DigiTech Bass Whammy User Manual

Owner’s Manual

ELECTROMAGNETIC COMPATIBILITY

This device complies with part 15 of the FCC Rules and
the Product Specifications noted on the Declaration
of Conformity. Operation is subject to the following
two conditions:

These symbols are internationally accepted symbols that warn of potential
hazards with electrical products. The lightning flash means that there are
dangerous voltages present within the unit. The exclamation point indi­cates that it is necessary for the user to refer to the owner’s manual.

These symbols warn that there are no user serviceable parts inside the
unit. Do not open the unit. Do not attempt to service the unit yourself.
Refer all servicing to qualified personnel. Opening the chassis for any
reason will void the manufacturer’s warranty. Do no get the unit wet. If
liquid is spilled on the unit, shut it off immediately and take it to a dealer
for service.

Disconnect the unit during storms to prevent damage.

If you want to dispose this product, do not mix it with general household waste. There is a
separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.

Private household in the 25 member states of the EU, in Switzerland and Norway may return their used
electronic products free of charge to designated collection facilities or to a retailer (if you purchase a similar
new one).

For Countries not mentioned above, please contact your local authorities for a correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and
recycling and thus prevent potential negative effects on the environment and human health.

• this device may not cause harmful
interference, and

• this device must accept any interference received,
including interference that may cause undesired
operation.

Operation of this unit within significant
electromagnetic fields should be avoided.

• use only shielded interconnecting cables.

Warning

For your protection, please read the following:

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Do not use this apparatus near water.

5. Clean only with dry cloth.

6. Do not block any ventilation openings. Install in accor­dance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

8. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.

9. Unplug this apparatus during lightning storms or when
unused for long periods of time.

10. No user serviceable parts inside. Refer all servicing to

qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.

11. WARNING: To reduce the risk of fire or electric

shock, do not expose this apparatus to rain or mois­ture.

12. Refer to labels on the unit, including bottom cover, or

other markings and pertinent information.

DECLARATION OF CONFORMITY

Manufacturer’s Name: DigiTech
Manufacturer’s Address: 8760 S. Sandy Parkway
Sandy, Utah 84070, USA

declares that the product:

Product name: Bass Whammy
Product option: all (requires Class II power adapter that
conforms to the requirements of EN60065,
EN60742, or equivalent.)

conforms to the following Product Specifications:
Safety: IEC 60065 -01+Amd 1
EMC: EN 55022:2006
EN 55024:1998
FCC Part 15

Supplementary Information:

The product herewith complies with the requirements of the:
Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC.
RoHS Directive 2002/95/EC
WEEE Directive 2002/96/EC
EC Regulation 278/2009

With regard to Directive 2005/32/EC and EC Regulation 1275/2008 of
17 December 2008, this product is designed, produced, and classified as
Professional Audio Equipment and thus is exempt from this Directive.

Roger Johnsen
Director, Engineering
Signal Processing
8760 S. Sandy Parkway
Sandy, Utah 84070, USA
Date: March 26, 2012

European Contact: Your local DigiTech Sales and Service Office or

Harman Signal Processing
8760 South Sandy Parkway
Sandy, Utah
84070 USA
Ph: [phone]
Fax: [phone]

Warranty

We at DigiTech® are very proud of our products and back-up each one we sell with the following warranty:

1. Please register online at www.digitech.com within ten days of purchase to validate this warranty. This

warranty is valid only in the United States.

2. DigiTech warrants this product, when purchased new from an authorized U.S. DigiTech dealer and

used solely within the U.S., to be free from defects in materials and workmanship under normal use and
service. This warranty is valid to the original purchaser only and is non-transferable.

3. DigiTech liability under this warranty is limited to repairing or replacing defective materials that show

evidence of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION,
where all parts and labor will be covered up to a period of one year (this warranty is extended to a
period of six years when the product has been properly registered through our website). A Return
Authorization number may be obtained from DigiTech by telephone. The company shall not be liable for
any consequential damage as a result of the product’s use in any circuit or assembly.

4. Proof-of-purchase is considered to be the responsibility of the consumer. A copy of the original

purchase receipt must be provided for any warranty service.

5. DigiTech reserves the right to make changes in design, or make additions to, or improvements upon this

product without incurring any obligation to install the same on products previously manufactured.

6. The consumer forfeits the benefits of this warranty if the product’s main assembly is opened and

tampered with by anyone other than a certified DigiTech technician or, if the product is used with AC
voltages outside of the range suggested by the manufacturer.

7. The foregoing is in lieu of all other warranties, expressed or implied, and DigiTech neither assumes nor

authorizes any person to assume any obligation or liability in connection with the sale of this product. In
no event shall DigiTech or its dealers be liable for special or consequential damages or from any delay in
the performance of this warranty due to causes beyond their control.

NOTE: The information contained in this manual is subject to change at any time without notification. Some
information contained in this manual may also be inaccurate due to undocumented changes in the product or
operating system since this version of the manual was completed. The information contained in this version of
the owner’s manual supersedes all previous versions.

Congratulations on the purchase of your new Bass Whammy™ Pedal. Designed specifically

for bass, the Bass Whammy offers DigiTech’s latest pitch shifting technology, classic Whammy
pitch bending effects, and true bypass operation. The added Classic/Chords switch toggles
between single note and chordal Whammy modes, providing rock solid pitch shifting effects.

The Bass Whammy interface features the same legacy Bass Whammy pitch bending options you’re
accustomed to along with some additional pitch bend settings from its guitar counterpart.

Features:

• Whammy Pitch Bending Effects

• Classic Whammy Interface

• Classic/Chords Switch

• True Bypass Operation

• MIDI In for Remote Control of Whammy Effects

• Included Power Supply

Included Items:

• Bass Whammy Pedal

• Power Supply

• Warranty Registration Information Card

If anything is missing, please contact the factory at once.

Page 1

Guided Tour

Detailed Description

Page 2

OCT 2OCT

OCT 10TH

OCT OCT

OCT 4TH

5TH OCT

5TH 5TH
