Dodge JS Avenger Sedan 2008, Avenger 2008 User Manual
2008
OWNER’S MANUAL
Avenger
VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name
Chrysler LLC shall be deemed to be deleted and the
name Chrysler Canada Inc. used in substitution therefor.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-drinking
driver, call a cab, a friend, or use public transportation.
WARNING!
Driving after drinking can lead to an accident. Your
perceptions are less sharp, your reflexes are slower,
and your judgment is impaired when you have been
drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or optional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
Chrysler LLC reserves the right to make changes in
design and specifications, and/or make additions to or
improvements to its products without imposing any
obligation upon itself to install them on products previously manufactured.
Copyright © 2007 Chrysler LLC
SECTION PAGE
1
INTRODUCTION
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
4
UNDERSTANDING YOUR INSTRUMENT PANEL
5
STARTING AND OPERATING
6
WHAT TO DO IN EMERGENCIES
7
MAINTAINING YOUR VEHICLE
8
MAINTENANCE SCHEDULES
9
IF YOU NEED CONSUMER ASSISTANCE
TABLE OF CONTENTS
.............................................................3
...............................9
...............................81
................................... 163
.................................................257
...............................................347
...............................................365
..................................................425
..........................................433
1
2
3
4
5
6
7
8
9
10
INDEX
....................................................................443
10
CONTENTS
INTRODUCTION
1
m Introduction ...........................4
m How To Use This Manual ..................4
m Warnings And Cautions ...................6
m Vehicle Identification Number ...............6
m Vehicle Modifications/Alterations ............7
4 INTRODUCTION
INTRODUCTION
This Owner’s Manual has been prepared with the assistance of service and engineering specialists to acquaint
you with the operation and maintenance of your vehicle.
It is supplemented by a Warranty Information Booklet
and various customer-oriented documents. You are
urged to read these publications carefully. Following the
instructions and recommendations in this manual will
help assure safe and enjoyable operation of your vehicle.
NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold, so that the new owner will be
aware of all safety warnings.
When it comes to service, rememberthat your authorized
dealer knows your vehicle best, has the factory-trained
technicians and genuine Mopart parts, and is interested
in your satisfaction.
HOW TO USE THIS MANUAL
Consult the table of contents to determine which section
contains the information you desire.
The detailed index, at the rear of this manual, contains a
complete listing of all subjects.
Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this owner manual:
INTRODUCTION 5
1
6 INTRODUCTION
WARNINGS AND CAUTIONS
This manual contains WARNINGS against operating
procedures that could result in an accident or bodily
injury. It also contains CAUTIONS against procedures
that could result in damage to your vehicle. If you do not
read this entire manual you may miss important information. Observe all Warnings and Cautions.
VEHICLE IDENTIFICATION NUMBER
The Vehicle Identification Number (VIN) is found on the
left front corner of the instrument panel, visible through
the windshield. This number also appears on the vehicle
registration and title.
Vehicle Identification Number
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to an accident resulting in serious injury or
death.
INTRODUCTION 7
1
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
m A Word About Your Keys ..................12
▫ Ignition Key Removal ...................12
▫ Key-In-Ignition Reminder ................14
▫ Locking Doors With The Key ..............14
m Sentry Keyt ...........................14
▫ Replacement Keys ......................16
▫ Customer Key Programming ..............16
▫ General Information ....................17
m Security Alarm System — If Equipped .........18
2
▫ Rearming The System ...................18
▫ To Arm The System .....................18
▫ To Disarm The System ...................19
m Illuminated Entry System — If Equipped .......20
m Remote Keyless Entry — If Equipped .........21
▫ To Unlock The Doors ...................22
▫ To Lock The Doors .....................24
▫ To Unlatch The Trunk ...................25
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
▫ Using The Express Down Windows Feature —
If Equipped ..........................25
▫ Using The Panic Alarm ..................25
▫ Programming Additional Transmitters ........26
▫ Battery Replacement ....................26
▫ General Information ....................27
m Remote Start System — If Equipped ..........28
▫ How To Use Remote Start ................29
m Door Locks ............................30
▫ Manual Door Locks .....................30
▫ Power Door Locks .....................32
▫ “Child-Protection” Door Lock System
(Rear Doors) ..........................34
m Power Windows ........................35
