NATURAL PROPANE/LP
(V)V36N (V)V36P (V)V42N (V)V42P CHDV47NR CHDV47PR
DIRECT-VENT FIREPLACE
OWNER’S OPERATION AND
TM
INSTALLATION MANUAL
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result caus­ing property damage, personal injury, or loss of life.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
FOR YOUR SAFETY WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s instructions.
department.
This appliance may be installed in an aftermarket* manufactured (mobile) home, where not prohibited by state or local codes.
WARNING: Improper installation, ad­justment, alteration, service, or mainte­nance can cause injury or property damage. Refer to this manual for cor­rect installation and operational proce­dures. For assistance or additional in­formation consult a qualified installer, service agency, or the gas supplier.
— Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
— This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer.
Save this manual for future reference.
Save this manual for future reference.
TABLE OF CONTENTS SAFETY INFORMATION
2
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
LOCAL CODES........................................................................... 3
PRODUCT IDENTIFICATION ..................................................... 3
PRODUCT FEATURES .............................................................. 4
PRE-INSTALLATION PREPARATION ........................................ 4
LOCATION OF TERMINATION CAP .......................................... 6
VENTING INSTALLATION INSTRUCTIONS.............................. 7
FIREPLACE INSTALLATION.................................................... 17
OPERA TING FIREPLACE ........................................................ 26
INSPECTING BURNERS.......................................................... 28

SAFETY INFORMATION

WARNINGS
IMPORTANT: Read this owners manual carefully and completely before trying to assemble, operate, or service this fireplace. Improper use of this fireplace can cause serious injury or death from burns, fire, explosions, electrical shock, and carbon monoxide poisoning.
DANGER: Carbon monoxide poisoning may lead
to death!
This fireplace must be installed by a qualified (certified or licensed) service person. It has a sealed gas combustion chamber that uses a coaxial pipe (pipe within a pipe and having the same center) venting system. It brings in fresh air for combustion through the outer pipe and combustion gases are exhausted through the inner pipe. If the glass door assembly and venting pipe are not properly seated, connected, and sealed, carbon monoxide leakage (spillage) can occur.
Carbon Monoxide Poisoning: Early signs of carbon monoxide
poisoning resemble the flu, with headaches, dizziness, or nausea. If you have these signs, the fireplace may not have been installed properly. Get fresh air at once! Have fireplace inspected and serviced by a qualified service person. Some people are more affected by carbon monoxide than others. These include pregnant women, people with heart or lung disease or anemia, those under the influence of alcohol, and those at high altitudes.
Propane/LP gas and natural gas are both odorless. An odor-making agent is added to each of these gases. The odor helps you detect a gas leak. However, the odor added to these gases can fade. Gas may be present even though no odor exists.
CLEANING AND MAINTENANCE ............................................ 29
TROUBLESHOOTING .............................................................. 30
REPLACEMENT PARTS .......................................................... 33
SPECIFICATIONS .................................................................... 33
SERVICE HINTS....................................................................... 33
TECHNICAL SERVICE ............................................................. 33
ILLUSTRATED PARTS BREAKDOWNAND PARTS LIST........ 34
ACCESSORIES ........................................................................ 42
WARRANTY INFORMATION...................................... Back Cover
Make certain you read and understand all warnings. Keep this manual for reference. It is your guide to safe and proper operation of this fireplace.
WARNING: Any change to this fireplace or its
controls can be dangerous.
1. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases unless a certified kit is used.
2. For propane/LP fireplace, do not place propane/LP supply tank(s) inside any structure. Locate propane/LP supply tank(s) outdoors. To prevent performance problems, do not use pro­pane/LP fuel tank of less than 100 lbs. capacity.
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not use any phone in
your building
• immediately call your gas supplier from a neighbor’ s phone.
Follow the gas supplier's instructions
• if you cannot reach you gas supplier , call the fire department.
4. Never install the fireplace
• in a recreational vehicle
• in windy or drafty areas where curtains or other combustible
(flammable) objects can make contact with the fireplace front
• in high traffic areas
5. This fireplace reaches high temperatures. Keep children and adults away from hot surfaces to avoid burns or clothing igni­tion. Fireplace will remain hot for a time after shutdown. Al­low surfaces to cool before touching.
