UNVENTED (VENT-FREE)
PROPANE/LP GAS LOG HEATER
VARIABLE MANUALLY-CONTROLLED MODELS ALSO DESIGN-CERTIFIED
AS VENTED DECORATIVE APPLIANCES
OWNER’S OPERATION AND INSTALLATION MANUAL
VFP18R
VFP24R
VFP30R
18", 24", and 30"
Remote-Ready
EMBER MASTER™
O
L
O
L
T
I
P
O
N
F
F
O
HI
E
T
O
M
E
R
F
F
O
N
O
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
WARNING: Improper installation, adjustment, alteration, service, or maintenance
can cause injury or property damage. Refer to this manual for correct installation
and operational procedures. For assistance or additional information consult a
qualified installer, service agency, or the
gas supplier.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas sup
plier, call the fire department.
— Installation and service must be performed
by a qualified installer, service agency, or
the gas supplier.
WARNING: This appliance is for installation only in a solid-fuel burning masonry,
UL127 factory-built fireplace, or in an approved ventless firebox. It is design certified for these installations in accordance
with ANS Z21.11.2. Exception: Do not install this appliance in a factory-built fireplace that includes instructions stating it
has not been tested or should not be used
with unvented gas logs.
This appliance may be installed in an aftermarket*, permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Save this manual for future reference.
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
SAFETY
INFORMATION
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, operate, or service this heater. Improper use of this heater can cause
serious injury or death from burns,
fire, explosion, electrical shock,
and carbon monoxide poisoning.
DANGER: Carbon monoxide
poisoning may lead to death!
Carbon Monoxide Poisoning: Early signs of
carbon monoxide poisoning resemble the flu,
with headaches, dizziness, or nausea. If you
have these signs, the heater may not be working properly. Get fresh air at once! Have
heater serviced. Some people are more affected by carbon monoxide than others. These
include pregnant women, people with heart or
lung disease or anemia, those under the influence of alcohol, and those at high altitudes.
Propane/LP Gas: Propane/LP gas is odor-
less. An odor-making agent is added to the gas.
The odor helps you detect a gas leak. However, the odor added to the gas can fade. Gas
may be present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference. It
is your guide to safe and proper operation of
this heater.
WARNING: Any change to
this heater or its controls can be
dangerous.
WARNING: Do not allow fans
to blow directly into the fireplace.
Avoid any drafts that alter burner
flame patterns. Ceiling fans can
create drafts that alter burner
flame patterns. Altered burner
patterns can cause sooting.
WARNING: Do not use a
blower insert, heat exchanger
insert, or other accessory not approved for use with this heater.
Due to high temperatures, the
appliance should be located out
of traffic and away from furniture
and draperies.
Do not place clothing or other
flammable material on or near
the appliance. Never place any
objects on the heater.
Heater base assembly becomes
very hot when running heater. Keep
children and adults away from hot
surface to avoid burns or clothing
ignition. Heater will remain hot for
a time after shutdown. Allow surface to cool before touching.
Carefully supervise young children when they are in the room
with heater. When using the handheld remote accessory, keep selector switch in the OFF position
to prevent children from turning
on burners with remote.
You must operate this heater with
a fireplace screen in place. Make
sure fireplace screen is closed
before running heater.
Keep the appliance area clear and
free from combustible materials,
gasoline, and other flammable
vapors and liquids.
1. This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases.
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/LP
supply tank(s) outdoors.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building
• immediately call your gas supplier
from a neighbor’s phone. F ollow the
gas supplier’s instructions
• if you cannot reach your gas supplier,
call the fire department
2
4. This heater shall not be installed in a bedroom or bathroom, unless installed as a
vented appliance (see Installing
Damper Clamp Accessory for Vented
Operation, page 10).
5. Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote,
ashes, and loose paint by a qualified
chimney cleaner. Creosote will ignite
if highly heated. Inspect chimney flue
for damage. If damaged, operate heater
with flue damper closed.
6. If fireplace has glass doors, never operate this heater with glass doors closed.
If you operate heater with doors closed,
heat buildup inside fireplace will cause
glass to burst. Also if fireplace opening has vents at the bottom, you must
open the vents before operating heater .
7. To prevent the creation of soot, follo w
the instructions in Cleaning and Main-
tenance, page 17.
8. This log heater is designed to be smokeless. If logs ever appear to smoke, turn
off heater and call a qualified service per son.
Note:
During initial operation, slight
smoking may occur due to log curing and
heater burning manufacturing residues.
9. Before using furniture polish, wax, carpet cleaner, or similar products, turn
heater off. If heated, the vapors from
these products may create a white powder residue within burner box or on
adjacent walls or furniture.
10. This heater needs fresh, outside air ventilation to run properly. This heater has
an Oxygen Depletion Sensing (ODS)
safety shutoff system. The ODS shuts
down the heater if not enough fresh air
is available. See Air for Combustion
and Ventilation, pages 4 through 6. If
heater keeps shutting off, see Trouble-
shooting, pages 18 through 20.
11. Do not run heater
• where flammable liquids or vapors
are used or stored
• under dusty conditions
12. Do not use this heater to cook food or
burn paper or other objects.
13. Do not use heater if any part has been
exposed to or under water . Immediately
call a qualified service technician to inspect the room heater and to replace any
part of the control system and any gas
control which has been under water .
105073
OWNER’S MANUAL
SAFETY
INFORMATION
Continued
14. Do not operate heater if any log is broken. Do not operate heater if a log is
chipped (dime-sized or larger).
15. Turn heater off and let cool before servicing, installing, or repairing. When
using the hand-held remote accessory,
make sure the selector switch is in the
OFF position. Only a qualified service
person should install, service, or repair
heater.
16. When using the hand-held remote accessory, make sure the selector switch is in
the OFF position when you are away
from home for long periods of time.
17. This heater must not be connected to
any external electrical source.
18. Operating heater above elevations of
4,500 feet may cause pilot outage.
19. To prevent performance problems, the
use of a propane/LP fuel tank of less than
100 lb. capacity is not recommended.
PRODUCT
IDENTIFICATION
Top Middle Log
Front
Logs
UNPACKING
CAUTION: Do not remove the
metal data plates from the grate
assembly. The dataplates contain
important product information.
1. Remove logs and heater base assembly from carton.
heater base assembly by the burner.
This could damage heater. Always
handle base assembly by grate.
2. Remove all protective packaging applied to logs and heater for shipment.
3. Check all items for any shipping damage. If damaged, promptly inform
dealer where you bought heater.
Crossover Log
Note:
Do not pick up
Rear Log
LOCAL CODES
Install and use heater with care. Follow all
local codes. In the absence of local codes, use
the latest edition of The National Fuel Gas
Code, ANS Z223.1, also known as NFPA 54*.
*Available from:
American National Standards Institute, Inc.
Batterymarch Park
New York, NY 10018
National Fire Protection Association, Inc.
1430 Broadway
Quincy, MA 02269
Note:
Where listed vented decorative logs
are required, thermostat operation is not
permitted.
PRODUCT
FEATURES
OPERATION
This heater is clean burning. It requires no
outside venting. There is no heat loss out a vent
or up a chimney. Heat is generated by both
realistic flames and glowing coals. This heater
is designed for vent-free operation with flue
damper closed. It has been tested and approved to ANS Z21.11.2 standard for
unvented heaters. State and local codes in
some areas prohibit the use of vent-free heaters. This heater may also be operated as a
vented decorative (ANS Z21.60) product by
opening the flue damper (non-thermostat
operation only).