▫ Power Window Switches .................35
▫ Auto Window Down — If Equipped .........36
▫ Auto Window Up — If Equipped ...........37
▫ Reset Auto Up ........................37
▫ Window Lockout Switch .................38
▫ Wind Buffeting ........................38
m Trunk Release ..........................39
m Trunk Safety Warning.....................39
▫ Trunk Internal Emergency Release ..........40
m Occupant Restraints ......................40
▫ Lap/Shoulder Belts .....................42
▫ Adjustable Upper Shoulder Belt Anchorage ....47
▫ Rear Seat Belts ........................48
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
▫ Seat Belt Pretensioners ...................48
▫ Enhanced Seat Belt Reminder System
(BeltAlertt) ..........................48
▫ BeltAlertt Programming .................49
▫ Automatic Locking Mode ................50
▫ Seat Belts And Pregnant Women ............50
▫ Supplemental Restraint System (SRS) - Airbag . .51
▫ Airbag System Components ...............52
▫ Front Seat Airbag Features ................53
▫ Airbag Deployment Sensors And Controls .....59
▫ Event Data Recorder (EDR) ...............65
▫ Child Restraint ........................67
m Engine Break-In Recommendations ...........78
m Safety Tips ............................78
▫ Exhaust Gas ..........................78
▫ Safety Checks You Should Make Inside The
Vehicle ..............................79
▫ Periodic Safety Checks You Should Make
Outside The Vehicle ....................80
2
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
A WORD ABOUT YOUR KEYS
The dealer that sold you your new vehicle has the key
code numbers for your vehicle locks. These numbers can
be used to order duplicate keys from your dealer. Ask
your dealer for these numbers and keep them in a safe
place.
Vehicle Key
IGNITION KEY REMOVAL
Automatic Transaxle
Place the shift lever in PARK. Turn the ignition switch to
the ACC position, push the key and cylinder inward,
rotate the key to the LOCK position, and remove the key.
Ignition Key Positions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
NOTE:
•
If you try to remove the key before you place the
selector lever in PARK, the key may become trapped
temporarily in the ignition switch lock cylinder. If this
occurs, rotate the key to the right slightly, then remove
the key as described. If a malfunction occurs, the
system will trap the key in the ignition switch lock
cylinder to warn you that this safety feature is inoperable. The engine can be started and stopped, but the
key cannot be removed until you obtain service.
•
For vehicles not equipped with the Electronic Vehicle
Information Center (EVIC), the power window
switches, radio, hands–free system (if equipped), and
power outlets will remain active for approximately 45
seconds after theignitionswitch is turned to the LOCK
position. Opening either door will cancel this feature.
•
For vehicles equipped with the Electronic Vehicle
Information Center (EVIC), the power window
switches, radio, hands–free system (if equipped), and
power outlets will remain active for up to 10 minutes
after the ignition switch is turned to the LOCK posi-
tion. Opening either door will cancel this feature. The
time for this feature isprogrammable. For details, refer
to “Key-Off Power Delay,” under “Personal Settings
(Customer Programmable Features)” under “Elec-
tronic Vehicle Information Center (EVIC)” in Section 4
of this manual.
WARNING!
NEVER leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be seriously or fatally injured. Don’t leave the keys in the
ignition. A child could operate power windows,
other controls, or move the vehicle
2
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CAUTION!
An unlocked car is an invitation to thieves. Always
remove key from the ignition and lock all doors
when leaving the vehicle unattended.
KEY-IN-IGNITION REMINDER
Opening the driver’s door when the key is inthe ignition,
sounds a signal to remind you to remove the key.
NOTE:
•
The Key-In-Ignition reminder only sounds when the
ignition key is placed in the LOCK or ACC position.
•
With either front door open, and the key in the
ignition, both the power door locks and Remote Keyless Entry (RKE) will not function.
LOCKING DOORS WITH THE KEY
There is only one external door lock cylinder which is
located in the driver’s door only.
You can insert the key with either side up. To lock the
door, turn the key rearward, to unlock the door, turn the
key forward. See Section 7 of this manual for door lock
lubrication.
SENTRY KEYT
The Sentry Keyt Immobilizer System prevents unauthorized vehicle operation by disabling the engine. The
system does not needto be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked.
The system uses ignition keys that have an embedded
electronic chip (transponder) to prevent unauthorized
vehicle operation. Therefore, only keys that are programmed to the vehicle can be used to start and operate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
the vehicle. The system will shut the engine off in two
seconds if someone uses an invalid key to try to start the
engine.
NOTE: A key that has not been programmed is also
considered an invalid key, even if it is cut to fit the
ignition switch lock cylinder for that vehicle.
