Electrolux CLASSIC-FOLDER LD DATASHEET

CLASSIC-FOLDER LD

LENGTH FOLDER

Model LD:

1 feeding lane with 2 length folds (longitudinal) and

!

rear delivery.

! 4 feeding lanes with 2 length folds (longitudinal) and

rear delivery.

Production:

Working width: 3000-3300 mm.

!

! Category of item: Large and small flat items.

Operation:

! Length folding section done by air jets between

reverse rotating rollers:

- 2 length folds on 1 lane (1 x 3000-3300 mm) or 2

lanes (4 x 700-750 mm).

Features:

! The robust steel c hassis is made of bended 3 and 4

mm thick metal sheets. White colour RAL 9010.
Transmission done by asynchronous m otor managed

!

by frequency control driving timing belts and using
clutches.

! Automatic speed variation by means of frequency

converter (3 pre-set speeds). Each progr am can get 3
different speeds.
Total by-pass of non-folded items.

!

Easy to use control system managing up to 20 folding

!

programs.

! Automatic detection and measuring of items by

photoelectric cells.

! Buzzer and flashing light alarms in case of jam.

Antistatic system for smooth operatio n.

!

Conveyor belts as junction between the ironer and the

!

CLASSIC-FOLDER.

All product specifications can be modified at any time by Electrolux without notice

Automatic torn/dirty linen rejection directly after the

!

length fold.

! Rear delivery table.
! Mounted on wheels

! Gangway on top of the feeding belts.

Options:

! Linear by-pass ½ + ½ (compulsory for connection to

!

!

! Safety device between ironer and folder.

! Additional control panel installed in front of the ironing

Option cross fold sections:

• Positioned underneath the prima ry fold sect io n .

• Available in the following models:

Option stackers:

ALC or ALC2 for single/double bed sheet sort-out.
Stacked piles of programmed num bers/quantities with
possibility to be installed on either side of fo ld er .

SP COLLECTOR, FLIP-FLOP, and DUBLO).
By-pass of first length fold.
Speed synchronisation with ironer by means of
tachymeter.

and folding set.

- Model T1 operating on: 1 la ne with 3 cross folds.
Items to be collected on the right or left hand side.
First cross fold carried out by a blade between
reverse rotating rollers. Second and third cross folds
carried out by air blasts between reversing conveyors.

CLASSIC-FOLDER LD

ALC

STACKER

ALC2

Electrical connection 3000 – 3300 SECTION

Voltage:

400V 3N AC 50Hz kW (A) 1.1 (10) 2.7 (16) 0.73 1.25
230V 3N AC 50Hz kW (A) 1.1 (10) 2.7 (16) 0.73 1.25

Compressed air connection

Air mm 12 from folder from folder from folder
Air pressure kPa 800 800 800 800
Air consumption NL/min 220 80 18 35

Sound level

Airborne sou nd level dB(A) < 70 < 70 < 70 < 70

Shipping data

Weight kg 1600 800 210 250
Static load Kg/cm² 1.3 1.5 1 1

Dimensions in mm

Overall width mm 3930 1080 1800
Overall depth mm 2830 2840 2840
Overall height mm 1930 1100 1100

LENGTH FOLDER

STACKER

T1

Folds:

Large flat

Small flat
