Product Highlights
Gigabit Ethernet Speeds
High-speed ports provide the latest Ethernet
technology while remaining backward compatible
for connections to older computers and
equipment
Built to Last
Rugged metal housing, desktop or rackmountable,
reliability that businesses demand
Eco-Friendly
A range of D-Link Green technology features
help save energy automatically and reduce costs,
without sacricing performance
DGS-1016D and DGS-1024D
16 and 24-Port Gigabit Unmanaged Desktop or Rackmount Switches
Features
Physical
• 16 or 24 Gigabit Ethernet ports for fast network
speeds
• Desktop or rackmountable metal housing - rackmount
brackets included
• Fanless design for silent operation
Performance
• IEEE 802.3x Flow Control (can be enabled/disabled1)
• Port Isolation and Broadcast Storm Control (can be
enabled/disabled1)
• Auto MDI/MDI-X crossover for all ports
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• Jumbo Frame support
Energy Eciency
• Innovative D-Link Green Ethernet Technology
conserves energy
• Link status detection reduces power usage
• 802.3az EEE reduces power consumption signicantly
(can be enabled/disabled1)
• RoHS compliant
Easy Installation
• Plug-and-play installation saves you time
DIP Switch-Controllable Features
• Energy-Ecient Ethernet (EEE), Flow Control, Port
Isolation, and Storm Control
Overview
The D-Link DGS-1016D and the DGS-1024D 24-Port Unmanaged Gigabit Switch
series oer an economical way for SOHO and Small-to-Medium Businesses (SMB)
to take advantage of Gigabit Ethernet speeds, while reducing energy consumption
and minimizing noise output.
Gigabit Connectivity
The DGS-1016D/1024D switches bring the speed of Gigabit Ethernet to all ports
for a truly high-speed network. If your network has a mix of legacy and modern
connection interfaces, each port allows for standard Ethernet, Fast Ethernet, or
Gigabit Ethernet connections. You have the latest technology available to every
computer and device connected to your network.
Improved Network Eciency
The DGS-1016D/1024D switches incorporate several advanced features to help
simplify and improve network management and eciency. Flow Control throttles
connections to ensure reliability during heavy usage periods by reducing packet
loss and wasteful data retransmission. In addition, Storm Control and Port Isolation
mitigate the eects of broadcast storms caused by rogue software and malware,
which can propagate across the network and bring communication to a standstill.
Innovative Design
The DGS-1016D/1024D feature a durable, compact metal case alongside a fanless
design allowing for improved heat dissipation while maintaining silent operation.
The 16/24-Port Gigabit Unmanaged Switch series is small, lightweight, wallmountable, and is ideal for any business with demanding requirements and a small
budget.
Page 2
DGS-1016D and DGS-1024D
16 and 24-Port Unmanaged Gigabit Switches
Green Technology
The 16/24-Port Gigabit Unmanaged Switch series helps you conserve energy
automatically through several methods. Link status detection automatically
powers down ports that have no link, allowing the switches to save substantial
amounts of power by cutting power usage for unused ports or any ports
connected to computers that have been shut down.
Meanwhile, Energy-Ecient Ethernet (EEE) conserves energy by dynamically
reducing power consumption when data activity is low. These environmentally
Technical Specications
DGS-1016D DGS-1024D
friendly switches are also RoHS compliant, use recyclable packaging, and
minimize the use of harmful substances. These green features combined,
provide more energy savings and a longer product life, without sacricing
operational performance or functionality.
Limited Lifetime Warranty
D-Link oers a Limited Lifetime Warranty on the DGS-1016D and DGS1024D unmanaged switches to further its commitment to product
quality and long-term customer condence.
