Version 1.0 | 11/11/2013

User Manual

Wireless AC750 Dual Band Cloud Router

DIR-816L

Preface

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes.

Manual Revisions

Revision Date Description

1.0 November 11, 2013 • Initial release for Revision A1

Trademarks

D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.

iD-Link DIR-816L User Manual

Table of Contents

Package Contents ......................................................................... 1

System Requirements ................................................................. 2

Introduction ...................................................................................3

Features ............................................................................................4

Hardware Overview ..................................................................... 5

Connections ...........................................................................5

LEDs ........................................................................................... 6

Installation .........................................................................7

Before you Begin ...........................................................................7

Wireless Installation Considerations ......................................8

Manual Setup ................................................................................. 9

Conguration ...................................................................11

Quick Setup Wizard ....................................................................12

QRS Mobile App ..........................................................................19

mydlink Shareport...........................................................20

Using the mydlink SharePort™ app for iPad®, iPhone®,

and iPod Touch® ..........................................................................20

Main Menu ............................................................................24

Documents ............................................................................25

Pictures ...................................................................................27

Videos .....................................................................................29

Music .......................................................................................31

Folders ....................................................................................34

Favorites .................................................................................37

Using the mydlink SharePort™ app for Android™ ...........38

Main Menu ............................................................................42

Documents ............................................................................43

Pictures ...................................................................................45

Videos .....................................................................................47

Music .......................................................................................49

Folders ....................................................................................52

Favorites .................................................................................56

Conguration ...................................................................57

Web-based Conguration Utility ..........................................57

Internet Connection Setup .............................................58

Internet Connection Setup Wizard ...............................59

Internet (Manual) ................................................................65

Static (assigned by ISP) ................................................67

PPPoE (DSL) ......................................................................68

PPTP ....................................................................................70

L2TP ....................................................................................72

DS-Lite ...............................................................................74

Wireless connection setup wizard ................................75

Wi-Fi Protected Setup Wizard .........................................78

Manual wireless network setup .....................................79

Wireless Security .................................................................88

What is WPA? ...................................................................88

Network Settings ................................................................89

Router Settings ...............................................................89

DHCP Server Settings ...................................................90

DHCP Reservation .........................................................92

iiD-Link DIR-816L User Manual

Table of Contents

Storage ...................................................................................93

Media Server.........................................................................96

IPv6 ..........................................................................................97

IPv6 Internet Connection Setup Wizard ................99

IPv6 Manual Setup...................................................... 104

mydlink Settings .............................................................. 114

Advanced ............................................................................ 117

Virtual Server ................................................................117

Port Forwarding .......................................................... 118

Application Rules ........................................................ 119

QoS Engine .................................................................... 120

Network Filters ............................................................. 122

Inbound Filters ............................................................. 123

Access Control .............................................................. 124

Website Filters .............................................................. 127

Firewall Settings .......................................................... 128

Routing ........................................................................... 130

Advanced Wireless .....................................................131

Wi-Fi Protected Setup (WPS) .................................. 132

Advanced Network Settings ................................... 134

Guest Zone .................................................................... 135

IPv6 Firewall ..................................................................136

IPv6 Routing .................................................................137

Tools .....................................................................................138

Admin.............................................................................. 138

Time ................................................................................. 140

SysLog .............................................................................141

Email Settings............................................................... 142

System ............................................................................143

Firmware ........................................................................ 144

Language Pack ............................................................. 144

Dynamic DNS ...............................................................145

System Check ............................................................... 146

Schedules ...................................................................... 147

Status ...................................................................................148

Device Info ....................................................................148

Logs..................................................................................149

Statistics ......................................................................... 150

Internet Sessions ......................................................... 151

Wireless...........................................................................152

Routing ........................................................................... 153

IPv6 ..................................................................................154

IPV6 Routing ................................................................. 155

Support ............................................................................... 156

Connect a Wireless Client to your Router ....................157

WPS Button ................................................................................ 157

Windows® 8 ................................................................................158

WPA/WPA2 ......................................................................... 158

Windows® 7 ................................................................................160

WPA/WPA2 ......................................................................... 160

WPS ....................................................................................... 163

Windows Vista® ......................................................................... 167

WPA/WPA2 ......................................................................... 168

WPS/WCN 2.0 ....................................................................170

Windows® XP ............................................................................. 171

WPA/WPA2 ......................................................................... 172

iiiD-Link DIR-816L User Manual

Table of Contents

Troubleshooting ............................................................174

Wireless Basics ...............................................................178

What is Wireless? ...................................................................... 179

Tips ................................................................................................ 181

Wireless Modes ......................................................................... 182

Networking Basics .........................................................183

Check your IP address ............................................................183

Statically Assign an IP address ............................................ 184

Technical Specications ................................................185

ivD-Link DIR-816L User Manual

Section 1 - Product Overview

DIR-816L Wireless AC750 Dual Band Cloud Router

Ethernet Cable

Power Adapter

Package Contents

Wi-Fi Conguration Note

WI-FI Conguration Note

If any of the above items are missing, please contact your reseller.

Note: Using a power supply with a dierent voltage rating than the one included with the DIR-816L will cause damage and void the warranty for this product.

1D-Link DIR-816L User Manual

Section 1 - Product Overview

Network Requirements

Web-based Conguration

Utility Requirements

System Requirements

• An Ethernet-based cable or DSL modem

• IEEE 802.11ac, 802.11a, 802.11n or 802.11g wireless clients

• 10/100 Ethernet

Computer with the following:

• Windows®, Macintosh, or Linux-based operating system

• An installed Ethernet adapter

Browser Requirements:

• Internet Explorer 7 or higher

• Firefox 3.5 or higher

• Safari 4 or higher

• Chrome 8 or higher

mydlink Requirements

Windows

installed. Visit www.java.com to download the latest version.

• iPhone®/iPad®/iPod Touch® (iOS 3.0 or higher)

• Android™ device (1.6 or higher)

• Computer with the following browser requirements:

iPhone, iPad, and iPod touch are registered trademarks of Apple Inc. Android is a trademark of Google, Inc.

Users: Make sure you have the latest version of Java

• Internet Explorer 7 or higher

• Firefox 3 or higher

• Safari 5 or higher

• Chrome 5 or higher

2D-Link DIR-816L User Manual

Section 1 - Product Overview

Introduction

Now you can monitor and manage your home network right from your laptop, iPhone®, iPad®, or Android™ device. The cloudenabled router can be congured to send an email to keep you informed anywhere, anytime when new devices are connecting to your network or unwanted access is detected. Monitor in realtime websites that are being visited with recent browser history displayed on the mydlink™ Lite app – which is great for parents. The D-Link Cloud Service can detect and block unwelcomed guests who try to get into your wireless network and suspicious activities will be displayed right on your mydlink™ Lite app or browser.

The D-Link DIR-816L is a IEEE 802.11ac compliant device that delivers up to 3 times faster speeds than 802.11n while staying backward compatible with 802.11a/g/b devices. Connect the DIR-816L to a cable or DSL modem and provide high-speed Internet access to multiple computers, game consoles, and media players. Create a secure wireless network to share photos, les, music, videos, printers, and network storage. Powered by the 802.11ac technology and equipped with an external antenna, this router provides great wireless coverage for larger homes and oces, or for users running bandwidth-intensive applications. The DIR-816L also includes a 4-port 10/100 Fast Ethernet switch that connects wired devices for enjoying lag-free network gaming and faster le transfers.

With some routers, all wired and wireless trac, including VoIP, video streaming, online gaming, and web browsing are mixed together into a single data stream. By handling data this way, applications like video streaming could pause or delay. With the D-Link Intelligent QoS Technology, wired and wireless trac are analyzed and separated into multiple data streams.

The DIR-816L supports the latest wireless security features to help prevent unauthorized access, be it from over a wireless network or the Internet. Support for WPA and WPA2 standards ensure that you will be able to use the best possible encryption regardless of your client devices. In addition, this router utilizes dual active rewalls (SPI and NAT) to prevent potential attacks from across the Internet for the ideal centerpiece for your wireless network in the home or oce.

3D-Link DIR-816L User Manual

Section 1 - Product Overview

• Ultimate Fast Wireless Networking - The DIR-816L provides up to 300 Mbps wireless connection in the

2.4 GHz band, and 433 Mbps wireless connection in the 5 GHz band with other draft 802.11ac and 802.11n wireless clients. This capability allows users to participate in real-time activities online, such as video streaming, online gaming, and real-time audio. The performance of this 802.11ac wireless router gives you the freedom of wireless networking at speeds 3x faster than 802.11n.

• Compatible with 802.11a/g/n Devices - The DIR-816L is still fully compatible with the IEEE 802.11a, 802.11g and 802.11n, so it can connect with existing 802.11a, 802.11g and 802.11n PCI, USB, and CardBus adapters.

• Advanced Firewall Features - The Web-based user interface displays a number of advanced network management features including:

• Content Filtering - Easily applied content ltering based on MAC address, URL, and/or domain name.

Features

• Filter Scheduling - These lters can be scheduled to be active on certain days or for a duration of hours or minutes.

