Elite MST-6805 User Manual

Model: MST-6805(A~Z)

Before operating your new appliance, please read all instructions

carefully and keep for future reference.

IMPORTANT SAFEGUARDS 2

SHORT CORD PURPOSE AND POLARIZED PLUG WARNING 4

PARTS IDENTIFICATION 5

FEATURES & BENEFITS 6

GETTING TO KNOW THE CONTROL PANEL 7

PREPARING YOUR INFINITY COOKER FOR USE 7

COOKING FUNCTION CHART 8

HOW TO USE YOUR INFINITY COOKER 9

HINTS & TIPS 16

CARE & MAINTENANCE 17

TROUBLESHOOTING 17

RECIPES 18

WARRANTY & CUSTOMER SERVICE 34

When using electrical appliances, basic safety precautions should always be followed, including the

following:

1. Read all instructions before using your Elite Platinum Infinity Cooker. WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:

2. To protect against electrical shock do not immerse cord, plugs, or the base unit in water or

other liquids. If the unit falls into liquid, unplug the power cord from the electrical outlet immediately. DO NOT reach into the liquid.

3. Close supervision is necessary when appliance is used near children.

4. NEVER ALLOW A CHILD TO USE THIS PRODUCT.

5. Remove the power cord from the electrical outlet when not in use, before assembling or

disassembling parts and before cleaning. To unplug, grasp the plug and pull from the electrical outlet. Never pull from the power cord. Allow the appliance to cool before adding or removing parts.

6. The use of attachments or tools not recommended by supplier may cause fire, electric shock

or injury.

7. DO NOT let the power cord hang over the edge of the table or work-top, and keep it away

from any hot surfaces.

8. Always use the appliance on a dry, level surface. Extreme caution must be used when moving

an appliance containing hot oil or other hot liquids. Always use oven mitts or pot holders when moving the cooking system. Allow hot oil to cool prior to removal or cleaning the appliance.

9. Allow lid and cooker to cool before allowing it to touch water. Never touch the outer

enclosure of the cooker during its operation or before it cools. Use the handles or knobs. Do not touch hot surfaces. Always use oven mitts or pot holders when removing the pot.

10. Do not use cooker or glass lid if cracked or chipped.

11. Never leave the appliance connected to the socket outlet when not in use.

12. Do not switch on the appliance when it is upside down or laid on its side.

13. The glass lid is fragile. Handle with care.

14. This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

15. If the supply cord is damaged, it must be replaced by a special cord or assembly available

from the manufacture or its service agent.

16. It is recommended to regularly inspect the appliance to avoid a hazard. Do not operate any

appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair, or adjustment.

17. Do not place on or near a hot gas or electric burner, or in a heated oven.

18. Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect,

power “off” by pressing POWER button, then remove plug from wall outlet.

19. Fully unwind the power cord before use.

20. Any maintenance other than cleaning should be performed at an authorized Service Center.

21. Do not use this appliance for anything other than its intended use. Do not use in moving

vehicles or boats. Do not use outdoors. Misuse may cause injury.

22. Remove any packaging material and promotional stickers before using the Cooker for the first

time.

23. Do not place the Cooker on the edge of a bench or table during operation. Ensure the surface

is level, clean and free of water and other substances.

24. Do not use on a sink drain board.

25. Position the Cooker well away from walls, curtains and other heat or steam sensitive

materials. Minimum of 20cm distance.

26. If using plastic utensils, do not leave inside the appliance when hot or on sauté setting.

27. Always ensure the Cooker is properly assembled before use.

28. Never plug in or switch on the Cooker without having the removable cooking bowl placed

inside the stainless steel housing.

29. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, COOK ONLY IN THE POT PROVIDED OR IN

CONTAINERS RECOMMENDED BY MAXI-MATIC PLACED ON THE COOKING RACK IN THE PROVIDED POT. DO NOT USE THE APPLIANCE WITHOUT THE REMOVABLE COOKING POT INSIDE.

