Echo SRM-210 User Manual
Grass T rimmer/Brush Cutter
Operator's Manual
MODEL SRM-210
Serial Number 05001001 - 05999999
X7702275401
W ARNING DANGER
Read rules for safe operation and instructions carefully. ECHO provides an Operator's
Manual and a Safety Manual. Both must be read and understood for proper and safe
operation.
X770000671
08/03
2
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job
dependability. Read and understand this manual and the SAFETY MANUAL before operation. You will find both easy
to use and full of helpful operating tips and SAFETY messages.
THE OPERATOR'S MANUAL
Contains specifications and information for operation, starting, stopping, maintenance, storage, and assembly specific to this product. Keep
it in a safe place for future reference.
THE SAFETY MANUAL
Explains possible hazards involved with the use of Grass Trimmers and
Brush Cutters and what measures you should take to make their use
safer. Keep it in a safe place for future reference.
TABLE OF CONTENTS
Introduction ........................................................................ 2
- The Operator's Manual ............................................... 2
- The Safety manual....................................................... 2
Manual Safety Symbols and Important Information ......... 3
Safety.................................................................................. 3
- Decals .......................................................................... 3
- International Symbols ................................................. 4
Safety Instructions ............................................................. 5
- Personal Condition and Safety Equipment................. 5
- Extended Operation/Extreme Conditions ................... 5
- Equipment .................................................................. 6
- Safe Operation ............................................................ 7
Emission Control ................................................................ 7
Description ......................................................................... 8
- Contents ..................................................................... 8
Specifications.................................................................... 11
Assembly.......................................................................... 12
- Plastic Shield Installation.......................................... 12
- Nylon Head Installation ........................................... 12
- Front Handle Installation.......................................... 13
Pre-Operation ................................................................... 13
- Operation with Blades.............................................. 13
- Fuel ........................................................................... 16
Copyright© 2003 By Echo, Incorporated
All Rights Reserved.
Operation.......................................................................... 17
- Starting Cold Engine .................................................. 17
- Starting Warm Engine ................................................ 18
- Stopping Engine ........................................................ 19
Maintenance ..................................................................... 19
- Skill Levels................................................................ 19
- Maintenance Intervals .............................................. 20
- Air Filter ................................................................... 21
- Fuel Filter ................................................................. 21
- Spark Plug................................................................. 22
- Cooling System Cleaning .......................................... 22
- Exhaust System ........................................................ 23
- Carburetor Adjustment ............................................. 24
- Lubrication................................................................ 26
- Nylon Line Replacement .......................................... 27
- Sharpening Metal Blades .......................................... 28
Troubleshooting................................................................ 29
Storage .............................................................................. 30
Servicing Information........................................................ 32
- Parts.......................................................................... 32
- ECHO Consumer Product Support.......................... 32
- Service ....................................................................... 32
- Warranty Card .......................................................... 32
- Additional or Replacement Manuals ........................ 32
Specifications, descriptions and illustrative material in
this literature are as accurate as known at the time of
publication, but are subject to change without notice.
Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
GRASS TRIMMER/BRUSH CUTTER
OPERATOR'S MANUAL
MANUAL SAFETY SYMBOLS AND IMPORT ANT INFORMATION
Throughout this manual and on the product itself, you will find safety
alerts and helpful, informational messages preceded by symbols or key
words. The following is an explanation of those symbols and key
words and what they mean to you.
This symbol accompanied by the words WARNING and
DANGER calls attention to an act or condition that can lead to
serious personal injury to operator and bystanders.
The circle with the slash symbol means whatever is shown
within the circle is prohibited.
IMPORTANT The enclosed message
provides information necessary for the
protection of the unit.
NOTE This enclosed message provides tips for
use, care and maintenance of the unit.
3
SAFETY
DECALS
Locate these safety decals on your unit. Make sure the decals are
legible and that you understand and follow the instructions on them.
If a decal cannot be read, a new one can be ordered from your ECHO
dealer. See PARTS ORDERING instructions for specific information.
Shaft Decal
Spanish Decal
ADVERTENCIA PELIGRO
P/N 89022809560
89022809560
Esta unidad puede ser peligrosa y producir lesiones
personales graves si no se usa en forma adecuada.
