Diodes PDS1040CTL User Manual

Green

10A DUAL LOW VF SCHOTTKY BARRIER RECTIFIER

Product Summary

(V) IO (A) V

V

RRM

40 10 0.50 0.2

F max

(V) I

R max

(mA) @ 40V

Description and Applications

PDS1040CTL is a dual die Schottky barrier rectifier in PowerDI5

package. It is designed for use in Low Voltage, High Frequency

Inverters, OR’ing, and Polarity Protection Applications.

POWERDI5

Features and Benefits

• Guard Ring Die Construction for Transient Protection

• Low Forward Voltage Drop

• Very Low Reverse Leakage Current

• High Forward Surge Current Capability

• Lead-Free Finish; RoHS Compliant (Notes 1 & 2)

• Halogen and Antimony Free. “Green” Device (Note 3)

• Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

• Case: POWERDI5

• Case Material: Molded Plastic, “Green” Molding Compound.

• Moisture Sensitivity: Level 1 per J-STD-020

• Terminals: Finish – Matte Tin annealed over Copper leadframe.

• Polarity: See Diagram

• Weight: 0.096 grams (approximate)

PDS1040CTL

UL Flammability Classification Rating 94V-0

Solderable per MIL-STD-202, Method 208

POWERDI

®

Top View

Bottom View

Ordering Information (Note 4)

Part Number Case Packaging

PDS1040CTL-13 POWERDI5 5000/Tape & Reel

PDS1040CTL-7 POWERDI5 1500/Tape & Reel

Notes: 1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

POWERDI is a registered trademark of Diodes Incorporated.

S1040CTL

PDS1040CTL

Document number: DS30485 Rev. 13 - 2

YYWWK

S1040CTL = Product type marking code

= Manufacturers’ code marking

YYWW = Date code marking
YY = Last digit of year (ex: 14 for 2014)
WW = Week code (01 - 53)
K = Factory Designator Code

1 of 5

www.diodes.com

February 2014

© Diodes Incorporated

Maximum Ratings (@T

= +25°C, unless otherwise specified.)

A

Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.

Characteristic Symbol Value Unit

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

RMS Reverse Voltage

Average Rectified Output Current (See also Figure 5) per element
total device

Non-Repetitive Peak Forward Surge Current, per element

8.3ms Single half sine-wave Superimposed on Rated Load

Thermal Characteristics

Characteristic Symbol Typ Max Unit

Thermal Resistance Junction to Soldering Point

Thermal Resistance Junction to Ambient Air (Note 5)

Thermal Resistance Junction to Ambient Air (Note 6)

Thermal Resistance Junction to Ambient Air (Note 7)

Operating and Storage Temperature Range

PDS1040CTL

V

RRM

V

RWM

V

R

V

R(RMS)

I

O

I

FSM

R

JS

θ

R

JA

θ

R

JA

θ

R

JA

θ

T

, T

J

STG

⎯

95

75

50

40 V

28 V

5

10

A

110 A

2.0

⎯

⎯

⎯

-65 to +150

°C/W

°C/W

°C/W

°C/W

°C

Electrical Characteristics (@T

= +25°C, unless otherwise specified.)

A

Characteristic Symbol Min Typ Max Unit Test Condition

Reverse Breakdown Voltage (Note 8)

Forward Voltage Per Element

V

(BR)R

V

F

40

⎯

⎯

⎯

⎯

⎯

⎯

0.465 0.50

0.41 0.45

0.39 0.43

0.55 0.60

0.53 0.57

0.52 0.56

⎯

⎯

Reverse Leakage Current (Note 8) Per Element

I

R

⎯

⎯

2.5 10 mA

⎯

⎯

Notes: 5. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.

6. Polyimide PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com.

7. Polyimide PCB, 2 oz. Copper. Cathode pad dimensions 9.4mm x 7.2mm. Anode pad dimensions 2.7mm x 1.6mm.

8. Short duration pulse test used to minimize self-heating effect.

POWERDI is a registered trademark of Diodes Incorporated.