30. Do not place food or liquid directly into the stainless steel housing. Only the removable

cooking bowl is designed to contain food or liquid.

31. Never operate the Cooker without food and liquid in the removable cooking bowl.

32. Ensure that the food or liquid to be cooked fills half or more of the removable cooking bowl

before switching on the appliance.

33. The glass lid has been specially treated to make it stronger, more durable and safer than

ordinary glass, however it is not unbreakable. If struck extremely hard it may break or weaken, and could at a later time, shatter into many small pieces without any apparent cause.

34. Do not move the appliance during cooking.

35. Always have the glass lid placed correctly into position on the removable cooking bowl

throughout operation of the appliance unless stated in the recipe to have it removed.

36. Do not place the removable cooking bowl when hot on any hot surface that may be affected

by heat.

37. Avoid sudden temperature changes. Do not place frozen or very cold foods into the

removable cooking bowl when it is hot. Do not place removable cooking bowl when hot into cold water.

38. Do not use the removable cooking pot in a conventional oven. Do not place the removable

cooking bowl onto a heat gas or electric burner.

39. Do not use a damaged or cracked removable cooking pot. Replace before using.

40. Use extreme caution when removing the lid after cooking. Serious burns can result from the

steam inside. Always lift and tilt the lid away from you when removing, using care to ensure that water does not drip back into the appliance.

41. Do not place anything, other than the lid, on top of the Cooker when assembled, when in use

and when stored.

42. Always POWER the Cooker ‘Off’ by pressing the POWER button, then unplug and allow to

cool, if appliance is not in use, before cleaning, before attempting to move the appliance, dissembling, assembling and when storing the appliance.

43. Keep the stainless steel housing, removable cooking bowl and glass lid clean. Follow the

cleaning instructions provided in this book.

44. The Cooker is not intended to be operated by means of an external timer or separate remote

control system.

45. Some countertop and table surfaces, such as Corian®, wood and / or laminates, are not

designed to withstand prolonged heat generated by certain appliances. It is recommended by countertop manufacturers and Maxi-Matic that a hot pad or trivet be placed under your appliance to prevent possible damage to the surface.

46. DO NOT use this appliance for deep frying.

47. Do not heat or pre-heat the Cooker when empty.

48. The removable bowl will not withstand sudden temperature changes. Always ensure the

bowl is at room temperature before adding hot or cold items.

NOTE: A short power cord is provided to reduce the risk of personal injury resulting from becoming entangled in or tripping over a longer cord.

Longer power-supply cords or extension cords are available and may be used if care is exercised in their use. If an extension cord is used: (1) the marked electrical rating of the extension cord should be at least as great as the electrical rating of the product; (2) the extension cord should be arranged so that it will not drape over the countertop or tabletop where it can unintentionally be pulled on or tripped over by children or pets.

If this appliance is equipped with a polarized plug (one blade is wider than the other), please follow the below instructions:

To reduce the risk of electrical shock, this plug is intended to fit into a polarized outlet only one way. If you are unable to fit the plug into the electrical outlet, try reversing the plug. If the plug still does not fit, contact a qualified electrician. Never use the plug with an extension cord unless the plug can be fully inserted into the extension cord. Do not alter the plug of the product or any extension cord being used with this product. Do not attempt to defeat the safety purpose of the polarized plug.

NOTE

The Inner Pot (d) consists of a nonstick surface. To avoid scratching the non-stick surface, please use wooden or plastic utensils.

b c d

e f g h i

a. Cool Touch Handle

b. Vented Tempered Glass Lid

c. Roasting/Steam Rack

d. 6.5QT. Non-Stick Inner Pot

e. Stainless Steel Main Housing

f. Cool Touch Handles

g. Cool Touch Base Unit

h. Control Panel

i. LCD Display

Thank you for purchasing the Elite Platinum 6.5Qt. Infinity Cooker. The Elite Platinum

6.5Qt. Infinity Cooker is one of the most innovative and versatile appliances that you will ever own. Digital controls and an effortless design give you the ability to Cook Rice, Sauté, Bake, Roast, Stew, Slow Cook, or Steam a wide range of healthy meals for your entire family.