• Secure Multiple/Concurrent Sessions - The DIR-816L can pass through VPN sessions. It supports multiple and concurrent IPSec and PPTP sessions, so users behind the DIR-816L can securely access corporate networks.

• User-friendly Setup Wizard - Through its easy-to-use web-based user interface, the DIR-816L lets you control what information is accessible to those on the wireless network, whether from the Internet or from your company’s server. Congure your router to your specic settings within minutes.

* Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, 802.11n and draft 802.11ac specications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network trac, building materials and construction, and network overhead, lower actual data throughput rate. Environmental conditions will adversely aect wireless signal range.

4D-Link DIR-816L User Manual

Section 1 - Product Overview

Hardware Overview

Connections

3 4 5 6 7

1 USB Port Connect a USB ash drive to share content throughout your network.

2 WPS Button Press to start the WPS process. The Internet LED will start to blink.

3 LAN Ports (1-4) Connect 10/100 Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.

4 Internet Port Using an Ethernet cable, connect your broadband modem to this port.

5 Reset Button Insert a paperclip in the hole and wait for 10 seconds to reset the router to default settings.

6 Power Button Press the power button to power on and o.

7 Power Receptor Receptor for the supplied power adapter.

5D-Link DIR-816L User Manual

Section 1 - Product Overview

Hardware Overview

LEDs

1 3 4

1 Power LED

2 Internet LED A solid light indicates connection on the Internet port.

3 Wi-Fi LED A green light indicates that Wi-Fi is active and available.

4 LAN Port LED A solid green light indicates that an Ethernet connection is established.

A solid green light indicates a proper connection to the power supply. The light will blink green during the WPS process.

6D-Link DIR-816L User Manual

Section 2 - Installation

Installation

This section will walk you through the installation process. Placement of the router is very important. Do not place the router in an enclosed area such as a closet, cabinet, or in the attic or garage.

Before you Begin

• Please congure the router with the computer that was last connected directly to your modem.

• You can only use the Ethernet port on your modem. If you were using the USB connection before using the router, then you must turn o your modem, disconnect the USB cable and connect an Ethernet cable to the Internet port on the router, and then turn the modem back on. In some cases, you may need to call your ISP to change connection types (USB to Ethernet).

• If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoET, BroadJump, or EnterNet 300 from your computer or you will not be able to connect to the Internet.

7D-Link DIR-816L User Manual

Section 2 - Installation

Wireless Installation Considerations

The D-Link wireless router lets you access your network using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:

1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum -

each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle

appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.

3. Building materials make a dierence. A solid metal door or aluminum studs may have a negative eect on range.

Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.

4. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF

noise.

5. If you are using 2.4 GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security

systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4 GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.

8D-Link DIR-816L User Manual

Section 2 - Installation

Manual Setup

1. Turn o and unplug your cable or DSL broadband modem. This is required.

Modem

2. Position your router close to your modem and a computer. Place the router in an open area of your intended

work area for better wireless coverage.

3. Unplug the Ethernet cable from your modem (or existing router if upgrading) that is connected to your computer.

Plug it into the LAN port labeled 1 on the back of your router. The router is now connected to your computer.

Computer

DIR-816L

9D-Link DIR-816L User Manual

Section 2 - Installation

4. Plug one end of the included blue Ethernet cable that came with your router into the yellow port labeled

INTERNET on the back of the router. Plug the other end of this cable into the Ethernet port on your modem.

Computer

DIR-816L

Modem

INTERNET

5. Reconnect the power adapter to your cable or DSL broadband modem and wait for two minutes.

6. Connect the supplied power adapter into the power port on the back of the router and then plug it into a power

outlet or surge protector. Press the power button and verify that the power LED is lit. Allow 1 minute for the router to boot up.

Computer

DIR-816L

Modem

INTERNET

7. If you are connecting to a broadband service that uses a dynamic connection (not PPPoE), you may be online

already. Try opening a web browser and enter a web site. If a solid light indicates connection on the Internet port and the router can connect to the Internet.

10D-Link DIR-816L User Manual

Section 3 - Conguration

Conguration

There are several dierent ways you can congure your router to connect to the Internet and connect to your clients:

• D-Link Setup Wizard - This wizard will launch when you log into the router for the rst time. Refer to page 12.

• QRS Mobile App - Use your iPhone, iPad, or iPod Touch to congure your router. Refer to page 19.

• Manual Setup - Log into the router and manually congure your router (advanced users only). Refer to page 58.

11D-Link DIR-816L User Manual

Section 3 - Conguration

Quick Setup Wizard

If this is your first time installing the router, open your web browser. You will automatically be directed to the

Wizard Setup Screen. If not, enter “http://dlinkrouter or http://dlinkrouter.local. in the address bar”. Then, press Enter.

If you have already congured your settings and you would like to access the conguration utility, please refer to page 57.

If this is your rst time logging into the router, this wizard will start automatically.

This wizard is designed to guide you through a step-by-step process to congure your new D-Link router and connect to the Internet.

Click Next to continue.

Please wait while your router detects your internet connection type. If the router detects your Internet connection, you may need to enter your ISP information such as username and password.

12D-Link DIR-816L User Manual

Section 3 - Conguration

If the router does not detect a valid Ethernet connection from the Internet port, this screen will appear. Connect your broadband modem to the Internet port and then click Try Again.

If the router detects an Ethernet connection but does not detect the type of Internet connection you have, this screen will appear. Click Guide me through the Internet Connection Settings to display a list of connection types to choose from.

Select your Internet connection type and click Next to continue.

13D-Link DIR-816L User Manual

Section 3 - Conguration

If the router detected or you selected PPPoE, enter your PPPoE username and password and click Next to continue.

Note: Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.

If the router detected or you selected PPTP, enter your PPTP username, password, and other information supplied by your ISP. Click Next to continue.

If the router detected or you selected L2TP, enter your L2TP username, password, and other information supplied by your ISP. Click Next to continue.

14D-Link DIR-816L User Manual

Section 3 - Conguration

If the router detected or you selected Static, enter the IP and DNS settings supplied by your ISP. Click Next to continue.

For both the 2.4 GHz and 5 GHz segments, create a Wi-Fi network name (SSID) using up to 32 characters.

Create a Wi-Fi password (between 8-63 characters). Your wireless clients will need to have this passphrase or key entered to be able to connect to your wireless network.

Click Next to continue.

In order to secure your router, please enter a new password. Check the Enable Graphical Authentication box to enable CAPTCHA authentication for added security. Click Next to continue.

15D-Link DIR-816L User Manual

Section 3 - Conguration

Select your time zone from the drop-down menu and click Next to continue.

The Setup Complete window will display your Wi-Fi settings. Click Next to continue.

If you want to create a bookmark to the router, click OK. Click Cancel if you do not want to create a bookmark.

If you clicked Yes, a window may appear (depending on what web browser you are using) to create a bookmark.

16D-Link DIR-816L User Manual

Section 3 - Conguration

To use the mydlink service (mydlink.com or the mydlink Lite app), you must have an account. Select if you do have a mydlink account or if you need to create one. Click Next to continue.

If you do not want to register at this time, click Cancel.

If you clicked Yes, enter your mydlink account name (email address) and password. Click Login to register your router.

If you clicked No, ll out the requested information and click Sign Up to create your mydlink account.

17D-Link DIR-816L User Manual

Section 3 - Conguration

The mydlink App will allow you to receive notices, browse network users, and congure your router from an iPhone/iPad/iPod Touch (iOS 3.0 or higher), Android device (1.6 or higher).

To download the "mydlink Lite" app, visit the Apple Store, Android Market or http://mydlink.com/Lite.

PC and Mac users can use the mydlink portal at http://mydlink.com.

18D-Link DIR-816L User Manual

Section 3 - Conguration

QRS Mobile App

QRS Mobile app allows you to install and congure your router from your mobile device.

Step 1

Search for the free QRS Mobile App on the iTunes Store or Google Play.

For the iTunes Store, you may also scan this code to download.

Step 2

Once your app is installed, you may now congure your router. Connect to the router wirelessly by going to your wireless utility on your device. Scan for the Wi-Fi name (SSID) as listed on the supplied info card. Select and then enter your Wi-Fi password.

Step 3

Once you connect to the router, launch the QRS mobile app and it will guide you through the installation of your router.

For Google Play, you may also scan this code to download.

19D-Link DIR-816L User Manual

Section 3 - Conguration

mydlink Shareport

Using the mydlink SharePort™ app for iPad®, iPhone®,

and iPod Touch®

The mydlink SharePort™ app is a streamlined mobile application that allows you to conveniently stream media and share les stored on a removable storage connected to your router. Once the router is set up, you can start the app and easily connect from a local network or through the Internet to access your photos, videos, music, and documents. It allows you to create your own personal cloud storage; you can upload les and photos from your mobile device to the removable storage via the app from anywhere in the world!

Note: In order to ensure smooth streaming performance, you will need a minimum of 2 Mbit/s upload bandwidth for your router’s Internet connection.

