Electro-Voice RE3-BPT Datasheet
Electro-Voice | RE3-BPT RE3 Bodypack Transmitter
RE3-BPT RE3 Bodypack
Transmitter
▪ Robust metal body
▪ Up to 36 MHz tuning bandwidth (band specific)
▪ Selectable low and high output power (band
specific)
▪ Unique magnetic latch and lock for easy access to
batteries
▪ Sync function for easy frequency setup
The RE3-BPT is a small, lightweight yet robust UHF
bodypack transmitter. It is easily worn and concealed,
making it an ideal form factor for a wide variety of
professional presentation and performance
applications. From stand-up presentations, to
theatrical and musical performances, to high-energy
fitness and athletic situations, this sleek and rugged
transmitter fits comfortably and accepts a wide variety
of input devices.
The all-metal body is robust and durable, and operates
on 2 AA alkaline or rechargeable NiMH cells. The
tuning bandwidth affords generous frequency tuning
options helping to avoid various sources of possible
interference. The selectable output power (band
specific) assists in overcoming the challenges of both
long, or short, transmission ranges. The unique
magnetic sliding latch and lock mechanism keeps the
battery door closed securely and makes opening to
access the batteries effortless. The ultrasonic sync
function makes for a simple system setup by syncing
the transmitter to the receiver frequency tuning and
other functional data. Recharging contacts provide for
functional use with the optional BC2 charging station
allowing the NiMH rechargeable cells within two
bodypack transmitters to be charged without removal.
Technical specifications
Frequency oscillation mode:
Available band names, tuning
bandwidths, and carrier
frequency ranges:
Sync frequency:
RF power output: Frequency band specific:
Display by:
Function controls: Power, mute, group, channel,
Phase-locked loop (PLL)
5L: 36 MHz (488-524 MHz)
5H: 36 MHz (560-596 MHz)
6M: 10 MHz (653-663 MHz)
8M: (823-865 MHz)*
T: 3 MHz (803-806 MHz)
*8M is split into two segments:
823-832MHz: 9MHz
863-865MHz: 2MHz
Ultrasonic
5L (488-524MHz): Low 10mW / High
50mW
5H (560-596MHz): Low 10mW / High
50mW
6M (653-663MHz): Low 10mW /
High 20mW
8M (823-865MHz) 10mW
T (803-806MHz): Low 10mW / High
50mW
LCD + LED
frequency, sensitivity adjustment,
input level attenuation, RF power,
auto off, key lock.
SET
RE3-BPT
64.5 mm
25 mm
81.5 mm
2 | RE3-BPT RE3 Bodypack Transmitter
RF stability: <±10kHz@Fc
Modulation frequency shift: Wideband FM ±48kHz deviation
Harmonic radiation:
Input jack: 4-pin mini jack
Battery: 2 x AA alkaline battery or NiMH
Charging contacts:
Finish: Black polyurethane paint
Dimensions (without
antenna):
Net weight:
Gross weight: 8.29 oz. (0.235 kg)
<-50dBc
rechargeable battery
Yes
Height: 3.2 in. (81.5mm)
Width: 2.54 in. (64.5mm)
Depth: 0.98 in. (25mm)
6.14 oz. (0.174 kg)
Dimensions:
MHz is covered under FCC Part 15, and do
not require an additional user license. For
more information, see https://www.fcc.gov/
consumers/guides/operation-wireless-microphones.
Responsible Party - U.S. Contact Information
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450
USA
Tel: +1 (585) 223-4060
For full operational information, download the RE3
installation manual at www.electrovoice.com.
Licensing and certification declarations:
FCC information:
Certified under FCC Part 74.
FCC IDs: B5DB1245L and B5DB1245H
Certified under FCC Part 15 and FCC Part 74.
FCC IDs: B5DB1246M
Notice!
Use of frequencies beginning at 653.000 MHz
up to 657.000 MHz is covered under FCC
Part 74 ID number B5DB1246M and requires
an LPAS user license, however use of frequencies between 657.025 up to 663.000