6. Carefully supervise young children when they are in the room with fireplace.
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
SAFETY INFORMATION

LOCAL CODES

PRODUCT IDENTIFICATION

3
3
SAFETY INFORMATION
Continued
7. Do not modify this fireplace under any circumstances. Any parts removed for servicing must be replaced prior to operat­ing fireplace.
8. Turn fireplace off and let cool before servicing, installing, or repairing. Only a qualified service person should install, ser­vice, or repair this fireplace. Have fireplace inspected annu­ally by a qualified service person.
9. You must keep control compartments, burners, and circulat­ing air passages clean. More frequent cleaning may be needed due to excessive lint and dust from carpeting, bedding mate­rial, etc. Turn of f the gas valve and pilot light before cleaning fireplace.
10. Have venting system inspected annually by a qualified service person. If needed, have venting system cleaned or repaired. See Cleaning and Maintenance, page 29.
11. Keep the area around your fireplace clear of combustible ma­terials, gasoline, and other flammable vapor and liquids. Do not run fireplace where these are used or stored. Do not place items such as clothing or decorations on or around fireplace.
12. Do not use this fireplace to cook food or burn paper or other objects.
13. Do not use any solid fuels (wood, coal, paper , cardboard, etc.) in this fireplace. Use only the gas type indicated on fireplace nameplate.
14. This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Ca- nadian Electrical Code, CSA C22.1.
15. Do not use fireplace if any part has been exposed to or under water. Immediately call a qualified service person to arrange for replacement of the unit.
16. Do not operate fireplace if any log is broken.
17. Do not use a blower insert, heat exchanger insert, or other ac­cessory not approved for use with this fireplace.
18. Do not operate fireplace with glass door removed, cracked, or broken.
PRODUCT IDENTIFICATION
Upper Louver Panel
Nailing Flange
Glass Door Assembly
Piezo Ignitor
Control Valve
Lower Louver Panel
Figure 1 - Direct-Vent Fireplace with Millivolt Ignition
Glowing Embers
ON/OFF/REMOTE Switch (Optional Installation)
Blower Switch (BKT Standard with CHDV Models)
Flue Collar
Log Set
Lava Rock
Grate Assembly
LOCAL CODES
Install and use fireplace with care. Follow all local codes. In the absence to local codes, use the current National Fuel Gas Code
ANSI Z223.1/NFPA 54* (USA) or the current CSA-B149.1 Instal­lation Code (Canada).
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
PRODUCT FEATURES PRE-INSTALLATION PREPARATION
4
Location and Space Requirements

PRODUCT FEATURES

These are a few facts that can help you understand and enjoy your direct-vent fireplace:
• The venting system may be routed to the outside of your home
in several ways. It may vent through the roof (vertical) or it may vent to an outside/exterior wall (horizontal). The vent pipe in­stallation is very important to allow for proper operation. You must follow the venting instructions very carefully for either vertical or horizontal applications.
• This fireplace may be installed in any room of your house provided
all local codes and these installation instructions are followed.
• This fireplace does not require electricity to operate.
• Only the blower requires electricity if installed and if you plan
to install the blower at a later date, do not forget to wire the outlet at the bottom of the fireplace when framing.
• A piezo ignitor and ceramic electrode create spark to ignite the
pilot light. It does not require any matches, batteries or any other sources of ignition to light the pilot.
• Each time you turn on your fireplace, you may notice some
amount of condensation on the inside of the fireplace glass. This is normal and will disappear after 10-20 minutes of operation.
• Your direct-vent gas fireplace system (fireplace and venting) is a
balanced and sealed gas operating unit. It requires approximately 10-20 minutes of operating time before the flame pattern stabilizes.
PRE-INSTALLATION
• Your fireplace is designed to be used in zero clearance installa­tions. Wall or framing material can be placed directly against any exterior surface on the back, sides, or top of your fireplace, except where standoff spacers are integrally attached. If stand­off spacers are attached to your fireplace, these spacers can be placed directly against wall or framing material. See framing details on page 5.
• If you plan on installing a television or entertainment center re­cessed above your fireplace, it is recommended that you main­tain a minimum 18" above top of louver opening.
• When locating termination cap, it is important to observe the minimum clearances shown in Figure 7, page 6.
• If recessing into a wall, you can avoid extra framing by position­ing your fireplace against an already existing framing member.
• Do not recess termination cap into a wall or siding.
