Dual LU-63PB, LU-563PW Owners Manual

LU63PB/PW

INSTALLATION/OWNER’S MANUAL

Indoor/Outdoor 3-Way Loudspeakers

®

®

LU63PB/PW INTRODUCTION

Introduction

Introduction

Important

Warranty Coverage

For Your Records

The Dual LU63 speakers are designed to deliver accurate high
fidelity sound in exterior or interior environments. Weather­resistant design and construction provide optimum durability
for permanent or temporary outdoor use.

The grilles are not designed or intended to be removed. Do
not remove the grilles from your speakers. There are no
user-serviceable parts behind the grille and removal will
damage the speaker.

You must have proof of purchase to receive warranty service.
Please keep your original sales receipt and be prepared to
provide this receipt in the event you require service.

Model

Dealer Name

Dealer Phone

Purchase Date

Note: You may want to keep your orginal sales receipt or a
photo copy with this installation/owner's manual.

2

LU63PB/PW PLACEMENT

Speaker Placement

®

Mounting Placement

Wall and Ceiling

Placement

Experiment for Better

Sound

Mounting both speakers on a common solid surface facing
the listening area will provide the best audio results.

Do NOT mount speakers on surfaces that have hazards
such as electrical wires or plumbing behind them. Be sure
that your mounting surface is capable of supporting the
weight of the speakers.

Mounting brackets are included for wall and ceiling
applications. The LU63 speakers have two standard 1/4-20
brass inserts incorporated into the rear of the enclosure for
aftermarket mounting systems.

We recommend that you take the time to experiment with
different speaker placements. Sound quality and imaging
are widely dependent on the location of your speakers as
well as room acoustics. Angling each speaker toward the
listening position often provides the most realistic imaging
experience. The amount of perceived bass increases as you
move a speaker closer to solid intersecting room surfaces
(wall, ceiling, floor).

3