Streaming performance will vary depending on the quality of your Internet connection.

Note: If you choose to skip the mydlink Shareport registration during the initial setup of your DIR-816L, you may begin the registration process

anytime by accessing the mydlink Shareport feature from within the router conguration. Please see “mydlink Settings” on page 114 for details on how to begin the mydlink shareport registration process.

1. If you are connecting remotely through the mydlink SharePort™ app from the Internet, you will need a mydlink account.

2. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.

Note: If you connect a removable storage with many les or a large capacity, it

may take a while for the router to scan and catalog your les.

USB drive

20D-Link DIR-816L User Manual

Section 3 - Conguration

3. Use your iPhone, iPad or iPod Touch to search for and download the free mydlink SharePort™ app from the App Store.

If you have a QR code reader, you can scan the code for mydlink SharePort™ to the right.

4. On your mobile device, go to your Wi-Fi settings and connect to your router’s wireless network using the default Wi-Fi settings. Your Wi-Fi network details can be found on the included Wi-Fi conguration card included with your router, or on the bottom of the router.

21D-Link DIR-816L User Manual

Section 3 - Conguration

5. Once connected, tap the mydlink SharePort™ icon, and the app will load.

6. At the login page, you can tap Help? to see diagrams with descriptions of the two types of connections available.

Local Access:

Local mode will connect you to storage on your current network. For example, if you are at home connecting to your router, choose this mode.

Remote Access:

Remote mode will connect you to storage on your router in a dierent location. For example, you are at your oce connecting to your router at home.

If you are directly connected to the DIR-816L’s wireless network, tap Local Access and enter the Admin Password of your router, then tap Log In.

If you are connecting through the Internet tap Remote Access and

enter your mydlink login information, then tap Log In. Tap on your router on the devices page that appears. You can now share your les.

If you are unsure about which connection method to choose, you can just click Remote Access.

After logging in, select your router from the device list.

22D-Link DIR-816L User Manual

Section 3 - Conguration

7. You can now use the mydlink SharePort™ app interface to stream media and access les stored on your removable drive. The wireless icon at the bottom will be lit blue to indicate a Local Access connection. It will be green to indicate you are connected to the router through Remote Access.

Note: If you see a red wireless icon, your router’s network environment may not

be suitable for a direct network connection and you may experience slow network speeds.

23D-Link DIR-816L User Manual

Section 3 - Conguration

Main Menu

The mydlink SharePort main menu has dierent sections that let you see all the documents, photos, movies, or music stored on your removable storage. Tap < or >, or swipe left or right to move between the dierent sections. The Wi-Fi icon at the bottom indicates an active local network connection (blue) or remote connection (green/red). Tap Log In if it is not lit, or Log Out to return to the login page.

Tap on the document icon to view documents.

Tap the camera icon to view photos.

Tap on the movie icon to play videos.

Tap on the music icon to play audio les.

Tap on the folder icon to browse all les in a folder view.

Tap on the star icon to access your favorite les.

24D-Link DIR-816L User Manual

Section 3 - Conguration

Documents

The Documents section allows you to share, print, and view documents streamed from your DIR-816L to your mobile device. Tap the document icon on the main menu to browse the documents on your mobile device.

Search Bar:

Enter a lename here to search your storage.

Tap to mark les for deletion.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tapping this icon gives you additional options:

• Mail: Tap to e-mail the le.

• iCloud: Tap to store the le on iCloud.

• AirPrint: Tap to print the le.

• Open In...: Tap to use a third-party app to open the le.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to update the list of les.

Tap to reorder the les alphabetically.

25D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start the document viewer. In the viewer:

Tap to add/remove the le from your Favorites.

Tap to bring up the same options as >.

Note: Some les may require a third-party app to view them.

26D-Link DIR-816L User Manual

Section 3 - Conguration

Pictures

The Pictures section allows you to stream images from your DIR-816L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage.

Search Bar:

Enter a lename here to search your storage.

Tap to mark les for deletion.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tapping this icon gives you additional options:

• Mail: Tap to e-mail the image.

• iCloud: Tap to store the image on iCloud.

• AirPrint: Tap to print the image.

• Facebook: Tap to upload the image to your Facebook account.

• Twitter: Tap to upload the image to your Twitter account.

• Open In...: Tap to use a third-party app to open the le.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to start a slideshow of your photos. Tap the screen again to bring up the menu.

Tap to update the list of les.

Tap to reorder the les alphabetically.

27D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start the photo viewer. In the viewer:

Tap to add/remove the current image from your Favorites.

Tap to start the slideshow.

Tap to bring up the same options as >.

28D-Link DIR-816L User Manual

Section 3 - Conguration

Videos

The Videos section allows you to stream video clips and movies from your DIR-816L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage.

Search Bar:

Enter a lename here to search for a specic le.

Tap to mark les for deletion.

Tap the star icon next to a le to download it to your device and add it into your Favorites section.

Tapping this icon gives you additional options:

• Mail: Lets you e-mail the le.

• iCloud: Lets you store the le on iCloud.

• Open In...: Lets you use a third-party app to open the le.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to update the list of les.

Tap to reorder the les alphabetically.

29D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start playing it. In the player:

Tap to play/pause the video. You can scroll to any time on the time line by holding and sliding your nger.

Tap to enter/exit fullscreen mode.

Tap to add/remove the le from your Favorites.

Tapping this icon gives you additional options:

• Mail: Lets you e-mail the video.

• iCloud: Lets you store the video on iCloud.

• Open In...: Lets you use a third-party app to open the le.

30D-Link DIR-816L User Manual

Section 3 - Conguration

Music

The Music section allows you to stream songs from your DIR-816L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage.

Search Bar:

Enter a lename here to search your storage.

Tap to create a playlist and mark les for deletion.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tapping this icon gives you additional options:

• Mail: Lets you e-mail the le.

• iCloud: Lets you store the le on iCloud.

• Open In...: Lets you use a third-party app to open the le.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to update the list of les.

Tap to reorder the les alphabetically.

31D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start playing it. In the player:

Tap to repeat all. Tap again to repeat a single song.

Tap to skip to the previous/next song.

Tap to enable/disable shue mode.

To create a playlist:

Tap Edit > Add Playlist.

Enter a name for the playlist, then tap Save.

The name of the playlist will appear in the browser next

to the

icon.

32D-Link DIR-816L User Manual

Section 3 - Conguration

To add songs to a playlist:

Tap the playlist in the browser. Tap Add Music... to add songs to the current playlist. Tick the songs you wish to add and tap Done.

To delete songs from the playlist:

Tap Edit in the playlist browser and mark the les to be

deleted.

Tap Delete.

33D-Link DIR-816L User Manual

Section 3 - Conguration

Folders

You can browse your removable storage in a folder view in the folders section. Tapping the lename will open the viewer/player for that le type as described in the previous pages. You can also upload les from your mobile device to the removable storage attached to your router.

Search Bar:

Enter a lename here to search your storage.

Tap to take you to the editing screen where you can add a folder and mark les for deletion or copying.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tapping the > icon gives you additional options depending on the le type.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to upload les from your device to your removable storage.

Tap to update the list of les.

Tap to reorder the les alphabetically.

34D-Link DIR-816L User Manual

Section 3 - Conguration

To delete les:

Tap Edit at the top right. Tick the circle next to a le to mark it for deletion. Tap on Delete at the bottom to delete the le.

To copy les:

Tap on Copy to bring up a window where you can select

the folder to copy to.

Browse to the directory you want to copy the marked

les to and tap Paste.

You can also tap Add Folder to create a new folder.

To create a new folder:

Browse to the directory you wish to create a new folder in. Tap Edit at the top right. Tap Add Folder to add a new folder. Enter the name of the new folder, then tap Save. Tap OK to conrm folder creation.

35D-Link DIR-816L User Manual

Section 3 - Conguration

To upload images and videos from your mobile device:

Browse to the folder you wish to upload to. Tap Upload at the bottom. Select the photos/videos you wish to upload. Tap Done.

During the upload process, the size of the le and the upload progress will be displayed.

To upload more les, tap the + icon at the top right and repeat the steps listed above.

36D-Link DIR-816L User Manual

Section 3 - Conguration

Favorites

The Favorites section allows you to quickly access your most often used les, no matter what le type, in a special section. Files added to the Favorites section will be copied here for playback in a centralized location.

Tap to mark les for deletion from the local storage in Favorites. The le will still be accessible in other mydlink SharePort sections.

Tapping this icon gives you additional options depending on the le type.

The bottom menu bar includes these options:

Tap to go back to the main menu.

Tap to update the list of les.

Tap to reorder the les alphabetically.

Tap on a le to start the le viewer. In the viewer:

Tap to add/remove the le from your Favorites.

Tap to bring up additional options.

Note: The le options available will vary depending on the le type.

37D-Link DIR-816L User Manual

Section 3 - Conguration

Using the mydlink SharePort™ app for Android™

Note: In order to ensure smooth streaming performance, you will need a minimum of 2 Mbit/s upload bandwidth for your router’s Internet connection.

Streaming performance will vary depending on the quality of your Internet connection.