Front
Burner
Piezo
Ignitor
Control Knob
Figure 1 - Ember Master
105073
Flame
Adjustment
Knob
Selector Switch
(Optional)
Base
Assembly
3
Rear
Burner
Bottom
Middle
Log
SAFETY PILOT
This heater has a pilot with an Oxygen
Depletion Sensing(ODS) safety shutoff system. The ODS/pilot is a required feature for
vent-free room heaters. The ODS/pilot shuts
off the heater if there is not enough fresh air.
PIEZO IGNITION SYSTEM
This heater has a piezo ignitor. This system
requires no matches, batteries, or other
sources to light heater.
Continued
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
PRODUCT
FEATURES
Continued
OPTIONAL REMOTE
CONTROL ACCESSORIES
There are four optional remote controls that
can be purchased separately for this log heater:
• wall switch
• wall thermostat
• hand-held ON/OFF remote
• hand-held thermostat remote
See Accessories, page 24.
The wall thermostat or hand-held thermo-
stat control may not be used where vented
decorative listing is required.
AIR FOR
COMBUSTION AND
VENTILATION
WARNING: This heater shall
not be installed in a confined space
or unusually tight construction
unless provisions are provided
for adequate combustion and ventilation air. Read the following instructions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
Today’s homes are built more energy efficient than ever. New materials, increased
insulation, and new construction methods
help reduce heat loss in homes. Home owners
weather strip and caulk around windows and
doors to keep the cold air out and the warm air
in. During heating months, home owners
want their homes as airtight as possible.
While it is good to make your home energy
efficient, your home needs to breathe. Fresh
air must enter your home. All fuel-burning
appliances need fresh air for proper combustion and ventilation.
Exhaust fans, fireplaces, clothes dryers, and
fuel burning appliances draw air from the
house to operate. You must provide adequate fresh air for these appliances. This
will insure proper venting of vented fuelburning appliances.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code, NFPA 54/ANS Z223.1, Section 5.3, Air for Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and windows may provide enough fresh air for
combustion and ventilation. However, in
buildings of unusually tight construction,
you must provide additional fresh air.
Unusually tight construction is defined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a continuous water vapor retarder with
a rating of one perm (6 x 10
per pa-sec-m2) or less with openings gasketed or sealed
b. weather stripping has been
added on openable windows and
doors
c. caulking or sealants are applied
to areas such as joints around
window and door frames, between sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations for plumbing, electrical, and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide additional fresh air. See
From Outdoors
If your home does not meet all of the
three criteria above, proceed to
mining Fresh-Air Flow for Heater Location,
and
page 5.
, page 6
Ventilation Air
.
-11
and
Deter-
kg
Confined and Unconfined Space
The National Fuel Gas Code, ANS Z223.1
defines a confined space as a space whose
volume is less than 50 cubic feet per 1,000
Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed
in that space and an unconfined space as a
space whose volume is not less than 50
cubic feet per 1,000 Btu per hour (4.8 m3 per
kw) of the aggregate input rating of all
appliances installed in that space. Rooms
communicating directly with the space in
which the appliances are installed*, through
openings not furnished with doors, are considered a part of the unconfined space.
This heater shall not be installed in a confined space or unusually tight construction
unless provisions are provided for adequate
combustion and ventilation air.
* Adjoining rooms are communicating only
if there are doorless passageways or ventilation grills between them.
4
105073
OWNER’S MANUAL
AIR FOR
COMBUSTION AND
VENTILATION
Continued
DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION
Determining if You Have a Confined or Unconfined Space
Use this work sheet to determine if you have a confined or unconfined space.
Space: Includes the room in which you will install heater plus any adjoining rooms with doorless passageways or ventilation grills between
the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = _________________ cu. ft. (volume of space)
Example:
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
____________(volume of space) ÷ 50 cu. ft. = (Maximum Btu/Hr the space can support)
Example:
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free heater ______________ Btu/Hr
Gas water heater* ______________ Btu/Hr
Gas furnace ______________ Btu/Hr
Vented gas heater ______________ Btu/Hr
Gas fireplace logs ______________ Btu/Hr
Other gas appliances* + ______________ Btu/Hr
Total = ______________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_________________ Btu/Hr (maximum the space can support)
_________________ Btu/Hr (actual amount of Btu/Hr used)
Example:
The space in the above example is a confined space because the actual Btu/Hr used is more than the maximum Btu/Hr the space can support.
You must provide additional fresh air. Your options are as follows:
A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-
ing room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6.
C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
Space size 20 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2560 cu. ft. (volume of space)
2560 cu. ft. (volume of space) ÷ 50 cu. ft. = 51.2 or 51,200 (maximum Btu/Hr the space can support)
Example:
Gas water heater 40,000 Btu/Hr
Vent-free heater + 33,000 Btu/Hr
Total = 73,000 Btu/Hr
51,200 Btu/Hr (maximum the space can support)
73,000 Btu/Hr (actual amount of Btu/Hr used)
WARNING: If the area in which the heater may be operated is smaller than that defined as an unconfined space
or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of
the methods described in the
105073
National Fuel Gas Code, ANS Z223.1, Section 5.3
5
or applicable local codes.
Continued
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
AIR FOR
COMBUSTION AND
VENTILATION
Continued
VENTILATION AIR
Ventilation Air From Inside
Building
This fresh air would come from an adjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must provide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(see options 1 and 2, Figure 2). You can also
remove door into adjoining room (see option 3, Figure 2). Follow the National Fuel
Gas Code, NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
WARNING: Rework worksheet, adding the space of the
adjoining unconfined space. The
combined spaces must have
enough fresh air to supply all
appliances in both spaces.
12"
Ventilation
Grills
Into Adjoining
Room,
Option 1
Figure 2 - Ventilation Air from Inside Building
Or
Remove
Door into
Adjoining
Room,
Option
3
12"
Outlet
Air
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilated
Attic
Outlet
Air
To Attic
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two permanent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connect these items directly to the outdoors
or spaces open to the outdoors. These spaces
include attics and crawl spaces. Follow the
National Fuel Gas Code, NFPA 54/ANS
Z223.1, Section 5.3, Air for Combustion and
Ventilation for required size of ventilation
grills or ducts.
IMPORTANT:
inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated air
entering the attic will activate the power vent.
Do not provide openings for
Inlet
Air
Inlet Air
Figure 3 - Ventilation Air from Outdoors
6
To
Crawl
Space
Ventilated
Crawl Space
105073
OWNER’S MANUAL
INSTALLATION
NOTICE: This heater is intended
for use as supplemental heat. Use
this heater along with your primary heating system. Do not install this heater as your primary
heat source. If you have a central
heating system, you may run
system’s circulating blower while
using heater. This will help circulate the heat throughout the
house. In the event of a power
outage, you can use this heater
as your primary heat source.
WARNING: A qualified service person must install heater.
Follow all local codes.
NOTICE: State or local codes may
only allow operation of this appliance in a vented configuration.
Check your state or local codes.
WARNING: Make sure the selector switch is in the OFF position before installing heater.
WARNING: Before installing
in a solid fuel burning fireplace,
the chimney flue and firebox must
be cleaned of soot, creosote,
ashes and loose paint by a qualified chimney cleaner. Creosote
will ignite if highly heated. A dirty
chimney may create and distribute soot within the house. Inspect
chimney flue for damage. If damaged, operate heater with flue
damper closed.
WARNING: Seal any fresh air
vents or ash clean-out doors located on floor or wall of fireplace.
If not, drafting may cause pilot
outage or sooting. Use a heatresistant sealant. Do not seal
chimney flue damper.
WARNING: Never install the
heater
• in a bedroom or bathroom unless installed as vented appliance, see page 10
• in a recreational vehicle
• where curtains, furniture, cloth-
ing, or other flammable objects
are less than 42 inches from the
front, top, or sides of the heater
• in high traffic areas
• in windy or drafty areas
CAUTION: This heater creates warm air currents. These
currents move heat to wall surfaces next to heater. Installing
heater next to vinyl or cloth wall
coverings or operating heater
where impurities (such as tobacco smoke, aromatic candles,
cleaning fluids, oil or kerosene
lamps, etc.) in the air exist, may
discolor walls.
