Eagle TT4, TT5, TT4AWD, TT6, TT8 AWD Operation Manual

EAGLE TUGS

OPERATIONS MANUAL

VEHICLE TYPES: ALL TT MODELS

Safety Warning

0-1

Read this manual in it’s entirety before putting
your Eagle tow tractor into service. This manual
contains important safety instructions. Improper
usage or a failure to follow the safety require­ments listed in this manual could result in severe
injury or death.

1-1

Table of Contents

0-1 Safety Warning

1-1 Table of Contents

2-1 Revision Sheet

3 Introduction

3-1 Welcome

3-2 Contact Info

3-3 Warranty

3-4 Proper Use

3-5 Vehicle Weights, Performance, and Specifications

4 Putting the Tow Tractor Into Service

4-1 Unpacking/Setting Up

4-2 Fuel Requirements

5 Instructions for Safe Use

5-1 General Safety Guidelines

5-2 Operator Requirements

5-2 Operator Workstation

5-3 Pre-Operation Inspection

5-4 H30 Display Panel

5-5 Instrumentation

5-6 Controls

5-7 Starting/Shutdown

5-8 Transmission

5-8 Braking

5-9 Parking

6 Instructions for safe towing/pushing a load

6-1 Towing

6-1 Pushing

7 Instructions for safe handling

7-1 Emergency Towing

7-2 Tie-Down Procedure

Table of Contents

8 Instructions for safe maintenance

8-1 Maintenance Operator Requirements

8-2 General Safety Guidelines

8-3 Daily operator responsibilities

Proper Fluid Checks

8-4 Filter Guide

8-5 Preventative Maintenance Schedules

1-1

2-1

Revision History

Revision Sheet

Rev Number Description

R00 Initial Release All 1/11/09

Affected

Section(s)

Date

Introduction

Welcome
Welcome to the growing family of EAGLE tractor operators. The tractor was built with

the operator's safety, comfort and ease of operation in mind. We hope you agree and
enjoy your EAGLE experience.

Purpose & Use of Manual
This manual is designed as a quick guide to familiarize you with the correct and safe

operation of your Eagle vehicle as well as to inform you of the preventative mainte­nance and servicing recommendations of the manufacturer.

Your EAGLE vehicle was designed to do very specific tasks. For that reason, it will
look, feel, drive and function differently than over-the-road trucks and automobiles, as
well as various other types of vocational vehicles. It is the operator’s responsibility to
operate this equipment in a safe and prudent (good sound judgment) manner. Be alert,
your and other’s safety is involved.

The descriptions and specifications contained in this manual were in effect at the time
the manual was printed. EAGLE INDUSTRIAL TRUCK, LLC. Reserves the right to dis­continue models at any time and/or to change specifications, designs or components
used without notice and without incurring obligations.

3-1

3-2

Contact Information

Corporate Offices

Sales, Support, Customer Service

Eagle Industrial Truck

26111 Northline Rd

Taylor, MI 48180

USA

[phone] — [phone]

Global Sales Office

Sales

Maple House

High Street

Introduction

Potters Bar

Herts, EN6 5BS

UK

[phone]

Web-Site

www.eagletugs.com contains useful sales and service information. Please refer to this
website for the latest revision of this and all other manuals.

Email Addresses

Customer Service [e-mail]

Parts Department [e-mail]

Technical Support [e-mail]

Sales Department [e-mail]

Introduction

Warranty

Please read warranty information carefully.

Before contacting Eagle Industrial Truck for any warranty issue please have the following
information ready:

TruckModel

TruckSerialNumber

EngineType

3-3

EngineMake

EngineSerial Number

HoursReading

All information can be found on the data plate located beside the driver seat with the
Exception of the hours which can be read using the H30 display or the hour meter on the

dash.



3-3

Introduction

Warranty Registration

Vehicles powered by a Yanmar engine should register the engine by entering the required
information into the Customer registration screen found on Yanmar’s website at
http://www.yanmar.co.jp. Vehicles powered by a Wisconsin Motors TME27 engine should
contact Eagle directly if prior to warranty work being performed for information on the nearest
Wisconsin Motors distributor in your area. Warranty registration for your Eagle tractor is
completed by either the distributor or directly at the factory prior to shipment of your new unit.