FEATURES & FUNCTIONS:  Sauté: Simmer, Sauté or Sear using this mode with temperature settings between

210°F ~ 420°F and timer settings between 5 minutes and 2 hours.

 Steam: Program the Infinity Cooker to steam between 20 ~ 90 minutes.  Stew: Program the Infinity Cooker to cook soups and stews from 2 hours up to 4

hours.

 Slow Cooker Settings: Select from 2 temperature settings of HIGH and LOW, and

program the timer to slow cook from 4 ~ 12 hours.

 Bake: Select this mode to bake at temperatures between 230°F ~ 425°F and

program baking times from 30 minutes up to 4 hours.

 Roast: Select this mode to roast at temperatures between 290°F ~ 425°F and

program roasting times from 30 minutes up to 4 hours.

 Cook Rice: Like any standard rice cooker, this mode will automatically cook rice

without any temperature or timer settings.

 Keep Warm Buffet: Keep food warm from 1 hour up to 4 hours in this cooker or

even use it as an elegant buffet station.

 Digital Controls with LCD Display and Timer/Temperature Settings.  Goes to Keep Warm automatically in Slow Cooker mode.

POWER BUTTON: Powers the Infinity

Cooker On/Off.

START/STOP BUTTON: Starts or Cancels selected cooking function. MENU BUTTON: Use this button to cycle through and select a cooking function The arrow on the display will point to the selected function - Bake, Rice, Roast, Slow Cook (HI, LOW), Keep Warm, Steam, Stew, or Sauté.

1. Before using your Infinity Cooker for

the first time, carefully remove all the parts from the box and wash the inner pot, roasting rack, and the tempered glass lid with warm, soapy water. The cooking pot may also be washed in the top shelf of the dishwasher. The roasting rack is not dishwasher safe. IMPORTANT: DO NOT IMMERSE THE MAIN HOUSING IN WATER. Wipe it clean with a damp cloth.

2. When ready to use, place the inner

pot inside the main housing. Never use the Infinity Cooker without the cooking pot placed into the housing.

3. Plug the unit into an electrical

outlet.

4. The LCD display will flash blue and

beep once.

LCD DISPLAY: The left side of the display shows the temperature in Fahrenheit degrees while the right side of the display shows the programmed cook time. TIMER/TEMP BUTTON: Use this button to toggle between adjusting Time and Temperature settings. +/- BUTTON: Use these buttons to adjust the Time and/or Temperature settings.

5. The Infinity Cooker will not power

“On” until you press the POWER button.

6. When ready to begin cooking, press

the POWER button. The LCD display will illuminate blue and show

"888°F 88:88." The indicator arrow will begin flashing until you press the MENU button.

7. Press the MENU button to move the

indicator arrow on the LCD display to the Function that you desire.

8. Follow instructions in the next

section of this manual on how to use the different functions.

NOTE: The initial 15 minutes of use may result in minimal smell and smoke. This is normal and harmless and comes from the protective substance applied to the heating elements during manufacturing.

Function

Default

Temperature

Default

Time

Cooking Time

Range

Cooking

Temperature

Range

SLOW COOKER

（HI）

N/A

6:00H

4:00 ~ 12:00H

30 min increments

N/A

SLOW COOKER

（LOW）

N/A

8:00H

4:00 ~ 12:00H

30 min increments

N/A

KEEP WARM

N/A

2:00H

1:00 ~ 4:00H

30 min increments

N/A

STEAM

N/A

0:30M

0:20 ~ 1:30H

10 min increments

N/A

ROAST

350°F

0:30M

0:30 ~ 4:00H

10 min increments

290°F ~425°F;

5°F increments

BAKE

325°F

1:00H

0:30 ~ 4:00H

10 min increments

230°F ~425°F;

5°F increments

SAUTÉ

(SIMMER | SEAR)

390°F

0:05M

0:05 ~ 2:00H

5 min increments

210°F ~420°F;

5°F increments

STEW

N/A

2:00H

2:00 ~ 4:00H

10 min increments

N/A

RICE

N/A

HOW TO SAUTÉ (SIMMER | SEAR):

1. Place the inner pot inside the main

housing.