During normal operation, after turning on the ignition
switch, the Vehicle Security Light will turn on for three
seconds for a bulb check. If the light remains on after the
bulb check, it indicates that there is a problem with the
electronics. In addition, if the light begins to flash after
the bulb check, it indicates that someone used an invalid
key to try to start the engine. Either of these conditions
will result in the engine being shut off after two seconds.
If the Vehicle Security Light turns on during normal
vehicle operation (vehicle running for longer than 10
seconds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon
as possible.
NOTE:
•
The Sentry Keyt Immobilizer System is not compat-
ible with some aftermarket remote starting systems.
Use of these systems may result in vehicle starting
problems and loss of security protection.
•
Exxon/Mobil Speedpass™, additional Sentry Keyst,
or any other transponder-equipped components on
the same key chain will not cause a key-related
(transponder) fault unless the additional part is physi-
cally held against the ignition key being used when
starting the vehicle. Cell phones, pagers, or other RF
electronics will notcause interference with this system.
All of the keys provided with your new vehicle have
been programmed to the vehicle electronics.
2
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Replacement Keys
NOTE: Only keys that are programmed to the vehicle
electronics can be used to start and operate the vehicle.
Once a Sentry Keyt is programmed to a vehicle, it cannot
be programmed to any other vehicle.
CAUTION!
Always remove the Sentry Keyst from the vehicle
and lock all doors when leaving the vehicle
unattended.
At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of keys. Duplication of keys may be performed at an authorized
dealer or by following the customer key programming
procedure. This procedure consists of programming a
blank key to the vehicle electronics. A blank key is one
that has never been programmed.
NOTE: When having the Sentry Keyt Immobilizer
System serviced, bring all vehicle keys with you to an
authorized dealer.
Customer Key Programming
If you have two valid Sentry Keyst, you can program
new Sentry Keyst to the system by performing the
following procedure:
1. Cut the additional Sentry Keyt Transponder blank(s)
to match the ignition switch lock cylinder key code.
2. Insert the first valid key into the ignition switch. Turn
the ignition switch to the ON position for at least three
seconds, but no longer than 15 seconds. Then, turn the
ignition switch to the LOCKposition and remove the first
key.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
3. Insert the second valid key into the ignition switch.
Turn the ignition switch to the ON position within 15
seconds. After 10 seconds, a chime will sound. In addition, the Vehicle Security Light will begin to flash. Turn
the ignition switch to the LOCK position and remove the
second key.
4. Insert a blank Sentry Keyt into the ignition switch.
Turn the ignition switch to the ON position within 60
seconds. After 10 seconds, a single chime will sound. In
addition, the Vehicle Security Light will stop flashing. To
indicate that programming is complete, the Vehicle Security Light will turn on again for three seconds and then
turn off.
The new Sentry Keyt is programmed. The Remote
Keyless Entry (RKE) transmitter will also be programmed during this procedure.
Repeat this procedure to program up to eight keys. If you
do not have a programmed Sentry Keyt, contact your
authorized dealer for details.
NOTE: If a programmed key is lost, see your authorized
dealer to have all remaining keys erased from the system’s memory. This will prevent the lost key from
starting your vehicle. The remaining keys must then be
reprogrammed. All vehicle keys must be taken to an
authorized dealer at the time of service to be reprogrammed.
General Information
The Sentry Keyt system complies with FCC rules Part 15
and with RSS-210 of Industry Canada. Operation is
subject to the following conditions:
•
This device may not cause harmful interference.
2
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
•
This device must accept any interference that may be
received, including interference that may cause undesired operation.
SECURITY ALARM SYSTEM — IF EQUIPPED
The Vehicle Security Alarm (VSA) system monitors the
doors and trunk for unauthorized entry and ignition
switch for unauthorized operation.
If something triggers the alarm, the system will signal for
about 18 minutes. For the first 3 minutes, the horn will
sound intermittently and the headlights, park lights,
taillights and the Vehicle Security Light in the cluster will
flash. Then the exterior lights will flash for another 15
minutes.
REARMING THE SYSTEM:
If something triggers the alarm, and no action is taken to
disarm it, the system will turn off the horn after 3
minutes, turn off all of the visual signals after 15 minutes,
and then the system will rearm itself.
TO ARM THE SYSTEM:
1. Remove the keys from the ignition switch and get out
of the vehicle.
2. Lock the door using either the power door lock switch
or the Keyless Entry Transmitter, and close all doors.