IMPORTANT:
Vent-free heaters add moisture to the air. Although this is beneficial,
installing heater in rooms without enough
ventilation air may cause mildew to form
from too much moisture. See Air for Com-
bustion and Ventilation, pages 4 through 6.
CHECK GAS TYPE
Use only propane/LP gas. If your gas supply is not propane/LP gas, do not install
heater. Call dealer where you bought heater
for proper type heater.
INSTALLATION AND
CLEARANCES
(Vent-Free Operation Only)
WARNING: Maintain the minimum clearances. If you can, provide greater clearances from
floor, ceiling, and adjoining wall.
MINIMUM FIREPLACE CLEARANCE
TO COMBUSTIBLE MATERIALS
Log Size Side Wall Ceiling Floor*
18", 24", 30” 16" 42" 5"
LOG SIZING REQUIREMENTS
Minimum Firebox Size
Log Front Rear*
Size Height Depth Width Width
18" 17" 14" 20" 14"
24" 17" 14" 26" 18"
30" 17" 14" 32" 22"
*Measured at 14” depth
Carefully follow the instructions below. This
will ensure safe installation into a masonry,
UL127-listed manufactured fireplace, or
listed vent-free firebox.
Minimum Clearances For Side
Combustible Material, Side Wall,
and Ceiling
A. Clearances from the side of the fire-
place cabinet to any combustible material and wall should follow the diagram in Figure 4.
Example:
shelf, etc. is made of combustible material and protrudes 3 1/2" from the wall.
This combustible material must be 4"
from the side of the fireplace opening
(see Figure 4).
Note:
into a manufactured firebox, follow
firebox manufacturer’ s instructions for
minimum clearances to combustible
materials.
B. Clearances from the top of the fireplace
opening to the ceiling should not be less
than 42 inches.
FIREBOX
*Minimum 16 inches from Side Wall
Figure 4 - Minimum Clearance for
Combustible to Wall
The face of a mantel, book-
When installing your gas logs
121/
Example
.5 2
1 4 6 8 10 12 14 16
INCHES
101/
8
7
51/
31/
1
7/8
7/16
*
4
2
3
/
4
4
2
3
/
4
INCHES
105073
*See
Floor Clearances,
page 9.
Continued
7
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
INSTALLATION
Continued
NOTICE: Manual control heaters
may be used as a vented product. If so, you must always run
heater with chimney flue damper
open. If running heater with
damper open, noncombustible
material above fireplace opening is not needed. Go to
ing Damper Clamp Accessory
for Vented Operation,
Minimum Noncombustible
Material Clearances
If Not Using Mantel
Note:
If using a mantel, see If Using Man-
tel. If not using a mantel, follow the infor-
mation below.
You must have noncombustible material(s)
above the fireplace opening. Noncombustible materials (such as slate, marble, tile,
etc.) must be at least 1/2 inch thick. With
sheet metal, you must have noncombustible
material behind it. Noncombustible material
must extend at least 8" up (for all models). If
noncombustible material is less than 12", you
must install the fireplace hood accessory. See
Figure 5 for minimum clearances.
IMPORTANT:
minimum clearances, you must operate heater
with chimney flue damper open. See Install-
ing Damper Clamp Accessory for Vented
Operation, page 10.
If you cannot meet these
Install-
page 10.
If Using Mantel
You must have noncombustible material(s)
above the fireplace opening. Noncombustible materials (such as slate, marble, tile,
etc.) must be at least 1/2 inch thick. With
sheet metal, you must have noncombustible
material behind it. Noncombustible material must extend at least 8 inches up. If
noncombustible material is less than 12",
you must install the fireplace hood accessory. Even if noncombustible material is
more than 12", you may need the hood
accessory to deflect heat away from your
mantel shelf. See Figure 5 and Figures 6 and
7, page 9 for minimum clearances.
Noncombustible Requirements for
Material Distance (A) Safe Installation
12" or more Noncombustible material OK.
Between 8" and 12" Install fireplace hood accessory (HDABK or
HDABR, see
18" model: Noncombustible material OK.
Less than 8" Noncombustible material must be extended to at
least 8". See
cannot extend material, you must operate heater
with flue damper open.
Heat Resistant
Material
(A)
IMPORTANT:
minimum clearances, you must operate heater
with chimney flue damper open. See Install-
ing Damper Clamp Accessory for Vented
Operation, page 10.
Accessories,
Between 8" and 12",
If you cannot meet these
page 24).
above. If you
Figure 5 - Heat Resistant Material (Slate, Marble, Tile, etc.) Above Fireplace
8
105073
OWNER’S MANUAL
INSTALLATION
Continued
MANTEL CLEARANCES
In addition to meeting noncombustible material clearances, you must also meet required
clearances between fireplace opening and
mantel shelf. If you do not meet clearances
listed in Figure 6 you will need a hood.
Determining Minimum Mantel
Clearance
If you meet minimum clearance between
mantel shelf and top of fireplace opening, a
hood is not required (see Figure 6).
Determining Minimum Mantel
Clearance When Using a Hood
If minimum clearances in Figure 6 are not met,
you must have a hood. When using a hood
there are still certain minimum mantel clearances required. Follow minimum clearances
shown in Figure 7, page 9 when using hood.
NOTICE: Surface temperatures of
adjacent walls and mantels become hot during operation. Walls
and mantels above the firebox
may become hot to the touch. If
installed properly, these temperatures meet the requirement of the
national product standard. Follow all minimum clearances
shown in this manual.
NOTICE: If your installation does
not meet the minimum clearances
shown, you must do one of the
following:
• operate the logs only with the
flue damper open
• raise the mantel to an acceptable height
• remove the mantel
Mantel Shelf
Minimum NonCombustible
Material
10"
8"
6"
1
/2
"
2
(A)
12"
8"
Minimum NonCombustible
Material Height
18"
14"
20"
22"
17"
19"
Distances to
Underside of
Mantel
Underside of
Mantel Shelf
24"
20"
Top of Fireplace
Opening
All minimum
distances are
in inches
Log Set
24" & 30" Models
24" Models
18" Model
Figure 6 - Minimum Mantel Clearances Without Using Hood
12"
10"
8"
6"
1
/2
"
2
Minimum NonCombustible
Material
8"
Min.
Hood
(HDABK,HDABR)
12" 15" 18"
Distances to
Underside of
Mantel
20"
Figure 7 - Minimum Mantel Clearances When Using Hood
Underside of
Mantel Shelf
All minimum
distances are
in inches
Log Sets
All Models
18" & 24" Models
Top of Fireplace
Opening
FLOOR CLEARANCES
A. If installing appliance on the floor level,
you must maintain the minimum distance of 14" to combustibles (see Figure 8).
B. If combustible materials are less than
14" to the fireplace, you must install
appliance at least 5" above the combustible flooring (see Figure 9).
105073
Combustible
Combustible
14"
14"
Min.
Min.
Noncombustible Material
Material
Material
Non-Combustible
Material
Figure 8 - Minimum Fireplace Clearances
If Installed at Floor Level
9
Hearth
Hearth
Combustible
Material
5"
5"
Min.
Min.
Combustible
Material
Figure 9 - Minimum Fireplace Clearances
Above Combustible Flooring
Continued
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
INSTALLATION
Continued
INSTALLING DAMPER
CLAMP ACCESSORY FOR
VENTED OPERATION
Note:
When used as a vented heater, appliance must be installed only in a solid-fuel
burning fireplace with a working flue and
constructed of noncombustible material.