Para reducir el riesgo de lesionarse, los operadores,
los ayudantes y los espectadores deben leer y
comprender el Manual Del Operador y los Manuales
De Seguridad que se entregan escritos en español.
Hot Surface Decal
P/N 89016006361
English Translation
WARNING DANGER
This unit can be dangerous and cause
serious injury if improperly used. to
reduce injury risk to operator, helpers
and bystanders, read and understand
the Operator's and Safety Manuals,
which are provided in Spanish.
4
Shaft Decal
W ARNING DANGER
• This unit can be dangerous and cause serious injury if improperly
used. To reduce injury risk to operator, helpers and bystanders, read
and understand the Operator's and Safety manuals.
• Blindness can occur from objects that are thrown or ricocheted even
with shield in place. Operators, helpers and bystanders must wear
ANSI Z87.1 approved eye protection.
• Always wear hearing protection when operating unit.
• Prevent accidental contact with unit and any cutting attachment.
Maintain a 50 ft. (15M) radius, DANGER ZONE surrounding the
operator. ONLY the operator, dressed in proper protective clothing
should be in the DANGER ZONE.
• Beware of KICKOUT (blade thrust) when using blades. Special
precautions are necessary for blade operation, see your Operator's
and Safety Manuals. ONLY install ECHO approved blades on Brush
Cutters (SRM) models equipped with proper blade shield, U-handles,
harness, blade collar, nut and cotter pin.
• Blade/Cutting attachment does not stop immediately after releasing
throttle. Keep hands and feet clear of blade/cutting attachment unless
engine is shut off and cutting attachment is not moving.
• INSPECT BLADES BEFORE USE.
• DO NOT USE DAMAGED, CRACKED, BENT, DULL OR
IMPROPERLY SHARPENED BLADES.
• Do not remove shields, modify the unit or install attachments or parts
not approved by ECHO. Approved attachment information and
replacement Operator's and Safety Manuals are available from your
ECHO dealer or by writing: ECHO, INCORPORATED,
400 OAKWOOD RD., LAKE ZURICH, IL 60047.
P/N 89016054130
INTERNA TIONAL SYMBOLS
DESCRIPTION
"WARNING, SEE
OPERATOR'S
MANUAL
Wear eye, ear
and head
protection
Wear hand and
foot protection
Safety/Alert
SYMBOLSYMBOL
Keep bystanders and helpers
away 15 m (50 ft.).
DESCRIPTION
Hot
Surface
Finger Severing
DO NOT allow
flames or sparks
near fuel.
DO NOT smoke
near fuel.
SYMBOL DESCRIPTION
Emergency
Stop
Carburetor
Adjustment
- High speed
mixture
Carburetor
Adjustment
- Idle speed
Carburetor
Adjustment
- Low speed
mixture
Choke Control
"Run"
Position
(Choke Open)
SYMBOL
DESCRIPTION
Fuel and oil
mixture
Primer
Bulb
Ignition
ON/
OFF
Do not use
blades. String
line only
Choke Control
"Cold Start"
Position
(Choke Closed)
SAFETY INSTRUCTIONS
GRASS TRIMMER/BRUSH CUTTER
OPERATOR'S MANUAL
5
PERSONAL
CONDITION AND SAFETY EQUIPMENT
W ARNING DANGER
Trimmer/Brush Cutter users risk injury to themselves and others if the trimmer/brush cutter is used improperly
or safety precautions are not followed. Proper clothing and safety gear must be worn when operating a
trimmer/brush cutter.
Physical Condition
Your judgment and physical dexterity may not be good:
• if you are tired or sick,
• if you are taking medication,
• if you have taken alcohol or drugs.
Operate unit only if you are physically and mentally well.
Eye Protection
Wear eye protection that meets ANSI Z87.1 or CE
requirements whenever you operate the trimmer.
Hand Protection
Wear no-slip, heavy duty work gloves to improve your
grip on the Trimmer/Brush Cutter handles. Gloves also
reduce the transmission of machine vibration to your
hands.
Hearing Protection
ECHO recommends wearing hearing protection whenever
unit is used.
Proper Clothing
Wear snug fitting, durable clothing;
• Pants should have long legs, shirts with long sleeves.
• DO NOT WEAR SHORTS,
• DO NOT WEAR TIES, SCARVES, JEWELRY.
