Detcon 1610-N4X User Manual

m

Model 1610-N4X

NEMA 4X Control Enclosure

Operator’s Installation and Instruction Manual

Covers 1610-N4X and 1610-N4X-BBU

In Fiberglass and Stainless Steel Enclosures

4055 Technology Forest, Suite 100

The Woodlands, Texas 77381

Ph.281.367.4100 / Fax 281.298.2868

December 14, 2011 • Document #2881 • Revision 1.4

DETCON, Inc.

www.detcon.co

Model 1610-N4X

This page left intentionally blank

1610-N4X Instruction Manual ii

Model 1610-N4X

Table of Contents

1.0

Introduction.............................................................................................................................................. 1

1.1 Description ........................................................................................................................................... 1

1.2 Specifications ....................................................................................................................................... 1

1.3 Auxiliary Alarm Relay Board (AARB)................................................................................................ 2

1.4 Remote Alarm Reset ............................................................................................................................ 3

2.0 Installation................................................................................................................................................ 3

2.1 Alarm and Fault Jumpers ..................................................................................................................... 5

2.2 Start Up ................................................................................................................................................ 6

3.0 Maintenance & Repair ............................................................................................................................ 7

4.0 Spare Parts List........................................................................................................................................ 8

5.0 Warranty .................................................................................................................................................. 8

Table of Figures

Figure 1 Auxiliary Alarm Relay Board ................................................................................................................ 2

Figure 2 Mounting of Fiberglass Enclosure ......................................................................................................... 3

Figure 3 Mounting of SS Enclosure..................................................................................................................... 4

Figure 4 Motherboard Wiring Diagram ............................................................................................................... 5

Figure 5 Backplane Configuration Jumpers......................................................................................................... 6

Figure 6 Power Supply Wiring............................................................................................................................. 7

1610-N4X Instruction Manual iii

Model 1610-N4X

This page left intentionally blank

Shipping Address: 4055 Technology Forest, Suite 100, The Woodlands Texas 77381

Mailing Address: P.O. Box 8067, The Woodlands Texas 77387-8067

Phone: 888.367.4286, 281.367.4100 • Fax: 281.292.2860 •

1610-N4X Instruction Manual iv

www.detcon.com • sales@detcon.com

Model 1610-N4X

1.0 Introduction

Detcon Model 1610-N4X Gas Detection System consists of 3 major assemblies:

1. The 1610-N4X Fiberglass or Stainless Steel control enclosure.

2. The Model 10 single channel digital control modules.

3. The remote mount gas sensor assemblies.

The NEMA 4X control enclosure is detailed in this manual; the Model 10 Control Modules are detailed in the Detcon Model 10 Operators Installation and Instruction Manual, and applicable sensor assemblies in their corresponding Operators Installation and Instruction Manual.

1.1 Description

Detcon Model 1610-N4X control enclosure, along with Model 10 Control Modules, is designed to serve as a host assembly for up to sixteen remote mount gas detection sensors. The control enclosure is rated NEMA 4X, which is by definition rain tight and therefore suitable for outdoor location in electrically non-hazardous environments. All control modules are plug-in front panel accessible for easy maintenance and repair. The unit is powered by 110~240VAC unless otherwise specified at the time of order.

Discrete output terminal strips located on the controller motherboard are provided for sensor terminations. 420mA outputs for remote recording devices and an RS-485 serial ModBus™ output are also located on the motherboard. VDC power in, and remote alarm reset terminations are also provided on the Motherboard.

Form-C relay outputs from each Control Module are provided for Alarm 1, Alarm 2, and Fault conditions. These relay outputs can be configured as discrete or zoned as determined by jumpers located between the channels on the motherboard and the relay settings determined by the dipswitches on the Model 10 Control Modules.