• You may paint the termination cap with 450ºF (232ºC) heat­resistant paint to coordinate with the exterior finish.
• There must not be any obstruction such as bushes, garden sheds, fences, decks, or utility buildings within 24" from the front of the termination cap.
• Do not locate termination cap where excessive snow or ice build up may occur. Be sure to clear vent termination area after snow falls to prevent accidental blockage of venting system. When using snow blowers, do not direct snow towards vent termina­tion area.
PREPARATION
LOCATION AND SPACE REQUIREMENTS
Determine the safest and most efficient location for your DESA International direct-vent fireplace. Make sure that rafters and wall studs are not in the way of the venting system. Choose a location where the heat output is not affected by drafts, air conditioning ducts, windows or doors. Figure 2 shows some common locations. Be aware of all restrictions and precautions before deciding the exact location for your fireplace and termination cap.
When deciding the location of your fireplace, follow these rules:
• Do not connect this fireplace venting to a chimney flue serving a separate solid-fuel burning fireplace or appliance.
• Due to high temperatures, do not locate this fireplace in high traf­fic areas, windy or drafty areas, or near furniture or draperies.
• Proper clearances must be maintained.
• If your fireplace is to be installed directly on carpeting, vinyl tile, or any combustible material other than wood, it must be installed on a metal or wood panel extending the full width and depth of the fireplace. See Figure 3.
Flush with a wall
Through exterior wall enclosed in a chase
Figure 2 - Common Fireplace Locations
RW
D
FW
Fireplace size D x FW x RW
36" 21 42" 23 1/4" 48" 35 7/8"
CHDV47 23
Figure 3 - Fireplace Bottom Dimensions
1
/8" 41" 29"
1
/4" 48" 35 7/8"
Corner installation
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
PRE-INSTALLATION PREPARATION
Continued
CLEARANCES
Minimum clearances to combustibles for the fireplace are as follows: Back, and sides 0"/mm Perpendicular walls 6" (152mm) Floor 0"/mm Ceiling to louver opening 42" (1067mm) Front 36" (914mm) Top of Standoffs 0"/mm Vent (See venting instructions for
specific venting clearances.)
Combustible material with a maximum thickness of 5/8" may be flush with the top front of fireplace .
PRE-INSTALLATION PREPARATION
Framing and Finishing
B
A
E
D
F G
H
Clearances
C
5
5
Nailing T abs
NOTICE: This fireplace is intended for use as supple­mental heat. Use this fireplace along with your pri­mary heating system. Do not install this fireplace as your primary heat source. If you have a central heat­ing system, you may run systems circulating blower while using fireplace. This will help circulate the heat throughout the house. In the event of a power outage, you can use this fireplace as a heat source.
FRAMING AND FINISHING
Figure 4 shows typical framing of this fireplace. Figure 5 shows framing for corner installation. All minimum clearances must be met.
For available accessories for this fireplace, see Accessories on pages 42 and 43. If you are using a separate combustible mantel piece, refer to Figure 6 for proper installation height. You can install noncombustible mantels at any height above the fireplace.
Note:
Noncombustible mantels may discolor!