1. If you are connecting remotely through the mydlink SharePort™ app from the Internet, you will need a mydlink account.

2. Make sure the device is powered on. Then plug your USB drive into the USB port of the device.

Note: If you connect a removable storage with many les or a large capacity, it

may take a while for the router to scan and catalog your les.

USB drive

38D-Link DIR-816L User Manual

Section 3 - Conguration

3. Use your Android mobile device to search for and download the free mydlink SharePort™ app from Google Play™.

If you have a QR code reader, you can scan the code for mydlink

SharePort™ to the right.

39D-Link DIR-816L User Manual

Section 3 - Conguration

5. Once connected, tap the mydlink SharePort™ icon, and the app will load.

6. At the login page:

You can tap ? to see diagrams with descriptions of the two types of connections available.

If you are unsure about which connection method to choose, you can just click Remote Access.

Local Access:

Local mode will connect you to storage on your current network. For example, if you are at home connecting to your router, choose this mode.

Remote Access:

Remote mode will connect you to storage on your router in a dierent location. For example, you are at your oce connecting to your router at home.

40D-Link DIR-816L User Manual

Section 3 - Conguration

If you are directly connected to the DIR-816L’s wireless network, tap Local Access and enter the Admin Password of your router, then tap Log In.

If you are connecting through the Internet tap Remote Access and enter your mydlink login information, then tap Log In. Tap on your router on the devices page that appears.

You can now share your les.

After logging in, select your router from the device list.

7. You can use the mydlink SharePort™ app interface to stream media and access les stored on your removable drive.

The wireless icon at the bottom will be lit blue to indicate a Local Access connection. It will be green to indicate you are connected to the router through Remote Access.

Note: If you see a red wireless icon, your router’s network environment may not

be suitable for a direct network connection and you may experience slow network speeds.

41D-Link DIR-816L User Manual

Section 3 - Conguration

Main Menu

Tap on the document icon to view documents.

Tap the camera icon to view pictures.

Tap on the movie icon to play videos.

Tap on the music icon to play audio les.

Tap on the folder icon to browse all les in a folder view.

Tap on the star icon to access your favorite les.

Note: Available features may dier depending on the Android OS version

of your device.

42D-Link DIR-816L User Manual

Section 3 - Conguration

Documents

The Documents section allows you to share, print, and view documents streamed from your DIR-816L to your mobile device. Tap the document icon on the main menu to browse the les on your mobile device.

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to refresh, sort, or mark les for deletion.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tap for additional options:

Tap to return to the main menu.

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Check a le then tap to delete it.

43D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start the document viewer. In the viewer:

Tap the screen to bring up zoom in/out buttons. Drag the screen up or down to scroll between pages. Tap

to perform File, Find, Zoom, Reading View, Go To

Page, and Bookmarks actions.

Note: Available actions may dier depending on your Android OS.

44D-Link DIR-816L User Manual

Section 3 - Conguration

Pictures

The Pictures section allows you to view images streamed from your DIR-816L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage.

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to start a slideshow.

Tap to refresh, sort, or mark les for deletion.

Tap the star icon next to each le to download it to your device and add it into your Favorites section.

Tap for additional options:

Tap to return to the main menu.

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Check a le then tap to delete it.

45D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on an image le to start the image viewer. In the viewer:

Tap the star icon to download it to your device and add it into your Favorites section.

Tap to start a slideshow. Tap the image to stop the slideshow.

Tap to delete the current image. Tap OK to conrm.

Tap to bring up additional options using other applications.

Tap to access the image editor.

Note: This function may vary depending on the version of your

Android OS.

46D-Link DIR-816L User Manual

Section 3 - Conguration

Videos

The Videos section allows you to stream video clips and movies from your DIR-816L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage.

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to refresh, sort, or mark les for deletion.

Tap the star icon next to a le to download it to your device and add it into your Favorites section.

Tap for additional options:

Tap to return to the main menu.

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Check a le then tap this icon to delete it.

47D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start playing it. Tap on the screen to bring up the scroll bar, pause button, and play button.

Tap to resume playback.

Tap to pause the video.

Note: Available features may vary depending on the Android OS version installed

on your device.

48D-Link DIR-816L User Manual

Section 3 - Conguration

Music

The Music section allows you to stream songs from your DIR-816L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage.

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to refresh, sort, or mark les for deletion.

Tap to browse your playlists.

Tap the star icon next to a le to download it to your device and add it into your Favorites section.

Tap for additional options:

Tap to return to the main menu.

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Check a le then tap this icon to delete it.

49D-Link DIR-816L User Manual

Section 3 - Conguration

Tap on a le to start playing it. In the player:

Tap on the up/down arrow to show/hide the player controls.

Tap to repeat all. Tap again to repeat a single song.

Tap to skip to the previous/next song.

Tap to play or pause the song.

Tap to enable/disable shue mode.

To create a playlist:

Tap Tap Add new playlist... Enter a name for the playlist, then tap OK. The name of the

playlist will appear in the browser next to the

You can tap

then to refresh the playlist page.

icon.

50D-Link DIR-816L User Manual

Section 3 - Conguration

To add songs to a playlist:

Tap a playlist to see its contents. Tap Add Music... to add songs to the current playlist. Tick the songs you wish to add and tap

To delete songs from the playlist:

Tap Edit in the playlist browser and mark the les to be

deleted.

Tap

then tap OK to conrm.

to save.

51D-Link DIR-816L User Manual

Section 3 - Conguration

Folders

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to access le options.

In the le browser:

Tap to return to the main menu.

Tap to upload les.

Tap to refresh, sort, create a new folder, or mark les for deletion and copying.

52D-Link DIR-816L User Manual

Section 3 - Conguration

Tap to select les and perform the following actions:

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Tap to create a new folder.

Mark a le then tap this icon to delete it.

Mark a le then tap this icon to copy it.

To delete les:

Tap on

and tick the box next to a le for deletion.

Tap on

To copy les:

Tap on

to each le for copying.

Tap on

to delete your selected les. Tap OK to conrm.

to select les for copying. Tick the box next

to browse to the destination.

53D-Link DIR-816L User Manual

Section 3 - Conguration

Tap Paste or Cancel. You can also tap New Folder if you wish to create a folder

in the current directory.

To create a new folder:

Browse to the directory you wish to create a new folder in. Tap

then .

Enter the name of the folder in the box, then tap OK.

54D-Link DIR-816L User Manual

Section 3 - Conguration

To upload images and videos from your mobile device:

Browse to the folder you wish to upload to. Tap

and browse to the le or les you wish to upload

from the local device. Tick the box next to each of the les you wish to upload. Tap Upload.

During the upload process, the size of the le and the upload progress will be displayed under the le name.

To remove a le from the upload queue, tap the X next

to it.

55D-Link DIR-816L User Manual

Section 3 - Conguration

Favorites

Search Bar:

Type in the name of a le to search for it.

Tap to return to the main menu.

Tap to refresh, sort, or mark les for deletion.

Tap for additional options:

Tap to return to the main menu.

Tap to update the list of les.

Tap to sort the les by name, size, type, or date.

Check a le then tap to delete it.

56D-Link DIR-816L User Manual

Section 3 - Conguration

Conguration

Web-based Conguration Utility

To access the conguration utility, open a web-browser such as Internet Explorer and enter address of the router (http://dlinkrouter.local. or http://192.168.0.1).

Leave the password blank by default.

57D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Connection Setup

Click Manual Internet Connection Setup to congure your connection manually and continue to the next page.

If you want to congure your router to connect to the Internet using the wizard, click Internet Connection Setup Wizard. You will be directed to the Quick Setup Wizard.

58D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Connection Setup Wizard

When conguring the router for the rst time, we recommend that you click use the Internet Connection Setup Wizard, and follow the instructions on the screen. This wizard is designed to assist the user with a quick and easy method to congure the Internet connection on this router.

Anytime during the Internet Connection Setup Wizard, the user can click on the Cancel button to discard any changes made and return to the main Internet page. Also the user can click on the Prev button, to return to the previous window for reconguration.

Welcome:

This wizard will guide you through a step-by-step process to congure your new D-Link router and connect to the Internet. Click Next to continue.

Step 1: Set Your Password

By default, the D-Link Router does not have a password congured for administrator access to the Web-based conguration pages. To secure your new networking device, please enter and verify a password in the spaces provided. The two passwords must match.

Click Next to continue.

59D-Link DIR-816L User Manual

Section 3 - Conguration

Step 2: Select Your Time Zone

Select the appropriate time zone for your location. This information is required to congure the time-based options for the router.

Click Next to continue.

Step 3: Internet Connection

Here the user will be able to congure the Internet connection used by this device. If your ISP connection is listed in the drop-down menu select it and click Next. If your ISP connection is not listed then you can proceed to select any of the other manual Internet connection methods listed below.

The following parameters will be available for conguration:

Dynamic IP Address: Choose this if your Internet connection

automatically provides you with an IP Address. Most cable modems use this type of connection.

PPPoE: Choose this option if your Internet con-

nection requires a PPPoE username and password to get online. Most DSL modems use this type of connection.