1.2 Specifications

Electrical Classification

NEMA 4X

Dimensions

25½ “W x 23''H x 10½”'D

Capacity

16 single channels

Power Input

110~240VAC/24VDC

Power Consumption

<5 watts per channel (includes gas sensor and control modules; Does not include annunciators.)

Outputs

Discrete Analog 4-20mA DC Serial RS-485 Modbus™ Discrete or zoned alarm relays (Alarm 1, Alarm 2, and Fault located on associated Mod 10 Control Modules. See the appropriate Mod 10 Control Module Manual for more information.)

Operating Temperature Range

-40°C to +75°C Battery Backup (If applicable) 2ea. 12V 6.5-7.2Ah batteries in series; ½ hour minimum operating time Low Voltage Cut-off Board

Warranty

One year

1610-N4X Instruction Manual Rev. 1.4 Page 1 of 10

1.3 Auxiliary Alarm Relay Board (AARB)

An Auxiliary Alarm Relay Board is included with each Detcon Model 1610-N4X. The board is mounted on the bottom quadrant of the motherboard. The AARB (Figure 1) consists of four interposing relays (contacts are rated 10Amp @ 120 VAC and 8Amp @ 30 VDC) with 24VDC coils. The AARB can be configured for Form-C dry contacts (common, normally open and normally closed), AC power, or DC power.

Model 1610-N4X

2.50

3.04

2.85

3.35

Figure 1 Auxiliary Alarm Relay Board

Ø0.165 X4

An ‘IN/OUT’ termination is provided for applying AC or DC power to any one of the interposing relays. A gold plated jumper tab is used to apply the power option to the corresponding relay(s). The 4 relays may be used in any combination of Form-C dry contacts, DC outputs, and AC outputs. The terminations labeled “ALM COIL PWR” (P20) located on the lower left of the motherboard are used to power the relay coils on the AARB. Terminals P1+4, P1+3, P1+2, and P1+1 on the AARB provide for various relay logic setups through the Form-C dry contact terminals of each Model 10 Control Module. P1-COM on the AARB should be wired directly back to P20-2 (ALM COIL PWR (-)) on the motherboard.

The terminations labeled “ALM PWR” located on the left of the 1610-N4X motherboard can be used to provide power to the In/Out termination on the AARB (AARB P2-IN/OUT). Alarm power terminations for AC (P18) come directly from the AC input terminals (P16) on the 1610-N4X motherboard. The DC power terminations at P18 come directly from the VDC IN Terminals (P15).

NOTE: DC power used to drive alarms must be obtained through a remote DC power source. The remote DC power source should be terminated at P15 labeled “VDC IN” located on the 1610-N4X motherboard. P15 (VDC IN) functions as both an alternative DC power source used to power the 1610N4X and as power for DC alarms. The 1610-N4X power supply is not designed to provide power for alarm devices.

1610-N4X Instruction Manual Rev. 1.4 Page 2 of 10

Model 1610-N4X

NOTE: If the Battery Option is installed (1610-N4X-BBU), the batteries are connected to P15 (VDC IN). Do not use the DC output of “ALM POWER” (P18-1 and P18-2). The Batteries are not designed to provide power for alarm devices.

Mounting hardware is provided on the 1610-N4X motherboard for two additional Auxiliary Alarm Relay Boards.

1.4 Remote Alarm Reset

A remote mounted normally open momentary switch may be used to reset the alarms of all Model 10 controllers. “ALM RESET” (P14-1 and P14-2) provides a set of terminals to connect the switch across every Model 10 Controller (Figure 4). The reset function is effective when the Model 10’s respective alarms have been programmed in the latching position and alarm conditions have passed. Each Model 10 controller also has its own discrete alarm reset switch, discussed further in the Model 10 Controller Manual.

2.0 Installation

1. Securely mount the 1610-N4X Enclosure in accordance with Figure 2 or Figure 3.

17.85" 10.0"

10.3"25.59"

CIRCUIT BREAKER

5 AMP

Model 1610-N4X

Detcon Inc.