36" Models 42" Models CHDV Models
1
A 36 B 41 C 27 D 24
A
B
Figure 4 - Framing Clearances for Installation Against an Exterior Wall
/2" 40 1/2" 40 1/2"
3
/4" 48 3/4" 48 3/4"
3
/8" 29 1/2" 29 1/2"
7
/8" 27" 27"
C Vertical Termination D Horizontal Termination
36" Models 42" Models CHDV Models
3
A 35 B 15" 21 C 49 5/8" 58 1/2" 58 1/2" D 10 E 13 F 41" 48" 48" G 41 H 68
/4" 41 5/8" 41 5/8"
3
/8" 13 1/2" 13 1/2"
3
/4" 16 3/4" 16 3/4"
3
/4" 48 3/4" 48 3/4"
1
/2" 81 1/2" 81 1/2"
5
/8" 21 5/8"
Figure 5 - Framing Clearances for Corner Installation
1 2
A
B
C
D
E
Top of Louver Opening
Ref. Mantel Depth Ref. Mantel from Top
1 14" (356mm) A 16" (406mm) 2 12" (305mm) B 14" (356mm) 3 10" (254mm) C 12" (305mm) 4 8" (203mm) D 10" (254mm) 5 6" (152mm) E 8" (203mm) 6 4" (101mm) F 6" (152mm) 7 2" (51mm) G 4" (101mm)
of Louver Opening
3
4
5 6 7
F
G
Wall
Figure 6 - Clearances for Combustible Mantels
108861
For more information, visit www.desatech.com
For more information, visit www.desatech.com

LOCATION OF TERMINATION CAP

6
LOCATION OF TERMINATION CAP
D
E
V
B
L
V
A = clearance above grade, veranda, porch, deck, or balcony
[*12 inches (305mm) minimum]
B = clearance to window or door that may be opened
[12 inches (305mm) minimum]
C = clearance to permanently closed window [minimum 12 inches
(305mm) recommended to prevent condensation on window]
D = vertical clearance to ventilated soffit located above the terminal
within a horizontal distance of 24 inches (610mm) from the
center-line of the terminal [18 inches (457mm) minimum] E = clearance to unventilated soffit [12 inches (305mm) minimum] F = clearance to outside corner (see below) G = clearance to inside corner (see below) H = *not to be installed above a meter/regulator assembly within
36 inches (914mm) horizontally from the center-line of the regulator
vent shall not terminate directly above a side-walk or paved driveway which is located between two single family dwellings and serves both dwellings* only permitted if veranda, porch, deck or balconey is fully open on a minimum of 2 sides beneath the floor*
* as specified in CAN/SGA B149 (.1 or .2) Installation Codes (1991) for Canada or for U.S.A. installation follow
the current
Note: Local codes or regulations may require different clearances
Termination Clearances for Buildings with Combustible and Noncombustible Exteriors
Inside Corner
C
Fixed
Closed
F
TERMINATION CAP
Openable
V
B
National Fuel Gas Code, ANS Z223.1
V
Outside Corner Recessed Location
Openable
B
AIR SUPPLY INLET
X
Closed
V A
B
Fixed
J
I = clearance to service regulator vent outlet [*72 inches (1829mm) J = clearance to non-mechanical air supply inlet to building or the
K = clearance to a mechanical air supply inlet [*72 inches (1829mm) L = clearance above paved side-walk or a paved driveway located on M = clearance under veranda, porch, deck [*12 inches (305mm) minimum ]
N = clearance above a roof shall extend a minimum of 24 inches (610mm)
N
H
V
B
X
G
minimum] combustion air inlet to any other fireplace [*12 inches (305mm)
minimum] minimum] public property [*84 inches (2133mm) minimum]
above the highest point when it passes through the roof surface and any other obstruction within a horizontal distance of 18 inches (457mm)
G
GAS METER RESTRICTED AREA
I
M
V
(TERMINATION PROHIBITED)
N
G
G
X
K
V
V
A
A
Balcony with No Side Wall
G = 12" (305mm) minimum clearance
A = 6" (152mm)
V
Balcony with Perpendicular Side Wall
G
V
Combustible & Noncombustible H = 24" (610mm) J = 20" (508mm)
Figure 7 - Minimum Clearances for Termination Cap
For more information, visit www.desatech.com
For more information, visit www.desatech.com
D
C
V
B = 6" (152mm)
B
H
V
J
C = Maximum depth of 48" (1219mm) for
recessed location
D = Minimum width for back wall of
recessed location ­Combustible - 38" (965mm) Noncombustible - 24" (610mm)
E = Clearance from corner in
recessed location­Combustible - 6" (152mm) Noncombustible - 2" (51mm)
V
C
E
108861

VENTING INSTALLATION INSTRUCTIONS

VENTING INSTALLATION INSTRUCTIONS
Installation Precautions
7
7
NOTICE: Read these instructions completely be­fore attempting installation.
These models are tested and approved for use with DESA Interna­tional (direct-vent) pipe components and terminations.
The venting system must terminate on the outside of the structure and can not be attached to a chimney or flue system serving a separate solid fuel or gas burning appliance. A direct-vent appliance must have its own venting system. DO NOT common vent this appliance.
These models are approved to be vented either horizontally through an outside wall or vertically through a roof or chase enclosure using the following guidelines:
• When venting system terminates horizontally on an outside wall, you must install a standoff if the termination cap is to be in­stalled directly on a combustible finish such as vinyl, wood, stucco, etc.
• Never run the vent downward as this may cause excessive tem­peratures which could cause a fire.