PPTP: Choose this option if your Internet con-

nection requires a PPTP username and password to get online.

L2TP: Choose this option if your Internet con-

nection requires an L2TP username and password to get online.

Static IP Address: Choose this option if your ISP provided

you with IP Address information that has to be manually congured.

60D-Link DIR-816L User Manual

Section 3 - Conguration

Step 3: Internet Connection (Dynamic IP Address)

After selecting the dynamic IP address Internet connection method, the following page will appear.

The following parameters will be available for conguration:

MAC Address: Enter the MAC address of the Internet

gateway (plugged into the Internet port of this device) here.

Clone Button: If the conguration PC also acts as the Internet

gateway, then click on the Clone Your PC’s MAC Address button to copy the PC’s MAC

address into the space provided. If you’re not sure, leave the MAC address eld blank.

Host Name: Enter the host name used here. You may also

need to provide a host name. If you do not have or know this information, please contact your ISP.

Primary DNS Address: Enter the primary DNS IP address used here.

Secondary DNS Address: Enter the secondary DNS IP address used here.

This eld is normally optional. Only one DNS address is required for a functional Internet connection, but using a second DNS address provides more stability.

Click Next to continue.

Step 3: Internet Connection (PPPoE)

After selecting the PPPoE Internet connection method, the following page will appear:

The following parameters will be available for conguration:

User Name: Enter the PPPoE account user name used here.

This information is given by the ISP.

Password: Enter the PPPoE account password used here.

This information is given by the ISP.

Click Next to continue.

61D-Link DIR-816L User Manual

Section 3 - Conguration

Step 3: Internet Connection (PPTP)

After selecting the PPTP Internet connection method, the following page will appear:

The following parameters will be available for conguration:

Address Mode: Here the user can specify whether this

Internet connection requires the use of a Dynamic or Static IP address. PPTP usual requires a Dynamic IP conguration.

PPTP IP Address: Enter the PPTP IP address used here. This

option is only available if Static IP is selected.

PPTP Subnet Mask: Enter the PPTP Subnet Mask used here.

PPTP Gateway IP Address: Enter the PPTP Gateway IP address used

here.

PPTP Server IP Address: Enter the PPTP Server IP address used

here. This is normally the same a the PPTP Gateway IP address.

User Name: Enter the PPTP username used here.

Password: Enter the PPTP password used here.

Verify Password: Re-enter the PPTP password used here.

Primary DNS Address: Enter the Primary DNS IP address used

here.

Secondary DNS Address: Enter the Secondary DNS IP address used

here. This eld is normally optional. Only one DNS address is required for a functional Internet connection, but using a second DNS address provides more stability.

Click Next to continue.

62D-Link DIR-816L User Manual

Section 3 - Conguration

Step 3: Internet Connection (L2TP)

After selecting the L2TP Internet connection method, the following page will appear:

The following parameters will be available for conguration:

Address Mode: Here the user can specify whether this

Internet connection requires the use of a Dynamic or Static IP address. L2TP usual requires a Dynamic IP conguration.

L2TP IP Address: Enter the L2TP IP address used here. This

option is only available if Static IP is selected.

L2TP Subnet Mask: Enter the L2TP Subnet Mask used here.

L2TP Gateway IP Address: Enter the L2TP Gateway IP address used

here.

L2TP Server IP Address: Enter the L2TP Server IP address used

here. This is normally the same a the L2TP Gateway IP address.

User Name: Enter the L2TP username used here.

Password: Enter the L2TP password used here.

Verify Password: Re-enter the L2TP password used here.

Primary DNS Address: Enter the Primary DNS IP address used

here.

Secondary DNS Address: Enter the Secondary DNS IP address used

here. This eld is normally optional. Only one DNS address is required for a functional Internet connection, but using a second DNS address provides more stability.

Click Next to continue.

63D-Link DIR-816L User Manual

Section 3 - Conguration

Step 3: Internet Connection (Static IP Address)

After selecting the Static IP Address Internet connection method, the following page will appear:

The following parameters will be available for conguration:

IP Address: Enter the Static IP address provided by the

ISP here.

Subnet Mask: Enter the Subnet Mask provided by the ISP

here.

Gateway Address: Enter the Gateway IP address provided by

the ISP here.

Primary DNS Address: Enter the Primary DNS IP address used

here.

Secondary DNS Address: Enter the Secondary DNS IP address used

here. This eld is normally optional. Only one DNS address is required for a functional Internet connection, but using a second DNS address provides more stability.

Click Next to continue.

Setup Complete!

This is the last page of the Internet Connection Setup Wizard.

Click the Connect button to save your settings.

64D-Link DIR-816L User Manual

Section 3 - Conguration

Internet (Manual)

On this page the user can congure the Internet Connection settings manually. To access the Manual Internet Connection Setup page, click on the Manual Internet Connection Setup button. On this page there a multiple parameters that can be congured regarding the Internet Connection setup. We’ll discuss them from top to bottom.

At any given point the user can save the conguration done, on this page, by clicking on the Save Settings button. If you choose to discard the changes made, click on the Don’t Save Settings button.

65D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Connection Type

In this section, the user can select from a list of Internet Connection types that can be congured and used on this router. Options to choose from are Static IP, Dynamic IP, PPPoE, PPTP, L2TP, and DS-Lite.

After selecting a specic Internet Connection type, this page will automatically refresh and provide unique elds to congure related to the specied Internet Connection type.

My Internet Connection is: Dynamic IP (DHCP)

The default WAN conguration for this router is Dynamic IP (DHCP). This option allows the router to obtain an IP address automatically from the device that is connected to the Internet port.

Note: If you’re not sure about the type of Internet Connection you have, please contact your Internet Service Provider (ISP) for assistance.

After selecting Dynamic IP, the following parameters will be available for conguration:

Host Name: The Host Name is optional but may be

required by some ISPs. Leave blank if you are not sure.

Use Unicasting: Tick this option if you ISP uses the unicast

method to provide IP addresses.

Primary DNS: Enter the Primary DNS IP address used

here.

Secondary DNS: Enter the Secondary DNS IP address used

here. This eld is normally optional. Only one DNS address is required for a functional Internet connection, but using a second DNS address provides more stability.

MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP.

1500 is the default MTU.

MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It

is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet

card.

66D-Link DIR-816L User Manual

Section 3 - Conguration

Manual Internet Setup

Static (assigned by ISP)

Select Static IP Address if all the Internet port’s IP information is provided to you by your ISP. You will need to enter in the IP address, subnet mask, gateway address, and DNS address(es) provided to you by your ISP. Each IP address entered in the elds must be in the appropriate IP form, which are four octets separated by a dot (x.x.x.x). The Router will not accept the IP address if it is not in this format.

My Internet Connection:

IP Address:

Subnet Mask:

Default Gateway:

DNS Servers:

MTU:

MAC Address:

Select Static IP to manually enter the IP settings supplied by your ISP.

Enter the IP address assigned by your ISP.

Enter the Subnet Mask assigned by your ISP.

Enter the Gateway assigned by your ISP.

The DNS server information will be supplied by your ISP (Internet Service Provider.)

Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP. 1500 is the default MTU.

The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It is not recommended that you change the default MAC address unless required by your ISP. You can use the Clone Your PC’s MAC Address button to replace the Internet port’s MAC address with the MAC address of your Ethernet card.

67D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Setup

PPPoE (DSL)

Choose PPPoE (Point to Point Protocol over Ethernet) if your ISP uses a PPPoE connection. Your ISP will provide you with a username and password. This option is typically used for DSL services. Make sure to remove your PPPoE software from your computer. The software is no longer needed and will not work through a router.

My Internet

Connection:

Address Mode:

IP Address:

Username:

Password:

Verify Password:

Service Name:

Select PPPoE (Username/Password) from the drop-down menu.

Here the user can specify whether this Internet connection requires the use of a Dynamic or Static IP address. PPPoE usually requires a Dynamic IP conguration.

Enter the PPPoE IP address used here. This option is only available if Static IP is selected.

Enter the PPPoE account user name used here. This information is given by the ISP.

Enter the PPPoE account password used here. This information is given by the ISP.

Re-enter the PPPoE account password used here.

This optional eld enables the user to enter a service name to identify this Internet connection here.

Reconnect Mode:

To create a new schedule, click the New Schedule button to open the Schedules page. Schedules will be discussed later.

Use the radio buttons to specify the reconnect mode. The user can specify a custom schedule or specify the On Demand, or Manual option. To specify a custom schedule, use the drop-down menu to select one of the schedules that has been dened in the Schedules page.

68D-Link DIR-816L User Manual

Section 3 - Conguration

Maximum Idle Time: Enter a maximum idle time during which the Internet connection is maintained during inactivity.

DNS Mode: This option allow the router to obtain the DNS IP addresses from the ISP, when Receive DNS from ISP is selected,

or allows the user to enter DNS IP address manually, when Enter DNS Manually is selected.

Primary DNS Server: Enter the Primary DNS IP address used here.