Gas Detection Control System

www.detcon.com

TexasHouston

Houston Texas

22.85"21.70"

Figure 2 Mounting of Fiberglass Enclosure

1610-N4X Instruction Manual Rev. 1.4 Page 3 of 10

Model 1610-N4X

MODEL 10

ALM 2

ALM 1

FAULT

ALARM

RESET

TEST

ALM 2

ALM 1

FAULT

ALARM

RESET

TEST

www.detcon.com

MODEL 10

ALM 2 ALM 1 FAULT

ALARM

RESET

TEST

ALM 2

ALM 1

FAULT

ALARM

RESET

TEST

ALM 2

ALM 1

FAULT

ALARM

RESET

TEST

27.85 28.6 29.6

23.5

24.75

Ø0.31

9.75

9.85

Figure 3 Mounting of SS Enclosure

2. Refer to installation and wiring detail of remote mount sensor assemblies as detailed in the Sensor

Instruction Manual. Terminate field wiring from sensors on the 1610-N4X motherboard. Terminals are labeled “Sensor” (mA, + and –, Figure 4).

3. If applicable, terminate the discrete 4-20mA outputs to external device(s). Terminals are labeled “4-

20 Out” (+ and –, Figure 4).

4. If applicable, terminate the RS-485 serial output to external device(s). Terminals are labeled “RS-

485” (A+, B–, and Shield, Figure 4). If applicable, terminate RS-485 Shield to Earth Ground via the jumper tab located to the left of the RS-485 terminals. Place the jumper on the bottom 2 contacts to tie RS-485 shield to Earth Ground or place the jumper tab on the top two terminals for storage.

5. If applicable a Remote Reset Switch can be utilized by connecting a Momentary, Normally-Open

Switch to P14 (ALM RESET).

6. Earth Ground can be connected to the ground point located in the lower left quadrant of the

motherboard.

7. If applicable, connect a 24VDC source or standby battery to the terminal strip labeled “VDC IN”

(P15+ and –) on the Motherboard (Figure 4).

NOTE: If the unit has the Battery Backup Option installed (1610-N4X-BBU), do not connect an external power source to P15.

8. Connect 110/220VAC input wiring to the terminals labeled “VAC IN”; P16-1 (L), P16-2 (N), and

P16-GND Ground (Figure 4). The Power Supply will accept input voltages from 100 to 240VAC, 50/60Hz.

1610-N4X Instruction Manual Rev. 1.4 Page 4 of 10

Model 1610-N4X

BRKR

1 2

P11

D2 6A 50V

D1 6A 50V

RS-485

Shield to Gnd

JP10

Earth

Ground

Tie to

Chassis

A1 C1

C2A2

A3 C3

C4A4 A5 C5 A6 C6

C7A7 A8 C8

C9A9

A10 C10 A11 C11

C12A12

A13 C13

C14A14 A15 C15 A16 C16

CH1 CH2-CH116

P11

1

+

2

mA

3

NC

4

NO

5

COM

6

NC

7

NO

COM

OUT

8 9

NC

10

NO

11 12

+

13 14

ALM 1

4-20 FAULT SENSORALM2

AL1-NO AL1-NC

Al1-COM

485-A

RST 485-S 485-B

XMXMXM-

VDCVDCVDC-

Typical

Jumpers

JP1-JP15

--

A

B

C

D

E

F

G

H

I

A1 C1

C2A2

A3 C3

C4A4 A5 C5 A6 C6

C7A7 A8 C8

C9A9

A10 C10 A11 C11

C12A12

A13 C13

C14A14 A15 C15 A16 C16

P12-P26

1 2 3 4 5 6 7 8

9 10 11 12 13 14

Al2-COM Al2-NC Al2-NO FLT-COM FLT-NC FLT-NO 4-20 OUT 4-20 IN

-XM+ XM+ XM+

-VDC+ VDC+ VDC+

GND

L1

ALM RESET

GND

A(+)