If your heater is a manually-controlled
model, you may use this heater as a vented
product. There are three reasons for operating your heater in the vented mode.
1. The fireplace does not meet the clear-
ance to combustibles requirements for
vent-free operation.
2. State or local codes do not permit vent-
free operation.
3. You prefer vented operation.
If reasons number 1 or 2 above apply to you,
you must permanently open chimney flue
damper. You must install the damper clamp
accessory (to order, see Accessories, page
24). This will insure vented operation (see
Figure 10). The damper clamp will keep
damper open. Installation instructions are
included with clamp accessory.
See chart below for minimum permanent
flue opening you must provide. Attach
damper clamp so the minimum permanent
flue opening will be maintained at all times.
Area of Various Standard Round Flues
Diameter (ins.) Area (sq. ins.)
5" 20 sq. inches
6" 29 sq. inches
7" 39 sq. inches
8" 51 sq. inches
Chimney Minimum Permanent
Height (ft.) Flue Opening (sq. ins.)
6' to 15' 39 sq. inches
15' to 30' 29 sq. inches
Damper Clamp
Damper
Masonry Fireplace
Figure 10 - Attaching Damper Clamp
Manufactured Fireplace
INSTALLING HEATER BASE
ASSEMBLY
CAUTION: Do not remove the
metal data plates attached to the
heater base assembly. The data
plates contain important warranty
information.
WARNING: You must secure
this heater to fireplace floor. If
not, heater will move when you
adjust controls. Moving heater
may cause a gas leak.
WARNING: If installing in a
sunken fireplace, special care is
needed. You must raise the fireplace floor to allow access to
heater control panel. This will insure adequate air flow and guard
against sooting. Raise fireplace
floor with noncombustible material. Make sure material is secure.
CAUTION: Do not pick up heater
base assembly by burners. This
could damage heater. Only handle
base assembly by grates.
IMPORTANT:
ers are level. If heater is not level, heater will
not work properly.
Make sure the heater burn-
Damper
Damper
Clamp
Damper
Note:
Install optional FHRC or FHRCT
Receiver and Hand-Held Remote Control
Kit (see Accessories, page 24) before installing gas log heater. See installation instructions included with the kit.
1. Apply pipe joint sealant lightly to male
threads of gas fitting. Connect approved
flexible gas hose to inlet side of gas
control (see Figure 11).
2. Locate two masonry screws in the hardware package.
3. Position heater base assembly in fireplace.
4. Place logs in their proper position on
heater base.
5. Center heater base and logs, front-toback and side-to-side in fireplace.
6. Carefully remove logs without moving
heater base.
7. Mark screw locations through holes in
front panel of base (see Figure 12, page
11). If installing in a brick-bottom fireplace, mark screw locations in mortar
joint of bricks.
8. Remove heater base from fireplace.
9. Drill holes at marked locations using
3/16" masonary drill bit.
10. Attach base to fireplace floor using
masonry screws (in hardware package).
Gas Control
Installation Items Needed
• hardware package (provided with heater)
• approved flexible gas hose (not provided)
(if allowed by local codes)
• sealant (resistant to propane/LP gas,
not provided)
• electric drill with 3/16" drill bit
10
Flexible Gas Hose (if
allowed by local codes)
Figure 11 - Attaching Flexible Gas Hose
to Heater Gas Regulator
105073
OWNER’S MANUAL
INSTALLATION
Continued
Masonry Screw
Figure 12 - Attaching Base Assembly to
Fireplace Floor
CONNECTING TO GAS
SUPPLY
WARNING: This appliance requires a 1/2" NPT (National Pipe
Thread) inlet connection to the
pressure regulator.
WARNING: A qualified service
person must connect heater to gas
supply. Follow all local codes.
CAUTION: Never connect
heater directly to the propane/LP
supply. This heater requires an external regulator (not supplied). Install the external regulator between
the heater and propane/LP supply.
The installer must supply an external regulator. The external regulator will reduce
incoming gas pressure. You must reduce
incoming gas pressure to between 11 and 14
inches of water. If you do not reduce incoming gas pressure, heater regulator damage
could occur. Install external regulator with
the vent pointing down as shown in Figure
13. Pointing the vent down protects it from
freezing rain or sleet.
WARNING: Never connect
heater to private (non-utility) gas
wells. This gas is commonly
known as wellhead gas.
CAUTION: Use only new,
black iron or steel pipe. Internally-tinned copper tubing may
be used in certain areas. Check
your local codes. Use pipe of 1/2"
diameter or greater to allow
proper gas volume to heater. If
pipe is too small, undue loss of
pressure will occur.
Propane/
LP Supply
Tank
Figure 13 - External Regulator With Vent
Pointing Down
External
Regulator
Vent
Pointing
Down
Installation must include an equipment
shutoff valve, union, and plugged 1/8" NPT
tap. Locate NPT tap within reach for test
gauge hook up. NPT tap must be upstream
from heater (see Figure 14).
IMPORTANT:
Install an equipment shutoff
valve in an accessible location. The equipment shutoff valve is for turning on or
shutting off the gas to the appliance.
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
from going into pipe. Excess sealant in pipe
could result in clogged heater valves.
CAUTION: Use pipe joint sealant that is resistant to liquid petroleum (LP) gas.
We recommend that you install a sediment
trap in supply line as shown in Figure 14.
Locate sediment trap where it is within
reach for cleaning. Install in piping system
between fuel supply and heater. Locate sediment trap where trapped matter is not likely
to freeze. A sediment trap traps moisture
and contaminants. This keeps them from
going into heater controls. If sediment trap
is not installed or is installed wrong, heater
may not run properly.
CAUTION: Avoid damage to
gas control. Hold gas control with
wrench when connecting it to gas
piping and/or fittings.
Installation Items Needed
Before installing heater, make sure you have
the items listed below.
• external regulator (supplied by installer,
see Figure 13)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
* An CSA design-certified equipment shutoff
valve with 1/8" NPT tap is an acceptable
alternative to test gauge connection.
105073
CSA Design-Certified Equipment
Shutoff Valve With 1/8" NPT Tap
Approved Flexible
Gas Hose (if allowed
by local codes)
Gas
Control
3" Minimum
Figure 14 - Gas Connection
* Minimum inlet pressure for purpose of input adjustment.
11
From External
Regulator
(11" W.C.* to
14" W.C. Pressure)
Tee
Joint
Pipe
Nipple
Cap
Sediment
Trap
Continued
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
INSTALLATION
Continued
CHECKING GAS
CONNECTIONS
WARNING: Test all gas piping and connections for leaks
after installing or servicing. Correct all leaks at once.
WARNING: Never use an open
flame to check for a leak. Apply a
mixture of liquid soap and water
to all joints. Bubbles forming
show a leak. Correct all leaks at
once.
CAUTION: Make sure external regulator has been installed
between propane/LP supply and
heater. See guidelines under
necting to Gas Supply
Pressure Testing gas Supply
Piping system
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
main gas valve (control valve) and equipment shutoff valve from g as supply piping system. Pressures in excess of 1/2
psig will damage heater regulator .
2. Cap off open end of gas pipe where
equipment shutoff valve was connected.
3. Pressurize supply piping system by either using compressed air or opening
propane/LP supply tank valve.
4. Check all joints of gas supply piping
system. Apply mixture of liquid soap
and water to gas joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect heater and equipment
shutoff valve to gas supply. Check reconnected fittings for leaks.
Con-
, page 11.
Test Pressures Equ al To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Figure 15).
2. Pressurize supply piping system by either using compressed air or opening
propane/LP supply tank valve.
3. Check all joints from propane/LP supply tank to equipment shutoff valve (see
Figure 16). Apply mixture of liquid
soap and water to gas joints. Bubbles
forming show a leak.
