MIN lbs/min lbs/min lbs/min lb/min
Pounds per hour LB/H lbs/hr lbs/hr lbs/hr lb/h
Pounds per day LB/D lbs/day lbs/day lbs/day lb/d
Short tons (2000 pounds) per minute
Short tons (2000 pounds) per hour
Short tons (2000 pounds) per day
Long tons (2240 pounds) per hour
Long tons (2240 pounds) per day
Special unit SPECL Special special special Spcl
ard)
ST/MIN sTon/min sTon/min sTon/min STon/min
ST/H sTon/hr sTon/hr sTon/hr STon/h
ST/D sTon/day sTon/day sTon/day STon/d
LT/H lTon/hr lTon/hr lTon/hr LTon/h
LT/D lTon/day lTon/day lTon/day LTon/d
Chinese-lan­guage display
ProLink II ProLink III Field Commu-
nicator
22 Micro Motion® Model 1700 Transmitters with Analog Outputs
Configure process measurement
Define a special measurement unit for mass flow
Display (standard) Not available
Chinese-language display
ProLink II ProLink > Configuration > Special Units
ProLink III Device Tools > Configuration > Process Measurement > Flow > Special Units
Field Communicator Configure > Manual Setup > Measurements > Special Units > Mass Special Units
Overview
A special measurement unit is a user-defined unit of measure that allows you to report process data, totalizer data, and inventory data in a unit that is not available in the transmitter. A special measurement unit is calculated from an existing measurement unit using a conversion factor.
Note
Although you cannot define a special measurement unit using the display (standard option), you can use the standard display to select an existing special measurement unit, and to view process data using the special measurement unit.
Offline Maintain > Configuration > Units > Special Mass Flow
Procedure
1. Specify Base Mass Unit.
Base Mass Unit is the existing mass unit that the special unit will be based on.
2. Specify Base Time Unit.
Base Time Unit is the existing time unit that the special unit will be based on.
3. Calculate Mass Flow Conversion Factor as follows:
a. x base units = y special units
b. Mass Flow Conversion Factor = x/y
4. Enter Mass Flow Conversion Factor.
5. Set Mass Flow Label to the name you want to use for the mass flow unit.
6. Set Mass Total Label to the name you want to use for the mass total and mass
inventory unit.
The special measurement unit is stored in the transmitter. You can configure the transmitter to use the special measurement unit at any time.
Example: Defining a special measurement unit for mass flow
You want to measure mass flow in ounces per second (oz/sec).
1. Set Base Mass Unit to Pounds (lb).
2. Set Base Time Unit to Seconds (sec).
Configuration and Use Manual 23
Configure process measurement
3. Calculate Mass Flow Conversion Factor:
a. 1 lb/sec = 16 oz/sec
b. Mass Flow Conversion Factor = 1/16 = 0.0625
4. Set Mass Flow Conversion Factor to 0.0625.
5. Set Mass Flow Label to oz/sec.
6. Set Mass Total Label to oz.
4.1.2 Configure Flow Damping
Display (standard) Not available
Chinese-language display
ProLink II ProLink > Configuration > Flow > Flow Damp
ProLink III Device Tools > Configuration > Process Measurement > Flow
Field Communicator Configure > Manual Setup > Measurements > Flow > Flow Damping
Offline Maintain > Configuration > Damping > Mass Flow Damping
Overview
Damping is used to smooth out small, rapid fluctuations in process measurement. Damping Value specifies the time period (in seconds) over which the transmitter will spread changes
in the reported process variable. At the end of the interval, the reported process variable will reflect 63% of the change in the actual measured value.
Procedure
Set Flow Damping to the value you want to use.
The default value is 0.8 seconds. The range depends on the core processor type and the setting of Update Rate, as shown in the following table.
Core processor type Update Rate setting Flow Damping range
Standard Normal 0 to 51.2 seconds
Special 0 to 10.24 seconds
Enhanced Not applicable 0 to 51.2 seconds
Tips
• A high damping value makes the process variable appear smoother because the reported value
changes slowly.
• A low damping value makes the process variable appear more erratic because the reported value
changes more quickly.
• The combination of a high damping value and rapid, large changes in flow rate can result in
increased measurement error.
24 Micro Motion® Model 1700 Transmitters with Analog Outputs
Loading...