PDS1040CTL

Document number: DS30485 Rev. 13 - 2

2 of 5

www.diodes.com

⎯ ⎯

V

IR = 500µA

I

F

IF = 5A, TS = +100°C

IF = 5A, TS = +125°C

V

I

F

IF = 10A, TS = +100°C

IF = 10A, TS = +125°C

20 200 µA

3 25 mA

15 150 µA

V

V

VR = 35V, TS = +25°C

V

6 80 µA

1 5 mA

V

VR = 17.5V, TS = +100°C

= 5A, TS = +25°C

= 10A, TS = +25°C

= 40V, TS = +25°C

R

= 40V, TS = +100°C

R

= 35V, TS = +100°C

R

= 17.5V, TS = +25°C

R

February 2014

© Diodes Incorporated

P, P

OWER

P

TIO

N

T

T

O

U

FORWAR

C

URRENT

NSTAN

TANEO

US R

R

CUR

REN

T

C

,

T

O

T

CAP

C

I

TANC

pF)

R

G

FORWAR

C

URR

N

T

PDS1040CTL

4

(A)

(W)

3

D

A

2

DISSI

D

1

S

ANE

AN

F

0

0132

I , AVERAGE FORWARD CURRENT (A)

F(AV)

4567 8910

Fig. 1 Forwar d Power Dissipation, Per Element

I , INS

0100
V , INSTANTANEOUS FORWARD VOLTAGE (mV)

F

200 300 400

500

600

700

Fig. 2 Typical Forward Characteristics, Per Element

100

(mA)

10

1

0.1

0.01

0.001
0

V , INSTANTANEOUS REVERSE VOLTAGE (V)

R

10

5

15

20

25 30 4035

Fig. 3 Typical Reverse Characteristics, Per Element

E (

A

AL

T

SE

EVE

R

I, I

0 10203040

V , INSTANTANEOUS REVERSE VOLTAGE (V)

R

Fig. 4 Typical Reverse Characteristics, Per Element

7.5

(A)

6.0

E

D

4.5

Note 7

3.0

E
A

Note 5

1.5

F(AV)

I, AVE

0

V , DC REVERSE VOLTAGE (V)

R

Fig. 5 Total Capacitance vs. Reverse Voltage, Per Element

0

25 50 75 100

T , AMBIENT TEMPERATURE (°C)

A

Fig. 6 Forwar d Current Derating Curve, Per Element

125 150

POWERDI is a registered trademark of Diodes Incorporated.

PDS1040CTL

Document number: DS30485 Rev. 13 - 2

3 of 5

www.diodes.com

February 2014

© Diodes Incorporated

T

RAT

T TEMP

R

TUR

C

PDS1040CTL

)

200

Note 5

E (°

160

A
E

120

80

ED AMBIEN

40

, DE

A

0

0

10

V , DC REVERSE VOLTAGE (V)

R

20 30 40

Fig. 7 Operating Temperatur e Derating, Per Element

Package Outline Dimensions

Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.

D

b2

E

e

b1

b1

A

A2

D2

L

POWERDI®5

Dim Min Max

A 1.05 1.15
A2 0.33 0.43
b1 0.80 0.99
b2 1.70 1.88

D 3.90 4.05
D2 3.054 Typ

E 6.40 6.60

E1

E2

e 1.84 Typ

W

L1

E1 5.30 5.45
E2 3.549 Typ

L 0.75 0.95

L1 0.50 0.65

W 1.10 1.41

A2

All Dimensions in mm

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

Y

Y1

(2x)

POWERDI is a registered trademark of Diodes Incorporated.

PDS1040CTL

Document number: DS30485 Rev. 13 - 2

X1

(2x)

X

Dimensions Value (in mm)

C 1.840
G 0.852

X 3.360

X1 1.390

Y 4.860

Y1 1.400

G

C

4 of 5

www.diodes.com

February 2014

© Diodes Incorporated