4. Correct all leaks at once.
ON
Open
POSITI
Equipment
Shutoff
Valve
O
POS
Closed
Figure 15 - Equipment Shutoff Valve
Equipment
Shutoff Valve
Propane/LP
Supply
Tank
Figure 16 - Checking Gas Joints
Pressure Testing Heater Gas
Connections
1. Open equipment shutoff valve (see Figure 15).
2. Open propane/LP supply tank valve.
3. Make sure control knob of heater is in
the OFF position.
4. Check all joints from equipment shutoff
valve to gas control (see Figure 15).
Apply mixture of liquid soap and water to gas joints. Bubbles forming show
a leak.
5. Correct all leaks at once.
6. Light heater (see Operating Heater,
pages 14 through 16). Check all other
internal joints for leaks.
7. Turn of f heater (see To Turn Off Gas to
Appliance, page 15).
Control Valve
Location
12
105073
INSTALLATION
Continued
INSTALLING LOGS
WARNING: Failure to position
the parts in accordance with these
diagrams or failure to use only
parts specifically approved with
this heater may result in property
damage or personal injury.
Notch
OWNER’S MANUAL
Peg
Front Log (#1)
Groove in
Back of Log
Grate Prong
Rear Log (#3)
Groove
in Back
of Log
Each log is marked with a number. These
numbers will help you identify the log when
installing. It is very important to install
these logs exactly as instructed. Do not
modify logs. Only use logs supplied with
heater.
1. Place front logs (#1L and #1R) on top
of the grate. Make sure the notches in
the bottom of the logs fit over the grate
prongs (see Figure 17). Push back of
logs flush with metal grate bar.
Note:
18" model has only one front log.
2. Rest bottom middle log (#2) behind
metal posts on front burner . Make sure
the grooves in the bottom of the log fit
over the grate. Bring the log forward
next to the metal posts. The pegs on
the log must be on top (see Figure 18).
3. Slide the grooves in the back of the rear
log (#3) against the rear grate prongs.
Make sure the peg on the log is on top
(see Figure 19).
4. Place the top middle log (#4) on the
bottom middle log (#2). Make sure the
pegs of the bottom middle log fit securely in the holes of the top middle
log (see Figure 20).
5. Place the crossover log (#5) on the back
log and the top middle log. Make sure
the peg on the rear log is in the hole in
the bottom of the crossover log. The
crossover log should fit in the cutout
of the top middle log (see Figure 21).
Grate
Prongs
Metal Grate Bar
Figure 17 - Installing Front Log (#1)
Bottom Middle
Log (#2)
Groove
Groove
Metal
Post
Metal Post
Grate
Figure 18 - Installing Bottom Middle
Log (#2)
Grate
Prong
Figure 19 - Installing Rear Log (#3)
Hole
Peg
Figure 20 - Installing Crossover Log (#4)
Cutout
Top Middle
Log (#4)
Crossover
Log (#5)
Hole
Peg
105073
Figure 21 - Installing Crossover Log (#5)
13
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
OPERATING
HEATER
FOR YOUR SAFETY
READ BEFORE
LIGHTING
WARNING: If you do not follow these instructions exactly, a
fire or explosion may result causing property damage, personal
injury or loss of life.
A. This appliance has a pilot which must
be lighted by hand. When lighting the
pilot, follow these instructions exactly .
B. BEFORE LIGHTING smell all
around the appliance area for gas. Be
sure to smell next to the floor because
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL
GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
C. Use only your hand to push in or turn
the gas control knob. Ne ver use tools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been under water.
LIGHTING
INSTRUCTIONS
WARNING
• If fireplace has glass doors,
never operate this heater with
glass doors closed. If you operate heater with doors closed,
heat buildup inside fireplace
will cause glass to burst. Also
if fireplace opening has vents
at the bottom, you must open
the vents before operating
heater.
• You must operate this heater
with a fireplace screen in place.
Make sure fireplace screen is
closed before running heater.
NOTICE: During initial operation
of new heater, burning logs will
give off a paper-burning smell.
Orange flame will also be present.
Open damper or window to vent
smell. This will only last a few
hours.
Note:
Home owners generally prefer to
operate their heater with the chimney
damper closed. This will put all the heat
into the room. However, there may be
times you will desire the full flames of the
Hi heat setting but will find the heat
output excessive. You can open the chimney damper (if you have one) fully or
partially to release some of the heat.
WARNING: Damper handle
will be hot if heater has been
running.
Control Knob
T
O
L
I
P
F
F
O
1. STOP! Read the safety information,
column 1.
2. Make sure equipment shutoff valve
is fully open.
3. Set selector switch in the OFF position.
WARNING: Burners will come
on automatically within one
minute when the selector switch
is in the ON position after the
pilot is lit.
4. Press in and turn control knob clockwise to the OFF position (see
Figure 22).
5. Wait f ive (5) minutes to clear out any
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety information above. If you don’t smell
gas, go to the next step.
6. Press in and turn control knob counterclockwise to the PILOT
position. Press in control knob for
five (5) seconds (see Figure 22).
Note: You may be running this
heater for the first time after hooking up to gas supply. If so, the control knob may need to be pressed in
for 30 seconds or less. This will allo w
air to bleed from the gas system.
7. With control knob pressed in, press
and release ignitor button. This will
light pilot. The pilot is attached to the
front burner. If needed, keep pressing ignitor button until pilot lights.
Note:
If pilot does not stay lit, contact a qualified service person or gas
supplier for repairs. Until repair s are
made, light pilot with match. T o light
pilot with match, see Manual Light-
ing Procedure, page 15.
O
O
N
L
H
I
AUTO
OFF
ON
Ignitor Button
Figure 22 - Control Knob and Ignitor Button Location
14
Flame Adjustment Knob
Selector Switch
in OFF Position
105073
OWNER’S MANUAL
OPERATING
HEATER
Continued
8. Keep control knob pressed in for 30
seconds after lighting pilot. After 30
seconds, release control knob.
• If control knob does not pop out
when released, contact a qualified
service person or gas supplier for
repairs.
Note:
If pilot goes out, repeat steps
4 through 8.
9. Slightly push in and turn control
knob counterclockwise to the
ON position.
10. Wait one minute and switch selector
switch to the ON position to light
burner.
tional when using GWMT1 or
GWMS2 optional accessories.
11. Set flame adjustment knob to any
level between HI and LO.
just heating levels by using the
equipment shutoff valve.
selector switch is in the OFF position when you are away from
home for long periods of time.
Heater will come on automatically with selector switch in the
ON position.
Pilot Burner
Figure 23 - Pilot
Note:
AUTO is only func-
CAUTION: Do not try to ad-
WARNING: Make sure the
Ignitor
Electrode
TO TURN OFF GAS TO
APPLIANCE
Shutting Off Heater
1. T urn control knob clockwise
to the OFF position.
2a. Set selector switch in the OFF position.
2b. If Using Optional Hand-Held Re-
mote: Set selector switch in the OFF
position to prevent draining battery.
Shutting Off Burners Only (pilot
stays lit)
You may shut off the burners and keep
the pilot lit by doing one of the following:
1. T urn control knob clockwise
to the PILOT position.
2. Use remote control manual OFF
button.
3. Set selector switch in the OFF position.
MANUAL LIGHTING
PROCEDURE
1. Follow steps 1 through 6 under Lighting Instructions, page 14.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot. After 30
seconds, release control knob. Now
follow steps 9 through 11, Lighting
Instructions, column 1.
OPTIONAL REMOTE
OPERATION
Note:
All remote control accessories must
be purchased separately (see Accessories,
page 24). Follow instructions included
with the remote control.