• V ent pipe air space clearances to combustibles are 1" on all sides except on the horizontal sections, which requires 2" clearance from the top of the pipe. Where the termination cap penetrates a combustible wall, 1" air space clearance is required.
• Snorkel terminations are required when minimum clearance to grade cannot be met (see Figure 16 on page 11).
• Have fireplace and selected vent components on hand to help determine the exact measurements when elbowing or offsetting. Always use wall firestops when penetrating walls and firestops when penetrating ceilings or attic spaces.
• Install horizontal venting with a 1/4" rise for every 12" of run toward the termination.
NOTICE: Failure to follow these instructions will void the warranty.
INSTALLATION PRECAUTIONS
• Wear gloves and safety glasses for protection
• Use extreme caution when using ladders or when on roof tops
• Be aware of electrical wiring locations in walls and ceilings The following actions will void the warranty on your venting
system:
• Installation of any damaged venting component
• Unauthorized modification of the venting system (Do not cut or alter vent components)
• Installation of any component part not manufactured or ap­proved by DESA International
• Installation other than as instructed by these instructions
WARNING: This gas fireplace and vent assembly must be vented directly to the outside. The venting system must NEVER be attached to a chimney serv­ing a separate solid fuel burning appliance. Each direct-vent gas appliance must use a separate vent system. Do not use common vent systems.
WARNING: Vent pipe air space clearances to com­bustibles are 1" on all sides except on the horizontal sections, which require 2" clearances from the top of the pipe. Where the termination cap penetrates a com­bustible wall, 1" air space clearance is required.
WARNING: Read all instructions completely and thoroughly before attempting installation. Failure to do so could result in serious injury, property damage or loss of life.
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
VENTING INSTALLATION INSTRUCTIONS
8
Installation Planning
VENTING INSTALLATION INSTRUCTIONS
Continued
INSTALLATION PLANNING
There are two basic types of direct-vent installation:
• Horizontal T ermination
• Vertical Termination
Horizontal Termination Installation
IMPORTANT:
portion of wall firestop. Horizontal installations using round termi­nation require exterior portion of wall firestop available only in vent kit 01491 for V and VV Series or SDHTRK-58 for CHDV Series (see Figure 14, page 10).
1. Set the fireplace in its desired location and determine the route your horizontal venting will take. Do not secure the fireplace until all venting has been installed. Some installations require sliding the fireplace in and out of position to make final vent­ing connections. Figures 14 through 18 on pages 10 through 12 show different configurations for venting with horizontal termination that will help you decide which application best suits your installation. Check to see if wall studs or roof rafters are in the path of your desired venting route. If they are, you may want to adjust the location of the fireplace.
2. Direct vent pipe sections and components are designed with special twist-lock connections.
Twist-Lock Procedure: The female ends of the pipes have
locking lugs (indentations). These lugs will slide straight into matching slots on the male ends of adjacent pipes. Push pipe sections together and twist one section clockwise approxi­mately one-quarter turn until the sections are fully locked (see Figure 8). ported every three feet. Use wall straps for this purpose.
3. Use a 45° elbow to connect venting system to fireplace flue col­lar. The elbow is designed to be twist-locked onto the flue collar as described in step 2. configuration of the elbow by cutting, twisting, bending, etc.
4. Assemble the desired combination of pipe and elbows to the fireplace flue collar. If there are long portions of venting run, pre-assembled pipe sections may be installed as subassemblies for convenience.
5. Carefully determine the location where the vent pipe assembly will penetrate the outside wall. The center of the hole should line up with the center-line of the horizontal vent pipe. Mark the wall for a 10 3/4" x 10 3/4" square hole. Cut and frame the square hole in the exterior wall where the vent will be terminated. If the wall being penetrated is constructed of noncombustible material, such as masonry block or concrete, a 8 1/2" hole with zero clearance is acceptable (see Figure 9).
Horizontal square terminations require only inner
Note:
Horizontal runs of vent must be sup-
IMPORTANT :
Do not attempt to alter the
Female Locking Lugs
Figure 8 - Vent Pipe Connections
Vent Opening
Combustible Wall
3
/4"
10
(273mm)
3
10
/4"
(273mm)
Vent Opening
Noncombustible Wall
8 1/2"
(216mm)
Figure 9 - Vent Opening Requirements
10 3/4" Inside Framing
(273mm)
(Framing
Detail)
Male Slots
Center of Hole
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
VENTING INSTALLATION INSTRUCTIONS
Continued
WARNING: Do not recess vent termination into
any wall. This will cause a fire hazard.