Tires

For pneumatic tires, contact your nearest Power King (Kelly-Springfield) brand dealer who will
adjust your claim based on the remaining tread wear as a percent of total new tread.

For solid tires, contact Eagle directly.

Battery

In the U.S. and Canada, call 1-888-823-0954 or 1-877-255-2287

Warranty

Threeagle

The Threeagle
October 1, 2006. Eagle Tugs (EAGLE) warrants that the Eagle TT-series tow tractors will be
free from defects in material and workmanship for a period of 3 years or 3,000 operating
hours, (except for the electrical and cooling systems which are 3 months or 500 hours), from
date of delivery to the first customer (or first use), whichever comes first. Written notice of any
claimed defect must be given to EAGLE within the warranty period and within thirty (30) days
after such defect is discovered. Liability under this warranty is limited to either replacing or re­pairing, at EAGLE's election, any part or parts deemed defective after examination by EAGLE
or an Authorized Service Representative. Any EAGLE machine or any of its parts returned by
customer to EAGLE or an Authorized Service Representative via prepaid transportation, and
which is found to be defective, will be repaired or replaced and returned to customer prepaid.
On the other hand, should a part be found not defective, inspection and handling charges may
be charged to the customer or Authorized Service Representative by EAGLE.

This warranty does not extend to the tires and batteries as these are warranted directly to the
user by their respective manufacturer and not by EAGLE or the Authorized Service
Representative.

SM

Warranty Information*

SM

Warranty covers only Eagle TT-series aircraft tractors manufactured after

Introduction

This warranty does not apply to any EAGLE tow tractor, or component part(s) that have been
subjected to misuse, accident or improper handling, maintenance or application; nor does it
extend to the EAGLE machine and/or parts which have been repaired or altered outside of
EAGLE's plant or the facility of an Authorized Service Representative.

This warranty does not apply to routine maintenance, ignition components, or wearable parts
of the EAGLE machine such as filters, seals, plugs, hoses, belts, brake pads, light bulbs, fuses
or similar items. Moreover, this warranty does not extend beyond its original term for any
EAGLE machine or part replaced or repaired under warranty.

EXCEPT AS SET FORTH ABOVE, ALL WARRANTIES, CONDITIONS, REPRESENTA­TIONS, INDEMNITIES AND GUARANTEES, EXPRESS OR IMPLIED, WHETHER ARISING
BY STATUTE, CUSTOM OF TRADE OR UNDER ORAL OR WRITTEN STATEMENTS MADE
BY OR ON BEHALF OF EAGLE NEGOTIATIONS WITH CUSTOMER, DISTRIBUTOR,
DEALER OR ANY REPRESENTATIVE, ARE HEREBY OVERWRITTEN AND EXCLUDED,
AND NO LIABILITY SHALL ATTACH TO EAGLE, EITHER IN CONTRACT OR IN TORT, OR
STRICT LIABILITY IN TORT, FOR ANY DAMAGE TO PROPERTY, LOSS OF PROFITS,
DAMAGES, COSTS, CHARGES, LIABILITY OR EXPENSES, WHETHER DIRECT OR INDI­RECT, CONSEQUENTIAL OR OTHERWISE, WHICH ARISE OUT OF OR IN CONNECTION
WITH THE SALE OR USE OF ANY EAGLE MACHINE OR THE SUPPLY OF SERVICES.

SUBJECT TO CHANGE WITHOUT NOTICE

*Note - The Threeagle
October 1, 2006. All TT-series manufactured prior to the date above, and all other Eagle Tugs
models, are covered under our Standard Warranty
are covered under Ford Motor Company's Standard Warranty for each respective Ford truck
model.

SM

Warranty covers only TT-series tow tractors manufactured after

of 1 Year or 2,000 hours. Eagle Bob Tails

3-3