Wear sturdy work shoes with non-skid soles;
• DO NOT WEAR OPEN TOED SHOES,
• DO NOT OPERATE UNIT BAREFOOTED.
Hot Humid Weather
Heavy protective clothing can increase operator fatigue
which may lead to heat stroke. Schedule heavy work for
early morning or late afternoon hours when temperatures
are cooler.
EXTENDED OPERATION/EXTREME CONDITIONS
Vibration and Cold
It is believed that a condition called Raynaud’s Phenomenon, which
affects the fingers of certain individuals, may be brought about by
exposure to vibration and cold. Exposure to vibration and cold may
cause tingling and burning sensations, followed by loss of color and
numbness in the fingers. The following precautions are strongly
recommended, because the minimum exposure which might trigger the
ailment is unknown.
• Keep your body warm, especially the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by performing vigorous arm
exercises during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where
operating the trimmer or other hand-held power equipment is not
required.
• If you experience discomfort, redness and swelling of the fingers
followed by whitening and loss of feeling, consult your physician
before further exposing yourself to cold and vibration.
6
Repetitive Stress Injuries
It is believed that overusing the muscles and tendons of the fingers,
hands, arms and shoulders may cause soreness, swelling, numbness,
weakness, and extreme pain in those areas. Certain repetitive hand
activities may put you at a high risk for developing a Repetitive Stress
Injury (RSI). An extreme RSI condition is Carpal Tunnel Syndrome
(CTS), which could occur when your wrist swells and squeezes a vital
nerve that runs through the area. Some believe that prolonged exposure
to vibration may contribute to CTS. CTS can cause severe pain for
months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position.
Instead, try to maintain a straight wrist position. Also, when grasping, use your whole hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive
movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if
you feel tingling, numbness, or pain in the fingers, hands, wrists, or
arms. The sooner RSI/CTS is diagnosed, the more likely permanent
nerve and muscle damage can be prevented.
EQUIPMENT
W ARNING DANGER
Use only ECHO approved attachments. Serious injury may result from the use of a non-approved attachment
combination. ECHO, INC. will not be responsible for the failure of cutting devices, attachments or accessories which
have not been tested and approved by ECHO. Read and comply with all safety instructions listed in this manual and
safety manual.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect fuel lines, tank, and area around carburetor for fuel leaks. DO
NOT operate unit if leaks are found.
• Inspect shield for damage and ensure that the cut-off knife issecurely
in place. Replace if either is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe
operating condition.
• Check that front loop handle and shoulder strap/ or shoulder/
waist harness are adjusted for safe, comfortable operation. See
Assembly Section for proper adjustment.
• Keep exhaust area clear of flammable debris. Avoid contact during
and immediately after operation.
GRASS TRIMMER/BRUSH CUTTER
SAFE OPERATION
W ARNING DANGER
Do not operate this product indoors or in inadequately ventilated
areas. Engine exhaust contains poisonous emissions and can cause
serious injury or death.
Read the Manuals
• Provide all users of this equipment with the Operator's Manual and
Safety Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and
animals prevented from coming nearer than 15 m (50 ft.) while the unit
is in use.
Keep a Firm Grip
• Hold the front and rear handles with both hands, with thumbs and
fingers tightly encircling the handles.
OPERATOR'S MANUAL
7
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on
ladders. Do not over reach.
EMISSION CONTROL
EPA Phase 2
The emission control system for these engines ia EM (Engine Modification ).
ENGINE FAMILY: 3EHXS.0214EA DISPLACEMENT: 21.2 CC
EMISSION COMPLIANCE PERIOD: 300 HOURS
THIS ENGINE MEETS U.S. EPA PH2 EMISSION REGULATIONS FOR SMALL NONROAD ENGINE. REFER TO
OWNER'S MANUAL FOR MAINTENANCE SPECIFICATIONS
AND ADJUSTMENTS.
An Emission Control Label is located on the engine. (This is an EXAMPLE ONLY, information on label varies by engine
FAMILY).
IMPORTANT ENGINE INFORMATION
PRODUCT EMISSION DURABILITY
The 300 hour emission durability compliance period is the time span selected by the manufacturer certifying the
engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures
are followed as listed in the Maintenance Section of this manual.