Secondary DNS Server: Enter the Secondary DNS IP address used here. This eld is normally optional. Only one DNS address is required for

a functional Internet connection, but using a second DNS address provides more stability.

MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP.

1492 is the default MTU.

MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It

69D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Setup

PPTP

Choose PPTP (Point-to-Point-Tunneling Protocol ) if your ISP uses a PPTP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services.

My Internet Connection: Select PPTP (Username/Password) from the

drop-down menu.

Address Mode: Here the user can specify whether this Internet

connection requires the use of a Dynamic or Static IP address. PPTP usually requires a Dynamic IP conguration.

PPTP IP Address: Enter the PPTP IP address used here. This option

is only available if Static IP is selected.

PPTP Subnet Mask: Enter the PPTP Subnet Mask used here.

PPTP Gateway IP Address: Enter the PPTP Gateway IP address used here.

PPTP Server IP Address: Enter the PPTP Server IP address used here. This

is normally the same a the PPTP Gateway IP address.

Username: Enter the PPTP username used here.

Password: Enter the PPTP password used here.

Verify Password: Re-enter the PPTP password used here.

Reconnect Mode: Use the radio buttons to specify the reconnect mode.

The user can specify a custom schedule or specify the On Demand, or Manual option. To specify a custom schedule, use the drop-down menu to select one of the schedules that has been dened in the Schedules page. To create a new schedule, click the New Schedule button to open the Schedules page. Schedules will be discussed later.

Maximum Idle Time: Enter a maximum idle time during which the

Internet connection is maintained during inactivity. To disable this feature, enable Autoreconnect.

70D-Link DIR-816L User Manual

Section 3 - Conguration

Primary DNS Server: Enter the Primary DNS IP address used here.

Secondary DNS Server: Enter the Secondary DNS IP address used here. This eld is normally optional. Only one DNS address is required for

a functional Internet connection, but using a second DNS address provides more stability.

MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP.

1400 is the default MTU.

MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It

71D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Setup

L2TP

Choose L2TP (Layer 2 Tunneling Protocol) if your ISP uses a L2TP connection. Your ISP will provide you with a username and password. This option is typically used for DSL services.

My Internet

Connection:

Address Mode: Here the user can specify whether this Internet

L2TP IP Address: Enter the L2TP IP address used here. This option is

L2TP Subnet Mask: Enter the L2TP Subnet Mask used here.

L2TP Gateway IP

Address:

L2TP Server IP

Address:

Username: Enter the L2TP username used here.

Password: Enter the L2TP password used here.

Verify Password: Re-enter the L2TP password used here.

Reconnect Mode: Use the radio buttons to specify the reconnect

Select L2TP (Username/Password) from the drop- down menu.

connection requires the use of a Dynamic or Static IP address. L2TP usual requires a Dynamic IP conguration.

only available if Static IP is selected.

Enter the L2TP Gateway IP address used here.

Enter the L2TP Server IP address used here. This is normally the same a the L2TP Gateway IP address.

mode. The user can specify a custom schedule or specify the On Demand, or Manual option. To specify a custom schedule, use the drop-down menu to select one of the schedules that has been dened in the Schedules page. To create a new schedule, click the New Schedule button to open the Schedules page. Schedules will be discussed later.

72D-Link DIR-816L User Manual

Section 3 - Conguration

Maximum Idle Time: Enter a maximum idle time during which the Internet connection is maintained during inactivity. To disable this

feature, enable Auto-reconnect.

Primary DNS Server: Enter the Primary DNS IP address used here.

Secondary DNS Server: Enter the Secondary DNS IP address used here. This eld is normally optional. Only one DNS address is required for

a functional Internet connection, but using a second DNS address provides more stability.

MTU: Maximum Transmission Unit - you may need to change the MTU for optimal performance with your specic ISP.

1400 is the default MTU.

MAC Address: The default MAC Address is set to the Internet port’s physical interface MAC address on the Broadband Router. It

73D-Link DIR-816L User Manual

Section 3 - Conguration

Internet Setup

DS-Lite

Another Internet connection type is DS-Lite.

DS-Lite is an IPv6 connection type. After selecting DS-Lite, the following parameters will be available for conguration:

DS-Lite Conguration: Select the DS-Lite DHCPv6 Option to let

the router allocate the AFTR IPv6 address automatically. Select the Manual Conguration to enter the AFTR IPv6 address in manually.

AFTR IPv6 Address: After selecting the Manual Conguration

option above, the user can enter the AFTR IPv6 address used here.

B4 IPv4 Address: Enter the B4 IPv4 address value used here.

WAN IPv6 Address: Once connected, the WAN IPv6 address

will be displayed here.

IPv6 WAN Default Gateway Once connected, the IPv6 WAN Default

Gateway address will be displayed here.

Click on the Save Settings button to accept the changes made. Click on the Don’t Save Settings button to discard the changes made.

74D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless connection setup wizard

On this page the user can congure the Wireless settings for this device. There are 3 ways to congure Wireless using this router. Firstly, the user can choose to make use for the quick and easy Wireless Connection Setup Wizard. Secondly, the user can choose to make use Wi-Fi Protected Setup. Lastly, the user can congure the Wireless settings manually.

Wireless Settings: Wireless Connection Setup Wizard

The Wireless Connection Setup Wizard is specially designed to assist basic network users with a simple, step-by-step set of instructions to congure the wireless settings of this router. It is highly recommended to customized the wireless network settings to t into your environment and to add higher security.

To initiate the Wireless Connection Setup Wizard click on the Wireless Connection Setup Wizard button.

Step 1: In this step, the user must enter a custom Wireless Network Name or SSID. Enter the new Network Name (SSID) in the appropriate space provided. There are seperate spaces provided for a 2.4 GHz Network Name and a 5 GHz Network Name.

Secondly the user can choose between two wireless security wizard congurations. The user can select ‘Automatically assign a network key’, by which the router will automatically generate a WPA/WPA2 preshared key using the TKIP and AES encryption methods; or the user can select ‘Manually assign a network key’, by which the user will be prompt to manually enter a WPA/WPA2 pre-shared key using the TKIP and AES encryption methods.

75D-Link DIR-816L User Manual

Section 3 - Conguration

Step 2: This step will only be available if the user selected ‘Manually assign a network key’ in the previous step. Here the user can manually enter the WPA/WPA2 pre-shared key in the Wireless Security Password space provided. The key entered must be between 8 and 63 characters long. Remember, this key will be used when wireless clients want to connect to this device. So please remember this key to prevent future troubleshooting. If you want to use the same Wireless Security Password for both 2.4 GHz and 5 GHz bands, tick the option provided. If not selected, you need to input two seperate wireless security passwords for each individual wireless band.

Setup Complete: On this page the user can view the conguration made and verify whether they are correct.

Click on the Prev button to return to the previous page. Click on the Cancel button to discard the changes made and return to the main wireless page. Click on the Save button to accept the changes made.

76D-Link DIR-816L User Manual

Section 3 - Conguration

After click the Save button the device will save the settings made and return to the main wireless page.

End of Wizard.

77D-Link DIR-816L User Manual

Section 3 - Conguration

Wi-Fi Protected Setup Wizard

Wireless Settings: Wi-Fi Protected Setup Wizard

If your Wireless Clients support the WPS connection method, this Wi-Fi Protected Setup Wizard can be used to initiate a wireless connection between this device and Wireless clients with a simple click of the WPS button. The Wi-Fi Protected Setup Wizard is specially designed to assist basic network users with a simple, step-by-step set of instructions to connect wireless clients to this router using the WPS method.

To initiate the Wi-Fi Protected Setup Wizard click on the Add Wireless

Device with WPS button.

Step 1: In this step the user have two options to choose from. You can

choose Auto if the wireless client supports WPS, or Manual if the wireless client does not support WPS.

Step 2: After selecting Auto, the following page will appear. There are two ways to add a wireless device, that supports WPS. Firstly, there is the Personal Identication Number (PIN) method. Using this method will prompt the user to enter a PIN code. This PIN code should be identical on the wireless client. Secondly, there is the Push Button Conguration (PBC) method. Using this method will allow the wireless client to connect to this device by similarly pressing the PBC button on it.

78D-Link DIR-816L User Manual

Section 3 - Conguration

Step 2: After selecting Manual, the following page will appear. On this page to user can view the wireless conguration of this router. The wireless clients should congure their wireless settings to be identical to the settings displayed on this page for a successful connection. This option is for wireless clients that can’t use the WPS method to connect to this device.

Click on the Prev button to return to the previous page. Click on the Next button to continue to the next page. Click on the Cancel button to discard the changes made and return to the main wireless page. Click on the Wireless Status button to navigate to the Status > Wireless page to view what wireless client are connected to this device.

End of Wizard.

Manual wireless network setup

Wireless Settings: Manual Wireless Network Setup

The manual wireless network setup option allows users to congure the wireless settings of this device manually. This option is for the more advanced user and includes all parameters that can be congured for wireless connectivity.

To initiate the Manual Wireless Setup page, click on the Manual Wireless Connection Setup button.

On this page the user can congure all the parameters related to the wireless connectivity of this router.