Thermostat Control Operation
(Optional GHRCTA Series Only) The
thermostat control setting on the remote
control unit can be set to any comfort
level between WARMER and COOLER.
The burners will turn on and off automatically to maintain the comfort level
you select. The ideal comfort setting will
vary by household depending upon the
amount of space to be heated, the output
of the central heating system, etc.
For wall thermostat operation, follow instruction supplied with thermostat accessory GWMT1. For wall switch operation follow instructions supplied with
GWMS2.
NOTICE: You must light the pilot
before using the remote control
unit. See
page 14.
1. After lighting, let pilot flame burn for
about one minute. Turn control knob
to ON position. Adjust flame adjustment knob anywhere between HI and
LO. Slide the selector switch to the
REMOTE position.
ers may light if hand-held remote ON
button was on when selector switch
was last turned off. You can now turn
the burners on and off with the handheld remote control unit.
IMPORTANT:
lector switch in the REMOTE or ON
position when the pilot is not lit. This
will drain the battery.
IMPORTANT:
OFF buttons on the hand-held remote
control unit for up to 3 seconds to assure proper operation
Lighting Instructions
Note:
Do not leave the se-
Be sure to press the ON/
on
The burn-
GHRC Series Operation:
2a. Press ON/OFF button to turn the
burner on and off. When turning
burner off, the pilot will remain lit.
GHRCTA Series Operation:
2b. Press the AUTO/ON/OFF button on
the hand-held remote control (see
Figure 25, page 16). The lights to the
left of the button will show AUTO,
ON, or OFF.
• In the ON mode, the burners will
ignite. The heater is in manual
mode when ON is lit.
• In the AUTO mode, the thermostat
in the hand-held remote unit controls the room temperature. T o i ncrease the room temperature, pr ess
the top arrow of the TEMP b utton.
To lower the room temperature,
press the bottom arrow of the
TEMP button. At higher settings
the heater will run longer.
105073
Continued
15
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
OPERATING
HEATER
Continued
IMPORTANT:
has been specially engineered to take
an air temperature sample every 5.5
minutes in the auto mode. It will not
respond immediately to the temperature setting being turned up or down.
IMPORTANT:
control unit must be near the heater.
Do not keep the hand-held remote
control unit too close to the heater.
The thermostat on the hand-held remote control unit will heat up too
quickly and turn the heater off.
3. To turn the burner off, press the
AUTO/ON/OFF button until OFF
lights. The pilot will remain lit.
IMPORTANT:
manually turn the control knob on
the heater to the OFF position.
This remote control
The hand-held remote
To turn the pilot off,
INSPECTING
BURNERS
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 26 shows a correct pilot flame pattern. Figure 27 shows an incorrect pilot
flame pattern. The incorrect pilot flame is
not touching the thermocouple. This will
cause the thermocouple to cool. When the
thermocouple cools, the heater will shut
down.
If pilot flame pattern is incorrect, as shown
in Figure 27
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• see Tr oubleshooting, pages 18 through 20
Pilot Burner
Figure 26 - Correct Pilot Flame Pattern
Pilot Burner
Thermocouple
Figure 27 - Incorrect Pilot Flame Pattern
Thermocouple
FRONT BURNER FLAME
PATTERN
Figure 28, page 17, shows correct front
burner flame pattern. Figure 29, page 17,
shows incorrect front burner flame pattern.
The incorrect burner flame pattern shows
yellow tipping at top of blue flame.
Control Knob in
On Position
Figure 24 - Setting the Remote Selector Switch, Control Knob, and Flame Adjustment
Knob for Remote Operation
Shows
Temperature
Setting
The Log Heater
will Automatically
Cycle between
Pilot and the Heat
Setting that has
been Selected
Flame
Adjustment
Knob
O
L
N
O
O
F
F
T
O
P
I
L
Selector Switch in Remote Position
H
I
ON
OFF
REMOTE
Increases Room
Temperature in
AUTO Mode
Decreases Room
Temperature in
AUTO Mode
Turns Burners
On or Off and
Allows You to
Choose the Auto
Setting
WARNING: If yellow tipping
occurs, your heater could produce increased levels of carbon
monoxide. If front burner flame
pattern shows yellow tipping,
follow instructions at bottom of
this page. Yellow flame on rear
burner is normal.
NOTICE: Do not mistake orange
flames with yellow tipping. Dirt
or other fine particles are burned
by heater, causing brief patches
of orange flame.
If front burner flame pattern is incorrect, as
shown in Figure 29, page 17.
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• see Troubleshooting , pages 18 through 20
Figure 24 - Thermostat Hand-Held Remote Control Unit Selections
(GHRCTA Series Only)
16
105073
OWNER’S MANUAL
INSPECTING
BURNERS
Continued
Figure 28 - Correct Front Burner Flame
Pattern
Yellow Tipping At
Top of Blue Flame
Figure 29 - Incorrect Front Burner Flame
Pattern
CLEANING AND
MAINTENANCE
WARNING: Turn off heater
and let cool before cleaning.
CAUTION: You must keep
control areas, burners, and circulating air passageways of
heater clean. Inspect these areas
of heater before each use. Have
heater inspected yearly by a qualified service person. Heater may
need more frequent cleaning due
to excessive lint from carpeting,
bedding material, pet hair, etc.
We also recommend that you keep the burner
tube and pilot assembly clean and free of
dust and dirt. To clean these parts we recommend using compressed air no greater than
30 PSI. Your local computer store, hardware store, or home center may carry compressed air in a can. You can use a vacuum
cleaner in the blow position. If using compressed air in a can, please follow the directions on the can. If you don't follow directions on the can, you could damage the pilot
assembly.
1. Shut off the unit, including the pilot.
Allow the unit to cool for at least thirty
minutes.
2. Inspect burners, pilot, and primary air
inlet holes on injector holder for dust
and dirt (see Figure 30).
3. Blow air through the ports/slots and
holes in the burners.
4. Check the injector holder located at the
end of the burner tube again. Remove
any large particles of dust, dirt, lint, or
pet hair with a soft cloth or vacuum
cleaner nozzle.
5. Blow air into the primary air holes on
the injector holder.
6. In case any large clumps of dust have
now been pushed into the burner repeat
steps 3 and 4.
Clean the pilot assembly also. A yellow tip
on the pilot flame indicates dust and dirt in
the pilot assembly. There is a small pilot air
inlet hole about two inches from where the
pilot flame comes out of the pilot assembly
(see Figure 31). With the unit off, lightly
blow air through the air inlet hole. You may
blow through a drinking straw if compressed
air is not available.
Ports/Slots
Burner
Tube
Pilot
Assembly
Pilot Air
Inlet Hole
Figure 31 - Pilot Inlet Air Hole
LOGS
• If you remove logs for cleaning, refer to
Installing Logs, page 13, to properly replace logs.
• Replace log(s) if broken or chipped
(dime-sized or larger).
CLEANING BURNERS
INJECTOR HOLDER AND
PILOT AIR INLET HOLE
The primary air inlet holes allow the proper
amount of air to mix with the gas. This provides a clean burning flame. Keep these holes
clear of dust, dirt, lint, and pet hair. Clean
these air inlet holes prior to each heating
season. Blocked air holes will create soot. We
recommend that you clean the unit every three
months during operation and have heater inspected yearly by a qualified service person.
105073
Injector Holder
Ports/Slots
Burner
Tube
Primary Air Inlet
Holes
Figure 30 - Injector Holder On Outlet
Burner Tube
17
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
TROUBLESHOOTING
Note:
For additional help, visit DESA
International’s technical service web site
at www.desatech.com.
Note:
All troubleshooting items are listed in
order of operation.