B(-)

Shld

ALM POWER

P18

P19

GND

PS DC

+

-

PS VAC

1

N

2 3

VDC IN

+

-

VAC IN

L1

N

RS-485

+

-

L1

N

ALM COIL

+

-

1 2

P12

P13

1 2

P14

1 2

P15

1 2 3

P16

1 2 3

P17

1 2 3 4 5

1 2

P20

Figure 4 Motherboard Wiring Diagram

2.1 Alarm and Fault Jumpers

A bank of jumpers is provided between each channel for use in setting up alarm and fault schemes. These jumpers can be installed or removed to create discrete or zoned alarm/fault schemes in conjuncture with the Model 10 Control Module relay settings. With all of the jumpers installed on the motherboard, the relays on the Control Modules are placed in parallel with each other. (I.E. All of the Alarm 1 relays are in parallel, all of the Alarm 2 relays are in parallel, and all of the Fault Relays are in parallel.) In this configuration, the normally open (“NO”) contacts of the relays would be used to generate an alarm or fault condition, as contact closure on any Control Module would create continuity between the “COM” contact and the “NO” contact output for that alarm or fault. A scheme for alarms should be conceived before power is applied to the unit, and the unit should be set up accordingly. For aid in setting up an appropriate alarm/fault scheme, contact Detcon Customer Service.

1610-N4X Instruction Manual Rev. 1.4 Page 5 of 10

, H,

Model 1610-N4X

CH...CH2 CH14 CH15

A B C D E F

G

H

I

JP2

1 2 3

A

4

B

5

C

6

D

7

E

9

F

9

G

10

H

11

I

12

JP...

13 14

1 2 3 4 5 6 7 9 9 10 11 12 13 14

A B C D E F

G

H

I

JP14

CH16

1 2 3

A

4

B

5

C

6

D

7

E

9

F

9

G

10

H

11

I

12

JP15

13 14

1 2 3 4 5 6 7 9 9 10 11 12 13 14

Alarm 2 Jumper positions A, B, anc C.

Alarm 1 Jumper positions D, E, and F.

Fault Jumper positions

and I.

G

mA

SENSORALM2

NC NO C NC NO

ALM 1

NC NO

OUT

4-20 FAULT

CH1

1

+

-

2 3

A

4

B

5

C

6

D

7

E

9

C

+

-

F

9

G

10

H

11

I

12

JP1

13 14

1 2 3 4 5 6 7 9 9 10 11 12 13 14

Figure 5 Backplane Configuration Jumpers

2.2 Start Up

Upon completion of all field wiring: Apply power to the 1610-N4X by setting the 5Amp Circuit Breaker (the Circuit Breaker is also a Power Switch, labeled ‘5Amp’) on the front on the Card Cage. Note that each Model 10 controller digital display illuminates.

NOTE: Varying readings may occur during sensor warm-up. A 10 second alarm delay will occur on power up. Refer to the applicable Sensor Instruction Manual for additional sensor start-up details.

1610-N4X Instruction Manual Rev. 1.4 Page 6 of 10

3.0 Maintenance & Repair

The Detcon Model 1610-N4X’s modular design allows for minimum ‘down-time’ during maintenance and/or repair.

Model 10 Control Modules

A Model 10 control module may be changed by simply loosening its mounting screw and sliding the module out of its card cage. See the Model 10 Instruction Manual for more information on the Model 10 controllers.

Circuit Breaker/Power Switch

If the 3Amp Circuit Breaker/Power Switch should trip due to a high current or over voltage, the circuit breaker can be reset by pushing the breaker in (‘ON’). If the breaker trips again, a problem has occurred that will need to be alleviated before power can be restored.

NOTE: The circuit Breaker/Power Switch does not remove VAC from the Power Supply or the Motherboard. If power is to be completely removed from the unit, the VAC must be disconnected from the source.