2. Place food inside the inner pot in an

even layer for best results. Do not cover with Glass Lid.

3. Plug the unit into an outlet and

push the POWER button to turn "On."

4. Press the MENU button until the

flashing indicator arrow moves to the SAUTÉ position.

5. Press the TIMER/TEMP button once

and the default temp of "390°F" on the LCD display will flash. Press the + or – buttons to adjust in 5°F increments to the desired temperature. Hold down for rapid increase/decrease.

TIP #1:  To SAUTÉ, set the temperature to

320°F~380°F.

 To SIMMER, set the temperature to

210°F~215°F.

 To SEAR, set the temperature to

380°F~420°F.

6. Once the desired temperature is

indicated on the LCD display, press the TIMER/TEMP button again and the default time of "00:05" on the display will flash. Press the + or – buttons to adjust in 5 min

increments to the desired cook time. Hold down for rapid increase/decrease.

7. Follow the Cooking Function Chart

on page 8 to reference the range of cooking times and temperatures for

the SAUTÉ (SIMMER | SEAR) mode. [NOTE: The unit will countdown 10 sec and begin cooking if no other buttons are pressed.]

8. Press the START/STOP button once

to begin cooking.

9. Continuously mix/stir the contents

of inner pot using a non-metallic

utensil.

10. Once cooking is complete the unit

will power off and beep 3 times.

11. When you are finished using the

unit, make sure the POWER is “Off”

and then unplug the unit and allow

it to cool completely before

handling. TIP #2: Waiting more than 10 sec in between making selections will cause the indicator arrow to turn solid and the cooking process to begin for whichever function and settings are currently displayed on the LCD screen. If this happens, simply press the START/STOP button to cancel cooking and start the selection process over.

HOW TO SLOW COOK (HI & LOW):

The 6.5QT. capacity of the Infinity Cooker makes it the perfect size for

cooking family meals or for large gatherings. In this mode, the unit will automatically switch to KEEP WARM once cooking is complete. Use the SAUTÉ function on 380°F~420°F to SEAR meats before slow cooking to enhance color, flavor, and texture.

1. Place ingredients into the inner pot

and place the pot into the base. Cover with Glass Lid.

2. If you need to pre-cook or brown

foods prior to slow cooking, follow the instructions in this manual under SAUTÉ (SIMMER | SEAR).

3. Plug the unit into an outlet and

press the POWER button.

4. Press the MENU button until the

flashing indicator arrow moves to the SLOW COOKER (HI) or (LOW) position depending on the recipe instructions.

5. Press the TIMER/TEMP button once

and the default time of “6:00” for HI or “8:00” for LOW on the display will flash. Press the + or - buttons to adjust in 30 min increments to the desired cook time.

6. Follow the Cooking Function Chart

on page 8 to reference the range of

cooking times for the SLOW COOKER

mode. (Cooking Temperatures are

not manually adjustable in SLOW

COOKER mode). [NOTE: The unit will countdown 10 sec and begin cooking if no other buttons are pressed.]

7. Press the START/STOP button once

to begin cooking. Do not open the

lid repeatedly while cooking.

8. After cooking is complete, the unit

will switch to Auto KEEP WARM for 2

hours (you will hear a 3 beep

indicator). After the timer counts

down the 2 hours the unit will shut

off.

9. When you are finished using the

unit, make sure the POWER is “Off”

and then unplug the unit and allow

it to cool completely before

handling.

TIP #3: The SLOW COOKER mode uses pre-programmed temperature settings to cook. Cooking temperatures are not manually adjustable in SLOW COOKER mode.

+ 25 hidden pages