79D-Link DIR-816L User Manual

Section 3 - Conguration

The following parameters will be available for conguration:

Wireless Band: Displays the wireless band being cong-

ured. In this option we nd that the following parameters will be regarding the

2.4GHz band.

Enable Wireless: Check the box to enable the wireless func-

tion. If you do not want to use wireless, uncheck the box to disable all the wireless functions. Select the time frame that you would like your wireless network enabled. The schedule may be set to Always. Any schedule you create will be available in the drop-down menu. Click New Schedule to create a new schedule.

Wireless Network Name: The Service Set Identier (SSID) is the name of your wireless network. Create a name using up to 32 characters. The

SSID is case-sensitive. Enable Auto Channel

802.11 Mode: Here the user can manually select the preferred frequency band to use for this wireless network.

Enable Auto Channel Scan: The auto channel selection setting can be selected to allow this device to choose the channel with the least

amount of interference.

Wireless Channel: By default the channel is set to 1. The Channel can be changed to t the channel setting for an existing wireless

network or to customize the wireless network. If you enable Auto Channel Selection, this option will be greyed out.

Transmission Rate: Select the transmit rate. It is strongly suggested to select Best (Automatic) for best performance.

Channel Width: When using the 802.11n frequency band, the user have an option to choose between a 20 MHz or 20/40 MHz

bandwidth.

Visibility Status: The Invisible option allows you to hide your wireless network. When this option is set to Visible, your wireless

network name is broadcasted to anyone within the range of your signal. If you are not using encryption then they could connect to your network. When Invisible mode is enabled, you must enter the Wireless Network Name (SSID) on the client manually to connect to the network.

80D-Link DIR-816L User Manual

Section 3 - Conguration

By default the wireless security of this router will be disabled. In this next option the user can enabled or disable wireless security for the frequency band 2.4 GHz. There are two types of encryption that can be used. WEP or WPA/WPA2.

Wireless Security Mode: WEP

Wired Equivalent Privacy (WEP) is the most basic form of encryption that can be used for wireless networks. Even though it is known as a ‘weak’ security method, it is better than no security at all. Older wireless adapter sometimes only supports WEP encryption and thus we still nd this encryption method used today.

The following parameters will be available for conguration:

WEP Key Length: Here the user can specify to either use a

64-Bit or a 128-Bit encrypted key.

Authentication: Authentication is a process by which the

router veries the identity of a network device that is attempting to join the wireless network. There are two types authentication for this device when using WEP. Open System allows all wireless devices to communicate with the router before they are required to provide the encryption key needed to gain access to the network. Shared Key requires any wireless device attempting to communicate with the router to provide the encryption key needed to access the network before they are allowed to communicate with the router.

WEP Key 1: Enter the WEP key used here. For 64-bit keys you must enter 10 hex digits into each key box. For 128-bit keys you

must enter 26 hex digits into each key box. A hex digit is either a number from 0 to 9 or a letter from A to F. You may also enter any text string into a WEP key box, in which case it will be converted into a hexadecimal key using the ASCII values of the characters. A maximum of 5 text characters can be entered for 64-bit keys, and a maximum of 13 characters for 128-bit keys.

81D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless Security Mode: WPA-Personal

Wi-Fi Protected Access (WPA) is the most advanced and up to date wireless encryption method used today. This is the recommended wireless security option. WPA supports two authentication frameworks. Personal (PSK) and Enterprise (EAP). Personal requires only the use of a passphrase (Shared Secret) for security.

The following parameters will be available for conguration:

WPA Mode: WPA is the older standard; select this op-

tion if the clients that will be used with the router only support the older standard. WPA2 is the newer implementation of the stronger IEEE 802.11i security standard. With the “WPA2” option, the router tries WPA2 rst, but falls back to WPA if the client only supports WPA. With the “WPA2 Only” option, the router associates only with clients that also support WPA2 security.

Cipher Type: Select the appropriate cipher type to use

here. Options to choose from are Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard (AES), and Both (TKIP

and AES).

Group Key Update Interval: Enter the amount of time before the group

key used for broadcast and multicast data is changed.

Pre-Shared Key: Enter the shared secret used here. This

secret phrase needs to be the same on all of the wireless clients for them to be able to connect to the wireless network successfully.

82D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless Security Mode: WPA-Enterprise

The following parameters will be available for conguration:

WPA Mode: WPA is the older standard; select this option

if the clients that will be used with the router only support the older standard. WPA2 is the newer implementation of the stronger IEEE

802.11i security standard. With the “WPA2” option, the router tries WPA2 rst, but falls back to WPA if the client only supports WPA. With the “WPA2 Only” option, the router associates only with clients that also support WPA2 security.

Cipher Type: Select the appropriate cipher type to use here.

Options to choose from are Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard (AES), and Both (TKIP and AES).

Group Key Update

Interval:

RADIUS Server IP

Address:

RADIUS Server Port: When the user chooses to use the EAP authentication framework, the RADIUS server’s port number can be entered

RADIUS Server

Shared Secret:

Enter the amount of time before the group key used for broadcast and multicast data is changed.

When the user chooses to use the EAP authentication framework, the RADIUS server’s IP address can be entered here.

here. Enter the shared secret used here. This secret phrase needs to be the same on all of the wireless clients for them to

be able to connect to the wireless network successfully.

83D-Link DIR-816L User Manual

Section 3 - Conguration

The following parameters will be available for conguration:

Wireless Band: Displays the wireless band being cong-

ured. In this option we nd that the following parameters will be regarding the 5GHz band.

Enable Wireless: Check the box to enable the wireless func-

Wireless Network Name: The Service Set Identier (SSID) is the name of your wireless network. Create a name using up to 32 characters. The

SSID is case-sensitive. Enable Auto Channel

802.11 Mode: Here the user can manually select the preferred frequency band to use for this wireless network.

Enable Auto Channel Scan: The auto channel selection setting can be selected to allow this device to choose the channel with the least

amount of interference.

Wireless Channel: By default the channel is set to 36. The Channel can be changed to t the channel setting for an existing wireless

network or to customize the wireless network. If you enable Auto Channel Selection, this option will be greyed out.

Transmission Rate: Select the transmit rate. It is strongly suggested to select Best (Automatic) for best performance.

Channel Width: When using the 802.11n frequency band, the user have an option to choose between a 20 MHz, 20/40 MHz, or

20/40/80 MHz bandwidth.

Visibility Status: The Invisible option allows you to hide your wireless network. When this option is set to Visible, your wireless

84D-Link DIR-816L User Manual

Section 3 - Conguration

By default the wireless security of this router will be disabled. In this next option the user can enabled or disable wireless security for the frequency band 5GHz. There are two types of encryption that can be used. WEP or WPA/WPA2.

Wireless Security Mode: WEP

The following parameters will be available for conguration:

WEP Key Length: Here the user can specify to either use a

64Bit or a 128Bit encrypted key.

Authentication: Authentication is a process by which the

WEP Key 1: Enter the WEP key used here. For 64-bit keys you must enter 10 hex digits into each key box. For 128-bit keys you

85D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless Security Mode: WPA-Personal

The following parameters will be available for conguration:

WPA Mode: WPA is the older standard; select this

option if the clients that will be used with the router only support the older standard. WPA2 is the newer implementation of the stronger IEEE

Cipher Type: Select the appropriate cipher type to use

here. Options to choose from are Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard (AES), and Both (TKIP

and AES).

Group Key Update Interval: Enter the amount of time before the group

key used for broadcast and multicast data is changed.

Pre-Shared Key: Enter the shared secret used here. This secret phrase needs to be the same on all of the wireless clients for them to

be able to connect to the wireless network successfully.

86D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless Security Mode: WPA-Enterprise

The following parameters will be available for conguration:

WPA Mode: WPA is the older standard; select this op-

Cipher Type: Select the appropriate cipher type to use

here. Options to choose from are Temporal Key Integrity Protocol (TKIP), Advanced Encryption Standard (AES), and Both (TKIP

and AES).

Group Key Update Interval: Enter the amount of time before the group

key used for broadcast and multicast data is changed.

RADIUS Server IP Address: When the user chooses to use the EAP

authentication framework, the RADIUS server’s IP address can be entered here.

RADIUS Server Port: When the user chooses to use the EAP authentication framework, the RADIUS server’s port number can be entered

here.

RADIUS Server Shared

Secret:

Enter the shared secret used here. This secret phrase needs to be the same on all of the wireless clients for them to be able to connect to the wireless network successfully.

87D-Link DIR-816L User Manual

Section 3 - Conguration

Wireless Security

This section will show you the dierent levels of security you can use to protect your data from intruders. The DIR-816L oers the following types of security:

• WPA2 (Wi-Fi Protected Access 2) • WPA2-PSK (Pre-Shared Key)

• WPA (Wi-Fi Protected Access) • WPA-PSK (Pre-Shared Key)

What is WPA?

WPA (Wi-Fi Protected Access), is a Wi-Fi standard that was designed to improve the security features of WEP (Wired Equivalent Privacy).