6. Noncombustible Exterior Wall: Position the horizontal vent cap in the center of the 8 1/2" round hole and attach to the exte­rior wall with four wood screws provided. Before attaching the vent cap to exterior wall, run a bead of non-hardening mastic (pliable sealant) around the outside edges to make a seal be­tween it and the outside wall. provided should be replaced with appropriate fasteners for stucco, brick, concrete, or other types of sidings.
Combustible Exterior W all: For vinyl siding, stucco, or wood
exteriors, a siding standoff must be installed between the vent cap and exterior wall. The siding standoff prevents excessive heat from damaging the siding materials. Siding material must be cut to accommodate standoff. Bolt the vent cap to the stand­off. Apply non-hardening mastic around outside edge of stand­off. Position the standoff/cap assembly in the center of the 10
3
/4" square hole and attach to exterior wall with wood screws provided (see Figure 11). The siding standoff must sit flush against the exterior fascia material.
7. Slide the wall firestop over the vent pipe before connecting horizontal run to vent cap (see Figure 12).
8. Carefully move fireplace, with vent assembly attached, toward wall and insert vent pipe into horizontal termination. The pipe overlap should be a minimum of 11/4".
Note:
The four wood screws
VENTING INSTALLATION INSTRUCTIONS
Installation Planning (Cont.)
Cut Siding Away to Fit Standoff
Standoff
Apply Mastic to All Four Sides
Figure 11 - Installing Siding Standoff
Interior Wall Surface
Vent Cap (Horizontal Termination)
Wood Screw
Vent Cap
Screws
Wall Firestop
Horizontal Vent Pipe
9
9
Apply Mastic to All Four Sides
Figure 10 - Installing Horizontal Vent Cap
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
Vent Cap
Wood Screw
Screw
Figure 12 - Connecting Vent Cap with Horizontal Vent Pipe
VENTING INSTALLATION INSTRUCTIONS
10
Installation Planning (Cont.)
VENTING INSTALLATION INSTRUCTIONS
Continued
9. Slide wall firestop against interior wall surface and attach with screws provided. See Figure 13 for horizontal termination details.
10. Place fireplace into position and shim with noncombustible ma­terial if needed. Nail or screw side flanges to framing to secure unit in place. securing. If fireplace is not level it will not work properly .
Direct Vent Pipe
IMPORTANT:
Minimum Pipe Overlap 1
Wall Firestop
1
/4"
Make sure fireplace is level before
Siding Standoff
Screws
WARNING: Never run vent downward as this may cause excessive temperatures which could cause a fire. Operation of improperly installed and main­tained venting system could result in serious injury, property damage or loss of life.
GROUND FLOOR INSTALLATION
Recommended Applications:
• Installation using cabinet surrounds
• Through the wall using round or square termination (up to 12" horizontal pipe)
• NOT FOR CORNER INSTALLATION
45° Elbow Horizontal High Wind Square Termination
Maintain 1" Minimum Air Space Around Outer Pipe When Penetrating a Wall
3
/4" x 10 3/4"
10 Framed Opening
Figure 13 - Typical Horizontal Termination Cap Mounting with Additional Siding Standoff Installed
High Wind Termination
Apply Mastic to Outside Edge of Standoff
Exterior Wall with Vinyl Siding
Horizontal Termination Configurations
Figures 14 through 18 show different configurations and alternatives for venting with horizontal termination. Each figure includes a chart with critical minimum and maximum dimensions which MUST be met.
IMPORTANT:
have a 1/4" rise for every 12" of run toward the termination.
Remember that a horizontal run of venting must
Adjustable Pipe 12" Max.
Wall Firestop
Square Termination
Vertical (V) Horizontal (H)
V36 Series 35" min. 17" max. V42 Series 39" min. 17" max. CHDV Series 39" min. 17" max.
45° Elbow
Wall Firestop
Exterior Portion of Wall Firestop (Round Termination Only)
Round Termination (Kit 01491 for V36, V42 Series Kit SDHTRK-58 CHDV Series)
Horizontal Round Termination
Figure 14 - Horizontal Termination Configuration for Square or Round Terminations
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
VENTING INSTALLATION INSTRUCTIONS
Continued
VENTING INSTALLATION INSTRUCTIONS
Installation Planning (Cont.)