OBSERVED PROBLEM
When ignitor button is pressed, there is no
spark at ODS/pilot
When ignitor button is pressed, there is
spark at ODS/pilot but no ignition
WARNING: Turn off and unplug heater and let cool before
servicing. Only a qualified service person should service and
repair heater.
POSSIBLE CAUSE
1. Ignitor electrode not connected to ignitor cable
2. Ignitor cable pinched or wet
3. Piezo ignitor nut is loose
4. Broken ignitor cable
5. Bad piezo ignitor
6. Ignitor electrode positioned wrong
7. Ignitor electrode broken
1. Gas supply turned off or equipment
shutoff valve closed
2. Control knob not in PILOT position
3. Control knob not pressed in while in
PILOT position
4. Air in gas lines when installed
5. Depleted gas supply
6. ODS/pilot is clogged
7. Gas control setting is not correct
CAUTION: Never use a wire,
needle, or similar object to clean
ODS/pilot. This can damage ODS/
pilot unit.
REMEDY
1. Reconnect ignitor cable
2. Free ignitor cable if pinched by any
metal or tubing. Keep ignitor cable dry
3. Tighten nut holding piezo ignitor to base
panel of log set. Nut is located behind
base panel
4. Replace ignitor cable
5. Replace piezo ignitor
6. Replace ignitor
7. Replace ignitor
1. Turn on gas supply or open equipment
shutoff valve
2. Turn control knob to PILOT position
3. Press in control knob while in PILOT
position
4. Continue holding down control knob.
Repeat igniting operation until air is removed
5. Contact local propane/LP gas company
6. Clean ODS/pilot (see Cleaning and
Maintenance, page 17) or replace ODS/
pilot assembly
7. Replace gas control
ODS/pilot lights but flame goes out when
control knob is released
1. Control knob not fully pressed in
2. Control knob not pressed in long enough
3. Equipment shutoff valve not fully open
4. Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This problem could be caused by one or both of
the following:
A) Low gas pressure
B) Dirty or partially clogged ODS/pilot
5. Thermocouple connection loose at control valve
6. Thermocouple damaged
7. Gas control damaged
www.desatech.com
18
1. Press in control knob fully
2. After ODS/pilot lights, keep control
knob pressed in 30 seconds
3. Fully open equipment shutoff valve
4. A) Contact local propane/LP gas
company
B) Clean ODS/pilot (see Cleaning and
Maintenance, page 17) or replace ODS/
pilot assembly
5. Hand tighten until snug, then tighten 1/4
turn more
6. Replace thermocouple
7. Replace gas control
105073
TROUBLESHOOTING
Continued
OWNER’S MANUAL
OBSERVED PROBLEM
One or both burners do not light after ODS/
pilot is lit
Delayed ignition of one or both burners
Burner backfiring during combustion
Yellow flame in front burner during burner
combustion
POSSIBLE CAUSE
1. Inlet gas pressure is too low
2. Burner orifice(s) clogged
3. Mislocated crossover tube
4. Burner orifice(s) diameter is too small
5. Selector switch in OFF position
6. Wire disconnected from gas control
1. Manifold pressure is too low
2. Burner orifice(s) clogged
3. Mislocated crossover tube
1. Burner orifice is clogged or damaged
2. Damaged burner
3. Gas control defective
1. Not enough air
2. Gas control defective
REMEDY
1. Contact local propane/LP gas company
2. Clean burner(s) (see Cleaning and Main-
tenance, page 17) or replace burner
orifice(s)
3. Contact qualified service person
4. Replace burner orifice(s)
5. Put selector switch in ON position
6. See Wiring Diagram, page 21
1. Contact local propane/LP gas company
2. Clean burner(s) (see Cleaning and Main-
tenance, page 17) or replace burner
orifice(s)
3. Contact qualified service person
1. Clean burner (see Cleaning and Mainte-
nance, page 17) or replace burner orifice
2. Replace damaged burner
3. Replace gas control
1. Check burner(s) for dirt and debris. If
found, clean burner(s) (see Cleaning and
Maintenance, page 17)
2. Replace gas control
Slight smoke or odor during initial operation
Moisture/condensation noticed on windows
Heater produces a whistling noise when
burners are lit
White powder residue forming within burner
box or on adjacent walls or furniture
Remote does not function (GHRC Series
and GHRCT Series only)
1. Residues from manufacturing processes
and logs curing
1. Not enough combustion/ventilation air
1. Turning control knob to HI position
when burners are cold
2. Air in gas line
3. Air passageways on heater blocked
4. Dirty or partially clogged burner
orifice(s)
1. When heated, vapors from furniture polish, wax, carpet cleaners, etc. turn into
white powder residue
1. Battery is not installed. Battery power
is low
www.desatech.com
1. Problem will stop after a few hours of
operation
1. Refer to Air for Combustion and Venti-
lation requirements (page 4)
1. Turn control knob to LO position and
let warm up for a minute
2. Operate burners until air is removed
from line. Have gas line checked by local Propane/LP gas company
3. Observe minimum installation clearances (see pages 7 through 9)
4. Clean burners (see Cleaning and Main-
tenance, page 17) or replace burner
orifice(s)
1. Turn heater off when using furniture
polish, wax, carpet cleaners, or similar
products
1. Replace 9-volt batteries in receiver and
remote control
Continued
105073
19
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
TROUBLESHOOTING
Continued
WARNING: If you smell gas
• Shut off gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor ’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
IMPORTANT:
supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles,
etc., create fumes. These fumes may mix with combustion air and create odors. These odors
will disappear over time.
Operating heater where impurities in air exist may create odors. Cleaning
OBSERVED PROBLEM
Heater produces a clicking/ticking noise
just after burners are lit or shut off
Heater produces unwanted odors
Heater shuts off in use (ODS operates)
Gas odor even when control knob is in OFF
position
POSSIBLE CAUSE
1. Metal expanding while heating or contracting while cooling
1. Heater burning vapors from paint, hair
spray, glues, cleaners, chemicals, new
carpet, etc. (See
ment above)
2. Low fuel supply
3. Gas leak. See Warning statement
above
1. Not enough fresh air is available
2. Low line pressure
3. ODS/pilot is partially clogged
1. Gas leak. See Warning statement
above
2. Gas control defective
IMPORTANT
state-
REMEDY
1. This is common with most heaters. If
noise is excessive, contact qualif ied service person
1. Open window to ventilate room. Stop using odor causing products while heater
is running
2. Refill supply tank
3. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
1. Open window and/or door for ventilation
2. Contact local propane/LP gas company
3. Clean ODS/pilot (see Cleaning and
Maintenance, page 17)
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
2. Replace gas control
Gas odor during combustion
Log set cycles to pilot, but room temperature drops to a lower than ideal level before
log set comes back on (GHRCT Series only)
1. Foreign matter between control valve
and burner
2. Gas leak. See Warning statement
above
1. Hand-held remote control unit needs to
be moved away from heater
www.desatech.com
20
1. Take apart gas tubing and remove foreign matter
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 12)
1. Move hand-held remote control unit farther away from the heater
105073
OWNER’S MANUAL
SPECIFICATIONS
18" Variable 24" Variable 30" Variable
Btu (Variable) 16,000/26,000 20,000/33,000 21,5000/36,000
Type Gas Propane/LP Only Propane/LP Only Propane/LP Only
Ignition Piezo Piezo Piezo
Manifold Pressure 7.9" W.C. 7.9" W.C. 7.9" W.C.
Inlet Gas Pressure
(in. of water)
Maximum 14" 14" 14"
Minimum* 11" 11" 11"
Shipping Weight 32 lbs. 34 lbs. 36 lbs.