8
DESCRIPTION
The ECHO product you purchased has been partially assembled for your convenience. Due to packaging restrictions,
installation of the plastic debris shield, nylon line head, and positioning of the front handle are necessary.
After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing
parts. Use the contents list to check for missing parts.
* Some units may be factory pre-assembled. No assembly tools are needed and the nylon line head, plastic debris shield,
and mounting hardware, shown in the contents list, are pre-assembled to the unit. Only the front handle may need to be
re-positioned for comfortable operation.
CONTENTS
______1 - Power Head / Drive Shaft Assembly
______1 - Operator's Manual
______1 - Safety Manual
______1 - Warranty Registration Card
______1 - Limited Warranty Statement
______1 - Safety Glasses
______1 - Echo Power Blend TM 2-stroke oil sample
______1 - Locking tool, P/N 89751801131
* ___ 1 - Nylon Trimmer Head
* ___ 1 - T - Wrench 17x19 mm, P/N 89541008030
* ___ 1 - Plastic shield
* ___ 1 - Shield plate
* ___ 3 - 5mm x 16mm screws (shield mtg.)
GRASS TRIMMER/BRUSH CUTTER
OPERATOR'S MANUAL
12
11
9
20
Safety
Video
7
6
8
9
18
19
17
5
16
13
14
15
4
3
2
1
10
10
1. POWER HEAD - Includes the Engine, Clutch, Fuel System, Ignition System and Recoil Starter.
2. GRIP - Rear (right hand) handle.
3. THROTTLE TRIGGER LOCKOUT - This lever must be held during starting. Operation of the throttle trigger is
prevented unless throttle trigger lockout lever is engaged.
4. STOP SWITCH - "SLIDE SWITCH" mounted on top of the Throttle Trigger Housing. Move switch FORWARD to
RUN, BACK to STOP.
5. FRONT HANDLE - The Front (loop) handle is loosely assembled to the Drive Shaft assembly and must be positioned
for proper cutting attitude and operator comfort.
6. DRIVE SHAFT ASSEMBLY - Includes the Gear Housing assembly, flex drive cable and Safety Decal.
7. NYLON CUTTER HEAD - Contains replaceable nylon trimming line that advances when the trimmer head is tapped
against the ground while the head is turning at normal operating speed.
8. CUT-OFF KNIFE - Automatically trims line to the correct length: 5" after head is tapped on the ground. If trimmer is
operated without a cut-off knife the line will become too long, the engine will overheat and engine damage may occur.
9. PLASTIC DEBRIS SHIELD ASSEMBLY - Included in plastic bag (co-pack). MUST be installed on unit before use,
see Assembly Instructions. Shield assembly includes the Cut-Off Knife. Mounts on the Gear Housing Assembly just
above the cutting attachment. Helps protect the operator by deflecting debris produced during the trimming operation.
This shield must be replaced with the steel shield for blade use.
10. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration, press trigger gradually for
best operating technique.
11. SPARK PLUG - Provides spark to ignite fuel mixture.
12. TOP GUARD - Protects arm from the hot engine.
13. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER -The muffler or catalytic muffler controls exhaust noise
and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep
exhaust area clear of flammable debris.
14. FUEL TANK - Contains fuel and fuel filter.
15. RECOIL STARTER HANDLE - Pull handle slowly until starter engages, then quickly and firmly. When engine starts,
return handle slowly. DO NOT let handle snap back or damage to unit will occur.
16. FUEL TANK CAP - Covers and seals fuel tank opening.
17. PRIMER BULB - Pumping primer bulb before starting engine draws fresh fuel from the fuel tank priming the carburetor
for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump bulb an
additional 4 or 5 times.
18. AIR CLEANER - Contains replaceable filter element.
19.CHOKE - Located at the rear of the air cleaner housing. Move choke lever to "Cold Start" ( ) to close choke for cold
starting. Move choke lever to "Run" ( ) position to open choke.
20. SAFETY VIDEO - (Not included with unit) P/N 99922202540 English version and P/N 99922203508 Spanish version are
available at a cost of $5.00 from ECHO, INC. or any authorized ECHO dealer. The video overviews safety precautions
and proper operating techniques and is supplemental to the Safety Manual. Read and understand the Safety Manual
for complete information on safe operation.
Loading...