General
Hardware Version • H • H
Number of Ports • Sixteen (16) 10/100/1000 Gigabit ports • Twenty-four (24) 10/100/1000 Gigabit ports
Standards • IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
Data Transfer Rates • Ethernet:
• 10 Mbps (half duplex) / 20 Mbps (full duplex)
• Fast Ethernet:
• 100 Mbps (half duplex) / 200 Mbps (full duplex)
• Gigabit Ethernet:
• 2000 Mbps (full duplex)
Network Cables • 10BASE-T:
• UTP CAT 3, 4, 5/5e (100 m max)
• EIA/TIA-586 100-ohm STP (100 m max)
• 100BASE-TX, 1000BASE-T:
• UTP CAT 5/5e (100 m max)
• EIA/TIA-568 100-ohm STP (100 m max)
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
• Ethernet:
• 10 Mbps (half duplex) / 20 Mbps (full duplex)
• Fast Ethernet:
• 100 Mbps (half duplex) / 200 Mbps (full duplex)
• Gigabit Ethernet:
• 2000 Mbps (full duplex)
• 10BASE-T:
• UTP CAT 3, 4, 5/5e (100 m max)
• EIA/TIA-586 100-ohm STP (100 m max)
• 100BASE-TX, 1000BASE-T:
• UTP CAT 5/5e (100 m max)
• EIA/TIA-568 100-ohm STP (100 m max)
Page 3
DGS-1016D and DGS-1024D
16 and 24-Port Unmanaged Gigabit Switches
Functionality
D-Link Green Features • Power saving by link status and cable length • Power saving by link status and cable length
Security • Storm Control • Storm Control
QoS (Quality of Service) • 802.1p priority
• 8 queues
Cable Diagnostics • Indicated through port LEDs • Indicated through port LEDs
• 802.1p priority
• 8 queues
Switching Features
Protocol • CSMA/CD • CSMA/CD
Switching Capacity • 32 Gbps • 48 Gbps
Max. Forwarding Rate • 23.81 mpps • 35.71 mpps
Packet Buffer RAM • 512 KBytes per device • 512 KBytes per device
Filtering Address Table • 8K MAC addresses per device • 8K MAC addresses per device
Packet Filtering/Forwarding Rate • Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
• Gigabit Ethernet: 1,488,000 pps per port
MAC Address Learning • Self-learning, auto-aging • Self-learning, auto-aging
Forwarding Mode • Store-and-forward • Store-and-forward
• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
• Gigabit Ethernet: 1,488,000 pps per port
Physical & Environmental
Indicator LEDs • Power LED (per device)
• Link/Activity/Speed LEDs (per port)
• Power LED (per device)
• Link/Activity/Speed LEDs (per port)
DIP Switch • Energy-Efficient Ethernet (EEE)
• Flow Control
• Port Isolation and Storm Control
AC Input • Internal universal power supply
• 100~240 V AC; 50 to 60 Hz, 0.2 A max
Maximum Power Consumption • 10.07 W • 13.3 W
Standby Power Consumption • 3.02 W • 4.4 W
Maximum Heat Dissipation • 34.3 BTU/h • 45.35 BTU/h
MTBF • 1,882,372 hours • 863,100 hours
Acoustic Value • 0 dB(A) Fanless • 0 dB(A) Fanless
Dimensions • 280 x 125 x 44 mm (11.02 x 4.92 x 1.73 inch) • 280 x 180 x 44 mm (11.02 x 7.09 x 1.73 inch)
Weight • 1.02 kg (2.25 lbs) • 1.30 kg (2.87 lbs)
Operating Temperature • 0 ºC to 40 ºC (32 ºF to 104 ºF) • 0 ºC to 40 ºC (32 ºF to 104 ºF)
Storage Temperature • -10 ºC to 70 ºC (14 ºF to 158 ºF) • -10 ºC to 70 ºC (14 ºF to 158 ºF)
Operating Humidity • 0% to 95% RH, non-condensing • 0% to 95% RH, non-condensing
Storage Humidity • 0% to 95% RH • 0% to 95% RH
• Energy-Efficient Ethernet (EEE)
• Flow Control
• Port Isolation and Storm Control
• Internal universal power supply
• 100~240 V AC; 50 to 60 Hz, 0.3 A max
Page 4
Certications
DGS-1016D and DGS-1024D
16 and 24-Port Unmanaged Gigabit Switches
Emission Certifications (EMI) • ICES-003 Class A
• FCC Class A
• RCM Class A
• BSMI Class A
• CE Class A
• VCCI A
• CCC
• KCC
Safety • cUL/UL
• CE LVD
• CCC
• CB
• BSMI
• ICES-003 Class A
• FCC Class A
• RCM Class A
• BSMI Class A
• CE Class A
• VCCI A
• CCC
• KCC
• cUL/UL
• CE LVD
• CCC
• CB
• BSMI
Ordering Information
Part Number Description Warranty
DGS-1016D 16-Port Unmanaged Gigabit Switch Limited Lifetime
DGS-1024D 24-Port Unmanaged Gigabit Switch Limited Lifetime
2
2
1
Front panel control switches are applicable only for DGS-1016D hardware rev G3 and higher, and for DGS-1024D hardware rev G2 and higher.
2
Limited Lifetime Warranty available in USA only. Warranty void when not purchased from Authorized US D-Link Reseller. Please visit us.dlink.com for list of Authorized US
Resellers.
UPDATED 05-SEP-2018 (SMO)
DGS-1016D-1024D_REVH1_DATASHEET_1.10_EN_US.PDF