* For purpose of input adjustment
WIRING DIAGRAM
AUTO
OFF
O
N
Thermopile
SERVICE HINTS
When Gas Pressure Is Too Low
• pilot will not stay lit
• burners will have delayed ignition
• heater will not produce specified heat
• propane/LP gas supply may be low
When Gas Quality Is Bad
• pilot will not stay lit
• burners will produce flames and soot
• heater will backfire when lit
You may feel your gas pressure is too low or
gas quality is bad. If so, contact your local
propane/LP gas supplier.
TECHNICAL
SERVICE
You may have further questions about installation, operation, or troubleshooting.
If so, contact DESA International’s Technical Service Department at 1-800-DESA LOG
(1-800-337-2564).
You can also visit DESA International’s
technical services web site at
www.desatech.com.
REPLACEMENT
PARTS
Note:
Use only original replacement parts.
This will protect your warranty coverage for
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call Fireplace Manufacturers
Incorporated’s Technical Service Department at 1-888-427-8322.
When calling Fireplace Manufacturers Incorporated, have ready
• your name and address
• model and serial numbers of your heater
• how heater was malfunctioning
• type of gas used (propane/LP or natural gas)
• purchase date
Usually, we will ask you to return the defec-
tive part to the factory.
PARTS NOT UNDER
WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call Fireplace Manufacturers
Incorporated’s Parts Department at 1-800888-2050 for referral information.
When calling Fireplace Manufacturers Incorporated, have ready
• model and serial numbers of your heater
• the replacement part number
105073
21
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
ILLUSTRATED
PARTS
BREAKDOWN
VFP18R
VFP24R
VFP30R
1L
1R
4
7
9
9-2
5
3
2
6
29
24
12
8
11
13
12
14
20
19
9-1
7
28
21
17
29
26
23
27
15
16
18
22
10
7
25
29
22
105073
OWNER’S MANUAL
PARTS LIST
VFP18R
VFP24R
VFP30R
KEY PART NUMBERS
NO.
1L 105241-01 105241-02 105998-01 Left Front Log (#1L) 1
1R
2 105243-01 105243-02 106000-01 Bottom Middle Log (#2) 1
3 105245-01 105245-02 106001-01 Rear Log (#3) 1
4 105249-01 105249-02 106002-01 Top Middle Log (#4) 1
5 105247-01 105247-02 106003-01 Crossover Log (#5) 1
6 103778-01 103778-01 103778-01 O.D.S. Pilot 1
7 098249-01 098249-01 098249-01 Nut 6
8 103780-01 103780-01 103780-01 Pilot Bracket 1
9 101330-01 101330-05 101330-06 Front Burner Assembly 1
9-1 101008-01 101008-01 101008-01 Crossover Burner Gasket 1
9-2 101007-01 101007-01 101007-01 Crossover Burner 1
10 100999-02 100999-02 100999-03 Rear Burner Assembly 1
11 103984-01 103984-02 103984-03 Base Assembly and Decal 1
12 098271-06 098271-06 098271-06 Ignitor Cable 1
13 102445-01 102445-01 102445-01 Piezo Ignitor 1
14 103588-01 103588-01 103588-01 Heat Shield 1
15 103782-01 103782-01 103782-01 Valve Bracket 1
16 M12461-26 M12461-26 M12461-26 Screw 5
17 103781-02 103781-02 103781-02 Gas Control 1
18 098264-02 098264-02 098264-02 Male Fitting 1
19 103784-02 103784-02 103784-02 Flame Adjustment Knob 1
20 103784-01 103784-01 103784-01 Control Knob 1
21 103587-01CK 103587-01CK 103587-01CK Switch Plate 1
22 M11084-26 M11084-26 M11084-26 Screw 2
23 103284-02 103284-02 103284-02 Wiring Harness 1
24 099387-09 099387-09 099387-09 Pilot Tube 1
25 101004-10 101004-01 101004-02 Rear Burner Injector 1
26 101004-10 101004-02 101004-06 Front Burner injector 1
27 103783-01 103783-01 103783-01 Remote Burner Tube 1
28 099998-01 099998-01 099998-01 Switch 1
29 M11084-26 M11084-26 M11084-26 Screw 6
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 21 of this manual.
VFP18R
_____
100563-01 100563-01 100563-01 Warning Plate 1
103877-01 103877-01 103877-01 Lighting Instructions Plate 1
100565-01 100565-01 100565-01 Warning Plate Fastener 1
100639-01 100639-01 100639-01 Caution Decal 1
101137-02 101137-02 101137-02 Hardware Kit 1
GA6060 GA6060 GA6060 Lava Rock 1
VFP24R VFP30R DESCRIPTION QTY.
105241-03 105999-01 Right Front Log (#1R) 1
PARTS AVAILABLE — NOT SHOWN
105073
23
FIREPLACE MANUFACTURERS INC.
UNVENTED PROPANE/LP GAS LOG HEATER
ACCESSORIES
Purchase these heater accessories from your
local dealer. If they can not supply these
accessories, call Fireplace Manufacturers
Incorporated’s Parts Department at 1-800888-2050 for referral information. You can
also write to the address listed on the back
page of this manual.
FIREPLACE HOOD
Black - HDABK
Brass - HDABR
For all models. Helps deflect heat away
from mantel or wall above fireplace. Fits
openings 28” and 49” wide.
W
A
R
M
E
R
C
O
T
O
E
L
M
E
P
R
A
U
T
O
O
N
O
F
F
RECEIVER AND HAND-HELD
THERMOSTAT REMOTE
CONTROL KIT - GHRCT
SERIES
For all models. Allows the gas log heater to
be operated in a manually or thermostatically-controlled mode. You can turn the gas
log heater on and off without ever leaving
the comfort of your easy chair.
WALL-MOUNT THERMOSTAT
SWITCH - GWMT1
(Not Shown)
For all models. The desired comfort setting
can be selected on the wall thermostat and
the log heater will automatically cycle from
pilot to the heat setting selected.
WALL-MOUNT ON/OFF
SWITCH - GWMS2
(Not Shown)
For all models. Allows the gas log heater to
be turned on and off with a wall switch.
DAMPER CLAMP - 02017
(Not Shown)
Permanently opens chimney flue damper
for vented operation. Can be used only with
non-thermostat accessories.
LAVA ROCK - GA6060
(Not Shown)
For all models. Order when additional rock
is desired. (31/2 lb. bag)
RECEIVER AND HANDHELD REMOTE CONTROL
KIT - GHRC SERIES
For all models. Allows the gas log heater to
be turned on and off by using a hand-held
remote control.
24
105073
OWNER’S MANUAL
NOTES
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
_______________________________________________________________________________________________
105073
25
WARRANTY INFORMATION
KEEP THIS WARRANTY
Model
Serial No.
Date Purchased
Always specify model and serial numbers when communicating with the factory.
We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty.
We make no other warranty, expressed or implied.
LIMITED WARRANTY
VENT-FREE PROPANE/LP GAS LOG HEATERS
DESA International warrants this product to be free from defects in materials and components for one (1) year from the date of first
purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions.
To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to
proper operating condition and an allowance for labor when provided by a DESA International Authorized Service Center. Warranty
part(s) MUST be obtained through authorized dealers of this product and/or DESA International who will provide original factory
replacement parts. Failure to use original factory replacement parts voids this warranty. The heater MUST be installed by a qualified
installer in accordance with all local codes and instructions furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become
damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost,
labor, transportation and any and all such other costs related to repairing a defective heater will be the responsibility of the owner.
TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT;
THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE TO ONE (1) YEAR ON ALL COMPONENTS AND FROM THE DATE OF FIRST PURCHASE;
AND DESA INTERNATIONAL’S LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND
DESA INTERNATIONAL SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential
damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
For information about this warranty write:
INTERNATIONAL
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
www.desatech.com
105073 01
NOT A UPC
105073-01
Rev. D
11/01
Loading...
