Digi Tech Bass Driver Owner's Manual

Warning

For your protection, please read the following:

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Do not use this apparatus near water.

5. Clean only with dry cloth.

6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

8. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.

9. Unplug this apparatus during lightning storms or when
unused for long periods of time.

10. No user serviceable parts inside. Refer all servicing to
qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does
not operate normally,or has been dropped.

11.WARNING:To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture.

12. Refer to labels on the unit, including bottom cover, for
other markings and pertinent information.

DECLARATION OF CONFORMITY

Manufacturer’s Name: DigiTech
Manufacturer’s Address: 8760 S. Sandy Parkway

Sandy,Utah 84070, USA

declares that the product:

Product name: Bass Driver

Product option: all (requires Class II power

adapter that conforms to the
requirements of EN60065,
EN60742, or equivalent.)

conforms to the following Product Specifications:

Safety: IEC 60065 (1998)

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the Low
Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC as
amended by Directive 93/68/EEC.

Vice-President of Engineering
8760 S. Sandy Parkway
Sandy,Utah 84070, USA
Date:August 12, 2002

European Contact: Your local DigiTech Sales and

Service Office or

Harman Music Group
8760 South Sandy Parkway
Sandy,Utah
84070 USA
Ph: [phone]
Fax: [phone]

WARRANTY: We at DigiTech are proud of our products and back-up each one with the following warranty:

1.The warranty registration card must be mailed within ten days after purchase date to validate this war­ranty.

2. DigiTech warrants this product, when used solely within the U.S.,to be free from defects in materials
and workmanship under normal use and service.

3. DigiTech liability under this warranty is limited to repairing or replacing defective materials that show
evidence of defect, provided the product is returned to DigiTech WITH RETURN AUTHORIZATION,
where all parts and labor will be covered up to a period of one year (this warranty is extended to a
period of six years when the product has been properly registered by mail or through our website).
A Return Authorization number may be obtained from DigiTech by telephone.The company shall not
be liable for any consequential damage as a result of the product's use in any circuit or assembly.

4. Proof-of-purchase is considered to be the burden of the consumer.

5. DigiTech reserves the right to make changes in design, or make additions to, or improvements upon
this product without incurring any obligation to install the same on products previously manufactured.

6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam­pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt­ages outside of the range suggested by the manufacturer.

7.The foregoing is in lieu of all other warranties, expressed or implied,and DigiTech neither assumes nor
authorizes any person to assume any obligation or liability in connection with the sale of this product.
In no event shall DigiTech or its dealers be liable for special or consequential damages or from any
delay in the performance of this warranty due to causes beyond their control.

NOTE:The information contained in this manual is subject to change at any time without notification. Some
information contained in this manual may also be inaccurate due to undocumented changes in the product or
operating system since this version of the manual was completed.The information contained in this version
of the owner's manual supersedes all previous versions.

The Bass Driver Distortion is the world’s most advanced overdrive
pedal designed specifically for bass. DigiTech’s exclusive AudioDNA™
technology is what makes the Bass Driver more than a standard
overdrive stompbox. Rather than working with a single distortion
circuit, the Bass Driver features a Morph knob that blends three totally
distinct overdrive and distortion types. You now get a wide variety of
overdrive sounds that can be dialed in quickly and easily.

1. Level Knob

Controls the effect’s output level. Turn this knob clockwise to increase
the output level, and counter-clockwise to decrease the output level.

2.Tone Knob

Controls the boost or cut of high frequencies. Turn this knob clockwise
to increase the high frequency content, and counter-clockwise to
decrease the high frequency content.

3.AC Adapter Jack

Connect a DigiTech PS200R power supply to this jack. Use the proper
supply for your area’s Mains line voltage.

11
10

152 3 4

6

9

7

8

4. Blend Knob

Controls the dry/distortion mix. Blending in dry signal helps maintain
the bottom end that is usually lost when using a standard overdrive or
distortion stompbox. At the Blend knob’s minimum position, only dry
signal is heard. At the Blend knob’s maximum position, only distortion
signal is heard. Experimenting with different Blend and Morph knob
settings provides tremendous flexibility in the overall distortion sound.