11
11
CORNER INSTALLATION
Recommended Applications:
• Corner ground floor installation
• Ground floor installation where pipe vents horizontally through wall (over 12" horizontal pipe)
• Basement installation where one foot clearance from ground to
36" 42" CHDV Vertical Pipe (36"/42")
1
/2" min. 50 1/2" min. 50 1/2" min. None 30" max.
*46
1
/2" min. 61 1/2" min. 61 1/2" min. 1 ft. 48" max.
57
1
69
/2" min. 73 1/2" min. 73 1/2" min. 2 ft. 60" max.
1
/2" min. 85 1/2" min. 85 1/2" min. 3 ft. 84" max.
81
1
/2" min. 97 1/2" min. 97 1/2" min. 4 ft. 20' max.
93
* Ground Floor Corner Venting
Vertical (V) Required Horizontal (H)
termination is possible
Not to Exceed (H) Limits
Square Termination
Wall Firestop
Figure 15 - Horizontal Termination Configuration for Corner Installation Using One 90° Elbow
45° Elbow
90° Elbow As Required for (V)
See Chart for Pipe Section Required
Not to Exceed (H) Limits
90° Elbow
Wall Firestop
45° Elbow
Square Termination
12" Minimum
SNORKEL TERMINATION INSTALLATION
Recommended Applications:
• Installations requiring a vertical rise on building exterior
• Any installation using snorkel termination to achieve one foot above ground
Snorkel terminations are available for installations requiring a vertical rise on the exterior of the building. If installing snorkel termination below grade, you must provide proper drainage to prevent water from entering snorkel termination (see Figure 16). Do not back fill around snorkel termination.
Snorkel Termination
12"
Minimum
Figure 16 - Snorkel Termination Configurations for Below Ground Installation
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
Snorkel Termination
12"
Minimum
Adequate Drainage
90° Elbow
45° Elbow
Wall Firestop
Snorkel Termination
12"
Minimum
VENTING INSTALLATION INSTRUCTIONS
12
Installation Planning (Cont.)
VENTING INSTALLATION INSTRUCTIONS
Continued
HORIZONTAL SYSTEM INSTALLATION USING TWO 90° ELBOWS
The following configurations show the minimum vertical rise requirements for a horizontal system using two 90° elbows.
Venting with Two 90° Elbows
Vertical (V) Horizontal (H1) Horizontal (H1) +
Horizontal (H2)
5' min. 2' max. 6' max. 6' min. 4' max. 12' max. 7' min. 6' max. 18' max. 8' min. 8' max. 20' max.
20' max. 8' max. 20' max.
45°Elbow
Figure 17 - Horizontal Termination Configuration for Venting Using Two 90° Elbows
Venting with Two 90° Elbows
Vertical (V) Horizontal (H1) +
Horizontal (H2)
5' min. 6' max. 6' min. 12' max. 7' min. 18' max. 8' min. 20' max.
20' max. 20' max.
45° Elbow
Figure 18 - Horizontal Termination Configuration for Venting Using Two 90° Elbows with Termination at 90° with Fireplace
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
VENTING INSTALLATION INSTRUCTIONS
Continued
VENTING INSTALLATION INSTRUCTIONS
Installation for Vertical Termination
13
13
INSTALLATION FOR VERTICAL TERMINATION
Note:
Vertical restrictor must be installed in all vertical installations.
1. Determine the route your vertical venting will take. If ceiling
joists, roof rafters, or other framing will obstruct the venting system, consider an offset (see Figure 19) to avoid cutting load bearing members. lation instructions for required clearances (air space) to com­bustibles when passing through ceilings, walls, roofs, enclo­sures, attic rafters, etc. Do not pack air spaces with insulation. Also note maximum vertical rise of the venting system and any maximum horizontal offset limitations.
2. Set the fireplace in desired location. Drop a plumb line down
from the ceiling to the position of the fireplace exit flue. Mark the center point where the vent will penetrate the ceiling. Drill a small locating hole at this point.
Drop a plumb line from the inside of the roof to the locating hole in the ceiling. Mark the center point where the vent will penetrate the roof. Drill a small locating hole at this point.