3. The Vehicle Security Light in the instrument cluster
will flash rapidly for approximately 16 seconds. This
shows that the system is arming. During this period, if a
door is opened, the ignition switch is turned ON, or the
power door locks are unlocked in any manner,the system
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
will automatically disarm. After 16 seconds, the Vehicle
Security Light will flash slowly. This shows that the
system is fully armed.
NOTE:
•
During the 16 second arming period, if a door is
opened or the ignition switchis turned ON, the system
will automatically disarm.
•
Once armed, the system disables the unlock switch on
the driver door trim panel and passenger door trim
panel, the trunk release button on the instrument
panel, and the HomeLinkt/Garage Door Opener (if
equipped).
TO DISARM THE SYSTEM
Either press the UNLOCK button on the remote keyless
entry transmitter or insert a valid sentry key into the
ignition lock cylinder and turn the key to the ON/START
position.
NOTE:
•
The driver’s door key cylinderand the trunk button on
the keyless entry transmitter cannot arm or disarm the
system.
•
The system remains armed during trunk entry. Press-
ing the trunk button will not disarm the system. If
someone enters the vehicle through the trunk and
opens any door, the alarm will sound.
•
When the system is armed, the interior power door
lock switches will not unlock the doors.
The Vehicle Security Alarm system is designed to protect
your vehicle; however, you can create conditions where
the system will give you a false alarm. If one of the
previously described arming sequences has occurred, the
system will arm regardless of whether you are in the
vehicle or not. If you remain in the vehicle and open a
door, the alarm will sound. If this occurs, disarm the
system.
2
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
If the alarm system is armed and the battery becomes
disconnected the system will remain armed when the
battery is reconnected. The exterior lights will flash, the
horn will sound, and the ignition will not start the
vehicle. If this occurs, disarm the system.
Tamper Alert
If the alarm was triggered, but the warning signals have
timed out, the park and taillights flash three times
(instead of the normal twice) when unlocking the vehicle
with a valid Remote Keyless Entry (RKE) transmitter to
alert the driver.
ILLUMINATED ENTRY SYSTEM — IF EQUIPPED
The courtesy/reading lights will turn on when you use
the Remote Keyless Entry (RKE) transmitter or open
either door.
This feature also turns on the approach lighting (if so
equipped). For details, refer to “Illumination Approach,”
under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center
(EVIC)” in Section 4 of this manual.
The lights will fade to off after about 30 seconds or they
will immediately fade to off once the ignition switch is
turned on.
NOTE:
•
The front courtesy overhead console and door cour-
tesy lights do not turn on if the dimmer control is in
the interior lights ON position (extreme top position).
•
The illuminated entry system will not operate if the
dimmer control is in the “defeat” position (extreme
downward position).
REMOTE KEYLESS ENTRY — IF EQUIPPED
This system allows you to lock or unlock the doors, open
the trunk, or activate the PANIC alarm from distances a
maximum of 66 ft (20 m) using a hand-held radio
transmitter. The transmitter need not be pointed at the
vehicle to activate the system.
NOTE: The line of transmission must not be blocked
with metal objects.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2
Vehicle Key
NOTE: Inserting the key into the ignition switch dis-
ables all buttons on the transmitter.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
TO UNLOCK THE DOORS
Press and release the UNLOCK button on the transmitter
once to unlock the driver’s door, or twice to unlock all
doors. The turn signal lights will flash to acknowledge
the unlock signal. The illuminated entry system (if
equipped) will also turn on.
Remote Key Unlock, Driver Door/All Doors First
This feature lets you program the system to unlock either
the driver’s door or all doors on the first press of the
UNLOCK button on the transmitter. To change the current setting, proceed as follows:
•
For vehicles equipped with the Electronic Vehicle
Information Center (EVIC), refer to “Remote Key
Unlock,” under “Personal Settings (Customer Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual for
details.
•
For vehicles not equipped with the EVIC, perform the
following procedure:
1. Press and hold the LOCK button on a programmed
transmitter for at least four seconds, but not longer than
ten seconds. Then, press and hold the UNLOCK button
while still holding the LOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle, by
pressing the LOCK/UNLOCK buttons on the transmitter
with the ignition in the LOCK position, and the key
removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Pressing the LOCK button on the transmitter
while you are inside the vehicle will activate the Security
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
Alarm. Opening a door withthe Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
Flash Lights With Lock
The feature will cause the turn signal lights to flash when
the doors are locked or unlocked with the transmitter.