NOTE: On units with Battery Backup installed (1610-N4X-BBU), the Circuit Breaker will remove power from the Unit, but does not disconnect the Battery circuit from the Motherboard or the Low Voltage Cutoff Board. The Batteries must be unplugged as well as disconnecting the VAC from the source to remove power completely from the unit.

Model 1610-N4X

CB1-1 / P1-2 (Red)

1

2

CB1-2 / P1-1 (Red)

CB1-1 / TB4-1 (Red)

1

CB1 5Amp

P1

1 2 3 4

2

Low-Voltage

Cut-off

(LV)

CB1-2 / P1-1 (Red)

LVP2-1 / CB1-1 (Red)

1

LVP2-2 / PS-(-V) (Blk)

2

P2

Power Supply Wiring - With Battery Backup

MADE IN CHINA

V ADJ

MADE IN CHINA

V ADJ

H

(Blk) P3-2 / PS-N

(Blk) LVP2-2 / PS-(-V)

(Wht) P3-3 / PS-L

(Grn) P3-1 / PS-(Gnd)

(Blk) P3-2 / PS-N

(Wht) P3-3 / PS-L

(Grn) P3-1 / PS-(Gnd)

(Blk) P2-2 / PS-(-V)

(Red) P2-1 / PS-(+V)

H

(Blk) P2-2 / PS-(-V)

(Red) P2-1 / PS-(+V)

P11

P12

P13

P11

1N4001

P12

P13

GND

BRKR

+

-

PS VAC

N

L1

BRKR

+

-

PS VAC

N

L1

PS DC

1 2

1 2 3

1 2

1 2 3

P1-1 / CB1-2 (Red) P1-2 / CB1-1 (Red)

P2-1 / PS-(+V) (Red) P2-2 / PS-(-V) (Blk)

P3-1 / PS-(Gnd) (Grn) P3-2 / PS-N (Wht) P3-3 / PS-L (Blk)

P1-1 / CB1-2 (Red) P1-2 / LVP1-1 (Red)

Note: 1N4001 diode added to charge batteries

P2-1 / PS-(+V) (Red) P2-2 / PS-(-V) (Blk)

P3-1 / PS-(Gnd) (Grn) P3-2 / PS-N (Wht) P3-3 / PS-L (Blk)

Circuit Breaker

CB1 5Amp

Circuit Breaker

P2-1 / LVP1-1 (Red)

Power Supply Wiring - without Battery Backup

Figure 6 Power Supply Wiring

1610-N4X Instruction Manual Rev. 1.4 Page 7 of 10

Power Supply

Replacement of the power supply is accomplished by, removing the 10 screws that secure the 1610-N4X face plate, disconnecting all wiring to/from the power supply, and removing the three screws holding the power supply bracket to the Motherboard. Remove the four screws that hold the power supply bracket to the power supply and reassembly with the new power supply. (Figure 6) Power Supply wiring is different between units with and units without the battery backup option; attention should be paid to the correct wiring scheme for the unit being worked on.

4.0 Spare Parts List

Part # Description 224 Gold plated jumper tab 320-228861-105 5Amp Circuit Breaker/Power Switch 360-SWS300-024 300 watt, 24 VDC switching power supply 500-502600-000 Auxiliary Alarm Relay Board 500-505000-000 Low Voltage Cut-off PCB (Battery Backup Units only) 344-400000-000 12V 6.5Ah Battery (Battery Backup Units only)

Model 1610-N4X

5.0 Warranty

Detcon Inc., as manufacturer, warrants under intended normal use each new Model 1610-N4X NEMA 4X control enclosure to be free from defects in material and workmanship for a period of one year. The warranty period begins from the date of shipment to the original purchaser and ends one year thereafter. All warranties and service policies are FOB the Detcon Inc. facility located in The Woodlands, Texas.

1610-N4X Instruction Manual Rev. 1.4 Page 8 of 10