Wall Strap
Figure 19 - Offset with Wall Strap and 45° Elbows
Flat Ceiling Installation
1. Cut a 10 3/4" square hole in the ceiling using the locating hole as
a center point. The opening should be framed to 10 3/4"x10 3/4" (273mm x 273mm) inside dimensions, as shown in Figure 9 on page 8 using framing lumber the same size as the ceiling joists. If the area above the ceiling is an insulated ceiling or a room, nail firestop from the top side. This prevents loose insulation from falling into the required clearance space. Otherwise, in­stall firestop below the framed hole. The firestop should be in­stalled with no less than three nails per side (see Figure 20).
Note:
Pay special attention to these instal-
Roof Flashing
45° Elbow
Ceiling Firestop
2. Assemble the desired lengths of pipe and elbows necessary to reach from the fireplace flue up through the firestop. Be sure all pipe and elbow connections are fully twist-locked (see Fig­ure 8, page 8).
3. Cut a hole in the roof using the locating hole as a center point. (Cover any exposed open vent pipes before cutting hole in roof.) The 10 actual length may be larger depending on the pitch of the roof. There must be a 1" clearance from the vent pipe to combustible materials. Frame the opening as shown in Figure 9, page 8.
4. Connect a section of pipe and extend up through the hole.
Note:
support the vent pipe every 3 feet. Use wall straps for this purpose (see Figure 19). Whenever possible, use 45° elbows instead of 90° elbows. The 45° elbow offers less restriction to the flow of the flue gases and intake air.
5. Place the flashing over the pipe section(s) extending through the roof. Secure the base of the flashing to the roof and fram­ing with roofing nails. Be sure roofing material overlaps the top edge of the flashing as shown in Figure 19. There must be a 1" clearance from the vent pipe to combustible materials.
6. Continue to add pipe sections until the height of the vent cap meets the minimum building code requirements described in Figure 7 on page 6. steep roof pitches. Nearby trees, adjoining rooflines, steep pitched roofs, and other similar factors may cause poor draft or down-drafting in high winds. Increasing the vent height may solve this problem.
7. Twist-lock the vent cap onto the last section of vent pipe.
Note:
floor, including storage spaces and closets, you must enclose pipe. You may frame and sheetrock the enclosure with standard construction material. Make sure and meet the minimum allowable clearances to combustibles. Do not fill any of the required air spaces with insulation.
If area above is a room, install firestop above framed hole.
Figure 20 - Installing Firestop
3
/4"x10 3/4" hole must be measured on the horizontal;
If an offset is needed to avoid obstructions, you must
Note
: You must increase vent height for
If the vent pipe passes through any occupied areas above the first
If area above is not a room, install firestop below framed hole.
108861
For more information, visit www.desatech.com
For more information, visit www.desatech.com
VENTING INSTALLATION INSTRUCTIONS
14
Installation for Vertical Termination (Cont.)
VENTING INSTALLATION INSTRUCTIONS
Continued
Vertical Termination Configurations
Figures 21 through 24 show four different configurations for verti­cal termination.
Venting with Two 90° Elbows
Vertical (V) Horizontal (H1) +
Horizontal (H2)
5' min. 2' max. 6' min. 4' max. 7' min. 6' max. 8' min. 8' max.
20' max. 8' max.
45° Elbow
Note:
Install restrictor into inner collar of fireplace as shown.
Venting with One 90° Elbow
Vertical (V) Horizontal (H)
5' min. 2' max. 6' min. 4' max. 7' min. 6' max. 8' min. 8' max.
20' max. 8' max.
45° Elbow
Figure 22 - Vertical Venting Configuration Using One 90° Elbow (Vertical Round High Wind Termination Shown)
Note:
Install restrictor into inner collar of fireplace as shown.
Figure 21 - Vertical Venting Configuration Using Two 90° Elbows with Two Horizontal Runs (Vertical Round High Wind Termination Shown)
Venting with Two 90° Elbows
Vertical (V1) Horizontal (H)
5' min. 6' max. 6' min. 12' max. 7' min. 18' max. 8' min. 20' max.
Note:
Install restrictor into inner collar of fireplace as shown.
45° Elbow
Note:
Vertical (V1) + Vertical (V2) = 40' max.
Figure 23 - Vertical Venting Configuration Using Two 90° Elbows (Vertical Round High Wind Termination Shown)
For more information, visit www.desatech.com
For more information, visit www.desatech.com
108861
Loading...
+ 30 hidden pages