5. Morph Knob

Morphs the three different distortion sounds. The minimum position is
a light overdrive tone. The 12 o’clock position is a warm fat distortion
sound. The maximum position is a classic high gain fuzz that will push
your bass tone over the edge when you need it. Experiment with
different Morph and Blend knob settings to hear the wide variety of
sounds the Bass Driver is capable of creating.

6. Input Jack

Connect your instrument to this jack. Connecting a 1/4” instrument
cable to this jack engages battery power even though the Indicator LED
may not be lit. To prolong battery life, disconnect all cables from the
pedal when not in use.

7. Pedal Release Pins

These two pins are spring-loaded hinges that hold the pedal in place.
Push these pins in to release the pedal from the chassis exposing the
battery compartment. (See battery replacement diagram.)

8. Pedal

Turns the effect on and off.

9. Out 1(Amp) Jack

Connect this output to your bass amplifier.

10. Indicator LED

Indicates when the effect is turned on. If the LED becomes dim or does
not light when the cables are connected, the battery needs to be
replaced.

11. Out 2 (Mixer) Jack

This output features DigiTech’s CIT™ cabinet modeling technology, that
lets you run the pedal directly into a mixer or recorder input without
having to use a bass amplifier. The CIT model is based on a 4x10
cabinet.

Connections

The Bass Driver has a single input (INPUT) and a pair of outputs (AMP
and MIXER). The two outputs give you the following options: running
into a bass amplifier, running directly to a mixing console or recording
device, or both. The MIXER output uses DigiTech’s advanced CIT™
cabinet modeling technology for an authentic bass amplifier sound
without using an amp. The CIT model is based on a 4x10 cabinet.

Follow these setup directions:

1.Turn the volume down on the amplifier/mixer you are connecting to.

2. Connect the pedal output to the amplifier/mixer input.

3. Connect the bass to the pedal input.

4. Connect the power supply to the pedal (optional).

5.Turn the LEVEL knob on the pedal to the minimum position.

6.Turn up your amplifier/mixer level to the preferred listening level.

7.Turn on the effect by pressing the PEDAL switch, and turn the

LEVEL knob up to the preferred listening level.

Battery Replacement

1. Using the tip of a 1/4” cable, push one of the release pins in on either
side of the pedal, and remove the pedal from the pedal chassis.

2. Remove the battery from the battery compartment and disconnect
the battery cable.

3. Connect a new battery to the battery cable and put it back in the
battery compartment. Make sure the battery cable does not interfere
with the spring or pedal switch arm.

4. Place one hole of the pedal over its corresponding pin.

5. Push the opposite pin in and lower the other side of the pedal into
place over the depressed pin. Release the pin. When the pedal is
properly fastened, both released pins are flush with the outer side of
the pedal.

9V DC Battery

Pedal Release
Pin

Pedal Chassis

Pedal

Pedal Switch

Arm

Pedal Release

Pin

Battery

Compartment

Spring

DigiTech

8760 South Sandy Parkway

Sandy, Utah 84070

PH [phone]

FAX [phone]

DigiTech and X-Series are trademarks

of the Harman Music Group Inc.

Copyright - Harman Music Group

Bass Driver Overdrive/Distortion

Owners Manual 18-1812V-A

Please visit DigiTech

on the World Wide Web at:

www.digitech.com

Printed in China

SPECIFICATIONS:

• Controls - Level,Tone, Blend, Morph,

On/Off Pedal

• Jacks - Input, Out 1 (Amp), Out 2

(Mixer)

• Input Impedance - 1 MOhms

• Output Impedance - 100 Ohms

• Power Supply - 9V Alkaline Dry Battery

• Power Consumption - 4.8Watts

(w/optional PS200R power supply)

• Battery Life - Approximately 4 hours

(with continuous usage)

• Dimensions - 4 15/16”(L) x 3 1/8”(W)

x 2 1/8”(H)

• Weight - 1.38 lbs.

• Optional Power Supply

PS200R - 100 (100V ~ 50/60Hz)
PS200R - 120 (120V ~ 60Hz)
PS200R - 230 (230V ~ 50Hz)
PS200R - 240 (240V ~ 50Hz)