The 2 major improvements over WEP:

• Improved data encryption through the Temporal Key Integrity Protocol (TKIP). TKIP scrambles the keys using a hashing

algorithm and, by adding an integrity-checking feature, ensures that the keys haven’t been tampered with. WPA2 is

based on 802.11i and uses Advanced Encryption Standard (AES) instead of TKIP.

• User authentication, which is generally missing in WEP, through the extensible authentication protocol (EAP). WEP

regulates access to a wireless network based on a computer’s hardware-specic MAC address, which is relatively simple

to be snied out and stolen. EAP is built on a more secure public-key encryption system to ensure that only authorized

network users can access the network.

WPA-PSK/WPA2-PSK uses a passphrase or key to authenticate your wireless connection. The key is an alpha-numeric password between 8 and 63 characters long. The password can include symbols (!?*&_) and spaces. This key must be the exact same key entered on your wireless router or access point.

WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network.

88D-Link DIR-816L User Manual

Section 3 - Conguration

Network Settings

This section will allow you to change the local network settings of the router and to congure the DHCP settings.

Router Settings

Router IP Address:

Subnet Mask:

Device Name:

Local Domain:

Enable DNS Relay:

Enter the IP address of the router. The default IP address is 192.168.0.1.

If you change the IP address, once you click Save Settings, you will need to enter the new IP address in your browser to get back into the conguration utility.

Enter the Subnet Mask. The default subnet mask is

255.255.255.0.

Enter a name for the router.

Enter the Domain name (Optional).

Uncheck the box to transfer the DNS server information from your ISP to your computers. If checked, your computers will use the router for a DNS server.

89D-Link DIR-816L User Manual

Section 3 - Conguration

DHCP Server Settings

DHCP stands for Dynamic Host Control Protocol. The DIR-816L has a built-in DHCP server. The DHCP Server will automatically assign an IP address to the computers on the LAN/private network. Be sure to set your computers to be DHCP clients by setting their TCP/IP settings to “Obtain an IP Address Automatically.” When you turn your computers on, they will automatically load the proper TCP/IP settings provided by the DIR-816L. The DHCP Server will automatically allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting and ending address of the IP address pool.

Enable DHCP

Server:

DHCP IP Address

Range:

DHCP Lease Time:

Always Broadcast:

Check this box to enable the DHCP server on your router. Uncheck to disable this function.

Enter the starting and ending IP addresses for the DHCP server’s IP assignment.

Note: If you statically (manually) assign IP addresses to your computers or devices, make sure the IP addresses are outside of this range or you may have an IP conict.

The length of time for the IP address lease. Enter the Lease time in minutes.

If all the computers on the LAN successfully obtain their IP addresses from the router’s DHCP server as expected, this option can remain disabled. However, if one of the computers on the LAN fails to obtain an IP address from the router’s DHCP server, it may have an old DHCP client that incorrectly turns o the broadcast ag of DHCP packets. Enabling this option will cause the router to always broadcast its responses to all clients, thereby working around the problem, at the cost of increased broadcast trac on the LAN.

NetBIOS

Announcement:

Check this box to allow the DHCP Server to oer NetBIOS conguration settings to the LAN hosts. NetBIOS allow LAN hosts to discover all other computers within the network, e.g. within Network Neighborhood.

90D-Link DIR-816L User Manual

Section 3 - Conguration

Learn NetBIOS

from WAN:

NetBIOS Scope:

NetBIOS Node:

WINS IP Address:

If NetBIOS announcement is switched on, it will cause WINS information to be learned from the WAN side, if available. Turn this setting o to congure manually.

This is an advanced setting and is normally left blank. This allows the conguration of a NetBIOS ‘domain’ name under which network hosts operate. This setting has no eect if the ‘Learn NetBIOS information from WAN’ is activated.

This eld indicates how network hosts are to perform NetBIOS name registration and discovery. H-Node, this indicates a HybridState of operation. First WINS servers are tried, if any, followed by local network broadcast. This is generally the preferred mode if you have congured WINS servers. M-Node (default), this indicates a Mixed-Mode of operation. First Broadcast operation is performed to register hosts and discover other hosts, if broadcast operation fails, WINS servers are tried, if any. This mode favours broadcast operation which may be preferred if WINS servers are reachable by a slow network link and the majority of network services such as servers and printers are local to the LAN. P-Node, this indicates to use WINS servers ONLY. This setting is useful to force all NetBIOS operation to the congured WINS servers. You must have congured at least the primary WINS server IP to point to a working WINS server. B-Node, this indicates to use local network broadcast ONLY. This setting is useful where there are no WINS servers available, however, it is preferred you try M-Node operation rst. This setting has no eect if the ‘Learn NetBIOS information from WAN’ is activated.

Enter your WINS Server IP address(es).

91D-Link DIR-816L User Manual

Section 3 - Conguration

DHCP Reservation

If you want a computer or device to always have the same IP address assigned, you can create a DHCP reservation. The router will assign the IP address only to that computer or device.

Note: This IP address must be within the DHCP IP Address Range.

Enable:

Computer Name:

IP Address:

MAC Address:

Copy Your PC’s MAC

Address:

Save:

DHCP Reservations

List:

Check this box to enable the reservation.

Enter the computer name or select from the drop-down menu and click <<.

Enter the IP address you want to assign to the computer or device. This IP Address must be within the DHCP IP Address Range.

Enter the MAC address of the computer or device.

If you want to assign an IP address to the computer you are currently on, click this button to populate the elds.

Click Save to save your entry. You must click Save Settings at the top to activate your reservations.

DHCP Reservations List

Displays any reservation entries. Displays the host name (name of your computer or device), MAC Address, and IP address.

Enable:

Edit:

Delete:

Check to enable the reservation.

Click the edit icon to make changes to the reservation entry.

Click to remove the reservation from the list.

92D-Link DIR-816L User Manual

Section 3 - Conguration

Storage

This page allows the user to use a web browser to remotely access les stored on an SD card or USB storage drive plugged into the router. You can access storage device by http://shareport.local when you enable SharePort Web Access

The following parameters will be available for conguration:

Enable SharePort Web

Access:

HTTP Access Port: Enter the HTTP Access Port number used

HTTPS Access Port: Enter the HTTPS Access Port number used

Allow Remote Access: Tick this option the allow remote access to this router.

Tick this option to enable the share port web access feature.

here. By default, this value is 8181.

here. By default, this value is 4433.

In the User Creation section, the user can create and modify usernames and passwords.

The following parameters will be available for conguration:

User Name: In the User Name eld we can enter the

new username that will be created. Alternatively, if we want to modify an existing user account, select a username from the drop-down menu. It will automatically be added to the User Name eld for modication.

Password: In the Password eld, the user can enter the password that will be associated with the user account.

Verify Password: In the Verify Password eld, the user can re-enter the password that will be associated with the user account.

Click the Add/Edit button the add a new user account or modify an existing account.

93D-Link DIR-816L User Manual

Section 3 - Conguration

In the User List section, the user can modify or delete dierent user settings for each account.

The following parameters will be available in the display.

No. Displays the number of the entry in the

user list.

User Name: Displays the user name of the entry in the

list.

Access Path: Displays the access path of the entry in the

list.

Permission: Displays the permission settings of the

entry in the list.

Click the Edit icon to edit the access path and permission, for each user. Click the Delete icon to delete an account from the list.

After click on the Edit button, this window will appear.

The following parameters will be available for conguration:

User Name: This eld will display the current user

name that will be modied.

Folder: This led will display the access path that

this user will have access to, after logging in. Click the Browse button to navigate to a folder, located on the USB storage device.

Permission: Here the user can select the appropriate

permission setting for this user account. Permissions available for selection, from the drop-down menu are Read Only and

Read/Write. Read Only permission will only allow this account to read data stored on the USB storage device within the con-

strains of the access path specied. Read/Write permission will allow this account to read and write data to and from the USB storage device within the constrains of the access path specied.

Click the Append button to add a blank account with the access path and permission specied. Click the OK button to accept the changes made for the existing account. Click the Cancel button to discard the changes made.

94D-Link DIR-816L User Manual

Section 3 - Conguration

In the Number Devices section, the user can view information about the external USB storage devices inserted into the USB port of this router.

The following parameters will be available in the display

Number of Devices: This eld will display the number of USB

storage devices that are attached to the USB port of the router.

Device: This eld will display the USB storage de-

vice’s name.

Total Space: This eld will display the total space that is available on the USB storage device attached.

Free Space: This eld will display the free space that is available on the USB storage device attached.

In the HTTP Storage Link section, the user can use this link to connect to the drive remotely after logging in with a user account.

Notice the path of the link(s) provided will point the external interface of this router. If no DDNS account is specied on the Dynamic DNS page, the WAN IP address will be used. If, however, a DDNS account is specied, then the domain name will be used.

Click on the Save Settings button to accept the changes made. Click on the Don’t Save Settings button to discard the changes made.

95D-Link DIR-816L User Manual

D-Link DIR-816L User Manual [nl]

Specifications and Main Features

Frequently Asked Questions

User Manual