This feature can be turned on or turned off. To change the
current setting, proceed as follows:
•
For vehicles equipped with the Electronic Vehicle
Information Center (EVIC), refer to “Flash Lights with
Lock,” under 9Personal Settings (Customer Programmable Features)” under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual for
details.
•
For vehicles not equipped with the EVIC, perform the
following procedure:
1. Press and hold the UNLOCKbuttonon a programmed
transmitter for at least four seconds, but not longer than
ten seconds. Then, press and hold the LOCK button
while still holding the UNLOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle, by
pressing the LOCK/UNLOCK buttons on the transmitter
with the ignition in the LOCK position, and the key
removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Pressing the LOCK button on the transmitter
while you are in the vehicle will activate the Security
Alarm. Opening a door withthe Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
2
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Illuminated Approach — If Equipped
This feature activates the headlights for up to 90 seconds
when the doors are unlocked with the transmitter. The
time for this feature is programmable on vehicles
equipped with EVIC. For details, refer to “Illuminated
Approach,” under “Personal Settings (Customer Programmable Features), under “Electronic Vehicle Information Center (EVIC)” in Section 4 of this manual.
TO LOCK THE DOORS
Press and release the LOCK button on the transmitter to
lock all doors. The turn signal lights will flash and the
horn will chirp once to acknowledge the lock signal.
Sound Horn with Lock
This feature will cause the horn to chirp when the doors
are locked with the transmitter. This feature can be
turned on or off.To changethecurrent setting, proceed as
follows:
•
For vehicles equipped with EVIC, refer to “Sound
Horn with Lock,” under “Personal Settings (Customer
Programmable Features)” under “Electronic Vehicle
Information Center (EVIC)” in Section4of this manual
for details.
•
For vehicles not equipped with the EVIC, perform the
following steps:
1. Press the LOCK button on a programmed transmitter
for at least four seconds, but not longer than ten seconds.
Then, press the PANIC button while still holding the
LOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle, by
pressing the LOCK button on the transmitter with the
ignition in the LOCK position, and the key removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
NOTE: Pressing the LOCK button on the transmitter
while you are in the vehicle will activate the Security
Alarm. Opening a door withthe Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
TO UNLATCH THE TRUNK
Press the TRUNK button on the transmitter two times to
unlatch the trunk.
USING THE EXPRESS DOWN WINDOWS
FEATURE — IF EQUIPPED
This feature allows youtoremotely lower both front door
windows at the same time. To use this feature, press and
release the UNLOCK button on the transmitter and then
immediately press and hold the UNLOCK button until
the windows lower to the level desired or until they
lower completely.
USING THE PANIC ALARM
To turn the PANIC alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the PANIC alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off, and the illuminated entry system (if
equipped) will turn on.
The PANIC alarm will stay on for three minutes unless
you turn it off by pressing the PANIC button a second
time or if the vehicle speed is 5 mph (8 km/h) or greater.
NOTE: You may need to be close to the vehicle when
using the transmitter to turn off the PANIC alarm due to
the radio frequency noises emitted by the system.
2
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
PROGRAMMING ADDITIONAL TRANSMITTERS
Refer to SENTRY KEYt “Sentry Keyt Programming.”
If you do not have a programmed transmitter, contact
your authorized dealer for details.
BATTERY REPLACEMENT
The recommended replacement battery is CR2032.
NOTE:
Perchlorate Material — special handling may
apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
1. With the transmitter buttons facing down, use a flat
blade to pry thetwo halves of the transmitter apart. Make
sure not to damage the seal during removal.
Separating Transmitter Halves
2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. To assemble the transmitter case, snap the two halves
together.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
GENERAL INFORMATION
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE: Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
If your Remote Lock Control fails to operate from a
normal distance, check for these two conditions.
1. Weak batteries in the transmitter. The expected life of
batteries is five years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, militarybase,and some mobile
or CB radios.
2
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
REMOTE START SYSTEM — IF EQUIPPED
Remote start conveniently starts the engine from outside
the vehicle by using the Remote Keyless Entry (RKE) key
fob while maintaining security. The system has a targeted
range of up to 328 ft (100 m). The vehicle must be locked,
the deck lid and hood closed and the transmission gear
selector lever in PARK in order to start the engine using
the Remote Start button on the key fob.
Remote Start
NOTE: Remote start requires automatic transaxle
equipped vehicles.
Loading...
